Miele PW 6065 User manual

Operating manual
Washer
PW 6065 Plus
To prevent accidents
and machine damage
read these instructions
before
installation or use.
UV
M.-Nr. 06 523 700

2

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Guide to the washer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
To change a program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To cancel a program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To change a program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adding/removing laundry during a wash program . . . . . . . . . . . . . . . . . . . . . . . . 16
Program guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Program sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Spin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Spin speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Delay Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cleaning the washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Cleaning the inlet hose filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
A wash program cannot be started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
General problems with the washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Opening the door during a power failure or when the drain is blocked . . . . . . . . 39
Changing the light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Contents
3

Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Installation on a base. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Installation site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Removing the shipping struts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Installing the shipping struts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Leveling the washer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Water connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Help to protect the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Settings J. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Settings - Supervisor level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Contents
4

Read the operating instructions
before using this machine for the
first time. They contain important
information about the safety, use and
maintenance of the machine. Doing
so will prevent injury and damage to
the dryer.
Save these instructions and pass
them on to any future user.
WARNING - To reduce the risk
of fire, electric shock or injury:
Technical Safety
Check the packaging, the washer
and accessories for any signs of
damage. Do not use a damaged
appliance.
Before connecting the machine,
ensure that the connection data on
the data plate (circuit protection,
voltage and frequency) match the
mains electrical supply. If in doubt
contact an electrician.
The appliance must be grounded.
It is imperative that this basic
safety requirement be met.
Do not connect the appliance to
the mains electrical supply with an
extension cord. Extension cords do not
guarantee the required safety of the
appliance (e.g. danger of overheating).
The machine is built in accordance
with current safety requirements.
Incorrectly repaired machines may
pose a considerable risk to the user
which is not covered by the
manufacturer. Repairs should only be
performed by a Miele approved
technician.
Ensure power is not supplied to the
appliance while maintenance or
repair work is being performed. The
machine is only completely isolated
from the electrical supply when it is
turned off at the main switch and the
plug is pulled or by tripping the circuit
breaker.
Connect the washer, to the water
mains. Do not use old hoses.
Inspect the intake hoses regularly for
damage. They should be replaced as
needed to prevent water damage.
Faulty components must only be
replaced with genuine Miele spare
parts to maintain safety standards.
If the power cord is damaged it
must only be replaced by a Miele
Service technician with a genuine Miele
power cord.
IMPORTANT SAFETY INSTRUCTIONS
5

Use
Only use the washing machine to
wash items which are specified by
the manufacturer to be machine
washable on the fabric care label. Any
other applications may cause
undesirable results. The manufacturer
cannot be held responsible for damage
caused by improper use of the
appliance.
This appliance is not designed for
maritime use or for use in mobile
installations such as recreational
vehicles or aircraft. However, under
certain conditions it may be possible for
installation in these applications. Please
contact the Miele Technical Service
Department with specific requirements.
Do not install this machine in rooms
where temperatures below freezing
may occur. Frozen hoses may burst
under pressure. The reliability of the
electronic control unit may be impaired
at temperatures below freezing.
Do not wash articles that have
been previously cleaned, washed
soaked or spotted with gasoline,
organic substances dry-cleaning
solvents, or any other flammable
substances. These articles give off
vapors that could ignite or explode. Do
not add these items to the washload.
Before using the machine for the
first time, check that the shipping
struts at the rear of the machine have
been removed (see "Installation"). If the
shipping struts are still in place during
spinning, damage may result to both
the machine and adjacent furniture or
appliances.
Turn off the water supply if the
machine is to be left for any length
of time (e.g. vacation).
Overflow hazard!
Check that the drain can
accommodate the water flow before
operating the washer.
Make certain the drain hose is secured
in the drain, otherwise the force of the
expelled water could cause the drain
hose to come out of the drain.
Be sure that foreign objects (e.g.
nails, pins, coins, paper clips) do
not find their way into the machine.
These items may damage the
machine, which may also cause
damage to the laundry.
IMPORTANT SAFETY INSTRUCTIONS
6

If the correct amount of detergent
is dispensed, the machine should
not need to be descaled. If the washer
needs to be descaled, use a descaling
agent with corrosion protection. These
special descaling agents can be
purchased from the Miele Service
department. Use as directed.
Never use solvent based cleaning
agents in this machine, this may
result in damage and create toxic
fumes. They will present a fire and
explosion hazard.
Items which have been pre-treated
in solvent based cleaning agents
must be thoroughly rinsed in clean
water before being washed in the
machine.
Only use dyes specified by the
manufacturer as being suitable for
use in a washing machine. Use as
directed by the manufacturer.
Dye removers may contain sulphur
compounds which cause damage
such as corrosion. Do not use dye
removers in this machine.
The drum door glass will be hot
when washing at very high
temperatures. Do not touch the glass.
Danger of burns!
The stainless steel casing must not
come in contact with liquid
cleaning or disinfection agents
containing chlorine. They may cause
corrosion. Do not store open
containers of this agent next to the
machine.
Children
Close supervision is necessary
when the appliance is used near
children. Do not allow children to play
on or in the appliance.
Using accessories
Accessories must only be installed
once approved by Miele. Installing
unapproved parts may void the
warranty and product liability.
IMPORTANT SAFETY INSTRUCTIONS
7

Control panel
aDisplay*
See the following pages for more
information
bDirect select buttons
To select a wash program directly.
You can also save a "Favorite" wash
program on these buttons.
c"Start" button
dOptical interface PC
Allows a service technician to check
and update the wash programs
eJog shuttle
Turn to select menus
Press to confirm the selection
faDoor button to open the drum
door.
* Contents in the display will vary with program offering.
Guide to the washer
8

Display function
Display contents will vary with program offering.
Main menu
1 Cottons Uni. 60°C Program selection
2 Wrinkle-free 40°C Settings F
3 Delicates 40°C
4 Woollens H30°C 12:00
The display shows the main menu (with factory default
settings). "Program selection" is highlighted.
If the display is dark (in Stand-by mode) turn the jog shuttle.
Jog shuttle
Turn the jog shuttle to select a program or setting.
Press the jog shuttle to confirm the selection.
Direct select buttons
The first four programs shown in the display on the left are the
"Favorites". They can be selected with the direct select
buttons.
The Favorites can be individually set to your desire. See
"Favorites" for more information.
The direct select buttons have different functions in the other
menus. In these menus an arrow His displayed above the
respective button with the function description of the button.
Program selection possibility
–Possibility 1 Select and confirm the menu "Program
selection" in the display with the jog shuttle.
–Possibility 2 Press one of the direct select buttons
D E F G and access directly the basic menu of
the program.
Guide to the washer
9

Menu Program selection
Program backA
selection Cottons Hygiene
Cottons Uni.
Wrinkle-free H
All pre-set programs can be selected with the jog shuttle.
Depending on the direction the jog shuttle is turned the
highlighter moves up or down.
The arrows e- at the right side of the display show that more
selections are available.
^Press the jog shuttle to open the basic menu of the
selected program.
Basic menu of a wash program
Cottons 60°C 1400 rpm
Duration 0:45 h
Extras
H
Delay Start Y
H
Back A
H
The program components (program, temperature and spin
speed) can be selected by turning the jog shuttle. The
selected component is highlighted. Press the jog shuttle to
select the component. The respective submenu is displayed.
The submenu "Extras" and "Delay Start" can be selected by
the direct select buttons.
^To go back to the main menu, press G"back".
All components can also be selected and confirmed with the
jog shuttle only.
Settings J
The "Settings" menu allows you to adjust the washer to
individual needs. See "Settings" for more information.
Guide to the washer
10

The appliance must be correctly
installed and connected before the
first use. Please see the "Installation
instructions."
For safety reasons, it is not possible to
run a spin cycle before the first use. A
program must be run without laundry
and detergent to flush out any residual
water from the factory testing process.
^Open the water mains.
Welcome screen
The Welcome screen shows when the
washer is turned on for the first time.
M
PROFESSIONAL
Welcome!
The welcome screen will not show
anymore, when the total wash time of
the washer exceeds one hour.
The display then shows the language
selection.
Language J
^Select the desired language and
confirm with "OK".
Shipping struts
The display reminds the user to remove
the shipping struts.
^If the shipping struts were already
removed, confirm with the G
button. Otherwise remove them at
this time then confirm.
Set the time of day
^Set the hour by turning the jog shuttle
and press to confirm.
^Repeat to set the minutes and
confirm. Press again to save the time
of day.
Basic menu "Cottons Uni." shows
^Press the flashing button "Start".
The drum door must be closed.
Once the program ends the washer can
be used for laundry.
Before using for the first time
11

1. Sort the laundry
^Empty all pockets.
,Foreign objects left in pockets
(e.g. nails, coins, paper clips, etc.)
can cause damage to clothes and
the machine.
^Pre-treat stains.
Tough stains (blood, egg, coffee, tea
etc.) or badly soiled areas (collars and
cuffs) should be penetrated with a stain
remover or a paste made from powder
detergent and warm water. Dab stains
with a damp light colored cloth. Do not
rub!
,Do not use chemical solvents in
the machine.
^Sort the laundry.
General tips
–Dark fabrics often bleed the first few
times they are washed. They should
be washed separately several times
before being included in a mixed
load.
–Remove any lead weights or strips
from curtains before washing.
–Loose underwires should be
removed or sewn in place before
washing.
–Woolens and knitted garments
should be turned inside out.
– Close zippers and hooks and eyes
before washing.
– Comforter covers and pillowcases
should be fastened in order to
prevent small items from getting
trapped inside of them.
Do not machine wash items if it is not
recommended on the fabric care label.
Using the washer
12

2. Load the washer
^Open the drum door using the a
button.
The drum light comes on.
^Load the laundry loosely into the
drum.
For best results, wash mixed loads of
small and large items. This will improve
washing effectiveness and help
distribute the load evenly.
For the lowest energy and water
consumption load the washer to its
max. capacity. See "Program guide".
Note: Overloading the washer will
affect wash results and cause wrinkling.
^Close the drum door.
Close the drum door. To prevent
damage to the door seal and
clothing, make sure that there are no
clothes caught between the drum
door and the seal.
3. Select a program
Two program selection possibilities:
–Select a "Favorite" by pressing the
respective direct select button.
–Select from the "Program selection"
menu by turning the jog shuttle.
^If desired select "Extras" and/or a
delay start time with the respective
submenus.
Coin mechanism
If a coin mechanism operates the
machine, please regard the displayed
request to pay.
If the door is opened after a program
has started or if the program is
canceled the credit is lost.
Using the washer
13

4. Adding detergent
Use detergent according to the laundry
soiling and water hardness.
Too little detergent may cause:
–ineffective cleaning of laundry;
fabrics may become gray and stiff
over time.
–grease stains on the laundry.
–hard water deposits on the heating
element.
Too much detergent may cause:
– oversudsing with minimal drum
movement; poor wash, rinse and
spin results.
– higher environmental burden.
See "Detergent" for more information.
^Pull out the detergent dispenser
drawer and add detergent.
j= Detergent for the main wash
i= Only add detergent (1/4of the
total recommended amount of
detergent) to this compartment
for the pre-wash.
§= Fabric softener or liquid starch.
^Close the detergent dispenser
drawer.
Using the washer
14

5. Starting a program
"Start" flashes when a program can be
started.
^Press the "Start" button.
The "Start" button lights.
The display shows the approximate
program run time. It will count down in
minutes. The first 10 minutes the
washer calculates the water
absorbency of the laundry. The overall
program time may be shortened or
lengthened.
Additionally the sequence cycle is
displayed. The washer shows the
current program step.
The drum light turns off after the
program starts.
Press one of the following direct select
buttons during the running program:
– Button D"Extras"
the displayed Extras can be selected
or deselected after the program start.
–Button E"Delay Start"
the time of day and the approximate
program end is displayed.
–Button G"Cancellation"
to cancel the currently running
program. The wash water will be
drained away.
6. At the end of a program
The anti-crease program starts when
the laundry is not immediately removed
from the washer after the program end.
"Anti-crease" and "End" will flash
alternately in the display.
^Use the a"Door" button to open the
drum door.
^Remove the laundry.
Check the drum for any missed
pieces of laundry. Items
inadvertently left in the washer may
get damaged (e.g. shrink or
discolor) during the next wash cycle.
^Check the folds of the door seal for
any small articles which may have
been trapped.
^Close the drum door. Otherwise
foreign objects may find their way
into the drum. These could be
inadvertently washed and cause
damage to laundry.
Using the washer
15

To cancel a program
A program can be canceled any time
after a program start.
^Press the button G"Cancellation".
The wash water will be drained away.
^Open the drum door before starting a
new program.
To change a program
After the program start the spin speed
can be selected until the final spin
starts. The Extras "Starch Stop" and
"Rinse Stop" can be selected or
deselected.
The temperature and the Extra
"Intensive" can be selected or
deselected up to 5 minutes after the
program start.
Adding/removing laundry
during a wash program
You can interrupt the programs (see
"Program guide") to add or remove a
piece of laundry.
^Use the abutton to open the door.
^Add or remove the piece of laundry.
^Close the drum door.
The program will continue
automatically.
Note:
Once the program has started the
washer cannot make adjustments of the
load size. After adding or removing
laundry, the washer will default to the
water and electrical consumption of a
full load.
The time remaining will automatically be
adjusted.
The drum door cannot be opened if:
–the water temperature is higher than
131°F/55°C.
– the water level is too high.
– the program has reached the "Final
Spin".
When operated with a coin
mechanism the machine will be
locked after 3 minutes. Canceling or
changing a program and opening
the door is no longer possible.
To change a program
16

Programs may vary depending on the offerings of your machine.
Cottons Hygiene 203°F to 158°F (95°C to 70°C) EF
Items Items made from cotton and linen, i.e. bed linen, baby clothing,
underwear
Detergent Universal detergent
Load size 14.3 lbs (6.5 kg)
Cottons Uni. 140°F to cold (60°C to cold) DBA
Items Items made from cotton or mixed fabric, i.e. T-Shirts, pants
Tip Wash dark colored fabrics with detergent for colors or a liquid
detergent.
Detergent Universal or color detergent
Load size 14.3 lbs (6.5 kg)
Minimum iron 140°F to 86°F (60°C to 30°C) JHG
Items Items made from synthetic fibers, mixed fabric or wrinkle free
cottons, i.e. shirts
Detergent Universal or color detergent
Load size 7.7 lbs (3.5 kg)
Delicates 140°F to 86°F (60°C to 30°C) NM
Items Delicates made from synthetic, mixed fabric or viscose silk
Detergent Detergent for delicates
Load size 5.5 lbs (2.5 kg)
Quick wash 104°F to cold (40°C to cold) BA
Items Small load of lightly soiled items, which can be washed in
"Cottons Uni."
Detergent Universal or color detergent
Load size 7.7 lbs (3.5 kg)
Program guide
17

Woollens 104°F to cold (40°C to cold)
Items Items made from machine washable wool and wool blend
fabrics.
Detergent Detergent for wool
Load size 5.5 lbs (2.5 kg)
Silk /86°F to cold (30°C to cold)
Items Hand washable items, that contain no wool.
Tip Wash hosiery and lingerie in a lingerie bag.
Detergent Detergent for delicates
Load size 5.5 lbs (2.5 kg)
Shirts 140°F to cold (60°C to cold)
Items Shirts and dress shirts.
Tip –Pre-treat collars and cuffs depending on soiling
–Wash silk shirts in the "Silk" program.
Detergent Universal or color detergent
Load size 5.5 lbs (2.5 kg)
Denim 104°F to cold (40°C to cold)
Tip –Before washing denim items turn them inside out.
–Denim items bleed at the first few washes. Wash dark and
light colored items separately.
Detergent Liquid color detergent
Load size 7.7 lbs (3.5 kg)
Towelling 203°F to 140°F (95°C to 60°C)
Tip Use color detergent for dark colored laundry
Detergent Universal detergent
Load size 12.1 lbs (5.5 kg)
Drain
To drain the water from the drum
Spin
Please select an appropriate spin speed
Program guide
18

Additional programs
The following programs can be added from the "Settings - Supervisor level"
when activated by Technical Service.
Kitchen linen 203°F to 140°F (95°C to 60°C)
Items Kitchen linen made from cottons and linen, i.e. chef jackets and
pants, towels, rags
Tip Use the "Pre-wash" program for tough stains. Use a pre-wash
detergent with enzymes.
Detergent Universal detergent
Load size 7.7 lbs (3.5 kg)
Table linen 140°F to 86°F (60°C to 30°C)
Items Table cloths and napkins made of cottons, linen or mixed
fabrics.
Tip Use the "Pre-wash" program for tough stains. Use a pre-wash
detergent with enzymes.
Detergent Universal detergent
Load size 14.3 lbs (6.5 kg)
Curtains 104°F to cold (40°C to cold)
Items Curtains which are machine washable according to the
manufacturer. To rinse dust, a pre-wash without detergent is
automatically added to the program.
Tip Curtains that wrinkle easily should be washed at a reduced spin
speed or without a spin .
Detergent Curtain, universal and color detergent in powder form.
Load size 6.6 lbs (3.0 kg)
Pillows 203°F to 104°F (95°C to 40°C)
Items Washable pillows with a filling of feathers, down or synthetics.
Tip Regard the fabric care label!
Detergent Liquid detergent
Load size 1 queen and 2 twin size pillows
Program guide
19

Outerwear 104°F to cold (40°C to cold)
Items Outdoor clothing made from micro fibers.
Tip –Close all zippers.
–Do not use fabric softener
Detergent Detergent for delicates
Load size 7.7 lbs (3.5 kg)
Proofing 104°F to 86°F (40°C to 30°C)
Items To treat micro fiber, ski clothing, fine dense cotton (poplin) or table
cloths to make them water repellent and soil resistant.
Tip –The item should be washed and rinsed or dried.
–To get an optimum result dry the items in a clothes dryer or iron
them.
Water
repellent –Only use water repellent that states it is "Suitable for membrane
textiles". They are based on fluorochemicals. Do not use
agents containing paraffin.
–Place the liquid detergent insert in compartment jan fill with
water repellent.
Load size 7.7 lbs (3.5 kg)
Program guide
20
