mikroElektronika Touchpad click User manual

2 3
2. Soldering the headers
3. Plugging the board in
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the cut
in the lower-right part of the board with the
markings on the silkscreen at the mikroBUS™
socket. If all the pins are aligned
correctly, push the board all the
way into the socket.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click board™, make sure
to solder 1x8 male headers to both left and
right side of the board. Two 1x8 male headers
are included with the board in the package.
4. Essential features
The MTCH6102 device supports taps,
doubletaps, swipes and scrolling gestures.
The small capacitive surface is optimized
for sungle-nger applications. The sensor
outputs 12-bit resolution coordinate
data (the I2C interface supports up to
400 kbps transfer rates). MTCH6102 also
incorporates power-saving features, such
as a congurable frame rate for sleep/idle
modes, as well as a separate standby and
active mode.
1
Touchpad click is a capacitive touch
input device driven by Microchip’s low-
powered MTCH6102 controller. The
touchpad surface is covered with a sheet
of black plastic to demonstrate the chip’s
support for cover layers (up to 3mm for
plastic, 5mm for glass) Touchpad click
communicates with the target MCU through
the mikroBUS™ I2C interface (SCL and SDA
pins), with additional functionality provided
by the Interrupt and RSTL pins. Designed to
use a 3.3V power supply.
1. Introduction
Touchpad click Manual v100
0100000091166
click
BOARDS™
www.mikroe.com
Touchpad click
Touchpad click Manual v100

AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
1
2
3
4
5
6
7
8
9
10 11
12
13 14
15
16
17
18
19
20
21
22 23
24 25 26
27
28
RX11
RX12
NC
RX13
VSS
NC
NC
INT SYNC RX14 SCL SDA RX0 RX1
RX8 RX7
RX10
RST
NC NC
RX6
RX3
RX5
RX4
VDD
VSS
RX2
NC
U1
R1
470
C1
100nF
VCC-3.3V
VCC-3.3V
RX6
RX5
RX4
RX3
RX2
VCC-3.3V
RX13
RX12
RX11
RX10 RX8 RX7RX1
RX0 RX14 INT SCL SDA
R2
100
R3
20K
RST
RST
R4
4K7
R5
1K8
R6
1K8
VCC-3.3V
INT
SCL
SDA
RX9
RSTL
8. Code examples
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end of
the product’s lifetime, so if something goes
wrong, we’re ready and willing to help!
Once you have done all the necessary
preparations, it’s time to get your click board™
up and running. We have provided examples
for mikroC™, mikroBasic™ and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
.com
6. Dimensions
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specication and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
mm mils
LENGTH 42.9 1690
WIDTH 25.4 1000
HEIGHT* 3.9 154
5. Schematic
9. Support
* without headers
10. Disclaimer
25.4 mm / 1000 mils
42.9 mm / 1690 mils
7. HMI click boards™
Touchpad click is just one of several input
devices on click boards. For the entire
selection, visit:
www.mikroe.com/click
