Midea YL2036S User manual

Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram aboveis just for reference. Please take the appearance of the actual product as the standard.
YL2036S
USER MANUAL
Water Dispenser

THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance oers in a safe way.
CONTENTS
0
02
1
01
21
31
41
51
61
05
06
THANK YOU LETTER
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
PRODUCT INSTALLATION
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DISPOSAL AND RECYCLING
DATA PROTECTION NOTICE
08

Danger
This symbol indicates that there are dangers to the life and health of
persons due to extremely flammable gas.
Warning of electrical voltage
This symbol indicates that there is a danger to life and health of
persons due to voltage.
Warning
The signal word indicates a hazard with a medium level of risk which, if
not avoided, may result in death or serious injury.
Caution
The signal word indicates a hazard with a low degree of risk which, if
not avoided, may result in minor or moderate injury.
Attention
The signal word indicates important information (e.g. damage to
property), but not danger.
Observe instructions
This symbol indicates that a service technician should only operate and
maintain this appliance in accordance with the operating instructions.
The following safety guidelines are intended to prevent unforeseen risks or damage from
unsafe or incorrect operation of the appliance. Please check the packaging and appliance
on arrival to make sure everything is intact to ensure safe operation. If you find any
damage, please contact the retailer or dealer. Please note modifications or alterations to
the appliance are not allowed for your safety concern. Unintended use may cause
hazards and loss of warranty claims.
Read these operating instructions carefully and attentively before using/commissioning the
unit and keep them in the immediate vicinity of the installation site or unit for later use!
Intended Use
Explanation of Symbols
SAFETY INSTRUCTIONS
02

03
DANGER: Risk of Fire/Flammable materials
●
●
●
Do not use an extension cord with your water dispenser.
Do NOT operate dispenser in the presence of explosive fumes.
Use only properly grounded outlets.
Always grasp plug and pull straight out from outlet. Never unplug by pulling on
power cord.
Do NOT use dispenser if cord becomes frayed or otherwise damaged.
To protect against electric shock, do NOT immerse cord, plug, or any other part of
dispenser in water or other liquids.
Ensure dispenser is unplugged prior to cleaning.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
It is recommended to use bottled pure water. If you use hard water, may lead to hot
pot furring or detonation tank or pipeline risk. If you need cleaning tube, remove
scale, need to find a professional institutions and professional operation.
WARNING: When positioning the appliance, ensure the supply cord is not trapped
or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
WARNING
●
●
●
●
●
●
●
CAUTION: Risk of injury!
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Never allow children to dispense hot water without proper and direct supervision.
Unplug unit to prevent unsupervised use by children.
Failure to comply with the safety information and instructions may result in injury.
Safety of children and persons with reduced abilities.
This appliance is intended to be used in household and similar applications such as:
sta kitchen areas in shops, oces and other working environments; farm houses and
by clients in hotels, motels and other residential type environments; bed and breakfast
type environments; catering and similar non-retail applications.
WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrost-
ing process, other than those recommended by the manufacturer.
This appliance is not suitable for installation in an area where a water jet could be
used.
SAFETY INSTRUCTIONS

04
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
SAFETY INSTRUCTIONS
Do not store explosive substances such as aerosol cans with a flammable propellant in
this appliance.
The appliance must not be immersed.
The appliance must not be cleaned by a water jet.
The appliance is suitable for indoor use only.
This appliance should work under environment of temp from 10℃~43℃.
Never turn the machine upside down or lean it more than 45°.
Thermostat has be adjusted. No need to adjust it by yourself. When the machine is
under the ice point and blocked by ice, the cooling switch must be closed for 4 hours
before turning it on again to continue its operation.
This machine should not be turned on until 3 minutes later after turning o the power
switch.
Prior to use, this dispenser must be properly assembled and installed in accordance
with this manual.
This dispenser is intended for water dispensing only. Do NOT use other liquids. Do
NOT use for other purposes. Never use any other liquid in the dispenser other than
known and microbiologically safe bottled water.
For indoor use only. Keep water dispenser in a dry place away from direct sunlight.
Do NOT use outdoors.
Install and use only on a hard, flat and level surface.
Do NOT place dispenser into an enclosed space or cabinet.
Position back of dispenser no closer than 20cm from wall and permit free airflow
between wall and dispenser. There must be at least 20cm clearance on the sides of
the dispenser to permit airflow.
Warning: Do not damage the refrigerant circuit.
Service should be performed only by a certified technician.
This product is not recommended at an altitude of 1500 meters above the region to
use.
In order to make sure the machine can be used normally, please keep it stand still for
24 hours before powering up.

SPECIFICATIONS
05
YL2036SProduct Model
Rated Voltage
Rated Frequency
220-240V~
50/60Hz
420W
1.0A
4L/h(≥85°C)
4L/h(≤10°C)
Rated power
Heating power
Cooling current
Hot water capacity
Cold water capacity
REFRIGERANT
520W
R134a(32g)

06
Product
PRODUCT OVERVIEW
Heating switch
Cooling switch
Round Indicator
Light Switch
Power supply
cord
Outlet of hot
water
Condenser
Top cover
Button of hot water
Button of normal water
Button of cold water
Indicator Lights
Faucet
Water collector
Door

Accessories
PRODUCT OVERVIEW
07
Fixed block x1
Instruction Manual x1 Warranty Card x1 Anchor bolt x1
Screw x2

PRODUCTINSTALLATION
Getting Started
Locate Dispenser
1. Place dispenser upright.
2.Locate dispenser on a hard and level surface in a cool shaded location near a grounded
wall outlet.
Note: Do not plug in power cord yet.
3.Position dispenser with at least 20cm from wall and at least 20cm on both sides.
Assemble
1.Remove drip tray from door and place the grid on top.
2.Snap drip tray and grid assembly into door.
Install Water Bottle
1.Open dispenser door.
2.Place probe assembly on probe hanger.
3.Place fresh bottle outside of cabinet.
4.Remove entire plastic cap from top of bottle.
5.Clean outside of new bottle with a cloth.
6.Place probe into bottle.
7.Slide collar down until it clicks in place.
8.Push head down until tubes hit bottom of bottle.
9.Slide bottle into cabinet and close door.
Provide Electricity
Plug cord into a properly grounded wall outlet.At this time the pump will begin to move
water from the bottle to the hot and cold tanks. It will take up to 5 minutes to fill the
tanks for the first time. During this period the pump will run continuously. This is normal.
Activate Heating & Cooling
Notice: This unit will not dispense hot or cold water until the switches are activated.
To activate, push top side of power switches in to start heating and coolingwater.
If you do not want to heat water, push bottom side of red switch in.
If you do not want to cool water, push bottom side of green switch in.
Activate Nightlight
Push top side of blue power switch in to turn light on. Push bottom side in to turn light
o.
3 Gallon Bottle5 Gallon Bottle
Head
Collar Head
Collar
08

PRODUCTINSTALLATION
Machine Installation
To prevent the machine from swaying to fall, please install
the bracket accordingly.
1-2. Loosen the screw of the left or right bottom angle just
as the picture shown.
3. Use the screw to fix the bracket on the left or right
bottom angle of the water dispenser.
4. Make a hole on the floor's or the desk's surface where
the water dispenser will be installed.
5. Fix the bracket on the floor by screw tightly.
6. Tighten the screw.
WARNING! To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
09
Water dispenser
Bracket
The hole for
tighten screw
2 3 5 641

Dispensing Water
This unit has been tested and sanitized prior to packing and shipping. During transit
dust and odors can accumulate in the tank and lines. Dispense and dispose at least one
quart of water prior to drinking any water.
Dispensing Cold Water
After setup, it will take up to 3 hour to get water to maximum cold temperature. During
this time the compressor could run continuously. This is normal.
1. Position bottle, glass, pitcher or cooking pot below spout.
2. Depress cold water control downward to start cold water flow.
3. Release control once desired fill level is achieved.
Operation Panel
OPERATION INSTRUCTIONS
Round Indicator
Light
●
●
Lacking Water
Indicator Light
Cooling Indicator
Light
●
●
●
Heating Indicator
Light
No.1
No.3
No.4
No.2
10
1 2 3 4
Description
When heating function is on, the icon lights on. When
heating function is o, the icon lights o
When lack of water, the icon flashes. When no lack of
water, the icon lights o
When cooling function is on, the icon lights on. When
cooling function is o, the icon lights o
Plug the power supply cord into a wall outlet, the
power pilot lamp will light up and will go o when
the unit is unplugged.
If the machine is powered on, you don't need the
round indicator light, you can turn o the round
indicator light switch on the back of the machine.

Dispensing Normal Water
1. Position bottle, glass, pitcher or cooking pot below spout.
2. Depress normal water control downward to start normal water flow.
3. Release control once desired fill level is achieved.
Dispensing Hot Water
After setup, hot water will be available in 15-20 minutes.
1. Position bottle, glass, pitcher or cooking pot below spout.
2. Slide red button away from you and depress hot water control downward to start hot
water flow.
3. Release control once desired fill level is achieved.
Changing Bottles
A flashing red light on your function lights alerts you when your bottle is empty.
Replace the bottle as soon as possible.
Notice: Do not dispense hot, cool or cold water if the red light is flashing as you could
empty the tanks and cause the dispenser to overheat.
1. Open dispenser door.
2. Slide empty bottle out of cabinet.
3. Remove probe assembly from empty bottle. Place probe assembly on probe hanger.
4. Set empty bottle aside.
5. Place fresh bottle outside of cabinet. Remove entire plastic cap from top of bottle.
Clean outside of new bottle with a cloth.
6. Place probe into bottle. Slide collar down until it clicks in place. Push head down until
tubes hit bottom of bottle.
7. Slide bottle into cabinet and close door.
OPERATION INSTRUCTIONS
11

12
CLEANING AND MAINTENANCE
To avoid accident cut off the power supply before operation according to the follow-
ing instruction.
1. The machine had been disinfected before departed from factory. Cleaning the dispens-
er prior to installing a full bottle of water for thefirst time.
2. Cleaning and draining instruction:
1) Making sure the power switch in the O(o) position and unplug the water dispenser
before cleaning.
2) Twist out the two screws 1 , then take down top cover, cold tank cover and
separator 2 .
3) Fill 0.6 gallons pure water into cold tank to clean it.
4) Turn on all the taps in turn for 3 minutes after the water outflow, which completes
the internal pipeline flushing.
5) Place a large water bucket beneath the drain outlet which on the back of water
dispenser, then, remove the drain cover and drain the water 3 .
6) Reposition the drain cover, separator, cold tank cover and top cover after draining.
Ensure the pipe and wires are connected properly, then, you can use the machine
normally.
Attention: 1) The cleaning must be under the guidance of professionalsta.
2) The dispenser heats water to a temperature of approximately 85 ℃.It
can cause severe burns.Please operate it carefully.
1 2 3
3. Sanitizing
The machine should be disinfected with the disinfectant separately bought from
drugstore or marketplace according to the instruction manual of the disinfectant and
then clean it with water(see cleaning and draining instruction).Generally this should be
done every three months.
4. To Remove Mineral Deposits:
Mix 4 liters water with 200g citric acid crystals, inject into the machine and make sure
the water can flow out of the hot water tap. Switch on the power and heat it about 10
minutes, 30 minutes later, drain o the liquor and clean it with water for two or three
times. Generally this should be done every six months.Never disassemble this machine
by yourself to avoid danger from damaging machine.

13
TROUBLESHOOTING
Possible reason SolutionProblem
Does not work
Operation of your appliance can lead to errors and malfunctions. The following tables
contain possible causes and notes for resolving an error message or malfunction. It is
recommended to read the tables carefully below in order to save your time and money
that may cost for calling to the service center.
Bonded in dierent voltage. Connect in correct voltage.
Wait for electric power ON or
change fuse.
Push the switches to the ON
position.
Use a voltage stabilizer.
Water leakage
Noisy operation
Voltage drop.
No Water is coming
from the tap
Make sure the bottle is not
empty.
The lacking water pilot lamp
is turn on to alert you when
your bottle is empty, if
empty, replace it.
Water not cold
from cold tank
Electric plug out of the
socket.
After setup, it will take up to
3 hour to chill the water until
minimal set temperature.
Make sure cold water switch
in the rear side of dispenser is
ON.
Electric plug out of the
socket.
After setup, it will take up to
15 min to heat the water until
maximal set temperature.
Make sure hot water switch in
the rear side of dispenser is ON
Plug in.
Wait 15 -20 min. for the heat
water supply.
Push the hot water switch
(red) to the ON position.
A hole or a crack in the bottle.
Overflow in the water collector.
Drainage cap not well
tightened.
Replace the water bottle.
Empty the water collector.
Tighten the cap.
●
●
●
●
●
●
●
●
●
●
●
●
Plug in.
Wait 3 hour for the cold
water supply.
Push the cold water switch
(green) to the ON position.
Product leaning on the wall.
Uneven placement.
The appliance must be at
least 20 cm from the wall.
Place the machine on placid &
solid surface.
●
●
●
●
●
●
●
●
●
●
●
Water not hot
from hot tank
●
●
●
●
●
●
●
●
●
Lack of electric power or fuse
blown.
Make sure water switchs in the
rear side of dispenser is ON.
Electric plug out of the socket. Plug in.
●●

14
logo, word marks, trade name, trade dress and all versions thereof are
valuable assets of Midea Group and/or its aliates (“Midea”), to which Midea owns
trademarks, copyrights and other intellectual property rights, and all goodwill derived
from using any part of an Midea trademark. Use of Midea trademark for commercial
purposes without the prior written consent of Midea may constitute trademark
infringement or unfair competition in violation of relevant laws.
This manual is created by Midea and Midea reserves all copyrights thereof. No entity or
individual may use, duplicate, modify, distribute in whole or in part this manual, or
bundle or sell with other products without the prior written consent of Midea.
All the described functions and instructions were up to date at the time of printing this
manual. However, the actual product may vary due to improved functions and designs.
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT

15
DISPOSAL AND RECYCLING
Important instructions for environment
Compliance with the WEEE Directive and Disposing of the Waster Product:
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waster electrical and electronic equipment (WEEE).
This symbol indicates that this product shall not be disposed
with other household wastes at the end of its service life. Used
device must be returned to ocial collection point for
recycling of electrical electronic devices. To find these
collection systems please contact to your local authorities or
retailer where the product was purchased. Each household
performs important role in recovering and recycling of old
appliance. Appropriate disposal of used appliance helps
prevent potential negative consequences for the environment
and human health.
Compliance with RoHS Directive
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials specified in the Directive.
Package information
Packaging materials of the product are manufactured from
recyclable materials in accordance with our National Environ-
ment Regulations. Do not dispose of the packaging materials
together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local
authorities.

16
DATA PROTECTION NOTICE
For the provision of the services agreed with the customer,
we agree to comply without restriction with all stipulations of applicable data protection
law, in line with agreed countries within which services to the customer will be delivered,
as well as, where applicable, the EU General Data Protection Regulation (GDPR).
Generally, our data processing is to fulfil our obligation under contract with you and for
product safety reasons, to safeguard your rights in connection with warranty and
product registration questions. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located outside of the
European Economic Area.
Further information are provided on request. You can contact our Data Protection
Ocer via [email protected]. To exercise your rights such as right to object your
personal date being processed for direct marketing purposes, please contact us via
[email protected]. To find further information, please follow the QR Code.

17

18

Midea 2023 all rights reserved
