Miele HR 1134-1 User manual

Operating Instructions
36" All Gas Range (Convection Oven)
To prevent accidents and damage to the range, you must read all
instructions supplied before installing or using the appliance.
en-US, CA M.-Nr. 10 944 260

IMPORTANT SAFETY INSTRUCTIONS
2
WARNING
Children and adults can tip over the range if has not been secured.
This may lead to fatal injuries.
 This range must be secured and connected using the anti-tip
device according to the installation instructions.
 If you have moved the range, slide the locking latch onto the anti-
tip device until you feel it lock into place.
 Do not use the range if the anti-tip device has not been properly
installed and engaged.
 Failure to observe the information contained in the installation
instructions can lead to serious or fatal injuries for children and
adults.
All ranges can tip
Injury to persons
could result
Install anti-tip devices
packed with range
See installation
instructions
WARNING

IMPORTANT SAFETY INSTRUCTIONS
3
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or death.
– Do not use or store gasoline or other combustible liquids or vapors in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
– Do not try to light any appliance.
– Do not touch any electric switches.
– Do not use any phones inside your building.
– Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
– If you are unable to reach your gas provider, call the fire department.
– Installation and service must be performed by a qualified installer, qualified
service agency or your gas provider.
(In Massachusetts, installation must be performed by a licensed installer / gas
fitter.)
– Note to the installer:
Please give these installation instructions to the consumer for the local
electrical/gas inspector.
®®

Contents
4
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 2
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 7
Guide to the range............................................................................................... 20
HR 1134-1 ............................................................................................................. 20
HR 1135-1, HR 1136-1.......................................................................................... 21
Control panel ....................................................................................................... 22
HR 1134-1 ............................................................................................................. 22
HR 1135-1, HR 1136-1.......................................................................................... 22
Burner knob........................................................................................................... 22
Temperature selector ............................................................................................ 23
Operating mode selector ...................................................................................... 23
Clock / Timer ......................................................................................................... 23
Display.............................................................................................................. 23
Symbols in the display .....................................................................................23
Sensor buttons................................................................................................. 24
Temperature indicator ................................................................................. 24
Features................................................................................................................ 25
Model numbers .................................................................................................... 25
Data plate ............................................................................................................. 25
Items included with this range............................................................................... 25
Standard and optional accessories....................................................................... 25
Shelf runners ....................................................................................................25
Universal tray and Wire oven rack.................................................................... 26
FlexiClips with wire rack HFCBBR36-2........................................................... 26
Oven safety features ............................................................................................. 30
System lock  for the oven ............................................................................. 30
Safety shut-off.................................................................................................. 30
Cooling fan ....................................................................................................... 30
Vented oven door ............................................................................................. 30
Safety Door Lock for Self Clean.......................................................................30
PerfectClean surfaces ........................................................................................... 31
Self Clean ready accessories ................................................................................ 31
Before first use .................................................................................................... 32
Before using for the first time................................................................................ 32
Setting the time of day for the first time ............................................................... 32
Heating the oven ................................................................................................... 32
Operating the oven.............................................................................................. 34
Energy saving tips ................................................................................................. 34

Contents
5
Using the oven ...................................................................................................... 34
Cooling fan ........................................................................................................... 34
Preheating the oven .............................................................................................. 34
Guide to the modes............................................................................................. 35
Clock / Timer ....................................................................................................... 36
Turning a cooking program On / Off automatically ............................................... 36
Setting the cooking time .................................................................................. 36
Setting a cooking time and finish time .............................................................37
At the end of the cooking time ......................................................................... 38
Changing the cooking time .............................................................................. 38
Deleting a cooking time....................................................................................38
Deleting a finish time ........................................................................................ 39
Changing the time of day ...................................................................................... 39
Changing factory default settings ......................................................................... 40
System lock ...................................................................................................... 43
Timer ..................................................................................................................... 45
Setting the timer............................................................................................... 45
Bake...................................................................................................................... 47
Roast .................................................................................................................... 49
Slow Roasting...................................................................................................... 50
Broil....................................................................................................................... 52
Defrost.................................................................................................................. 54
Canning ................................................................................................................ 55
Dehydrate............................................................................................................. 56
Frozen food .......................................................................................................... 57
Cleaning and care ............................................................................................... 58
Unsuitable cleaning agents ................................................................................... 58
Normal soiling........................................................................................................ 59
Stubborn soiling .................................................................................................... 60
Operating mode and temperature selectors in stainless steel .............................. 61
Self Cleaning the oven interior .............................................................................. 62
Preparing for the Self Clean program............................................................... 62
Starting the Self Clean program ....................................................................... 63
At the end of the Self Clean program............................................................... 64
The Self Clean program is canceled ................................................................65

Contents
6
Door removal......................................................................................................... 66
Reinstalling the door ............................................................................................. 67
Removing the shelf runners................................................................................... 68
Frequently Asked Questions .............................................................................. 69
Technical Service................................................................................................. 73
Contact in case of fault ......................................................................................... 73
Warranty ................................................................................................................ 73

IMPORTANT SAFETY INSTRUCTIONS
7
When using the appliance, follow basic safety precautions, including the
following:
Read all instructions before installation and use of the range to prevent
accidents and machine damage.
This range complies with current safety requirements. However,
improper use of the appliance can result in personal injury or
damage to property.
Please read the installation instructions carefully before installing
and connecting the appliance.
Read the operating instructions before using the range for the first
time. To prevent accidents and damage to the appliance, always
observe both the installation instructions and operating
instructions. Both documents contain important information about
installation, safety, use and maintenance.
Miele cannot be held liable for damage occurring as a result of
non-compliance with the instructions.
Keep these installation instructions and operating instructions in a
safe place and pass them on to any future owner.

IMPORTANT SAFETY INSTRUCTIONS
8
Appropriate use
 This appliance is intended for residential use only. Use only as
described in these operating instructions.
 This appliance is not intended for outdoor use.
 Only use this oven for residential cooking, and the purposes
described in this manual.
Other uses are not permitted and can be dangerous.
 Risk of Fire! Do not use this oven to store or dry flammable
materials.
 Persons who lack physical, sensory or mental abilities, or
experience with the appliance should not use it without supervision
or instruction by a responsible person.

IMPORTANT SAFETY INSTRUCTIONS
9
Safety with children
 As with any appliance, close supervision is necessary when the
oven is used by children.
 Do not leave children unattended: Children should not be alone or
unsupervised in the area where the appliance is installed. Do not
allow them to sit or stand on the appliance.
 As with any appliance, close supervision is necessary when used
by children.
 Children 8 years and older may only use the oven unsupervised if
they have been shown how to use it safely and recognize and
understand the consequences of incorrect operation.
 Children must not be allowed to clean or maintain the appliance
unsupervised.
 Children should not be left alone or unattended in an area where
an oven is in use. Never allow children to operate, sit or stand on any
part of the oven. Caution: Do not store items of interest to children
in cabinets above an oven. Children climbing on the oven to reach
these items could be injured.
 Danger of burns. The oven gets hot at the oven door glass, the
vapor vent, the handle and the operating controls. Do not allow
children to touch or play in, on or near the oven.
 Danger of burns.
Children's skin is more sensitive to high temperatures than that of
adults. The oven becomes hotter during self-cleaning than it does in
normal use. Do not let children touch the oven while the Self Clean
program is running.
 Burn Hazard - Do not allow children to use the oven. Failure to do
so can result in severe burns or serious injury.
 Danger of suffocation! Ensure that any plastic wrappings, bags,
etc. are disposed of safely and kept out of the reach of children.

IMPORTANT SAFETY INSTRUCTIONS
10
 Burn hazard!
Keep the spaces above and behind the range clear of any items that
could draw the attention of children. Otherwise, they can be tempted
into climbing onto the appliance.
 Danger of injury. Never allow children to hang or lean on any part
of the appliance.
