Miles Industries Valor L3 Series Operating instructions

L3 Series
DV ZC Gas Fireplace
1800JN (natural gas) & 1800JP (propane gas)
Installation & Owner’s Manual
4004995-07
©2017, Miles Industries Ltd.
This manual contains instructions to install the
ENGINE ONLY. A front or trim kit is REQUIRED
to install the engine. A barrier screen is provided
with the front or trim kit. Refer to the manual
supplied with the front or trim for installation.
— Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪ Do not try to light any appliance.
▪ Do not touch any electrical switch; do
not use any phone in your building.
▪ Leave the building immediately.
▪ Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
▪ If you cannot reach your gas supplier,
call the fi re department.
— Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
Ce guide est disponible en français sur demande.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
! WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
INSTALLER
Leave this manual
with the appliance.
CONSUMER
Retain this manual
for future reference.
Please read this manual
BEFORE installing and
operating this appliance.

2
Table of Contents
Commonwealth of Massachusetts...............18
Specifi cations ................................................ 20
Overview.........................................................21
Dimensions & Location .................................22
Mantel & Hearth Clearances .........................23
Framing Requirements .................................25
Venting ............................................................28
Co-axial Venting.............................................29
Installation Planning .....................................33
Plan Wall Finish .......................................................34
Installation ......................................................35
Unpack the Appliance ..............................................35
Install the Standoff s ................................................. 35
Remove Heat Shield ................................................ 36
Convert Vent Outlet (if required) ..............................36
Fit optional LDK Duct Kit’s take-off collars to
appliance (if used) ................................................36
Fit the Appliance into Framing .................................36
Remove Window .....................................................37
Complete Installation of optional LDK Duct
Kit (if used)............................................................37
Install Electrical Wiring (for optional accessories) ... 38
Set-up Gas Supply ..................................................39
Install Liners ............................................................41
Install Driftwood Kit 1800DWK ................................ 43
Install Decorative Glass Murano 1800DGM ............ 46
Refi t Window ...........................................................47
Install Remote Battery and Wall Switch Kit
RBWSK (required) ................................................ 48
Initialize Remote Control .........................................50
Check Operation ...................................................... 50
Set Aeration (if necessary) ...................................... 50
Install Plinth Support Bracket ..................................51
Install Trim and Barrier Screen ................................51
Install Remote Control Handset Wall Holder ...........51
Wiring Diagram ..............................................52
Approved Venting Components ................... 53
Warranty .........................................................55
Spare Parts.....................................................56
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts. Also, see Carbon Monoxide
Detector requirements on page 18.
Designed and Manufactured by / for
Miles Industries Ltd.
190–2255 Dollarton Highway,
North Vancouver, BC, CANADA V7H 3B1
Tel. [phone] Fax [phone]
www.valorfi replaces.com
FOR THE OWNER FOR THE QUALIFIED INSTALLER
The information contained in this installation manual
is believed to be correct at the time of printing. Miles
Industries Ltd. reserves the right to change or modify
any information or specifi cations without notice.
Miles Industries Ltd. grants no warranty, implied or
stated, for the installation or maintenance of your
heater, and assumes no responsibility for any conse-
quential damage(s).
Warranty Card at the
back of this manual.
W
A
R
R
A
N
T
Y
P
R
O
G
R
A
M
W
A
R
R
A
N
T
Y
P
R
O
G
R
A
M
V
A
L
O
R
C
O
M
F
O
R
T
V
A
L
O
R
C
O
M
F
O
R
T
V
A
L
O
R
C
O
M
F
O
R
T
© Copyright Miles Industries Ltd., 2017. All rights reserved.
Safety Precautions .......................................... 3
Safety and Your Fireplace ...............................4
Owner’s Information ........................................5
Operating Your Fireplace for the First Time ...............6
Cleaning Your Fireplace ............................................6
Checking Pilot and Burner Flames ............................8
Replacing Batteries ...................................................9
Using Remote Control Handset Wall Holder ............. 9
Locating Lighting, Operation and Rating
Information Card ..................................................... 9
Servicing Your Fireplace ............................................9
Fireplace Control Devices ....................................... 10
How to Turn Your Fireplace OFF (including pilot) ....10
How to Ensure Your Fireplace Cannot
Be Turned ON Inadvertently .................................10
Remote Control Operation ............................ 11
Wall Switch Operation ...................................16
Options ...........................................................16
Lighting Instructions .....................................17
Warranty .........................................................55

3
Safety Precautions
!
Children and adults should be ALERTED to the hazards
of high surface temperature and should STAY AWAY to
avoid burns or clothing ignition.
YOUNG CHILDREN should be CAREFULLY
SUPERVISED when they are in the same room as the
appliance. Toddlers, young children and others may
be susceptible to ACCIDENTAL CONTACT BURNS.
A physical barrier is recommended if there are at-risk
individuals in the house. To restrict access to a fi replace
or stove, INSTALL AN ADJUSTABLE SAFETY GATE
to keep toddlers, young children and other at-risk
individuals out of the room and away from hot surfaces.
DO NOT place furniture or any other combustible
household objects within 36” of the fi replace front.
READ and UNDERSTAND all instructions carefully
before starting the installation. FAILURE TO FOLLOW
these installation instructions may result in possible fi re
hazard and will void the warranty.
Prior to the fi rst fi ring of the fi replace, READ the
Owner’s Information section of this manual.
DO NOT USE this appliance if any part has been under
water. Immediately, CALL a qualifi ed service technician
to inspect the unit and to replace any part of the control
system and any gas control that has been under water.
THIS UNIT IS NOT FOR USE WITH SOLID FUEL.
Installation and repair should be PERFORMED by a
qualifi ed service person. The appliance and venting
system should be INSPECTED before initial use and at
least annually by a professional service person. More
frequent cleaning may be required due to excessive
lint from carpeting, bedding, etc. It is IMPERATIVE that
the unit’s control compartment, burner, and circulating
air passageways BE KEPT CLEAN to provide for
adequate combustion and ventilation air.
Always KEEP the appliance clear and free from
combustible materials, gasoline, and other fl ammable
vapors and liquids.
NEVER OBSTRUCT the fl ow of combustion and
ventilation air. Keep the front of the appliance CLEAR
of all obstacles and materials for servicing and proper
operation.
Due to the high temperature, the appliance should be
LOCATED out of traffi c areas and away from furniture
and draperies.
Clothing or fl ammable material SHOULD NOT BE
PLACED on or near the appliance.
This unit MUST be used with a vent system as
described in this installation manual. NO OTHER vent
system or components MAY BE USED.
This gas fi replace and vent assembly MUST be vented
directly to the outside and MUST NEVER be attached
to a chimney serving a separate solid fuel burning
appliance. Each gas appliance MUST USE a separate
vent system. Common vent systems are PROHIBITED.
INSPECT the external vent cap on a regular basis to
make sure that no debris, plants, trees, shrubs are
interfering with the air fl ow.
DO NOT OPERATE this appliance with the glass door
removed, cracked, or broken. Replacement of the glass
door should be performed by a licensed or qualifi ed
service person. DO NOT strike or slam the glass door.
The glass door assembly SHALL ONLY be replaced
as a complete unit, as supplied by the fi replace
manufacturer. NO SUBSTITUTE material may be used.
A BARRIER DESIGNED TO REDUCE THE RISK OF
BURNS from the hot viewing glass is provided with
this appliance and SHALL BE INSTALLED for the
PROTECTION OF CHILDREN and other AT-RISK
INDIVIDUALS.
DO NOT USE abrasive cleaners on the glass door
assembly. DO NOT ATTEMPT to clean the glass door
when it is hot.
If the barrier becomes damaged, the barrier SHALL BE
REPLACED with the MANUFACTURER’S BARRIER
for this appliance.
TURN OFF the gas before servicing this appliance.
It is recommended that a qualifi ed service technician
perform an appliance check-up at the beginning of each
heating season.
Any safety screen, guard or barrier removed for ser-
vicing the appliance, MUST BE REPLACED prior to
operating the appliance.
BE CAREFUL not to put any decorating objects
sensitive to heat to close above or around the fi replace
as it gets very hot when operating.
DO NOT use this heater as a temporary source of heat
during construction.
This appliance is a DOMESTIC ROOM-HEATING AP-
PLIANCE. It must not be used for any other purposes
such as drying clothes, etc.
State of California. Proposition 65 Warning. Fuels
used in gas, wood-burning or oil fi red appliances,
and the products of combustion of such fuels, contain
chemicals known to the State of California to cause
cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6.
The glass door assembly MUST be in place and sealed
before the unit can be placed into safe operation.

4
Safety and Your Fireplace
Please Follow These Important
Child Safety Precautions and
Recommendations,
• Parts of your Valor Fireplace become
extremely hot while in operation.
• The glass viewing window
temperature can
exceed 500 F
at full capacity.
Momentary contact
with a hot glass
surface can cause
a severe burn, even if the fi replace
is operating at reduced heating
capacity.
• The glass window will remain hot
for an extended period of time after
the fi replace has been turned off .
Ensure that children are prevented
from touching the fi replace during the
cool down period.
• Toddlers and Young Children
must be closely supervised at all
times when they are in the same
room as the operating fi replace. They
lack full awareness of danger and
rely on your protection. Toddlers,
in particular, do not have the motor
skills and response refl exes to
withdraw in the event of accidental
contact with a hot surface.
• A physical barrier is strongly
recommended if there are young
children, or at-risk individuals in the
house. Install an approved after-
market safety gate to keep toddlers,
young children and other at-risk
individuals a safe distance from the
fi replace.
• Keep the remote control handset
out of reach of children at all
times. A wall mount storage holster
is provided with your remote control
handset.
• Ensure that the fi replace, including
the pilot light, is completely turned
off when children are present and
close supervision and safety barriers
are not available—see page 10
of Owner’s Information section.
• If the fi replace is not going to
be used for the summer or any
extended period of time, remove the
batteries from the remote control
handset and wall battery holder.
It is recommended that batteries are
replaced annually in any event—see
page 9.
Please Read and Carefully Follow all Safety Warnings and
Operating Instructions Contained in Your Owner’s Manual
(Replacement Manuals are available by contacting our service department at
1-800-468-2567 or visit www.valorfi replaces.com).
Safety and Your Fireplace
!

5
Owner’s Information
!WARNING
EXTREMELY HOT!!!
• READ the SAFETY information on pages
3 and 4 of this manual BEFORE operating
your gas heater.
• Some parts of your fi replace are EXTREMELY
HOT, particularly the GLASS window.
• DO NOT LET CHILDREN touch the glass or
any parts of your fi replace even after it is
turned off as it is still hot.
• USE THE BARRIER SCREEN provided with
the trim or a GATE to reduce the risk of severe
burns.
• Keep the remote control handset OUT OF
REACH of children.
• HOT WALL SURFACES! The wall directly above
the fi replace is VERY HOT when the fi replace
heats. It is constructed of non-combustible
materials and although safe, it may reach
temperatures in excess of 250º F depending
on choice of trims or optional accessories. DO
NOT TOUCH! We recommend installing the
optional LDK HeatShift Duct Kit when hot
walls are a concern.
•
•
Some materials or items, although safe, may
Some materials or items, although safe, may
discolor, shrink, warp, crack, peel, and so on
discolor, shrink, warp, crack, peel, and so on
because of the heat produced by the fi replace.
because of the heat produced by the fi replace.
AVOID PLACING
AVOID PLACING
candles, paintings, photos,
candles, paintings, photos,
and other items
and other items
SENSITIVE TO HEAT
SENSITIVE TO HEAT within
36 inches (0.9 m) around the fi replace.
• Solid wood fl ooring in front of the fi replace (if
allowed) may shrink during the heating season
due to heat.
Performance of propane gas appliances may
be aff ected by the quality of commercial gas
supplied in your area.
Do not put
furniture or other objects
in this space in front of
the replace:
36” (0.9 m)
Fireplace
Hearth
WARNING
If fitted with optional LDK HeatShift
Duct Kit, DO NOT COVER OR PLACE
ITEMS IN FRONT OF OUTLET(S)!
!
This appliance is designed and approved as a
supplemental heater and provides the potential
for most energy conservation when used while
attended. The use of an alternate primary heat
source is advisable.
This manual and particularly the preceeding and
following pages contain very important information
regarding the safe operation of your fi replace as
well as maintenance instructions.
Read carefully BEFORE operating your fi replace and
pay special attention to the SAFETY WARNINGS.
A heating gas appliance does require safe handling
and for this reason, we very strongly recommend that
no children be allowed to touch the fi replace and its
controls at all times. Do install a screen or barrier
in front of the fi replace to protect your children
against severe burns.
Thank You ...
For purchasing a Valor by Miles Industries. Your new
radiant gas heater is a technical appliance that must be
installed by a qualifi ed dealer. Each Valor fi replace is fully
tested during the production process for your safety and
comfort.
Your unit has been professionally installed by:
Dealer Name: ________________________________
Phone Number :_______________________________
Should you encounter an operational problem, call
your dealer immediately.
Do not try to repair the unit as you may cause an
injury or damage the fi replace.
OWNER’S
INFORMATION

6
Owner’s Information
WARNING
DO NOT TOUCH THE GLASS WHILE IT IS HOT!
Let the fi replace cool fi rst before cleaning it.
!
Spring Loaded Window Levers
Operating Your Fireplace for the First Time
When operating your new fi replace for the fi rst time,
some vapors may be released due to the burning of
curing compounds used in the manufacture of the
appliance. They may cause a slight odor and could
cause the fl ames to be the full height of the fi rebox, or
even slightly higher, for the fi rst few hours of operation.
It is also possible that these vapors could set off any
smoke detection alarms in the immediate vicinity.
These vapors are quite normal on new appliances. We
recommend opening a window to vent the room. After
a few hours use, the vapors will have disappeared and
the fl ames will be at their normal height.
Flame Supervision Device
For your safety, this appliance is fi tted with a fl ame
supervision device which will shut-off the gas supply
if, for any reason, the pilot fl ame goes out. This device
incorporates a fi xed probe, which senses the heat
from the pilot fl ame. If the probe is cool, the device will
prevent any gas fl ow unless manually lighting the pilot.
See full lighting instructions on page 17 of this manual.
Cleaning Your Fireplace
Important - Glass cleaning - Mineral deposits
One of the by-products of the combustion process in
a gas appliance is a mineral which can show up as a
white fi lm on the ceramic glass of the viewing door.
The composition of the deposit varies with location and
time. It is believed to be associated with the varying
sulfur content of the gas. You may have the problem
intermittently.
We have consulted with ceramic glass manufacturers
and they cannot off er a defi nitive solution to this prob-
lem. Dealers have tried various cleaning products with
varying results. The following are recommendations
only and are not meant to guarantee results.
NOTE: This is a problem beyond Miles Industries’
control and is not covered under warranty.
• Clean the glass regularly as soon as you notice
the buildup (white fi lm). If the fi lm is left for a longer
period of time, it will etch into the glass. It is then
much harder, if not impossible, to remove.
• NEVER use an abrasive cleaner or ammonia-
based cleaner on the ceramic glass. Any
abrasion of the surface has the immediate eff ect of
compromising the strength of the glass. An emulsion
type cleaner is recommended.
• Use a soft damp cloth to apply the cleaner. Dry the
glass with a soft, dry, preferably cotton cloth. Most
paper towels and synthetic materials are abrasive to
ceramic glass and should be avoided.
• Our dealers have had good results from the
products listed below. We cannot, however,
guarantee the results of these products.
◊ Brasso, Polish Plus by Kelkem, Cook Top Clean
Creme by Elco, White Off by Rutland, Turtle Wax
Do not clean the glass while it is hot!
Always securely replace the window and the barrier
screen before lighting.
If broken, the glass pane may only be replaced
as a complete window unit as supplied by the
manufacturer.
If the barrier becomes damaged, the barrier shall
be replaced with the manufacturer’s barrier for this
appliance.
To remove the window for cleaning, we suggest
you get help from another person as the window
is long and heavy:
1. Remove the barrier screen.
2. Remove the side doors and the plinth.
3. Remove plinth support bracket.
4. Find the levers on each
side of the window towards
the top. Using your fi nger,
pull the levers towards you
and unhook them from the
window frame brackets.
Remove plinthRemove side doors
OWNER’S
INFORMATION

7
Owner’s Information
WARNING
CHOKING HAZARD! Ensure that the fi replace
area is clear of fi reglass or vermiculite particles as
these could be ingested by small children. Vacuum
thoroughly around the fi replace area after cleaning.
5. Gently pull the top of the window outward.
6. Lift the window out of its bottom railing and set it
aside in a safe place to avoid damage.
Clean the window following the guidelines in this section.
Clean the trim with mild soap and warm water. Any
alcohol/solvent base cleaner will weaken the coating
and damage it.
Clean the barrier screen dusting it with a soft brush.
Clean the fi rebox ceramic logs/rocks and walls dust-
ing them with a soft brush. Dust can also be removed
from the burner using a soft brush after removing the
ceramic logs. When cleaning, make sure that no par-
ticles are brushed into the slots of the burner.
To refi t the window:
1. Place the window in its bottom railing. Ensure to
remove any vermiculite or glass particles in the
railing before installing the window.
2. Push the top
of the window
frame against
the fi rebox.
!
Window frame
Bottom railing
3. While you hold it, pull and hook the side levers back
to the window brackets on each side.
4. Apply fi rm hand pressure around the window frame to
ensure the window is sealed tight against the fi rebox.
1
2
3
WARNING
Failure to install the window correctly can
leak carbon monoxide, aff ect the performance
of the fi replace, damage components, cause
overheating resulting in dangerous conditions.
Damage caused by incorrect window installa-
tion is not covered by the Valor warranty.
!
DANGER
The window unit must be correctly installed,
fastened and sealed after servicing or serious
bodily injury and/or damage to the appliance
may result.
To ensure a safe operation:
• Double-check that the bottom of the window
frame is correctly installed in the bottom
support railing;
• Verify that the levers are hooked properly to
the window tabs then;
• Pull out the top of the window and release it
to insure the springs return it;
• Ensure the window is sealed before operation.
!
OWNER’S
INFORMATION

8
Owner’s Information
Driftwood Kit Correct Flame Picture
Murano Glass Fire Correct Flame Picture
Pilot Flame can
be seen left of
the fi re bed
Pilot Flame can be seen
between the front and
rear left logs
Pilot Flame Thermocouple Probe
must be in Flame
5. If the Hot Glass Warning plate has been
removed from the front lower corner of the
window, reinstall it by sliding it between the
glass and the frame as indicated.
6. Reinstall the plinth support
bracket hooking it up to the
stiff ener bracket located
below the window as
shown.
7. Reinstall the plinth and side doors.
8. Reinstall the barrier screen on the trim..
9. Verify that the screen is properly hooked to the trim
and secure.
Checking Pilot and Burner Flames
A periodic check of the pilot and burner fl ames should
be made. Check after the fi re has been on for at least
30 minutes. The pilot fl ame must cover the tip of the
thermocouple probe. The main burner fl ame pattern will
vary from appliance to appliance depending on the type
of installation and climatic conditions.
The appliance area must always be kept clear and
free from combustible materials, gasoline and other
fl ammable vapors and liquids.
Inspect the vent terminal outdoors regularly to make
sure that snow, trees, bushes, leaves, or other objects
do not obstruct it.
Examine the vent system and terminal regularly. We
recommend annually.
WARNING
FOR SAFETY PURPOSE, ensure the barrier
screen is re-installed on the fireplace front
after maintenance.
!
Hot Glass Warning Plate
Plinth
support
bracket
Stiff ener
bracket
OWNER’S
INFORMATION

9
Owner’s Information
WARNING
DO NOT ATTEMPT TO TOUCH THE DATA CARD
WHILE THE FIREPLACE IS STILL HOT! Let the
fi replace cool fi rst before touching it.
WARNING
DO NOT ATTEMPT TO CHANGE THE BATTER-
IES WHILE THE FIREPLACE IS STILL HOT! Let
the fi replace cool fi rst before touching it.
CAUTION
DO NOT USE a screwdriver or other metallic object
to remove the batteries from the battery holder or
the handset! This could cause a short circuit.
Using Remote Control
Handset Wall Holder
Your fi replace equipment includes a wall
holder to store the handset. If it hasn’t be
installed, refer to the instructions further
on in this manual for the installation.
Locating Lighting, Operation and Rating
Information Card
The Lighting, Operation and Rating information is
located on a card at the right hand side of the fi replace
opening. The card is attached under the plinth.
To access the card, remove the barrier screen, side
doors and the plinth. Grab the rolled card and pull it out
of its clip. There is important information on both sides
of the card.
Servicing Your Fireplace
If any attention is required for your appliance, contact
your supplier quoting the model number. It will be
helpful if the appliance’s serial number can also
be quoted. This number is on the rating plate. The
replacement parts are shown at the end of this manual.
Please always quote the part number and description
when requesting spare parts.
Replacing Batteries
Low batteries signal: see page 15.
BEFORE changing the batteries, turn the fi replace
off (including pilot).
The appliance uses four 1.5 V AA alkaline batteries
located next to the wall switch and one 9 V alkaline
battery in its handset. Batteries should last one to two
seasons, depending on usage. Removing the batteries
in the off -season will extend the battery life.
To replace the batteries:
The battery compartment is located next to the wall
switch in the vicinity of the fi replace. Its front plate is
attached with magnets to the wall switch box.
1. Pull on the plate next to
the wall switch to access
the batteries.
2. Disconnect the snap
connector from the battery
holder. Do not pull the
connector by the wire!
3. Replace the batteries with
4 AA alkaline batteries
orienting them as indicated
inside the holder.
4. Reconnect the snap
connector to the battery
holder.
5. Put the battery holder back
in its place beside the wall
switch and snap it in place.
!
!
Data
card
Window
The data card is located behind the front panel below
the window at the right-hand side.
Battery holder
& wall switch
Fireplace
The battery holder is located beside the wall switch.
Disconnect
connector
OWNER’S
INFORMATION

10
Owner’s Information
Gas valve
How to Ensure Your Fireplace Cannot
Be Turned ON Inadvertently
You can use one of the two following methods to
ensure that your fi replace will not turn on when you
don’t want it on.
First, ensure your fi replace is turned off —including
the pilot—and cold BEFORE going ahead.
• Turn the dial on the gas valve from the ON position
to the MAN position as shown. Turning the dial to
MAN (arrow up) will ensure that the main burner can
not come on. The pilot will remain on if it is lit.
• Alternately, remove all batteries from the battery
holder next to the wall switch as well as the battery
from the handset.
Automatic Shut-Off (in certain conditions)
Your fi replace’s remote control is equipped with an
automatic shut-off mechanism which is activated in
certain conditions. See page 15 in the Remote Control
Operation section for a description of this feature.
Battery holder
& wall switch
Fireplace
Receiver Gas valve
The receiver and gas valve are located on the bottom of the
fi replace behind the front panel. The battery holder is located
next to the wall switch.
Fireplace Control Devices
There are two ways to control your fi replace.
1. Thermostatic Remote Control;
2. Wall Switch.
The Thermostatic Remote Control can be programmed
to function automatically—see pages 11–15.
The Wall Switch can be used to turn on, off and to
increase or decrease the fl ame height—see page 16.
How to Turn Your Fireplace OFF
(including pilot)
Familiarize yourself with each of these methods before
operating your fi replace.
Press and hold the OFF button for a second (either on
the handset or the wall switch).
If the fl ames are on, they go down and you hear the
valve motor wind down. You hear a clunk and a beep
indicating that the valve has received the signal from the
remote control.
As well, familiarize yourself with the gas shut-off valve
location in your house. As indicated below, the gas is
running when the handle is parallel with the pipe. The
gas is off when the handle is perpendicular with the pipe.
Wall Switch
Remote control handset
ON: parallel to pipe OFF:
perpendicular
to pipe
Thermostatic
Remote Control
Wall Switch
OWNER’S
INFORMATION

11
Remote Control Operation
NOTE: Before using the remote control system for
the fi rst time, the receiver and the handset must be
synchronized. See the section Initialize Remote Control
on page 50 of this manual.
IMPORTANT: BEFORE YOU BEGIN, please note that
on this system, the settings of time, temperature and
automatic ON/OFF can only be programmed when
the function display is flashing. Be patient when
programming as it can take a few seconds to set.
When the pilot is off , it will take 2
minutes before it can be lit again.
TO TURN ON APPLIANCE TO TURN OFF APPLIANCE
FLAME HEIGHT ADJUSTMENT
• On the valve, turn MAN knob on the ON, full
counterclockwise position.
• Place ON/OFF switch (if equipped) in I (ON
position). STANDBY MODE (Pilot Flame)
• Press and hold (small fl ame) to set appliance at
pilot fl ame.
• Simultaneously press the OFF and
(large fl ame) buttons until a short
beep confi rms the start sequence
has begun; release buttons.
• Continuing beeps confi rm the
ignition is in process.
• Once pilot ignition is confi rmed,
there is main gas fl ow.
• After main burner ignition the
handset will automatically go into
manual (MAN) control mode.
• Press OFF button.
When the pilot is off , it will take 2
minutes before it can be lit again.
• In standby mode: Press and hold
(large fl ame) button to increase
fl ame height.
CAUTION
When pilot ignition is confi rmed, motor turns
automatically to maximum fl ame height.
Set (scrolls
through
modes and
settings)
OFF (returns
to set mode,
turns the burner
and the pilot o)
Large ame
button (ames
up, sets hours,
temperature)
Small ame
button (ames
down and o,
sets minutes,
temperature)
Current
temperature
(F or C)
Current time
(12 or 24 hour clock)
Modes (Manual,
Temperature, Timer)
Handset
sensor
Battery status
Current
programmed
period (Timer)
Period
start or end
(Temp, Timer)
Display Overview
Handset Overview
Note: In the TEMP or TIMER modes, the remote
handset senses the room temperature and adjusts the
fl ame accordingly.
To communicate, the handset should be within 15 feet
(4.5 meters) of the fi replace.
Do not leave the handset on the mantel or hearth.
OWNER’S
INFORMATION

12
Remote Control Operation
SETTING THE TIME
SETTING ºC/24-HOUR OR ºF/12-HOUR CLOCK
MODES OF OPERATION
NOTE: Manual mode can also be reached by pressing
either the (large fl ame) or the (small
fl ame) buttons.
• Press and hold (small fl ame)
button to decrease fl ame height or
to set the appliance at pilot fl ame.
• For fi ne adjustment tap the
(large fl ame) or (small fl ame)
buttons.
• Briefl y pressing the SET button
changes the mode of operation in
the following order:
→ →
→ → and back to .
• Double-click (small fl ame)
button. “LO” will be displayed.
NOTE: Flame goes to high fi re fi rst
before going to designated low fi re.
• In MAN mode, press OFF and
(small fl ame) buttons until display
changes from Farenheit/12-hour
clock to Celsius/24-hour clock and
vice versa.
• The time display will fl ash after
either:
◊ Installing the battery or
◊ Simultaneously pressing the
(large fl ame) and (small
fl ame) buttons.
• Press (large fl ame) button to
set the hour.
• Press (small fl ame) button to
set the minute.
• Press OFF or simply wait to return
to MAN mode.
• Double-click (large fl ame)
button. Flame automatically goes
to high fi re. “HI” will be displayed.
• - Manual Mode - Manual
Flame Height Adjustment.
Express Low and High Fire
• - Daytime Tempera-
ture Mode (Appliance must be in
standby mode; pilot ignited) - The
room temperature is measured and
compared to the set temperature.
The fl ame height is then auto-
matically adjusted to achieve the
Daytime Set Temperature.
• - Nighttime Setback
Temperature Mode (Appliance
must be in standby mode; pilot
ignited) - The room temperature
is measured and compared to the
Nighttime Setback temperature.
The fl ame height is then automati-
cally adjusted to achieve the Night-
time Setback Temperature.
• - Timer Mode (Appliance
must be in standby mode; pilot
ignited) - The timers P1 and P2
(Program 1, Program 2) each can
be programmed to go ON and OFF
at specifi c times. For instructions
see Timer Programming Mode.
NOTE: The display shows the set temperature every
30 seconds.
x 2
x 2
MAN
MAN
MAN
TEMP
TEMP
TEMP
TIMER
TEMP
TIMER
OWNER’S
INFORMATION

13
Remote Control Operation
SETTING THE ON / OFF TEMPERATURES
• Briefl y press SET button to scroll to
TEMP (sun) mode. Hold
the SET button until the TEMP
fl ashes.
• Press (large fl ame) button
to increase the Daytime Set
Temperature.
• Press (small fl ame) button
to decrease Daytime Set
Temperature.
• Press OFF or simply wait to
complete programming.
SETTING THE “DAYTIME” TEMPERATURE
SETTING THE “NIGHTTIME SETBACK”
TEMPERATURE
Default Settings: (sun), 23ºC / 74ºF Default Settings: (moon), “--” (OFF)
• Press (large fl ame) button to
increase Nighttime Setback
Temperature.
• Press (small fl ame) button to
decrease Nighttime Setback
Temperature.
• Press OFF or simply wait to
complete programming.
• Briefl y press SET button to scroll to
TEMP (moon) mode. Hold
the SET button until the TEMP
fl ashes.
Tip
Set the diff erent parameters when they are fl ashing.
TEMP
TEMP
TEMP
TEMP
OWNER’S
INFORMATION

14
Remote Control Operation
SETTING PROGRAM TIMERS
• You can program two periods of time between 12:00
am and 11:50 pm in each 24-hour cycle.
• The Programs P1 and P2 must be set in the
following order during a 24-hour cycle: , ,
and .
• The icon indicates the beginning of the period (ON)
and the icon indicates the end of the period (OFF).
• If = or = , the programming
is cancelled.
• To keep the fi replace ON all night, set at
11:50 am and at 12:00 am.
Default settings:
Program 1: 6:00 am 8:00 am
Program 2: 11:50 pm 11:50 pm
• Briefl y press SET button to scroll to
TIMER mode.
• Hold the SET button until
(sun) is displayed and the time
fl ashes.
• Briefl y press SET button to scroll
to TIMER (moon) while the
time fl ashes.
• Press (large fl ame) button to
set the hour.
• Press (large fl ame) button to set
the hour.
• Press (small fl ame) button to
set the minutes.
• Press (small fl ame) button to
set the minutes.
SETTING P1 ON TIME SETTING P2 ON TIME
• Briefl y press SET to scroll to TIMER mode
(sun) while the time fl ashes.
• Follow the instructions given to set P1 ON time.
SETTING P2 OFF TIME
• Briefl y press SET to scroll to TIMER mode
(moon) while the time fl ashes.
• Follow the instructions given to set P1 OFF time.
Press OFF button to save these settings. The timers
are programmed. See the diagram on programming
sequences on the following page.
Tip
If you want to program only one period, program
and with desired times and program and
with the same time as .
SETTING P1 OFF TIME
P1
P1
P1
P1
P1 P1
P2
P2
P2
P2
P2
P2
P1
P1
P1
P1
P1
P1
P2
P2
P2
P2
P2
OWNER’S
INFORMATION

15
Remote Control Operation
AUTOMATIC TURN DOWN
AUTOMATIC SHUT OFF
LOW BATTERY INDICATION
HANDSET / RECEIVER MATCH
Remote handset: The battery icon will show
when the battery needs to be replaced.
Replace with one 9 V alkaline battery.
Battery holder: Frequent ‘beeps’ for 3 seconds when
the valve motor turns indicate the batteries need to be
replaced. Replace with four 1.5 V alkaline batteries.
The remote control handset and receiver are program-
med to function together. In case of a replacement of
the handset or the receiver, you will need to reset the
receiver to allow them to function together. Contact your
dealer for details.
• No communication. If there is no communication
between the receiver and the handset for a period of
6 hours, the appliance goes into pilot mode.
• No change in fl ame height. If there is no change
in fl ame height for a period of 6 hours, the appliance
goes into pilot mode.
NOTE: In TEMP or TIMER modes, the fl ame height
will vary according to room temperature. The appli-
ance will continue to work normally. However, if the
room temperature remains the same for 6 hours, the
appliance will go into pilot mode.
• Low batteries in the battery holder. With low
batteries powering the receiver the system shuts off
completely.
NOTE: This does not apply when the power supply
is interrupted.
• No change in pilot. The appliance shuts off
completely when it is continually in pilot position—
without any change—for a period of 5 days.
Timer Programming Example (default temperatures shown)
6:00 a.m.—
P1
Start time
4:00 p.m.—
P2
Start time
6:00 a.m.—
P1
Start time
8:00 a.m.—
P1
End time
10:00 p.m.—
P2
End time
Set temp 74˚F Set temp 40˚FSet temp 74˚F
Set temp 40˚F
CAUTION
DO NOT USE a screwdriver or other metallic object
to remove the batteries from the battery holder or
the handset! This could cause a short circuit.
OWNER’S
INFORMATION

16
Wall Switch Operation
TO TURN APPLIANCE ON and OFF
TO ADJUST FLAME HEIGHT
• Press ON-OFF button once to light
pilot. Press again to shut of pilot.
• Press and hold large fl ame
button to gradually increase
fl ame height.
• Press and hold small fl ame
button to gradually decrease
fl ame height.
The Wall Switch can be used to
control your fi replace. You can
turn the pilot on or off and you can
increase or decrease the fl ame
height.
Note that the thermostat and
programming functions are not
available with the wall switch.
Options
Required Kits*
Fuel Beds (choose one)
1800DWK Driftwood Set Kit
1800DGM Decorative Glass Murano
Liners (choose one)
1815FBL Linear Fluted Black Liner Set
1825RGL** Linear Refl ective Glass Liner Set
(**Add 1725RGL-3 Glass Retainer Kit)
Trims (choose one) Barrier
Screen
1850LSB Linear 5-1/4” Surround - black 4005460
1875LFB Linear 1” Finishing Trim Black 4005413
Optional Accessories*
Conversion Kits
1800NGK Conversion to natural gas
1800PGK Conversion to propane gas
Other Accessories
GV60CKO Outdoor Fireplace Conversion Kit
1506DRK Additional rocks for Driftwood Kit
1595CFK Circulating Fan Kit
1270RBK Remote Blower Kit
LDK HeatShift Duct Kits (gravity fl ow)
Hearth
Gate
Hearth gates such as Cardinal’s
VersaGates are available at retail stores
carrying safety products for children.
*Information accurate at the time of printing and subject to change without notice.
OWNER’S
INFORMATION

17
Lighting Instructions
FOR YOUR SAFETY, READ BEFORE LIGHTING
WARNING: If you do not follow these instructions exactly, a fi re or explosion may result
causing property damage, personal injury or loss of life.
A. This appliance has a pilot which must be lighted by hand, remote control, or wall switch. Follow these instructions
exactly. To save gas, turn the pilot off when not using the appliance for a prolonged period of time.
B. BEFORE LIGHTING, smell all around the appliance area for gas. Be sure to smell next to the fl oor because
some gases are heavier than air and will settle on the fl oor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fi re department.
C. Use only your hand to push in or turn the control knobs. Never use tools. If the knobs will not push in or turn by
hand, don’t try to repair them; call a qualifi ed service technician. Force or attempted repair may result in a fi re or
explosion.
D. Do not use this appliance if any part has been under water. Immediately call a qualifi ed service technician to
inspect the appliance and to replace any part of the control system and any gas control, which has been under water.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above.
2. TO CLEAR ANY GAS, turn main valve off by pressing OFF (red dot) button on remote
handset (1).
• Wait fi ve (5) minutes to clear out any gas, then smell for gas, including near the fl oor. If you
smell gas, STOP! Follow “B” in the safety information above on this label. If you don’t smell
gas, go to the next step.
3. AUTOMATIC IGNITION: MAN-knob (2) in ON position. Ensure Flame Adjustment
knob (3) is set to lowest setting () (Fig. 1). Locate the pilot (Fig. 3.) inside of
fi rebox at left hand side.
• On the remote control handset, press the OFF button (red dot) and large fl ame
button () simultaneously; a short acoustic signal confi rms the start has begun.
• Further short acoustic signals indicate the ignition process is in progress.
• When the pilot is lit, the Flame Adjustment knob (3) will automatically rotate to
the highest setting.
• Press the small fl ame button () on the remote control handset to reduce the
fl ame height.
4. MANUAL IGNITION: MAN-knob (2) in MAN position (Fig. 2). With the window
off , locate the pilot (Fig. 3) inside of fi rebox at left hand side.
• Set Flame Adjustment knob (3) to the lowest setting ().
• Push down the metallic core (4) with a pen or similar instrument; this will establish
the pilot gas fl ow.
• Light gas at the pilot (5) with a match.
• Continue holding down metal core (4) for about 10 seconds; after release, pilot
should remain lit.
• If the pilot will not stay lit after several tries, turn the gas control knob (3) to OFF () and call your local
service technician or gas supplier.
• Reinstall the window and set the MAN-knob (2) to ON; turn Flame Adjustment knob (3) up () or down ()
manually or use the fl ame buttons ()() buttons on the remote control handset to adjust the fl ame height.
TO TURN OFF GAS TO APPLIANCE
AUTOMATIC SHUT-OFF (using the remote control handset):
• Press and hold the small fl ame button () on the remote control handset to shut-off the main burner gas fl ow.
• Press OFF button (red dot) on remote handset to shut-off the appliance, including pilot fl ame.
Spark
Pilot
Fig 3
5
Fig 1
Fig 2
1
OFF
OWNER’S
INFORMATION

18
State of Massachusetts Carbon Monoxide
Detector/Vent Terminal Signage
Requirements
For all side wall horizontally vented gas fueled
equipment installed in every dwelling, building or
structure used in whole or in part for residential
purposes, including those owned or operated by the
Commonwealth and where the side wall exhaust
vent termination is less than seven (7) feet above
fi nished grade in the area of the venting, including
but not limited to decks and porches, the following
requirements shall be satisfi ed:
1. INSTALLATION OF CARBON MONOXIDE
DETECTORS. At the time of installation of the side wall
horizontal vented gas fueled equipment, the installing
plumber or gas fi tter shall observe that a hard wired
carbon monoxide detector with an alarm and battery
back-up is installed on the fl oor level where the gas
equipment is to be installed. In addition, the installing
plumber or gas fi tter shall observe that a battery
operated or hard wired carbon monoxide detector
with an alarm is installed on each additional level of
the dwelling, building or structure served by the side
wall horizontal vented gas fueled equipment. It shall
be the responsibility of the property owner to secure
the services of qualifi ed licensed professionals for the
installation of hard wired carbon monoxide detectors.
a. In the event that the side wall horizontally vented
gas fueled equipment is installed in a crawl space or
an attic, the hard wired carbon monoxide detector with
alarm and battery back-up may be installed on the next
adjacent fl oor level.
b. In the event that the requirements of this subdivision
can not be met at the time of completion of installation,
the owner shall have a period of thirty (30) days
to comply with the above requirements; provided,
however, that during said thirty (30) day period, a
battery operated carbon monoxide detector with an
alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS.
Each carbon monoxide detector as required in
accordance with the above provisions shall comply
with NFPA 720 and be ANSI/UL 2034 listed and IAS
certifi ed.
3. SIGNAGE. A metal or plastic identifi cation plate
shall be permanently mounted to the exterior of the
building at a minimum height of eight (8) feet above
grade directly in line with the exhaust vent terminal for
the horizontally vented gas fueled heating appliance
or equipment. The sign shall read, in print size no less
than one-half (1/2) inch in size, “GAS VENT DIRECTLY
BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of
the side wall horizontally vented gas fueled equipment
shall not approve the installation unless, upon
inspection, the inspector observes carbon monoxide
detectors and signage installed in accordance with the
provisions of 248 CMR 5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt
from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled
“Equipment Not Required To Be Vented” in the most
current edition of NFPA 54 as adopted by the Board;
and
2. Product Approved side wall horizontally vented
gas fueled equipment installed in a room or structure
separate from the dwelling, building or structure used in
whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS
EQUIPMENT VENTING SYSTEM PROVIDED.
When the manufacturer of Product Approved side
wall horizontally vented gas equipment provides a
venting system design or venting system components
with the equipment, the instructions provided by the
manufacturer for installation of the equipment and the
venting system shall include:
1. Detailed instructions for the installation of the venting
system design or the venting system components; and
2. A complete parts list for the venting system design or
venting system.
Commonwealth of Massachusetts
QUALIFIED
INSTALLER

19
(d) MANUFACTURER REQUIREMENTS - GAS
EQUIPMENT VENTING SYSTEM NOT PROVIDED.
When the manufacturer of a Product Approved side
wall horizontally vented gas fueled equipment does
not provide the parts for venting the fl ue gases, but
identifi es “special venting systems”, the following
requirements shall be satisfi ed by the manufacturer:
1. The referenced “special venting system” instructions
shall be included with the appliance or equipment
installation instructions; and
2. The “special venting systems” shall be Product
Approved by the Board, and the instructions for that
system shall include a parts list and detailed installation
instructions.
(e) A copy of all installation instructions for all Product
Approved side wall horizontally vented gas fueled
equipment, all venting instructions, all parts lists
for venting instructions, and/or all venting design
instructions shall remain with the appliance or
equipment at the completion of the installation.
Commonwealth of Massachusetts
QUALIFIED
INSTALLER

20
X
Model JN JP
Gas Natural Propane
Altitude (Ft.)* 0-4,500 feet*
Input Maximum (Btu/h) 42,000 42,000
Input Minimum (Btu/h) 23,000 23,000
Manifold Pressure (in w.c.) 3.5” 10”
Minimum Supply Pressure (in
w.c.) 5” 11”
Maximum Supply Pressure (in
w.c.) 10” 14”
Main Burner Injector Marking 1400 DMS#47
Pilot Injector Marking 51 30
Min. Rate By-Pass Screw 260 160
Approval & Codes
This appliance is certifi ed to ANSI Z21.88-2014/CSA
2.33-2014 American National Standard / CSA Standard
for Vented Gas Fireplace Heaters for use in Canada
and USA, and to CGA 2.17-91 High Altitude Standard in
Canada. This appliance is for direct vent installations.
This appliance complies with CSA P4.1-09 Testing
method for measuring annual fireplace efficiencies.
The installation must conform to local codes or, in the
absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1 or the Natural Gas and Propane Installation
Code CAN/CGA-B149. Only qualifi ed licensed or trained
personnel should install this appliance.
This appliance must be electrically grounded in
accordance with local codes, or, in the absence of local
codes, with the National Electrical Code, ANSI/NFPA
70 or the Canadian Electrical Code, CSA C22.1.
Ratings
*High Altitude Installations
Input ratings are shown in BTU per hour and are
certifi ed without deration for elevations up to 4,500 feet
(1,370 m) above sea level.
For elevations above 4,500 feet (1,370 m) in USA,
installations must be in accordance with the current
ANSI Z223.1 and/or local codes having jurisdiction.
Heating value of gas in some areas is reduced to
compensate for elevation—consult your local gas
utility to confi rm.
For installations at elevations above 4,500 feet
(1,370 m) in Canada, please consult provincial and/or
local authorities having jurisdiction.
Supply Gas
Heater engine 1800JN is used with natural gas.
Heater engine 1800JP is used with propane gas.
Specifi cations
The supply pressure must be
between the limits shown in
the Ratings section above.
The supply connection is
3/8” NPT male and located
on the left hand side of the
fi rebox. A shut-off valve (not supplied) is required on
the supply line to isolate the unit during service. See
Supply Gas Installation section for details.
Conversion Kits
The 1800J L3 is supplied as natural gas or propane gas
and is fi eld convertible between fuels. See instructions
packaged with the conversion kit for further information.
Electrical
The 1800J is designed to run on battery power and
does not require an electrical power source to operate
as a heater. However, it requires electrical power
to operate optional 1595CFK Circulating Fan Kit or
1270RBK Remote Blower Kit.
LDK HeatShift Duct Kit
The 1800J is designed to allow the installation of the
optional LDK HeatShift Duct Kit, a convection system
that redistributes the warm air fl ow away from the
fi replace opening to a more desirable location using
natural convection, without use of a fan.
The warm air fl ow may be relocated to a position higher
up the wall, out the sidewalls, or even to another room.
The result is much cooler wall temperatures above the
fi replace opening for locating televisions, artwork, etc.
Please note that the framing and mantel clearances
are aff ected by the installation of the LDK. Refer to
the installation manual packed with the kit for more
information.
This appliance is designed and approved as a
supplemental heater and provides the potential
for most energy conservation when used while
attended. The use of an alternate primary heat
source is advisable.
Outdoor Conversion Kit
The 1800J models are supplied standard for indoor
applications and may be adapted for installation
in specifi c “outdoor” applications protected from
weather as defi ned in the GV60CKO outdoor
conversion kit manual.
WARNING
Optional electrical accessories
ARE NOT ALLOWED when adapting
appliance for outdoor use.
!
QUALIFIED
INSTALLER
