Miele PWM 908 DV User manual

Installation Plan
Washing Machine
PWM 908 DV/DP
Always read the operating and installation instructions before
setting up, installing, and commissioning the machine.
This prevents both personal injury and damage to the machine.
en-US
11 282 580/00

2 11 282 580/00
Please have the model and serial number of your machine available when contacting Technical Service.
U.S.A.
Miele, Inc.
National Headquarters
9 Independence Way
Princeton, NJ 08540
Phone: [phone]
Fax: [phone]
www.miele-pro.com
[e-mail]
Technical Service & Support
Phone: [phone]
Fax: [phone]
[e-mail]
Legend:
Connection required
Connection optional or required,
depending on model
DV
Drain valve
KW
Cold water connection
AW
Drain connection
DP
Drain pump
B
Machine anchoring
PA
Equipotential bonding and
grounding
DOS
Dispenser connection
SLA
Peak-load connection
EL
Electrical connection
UG
Closed plinth
F
Machine feet, adjustable
UO
Open plinth
KG
Payment system
APCL
Washer-dryer stacking kit
KGA
Payment system connection
WW
Hot water connection
XKM
Communication module
All rights reserved.

PWM 908 en-US
11 282 580/00 3
Machine dimensions
F
F F F
FF
FF
EL
KGASLA
XKM
DP
DV
KW
WW
DOS
PA

PWM 908 en-US
4 11 282 580/00
Installation
EL
WW KW KG
DV
DP
KG
WW KW EL
DP
DV KGA
SLA
EL
WW KW KG
DP
UO UG/
DV
UO UG/
KG
WW KW EL
DP
DV KGA
SLA
PA
PA

PWM 908 en-US
11 282 580/00 5
Washer-dryer stack
F F
EL
WW KW
DP
DV
EL
WW
KW
F
F
APCL
APCL KGA
SLA
DV
PA

PWM 908 en-US
6 11 282 580/00
Installation
305145,5 145,5
681
1031
B B
BB BS
BB
305145,5 145,5
305
1031
B B
148148
305148 148
BS

PWM 908 en-US
11 282 580/00 7
Installation
UO UG/
B B
UO UG/
B B
UO UG/
B B
B B
UO UG/
B B
B B

PWM 908 en-US
= standard, = optional, + = only on request, - not available
8 11 282 580/00
Technical data
PWM 908 DV
PWM 908 DP
Drum volume
gal (l)
19.3 (73)
19.3 (73)
Capacity
lb (kg)
17.6 (8.0)
17.6 (8.0)
Door opening diameter
inch (mm)
11 13/16" (300)
11 13/16" (300)
Max. spin speed
rpm
1,600
1,600
g-factor
704
704
Residual moisture (standard load according to DIN 60456)
%
48
48
Electrical connection (EL)
Standard voltage
2N AC 400 V
2N AC 400 V
Frequency
Hz
50
50
Total rated load
kW
5.5
5.5
Fuse rating (B trip rating according to EN 60898)
A
2 x 16
2 x 16
Power cord min. cross-section
mm²
4 x 1.5
4 x 1.5
Wire without plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Alternative voltage (convertible by Technical Service)
1N AC 230 V
1N AC 230 V
Total rated load
kW
2.85
2.85
Fuse rating (B trip rating according to EN 60898)
A
1 x 16
1 x 16
Power cord min. cross-section
mm²
3 x 1.5
3 x 1.5
Non-standard voltages MAR 400/440/480 (Marine)
-
3 AC 400/440/480V
Frequency
Hz
-
50/60
Total rated load
kW
-
3.6/4.23/5.0
Fuse rating (B trip rating according to EN 60898)
A
-
3 x 16
Power cord min. cross-section
mm²
-
4 x 1.5
Wire without plug
-

Wire length
inch (mm)
-
78 3/4" (2,000)
Non-standard voltage MAR 230 (Marine)
-
3 AC 230 V
Frequency
Hz
-
50/60
Total rated load
kW
-
4.4
Fuse rating (B trip rating according to EN 60898)
A
-
3 x 16
Power cord min. cross-section
mm²
-
4 x 1.5
Wire without plug
-

Wire length
inch (mm)
-
78 3/4" (2,000)
Non-standard voltage MAR 400 (Marine)
-
2N AC 400 V
Frequency
Hz
-
50/60
Total rated load
kW
-
5.5
Fuse rating (B trip rating according to EN 60898)
A
-
2 x 16
Power cord min. cross-section
mm²
-
3 x 1.5
Wire without plug
-

Wire length
inch (mm)
-
78 3/4" (2,000)
Non-standard voltage MAR 208-240 (Marine)
-
2 AC 208-240 V
Frequency
Hz
-
60
Total rated load
kW
-
4.0 –5.2
Fuse rating (B trip rating according to EN 60898)
A
-
2 x 30
Power cord min. cross-section
-
3 x AWG10
Wire with plug
-

Wire length
inch (mm)
-
78 3/4" (2,000)

PWM 908 en-US
= standard, = optional, + = only on request, - not available
11 282 580/00 9
Technical data
PWM 908 DV
PWM 908 DP
Variations in the following countries:
Standard voltage 13 A (GB only)
2N AC 400 V
2N AC 400 V
Frequency
Hz
50
50
Total rated load
kW
5.5
5.5
Fuse rating (B trip rating according to EN 60898)
A
2 x 13
2 x 13
Power cord min. cross-section
mm²
4 x 1.5
4 x 1.5
Wire without plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Alternative voltage (convertible)
1N AC 230 V
1N AC 230 V
Total rated load
kW
2.85
2.85
Fuse rating (B trip rating according to EN 60898)
A
1 x 13
1 x 13
Power cord min. cross-section
mm²
3 x 1.5
3 x 1.5
Standard voltage 25 A (GB only)
1N AC 220-240 V
1N AC 220-240 V
Frequency
Hz
50
50
Total rated load
kW
5.05 –6.0
5.05 –6.0
Fuse rating (B trip rating according to EN 60898)
A
1 x 25
1 x 25
Power cord min. cross-section
mm²
3 x 2.5
3 x 2.5
Wire without plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Standard voltage (CH, DK, S only)
3N AC 400 V
3N AC 400 V
Frequency
Hz
50
50
Total rated load
kW
4.8
4.8
Fuse rating (B trip rating according to EN 60898)
A
3 x 10
3 x 10
Power cord min. cross-section
mm²
5 x 1.5
5 x 1.5
Wire without plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Standard voltage (B only)
2N AC 400 V
2N AC 400 V
Frequency
Hz
50
50
Total rated load
kW
5.5
5.5
Fuse rating (B trip rating according to EN 60898)
A
2 x 16
2 x 16
Power cord min. cross-section
mm²
4 x 2.5
4 x 2.5
Wire without plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Alternative voltage (convertible)
3 AC 230 V
3 AC 230 V
Total rated load
kW
5.5
5.5
Fuse rating (B trip rating according to EN 60898)
A
3 x 20
3 x 20
Power cord min. cross-section
mm²
4 x 2.5
4 x 2.5
Alternative voltage (convertible)
1N AC 230
1N AC 230
Total rated load
kW
2.85
2.85
Fuse rating (B trip rating according to EN 60898)
A
1 x 16
1 x 16
Power cord min. cross-section
mm²
3 x 1.5
3 x 1.5
Standard voltage (N only)
1N AC 230 V
1N AC 230 V
Frequency
Hz
50
50
Total rated load
kW
2.85
2.85
Fuse rating (B trip rating according to EN 60898)
A
1 x 16
1 x 16
Power cord min. cross-section
mm²
3 x 1.5
3 x 1.5
Wire with plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Alternative voltage (convertible)
3 AC 230 V
3 AC 230 V
Total rated load
kW
5.5
5.5
Fuse rating (B trip rating according to EN 60898)
A
3 x 20
3 x 20
Power cord min. cross-section
mm²
4 x 2.5
4 x 2.5

PWM 908 en-US
= standard, = optional, + = only on request, - not available
10 11 282 580/00
Technical data
PWM 908 DV
PWM 908 DP
Alternative voltage (convertible)
2N AC 400 V
2N AC 400 V
Total rated load
kW
5.5
5.5
Fuse rating (B trip rating according to EN 60898)
A
2 x 16
2 x 16
Power cord min. cross-section
mm²
4 x 1.5
4 x 1.5
Standard voltage (AUS only)
1N AC 230 V
1N AC 230 V
Frequency
Hz
50
50
Total rated load
kW
5.5
5.5
Fuse rating
A
1 x 25
1 x 25
Power cord min. cross-section
mm²
3 x 2.5
3 x 2.5
Wire without plug


Wire length
inch (mm)
78 3/4" (2,000)
78 3/4" (2,000)
Standard voltage (AUS only)
-
1N AC 230 V
Frequency
Hz
-
50
Total rated load
kW
-
2.85
Fuse rating
A
-
1 x 16
Power cord min. cross-section
mm²
-
3 x 1.5
Wire with plug
-

Wire length
inch (mm)
-
78 3/4" (2,000)
Alternative voltage (convertible)
-
1N AC 230 V
Frequency
Hz
-
50
Total rated load
kW
-
5.5
Fuse rating
A
-
1 x 25
Power cord min. cross-section
mm²
-
3 x 2.5
Standard voltage for CDN & USA
-
2 AC 208-240 V
Frequency
Hz
-
60
Total rated load
kW
-
4.0 –5.2
Fuse rating
A
-
2 x 30
Power cord min. cross-section
-
3 x AWG10
Wire with plug
-

Wire length
inch (mm)
-
78 3/4" 2000
Cold water (KW)
Permissible water flow pressure
PSI (kPa)
1.45 –14.5 (100 –1,000)
1.45 –14.5 (100 –1,000)
Required flow rate (cold water connection only)
gal/min (l/min)
2.9 (11)
2.9 (11)
Required flow rate (with additional hot water connection)
gal/min (l/min)
2.6 (10)
2.6 (10)
Average water consumption (60°C standard programme)
gal/h (l/h)
10.5 (40)
10.5 (40)
Connection to be provided on site, external thread according to DIN 44991 (flat seal)
Inches
¾"
¾"
Connection hose ½" with ¾" threaded union


Connection hose length
inch (mm)
61 (1,550)
61 (1,550)
Hot water (WW)
Max. water intake temperature
°F (°C)
158 (70)
158 (70)
Permissible water flow pressure
PSI (kPa)
1.45 –14.5 (100 –1,000)
1.45 –14.5 (100 –1,000)
Required flow rate
gal/min (l/min)
2.9 (11)
2.9 (11)
Average water consumption (60°C standard programme)
gal/h (l/h)
3.4 (13)
3.4 (13)
Connection to be provided on site, external thread according to DIN 44991 (flat seal)
Inches
¾"
¾"
Connection hose ½" with ¾" threaded union


Connection hose length
inch (mm)
61 (1,550)
61 (1,550)
Drain valve (DV)
Connector (ext. diameter)
inch (mm)
3 (75) /DN70
-
Max. drainage temperature
°F (°C)
194 (90)
Max. transient flow rate
gal/min (l/min)
16 (62)
-

PWM 908 en-US
= standard, = optional, + = only on request, - not available
11 282 580/00 11
Technical data
PWM 908 DV
PWM 908 DP
Drain pump (DP)
Hose connection (external diameter)
inch (mm)
-
7/8 (22) /DN22
Max. drainage temperature
°F (°C)
-
194 (90)
On-site hose sleeve (int. diameter x length)
inch (mm)
-
22 x 30
Max. transient flow rate
gal/min (l/min)
-
6.8 (26)
Max. delivery head (from lower edge of machine)
inch (mm)
-
39 3/8" (1000)
Drain hose DN 22 with connector (supplied as standard)
-

Connection hose length
inch (mm)
-
59 1/16" (1500)
Potential equalization (PA)
Machine connection (separate kit required)


XCI box LG interface


Peak load/energy management (SLA)
Machine connection (with XCI box LG)




Payment system connection (KGA)
Connection of payment systems (with XCI box LG)


Communication module (XKM)
Communication module XKM 3200 WLPLT


Liquid dispensing (DOS)
Connection for liquid dispensing agents


Max. no. of dispenser pumps
No.
6
6
XCI box LG interface




Installation on machine feet (F)
No. of machine feet
No.
4
4
Machine foot, height-adjustable with thread
inch (mm)
+5/16" (8)
+5/16" (8)
Machine foot diameter
inch (mm)
10.5 (40)
10.5 (40)
Anchoring (B)
Standard floor anchoring
Floor anchor kit (for 2 machine feet) with anchors


Wood screws according to DIN 571
inch (mm)
6 x 50
6 x 50
Rawl plugs (diameter x length)
inch (mm)
8 x 40
8 x 40
Anchoring of Miele Plinths
Accessory: Miele Plinth installation (fasteners included)


Required anchor points
No.
4
4
Wood screws according to DIN 571
inch (mm)
8 x 65
8 x 65
Rawl plugs (diameter x length)
inch (mm)
12 x 60
12 x 60
Plinth floor anchoring (to be provided on site)
Machine installation on on-site plinth (concrete or masonry)


Min. plinth installation footprint (W/D)
inch (mm)
23 5/8"/25 9/16" (600/650)
23 5/8"/25 9/16" (600/650)
Wood screws according to DIN 571
inch (mm)
6 x 50
6 x 50
Rawl plugs (diameter x length)
inch (mm)
8 x 40
8 x 40

PWM 908 en-US
= standard, = optional, + = only on request, - not available
12 11 282 580/00
Technical data
PWM 908 DV
PWM 908 DP
Machine data
Overall machine dimensions (H/W/D)
inch (mm)
33 5/8"/23 13/16"/28 1/8"
(854/605/714)
33 5/8"/23 13/16"/28 1/8"
(854/605/714)
Casing dimensions (H/W/D)
inch (mm)
33 7/16"/23 7/16"/26
11/16" (850/596/678)
33 7/16"/23 7/16"/26
11/16" (850/596/678)
Site-access dimensions (H/W)
Min. site-access opening (excl. packaging)
inch (mm)
35 7/16"/23 13/16"
(900/605)
35 7/16"/23 13/16"
(900/605)
Installation dimensions
Min. side gap
inch (mm)
13/16" (20)
13/16" (20)
Recommended side gap –washer-dryer stack
inch (mm)
>11 13/16" (300)
>11 13/16" (300)
Min. distance to opposite wall from front of machine
inch (mm)
37 3/8" (950)
37 3/8" (950)
Recommended distance to opposite wall from front of machine
inch (mm)
43 5/16" (1,100)
43 5/16" (1,100)
Weights and floor loads
Machine weight (net weight)
lb (kg)
227 (103)
227 (103)
Max. floor load in operation
N
2,820
2,820
Max. floor load, static
N
1,380
1,380
Max. floor load, dynamic
N
1365
1365
Emissions
Sound pressure level (in accordance with EN ISO 11204/11203)
dB(A)
<70
<70
Heat dissipation rate to installation site
W
250
250

PWM 908 en-US
11 282 580/00 13
Installation and planning notes
Installation requirements
The machine should only be connected to a power supply provided in
accordance with all appropriate local and national legislation and
regulations.
In addition, all regulations issued by the appropriate utilities as well as
standards relating to occupational safety and all applicable valid
regulations and technical standards must be observed.
Transportation and site access
The washing machine must not be moved without the shipping struts
in place. Keep the struts in a safe place. They must be refitted if the
machine is to be moved again (e.g., when moving house).
General operating conditions
Ambient temperature in installation room: +36°F to +95°F (+2°C to
+35°C).
Depending on the nature of the installation site, sound emissions and
vibration may occur. Miele recommends having the installation site
inspected and seeking the advice of a professional in instances where
increased noise may cause a nuisance.
Electrical connection
Depending on the model, the machine will be delivered with a wire
with/without a plug.
The machine may only be connected to an electrical system that
conforms to national and local codes and regulations. This connection
must be made by a qualified electrician.
The data tag indicates the nominal power consumption and the
appropriate fuse rating. Compare the specifications on the data tag
with those of the electrical power supply.
The machine can either be hard-wired or connected using a plug-and-
socket connection in accordance with IEC 60309-1. Miele always
recommends connecting the machine via a plug and socket so that
electrical safety checks can be carried out easily (during repair or
service work, for example).
If the machine is hard-wired, a dual circuit breaker must be provided
on site. When switched off, there must be an all-pole contact gap of at
least 3 mm in the isolator switch (including circuit breakers, breakers,
and relays according to IEC/EN 60947).
The plug connector or isolator switch should be easily accessible at all
times. If the machine is disconnected from the electricity supply, the
isolator must be lockable or the point of disconnection must be
monitored at all times.
New connections, modifications to the system, or servicing of the
ground conductor, including determining the correct fuse rating, must
be carried out by a qualified electrician, as they are familiar with the
pertinent regulations and the specific requirements of the electric
utility company.
If converting the machine to an alternative voltage, follow the
instructions in the wiring diagram. Conversion must be performed
by Miele Technical Service or by an authorized service technician.
The heater rating must also be adapted.
The machine must not be connected to devices such as timers which
would switch it off automatically.
References to cable cross-sections in the technical data refer only to
the required power cord. Please consult relevant local and national
regulations when calculating any other wire gauges.
Cold water connection
The washing machine should be connected to a domestic water
supply in accordance with current local and national safety
regulations.
Connection to the water supply should be carried out by a qualified
plumber using a stopcock with a threaded union. If a stopcock is not
available, the qualified plumber should connect the machine to the
domestic water supply.
A suitable connection hose with a threaded union is supplied with the
machine.
Longer hoses 8' 2 1/2" or 13' 1 1/2" (2.5 m or 4.0 m) in length are
available from Miele Technical Service or from your Miele dealer as
accessories.
Hot water connection
The same connection requirements as for cold water also apply to hot
water (max. 158°F/70°C).
A suitable connection hose with a threaded union is supplied with the
machine.
The hot water connection appliance also requires a cold water
connection.
In the event that hot water is not available on site, connection of the
second hose must be made to a cold water supply.
Alternatively, the hot water connection should be blocked using the
enclosed blind stopper and the machine controls set to cold water
intake.
The required amount of hot water should be added to the cold water
volume.
Drain valve (depending on model)
The machine is drained using a motorized drain valve. It can be
connected directly to the on-site drainage system (without a siphon) or
via a floor drain (gully with odor trap).
A vented drainage system is vital for unimpeded drainage. If on-site
venting is insufficient, a vent kit (mat. no. 05 239 540) is available from
your Miele dealer or Miele Technical Service.
If several machines are connected to a single drain pipe, this should
be sufficiently large to allow all machines to drain simultaneously.
Drain pump (depending on model)
The suds are drained through a drain pump with a 1 m delivery head.
For the water to drain freely, the hose must be installed free of kinks.
Drainage options:
1. Connected securely to a plastic drain pipe with a rubber nipple
(there is no need to use a siphon).
2. Connected securely to a sink with a plastic nipple.
3. Connected securely to a floor drain.

PWM 908 en-US
14 11 282 580/00
Connecting the drain hose to a sink drain outlet
The drain hose can be connected securely to a suitable sink drain
outlet.
If required, the hose can be extended to a length of up to 16.4 ft (5 m).
Accessories are available from your Miele dealer or Miele Technical
Service.
For a drain height of more than 3' 3 3/8" (1 m) up to a max. of 1.6 m),
a replacement drain pump is available from Miele Technical Service or
your Miele dealer.
Equipotential bonding and grounding
If necessary, an equipotential bond with good contact connection must
be provided in accordance with all appropriate national and local
regulations.
Material for equipotential bonding and grounding must be provided on
site or using a kit available from Miele Technical Service.
Peak load/Energy management
The machine can be connected to a peak-load or energy
management system using an optional kit.
When the peak-load function is activated, the heating is deactivated.
A message appears in the display to inform you of this.
Liquid dispensing connection
External liquid dispenser pumps with a “container empty” indicator can
be used to dispense liquid detergents.
The dispenser pumps can only be programmed with MDU.
It is particularly important to follow the manufacturer’s instructions
when using a combination of detergents, additives, and special-
purpose products.
Payment system
This washing machine can be equipped with a single-machine
payment system as an optional accessory using an optional kit
(XCI box).
The programming required for connecting a payment system can be
carried out during the initial commissioning process. After initial
commissioning, changes may only be carried out by your Miele dealer
or Miele Technical Service.
Interface
The machine can be retrofitted with an XKM 3200 WL PLT
communication module.
This module can be used as a WiFi or LAN interface.
The LAN interface provided via the module complies with SELV
(Safety Extra Low Voltage) in accordance with EN 60950. Connected
appliances must also comply with SELV. The LAN connection uses a
RJ45 connector in accordance with EIA/TIA 568-B.
Installation
The machine must be installed on a perfectly smooth, level, and firm
surface which is able to withstand the quoted loads.
The floor load created by the machine is concentrated and transferred
to the installation footprint via the machine feet.
The machine should be leveled in both directions with the aid of the
adjustable feet.
Plinth installation
The washing machine can be installed on a machine plinth (open or
box plinth, available as an optional Miele accessory) or on a concrete
plinth to be provided on site.
The quality of the concrete and its strength must be assessed
according to the machine load. Ensure that any raised concrete plinth
is adequately bonded to the floor below.
If the washing machine is installed on a concrete or masonry plinth, it
must be secured using the anchors supplied with the machine.
Otherwise, there is a risk of the washing machine moving about during
spinning and falling off the plinth.
The anchors provided can be used to bolt the machine to the floor by
both front feet. The fasteners provided are intended for use in bolting
the machine to a concrete floor.
Washer-dryer stack
The washing machine can be installed as a washer-dryer stack
together with a Miele Tumble Dryer. A stacking kit (optional
accessory) is required for this.
Installation of the stacking kit must be performed by Miele Technical
Service or an authorized Miele service technician.
