Mifa F5 User manual

LIGHT YOUR FIRE
Portable Bluetooth Speaker
F5
USE R MANUAL

LISTEN.MIFA
THE MUSIC POWER TO
YOUR DEEP HEART!
www.mifalife.net
JUST ENJOY

◆Please use and store this product at room temperature
◆Do not expose this product to rain or wet conditions
◆Do not throw and drop this product to avoid product damage
◆Do not self-dismantling ,repair and transform the product
◆Do not use chemical solvent cleaning the product
◆Please don’t arbitrarily discarded or placed the lithium battery in the fire in order to avoid
the risk of explosion
01 Warnings English
02 Product Features English
◎DSP 3D surround stereo sound effect
◎3D mega bass enhance
◎Support Bluetooth wireless connection and with hands-free function
◎Support Bluetooth one button reconnect
◎Support APE,FLAC format audio files
◎Support MP3,WAV,WMA format audio files
◎Auxiliary enabled , data exchanging directly enabled
◎Intelligent power save , with LED charging indicator
◎Automatically power off when there is no any operation in 10 minutes
If there is no operation in 20minutes ,It will power off automatically while in bluetooth mode.
◎With voice prompt function
◎Support ring tone play under iOS system

03 Packing Content English
Warranty Card
User Manual
User Manual
Warranty Card
Speaker 1pc
3.5mm audio cable 1pc
USB cable 1pc
Hook 1pc

04 Keys Function English
Next : Press to next song, Press and hold to fast forward under Micro SD card mode
Previous: Press to previous song , Press and hold to fast reverse under Micro SD
card mode
Plus(+) Increase volume : MODE LED white light fast flashing when Max.
volume is reached
Power : Press and hold 2 seconds to power on/off
Mode : Press this key to exchange the functions among Bluetooth mode/ Micro SD mode/ Auxiliary input
Hanging Ring
Built-in Mic
Answer the call button : when call coming ,shot press to answer the phone or
hang up the phone, Press and hold to reject the phone
Normal status : Press and hold this key to open or close locking key function ,
white flashing one time to indicate
Play/Pause : press to play or pause
Press and hold to set the speaker to discoverable mode and allow pairing with
another Bluetooth device
Minus (-) decrease volume

05 Interface function English
Reset hole
MICRO USB
Auxiliary input port
Connect to mobile phone ,MID ,MP3 and other
music players without bluetooth
Micro SD card slot
Insert micro SD card to play the music stored in card
Data transfer
When the speaker power off , insert micro SD card ,connect the speaker
to computer to copy or delete files from the micro SD card
Charging :
To charge the battery , connect the power supply to the speaker and
plug it into a live AC (mains) outlet, or connect to USB outlet .

06 Charging LED light English
Battery Indicator
75% of full charge
Continuous white
100% full charge
Continuous white
15% of full charge
(low battery ,charge
needed)
Turn to be red
Power off soon
Flashing red
Charging LED light
15% of full
charge
Continuous
white Flashing in turn
75% of full
charge
Flashing
Charging
Flashing in turn
Notes:
When low battery , power on the red LED fast flickering , and then power off 15 seconds later
Continuous
white
30% of full charge
Continuous white

07 MODEL LED Indicator English
Power on : white flashing ,ready for bluetooth paring ,
paired continuous white
Micro SD card playing mode : white LED light keeps on
Micro SD card playing pause : White LED light flickering
Auxiliary works mode : White LED light keeps on
Auxiliary Mute mode: White LED light flickering
Max. volume : White LED light fast flickering
Normal status : Press and hold this key to open or close locking key function ,
white flashing one time to indicate
Pause in bluetooth mode: white slow flashing

08 Pairing with Bluetooth devices English
Bluet ooth
Blu etoo th OFF
Dev ices
Mif a_F5 u npai red
Devices
Mifa_F5
Wireless range
up to 10m
When pairing is
complete ,,white
LED light remains
steadily on
Turn on the Bluetooth device , set it
to “discover ” the “Mifa-F5” ,then
locate the Bluetooth device list
,from the Bluetooth device list
select the device named “Mifa_F5”,
and then start to connect .
Power on the speaker ,after
“Dingdong” sound and
“Bluetooth enabled” ,blue
light flickering , allow pairing
a Bluetooth device.
Notes:
1, The default password is “0000”
2. The speaker will auto connect the last paired device when it powers on
3. If want to connect other devices , press to disconnect first ,and then the speaker
Is discoverable and ready to pair a new device

09 Technique Parameters English
148mm
55mm
Product size : W55×D55×H148mm
Product weight ：300g（including battery inside）
Speaker type Portable Bluetooth Speaker
Speaker system 2.0 channel +bass
Active /passive Active
Operate mode
DSP 3D surround stereo sound effect,
Bluetooth ,hands-free , Auxiliary etc
Basic parameters
Button
Main functions
Storage type Max.32GB micro SD card
Power supply built in 1200mAh lithium battery
DC5V-500mA USB adapter
File format APE、FLAC、WAV、WMA、MP3
Bit Rate
Playing function
MP3、8Kbps-320Kbps
WMA、32Kbps-384Kbps
RMS 6W THD=10%
Frequency Response
100Hz~20KHz
Technique Parameters
Loudspeaker 1.5inch *2 +bass radiator
Bluetooth version
Bluetooth 3.0+EDR
USB specification
USB2.0 Compatible with USB1.1
APE、600Kbps-1400Kbps
FLAC、600Kbps-1400Kbps
WAV、32Kbps-1200Kbps

10 FAQ English
Paired Bluetooth
device will not connect
Problems What to do
1.Restar t the speak er
2.If need password , please input “0000”
File format fault
1. Check if the TF card format is right (the speaker just can
support FAT 32 format TF card )
Music play hang up Please check the Bluetooth connection valid distance or if
something cut off the signal
Speaker indicates a
connection ,but is not
playing music
1.Check the volume of speaker
2.Check if the speaker is in mute or pause
Poor sound quality
From the AUX source Check if the audio cable connect right
Speaker will not turn on Check if the battery is low
System halted Reset the speaker
2.Check if the music file format store in TF card is right ,the
speaker just can support APE/FLAC/WAV/WMA/MP3 format
files
©2013 MIFA all rights reserved .The product and the packaging trademarks or registered trademarks of
MIFA INNOVATIONS LLC in the united states or other countries .All rights reserved . Other trademarks and
trade names are registered mark of their respective owners . MIFA INNOVATIONS LLC for any errors that may
occur in this manual does not undertake any responsibility. The information contained in this manual are
subject to change no prior notice.
MIFA INNOVATIONS LLC Hotline ：[phone] www.mifalife.net Made in China
