MIMAKI UJV100-160 Maintenance manual

You can also download the latest manual from official website.
MIMAKI ENGINEERING CO., LTD.
https://mimaki.com/ D203468-12
Original instructions

TABLE OF CONTENTS
2
Maintenance
1. Maintenance Precautions ........................................................... 4
2. Daily Maintenance ...................................................................... 5
Maintenance Items and Timing............................................................. 5
Items Required for Maintenance........................................................... 5
Ink Maintenance ................................................................................... 6
White Ink Maintenance ......................................................................... 6
Wiper Cleaning ..................................................................................... 7
Cap Cleaning ........................................................................................ 8
NCU Cleaning....................................................................................... 9
Carriage Underside Cleaning ............................................................. 10
Print Head Nozzle Washing................................................................ 12
Ink Discharge Channel Cleaning ........................................................ 13
Media Sensor Cleaning ...................................................................... 13
Automatic Correction Sensor (DAS) Cleaning.................................... 14
Media Holder Cleaning ....................................................................... 15
Platen Cleaning .................................................................................. 15
Cover (Exterior) Cleaning ................................................................... 16
When Not in Use for Extended Periods .............................................. 16
3. Consumable Item Replacement ............................................... 19
Wiper Replacement ............................................................................ 19
Cap Replacement ............................................................................... 20
Cap Absorber Replacement ............................................................... 21
Waste Ink Tank Replacement............................................................. 23
Pinch Roller Replacement .................................................................. 25
Media Holder Replacement ................................................................ 26
Media Cutter Replacement ................................................................. 28
LED Glass Replacement .................................................................... 29

3
Maintenance
To ensure years of precise performance, maintain this product periodically or based on frequency of use.
Read the maintenance precautions thoroughly before maintaining this product.

1. Maintenance Precautions
4
1. Maintenance Precautions
• This product contains components that must be replaced periodically. We recommend
concluding a maintenance contract.
• Maintain this product and replace consumable items to prevent quality defects and accidents.
• Clean periodically. Debris and dust will accumulate on electrical components when this product
is used for extended periods. Current leaks may result in failure, electric shock, or fire.
• Do not clean by blowing—e.g., avoid using air blowers. Doing so may lead to failure, electric
shock, or fire involving the product if airborne debris or dust gets inside electrical components.
Wipe away debris or dust using a soft cloth soaked in water and thoroughly wrung out. A
vacuum cleaner may also be used for cleaning.
• Do not allow liquids to get inside the product. Ingress of liquids into the product may lead to
failure, electric shock, or fire.
• For heavy soiling, wipe using a soft cloth soaked in dilute detergent and thoroughly wrung out.
• Wear safety glasses, gloves, and a mask when handling ink, maintenance cleaning solution,
waste ink, or other solutions used with this machine. Leaking ink may adhere to the skin or get
into your eyes or mouth.
• Avoid touching the print nozzle surface. Do not allow water or alcohol to come into contact with
the print nozzle surface. Contact with water or alcohol may lead to failure or print defects (e.g.,
nozzle clogging, deflection).
• Avoid using cotton swabs to clean around the head or carriage. Fibers from cotton swabs may
adhere to the head nozzle surface and lead to print defects (e.g., nozzle clogging, deflection).
• Be careful to avoid splashing ink or washing liquid on the covers. Exposure to splashing ink or
washing liquid may damage or deform the cover.
• Avoid using chemical products containing benzine, thinner, or abrasives. Use of these
chemicals may result in damage to or deformation of parts.
• Do not move the carriage by hand. To move the carriage, use the carriage out function on the
menu.

2. Daily Maintenance
5
2. Daily Maintenance
Maintenance Items and Timing
Timing Item
Before starting the
week's work
Perform white ink maintenance. "White Ink Maintenance"(P. 6)
At the end of the
work week
Clean the wiper and wiper bracket. "Wiper Cleaning"(P. 7)
Clean the cap rubber. "Cap Cleaning"(P. 8)
Clean the NCU. "NCU Cleaning"(P. 9)
Clean the underside of the UV-LED lamp. "Carriage Underside
Cleaning"(P. 10)
Clean the underside of the carriage. "Carriage Underside Cleaning"(P. 10)
Clean the media sensor. "Media Sensor Cleaning"(P. 13)
Clean the DAS sensor. "Automatic Correction Sensor (DAS) Cleaning"(P. 14)
Clean the media holder. "Media Holder Cleaning"(P. 15)
Clean the ink discharge channel. "Ink Discharge Channel Cleaning"(P. 13)
Clean the platen. "Platen Cleaning"(P. 15)
Clean the cover (exterior). "Cover (Exterior) Cleaning"(P. 16)
Check the waste ink levels in the waste ink tank.
When not used for
more than a week
Clean the wiper and cap and wash the ink discharge channels. After cleaning, store
without turning off the main power supply. "When Not in Use for Extended
Periods"(P. 16)
Periodically Shake the Ink bottle. "Ink Maintenance"(P. 6)
Items Required for Maintenance
To order replacement consumable items, contact your local dealer or our service office.
Item Code
F-200/LF-200 Washing Liquid Kit SPC-0569
F-200/LF-200 Washing Liquid SPC-0568
UJ Cleaning Swab SPC-0386
Cleaning Stick for Head Surrounding SPC-0527
Nozzle Swab SPC-0421
Swab 6-axis "S" A101438
Paper towel (KIM TOWEL) SPC-0499
KIMWIPE S-200 SPA-0207
Maintenance cloth SPC-0574
UV goggles SPC-0387
Safety glasses
Gloves

2. Daily Maintenance
6
For more information on other consumable items, refer to our website.
https://mimaki.com/supply/inkjet.html
• Do not store in places accessible to children.
Ink Maintenance
If ink constituents are sedimented, the ink density may become uneven. We recommend shaking the Ink
bottle periodically to keep printing consistent.
UV ink: once a month.
White ink: once a day.
lWhite Ink
This product counts the time elapsed after stirring the white ink Ink bottle. The “Shake White Ink Bottle”
message appears when a preset count is reached. If the message appears, shake the Ink bottle by following
the instructions below:
• Timing when the message appears
– Every 24 hours (or when the power is turned on if the power was turned off).
lShaking the Ink bottle
1Shake the Ink bottle to the left and right slowly at least 20 times.
• Tighten the ink bottle lid securely, then shake the bottle slowly from left to right to ensure that the
ink moves inside, holding the ink bottle lid with a paper towel.
Repeat the procedure.
• Shake slowly. If the bottle is shaken too violently, ink may leak out or the air mixed in the
ink may cause nozzle clogging.
• If the Ink bottle is partially used, flip the Ink bottle upright and shake slowly at an angle.
White Ink Maintenance
White ink constituents are more easily sedimented than other ink colors. If ink constituents are sedimented,
the ink density may become uneven. Perform maintenance once a week as follows before using the
machine.
1Shake the white ink Ink bottle.
• "Ink Maintenance"(P. 6)
2Close the front cover.
• Be sure to close the front cover. Ink stirring starts.

2. Daily Maintenance
7
3In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
4Select [White Maintenance], then press the [ENTER] key.
5Remove the media, then press the [ENTER] key.
6Press the [ENTER] key.
• Discharging/filling/cleaning starts automatically.
• The elapsed time is displayed.
Wiper Cleaning
The wiper wipes off ink adhering to the print head nozzle surface. Continuing to use the dirty wiper may
cause the wiper to which dried ink and dust are attached to rub against the nozzle surface, leading to print
defects (e.g., nozzle clogging, deflection).
• Be careful to avoid leaving fragments from the cleaning stick behind when cleaning. These
fragments will increase the risk of print defects (e.g., nozzle clogging, deflection).
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [Carriage Out] > [Move To Platen Right End ], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
4Pull out the wiper.
• Hold the lug at the rear of the wiper, then tilt forward to pull out the wiper.
Lug

2. Daily Maintenance
8
5Clean the wiper and bracket.
• Wipe off any ink adhering to the wiper and bracket using a cleaning stick moistened with washing
liquid.
• Wipe off the washing liquid. Make sure none remains.
Wiper
Bracket
• Replace dirty or warped wipers with new ones.
"Wiper Replacement"(P. 19)
6Reattach the wiper at the original position.
Lug
• Do not remove the absorbent material in the absorbent material case. Doing so may result
in leaking ink.
7Once cleaning is complete, close the front cover, then press the [ENTER] key.
Cap Cleaning
The cap prevents the print head nozzle surface from drying out. Continuing to use a dirty cap may affect ink
take-up and lead to print defects (e.g., nozzle clogging, deflection).
• Be careful to avoid leaving fragments from the cleaning stick behind when cleaning. These
fragments will increase the risk of print defects (e.g., nozzle clogging, deflection).
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.

2. Daily Maintenance
9
2Select [Station] > [Carriage Out] > [Move To Platen Right End ], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
4Clean the cap rubber.
• Wipe off any ink adhering to the cap rubber using a cleaning stick moistened with washing liquid.
• Wipe off the washing liquid. Make sure none remains.
Cap rubber
5Check to confirm that the cap slider is not tilted once cleaning is complete.
• If the cap slider is tilted, move the slider block to the left or right to correct the tilt.
6Once cleaning is complete, close the front cover, then press the [ENTER] key.
NCU Cleaning
The NCU uses a sensor to monitor the ink droplets ejected from the print head nozzles. Continuing to use
the dirty NCU may prevent the nozzle recovery function from operating correctly.
• Be careful to avoid leaving fragments from the cleaning stick behind when cleaning. These
fragments will increase the risk of print defects (e.g., nozzle clogging, deflection).

2. Daily Maintenance
10
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [Carriage Out] > [Move To Platen Right End ], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
4Wipe away any ink or dust adhering to the NCU.
• Wipe off any ink adhering to the NCU using a cleaning stick moistened with washing liquid.
• Wipe off the washing liquid. Make sure none remains.
• Insert the cleaning stick as far as the line shown in the figure.
Insert to this line
5Once cleaning is complete, close the front cover, then press the [ENTER] key.
Carriage Underside Cleaning
The underside of the carriage becomes coated with ink wiped off by the wiper. Continuing to use the dirty
carriage underside will rub dried ink and attached dust on to the media, resulting in contaminated prints.
The print head uses an extremely delicate mechanism. Take great care when handling it.
• Be careful to avoid leaving fragments from the cleaning stick behind when cleaning. These
fragments will increase the risk of print defects (e.g., nozzle clogging, deflection).
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.

2. Daily Maintenance
11
2Select [Station] > [Carriage Out] > [Move To Maint. Space], then press the [ENTER] key.
• The carriage moves to the maintenance space.
3Open the maintenance covers.
4Clean the underside of the UV-LED lamp.
• Wipe off any ink adhering to the UV-LED lamp underside using a cleaning stick moistened with
washing liquid.
• Wipe off the washing liquid. Make sure none remains.
5Clean around the print head on the underside of the carriage.
• Wipe off any ink adhering to the carriage underside using a cleaning stick moistened with washing
liquid.
• Wipe off the washing liquid. Make sure none remains.
Clean the print head sides (dark red area)
using a cleaning stick.
Never touch the nozzle
surface!
Clean using a cleaning stick or soft cloth.
• Never touch the print head nozzle surface.
6Once cleaning is complete, close the maintenance covers, then press the [ENTER] key.

2. Daily Maintenance
12
Print Head Nozzle Washing
If print defects (e.g., nozzle clogging, deflection) remain unresolved even after head cleaning (Head
Cleaning), apply nozzle washing to the print head.
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [Nozzle Wash], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
4Clean the wiper and bracket.
"Wiper Cleaning"(P. 7)
5Press the [ENTER] key once cleaning is complete.
• “Cap Cleaning Completed (Next)[ENT]” appears on the display.
6Clean the cap rubber.
"Cap Cleaning"(P. 8)
7Press the [ENTER] key once cleaning is complete.
• “Fill the Liquid. Exit Next [ENT]” appears on the display.
8Fill the cap with washing liquid.
• Use a syringe to draw up some washing liquid and fill until it almost overflows from the cap.
9Close the front cover, then press the [ENTER] key.
• Print nozzle washing starts. The elapsed time is displayed on the display. Nozzle washing takes
approximately one minute.
• Cleaning is performed automatically once print nozzle washing has ended.
• If print defects (e.g., nozzle clogging, deflection) remain unresolved even after washing
the nozzles several times, contact your local dealer or our service office.

2. Daily Maintenance
13
Ink Discharge Channel Cleaning
Clean the ink discharge channel regularly to prevent clogging of the ink discharge channel below the cap.
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [DISWAY WASH], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
4Fill the cap with washing liquid.
• Use a syringe to draw up some washing liquid and fill until it almost overflows from the cap.
5Close the front cover, then press the [ENTER] key.
• Pump tube (ink discharge channel below the cap) washing starts.
Media Sensor Cleaning
Media sensors are located on the rear cover and carriage underside. The media cannot be detected
correctly if dust or debris accumulates on the sensors. Remove any debris using cotton swabs or a soft cloth.
Rear of product Carriage underside

2. Daily Maintenance
14
lCleaning the carriage underside sensor
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [Carriage Out] > [Move To Maint. Space], then press the [ENTER] key.
• The carriage moves to the maintenance space.
3Open the maintenance covers.
4Clean the media sensor.
5Once cleaning is complete, close the maintenance covers, then press the [ENTER] key.
Automatic Correction Sensor (DAS) Cleaning
The DAS sensor is located on the carriage underside. If dust or debris accumulates on the sensor, an error
may occur in the automatic correction function (Automatic correction of dot landing position). Remove any
debris using cotton swabs or a soft cloth.
1In LOCAL mode, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [Carriage Out] > [Move To Maint. Space], then press the [ENTER] key.
• The carriage moves to the maintenance space.
3Open the maintenance covers.

2. Daily Maintenance
15
4Clean the DAS sensor.
5Once cleaning is complete, close the maintenance covers, then press the [ENTER] key.
Media Holder Cleaning
• Turn off the main power and unplug the power cable before carrying out maintenance.
Continuing to use the dirty platen will prevent proper feeding of the media. It will also cause dried ink and
attached dust to rub against the head nozzle surface and lead to print defects (e.g., nozzle clogging,
deflection).
Media holder
• Do not allow liquids to get inside the product. Ingress of liquids into the product may lead to
failure, electric shock, or fire.
• For heavy soiling, wipe using a soft cloth soaked in dilute detergent and thoroughly wrung out.
Platen Cleaning
• Turn off the main power and unplug the power cable before carrying out maintenance.

2. Daily Maintenance
16
Continuing to use the dirty platen will prevent proper feeding of the media. It will also cause dried ink and
attached dust to rub against the head nozzle surface and lead to print defects (e.g., nozzle clogging,
deflection).
• Do not allow liquids to get inside the product. Ingress of liquids into the product may lead to
failure, electric shock, or fire.
• For heavy soiling, wipe using a soft cloth soaked in dilute detergent and thoroughly wrung out.
• The grooves in which the media holder slides and the media is cut are especially susceptible to
dust accumulation. Remove any debris carefully.
Cover (Exterior) Cleaning
• Do not allow liquids to get inside the product. Ingress of liquids into the product may lead to
failure, electric shock, or fire.
• For heavy soiling, wipe using a soft cloth soaked in dilute detergent and thoroughly wrung out.
When Not in Use for Extended Periods
Clean as follows if the product is not used for one week or longer:
Check beforehand
Is [NEAR END] or [INK END] displayed?
• Washing liquid and ink is aspirated during the washing operation. Washing is not possible if an error
occurs during this process. Replace with new ink.
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.

2. Daily Maintenance
17
2Select [Station] > [Custody Wash], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
4Clean the wiper and bracket.
"Wiper Cleaning"(P. 7)
5Press the [ENTER] key once cleaning is complete.
• “Cap Cleaning Completed (Next)[ENT]” appears on the display.
6Clean the cap rubber.
"Cap Cleaning"(P. 8)
7Press the [ENTER] key once cleaning is complete.
• “Fill the Liquid. Exit Next [ENT]" appears on the display.
8Fill the cap with washing liquid.
• Use a syringe to draw up some washing liquid and fill until it almost overflows from the cap.
9Close the front cover, then press the [ENTER] key.
• Print nozzle washing starts. The elapsed time is displayed on the display. Nozzle washing takes
approximately one minute.
• Cleaning is performed automatically once print nozzle washing has ended.
• “Fill the Liquid. Exit Next [ENT]” appears on the display when print nozzle washing is complete.

2. Daily Maintenance
18
10 Fill the cap with washing liquid.
• Use a syringe to draw up some washing liquid and fill until it almost overflows from the cap.
11 Close the front cover, then press the [ENTER] key.
• Pump tube (ink discharge channel below the cap) washing starts.
• Do not turn off the main power supply. Turning off the main power supply will disable the
automatic maintenance function (including nozzle clogging prevention function and ink
discharge channel cleaning function) and may result in printing defects (such as nozzle clogging
and deflection) or other faults.
• Do not leave media loaded on the platen. This may leave irregularities or ripples in the media.
• When this product is not in use, raise the clamp lever to separate the pinch rollers from the grid
rollers. If the pinch rollers are left in the lowered position for an extended period of time, they
may become deformed, possibly preventing the media from being fed correctly.
• Perform the following if the “Check Waste Ink Tank” message appears on the display.
"Waste Ink Tank Replacement"(P. 23)

3. Consumable Item Replacement
19
3. Consumable Item Replacement
To order replacement consumable items, contact your local dealer or our service office.
For more information on consumable items, refer to our website.
https://mimaki.com/supply/inkjet.html
• When disposing of the product, contact an industrial waste disposal operator or dispose of the
product in accordance with the local laws and regulations.
• Do not store in places accessible to children.
Wiper Replacement
This product maintains a count of the number of wiping cycles. The “Replace Wiper” message appears when
a preset count is reached. Replace dirty or warped wipers with new ones.
1“Replace Wiper” appears on the display.
2In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
3Select [Station] > [Replace Wiper], then press the [ENTER] key.
• The carriage moves over the platen.
4Open the front cover.
5Pull out the wiper.
• Hold the lug at the rear of the wiper, then tilt forward to pull out the wiper.
Lug

3. Consumable Item Replacement
20
6Insert a new wiper.
Lug
7Once replacement is complete, close the front cover, then press the [ENTER] key.
• The wiper usage count is reset.
Cap Replacement
If print defects (e.g., nozzle clogging, deflection) remain unresolved even after cleaning, replace with a new
cap.
• Be sure to replace the cap if you observe any scratches or other damage on the rim.
1In LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2Select [Station] > [Carriage Out] > [Move To Platen Right End ], then press the [ENTER] key.
• The carriage moves over the platen.
3Open the front cover.
