Mifold Grab-and-Go Child Restraint User manual

Age 4 years and upwards
Group 2/3 (15-36kg)
Approved to ECE R44.04
P/N - 1189 Rev. B GB
the Grab-and-Go Child Restraint
TM

32
Congratulations on buying your mifold
Grab-and-Go Child Restraint. mifold is the most
advanced, compact, and portable child restraint
ever invented. mifold is more than 10x smaller
than a regular backless child restraint, and is just
as safe*.
We hope that you are delighted and satisfied
with mifold. We always enjoy hearing from
customers with your ideas, thoughts, feedback,
pictures and videos.
You can contact us in many ways:
[email protected].uk
www.mifold.co.uk/pages/contact-us
pinterest.com/mifold
facebook.com/mifolduk
instagram.com/mifolduk
*Safety claim based on compliance with
UNECE Regulation 44/04.
Introduction to your mifold
Grab-and-Go Child Restraint
Before using this child restraint it is important
to understand how to properly install your
child restraint, secure your child correctly,
and familiarise yourself with the features and
functions of the child restraint.
It is important to take the time to read and
understand these instructions fully. This is best
done with the mifold Grab-and-Go child restraint
in front of you.
Read all the safety warnings before using the
child restraint.
User Manual Storage
It is most important that these instructions
remain with the mifold Grab-and-Go child
restraint at all times. Store these instructions in
the slot located on the edge of the mifold Grab-
and-Go child restraint.
Read and follow all instructions and information
in this manual, on the product
labels, and in the vehicle owner’s manual for
child restraint and vehicle seat belt use.

54
mifold Grab-and-Go Child Restraint Features
E
F
ALH
G
H
I
CRH
BRH
CLH
B
LH
RH
DD
Shoulder Belt Guide Strap
Shoulder Belt Guide
Shoulder Belt Guide Buckle
Child Restraint Cushion
User Manual
Child Restraint
Lap Belt Guide (RH & LH)
Lap Belt Slot (RH & LH)
Lap Belt Guide Release Button (RH & LH)
E
F
G
H
I
A
B
C
D

76
Safety Instructions Safety Instructions
yAlways give preference to using the rear seats of
your vehicle even if your highway code permits the
use on the front seat.
yCheck your highway code as this regulation may vary
according to the country.
yCheck the vehicle manual for advice on tting your
car seat in the front of the vehicle.
yAirbags can cause injury. Do not use this seat on
passenger seats tted with a frontal airbag.
yYour mifold Grab-and-Go child restraint must be
positioned and installed so that, under normal vehicle
usage conditions, no part can become jammed under
or between any moveable seat, or in the vehicle door.
yMake sure there is no loose luggage or other large
objects that are likely to cause injuries in the event of
an accident. These items may cause injury to other
occupants. Always secure loose items.
yShade your child restraint from sunlight to avoid hot
items causing injury to your child.
yDo not modify or add to your car seat in any way
without the approval of a competent authority or the
manufacturer, as this will void any warranty.
yToxic cleaning uids can cause illness. Never use
bleach, do not iron, do not machine wash and do not
tumble dry as this could damage the product.
yDo not leave your child unattended while in the child
restraint and in the vehicle.
yThe mifold child restraint is a unique design that
absorbs some of the forces in a vehicle crash when
occupied by a child. These crash forces can deform
parts of the child restraint and result in damage that
may not be detectable by a visual inspection. As a
result, the child restraint MUST be replaced after any
crash in which the child restraint was occupied.
yFor a crash in which the child restraint was stored
and remained in place or was secured with the lap
portion of the vehicle seat belt passing through both
lap belt guides, and was unoccupied at the time of the
crash, the mifold may continue to be used.Store your
child restraint in a safe area when your child is not in
the car seat. An unsecured child restraint can cause
injuries in the event of a collision.
yIf you are in any doubt about any part of the
installation or proper use of your child restraint,
contact the child restraint manufacturer.
yFailure to follow these instructions may
affect your child’s safety.
yKeep these instructions with the child restraint to
refer to for future reference.

98
The seat can be used for a child aged 4 years and
above, weighing 15kg – 36kg, securing the child
with the adult 3 point seat belt approved to
ECE R16.
Note: Your child restraint is designed to t only
with a 3 point lap and diagonal seat belt and
must not at any time be tted using only a
2 point lap belt.
Install your child restraint Prepare Your
Child Restraint
Open the child restraint and fold out the upper body.
To unlock the lap belt guides, slide the Lap
Belt Guide Release button forward.
To lock the guides, release the Lap Belt
Guide Release button.
NO
2
1

1110
Extract the lap belt guides and position
according to the chart.
To access the
shoulder belt guide
strap, pull open the
shoulder belt guide
buckle.
To shorten or lengthen
the shoulder belt guide
pull the strap in the
desired direction.
4 4a
3
Ensure that the shoulder belt guide
is positioned above and centred on
your child’s shoulder.
5 5a

1312
Position your child sitting upright on the child
restraint and if necessary, slide lap belt guides into
the position nearest to, but not touching the child’s
thigh. Pull out the lap belt guides to check they are
locked into position.
8 8a
Extract the vehicle seat belt and pass it across the
front of your child. Slide lap belt portion of vehicle
seat belt through both lap belt guides and connect
the seat belt tongue into the vehicle buckle.
9
Install Your
Child Restraint
Ensure that the child restraint is laid at and up
against the back rest of the vehicle seat.
For contoured vehicle
seats, position back
of child restraint on
contour and in contact
with vehicle seat back.
Seat child on the child
restraint with child’s
bottom and back in
contact with the vehicle
seat back cushion.
7
66a

1514
Ensure that the lap portion of the vehicle seat
belt has passed through the lap belt slots on
both sides of the child restraint.
12
Insert the lap portion only of the vehicle seat
belt through the red belt guides on each side of
the child restraint.
WARNING! If the vehicle seat belt
tongue is up against the red lap
belt guide such that you cannot
tighten the seat belt, this condition
is unacceptable. You must use a
different seat position.
11
To position the shoulder belt guide, attach the
shoulder belt guide to the diagonal portion of
the vehicle seat belt, by opening the clip and
inserting the seat belt. Then close the clip.
10 10a

1716
Ensure that the lap portion is positioned
over the child’s lap and supported on the
child’s pelvis.
14
Remove any twists or seat belt slack by pulling on
the lap portion and then the diagonal portion of
the adult seat belt.
13a13 Pull up on vehicle shoulder belt to remove slack
from lap portion of vehicle seat belt and snugly
adjust lap belt around child.
Check that vehicle lap belt is low on hips and
contacting thighs.
15

1918
Final checklist
However safe a child seat is, however well
built it is, your child’s safety depends on you
carrying out the following checks before every
journey:
yCheck that the child restraint is facing
forwards in the vehicle and in the direction
of travel.
yCheck that the vehicle seat belt is tted
correctly with the shoulder belt engaged
with the shoulder belt guide, the lap strap
is attached to the red lap belt guides, and the
tongue is connected to the buckle.
yCheck that the vehicle seat belt is not
twisted or slack
IMPORTANT! Misusing your child seat
will reduce the protection and safety
you offer your child.
Additional information
This child restraint is not approved for use on
aircraft. For more information, contact the
airline.
To dispose of your child restraint safely always
render the seat unusable.
IMPORTANT! Make sure the
instruction book is removed from the
slot before cleaning.
Toxic cleaning uids can cause illness.
Never use bleach, do not iron, do not machine
wash, do not tumble dry as this could
damage the cover and require replacing.
Safety Warning
Maintenance advice
The child restraint cover is not removable. In
case of light staining, clean using a damp cloth
or soapy water.

2120
Notice
This child restraint is a “Universal” child
restraint system. It has been approved in
accordance with regulation ECE R44/04, and
is suitable for general use in vehicles, and is
compatible with the majority of vehicle seats.
yThis child restraint is likely to t if the
vehicle manufacturer states that the
vehicle approval species suitability for
“Universal” child restraint systems.
yThis restraint system is classied as
“Universal” in accordance with the strictest
approval criteria, whereas earlier models
do not correspond to these new provisions.
yThis restraint system can only be installed
in vehicles with 3-point static or retractable
seat belts that have been approved
compliant with the UN/ECE No.16 or other
equivalent standards.
If in doubt, contact the manufacturer of the
restraint system.
© 2018 Carfoldio Ltd. CarfoldioTM. mifold®and
mifold the Grab-and-Go Child RestraintTM, are
registered trademarks of Carfoldio Ltd.
This innovative product is protected by patents
and design registrations worldwide, including
U.S. Pat. No. 9,376,088 and European Pat.
No. 13 797 456.4-1503 and other patents pending.
All pictures are illustrations.
Actual product may vary.

2322
MEMO MEMO
