Midea MHC90GSS User manual

SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your cooker hood,and keep it
carefully. If you follow the instructions, your cooker hood will provide you with many years
of good service.
Cooker Hood
Midea
Instruction
MODEL : MHC60GSS
MHC90GSS

2
RECOMMENDATIONS AND SUGGESTIONS
The instructions for Use apply to several versions of this appliance. Accordingly, you
may find descriptions of individual features that do not apply to your specific appliance.
INSTALLATION
The manufacturer will not be held liable for any damages resulting from incorrect or
improper installation.
The minimum distance between the supporting surface for the cooking vessels on the
hob and the lowest part of the range hood. ( When the range hood is located above a
gas appliance, this distance shall be at least 65 cm. If the instructions for installation for
the gas hob specify a greater distance, this has to be taken into account. The distance of
65 cm can be reduced for:non-combustible parts of range hoods, andparts operating at
safety extra low voltage,Provided these parts do not give access to live parts if deformed ;)
Check that the mains voltage corresponds to that indicated on the rating plate fixed to
the inside of the hood.
For Class I appliances, check that the domestic power supply guarantees adequate
earthing.
Connect the extractor to the exhaust flue through a pipe of minimum diameter 120mm.
The route of the flue must be as short as possible.
The air must not be discharged into a flue that is used for exhausting fumes from
appliances burning gas or other fuels.
If the extractor is used in conjunction with non-electrical appliances (e.g. gas burning
appliances),a sufficient degree of aeration must be guaranteed in the room in order to
prevent the backflow of exhaust gas. The kitchen must have an opening
communicating directly with the open air in order to guarantee the entry of clean air.
When the cooker hood is used in conjunction with appliances supplied with energy
other than electric, the negative pressure in the room must not exceed 0,04 mbar to
prevent fumes being drawn back into the room by the cooker hood.
zIf the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Regulations concerning the discharge of air have to be fulfilled.
USE
z The cooker hood is only for home use, not suitable for barbecue, roast shop and other commercial purposes.
Never use the hood for purposes other than for which it has been designed.
Never leave high naked flames under the hood when it is in operation.
Adjust the flame intensity to direct it onto the bottom of the pan only, making sure that
it does not engulf the sides.
Deep fat fryers must be continuously monitored during use: overheated oil can burst
into flames.
Do not flame under the range hood; risk of fire.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
“CAUTION: Accessible parts may become hot when used with cooking appliances”.
MAINTENANCE
Switch off or unplug the appliance from the mains supply before carrying out any
maintenance work.
Clean and/or replace the Filters after the specified lime period (Fire hazard).
Clean the hood using a damp cloth and a neutral liquid detergent.
The appliance uses 4 hob elements at most.
The cooker hood and its filter should be cleaned regularly according to the instruction.

COMPONENTS
3
Ref.
Qty.
Product Components
1
1
Hood Body, complete with: Controls, Light,
Blower, Filter.
2.1
1
Lower Decorative Chimney
2.2
1
Upper Decorative Chimney
3
1
Flange ( optional )
4
1
Exhaust Pipe
5
2
The Activated Charcoal filter ( optional )
Ref.
Qty.
Installation Components
7
11 7
12 6 ( 2 Spare)
13 4
14 4
4 2
M4 x 20
Decorative washers
20 1 Hood fixing bracket
21 2 Chimney fixing bracket
Qty. Documentation
1 Instruction Manual
15 4Spare
2.2 4
3
2.1
5
122
20 12 10
21 13 11
15 14
22 1 Glass panel

DIMENSIONS
4
650mm
Min.
650mm
Min.
448
391
600/900
500
322
500
401
282
322
282
500
600/900
448
min.
448
max.
828

INSTALLATION
WALL DRILLING AND BRACKET FIXING
5
As a first step, proceed with the following drawings:
A vertical line up to the ceiling or up to the upper limit, at the center of the area in which the
hood is to be fitted.
A horizontal line A at 1083–1183 mm above the cooker top.
A horizontal line B at a 40-377mm above the horizontal line A.
A horizontal line C at a 116mm below the horizontal line A.
Mark Points:
Mark a point (1) on the horizontal line A, 60 mm to the vertical reference line.
Repeat this operation on the other side , checking that the two marks are leveled.
Mark a point (2) on the horizontal line B, 60 mm to the vertical reference line.
Repeat this operation on the other side , checking that the two marks are leveled.
8080
6060
6060
1083-1183
116
40-377
A
C
B
Vertical reference line
(2)
(1)
(3)

Fix the brackets (Optional):
CONNECTIONS
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the chimney
using either a flexible or rigid pipe ɸ 150 or ɸ 120 mm, the choice of
which is left to the installer.
To install a ɸ 120 mm air exhaust connection, insert the reducer
flange 3 on the hood body outlet.
Fix the pipe 4 in position using sufficient pipe clamps (not
supplied).
Remove possible charcoal filters.
6
Drill holes at the marked points with a ɸ10 mm drill bit.
Insert the Wall Plugs 11 into the holes.
Fix the hood fixing bracket 20 with 3 screws 10 (5 x 50) at the horizontal line A,
Fix a Chimney fixing bracket 21 with 2 screws 10 (5 x 50) at the horizontal line B.
Mark a point (3) on the horizontal line C, 80 mm to the vertical reference line.
Repeat this operation on the other side and on the vertical reference line , checking that
the three marks are leveled.
Hook the hood body to the bracket 20.
Level the hood body itself.
Fix the exhaust pipe on the hood body.
Connect the Chimney fixing bracket 21 and Lower Decorative Chimney2.1
Fix the Chimney fixing bracket 21 with 2 screws 10 (5 x 50) at the horizontal line A to prevent the
hood body from accidently sliding off the hood fixing bracket.
Hook the hood body
B
A
Right Wrong

7
CHIMNEY ASSEMBLY
The chimney can only be installed with exhausting hood.
Lower Decorative Chimney
Fix a Chimney fixing bracket 21 onto the Lower Decorative Chimney with 2 screws 12
(4.2 x 9.5) supplied with the hood.
Upper Decorative Chimney
Slightly widen the two sides of the upper chimney and hook them between the wall and the
bracket 21 which is fixed on the Lower Decorative Chimney.
Fix the upper chimney onto the bracket 21 with 2 screws 12 (4.2 x 9.5) supplied with the hood.
21
2.1
12

8
USE
ON/OFF LIGHTING SWITCH: Press on this switch to turn on the
lights, and press again to turn them off.
OFF MOTOR SWITCH: Press on this switch to stop the motor
operation.
SPEED SWITCH: Press on this switch, the motor runs at LOW
speed.
SPEED SWITCH: Press on this switch, the motor runs at
MEDIUM speed.
SPEED SWITCH: Press on this switch, the motor runs at HIGH
speed.

MAINTENANC
GREASE FILTERS
CLEANING METAL SELF-SUPPORTING GREASE FILTERS
The filters must be cleaned every 2 months of operation, or
more frequently for particularly heavy usage, and can be
washed in a dishwasher.
Pull the comfort panels to open them.
Remove the filters one by one pushing them towards the back
side of the hood unit and simultaneously pulling downwards.
Any kind of bending of the filters has to be avoided when
washing them. Before fitting them again into the hood make sure
that they are completely dry. (The color of the filter surface may
change throughout the time but this has no influence to the filter
efficiency).
When fitting the filters into the hood pay attention that they are
mounted in correct position the handle facing outwards.
Close the comfort panel.
ACTIVATED CHARCOAL FILTER (RECIRCULATION VERSION)
These filters are not washable and cannot be regenerated, and must be replaced approximately
every 4 months of operation, or more frequently with heavy usage.
REPLACING THE ACTIVATED CHARCOAL FILTER
Open the comfort panels pulling them downwards.
Remove the metal grease filters.
Remove the saturated activated charcoal filter.
Fit the new filters.
Replace the metal grease filters.
Close the comfort panel.
9
REMOVE
REMOVE
FIX
FIX


10
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old
household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old
appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain,
and reduce the impact on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the
appliance, it must be separately collected.
Consumers should contact their local authority or retailer for information concerning the correct disposal of their old
appliance.
LED LIGHT REPLACEMENT
',60$17/(/('/,*+702'8/(
:KHQFKDQJLQJWKHOLJKWPRGXOHVWKHFRQWDFWVDUHOLYH
Before changing the light module(s), unplug the appliance from the mains or switch off the
circuit breaker in the fuse box.
Replacing the light modules
2. Lower the control panel at the front by carefully pulling it downwards. You can now access the
light module and terminals.Replace the lamp(commercially available LED lamp (max.1.5w).
YRXFDQQRWUHSODFHGWKHOLJKWEXOEVWKHHQWLUHOLJKWPRGXOHKDVWREHUHSODFHG
5HPRYHWKHJUHDVHILOWHUDQGFDUHIXOO\UHPRYHWKHVFUHZVIURPHDFKVLGHRQWKHRSHQLQJD
FURVVKHDGHGVFUHZGULYHUZLOOEHQHHGHGWRUHPRYHWKHVFUHZV
1.



Max Power Voltage Picture Lamp Cap ILCOS D code
1.5W DC 12 V —— DSR-1.5-S-70
Round/ Diameter
: 70mm

TROUBLE SHOOTING
Fault
Cause
Solution
Light on, but
motor does not
work
The blades are blocked.
The capacitor is damaged.
Replace capacitor.
The motor is damaged.
Replace motor.
The internal wiring of motor is cut off/
disconnected. An unpleasant smell
may be produced.
Replace motor.
Both light and
motor do not
work
Apart from the above mentioned, check the following:
Light damaged.
Replace lights.
Power cord loose.
Connect the wires as per the electric
diagram.
Oil leakage
Outlet and the air ventilation entrance
are not tightly sealed.
Take down the outlet and seal with glue.
Leakage from the connection of
U-shaped section and cover.
Take U-shaped section down and seal
with soap or paint.
Vibration
The blade, if damaged, can cause
vibrating.
Replace the blade.
The motor is not tightly fastened.
Fasten the motor tightly.
The cooker hood is not tightly fixed.
Fixed the cooker hood tightly.
Insufficient
suction
The distance between the cooker
hood and the cooker top is too large.
Readjust the distance.
Too much ventilation from open doors
or windows.
Choose a new place to install the
appliance or close some doors / windows.
The
machine
inclines
The fixing screws are not tight
enough.
Tighten the fixing screw and make it
horizontal.
The hanging screws are not tight
enough
Tighten the hanging screw and make it
horizontal.
11

P/N:16173000A12971
