mikroElektronika Serial Flash PROTO User manual

MikroElektronika
Serial Flash PROTO™
Manual
All Mikroelektronika’s development systems feature a large number of peripheral
modules expanding microcontroller’s range of application and making the
process of program testing easier. In addition to these modules, it is also
possible to use numerous additional modules linked to the development system
through the I/O port connectors. Some of these additional modules can operate
as stand-alone devices without being connected to the microcontroller.
Additional Board

MikroElektronika
Figure 3: Additional board schematic Figure 4: Dimensions of the board
Figure 1: Serial Flash PROTO Figure 2: Back side of Serial Flash PROTO
The function of pins provided on the Serial Flash PROTO board:
CS - Chip select
HOLD - Hold
SCK - Serial Clock
MISO - Serial Data output
MOSI - Serial Data input
VCC-3.3 - 3.3V power supply voltage
GND - Ground
How to connect the board?
The Serial Flash PROTO board is connected to other devices via the Serial Peripheral Interface (SPI). Connection is
established via a 1x7 connector CN1 provided on the additional board. Next to the CN1 connector, there are designations
indicating the function of pins provided on the additional board.
Serial Flash PROTO
The Serial Flash PROTO additional board features 8Mbit ash memory that can be used by the microcontroller or some
other device.
Key features:
- SPI communication;
- 75Mhz (max) clock signal;
- 3.3V DC power supply voltage; and
- low power consumption.
