Milesight Network camera Operator's manual

Table of Content
1. Package Contents.......................................................................................................................1
2. Cautions..................................................................................................................................... 1
3. System Requirements................................................................................................................ 1
4. Hardware Overview................................................................................................................... 2
4.1 Mini Dome Network Camera............................................................................................2
4.2 IR Mini Dome Network Camera........................................................................................3
4.3 Vandal-proof Mini Dome Network Camera......................................................................4
4.4 Wi-Fi Mini Cube Network Camera....................................................................................5
4.5 Mini Bullet Network Camera............................................................................................ 6
4.6 Remote Focus&Zoom Mini Bullet Network Camera........................................................ 7
4.7 Pro Bullet Network Camera.............................................................................................. 8
4.8 Pro Dome Network Camera............................................................................................10
4.9 Mini PTZ Bullet Network Camera................................................................................... 12
4.10 Speed Dome Network Camera..................................................................................... 13
5. Hardware Installation.............................................................................................................. 14
5.1 Mini Dome Network Camera..........................................................................................14
5.2 IR Mini Dome Network Camera......................................................................................15
5.3 Vandal-proof Mini Dome Network Camera....................................................................18
5.4 Wi-Fi Mini Cube Network Camera..................................................................................20
5.5 Mini Bullet Network Camera.......................................................................................... 22
5.6 Pro Bullet Network Camera............................................................................................ 24
5.7 Pro Dome Network Camera............................................................................................26
5.8 Mini PTZ Bullet Network Camera................................................................................... 30
5.9 Speed Dome Network Camera....................................................................................... 32
6. How to Connect to Alarm Interface.........................................................................................33
7. How to Connect the Water-proof Connector..........................................................................33
8. Accessing the Milesight Network Camera...............................................................................34
8.1 Assigning an IP Address.................................................................................................. 34
8.2 Accessing from the Web Browser...................................................................................40
Thank you for choosing Milesight product..................................................................................43

Quick Start Guide
www.milesight.com
1
Thank you for purchasing Milesight Network Camera. This Guide provides basic instructions on
installing and accessing Milesight Network Camera. For more details, please refer to the User
Manual.
1. Package Contents
Before installation, please verify that all the necessary items are supplied in the gift box as the
package contents listed below. If any item is missing or damaged, please contact the shipper and
your Milesight sales representative.
Sheet 1-1
Items
Quantity
Description
Default
Milesight Network
Camera
1 PC
The purchased model
Power Adapter
1 PC
DC 12V (optional for part of devices)
Quick Start Guide
1 PC
Printed material
Warranty Card
1 PC
Printed material
Optional
Lens
If purchased
Bracket& Screw
Pack
If purchased
2. Cautions
Do not expose the product to rain or moisture.
Make sure the device is firmly fixed when mounting them on the wall or ceiling.
Make sure that the power supply voltage is correct before using the camera.
Do not use a third party power adapter.
Never attempt to disassemble or modify the camera.
3. System Requirements
Operating System: Windows XP/Vista/7/8/10/Server 2000/Server 2008
CPU: 1.66GHz or higher
RAM: 1G or higher
Graphic memory: 128MB or more
Internet protocol: TCP/IP (IPv4/IPv6)
Web Browsers: Internet Explorer 8.0 and above version, Mozilla Firefox, Google Chrome and Safari.

Quick Start Guide
www.milesight.com
2
4. Hardware Overview
4.1 Mini Dome Network Camera
Figure 4-1 Mini Dome Network Camera
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runs error;
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default;
3) Only PoE is available for power supply.

Quick Start Guide
www.milesight.com
3
4.2 IR Mini Dome Network Camera
Figure 4-2 IR Mini Dome Network Camera
Note:
1) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default;
2) Only PoE is available for power supply.

Quick Start Guide
www.milesight.com
4
4.3 Vandal-proof Mini Dome Network Camera
Figure 4-3 Vandal-proof Mini Dome Network Camera
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runs error;
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default;
3) Only PoE is available for power supply.

Quick Start Guide
www.milesight.com
5
4.4 Wi-Fi Mini Cube Network Camera
Figure 4-4 Wi-Fi Mini Cube Network Camera
Note:
1) SIP Button: Trigger alarm via SIP calling. After this button is pressed, the camera will call the SIP
Phone;
2) WPS Button: Press this button, and then press the WPS button on your router to set up
wireless connection automatically;
3) DC 12V and PoE are available for power supply;
4) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory default.
Microphone
Lens
Light Sensor
IR LEDs
LED Indicators
Speaker
PIR Sensor or SIP Button
Micro SD/SDHC/SDXC
Card Slot
SIP Button
Ethernet Port(PoE)
WPS/Reset Button
DC 12V
Alarm Input/Output

Quick Start Guide
www.milesight.com
6
4.5 Mini Bullet Network Camera
Figure 4-5 Mini Bullet Network Camera
Note:
1) Only PoE is available for power supply;
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.

Quick Start Guide
www.milesight.com
7
4.6 Remote Focus&Zoom Mini Bullet Network Camera
Figure 4-6 Remote Focus&Zoom Mini Bullet Network Camera
Note:
1) DC 12V and PoE are available for power supply;
2) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.

Quick Start Guide
www.milesight.com
8
4.7 Pro Bullet Network Camera
Figure 4-7 Pro Bullet Network Camera
Note:
1) There are two versions for Pro Bullet: the interface’s pictures are as following;
2) DC 12V and PoE are available for power supply;
3) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.

Quick Start Guide
www.milesight.com
9
Figure 4-8 Pro Bullet Network Camera(Version A)
Figure 4-8 Pro Bullet Network Camera(Version B)

Quick Start Guide
www.milesight.com
10
4.8 Pro Dome Network Camera
Note:
1) Reset Button: Press “Reset” button for 5 seconds, the device will be restored to factory
default.

Quick Start Guide
www.milesight.com
11
Figure 4-9 Pro Dome Network Camera multiple interface
Here is one equipped cable for multiple interface usage:
Figure 4-10 Pro Dome Network Camera multiple interface cable

Quick Start Guide
www.milesight.com
12
4.9 Mini PTZ Bullet Network Camera
Figure 4-11 Mini PTZ Bullet Network Camera
Note:
1) Only DC 12V is available for power supply.

Quick Start Guide
www.milesight.com
13
4.10 Speed Dome Network Camera
Figure 4-12 Speed Dome Network Camera
Note:
1) DC 12V and AC 24V are available for power supply;
2) Built-in SD card slot can be seen after removing the 4 screws and open the front panel.

Quick Start Guide
www.milesight.com
14
5. Hardware Installation
5.1 Mini Dome Network Camera
Step1: Remove the dome cover;
Step2: Secure the screws;
Step3: Connect and route an Ethernet cable through the ceiling or wall;

Quick Start Guide
www.milesight.com
15
Step4: Adjust the lens angle and focus;
Step5: Attach the dome cover;
5.2 IR Mini Dome Network Camera
Step1: Remove the dome cover;

Quick Start Guide
www.milesight.com
16
Step2: Secure the screws to wall or bracket, please notice to get the cable through the bracket
firstly;
Step3: Connect and route an Ethernet cable;
