Midea MAC-200U User manual

Buku Manual
Model: MAC-200U
AIR COOLER
Please read this manual carefully before running this appliance
and save it for reference

,PSRUWDQW6DIHJXDUGV
)HDWXUHV
0RGHO6SHFLILFDWLRQ
.QRZ<RXU$LU&RROHU
+RZWR$VVHPEOHDQG8VH
 
+RZWR&OHDQDQG0DLQWDLQ
 
7URXEOHVKRRWLQJ

1. Non-specialized personnel or unauthorized repair personnel shall not to repair or modify the
machine.
2. It is forbidden to operate with wet hands to avoid electric shock.
3. Any power cord, which suffers from aging and knotting and whose plug is damaged, should
be stopped its use immediately,and must be repaired by a professional manufacturer or
equally qualified personnel.
4. If the unit is not in use for a long time, unplug the power cord.
5. To prevent accidental injury or damage to the unit, please donot insert any foreign matter
into the air inlet and outlet,because the unit incorporates a high-speed wind rotor.
6. It is prohibited to use this unit in environments with flammable and explosive gases and
direct sunlight for a long period shall be avoided.
7. Do not place this unit in an inclined or other uneven place toprevent the unit from falling
and causing damage to the unit or internal parts.
8. This machine is suitable for indoor use instead of outdoor use.
9. This machine has a safety switch. If the honeycomb filter support has not been installed
well, the unit will not work as usual; when the machine is working, do not remove the
honeycomb filter frame.
10.At any time the water level in the tank shall not exceed "MAX"(maximum) scale, and during
humidification, the total water level in the tank shall be controlled, and shall not be below
"MIN" (minimum) scale.
11.After the water tank is filled with water, do not tilt or collide with the unit when placing or
moving it. To move the unit body,please drive it slowly from the side to prevent water overflow.
12.In using the unit, prohibit overturning to avoid any accident.If the unit topples over accidentally,
and it contains water,unplug the power cord immediately and take it to repair store.
13.Do not place items on the unit, and covering the outlet is strictly prohibited.
14.When wash the unit appearance, apply a damp cloth (or adda little cleaning agent) to wipe,
and never use corrosive cleaning agent or solvent for cleaning. Never rinse the unit with water.
15.Do not have the air inlet and outlet of the unit close to walls,curtains and other objects, or
they may block the airflow and affect air supply.
16.When the unit is running, do not knock at or shock the unit body forcibly or it may lead to
automatic shutdown, in whichcase simply restart the unit.
17.Do not place the unit directly below the power outlet.
18.Do not use the unit around the tub, sprinkler or swimming pool.
19.Appliance is not to be used by children or persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction.
20.Unplug the appliance during filling and cleaning.
1. 3 Speed Settings & 7 Hours Timer
There are 3 speed settings,low,middle,high,and 7 hours timer.
2. Remote Control
Let you operate the unit as far as 6 metres away from it.
3. Built-in Ionizer
Produce negative ions and quickly make air fresh.
21.Children should be supervised to ensure that they do not play with the appliance.

408X280X760mm
MAC-200U
220-240V～50Hz
50W
7.1KG
Remote control
Ice box
Water tank
Water tank cover
Filter frame Pre-filter

1. Unfold the package and take out the air cooler,put it on the ground.
2. Check out the spare part.
3. Install the universal wheel: take out the universal wheel and install it on the air cooler.
(Fig.1)
4. Watering: Pull out the water tank from the body about 1/3, and pour water into the
water tank. If you want to pull out the water tank, please pull out after power-off 2
minutes.
Attention:
�*Pay attention to the Water line when watering.
�*When watering, the water must not be higher than the“MAX”water line. When
humidifying, the water must not be lower thanthe “MIN” water line.
* If you want to increase the cooling e ffect, you can put the frozen ice box into the
water tank. (Fig.2)
5. Check the power cord to find whether it is same with the rating label.
6. Turn the power switch to “I”
Connect the power cord, and then turn on the power button.
Attention:
�*Do not connect the power cord with a wet hand.
�*When remove the machine, please pull out the power cord.
�*When connect the power cord, please make it contact well.
Fig.1
wheels
water tank
Add water and
Frozen ice box
Fig.2
Prepare to Operate
Control board
ON/OFF
TIMER NATURAL SPEED OSC.
ION
EVA. /
COOLER

7、
EVA./COOLER: Press the EVA./COOLER key once . The unit will act as a evaporator now .
If combined with Ice box, this unit can lower its surrounding about 3 C.
1、ON/OFF: Plug the unit into an electric outlet, the until will be ready to run. Press the ON/OFF
key to start running.
2、 OSC.: Press the OSC. key once to turn on the oscillation and the wind will oscillate in
horizontally 120 degrees, press it again to stop.
3、 SPEED: When the air cooler is turned on, the fan will run at medium speed for 3 seconds
before running at low speed(default speed). Press the SPEED key each time, the fan speed
will recycle as shown below:
4、
STYLE / NATURAL: Press the NATURAL key once to turn on this feature. Controlled by
the special program in the microcomputer chip, the fan will be switched among high speed,
medium speed, low speed and stop automatically according to the default settings. it is
simulated like natural breeze.
5、
TIMER: When the air cooler is running, press the TIMER key to preset the running time,
and the presetting time will recycle each time pressing this key as shown below:
6、
ION: press this key, the function of Anion is turned on. Press the button, this function is
Ice Box
3. Prepare the two Ice Boxes for the unit, insure continuously use.
Ice Box could slowly absorb the heat in the water to keep the temperature in the water tank lower than
that of environment, which ensures the air cooler blows cooler wind:
1. Please put the Ice Box into the refrigeratory, make the liquid in the Ice Box freeze completely.
2. Remove the pre-filter by pulling its handle upward, then pull the filter out put the Ice Box into the
water tank.
turned off.

Warning:
Prior to cleaning or other maintance, the Air cooler must cut off the power and pull out
the plug;
Non-professional maintenance personnel, please don't dismantle the power cord.
water tank
Add water and
Frozen ice box
Fig.2
Fig.3 Fig.4
Take out the
filter frame
honey comb filter
Per fig.2 fig 3 and fig 4: Unplug the unit for two minutes, take out filter, filter frame, honey
comb filter and water tank seperately, wash them with detergent and soft brush, then put
them back to the unit.
Remote Controller
1.Open the remote controller rear cover and set a CR2032
battery; then the remoter controller
can be used. It has
thesame button with the control board.
2.The effective distance for the remote controller is 6 meter.
1. If curtains, doors or other objects disturb the remote control from giving signals. the unti may
not receive the remote control signals normall
y.
2. In the room with lamps of instant electrical lightening, the remote control may be influenced.
Please keep it away from the lamp or change a direction.
3.Be sure to avoid direct sunshine on the unit. Otherwise, the remote control signals may not be
received sometimes.
ION
ON/OFF
SPEED
EVAPORATOR
TIMEROSC.
STYLE
NOTE:

No. 28, East Area, Hesui Industrial Park, Dongfu Rd.,Dongfeng Town, Zhongshan City, Guangdong, China
Web Site:global.midea.com.cn
GD Midea Environment Appliances Manufacturing CO.,LTD.
