MBRK/BRK Series
DCFANKIT-4/IDCFANKIT-4 FAN KIT
Instruction Sheet
I-00276 Rev C
TOOLS REQUIRED
#2 Phillips screwdriver
PARTS
(International Model
IDCFANKIT-4 Only)
Fan Panel
(1) Inline Thermostatic Controller
(1)
#6 X 3/8 Wood Screw
(3) #10 X 5/8 Wood Screw (5) #10-32 Truss Head Rack Screw (4) Cable Tie Mount
(5)
12 Volt DC, 0.5 Amp Power Supply
(Used with IDCFANKIT-4)
(1)
12 Volt DC, 0.5 Amp Power Supply
(Used with DCFANKIT-4)
(1)
Wire Tie
(12)
INSTALLATION
NOTE: For optimal thermal management, this DCFANKIT-4/IDCFANKIT-4 Fan Kit must be used with
MAP's RK-RAPxx Rear Access Panel.
1) Remove Top Panel from the rear of the rack, if installed. (See FIGURE A)
TOP PANEL
REAR
FIGURE A

Page 2
INSTALLATION (Continued)
JUMPER SETTINGS: The Inline Thermostatic Controller comes with the jumper
installed in the AUTO position (2 center pins) which turns fans on at 87ºF (30.5ºC)
and turns fans off at 85ºF (29.4ºC). (See FIGURE B)
Jumper installed in the ON (2 right pins) position keeps fans on continuously.
Jumper installed in the OFF (2 left pins) position keeps fans off.
FACTORY SHIPPED WITH JUMPER
INSTALLED IN THE AUTO POSITION
ALWAYS OFF
POSITION
CONSTANT ON
POSITION
JUMPER FIGURE B
INLINE THERMOSTATIC
CONTROLLER
2) Install the controller inside the rack using two #6 X 3/8 wood screws. Do not overtighten.
(See FIGURE C)
NOTE: It is recommended that the Controller
be installed at the highest location on the side
panel with the most amount of heat, near the top
panel, as close to the center of the side panel as
possible without obstruction from components.
(See FIGURE C)
REAR
FRONT
FIGURE C
INLINE THERMOSTATIC
CONTROLLER
FRONT
RACKRAIL
REAR RACKRAIL
(OPTIONAL ON
18" BRK)
AUTO POSITION

Page 3
INSTALLATON (Continued)
3) Install the Fan Panel into the rear of the rack using four
#10-32 Truss Head rack screws. (See FIGURE D)FRONT
NOTE: Fan panel cord is routed to either
the left or right side of fan panel,
depending on which side panel the
Inline Thermostatic Controller is
mounted.
FIGURE D
2 SPACE RACKRAIL
(SUPPLIED WITH RK-RAPxx
REAR ACCESS PANEL)
REAR
FAN PANEL
FAN PANEL CORD
FAN PLUG
4) Install fan plug into either the FAN 1 or FAN 2 position. (See FIGURE E)
FIGURE E
5) Install power supply plug into POWER INPUT. (See FIGURE F)
FIGURE F
POWER SUPPLY PLUG

WARRANTY
Middle Atlantic Products (the "Company") warrants the Fan Kit (DCFANKIT-4/IDCFANKIT-4) to be free from defects in material or workmanship under normal use and conditions for a period of (3) years from
date of shipment by the Company.
The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and exclusive remedy, under this warranty shall be limited, at the Company's option, to either (a) return of and
refund of the price paid for, or (b) repair or replacement at the Company's factory of the products purchased, or any part or parts thereof, which the Company has determined to be defective after inspection
thereof at the Company's factory.
This warranty does not cover damage due to acts of God, accident, misuse, abuse or negligence by parties other than the Company, or any modification or alteration of the products. In addition, this warranty
does not cover damage due to improper handling, assembly, installation or maintenance.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE
OF THE PRODUCTS PURCHASED, EVEN IF THE COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE COMPANY'S LIABILITY TO THE PURCHASER (OR ANY OTHER
PARTY) HEREUNDER, IF ANY, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCTS PAID TO THE COMPANY.
Corporate Headquarters Middle Atlantic Canada Factory Distribution
Corporate Voice 973-839-1011 - Fax [phone] Voice 613-836-2501 - Fax [phone] USA: NJ - CA - IL Canada: ON - BC
International Voice [phone] - Fax [phone] middleatlantic.ca - [email protected]
middleatlantic.com - [email protected]
At Middle Atlantic Products we are always listening. Your comments are welcome. Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company.
30% Recycled Paper
Page 4
INSTALLATON (Continued)
FAN PANEL CORD
6) Route the fan panel and power supply cords along the side
panel using the provided cable tie mounts and wire ties as
needed. (See FIGURE G)
TIP: Fold excess fan panel cord into a neat bundle and tie
onto cable tie mounts with included wire ties.
SIDE PANEL
FRONT
IN LINE THERMOSTATIC
CONTROLLER
POWER SUPPLY
CORD
CABLE TIE MOUNTS
(AS NEEDED)
WIRE TIES
(AS NEEDED)
POWER SUPPLY
REAR RACKRAIL
REAR FIGURE C
7) Select the appropriate wall plug adapter supplied with the power supply for your region, and install
into the power supply. Connect power supply to power source.
NOTE: To remove a wall plug adapter, press tab labeled PUSH, while simultaneously turning plug
counterclockwise and lift out. To install a wall plug adapter, properly orient the wall plug adapter and
insert into the power supply and turn plug slightly clockwise until a clicking sound is heard.
(FOR INTERNATIONAL MODEL IDCFANKIT-4 ONLY)
