Milesight MS-C3262-FPNA User manual

Quick Start Guide
VV
Version 2.6

1
Table of Contents
1. Package Contents ......................................................................................................................2
2. Cautions.....................................................................................................................................3
3. System Requirements................................................................................................................3
4. Hardware Overview................................................................................................................... 4
4.1 Mini Dome Network Camera ...........................................................................................4
4.2 IR Mini Dome Network Camera .......................................................................................5
4.3 Vandal-proof Mini Dome Network Camera ..................................................................6
4.4 Wi-Fi Mini Cube Network Camera ...................................................................................7
4.5 Mini Bullet Network Camera............................................................................................ 9
4.6 Remote Focus&Zoom Mini Bullet Network Camera...................................................... 11
4.7 Pro Bullet Network Camera............................................................................................12
4.8 Pro Dome Network Camera ...........................................................................................13
5. Hardware Installation ..............................................................................................................16
5.1 Mini Dome Network Camera .........................................................................................16
5.2 IR Mini Dome Network Camera .....................................................................................19
5.3 Vandal-proof Mini Dome Network Camera ................................................................... 23
5.4 Wi-Fi Mini Cube Network Camera .................................................................................26
5.5 Mini Bullet Network Camera.......................................................................................... 28
5.6 Pro Bullet Network Camera............................................................................................ 31
5.7 Pro Dome Network Camera ...........................................................................................34
6. How to Connect to Alarm Interface ........................................................................................38
7. Accessing the Milesight Network Camera...............................................................................39
7.1 Assigning An IP Address .................................................................................................39
7.1.1 Assigning An IP Address by Using Smart Tools........................................................................ 40

Quick Start Guide
2
7.1.2 Assign An IP Address via Browser ........................................................................................... 46
7.2 Accessing from the Web Browser ..................................................................................49
7.2.1 Access over IE Browser ........................................................................................................... 49
Thank you for purchasing Milesight Network Camera. This Guide provides basic instructions on
installing and accessing Milesight Network Camera. For more details, please refer to the User
Manual.
1. Package Contents
Before installation, please verify that all the necessary items are supplied in the gift box as the

Quick Start Guide
3
package contents listed below. If any item is missing or damaged, please contact the shipper and
your Milesight sales representative.
Sheet 1-1
Items
Quantity
Description
Default
Milesight Network
Camera
1 PC
The purchased model
Power Adapter
1 PC
DC12V, 1.5A MAX (optional for part of devices)
Quick Start Guide
1 PC
Printed material
Warranty Card
1 PC
Printed material
Optional
Lens
If purchased
Bracket& Screw
Pack
If purchased
2. Cautions
Do not expose the product to rain or moisture.
Make sure the device is firmly fixed when mounting them on the wall or ceiling.
Make sure that the power supply voltage is correct before using the camera.
Do not use a third party power adapter.
Never attempt to disassemble or modify the camera.
3. System Requirements
Operating System: Windows XP/Vista/7/8/10/Server 2000/Server 2008
CPU: 1.66GHz or higher
RAM: 1G or higher
Graphic memory: 128MB or more
Internet protocol: TCP/IP (IPv4/IPv6)

Quick Start Guide
4
Web Browsers: Internet Explorer 8.0 and above version, Mozilla Firefox, Google Chrome and Safari.
4. Hardware Overview
4.1 Mini Dome Network Camera
Figure 4-1 Mini Dome Network Camera
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runs error.
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.
3) Only PoE is available for power supply.
Press Button
Ethernet Port (PoE)
Lens
Error LED Indicator
Power LED Indicator
Micro SD/SDHC/SDXC Card Slot
Reset

Quick Start Guide
5
4.2 IR Mini Dome Network Camera
Figure 4-2 IR Mini Dome Network Camera
Ethernet Port (PoE)
Lens
Press Button
Error LED Indicator
Power LED Indicator
Micro SD/SDHC/SDXC Card
Reset
IR LEDs
Light Sensor

Quick Start Guide
6
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runs error.
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.
3) Only PoE is available for power supply.
4.3 Vandal-proof Mini Dome Network Camera

Quick Start Guide
7
Figure 4-3 Vandal-proof Mini Dome Network Camera
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runs error.
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.
3) Only PoE is available for power supply.
4.4 Wi-Fi Mini Cube Network Camera
IR LEDs
Microphone
Micro SD/SDHC/SDXC
Card Slot
Power and System LED Indicator
Reset
Ethernet Port
(PoE)
Lens
Screw
Light Sensor

Quick Start Guide
8
Figure 4-4 Wi-Fi Mini Cube Network Camera
Note:
1) SIP Button: Trigger alarm via SIP calling. After this button is pressed, the camera will call the SIP
Phone.
2) WPS Button: Press this button, and then press the WPS button on your router to set up
wireless connection automatically.
Microphone
Lens
Light Sensor
IR LEDs
LED Indicators
Speaker
PIR Sensor or SIP Button
Micro SD/SDHC/SDXC
Card Slot
SIP Button
Ethernet Port(PoE)
WPS/Reset Button
Power Connector
Alarm Input/Output

Quick Start Guide
9
3) DC 12V and PoE are available for power supply;
4.5 Mini Bullet Network Camera
Figure 4-5 Mini Bullet Network Camera
IR LEDs
Light Sensor
Lens
Ethernet Port(PoE)
Micro SD/SDHC/SDXC Card Slot
Reset Button

Quick Start Guide
10
Note:
1) Only PoE is available for power supply.

Quick Start Guide
11
4.6 Remote Focus&Zoom Mini Bullet Network Camera
Figure 4-6 Remote Focus&Zoom Mini Bullet Network Camera
Note:
IR LEDs
Light Sensor
Lens
DC 12V
Ethernet Port(PoE)
Micro SD/SDHC/SDXC Card Slot
Reset Button

Quick Start Guide
12
1) DC 12V and PoE are available for power supply.
4.7 Pro Bullet Network Camera
Figure 4-7 Pro Bullet Network Camera
Note:
Ethernet Port (PoE)
Alarm/Audio
Power Connector
Lens
Light Sensor
IR LEDs
Micro SD/SDHC/SDXC Card Slot
Reset
Breathe
Light Sensor
Ethernet Port (POE)

Quick Start Guide
13
1) DC 12V and PoE are available for power supply.
4.8 Pro Dome Network Camera
Figure 4-8 Pro Dome Network Camera
IR LEDs
Micro SD/SDHC/SDXC Card Slot
Lens
Light Sensor
Reset

Quick Start Guide
14
Note:
1) There are two versions for Pro Dome: Standard and Multiple Interface, the interface’s pictures
are as following;
2) Multiple Interface adopts the external interface “Audio In” instead of the Microphone built-in;
Figure 4-9 Pro Dome Network Camera(Standard Interface)
DC 12V
Ethernet Port(PoE)
WAFER Contact

Quick Start Guide
15
Figure 4-10 Pro Dome Network Camera(Multiple Interface)
Audio In
Audio Out
Ethernet Port
(PoE)
DC 12V
External Interface

Quick Start Guide
16
5. Hardware Installation
5.1 Mini Dome Network Camera
Step1: Remove the dome cover;
Step2: Secure the screws;
Press Button

Quick Start Guide
17
Step3: Connect and route an Ethernet cable through the ceiling or wall;
Step4: Adjust the lens angle and focus;

Quick Start Guide
18
Step5: Attach the dome cover;
Pan Range:+15°
Tilt Range:0-90°
20°
