MIMAKI UJF-7151 plus User manual

MIMAKI ENGINEERING CO., LTD.
URL: http://eng.mimaki.co.jp/ D202901-12
Original instructions

i
CAUTION ........................................................................................ v
DISCLAIMER OF WARRANTY ............................................................ v
Requests .............................................................................................. v
FCC Statement (USA) .......................................................................... v
Interference to televisions and radios ................................................... v
CDRH REGULATION ........................................................................... v
Foreword .........................................................................................vi
On this operation manual .................................................................... vi
For safe operation ...........................................................................vi
Symbols ............................................................................................... vi
Position of the warning label ..........................................................xii
Chapter 1 Before Use
Installing the machine .................................................................. 1-2
Where to install the machine............................................................. 1-2
Moving this machine.......................................................................... 1-2
Configuration and Function .......................................................... 1-3
Front.................................................................................................. 1-3
Rear................................................................................................... 1-4
Operation Panel ................................................................................ 1-5
Carriage............................................................................................. 1-6
About table ................................................................................... 1-6
About tap position.............................................................................. 1-6
Connecting the cables ................................................................. 1-7
Connecting the USB2.0 interface cable ............................................ 1-7
Connecting the LAN cable................................................................. 1-7
Connecting the power cable.............................................................. 1-8
About ink bottle ............................................................................ 1-8
Kinds of ink that can be used ............................................................ 1-8
Caution in handling of ink bottles ...................................................... 1-9
Setting ink bottles ........................................................................ 1-9
About Media ............................................................................... 1-14
The sizes of media that can be used............................................... 1-14
Precautions in handling the media .................................................. 1-14
Menu mode ................................................................................ 1-14
Chapter 2 Basic Operations
Operation flow .............................................................................. 2-2
Turning the Power ON/OFF ......................................................... 2-3
Turning the Power ON....................................................................... 2-3
Turning the Power OFF..................................................................... 2-3
Setting the media ......................................................................... 2-4
Set the media in another method ...................................................... 2-6
Test printing ................................................................................. 2-6
Execution of head cleaning .......................................................... 2-7
Printing an image from source data ............................................. 2-8
Starting the printing operation ........................................................... 2-8
TABLE OF CONTENTS

ii
Interruption of printing ....................................................................... 2-8
Checking printing data that is being received or has been received . 2-9
When [! WORK High] is displayed..................................................... 2-9
If you open the cover during printing ................................................. 2-9
Chapter 3 Setup
About Head Height MENU ...........................................................3-2
Head Height MENU table .................................................................. 3-2
Setting the Media Thickness ............................................................. 3-3
Setting the HEAD GAP...................................................................... 3-3
Gap check ......................................................................................... 3-3
About ORIGIN SETUP MENU .....................................................3-4
ORIGIN SETUP MENU table ............................................................ 3-4
Setting the X offset ............................................................................ 3-5
Setting the Y offset ............................................................................ 3-5
Setting the Z origin ............................................................................ 3-5
Changing the origin using the JOG keys........................................... 3-5
About SETUP MENU ...................................................................3-6
SETUP MENU table .......................................................................... 3-7
Setting of Media Correction............................................................... 3-8
Setting of LOGICAL SEEK ................................................................ 3-8
Setting of INK LAYERS ..................................................................... 3-9
Setting of REFRESH LEVEL............................................................. 3-9
Setting of PRIORITY ......................................................................... 3-9
Setting of UV MODE ....................................................................... 3-10
Setting of WORK CHANGE............................................................. 3-10
Setting of FAN MODE ..................................................................... 3-10
Setting of AUTO CLEANING........................................................... 3-10
Setting of PRINT FLUSHING LEVEL .............................................. 3-11
Setting of MAPS .............................................................................. 3-11
Setting of the Misregistration adjust ................................................ 3-12
About MACHINE SETUP MENU ................................................3-13
MACHINE SETUP MENU table ...................................................... 3-14
Setting Time .................................................................................... 3-15
Setting Unit (Temperature/ Length)................................................. 3-15
Setting a KEY BUZZER................................................................... 3-15
Set the network ............................................................................... 3-16
Setting event mail function .............................................................. 3-17
Setting a LANGUAGE ..................................................................... 3-21
Initializing the Settings..................................................................... 3-21
About NOZZLE CHECK MENU .................................................3-22
INFORMATION MENU table........................................................... 3-22
Printing Check Flow ........................................................................ 3-23
Printing Operations at “Nozzle Missing” Judgment and Error
Occurrence...................................................................................... 3-23
Setting the Printing Check............................................................... 3-24
Setting the NOZZLE RECOVERY................................................... 3-24
Setting the Judgement Condition .................................................... 3-24
About INFORMATION MENU ....................................................3-25
INFORMATION MENU table........................................................... 3-25
Displaying the Information............................................................... 3-26

iii
Chapter 4 Maintenance
Routine maintenance ................................................................... 4-2
When this machine is left unused for a long time.............................. 4-2
Precautions in cleaning ..................................................................... 4-2
Cleaning exterior surfaces................................................................. 4-2
Cleaning the table ............................................................................. 4-3
About MAINTENANCE MENU ..................................................... 4-4
MAINTENANCE MENUs at-a-glance................................................ 4-5
Maintaining the Capping Station .................................................. 4-6
Cleaning the Wiper and Cap ............................................................. 4-6
Washing the Ink Discharge Passage ................................................ 4-7
Cleaning the Ink Head and the Area around It ............................ 4-8
Nozzle Recovery Function ....................................................................... 4-9
Reset the set value.......................................................................... 4-10
Checking the UV Lamp Usage........................................................ 4-10
Setting Interval wiping ..................................................................... 4-10
Changing the Time When a Warning about Wiper Replacement Is
Issued.............................................................................................. 4-11
Checking the Head Gaps at the Four Corners of the Table............ 4-11
Checking Ink Landing Displacement............................................... 4-11
Solving the Ink Overflow Problem ................................................... 4-12
Replacing consumables ............................................................. 4-12
If a Waste Ink Tank Confirmation Message Appears...................... 4-12
Replacing the waste ink tank before the waste ink tank confirmation
message is displayed...................................................................... 4-14
Refilling antifreeze mixed water ................................................. 4-14
Refill antifreeze mixed water ........................................................... 4-15
Chapter 5 Troubleshooting
Troubleshooting ........................................................................... 5-2
Power does not turn on ..................................................................... 5-2
The machine does not start printing.................................................. 5-2
Image quality is poor ......................................................................... 5-2
Nozzle is clogged .............................................................................. 5-3
Ink bottle warning appears ................................................................ 5-3
Warning / Error Messages ........................................................... 5-4
Warning messages............................................................................ 5-4
Error messages................................................................................. 5-6
Chapter 6 Appendix
Specifications ............................................................................... 6-2
Machine specifications ...................................................................... 6-2
Ink specifications............................................................................... 6-3
Setting orders of ink bottles ......................................................... 6-4
Sheet for inquiry ........................................................................... 6-5

iv

CAUTION
v
CAUTION
DISCLAIMER OF WARRANTY
THIS LIMITED WARRANTY OF MIMAKI SHALL BE THE
SOLE AND EXCLUSIVE WARRANTY AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS, AND MIMAKI NEITHER ASSUMES NOR
AUTHORIZES DEALER TO ASSUME FOR IT ANY
OTHER OBLIGATION OR LIABILITY OR MAKE ANY
OTHER WARRANTY OR MAKE ANY OTHER
WARRANTY IN CONNECTION WITH ANY PRODUCT
WITHOUT MIMAKI’S PRIOR WRITTEN CONSENT.
IN NO EVENT SHALL MIMAKI BE LIABLE FOR
SPECIAL, INCIDNETAL OR CONSEQUENTIAL
DAMAGES OR FOR LOSS OF PROFITS OF DEALER
OR CUSTOMERS OF ANY PRODUCT.
Requests
• This Operation Manual has been carefully prepared for
your easy understanding, however, please do not
hesitate to contact a distributor in your district or our
office if you have any inquiry.
• Description contained in this Operation Manual are
subject to change without notice for improvement.
FCC Statement (USA)
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the operation manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely
to cause harmful interference in which cause the user will
be required to correct the interference at his own
expense.
Interference to televisions and radios
The product described in this manual generates low radio
waves while it is in operation. The product can interfere
with radios and televisions if set up or commissioned
under improper conditions. The product is not guaranteed
against any damage to specific-purpose radios and
televisions.
The product’s interference with your radio or television will
be checked by turning on/off the power switch of the
product.
In the event that the product is the cause of interference,
try to eliminate it by taking one of the following corrective
measures or taking some of them in combination.
• Change the direction of the receiving antenna or the
feeder of your radio/television.
• Move the receiver away from the product.
• Plug the power cord of this machine into an outlet
which is isolated from power circuits connected to the
television set or radio.
CDRH REGULATION
The Center for Devices and Radiological Health for the
U.S. Food and Drug Administration Implement regulations
for laser products. The sentence of “This product
complies with 21 CFR chapter I and subchapter J”
indicates compliance with the CDRH regulations and is
labeled on the product when marketed in the United
States. This Model is equivalent to Class II laser device
according to CDRH Regulation.
• In the case where MIMAKI-recommended
cable is not used for connection of this
device, limits provided by FCC rules can be
exceeded. To prevent this, use of MIMAKI-
recommended cable is essential for the
connection of this machine.
This product complies with 21 CFR chapter I
and subchapter J
• Use of controls, adjustments or performance
of procedures other than those specified in
this manual may results in hazardous
radiation exposure.

vi
Foreword
1
2
2
2
2
2
Foreword
Congratulations on your purchase of a MIMAKI “UJF-
7151 plus” model of UV ink jet printer.
UV Inkjet Printer UJF-7151 plus uses ultraviolet ray curing
ink (UV ink).
Read this Operation Manual carefully and make the most
effective use of your printer.
On this operation manual
• This Operation Manual describes the operation and
maintenance of Model UJF-7151 plus Color Ink Jet
Printer (hereinafter referred to as the machine).
• Please read and fully understand this Operation
Manual before putting the machine into service. It is
also necessary to keep this Operation Manual on hand.
• Make arrangements to deliver this Operation Manual to
the person in charge of the operation of this machine.
• This Operation Manual has been carefully prepared for
your easy understanding, however, please do not
hesitate to contact a distributor in your district or our
office if you have any inquiry.
• Description contained in this Operation Manual are
subject to change without notice for improvement.
• In the case where this Operation Manual should be
illegible due to destruction or lost by fire or breakage,
purchase another copy of the Operation Manual from
our office.
• You can also download the latest operation manual
from our website.
Reproduction of this manual is strictly prohibited.
All Rights Reserved. Copyright
© 2015 MIMAKI ENGINEERING CO., LTD.
For safe operation
Symbols
Symbols are used in this Operation Manual for safe
operation and for prevention of damage to the machine.
The indicated sign is different depending on the content of
caution.
Symbols and their meanings are given below. Please
follow these instructions as you read this manual.
Examples of symbols
Meaning
Failure to observe the instructions given with
this symbol can result in death or serious
injuries to personnel. Be sure to read it carefully
and use it properly.
Failure to observe the instructions given with
this symbol can result in injuries to personnel or
damage to property.
Important notes in use of this machine are
given with this symbol. Understand the notes
thoroughly to operate the machine properly.
Useful information is given with this symbol.
Refer to the information to operate the machine
properly.
Indicates the reference page for related
contents.
The symbol " " indicates that the
instructions must be observed as strictly as the
CAUTION instructions (including DANGER and
WARNING instructions). A sign representing a
precaution (the sign shown at left warns of
hazardous voltage) is shown in the triangle.
The symbol " " indicates that the action
shown is prohibited. A sign representing a
prohibited action (the sign shown at left
prohibits disassembly) is shown in or around
the circle.
The symbol " " indicates that the action
shown must be taken without fail or the
instructions must be observed without fail. A
sign representing a particular instruction (the
sign shown at left instructs to unplug the cable
from the wall outlet) is shown in the circle.

For safe operation
vii
Never do the following
WARNING
• Be sure to setup the appropriate air-moving
system in case of using this machine in a
closed room or a room with bad ventilation.
• Cautions for constructing exhaust outlet
Please observe the following cautions to
avoid breakdown of this machine.
(1) The opening area of the exhaust outlet
requires more than half of the duct
entrance area.
(2) If mounting a valve on the exhaust outlet,
be sure to open the valve when using the
machine.
• The ink used for this machine falls into the
category of UN No.3082 and UN Class 9.
Since the ink is flammable, never use fire
when using the machine.
• When cleaning the ink station or the head, be
sure to wear the supplied goggle and gloves
since you may get ink or cleaning solution in
your eyes.
• If anyone swallows ink or cleaning solution in
mistake, get the person to vomit and see a
doctor immediately. Do not let him or her
swallow the vomit. Then, refer MSDS about
the inquiry.
• If you inhale a lot of vapor and feel bad,
immediately move to a location of fresh air and
then keep yourself warm and quiet. Then,
consult a doctor as soon as possible.
•Discard the waste ink according to the local
regulations of the area that this machine is
used.
WARNING
Do not disassemble or remodel the machine
• Never disassemble or remodel this machine
and the ink bottle.
Disassembling or remodeling any of them will
result in electric shocks or breakdown of this
machine.
Do not use this machine in damp places
• Avoid damp environment to use this machine.
Do not splash water onto this machine. High
humidity or water will give rise to fire, electric
shocks or breakdown of this machine.
Wearing protective devices
• When cleaning the suction nozzle, which may
scatter ink, be sure to wear safety glasses and
gloves, or ink and cleaning solution might
enter your eyes or ink and cleaning solution
put on your hands might make your hands
rough.
Handling of ink bottles
• Some of the ingredients (UV Curing initiator)
have toxic consequences to aquatic life. Avoid
leak into water system or sewage containing
water.
• Store ink bottles and waste ink tank in a place
that is out of the reach of children.
• If ink settles on the skin or clothes,
immediately wash it off with detergent or
water. If you get ink in your eyes, immediately
wash your eyes with a lot of clean water, and
then consult a doctor as soon as possible.
Abnormal event occurs
• If the machine is used under an abnormal
condition where the machine produces smoke
or unpleasant smell, fire or electric shocks can
result. Be sure to turn off the power switch
immediately and detach the plug from the
receptacle. Check first to be sure that the
machine no longer produces smoke, and
contact a distributor in your district for repair.
• Never repair your machine by yourself since it
is very dangerous for you to do so.
Power supply and voltage
• Use this machine with indicated power
specifications.
Be sure to connect the power cable plug to the
grounded outlet, or it may cause fire or electric
shock.
• Never look at the LED UV being lit with your
naked eyes, or it may cause pain in your eyes
or visual impairment. Be sure to wear safety
glasses.
• Do not apply ultraviolet (UV) light directly to
your skin, or it may cause irritation on your
skin.
• To prevent electrical shock, be sure to set OFF
the main power circuit breaker and disconnect
the power plug before carrying out
maintenance. For some units, capacitors may
take one minute for discharging; therefore,
start maintenance work three minutes after
setting OFF the main power circuit breaker
and disconnecting the power plug.
• If LED UV has been damaged, you should
replace the LED UV that has reached or has
past its rating life.
• The main power circuit breaker should be set
ON only by personnel with sufficient
knowledge about operations of this machine.
• Do not touch the lamp with bare hands while
lighting or right after the lamp off to avoid from
burn injury.
Handling of the power cable
• Use a power cable attached to this machine.
• Take care not to damage, break or work on the
power cable. If a heavy things are put on the
power cable, heated or drawn, the power
cable can break to cause fire or electric
shocks.
WARNING

viii
For safe operation
1
2
2
2
2
2
Precautions for use
Handling of LED UV
• Do not use the LED UV in an ambience with a
possibility of catching fire (gasoline,
combustible gas spray, thinner, lacquer,
powder dust, etc.). In addition, do not put
paper or cloth near or on the LED UV, or it may
cause fire, or it may cause electrical shock.
Handling of the antifreeze liquid
• Use the exclusive antifreeze liquid, or the
cooling device may be damaged.
• If the antifreeze liquid or mixed soft water with
antifreeze liquid gets on the skin or clothes,
immediately wash it off with soap.
If you get the antifreeze liquid in your eyes,
immediately wash your eyes with a lot of clean
water. Then, consult a doctor as soon as
possible.
• Before using the antifreeze liquid, be sure to
read the Material Safety Data Sheet (MSDS).
• If you swallowed the antifreeze liquid
accidentally, try to get to vomit, and then
consult a doctor as soon as possible.
• Discard the waste antifreeze liquid or used
mixed soft water with antifreeze liquid as
follows;
Absorb in a sawdust or waste cloth, then
incinerate it.
• Entrust to an industrial waste disposal
contractor, clarifying their contents.
• Avoid causing ignition with static electricity,
impact spark and so on.
• Be sure to wear goggles and gloves for
handling the antifreeze liquid.
CAUTION
Protection against dust
• It is strongly recommended to use the
machine in a room that is not dusty.
Set the Refresh level 2 or 3 when in bad
environment.
• When leaving the work place after the working
hours, be sure to remove media from the
printer.If any media is left on the printer, dust
can put on it.
• Store media not to put dust on it. Wiping dust
off the media, dust will be put on the media
due to static electricity.
• Due to the dust on the head, ink drops will fall
down on the media during printing. If so, be
sure to clean up the head. ( P.2-12)
Periodic exchange parts
• There are some parts which must be
periodically replaced. Contract with
distributors or dealers for maintenance.
WARNING
Ink bottles
• If the ink bottle is moved from a cold place to a
warm place, leave it in a place of use for three
hours or more and use it.
• Open the ink bottle just before installing.
Leaving it open for a long time will cause
abnormal printing.
• Be sure to store ink bottles in a cold and dark
place.
• Once the ink opened, be sure to use ink up
early. The ink passed for a long time after
opening the bottle will lower the printing
quality.
• Using other than exclusive ink will break this
machine. In this case, repairing of this
machine is your responsibility.
• Never refill the ink bottle with ink.
• Do not pound the ink bottle nor shake it
violently. If so, ink may leak out of the bottle.
UV light
• A little UV light spills around the LED UV unit.
UV light applied to your skin might cause
inflammation and/or skin cancer.
Even weak UV light causing no inflammation
may lead to chronic disorders by repeated
exposure. Avoid applying UV light to your skin
and eyes.
• Impairment of eyes caused by UV light may be
acute disorders, pain in eyes, tearing, chronic
disorders, cataract, etc.
When using this machine, protect your body
such as gloves, long-sleeve cloth, light-
resistant mask, attached light-resistant
glasses, etc.
Hot parts
• The LED UV and the interior of the UV
irradiation device will have a very high
temperature. When carrying out maintenance,
wait until the temperature has been sufficiently
lowered after the lamp is turned OFF.
• When it is unavoidable to touch hot parts, be
sure to wear heat-insulating gloves to protect
your hands.
Warning labels
• Warning labels are adhered on this machine.
Be sure to fully understand the warnings given
on the labels. In the case where any of the
warning label has become so soiled that the
warning message is illegible or has come off,
purchase a new one from your local distributor
or our office.
Periodic exchange parts
• There are some parts which must be
periodically replaced. Contract with
distributors or dealers for maintenance.
Adjusting the level
• Keep this machine horizontal.
CAUTION

ix
For safe operation
Handling of cleaning solution
• Be sure to store the cleaning solution in a cold
and dark place. Store the cleaning solution in
a place that is out of the reach of children.
Handling the antifreeze liquid
• Be sure to store the antifreeze liquid in a cold
and dark place.
• Store the antifreeze liquid in a place that is out
of the reach of children.
Notes on LED UV
• When handling the glass on the bottom of the
LED UV unit, be sure to wear the gloves
attached and never touch them with bare
hands. Or the UV ink curing level may
significantly lower. If the glass becomes dirty,
wipe it with clean gauze moistened with
alcohol. (Do not use alcohol for cleaning the
exterior cover, or the paint will peel off.)
• The LED UV performance and service life are
significantly affected by the UV irradiation and
UV power supply units used. Never use those
UV devices other than those recommended by
Mimaki. We would take no responsibility for
any troubles caused through the use of a UV
devices not recommended by Mimaki.
Cleaning
• After using this machine long time, foreign
materials and dust may be gathered on the
conductive and insulating parts, causing
electric leakage. Periodically clean such parts.
• For cleaning, do not use compressed air
because it scatters foreign materials and dust,
which may cause malfunctions when put
inside the conductive parts. Be sure to use
vacuum cleaner to vacuum off foreign
materials and dust.
• Do not use the machine in a place where there
is a possibility of being wet, or electricity may
leak.
• Electrical leakage may lead to electrical shock
of personnel or fire.
• To prevent accidents, be sure to carry out
periodic inspections and replace periodic
replacement parts.
Firing and smoking
• Touching hot parts such as the LED UV with
combustible materials may cause firing and/or
smoking.
Leaving combustible materials under the LED
UV unit for a couple of minutes may also
cause firing and/or smoking.
CAUTION

x
For safe operation
1
2
2
2
2
2
• After this machine is used long time, foreign
materials or dust gathered may cause
electrical leakage, or insulation deterioration
may cause firing and/or smoking. Periodically
clean this machine and replace the
deteriorated parts after the insulation
resistance.
• After this machine is used long time, screws or
others on the conductive parts may be
loosened, causing firing and/or smoking.
Periodically tighten the screws.
• If abnormalities such as a strange odor, a
smoking or a spark burn occurred, turn the
power off and call our office immediately.
Laser Module
CAUTIO
N
• The printer incorporates a laser module.
The laser module is evaluates as Class 1
Laser Products.
• Use of controls or adjustments or performance
of procedures other than those specified
herein may result in hazardous radiation
exposure.
Laser Diode 655 - 660nm, max. 0.5mW
Maximum output : 0.12 mW
IEC60825-1: 2007
CAUTION

xi
For safe operation
Cautions on Installation
CAUTION
A place exposed to direct
sunlight On an inclined surface
A place that vibrates
A place exposed to direct air
flow from an air conditioner
or the like.
A place where temperature or
humidity varies significantly
Around a place where fire
is used
•Use the machine
under the following
environmental
conditions:
• Operating environment:
20 to 30 °C
(68 to 86 °F)
35 to 65 % (Rh)

xii
Position of the warning label
1
2
2
2
2
2
Position of the warning
label
Warning labels are adhered on this machine. Be sure to
fully understand the warnings given on the labels.
In the case where any of the warning label has become so
soiled that the warning message is illegible or has come
off, purchase a new one from your local distributor or our
office.

Position of the warning label
xiii
6
4
2
3
7
9
8
1
1
5
10
1
11
1
6
8
1
1
12
1
Order No. Label Order No. Label

xiv
Position of the warning label
1
2
2
2
2
2
(1)M910540 (6)M906222
(2)M901549 (7)M906115
(3)M903330 (8)M903226
(4)M905980 (9)M912568
(10)M904325
(11)M912569
(5)M910560 (12)M907935
ἘὊἨἽɥỆ ᵏᵎᶉᶅ ˌɥỉờỉử
᠍ẶễẟỂɦẰẟẇ
DO NOT PUT OVER
10KG ON THE TABLE

Position of the warning label
xv

This chapter
describes the items required to understand before use, such as the name of each part of
the machine or the installation procedures.
Installing the machine ................................... 1-2
Where to install the machine ....................... 1-2
Moving this machine ................................... 1-2
Configuration and Function........................... 1-3
Front ............................................................ 1-3
Rear ............................................................ 1-4
Operation Panel .......................................... 1-5
Carriage ...................................................... 1-6
About table.................................................... 1-6
About tap position ....................................... 1-6
Connecting the cables .................................. 1-7
Connecting the USB2.0 interface cable ...... 1-7
Connecting the LAN cable .......................... 1-7
Connecting the power cable ........................ 1-8
About ink bottle ............................................. 1-8
Kinds of ink that can be used .......................1-8
Caution in handling of ink bottles .................1-9
Setting ink bottles.......................................... 1-9
About Media ................................................ 1-14
The sizes of media that can be used ......... 1-14
Precautions in handling the media .............1-14
Menu mode ................................................. 1-14
Chapter 1
Before Use

Chapter 1 Before Use
1-2
Installing the machine
Where to install the machine
Secure sufficient space for installation before assembling
this machine.
Decide the place considering the size of the machine and
a space required for printing.
Moving this machine
Move this machine as follows when this machine is
required to move on the step-free same floor.
Before moving this machine, install the
handles for transporting. (two places)
Insert the handles into this machine, and fix them
tightening screws.
For safety, be sure to work it with more than 8
people.
Do not push the cover to move this machine since the
cover may be deformed. Be sure to hold the handles
for transporting when moving the machine.
Model Width Depth Height Total
Weight
UJF-7151
plus 2,193
mm 1,572mm
1,273mm
(Including
dedicated stand)
Approx.310 kg
• When moving this machine, take care not to give a
significant impact on it.
• When moving this machine, keep it as flatly as
possible. Do not move it on its side. It may cause
machine failure.
• The dedicated stand of this machine includes
leveling feet to secure the machine.
Before turning the power ON, make sure that the
printer body is fixed with the leveling feet.
The printer body may start moving during
operation if it is not fixed with the leveling feet.
300 mm
or more
500 mm or more
2,793mm or more
1,702mm or more
300 mm
or more
500 mm or more
300 mm
Handles for
transporting

1-3
Chapter 1 Before Use
1
2
2
2
2
Configuration and Function
Front
Ink supply unit
Insert ink bottles here.( P.1-
8)
Table ( P.2-4)
Set media on it.
Operation Panel ( P.1-5)
Operation keys for setting
the machine, and a display
to display operation items
are placed.
Power button
Turn ON/OFF the power of
this machine instead of the
power switch of main body.
(P.2-3, P.2-3)
Carriage ( P.1-6)
The carriage is provided with the
heads for printing.
Waste ink tank
Waste ink gathers in this tank.
Maintenance Cover
Open the cover during
maintenance.

1-4
Chapter 1 Before Use
Rear
Main power switch
Turn ON/OFF the power of the
machine.
USB socket
Connect USB interface cable.
LAN connector
This is Ethernet interface
connector.
