Midea YL1633S User manual

MODEL:
Water Dispenser
Instruction Manual
YL1633S

H: MAINTENANEC INSTRUCTION 8
A: PART NAME
B: SAFETY PRECAUTIONS
C: GETTING STARTED
D: DISPENSING WATER
E: TROUBLESHOOTING
F: CLEANING
G: MACHINE INSTALLATION
The packaging material used is recyclable; we recommend that you separate plastic,
paper and cardboard and give them to recycling companies. To help preserve the
environment, the refrigerant used in this product is R134a (Hydrofluorocarbon -HFC),
which does not affect the ozone layer and has little impact on the greenhouse effect.
According to WEEE (Waste of Electrical and Electronic Equipment) guidelines, waste
from electrical and electronic devices should be collected separately. If
you need to dispose of this appliance in the future, do NOT throw it away
with the rest of your domestic garbage. Instead, please take the appliance
to the nearest WEEE collection point, where available.

NOTE:
This machine can be suitable for bottles of 3 or 5 gallons.
PART NAME PART NAME
NO. NO.
Top cover
Heating switch
Condenser
Push button of cold water
Tap of cold water
Tap of normal water
Tap of hot water
Water collector
Power Supply Cord
Drain Outlet
Water Shortage Pilot Lamp
Heating Pilot Lamp
Cooling Pilot Lamp
A: PART NAME
1
Push button of normal water
Push button of hot water

The water cooler shall plug into a ground fault interrupter receptacle.
above 176 F
B: SAFETY PRECAUTIONS
2

This appliance is intended to be used in household and similar applicaons
such as: kitchen areas in shops, offices, and other working environments,
hotels, motels, and other residenal type environments, bed and breakfast
type environments, catering, and similar non-retail applicaons.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
If the supply cord is damaged, it must be replaced by a special cord
avaiable from the manufacturer or its service agent.
assembly
Thermostat has been adjusted. No need to adjust it by yourself. When the
machine is below the freezing point and blocked by ice, the cooling switch be
turned off for 4 hours before turning it on again to connue its operaon.
This machine should not be turned on unl 3 minutes aer turning off
power switch.
the
Never turn the machine upside down or lean it more than 45 .
Locate Dispenser
1. Place dispenser upright.
2. locate dispenser on a hard and level surface in a cool shaded locaon
near a grounded wall outlet.
Noce: DO NOT plug in power cord yet.
3. Posion dispenser so the back is at least 20cm from wall and there are
at least 20cm of clearance on both sides.
Assemble
1. Remove drip tray from door and place the grid on top.
2. Snap drip tray and grid assembly into door.
This appliance can be used by children aged from 8 years and above if
they have been given supervision or instrucon concerning use of the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance and its cord
out of reach of children aged less than 8 years.
Appliances can be used by persons with reduced physical, sensory, or
mental cappsbilies or lack of experience and knowledge if they have
been given supervision or instrucon concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not play
with the appliance.
C: GETTING STARTED
3

Install water bole
1. Open cabinet door.
2. Place probe assembly on probe hanger.
3. Place fresh bole outside of cabinet.
4. Remove enre plasc cap from top of bole.
5. Clean outside of new bole with a cloth.
6. Place probe into bole.
7. Slide collar down unl it clicks in place.
8. Push head down unl tube hits boom of
bole.
9. Slide bole into cabinet and close door.
Provide Electricity
Plug cord into a properly grounded wall outlet.
At this me the pump will begin to move water
from the bole to the hot and cold tanks. It will
take up to 12 minutes to fill the tanks for the first
me. During this period the pump will run
connuously. This is normal.
Acvate Heang & Cooling
Noce: This unit will not dispense hot or cold water unl the switches
are acvated.
To acvate, push top side of power switches in to start heang and cooling
water.
- If you do not want to heat water, push boom side of red switch in.
- If you do not want to cool water, push boom side of green switch in.
4

This unit has been tested and sanized prior to packing and shipping. During
transit dust and odors can accumulate in the tank and lines. Dispense and
dispose at least one quart of water prior to drinking any water.
Dispensing Cold Water
Aer setup, it will take up to 1 hour to get water to maximum cold
temperature. During this me the compressor could run connuously.
This is normal.
1. Posion bole, glass, pitcher or cooking pot below spout.
2. Depress cold water control downward to start cold water flow.
3. Release control once desired fill level is achieved.
Dispensing Room Temperature Water
1. Posion bole, glass, pitcher or cooking pot below spout.
2. Depress normal water control downward to start normal water flow.
3. Release control once desired fill level is achieved.
Dispensing Hot Water
Aer setup, hot water will be available in 15-20 minutes.
1. Posion bole, glass, pitcher or cooking pot below spout.
2. Slide red buon away from you and depress hot water control downward
to start hot water flow.
3. Release control once desired fill level is achieved.
Changing Boles
A flashing red light on your funcon lights alerts you when your bole is
empty. Replace the bole as soon as possible.
Noce: Do not dispense hot, cool or cold water if the red light is flashing as
you could empty the tanks and cause the dispenser to overheat.
1. Open cabinet door.
2. Slide empty bole out of cabinet.
3. Remove probe assembly from empty bole. Place probe assembly on
probe hanger.
4. Set empty bole aside.
5. Place fresh bole outside of cabinet. Remove enre plasc cap from top
of bole. Clean outside of new bole with a cloth.
6. Place probe into bole. slide collar down unl it clicks in place. Push
head down unl tubes hit boom of bole.
7. Slide bole into cabinet and close door.
D: DISPENSING WATER
5

1. The machine had been disinfected before deparng from factory. Clean the
Clean the dispenser prior to installing a full bole of water for the fist me.
2. Cleaning and draining instrucon:
1)make sure the power switch in the O(off) posion and unplug the water
disperser before cleaning.
2)Twist out the two screws , the take down top cover, cold tank cover,
and separator
3)Fill 0.6 gallons pure water into cold tank to clean it.
4)Place a large water bucket beneath the drain outlet which is in the back of
water dispenser, then remove the drain cover and drain the water
5)Reposion the drain cover, sparator, cold tank cover, and top cover aer
draining. Ensure the pipe and wires are connected properly, then you can use
the machine normally.
Water is leaking.
Unplug dispenser, remove bole and replace it.
No water is coming from the spout.
Make sure the bole is not empty. If empty, replace it.
Make sure to completely depress the pushbuon controls.
Cold water is not cold.
It takes up to one hour aer setup to dispense cold water.
Make sure the power cord is properly connected to a working outlet.
Make sure the back of the dispenser is at least 20cm from a wall and
there is free airflow on all 20cm sides of the dispenser.
Make sure green power switch on back of dispenser is ON.
If water sll isn’t cold, please ask a service agent for assistance.
Hot water is not hot.
Dispenser is noisy.
It takes 15-20 minutes aer setup to dispense hot water.
Make sure the power cord is properly connected to a working outlet.
Make suer red power switch on back of dispenser is ON.
Make sure the dispenser is posioned on a level surface.
To avoid accident, cut off the power supply before operaon according
to the following instrucons.
E: TROUBLE SHOOTING
F: CLEANING
6

Aenon:
1) The cleaning must be unber the guidance or professional staff.
2) The dispenser heats water to a temperature of approximately 185 F.
It can cause severe burns. Please operate it carefully.
The machine should be disinfected with a disinfectant according to the
instrucon manual of the disinfectant and then clean it with water(see
cleaning and draining instrucon) Generally this should be done every
three months.
3. Sanizing
Mix 4 liters water with 200g citric acid crystals, inject into the machine and make
sure the water can flow out of the hot water tap. Switch on the power and heat it
about 10 minute. 30 minutes later, drain off the liquidand clean it with water two
or three mes.Generally this should be done every six months.
Never disassemble this machine by yourself to avoid danger from damaging
machine.
4. To Remove Mineral Deposits:
To prevent the machine from swaying or falling,
Please install the bracket accordingly.
1-2. Loosen the screw of the le or right boom angle
Just as the picture shown
3.Use the screw to fix the bracket on the le or right
boom angle of the water dispenser.
4.Make a hole on the floor's surface where
The water dispenser will be installed.
5.Fix the bracket on the floor by screwing ghtly.
6. Tighten the screw.
WARNING! To avoid a hazard due to instability of the appliance, it must be
fixed in accordance with the instrucons.
G: MACHINE INSTALLATION
7
