Milwaukee 0511-21 User manual

TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND OPERATOR'S MANUAL.
AFIN DE RÉDUIRE LE RISQUE DE BLESSURES, L'UTILISATEUR DOIT LIRE ET BIEN COMPRENDRE LE
MANUEL DE L'UTILISATEUR.
PARA REDUCIR EL RIESGO DE LESIONES, EL USUARIO DEBE LEER Y ENTENDER EL MANUAL DEL
OPERADOR.
SPECIAL NOTE: New battery packs are not fully charged. Charge
your battery pack before using it for the first time and follow the
charging instructions in your charger manual.
NOTE SPÉCIALE : Les batteries neuves ne sont pas entièrement
chargées. Chargez la batterie avant de vous en servir la première fois
en suivant les instructions de recharge dans le manuel qui
accompagne cet outil.
NOTA ESPECIAL: Las bater as, cuando son nuevas, no están
totalmente cargadas. Cargue su bater a antes de usarla por
primera vez y siga las instrucciones de carga que vienen en el
manual de la herramienta.
Catalog No.
No de Cat.
Catálogo No.
0511-21
0512-21
14.4V 1/2" HI-TORQUE DRIVER/DRILLS
PERCEUSES-TOURNEVIS 14,4V 13 mm (1/2") SANS CORDON À COUPLE ÉLEVÉ
TALADROS/ATORNILLADORES DE 14,4V 13 mm (1/2"), A ATERIAS, DE ALTO
TORQUE
OPERATOR'S MANUAL
MANUEL de L'UTILISATEUR
MANUAL del OPERADOR

page 2
GENERAL SAFETY RULES  FOR ALL BATTERY OPERATED TOOLS
READ AND UNDERSTAND ALL INSTRUCTIONS.
1. Keep your work area clean and well lit. Cluttered benches and
dark areas invite accidents.
2. Do not operate power tool in explo ive atmo phere , uch a
in the pre ence of flammable liquid , ga e , or du t. Power tools
create sparks which may ignite the dust or fumes.
3. Keep by tander , children, and vi itor away while operating a
power tool. Distractions can cause you to lose control. Protect oth-
ers in the work area from debris such as chips and sparks. Provide
barriers or shields as needed.
WORK AREA
ELECTRICAL SAFETY
Failure to follow all in truction li ted below, may re ult in electric hock,
fire and/or eriou per onal injury.
WARNING!
SAVE THESE INSTRUCTIONS
PERSONAL SAFETY
TOOL USE AND CARE
SERVICE
4. Do not abu e the cord. Never u e the cord to carry the tool. Keep
cord away from heat, oil, harp edge , or moving part . Replace
damaged cord immediately. Damaged cords may create a fire.
5. A battery operated tool with integral batterie or a eparate bat-
tery pack mu t be recharged only with the pecified charger for
the battery. A charger that may be suitable for one type of battery
may create a risk of fire when used with another battery.
6. U e battery operated tool only with pecifically de ignated bat-
tery pack. Use of any other batteries may create a risk of fire.
13. U e clamp or other practical way to ecure and upport the
workpiece to a table platform. Holding the work by hand or against
your body is unstable and may lead to loss of control.
14. Do not force tool. U e the correct tool for your application. The
correct tool will do the job better and safer at the rate for which it is
designed.
15. Do not u e tool if witch doe not turn it on or off. A tool that
cannot be controlled with the switch is dangerous and must be re-
paired.
16. Di connect battery pack from tool or place the witch in the
locked or off po ition before making any adju tment , changing
acce orie , or toring the tool. Such preventive safety measures
reduce the risk of starting the tool accidentally.
17. Store idle tool out of reach of children and other untrained per-
on . Tools are dangerous in the hands of untrained users.
18. When battery pack i not in u e, keep it away from other metal
object like: paper clip , coin , key , nail , crew , or other mall
metal object that can make a connection from one terminal to
another. Shorting the battery terminals together may cause sparks,
burns, or a fire.
19. Maintain tool with care. Keep cutting tool harp and clean.
Properly maintained tools with sharp cutting edge are less likely to
bind and are easier to control.
20. Check for mi alignment or binding of moving part , breakage of
part , and any other condition that may affect the tool opera-
tion. If damaged, have the tool erviced before u ing. Many acci-
dents are caused by poorly maintained tools. Do not use a damaged
tool. Tag damaged tools Do not use until repaired.
21. U e only acce orie that are recommended by the manufac-
turer for your model. Accessories that may be suitable for one tool
may create a risk of injury when used on another tool.
7. Stay alert, watch what you are doing, and u e common en e
when operating a power tool. Do not u e tool while tired or un-
der the influence of drug , alcohol, or medication. A moment of
inattention while operating power tools may result in serious per-
sonal injury.
8. Dre properly. Do not wear loo e clothing or jewelry. Contain
long hair. Keep your hair, clothing, and glove away from mov-
ing part . Loose clothes, jewelry, or long hair can be caught in mov-
ing parts.
9. Avoid accidental tarting. Be ure witch i in the locked or off
po ition before in erting battery pack. Carrying tools with your
finger on the switch or inserting the battery pack into a tool with the
switch on invites accidents.
10. Remove adju ting key or wrenche before turning the tool on.
A wrench or a key that is left attached to a rotating part of the tool
may result in personal injury.
11. Do not overreach. Keep proper footing and balance at all time .
Proper footing and balance enable better control of the tool in unex-
pected situations.
12. U e afety equipment. Alway wear eye protection. Dust mask,
non-skid safety shoes, hard hat, or hearing protection must be used for
appropriate conditions.
22. Tool ervice mu t be performed only by qualified repair per on-
nel. Service or maintenance performed by unqualified personnel may
result in a risk of injury.
23. When ervicing a tool, u e only identical replacement part . Fol-
low in truction in the Maintenance ection of thi manual. Use
of unauthorized parts or failure to follow Maintenance Instructions may
create a risk of shock or injury.

page 3
SPECIFIC SAFETY RULES
1. Maintain label and nameplate . These carry important information. If unreadable or missing, contact a MILWAUKEE service facility for a free
replacement.
2. WARNING! Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause
cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
 lead from lead-based paint
 crystalline silica from bricks and cement and other masonry products, and
 arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.
FUNCTIONAL DESCRIPTION
S ecifications
Bit Shank
Size
1/2"
1/2"
Catalog
No.
0511-21
0512-21
Volt
14.4
14.4
No Load
RPM
Low 0-450
High 0-1250
Low 0-450
High 0-1250
1. Clutch adjusting ring
2. Speed selector
3. Release buttons
4. Battery pack
5. Trigger
6. Control switch
7. Keyless chuck
12
43
5
7
6
Cat. No. 0511-21
12
43
5
7
6
Cat. No. 0512-21
Symbology
Volts Direct Current
No Load Revolutions per
Minute (RPM)
Properly Recycle Nickel
Cadmium Batteries
Underwriters Laboratories, Inc.
Canadian Standards Association

page 4
CHARGING AND USING BATTERY PACK
Charge your battery pack before using your tool for the first time and
when your tool no longer performs with the power and torque needed for
the job. Full loading capacity of battery pack is only reached after
4 - 5 chargings. Never completely discharge the battery pack. Standard
charging time will vary according to the type of charger you use. The
charging time will also vary depending on the supply voltage and charge
needed. For example, if your battery pack does not require a full charge,
charging time will be less.
FOR SPECIFIC CHARGING INSTRUCTIONS, PLEASE READ THE
CHARGER INSTRUCTION SHEET SUPPLIED WITH YOUR CHARGER.
Battery packs are affected by temperature. Your battery pack will
perform best and have longest life if it is charged when the temperature
is between 60°-80°F (15°-27°C). Do not charge in temperatures below
40°F (5°C) or above 105°F (40°C). Under these conditions, capacity will
be reduced. See Maintenance.
Removing Battery Pack from Tool
Push in the release buttons and remove the battery pack.
In erting Battery Pack into Tool (Fig. 1 & 2)
Battery pack can be inserted into the tool in two ways.
1. For working in restricted spaces.
Insert the battery pack from the front by pressing in the release but-
tons and sliding battery pack into the body of the tool (Fig. 1). Insert
the battery pack until clamp engages.
Charge only MILWAUKEE 12 and 14.4 Volt
Power Plu battery pack in Power Plu
charger . Other type of batterie may ex-
plode cau ing per onal injury and damage.
WARNING!
2. For optimum weight distribution and balance.
Insert the battery pack from the back by pressing in the release but-
tons and sliding the battery pack into the body of the tool (Fig. 2).
Insert the battery pack until clamp engages.
Fig. 1
Cat. No. 0511-21
Fig. 2
Cat. No. 0511-21

page 5
To reduce the ri k of injury, wear afety goggle
or gla e with ide hield .
WARNING!
OPERATION
For driving small screws.
For driving screws into soft materials
such as wood veneers, etc.
For terminal screws on electrical
equipment, etc.
For driving screws into hardwood.
For drilling and powerful screwdriving.
The torque specifications shown here are approxi ate values obtained
with a fully charged battery pack.
U ing Clutch (Fig. 3)
This tool has an adjustable clutch for driving different types of screws into
different materials. When properly adjusted, the clutch will slip at a preset
torque to prevent driving the screw too deep and to prevent damage to
the screw or tool. Refer to the table below to select the correct position
for the type of material and screw size you are using.
To adjust the clutch, turn the clutch adjusting ring to one of the nineteen
positions shown on the adjusting ring.
NOTE: Because the above settings are only a guide, use a piece of scrap
material to test the different clutch positions before driving screws into
the workpiece.
Fig. 3
Clutch
Adjusting Ring Position
Numbers
1. For Low speed (up to 450 RPM), push the speed selector forward
(position 1).
2. For High speed (up to 1,250 RPM), push the speed selector back
(position 2).
Starting, Stopping & Controlling Speed
1. To tart the tool, pull the trigger.
2. To top the tool, release the trigger and an electric brake stops the
tool instantly.
All models feature variable speed control. To vary the speed, simply in-
crease or decrease pressure on the trigger. The further the trigger is pulled,
the greater the speed.
U ing Control Switch (Fig. 5)
The control switch may be set to three positions: forward, reverse and
lock. Due to a lockout mechanism, the control switch can only be ad-
justed when the ON/OFF switch is not depressed. Always allow the motor
to come to a complete stop before using the control switch.
Forward (clockwise) rotation,
For Catalog Number 0511-21  push the control switch to the left
position.
For Catalog Number 0512-21  push the control switch towards
the symbol on the body of tool.
Check the direction of rotation before u e.
Rever e (counter clockwise) rotation,
For Catalog Number 0511-21  push the control switch to the right
position.
For Catalog Number 0512-21  push the control switch towards
the symbol on the body of tool.
Check direction of rotation before u e.
Locking the trigger,
For Catalog Number 0511-21 & 0512-21  push the control switch
to center position. The trigger will not work while the control switch is in
the center locked position. Always lock the trigger or remove the bat-
tery pack before performing maintenance, changing accessories, stor-
ing the tool and any time the tool is not in use.
Selecting Speed (Fig. 4)
The speed selector is on top of the motor housing. Allow the tool to come
to a complete stop before changing speeds. See Applications for rec-
ommended speeds under various conditions.
Fig. 4 Low High
Po ition 1- 5
10 - 20 in. lb .
Po ition 6 - 10
21 - 40 in. lb .
Po ition 11 - 15
41 - 60 in. lb .
Po ition 16 - 19
61 - 75 in. lb .
Drill
Low 350 in. lb .
High 105 in. lb .
0511-21
0512-21
Low 280 in. lb .
High 105 in. lb .
Control Switch
Cat. No. 0511-21
Cat. No. 0512-21
Fig. 5

page 6
Drilling
Set the clutch adjusting ring to the drill position. Place the bit on the work
surface and apply firm pressure before starting. Too much pressure will
slow the bit and reduce drilling efficiency. Too little pressure will cause
the bit to slide over the work area and dull the point of the bit.
If the tool begins to stall, reduce pressure slightly to allow the bit to regain
speed. If the bit binds, reverse the motor to free the bit from the workpiece.
Drilling in Wood, Compo ition Material and Pla tic
When drilling in wood, composition materials and plastic, start the drill
slowly, gradually increasing speed as you drill. When drilling into wood,
use wood augers or twist drill bits. Always use sharp bits. When using
twist drill bits, pull the bit out of the hole frequently to clear chips from the
bit flutes. To reduce the chance of splintering, back work with a piece of
scrap wood. Select low speeds for plastics with a low melting point.
U ing Keyle Chuck (Fig. 6)
Always remove the battery pack or lock the trigger before inserting or
removing bits.
1. To open the chuck jaws, hold the collar while turning the sleeve in the
counterclockwise direction.
When using drill bits, allow the bit to strike the bottom of the chuck.
Center the bit in the chuck jaws and lift it about 1/16" off of the bot-
tom.
When using screwdriver bits, insert the bit far enough for the chuck
jaws to grip the hex of the bit.
Fig. 6
Sleeve
Collar
APPLICATIONS
Drilling in Metal
When drilling in metal, use high speed steel twist drills or hole saws. Use
a center punch to start the hole. Lubricate drill bits with cutting oil when
drilling in iron or steel. Use a coolant when drilling in nonferrous metals
such as copper, brass or aluminum. Back the material to prevent binding
and distortion on breakthrough.
Driving Screw and Nut Running
Drill a pilot hole when driving screws into thick or hard materials. Set the
clutch adjusting ring to the proper position and set the speed to low. Use
the proper style and size screwdriver bit for the type of screw you are
using.
With the screwdriver bit in the screw, place the tip of the screw on the
workpiece and apply firm pressure before pulling the trigger. Screws can
be removed by reversing the motor.
Overloading
Continuous overloading may cause permanent damage to tool or battery
pack.
2. To close the chuck jaws, hold the collar while turning the sleeve in
the clockwise direction. Tighten securely.
3. To remove the bit, hold the collar while turning the sleeve in the coun-
terclockwise direction.
To reduce the ri k of electric hock, check
work area for hidden pipe and wire before
drilling or driving crew .
WARNING!

page 7
Maintaining Tool
Keep your tool, battery pack and charger in good repair by adopting a
regular maintenance program. After six months to one year, depending
on use, return the tool, battery pack and charger to a MILWAUKEE ser-
vice facility for:
 Lubrication
 Brush inspection and replacement
 Mechanical inspection and cleaning (gears, spindles,
bearings, housing, etc.)
 Electrical inspection (battery pack, charger, motor)
 Testing to assure proper mechanical and electrical operation
If the tool does not start or operate at full power with a fully charged
battery pack, clean the contacts on the battery pack. If the tool still does
not work properly, return the tool, charger and battery pack to a
MILWAUKEE service facility for repairs.
Maintaining Battery Pack
MILWAUKEE battery packs will operate for many years and/or hundreds
of cycles when they are maintained and used according to these instruc-
tions.
A battery pack that is stored for six months without being used will dis-
charge itself. Batteries discharge at a rate of about 1% per day. Charge
the battery every six months even if it is unused to maximize battery life.
Do not tape the trigger in the ON position and leave the tool unattended
as this may discharge the battery to a point where it will no longer be able
to recharge. Use a MILWAUKEE battery pack only until it no longer per-
forms with the power and torque needed for your application.
Store your battery pack in a cool, dry place. Do not store it where the
temperature may exceed 120°F (50°C) such as in a vehicle or metal build-
ing during the summer. High temperatures will overheat the battery pack,
reducing battery life. If it is stored for several months, the battery pack
will gradually lose its charge. One to three cycles of charging and dis-
charging through normal use will restore the capacity of the battery pack.
During the life of the battery pack, the operating time between charges
becomes shorter. If the operating time becomes extremely short after a
proper charge, the usable life of the battery pack has been reached and
it should be replaced.
Cleaning
Clean dust and debris from charger and tool vents. Keep tool handles
clean, dry and free of oil or grease. Use only mild soap and a damp cloth
to clean the tool, battery pack and charger since certain cleaning agents
and solvents are harmful to plastics and other insulated parts. Some of
these include gasoline, turpentine, lacquer thinner, paint thinner, chlori-
nated cleaning solvents, ammonia and household detergents containing
ammonia. Never use flammable or combustible solvents around tools.
MAINTENANCE
Di po ing of Nickel-Cadmium Battery Pack
Nickel-Cadmium battery packs are recyclable. Under various state and
local laws, it may be illegal to dispose of this battery into the municipal
waste stream. Dispose of your battery pack according to federal, state
and local regulations.
Di po ing of Nickel-Metal Hydride Battery Pack
Nickel-Metal Hydride battery packs are recyclable. To recycle, return the
battery pack to the nearest MILWAUKEE Branch Office/Service Center.
Always dispose of your battery pack according to federal, state and local
regulations.
Repair
For repairs, return the tool, battery pack and charger to the nearest ser-
vice center listed on the back cover of this operator's manual.
Battery Pack Warranty
Battery packs for cordless tools are warranted for one year from the date
of purchase.
WARRANTY
To reduce the ri k of per onal injury and
damage, never immer e your tool, battery
pack or charger in liquid or allow a liquid to
flow in ide them.
WARNING!
To reduce the ri k of per onal injury,
alway unplug the charger and remove the
battery pack from the charger or tool
before performing any maintenance. Never
di a emble the tool, battery pack or
charger. Contact a MILWAUKEE ervice
facility for ALL repair .
WARNING!
To reduce the ri k of explo ion, never burn
a battery pack even if it i damaged, dead or
completely di charged.
WARNING!
Every MILWAUKEE product is warranted to be free from defects in mate-
rial and workmanship. MILWAUKEE will repair or replace any product which
examination proves to be defective in material or workmanship.
Limitation : This warranty does not cover: 1) repairs made or attempted
by other than MILWAUKEE or MILWAUKEE Authorized Service Station
personnel; 2) normal wear and tear; 3) abuse; 4) misuse; 5) improper
maintenance; 6) continued use after partial failure; 7) tools that have been
modified; or product used with an improper accessory.
Battery Packs are warranted for one (1) year from the date of purchase.
Should a problem develop, return the complete product to any
MILWAUKEE Factory Service Center or MILWAUKEE Authorized Ser-
vice Station, freight prepaid and insured. If inspection shows the problem
is caused by a defect in material or workmanship, all repairs or a replace-
ment will be made at no charge and the product will be returned, transpor-
tation prepaid. No other warranty, written or verbal, is authorized.
THE REPAIR AND REPLACEMENT REMEDIES DESCRIBED HEREIN
ARE EXCLUSIVE. IN NO EVENT SHALL MILWAUKEE BE LIABLE FOR
ANY INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES, IN-
CLUDING LOSS OF PROFITS.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED WHETHER FOR MERCHANTABILITY OR FITNESS FOR
PARTICULAR USE OR PURPOSE.
This warranty gives you specific legal rights. You may also have other
rights that vary from state to state. In those states that o not allow the
exclusion of implie warranties or limitations of inci ental or conse-
quential amages, the above limitations or exclusions may not apply
to you.

page 8
ACCESSORIES
For a complete listing of accessories refer to your MILWAUKEE Electric Tool catalog. To obtain a catalog, contact your local distributor or a service
center listed on the back cover of this operators manual.
Alway remove battery pack before changing or
removing acce orie . Only u e acce orie
pecifically recommended for thi tool. Other
may be hazardou .
WARNING!
14.4 V Power Plu Battery Pack
Cat. No. 48-11-1000
Fits MILWAUKEE Charger Cat. No. 48-59-0231, 48-59-0241, 48-59-0245.
Power Plu Charger 120 V
Cat. No. 48-59-0231
For charging Power Plus Battery Pack Cat. No. 48-11-1000.
Pla tic Carrying Ca e
Cat. No. 48-55-3015
Driver/Drill Acce ory Kit
Cat. No. 48-30-0101
Includes 1/4" socket driver, 6F-7R slotted bit, #1 and #2 Phillips bits, 1/4"
and 3/16" twist bits, and two 1/8" twist bits.
1/2" Keyle Chuck (For Cat. No. 0511-21)
Cat. No. 48-66-0365
Rugged nylon housing with rust resistant nickel plated jaws and body.
For cordless drills with 1/2" - 20 thread.
1/2" Keyle Chuck (For Cat. No. 0512-21)
Cat. No. 48-66-0420
Rugged nylon housing with rust resistant nickel plated jaws and body.
For cordless drills with 1/2" - 24 thread.
Jobber Length Twi t Drill Set
13 Piece Set
Cat. No. 48-89-0030
Sizes 1/16" to 1/4" by 64ths.
15 Piece Set
Cat. No. 48-89-0020
Sizes 1/16" to 1/2" by 32nds.
21 Piece Set
Cat. No. 48-89-0015
Sizes 1/16" to 3/8" by 64ths.
29 Piece Set
Cat. No. 48-89-0010
Sizes 1/16" to 1/2" by 64ths.
Cat. No. 48-30-0101
Cat. No. 48-89-0020
Cat. No. 48-11-1000
Cat. No. 48-59-0231

page 9
RÈGLES DE SÉCURITÉ GÉNÉRALES POUR TOUS LES OUTILS À BATTERIE
4. Ne maltraitez pa le cordon. Ne tran portez pa l'outil par on
cordon. N'expo ez pa le cordon à la chaleur, à de huile , à
de arête vive ou à de pièce en mouvement. Remplacez
immédiatement un cordon endommagé. Un cordon endommagé
peut constituer un risque d'incendie.
5. Un outil à bloc-batterie amovible ou à batterie intégrée ne doit
être rechargé qu'avec le chargeur prévu pour la batterie. Un
chargeur qui convient à tel type de batterie peut présenter un risque
d'incendie avec tel autre type de batterie.
6. N'utili ez un outil qu'avec un bloc-batterie conçu pécifiquement
pour lui. L'emploi d'un autre bloc-batterie peut créer un risque
d'incendie.
AIRE DE TRAVAIL
RÉPARATION
SÉCURITÉ ÉLECTRIQUE
SÉCURITÉ DES PERSONNES
UTILISATION ET ENTRETIEN DES OUTILS
1. Veillez à ce que l'aire de travail oit propre et bien éclairée. Le
désordre et le manque de lumière favorisent les accidents.
2. N'utili ez pa d'outil électrique dan une atmo phère explo-
ive, par exemple en pré ence de liquide , de gaz ou de
pou ière inflammable . Les outils électriques créent des
étincelles qui pourraient enflammer les poussières ou les vapeurs.
3. Tenez à di tance le curieux, le enfant et le vi iteur pendant
que vou travaillez avec un outil électrique. Ils pourraient vous
distraire et vous faire faire une fausse manoeuvre. Installez des
barrières ou des écrans protecteurs si nécessaires.
7. Re tez alerte, concentrez-vou ur votre travail et faite preuve
de jugement. N'utili ez pa un outil électrique i vou ête fatigué
ou ou l'influence de drogue , d'alcool ou de médicament . Un
instant d'inattention suffit pour entraîner des blessures graves.
8. Habillez-vou convenablement. Ne portez ni vêtement flottant
ni bijoux. Confinez le cheveux long . N'approchez jamai le
cheveux, le vêtement ou le gant de pièce en mouvement.
Des vêtements flottants, des bijoux ou des cheveux longs risquent
d'être happés par des pièces en mouvement.
9. Méfiez-vou d'un démarrage accidentel. Avant d'in érer un
bloc-batterie, a urez-vou que l'interrupteur de l'outil e t ur
ARRÊT. Le fait de transporter un outil avec le doigt sur la détente ou
d'insérer un bloc-batterie alors que l'interrupteur est en position
MARCHE peut mener tout droit à un accident.
10. Enlevez le clé de réglage ou de errage avant de démarrer
l'outil. Une clé laissée dans une pièce tournante de l'outil peut
provoquer des blessures.
11. Ne vou penchez pa trop en avant. Maintenez un bon appui et
re tez en équilibre en tout temp . Un bonne stabilité vous permet
de mieux réagir à une situation inattendue.
12. Utili ez de acce oire de écurité. Portez toujour de lunette
ou une vi ière. Selon les conditions, portez aussi un masque
antipoussière, des bottes de sécurité antidérapantes, un casque
protecteur et/ou un appareil antibruit.
14. Ne forcez pa l'outil. Utili ez l'outil approprié à la tâche. L'outil
correct fonctionne mieux et de façon plus sécuritaire. Respectez aussi
la vitesse de travail qui lui est propre.
15. N'utili ez pa un outil i on interrupteur e t bloqué. Un outil que
vous ne pouvez pas commander par son interrupteur est dangereux
et doit être réparé.
16. Retirez le bloc-batterie ou mettez l'interrupteur ur ARRÊT ou
en po ition verrouillée avant d'effectuer un réglage, de changer
d'acce oire ou de ranger l'outil. De telles mesures préventives
réduisent le risque de démarrage accidentel de l'outil.
17. Rangez le outil hor de la portée de enfant et d'autre
per onne inexpérimentée . Les outils sont dangereux dans les
mains d'utilisateurs novices.
18. Lor que le bloc-batterie n'e t pa en ervice, tenez-le à l'écart
d'autre objet métallique (trombone , pièce de monnaie, clé ,
clou , vi , etc.) u ceptible d'établir un contact électrique en-
tre le deux borne . La mise en court-circuit des bornes de la batterie
peut produire des étincelles et constitue un risque de brûlures ou
d'incendie.
19. Prenez oin de bien entretenir le outil . Le outil de coupe
doivent être toujour bien affûté et propre . Des outils bien
entretenus, dont les arêtes sont bien tranchantes, sont moins
susceptibles de coincer et plus faciles à diriger.
20. Soyez attentif à tout dé alignement ou coincement de pièce
en mouvement, à tout bri ou à toute autre condition préjudiciable
au bon fonctionnement de l'outil. Si vou con tatez qu'un outil
e t endommagé, faite -le réparer avant de vou en ervir. De
nombreux accidents sont causés par des outils en mauvais état. Fixez-
y une étiquette marquée « Hors d'usage » jusqu'à ce qu'il soit réparé.
21. N'utili ez que de acce oire que le fabricant recommande pour
votre modèle d'outil. Certains accessoires peuvent convenir à un
outil, mais être dangereux avec un autre.
VOUS DEVEZ LIRE ET COMPRENDRE TOUTES LES INSTRUCTIONS.
Le non-re pect, même partiel, de in truction ci-aprè entraîne un ri que de choc
électrique, d'incendie et/ou de ble ure grave .
CONSERVEZ CES INSTRUCTIONS
13. Immobili ez le matériau ur une urface table au moyen
debride ou de toute autre façon adéquate. Le fait de tenir la pièce
avec la main ou contre votre corps offre une stabilité insuffisante et
peut amener un dérapage de l'outil.
22. La réparation de outil électrique doit être confiée à un
réparateur qualifié. L'entretien ou la réparation d'un outil électrique
par un amateur peut avoir des conséquences graves.
23. Pour la réparation d'un outil, n'employez que de pièce de
rechange d'origine. Suivez le directive donnée à la ection «
Réparation » de ce manuel. L'emploi de pièces non autorisées ou
le non-respect des instructions d'entretien peut créer un risque de
choc électrique ou de blessures.
AVERTISSEMENT!

page 10
Disposez correctement des
batteries au nickel-cadmium
RÈGLES DE SÉCURITÉ PARTICULIÈRE
1. Entretenez le étiquette et marque du fabricant. Les indications qu'elles contiennent sont précieuses. Si elles deviennent illisibles ou se
détachent, faites-les remplacer gratuitement à un centre de service MILWAUKEE accrédité.
2. AVERTISSEMENT! La poussière dégagée par perçage, sciage et autres travaux de construction contient des substances chimiques reconnues
comme pouvant causer le cancer, des malformations congénitales ou dautres troubles de reproduction. Voici quelques exemples de telles sub-
stances :
 Le plomb contenu dans la peinture au plomb.
 Le silice cristallin contenu dans la brique, le béton et divers produits de maçonnerie.
 Larsenic et le chrome servant au traitement chimique du bois.
Les risques associés à lexposition à ces substances varient, dépendant de la fréquence des travaux. Afin de minimiser lexposition à ces sub-
stances chimiques, assurez-vous de travailler dans un endroit bien aéré et dutiliser de lequipement de sécurité tel un masque antipoussière
spécifiquement conçu pour la filtration de particules microscopiques.
DESCRIPTION FONCTIONNELLE
Pictogra hie
Tension CD seul.
Tours-minute á vide (RPM)
Underwriters Laboratories, Inc.
ACNOR Association Canadienne
de normalisation
Dim. tige
de foret
13 mm
(1/2")
9,5 mm
(1/2")
No de
Cat.
0511-21
0512-21
Volt
14,4
14,4
Tr/min.
à vide
Low 0-450
High 0-1 250
Low 0-450
High 0-1 250
S écifications
12
43
5
7
6
No de Cat. 0511-21
12
43
5
7
6
No de Cat. 0512-21
1. Réglage du démultiplicateur
2. Sélecteur de vitesse
3. Boutons de dégagement
4. Batterie
5. Détente
6. Commande d' interrupteur
7. Mandrin à serrage sans clé
