70-0671 Alignment Procedure
SETUP
1 Remove the six securing screws from the bottom cover , and the cover itself.
2 Connect a resistive 50 ΩRF load and wattmeter to Antenna Connector J502.
3 Connect 13.4V DC power to transceiver J505.
4 Connect a 3.2 Ω, 20W resistor to pins 4 and 6 of the Accessory Plug. The jumper
between pins 5 and 6 must be temporarily removed to make this connection.
The resistor serves as a constant load to replace the speaker’s inconsistencies.
CAUTION:Both speaker terminals are LIVE. Never ground either one. Connect grounded receive-audio
measuring-equipment to only one side of the speaker, and chassis ground. Normally, voltage
measurement will be half of true values.
5 Turn the radio on (Push on and Push off switch), set the VOLUME control to
a mid-position.
Connect the Programmer to Programming Port Mic Jack J302.
Upload the radio programming Data-Packet into the Programmer and
initiate its Remote Control Mode. Refer to the appropriate manual for details.
SYNTHESIZER ALIGNMENT
•VCO Resonance
1 Select the Remote Control Mode of the Programmer and enter the following test
frequencies:
A-Band B-Band C-Band
RX Frequency 30.00 36.00 42.00 MHz
TX Frequency 30.00 36.00 42.00 MHz
2 Adjust Channel RX Tank L713 for 1.5V DC at VC (VCO Steering) .
3 Active transmit mode (using the programmer ) and adjust TX Tank
L702 for 1.5V DC at VC (VCO Steering) .

•Reference Oscillator
4 Initiate transmit on any channel. Measure transmitted RF carrier frequency
without modulation and, if necessary, adjust REFERENCE OSCILLATOR X701
for carrier frequency to within ±30Hz of channel frequency.
PA MODULE ALIGNMENT
The 70 -0671 should be adjusted to have a 6 MHz channel spread (8 MHz C-Band)
at 110W. To do so :
1 Change the TX test frequency to the desired frequency.
2 Activate transmit mode and measure RF power at Antenna connector J502.
Set RF output power to 110W at J502 using the programmer.
MODULATOR ALIGNMENT
•Modulation Limiting
1 Disconnect the hand microphone from its front panel Mic Jack J302.
Apply 3Vrms of 1000Hz signal to pin 1 of Mic Jack J302, then initiate transmit.
2 Measure total carrier deviation and, if needed adjust modulation limiting to obtain
±5KHz (wide) or ±2.5KHz (narrow) using the programmer.
•Microphone Gain
3 No alignment for Microphone gain is required.
•CTCSS/DCS
4 Remove the 1KHz audio signal from Mic Jack J302.
5 Add 250.3Hz CTCSS tone to the transmit test by testing frequency using the
programmer.
6 Adjust CTCSS deviation to ±750 Hz ±10 Hz (wide) or ±375 Hz ±10 Hz
(narrow) deviation using the programmer.
7 Change 67.0 Hz CTCSS tone to the transmit test b y testing frequency using in the
programmer.

8 Adjust RV401 for ±750 Hz ±100 Hz (wide) or ±375 Hz ±100 Hz (narrow)
deviation.
9 Change the transmit DCS code +023 to the transmit test by testing frequency
using the programmer.
10 Adjust RV401 so that modulation waveform from modulation analyzer matches
the correct waveform shown in Figure 2-1.
11 Change 250.3 Hz CTCSS tone to the transmit test by testing frequency using the
programmer. Carefully adjust RV401 for ±750 Hz ±10 Hz (wide) or
±375 Hz ±10 Hz (narrow) deviation.
•DTMF
12 Clear the CTCSS tone, then initiate transmit test by testing frequency using the
programmer.
13 Adjust DTMF deviation to ±2.0KHz ±10 Hz (wide) or ±1KHz ±10 Hz
(narrow) deviation using the programmer.
CORRECT INCORRECT INCORRECT
Figure 2-1 Modulation Waveforms

RECEIVER ALIGNMENT
1 Change the RX test frequency to 33.0 MHz for A-Band radios, 39.0 MHz for
B-Band , 46.0 MHz for C-Band.
•First Injection
2 No adjustment for first injection is required.
•Preselector Alignment
3 No adjust ment for the preselector (L201, L202, L203, L204, L205, L206, L207,and
L208 ) is required.
•Quadrature Detector
4 No adjustment for the quadrature is required.
•First IF
5 Apply enough modulated ( by 1KHz tone at ±3KHz (wide) or ±1.5KHz (narrow)
deviation ) on-channel RF signal to maintain 12 to 15 dB SINAD. Adjust L215,
and L217, L803 and L804 for maximum SINAD, reducing the RF signal generator
output as necessary to stay between 12 and 15 dB SINAD.
NOTE: Do not adjust L801 or L802 unless appropriate test equipment is available
for performing the “Noise Blanker Tuning’’ steps below. Normally, these coils are
tuned for optimum sensitivity as are L803 and L804, then are retuned slightly for
optimum noise blanker effectiveness. If the required test equipment is not avai-
lable, skip steps 6 through 14. If coils L801 or L802 were replaced, they may be
tuned for best sensitivity after adjustment of L215, L217, L803 and L804. Noise
blanker performance specifications, however, may not be met.
•Noise Blanker Tuning
This procedures requires the additional test equipment shown in Table 2-2.
6 Adjust the pulse generator to obtain a 10 nsec wide pulse, as shown in Figure 2-2.
Set the pulse period controls to obtain 200 u secbetween pulses(the pulse period
is easier to observe on an oscilloscope if the pulse width is temporarily increased
by about 10 times.)

7 Temporarily disable the pulse generator.
8 Using coax cable of minimum convenient length, connect the pulse generator,
the RF signal generator, and the radio to the two-way power divider.
9 Disable the noise blanker by placing SW801 to the OFF position.
10 Apply an on-channel signal to obtain12dB SINAD, then increase the RF generator
output by 40dB.
11 Enable the pulse generator to produce the 10nsec pulses. Adjust pulse amplitude
to return SINAD reading to 12 dB.
12 Switch SW801 to the ON position. The SINAD reading should improve.
13 Reduce the RF generator output until a 12 dB SINAD reading is obtained.
14 Using a non-metallic tool, slowly tune L801(clockwise or counter-clockwise, as
required) for best SINAD. The amount of L801 adjustment required should be
slight. Tune L802 in the same manner. Repeat this step. Noise blanker
tuning is complete.
Table 2-2----Noise Blanker Test Equipment
TEST INSTRUMENT CAPABITIES
Pulse Generator Pulse Rate: 5000 pulses per second
Pulse Width: Adjustable to 10 ns at
1/2 amplitude.
Output: Continuously variable from
0.1 to 10V peak into 50 Ω
Power Divider,3 port: 50 Ωeach port, 6 dB attenuation,
DC to 50 MHz as defined in EIA Standard
RS-204C or RS-204D Appendix A.

•Tight Squelch
15 Squelch level set maximum ( 80 ). by using the front UP / DN switch
16 Apply 0.95 uV of modulated standard deviation on-channel RF signal to the 50 Ω
antenna connector.
Adjust Squelch range RV201 counter-clockwise just until squelch opens ( audio
on ).
Figure 2-2 Adjustment Map TR-055 Board
L702
L713
L804
L803
L801 L802
L217L215
X701
VC RV201
RV401

COMPLETE REALIGNMENT
Complete realignment is only needed when a component that affects alignment has been replaced. RADIO
REPROGRAMMING WITH TEST FREQUENCIES IS REQUIRED.
Table 2-1 TEST EQUIPMENT REQUIRED
TEST INSTRUMENT INSTRUMENT CAPABILITIES USE
Regulated
DC Power supply
RF Wattmeter
RF Load Resistor
Frequency
Modulation Meter
Frequency Meter or
Frequency Counter
Audio Generator
RF Signal
Generator
Distortion Analyzer
Load Resistor
( audio )
AC Voltmeter
Oscilloscope
Digital Multimeter
Programmer
13.4 V DC, 30 A, adjustable voltage
150 W, 30 -50MHz,
50 Ωcircuit
50 Ω, 200 W
30 -50 MHz, peak -
responding, +/-5KHz range
30 -50 MHz,
1.0 ppm accuracy
1,000KHz sine-wave
0-4 Vrms output
30 -50 MHz range,
0.1 -1 KuV output, 3KHz
FM mod. With 1 KHz tone
1 KHz notch,
1% measuring range
3.2 Ω, 20 W
10mV to 10 Vrms
DC to 500KHz bandwidth
0.1 to 20 V DC
PC Programming Software
Radio power source
Transmitter power
measurements
Antenna dummy load
Modulation level
measurements
Carrier frequency
measurements
Modulation level
measurements
All receiver
measurements
Receiver performance
test and IF alignment
Speaker load for all
receiver measurements
Audio level adjustments
Test point measurements
and power supply setup
Manual radio control
