Graphic Arts Solutions
imagePROGRAF W8400 PRINTER
WITH COLORTRAC SCANNER SYSTEM*
*This solution is also available with the imagePROGRAF W8400D and imagePROGRAF W6400 models.

This complete workflow solution provides for a fast and effective
large-format capture-to-output system for a wide variety of users.
Copying, archiving, or distributing maps, CAD drawings, posters,
or documents is simple, quick, and easy. This system includes
not only the hardware–imagePROGRAF printer, Colortrac color
scanner, desktop workstation–but also software, such as
CopySmart, SmartLF, and the HDI driver, to give any level of
user a complete, out-of-the-box solution.
The scanner provides room for flexible document formats of up
to 44" wide (40" image width) by unlimited length. It has scan
speeds of up to 10.1 inches per second for monochrome and
3.36 inches per second for color, making this a powerful pro-
duction tool for many environments. It’s ideal for documents in
the AEC, CAD, GIS, archive, reproduction, and office markets, such
as maps (GIS); construction, engineering, and manufacturing
drawings; site and facilities management plans (VAC/plumbing/
utilities); court and property documents; design and layout
proofs; posters; and office documents.
Large-Format Solutions
imagePROGRAF W8400 PRINTER
WITH COLORTRAC SCANNER SYSTEM
Canon has teamed up with Colortrac to provide a
powerful scan-to-copy/print/e-mail integrated system
that combines Canon’s fast, high-quality printer with
Colortrac’s speedy, color-accurate scanner.
imagePROGRAF W8400D with
Colortrac Scanner System
imagePROGRAF W6400
(Also available with Colortrac Scanner System)

SCANNER
It’s ready to go within seconds from power ON, with no warm-up
or stabilization time required.
• 600-dpi optical/maximum resolution
• Maximum achievable scan speeds, at 200-dpi resolution,
of up to 10.1 inches per second for monochrome and 3.36
inches per second for color
• Reliable, solid-state optical sensors for optimum support
and positioning of the original image
• Auto-size detection techniques that work in-line as the
image is scanned
• Documents are transported by precision rollers with the
minimum force necessary to preserve delicate originals
imagePROGRAF PRINTER*
The imagePROGRAF Series of printers, with Canon’s pro-
prietary print-head technology, enables high-speed printing
at 2400 x 1200 dpi, with precise 4pl ink droplets for high
image resolution, clarity, and detail. A wide variety of media is
available for applications, ranging from technical documents
to photographs. This solution is available now with the
imagePROGRAF W8400D, imagePROGRAF W8400, and
imagePROGRAF W6400 models.
A solution isn’t just hardware...
SMARTLF SOFTWARE
This “ready-to-run” software is easy to use and designed for oper-
ation by a novice user. Select the File, Copy, or E-Mail function,
the type of file to be scanned, and a few other intuitive settings.
Then place the original in the scanner and off it goes!
As the document is scanned, the image is displayed on the
screen to provide reassurance that what you’re getting is what
you want.
COPYSMART SOFTWARE
This software creates a multifunction scan/copy/print system,
maximizing investment and the utilization of the equipment.
CopySmart has a graphical user interface that adopts a “big
button” philosophy with which current Canon office equipment
users will be familiar. Utilize the software’s advanced feature set
of CMYK color controls, brightening adjustment, text or bitmap
insertion, crop, scale, zoom, and many others to edit documents.
AND THERE’S MORE…
All Canon scan-to-print solutions include the creative software
that comes with an imagePROGRAF printer. Create stunning prints
right out of the box with software that’s designed to put your
ideas on paper. Or scan documents and import them into
PosterArtist to create custom posters.
SmartLF Screen
THIS imagePROGRAF SYSTEM INCLUDES ALL COMPONENTS NECESSARY TO SAVE SCANNED IMAGES,
DISTRIBUTE THEM ELECTRONICALLY, AND PRINT THEM QUICKLY AND ACCURATELY.
No matter what the application or skill level of the user, Canon includes the tools
needed to create, process, and print large-format output.
*Please check www.usa.canon.com for up-to-date model availability.

As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that the imagePROGRAF W8400D,
imagePROGRAF W8400, and imagePROGRAF W6400 devices meet the ENERGY STAR guidelines for energy
efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. AutoCAD is a registered trade-
mark of Autodesk, Inc. in the United States. Windows and Windows NT are registered trademarks of Microsoft
Corporation in the United States and/or other countries. Macintosh is a registered trademark of Apple
Computer, Inc. Adobe, Photoshop, and PostScript are registered trademarks of Adobe Systems Incorporated
in the United States and/or other countries. Pentium is a registered trademark of Intel Corporation. PANTONE
is a registered trademark of Pantone, Inc. UL is a registered trademark of Underwriter’s Laboratories, Inc.
PhotoPRINT is a trademark of Scanvec Amiable, Inc. CANON and IMAGEPROGRAF are registered trademarks of
Canon Inc. in the United States and may also be registered trademarks or trademarks in other countries.
IMAGEANYWARE is a trademark of Canon. All referenced product names and other marks are trademarks of
their respective owners.
Specifications subject to change without notice.
©2006 Canon U.S.A., Inc. All rights reserved.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
Specifications
0062W777
0606-W8400SCAN-5M-MTM
printed on recycled
paper in the u.s.a
Print Head: Bubble Jet On-Demand/
FINE/End-User Replaceable (BC-1300)/
6-Color Print Head
Number of Nozzles:
1,280 per Color; 7,680 Total
Droplet Size: 4 Picoliter
Nozzle Pitch (Head Resolution):
1200 dpi
Print Resolution (Max.):
2400 x 1200 dpi
Ink Tank: Cyan, Magenta, Yellow,
Black, Photo Cyan, Photo Magenta
Ink Capacity: 330ml
Ink Type: Dye
Bundled Software:
• Printing Software
-Printer Driver 2005, HDI Driver for
AutoCAD®
• Applications
-PosterArtist:▲Template-based
Custom Poster-Creation Software
-Digital Photo Print Pro:▲
Image Editing and Layout Software
for Large-Format Photo Printing
-Software RIP
PhotoPRINT Select for imagePROGRAF
(Adobe PostScript 3)
Languages:
• Printer
-GARO (Canon Proprietary)
• Via Software RIP
-PostScript, PDF 1.4, EPS, TIFF,
JPEG, BMP
Operating System:
• Driver
- Windows®98/Me, Windows NT®4.0
SP6/2000/XP/2003 Server,
Macintosh®OS 8.6/9/X
(10.2, 10.3, 10.4)
• Software RIP
- Windows 2000/XP, Macintosh OS X
Borderless Printing Width (Roll
Media Only):
10", 14", 16", 24", 36",
42", 594mm (ISO A1), 840mm (ISO A0),
515mm (JIS B2), 1030mm (JIS B0)
Nozzle Recovery System: Non-Firing
Nozzle Detection and Compensation
Interface:
• Standard: USB 2.0 High Speed,
10/100Base-T/TX
• Optional: IEEE1394 FireWire Card
(10/100Base-T/TX Card Must Be
Uninstalled)
Margins:
• Roll: All Sides: 0.20" (5mm)
• Cut Sheet: Leading and Left/Right
Edges: 0.20" (5mm);
Trailing Edge: 0.90"
(23mm)
Media Roll Diameter: 5.9" (150mm)
Power Supply: Input Power:
AC 100 – 240V (50 – 60Hz)
Certifications: UL®, FCC Class B,
ENERGY STAR®
Dimensions (With Stand):
64.6" x 38.2" x 42.3"
(1642mm x 972mm x 1075mm)
Weight (With Stand): 216 lb. (98kg)
User-Replaceable Items:
• Print Head (BC-1300)
• Maintenance Cartridge (MC-04)
• Cutter Blade (CT-02)
Operational Environment:
• Temperature: 59 – 86° F (15 – 30° C)
• Humidity: RH 10 – 80 %
(No Condensation)
▲Windows 2000/XP Only
Print Speed
Mode Resolution Sq. Feet/Hour
Plain Paper Draft 1200 x 1200 305
Standard 117
Heavyweight Draft 181
Coated Paper Standard 1200 x 1200 117
High 2400 x 1200 43
Glossy Photo Paper Standard 1200 x 1200 90
High 2400 x 1200 51
Plain Paper (CAD) Standard 1200 x 1200 175
High 92
Printed Image: ISO JIS-SCID No. 5 Chart (Bicycle Image)
Printed Image Size: 43.6 x 54.5" (1107mm x 1384mm)
Test Environment: Pentium®4/3.2GHz, Windows XP SP2, 1024MB RAM, USB 2.0 High
Speed, Adobe®Photoshop®7.0
Square Feet Per Hour does not include data transfer time and time for media cutting.
The test conducted here is a result of Canon Inc. internal testing. The actual print
speed varies, depending on number of factors including data size, data complexity,
application software, and interface.
Print Speed (CAD Line Drawing)
Rendering Print Time
Resolution
Plain Paper (CAD) 300 dpi 2 min. 15 sec.
600 dpi 3 min. 55 sec.
Coated Paper (CAD) 300 dpi 3 min. 48 sec.
Tracing Paper (CAD) 300 dpi 2 min. 15 sec.
600 dpi 3 min. 56 sec.
Printed Image: Cottage Plan and Elevation.dwg
Printed Image Size: E-size 44.6" x 31.2"
(1135mm x 795mm)
Print Resolution: 1200 x 1200 dpi
Test Environment: Pentium 4/2.2GHz, Windows 2000 SP4,
1048MB RAM, USB 2.0 High Speed, AutoCAD LT 2005
Print time does not include data transfer time and time for media cutting. The test conducted here is a result of Canon Inc.
internal testing. The actual print speed varies depending on number of factors such as data size, data complexity, appli-
cation software, and interface.
imagePROGRAF W8400D*
Scan Speeds:1
(a) Full Color @ 200 dpi: 3.36" (Per Second)
(b) Full Color @ 600 dpi: 1.68" (Per Second)
(c) Grayscale and Monochrome @ 200 dpi:
10.10" (Per Second)
(d) Grayscale/Monochrome @ 600 dpi:
5.04" (Per Second)
Scan Modes: 16.7-Million-Color RGB (24-Bit)
256-Level Grayscale (8-Bit)
Black and White (1-Bit)
Color Space: Normalized/Linearized Raw RGB
Color Image Processing: Gamma, Brightness,
Black-and-White Point Adjustment
Resolution: 3600 dpi (Max.)/600 dpi (Optical)/
Variable (100-3600 dpi, in 1-dpi Steps)
Scan Accuracy:
2+/- 0.1% ; +/- 1 pixel
Maximum Image Width: 40"
Maximum Media Width: 44"
Maximum Media Length: Not Limited by Scanner
Maximum Media Thickness: 0.08"
Media Feed System: Reliable, Front Loading and
Straight Through Media Path for User-Friendly,
Jam-Free Operation; Chemically Treated, Scratch-
Resistant Scan Glass with Easy-Clean Access Via
Hinged Grip-Roller Cover; Side Justified, One-Way
Document Transport with Adjustable Pressure
Plate (Paper Hold Down) Continuously Variable
Over a Range 0.08 inches (0.2 cm) with 0.06
Inches (0.15 cm) Pre-Compression; Precision
Power Rollers with 20 Offset, Dual Independently
Suspended High-Grip Contour Rollers Transport
Documents Gently and Accurately Through the
Scanner; Accurate, Zero-Maintenance Optical
Media Sensors and Automatic Media Size
Detection.
Digital Imaging Technology: Contact Image
Sensor (CIS) Technology–Requires No Stitching or
Maintenance Adjustment
• 5x Close-Spaced "Deep Focus" CIS (17,000 Pixels)
• Integral LED Illumination for Instant Scanning from
Power ON and Practically Unlimited Life Span
• 36-Bit Digital Color Image Capture
• Panchromatic Black and White
• Factory-Set, Permanent Smart Color Calibration
Digital Imaging Processing:
• 2D Intelligent Adaptive Thresholding (IAT)
(1-Bit Mode)
• Fixed Threshold Black and White (1-Bit Mode)
User Status and Control:
User Status and Control LCD Screen
Displaying Scanner Status, Mode, and
Settings. One-touch Push Button Operation for
Scan-To-File, Scan-To-Copy, and Scan-To-E-Mail.
User Maintenance: Installable Plug-n-Play
Scanner; Simple Cleaning
Scanner Interface Kit: 480 Mbits/Sec. USB 2
(On Scanner)/2m USB 2 Cable/Local Power
Cable
Operating Environment:
15 – 30° C, 15-80% RH, Non-Condensing
90 – 250 VAC Autosensing, 47 – 63 Hz, 24 VA
(Scanning), 15VA (Standby)
Compliances: CB, CE, FCC, UL
Colortrac Cx40e Scanner
System Components
1The scan rate is proportional across the full range of resolutions supported by the scanner. Actual scan times will depend on the host system performance. Speeds quoted are for documents less than 24 inches width (60.96 cm); wider documents scan half this speed.
2The quoted scan accuracy is valid for media up to 0.8mm thick and may vary depending on the operating environment and the type and thickness of media. SmartLF scanners are tested using a Mylar target at 20
° C +/- 30 ° C, 60% +/- 10% RH with the media feed set to standard.
imagePROGRAF Printer
Colortrac SmartLF 4080E Scanner with power cord and USB 2.0 Cable (scanner to server)
• 2 Meter USB Cable
(server to printer)
• Colortrac Universal
Reprographic Stand
• Colortrac Universal
Reprographic Stand
Assembly Instructions
• Colortrac CopySmart
Software
• Colortrac SmartLF
Software
• Dell Server: Pentium 4
HT 3 GHz Processor
• 1GB RAM
• Mini-Keyboard
• Mouse
• 17" Flat Panel Display
• 13:1 Media Card
Reader
• DVD/CD-RW Drive
• MS Windows XP
Professional
Operating System
• Quick Start Guide
• Operator Manual on
CD-ROM
* These are specifications for the imagePROGRAF W8400D printer. Please refer to www.usa.canon.com
for specifications for other Canon imagePROGRAF printers.
Standard with the Printer
• Stand
• User Software CD (Printer
Driver, HDI Driver,
Utilities)
• Application CDs
(PosterArtist, Digital
Photo Print Pro)
• Software RIP CD
(PhotoPRINT Select for
imagePROGRAF)
• 6 Ink Tanks (C, M, Y, K,
PC, PM)
• Basket
• 2" Core Media Spool
• Print Head
• Maintenance Cartridge
• Ethernet Card (Built In)
• USB 2.0 High-Speed
Interface
• User Guide CD
• Setup Guide (Poster)
• Printer Reference Guide
(Booklet)
• Hardware (For Setting
Upthe Stand)
• Power Cord
• Cutter Blade
