Minarik MMRG30U User manual

MMRG30U
MMRG30U-PCM
MMRG31U
MMRG31U-PCM
MMRG40U
MMRG40U-PCM
USER MANUAL
www.minarikdrives.com
MMRG SERIES

Dear Valued Consumer:
Congratulaons on your purchase of the MMRG Series drive.
This User Manual was created for you to get the most out of
your new device and assist with the inial setup. Please visit
www.minarikdrives.com to learn more about our other drives.
Thank you for choosing Minarik Drives!
© 2014 Minarik Drives. All rights reserved.
No part of this document may be reproduced or transmied in any form without wrien permission
from Minarik Drives. The informaon and technical data in this document are subject to change
without noce. Minarik Drives makes no warranty of any kind with respect to this material,
including, but not limited to, the implied warranes of its merchantability and tness for a given
purpose. Minarik Drives assumes no responsibility for any errors that may appear in this document
and makes no commitment to update or to keep current the informaon in this document.

i
MMRG Series
Safety First!
• DO NOT INSTALL, REMOVE, OR REWIRE THIS EQUIPMENT WITH
POWER APPLIED. Have a qualified electrical technician install, adjust
and service this equipment. Follow the National Electrical Code
and all other applicable electrical and safety codes, including the
provisions of the Occupational Safety and Health Act (OSHA), when
installing equipment.
• Reduce the chance of an electrical fire, shock, or explosion by using
proper grounding techniques, over-current protection, thermal
protection, and enclosure. Follow sound maintenance procedures.
SAFETY WARNINGS
Text in gray boxes denote important safety ps or warnings.
Please read these instrucons carefully before performing any of
the procedures contained in this manual.
It is possible for a drive to run at full speed as a result of a
component failure. Minarik Drives strongly recommends the
installaon of a master switch in the main power input to stop
the drive in an emergency.
Circuit potenals are at 115 VAC or 230 VAC above earth ground.
Avoid direct contact with the printed circuit board or with circuit
elements to prevent the risk of serious injury or fatality. Use a
non-metallic screwdriver for adjusng the calibraon trim pots.
Use approved personal protecve equipment and insulated tools
if working on this drive with power applied.

!
WARNING!

!
WARNING!

ii
MMRG Series
Table of Contents
Section 1. Regenerative Drives ............................................ 1
Section 2. Specifications ..................................................... 2
Section 3. Dimensions......................................................... 3
Section 4. Installation......................................................... 6
Heat Sinking ................................................................................. 6
Mounting ..................................................................................... 7
Speed Adjust Potentiometer.................................................. 8
Wiring .......................................................................................... 9
Shielding Guidelines.............................................................10
Line Fusing ..........................................................................11
Connections.................................................................................12
Power Inputs .......................................................................12
Motor..................................................................................12
Speed Adjust Potentiometer.................................................14
Analog Input Signal (MMRG models).....................................15
Analog Input Signal (MMRG-PCM models).............................16
+15 and -15 .........................................................................17
Direction Switch (MMRG-PCM models) .................................17
Section 5. Operation......................................................... 18
Before Applying Power .................................................................18
Select Switches............................................................................19
Line Frequency Select (SW501).............................................19
Startup ........................................................................................20
Starting and Stopping Methods ....................................................21
Line Starting and Stopping ...................................................21
Regenerative Brake to Zero Speed.........................................22
Regenerative Decel to Zero Speed.........................................23
Section 6. Calibration ....................................................... 24
Maximum Speed (MAX SPD) .........................................................25
Acceleration and Deceleration (ACC-DEC)......................................25

iii
MMRG Series
Forward Torque (FORWARD TORQUE)............................................26
Reverse Torque (REVERSE TORQUE)...............................................27
Deadband....................................................................................27
IR Compensation (IR COMP) .........................................................28
Section 7.Application Notes ............................................... 30
Direction Switch ..........................................................................30
Multiple Fixed Speeds ..................................................................31
Adjustable Speeds Using Potentiometers In Series.........................32
Independent Adjustable Speeds....................................................33
Independent Adjustable Forward and Reverse Speeds ...................34
RUN/JOG Switch - Inhibit Connection............................................35
RUN/JOG Switch - Potentiometer Connection................................36
Leader-Follower Application .........................................................37
Single Speed Potentiometer Control Of Multiple Drives .................38
Section 8. Troubleshooting................................................ 39
Before Troubleshooting ................................................................39
Section 9. Accessories & Replacement Parts ....................... 42
Notes ............................................................................... 43
Unconditional Warranty..................................................... 44

iv
MMRG Series
List of Tables
Table 1 Recommended Line Fuse Sizes ..........................................11

v
MMRG Series
List of Figures
Figure 1 Four Quadrant Operation .................................................. 1
Figure 2 MMRG Dimensions............................................................ 3
Figure 3 MMRG-PCM Dimensions.................................................... 4
Figure 4 223-0159 Dimensions........................................................ 5
Figure 5 Speed Adjust Potentiometer .............................................. 8
Figure 6 Power and Motor Connections..........................................13
Figure 7 Speed Adjust Potentiometer Connections..........................14
Figure 8 MMRG Analog Input Signal Connections............................15
Figure 9 MMRG-PCM Analog Input Signal Connections....................16
Figure 10 +15 and -15 Terminal Locations.........................................17
Figure 11 Line Frequency Switch Location ........................................19
Figure 12 Inhibit Terminal Location..................................................22
Figure 13 Run/Stop Switch...............................................................23
Figure 14 Recommended FORWARD TORQUE, REVERSE TORQUE, and
IR COMP Setting...............................................................29
Figure 15 Forward-Reverse Switch ...................................................30
Figure 16 Forward-Stop-Reverse Switch ...........................................30
Figure 17 Multiple Fixed Speeds ......................................................31
Figure 18 Adjustable Speeds Using Potentiometers in Series .............32
Figure 19 Independent Adjustable Speeds........................................33
Figure 20 Independent Adjustable Forward and Reverse Speeds........34
Figure 21 Independent Adjustable Forward and Reverse Speeds with
Stop ................................................................................34
Figure 22 RUN/JOG Switch - Inhibit Connection ...............................35
Figure 23 RUN/JOG Switch - Speed Adjust Potentiometer Connection. 36
Figure 24 Leader-Follower Application .............................................37
Figure 25 Single Speed Potentiometer Control of Multiple Drives......38

1
MMRG Series
Most non-regenerave,
variable speed, DC drives
control current ow to a
motor in one direcon.
The direcon of current
ow is the same direcon
as the motor rotaon.
Non-regenerave drives
operate in Quadrant I,
and also in Quadrant III if
the drive is reversible (see
Figure 1). Motors must stop
before reversing direcon.
Unless dynamic braking
is used, non regenerave
drives cannot decelerate a
load faster than coasng to a
lower speed.
Regenerative drives operate
in two addional quadrants:
Quadrant II and Quadrant
IV. In these quadrants,
motor torque is in the
opposite direcon of motor rotaon.
This allows regenerave drives to reverse a motor without contractors
or switches, to control an overhauling load, and to decelerate a load
faster than it would to coast to a lower speed.
Section 1. Regenerative Drives
ARROWS IN OPPOSITE DIRECTION = REGENERATIVE ACTION
NOTE: ARROWS IN SAME DIRECTION = MOTOR ACTION
MOTOR
TORQUE
ROTATION
MOTOR
Quadrant III
Quadrant II
Quadrant IV
Quadrant I
Figure 1. Four Quadrant Operaon

2
MMRG Series
Section 2. Specifications
Model
Maximum
Armature
Current (ADC)
Armature
Voltage
Range (VDC)
Maximum
Armature
Current (ADC) HP Range
MMRG31U
MMRG31U-PCM
115 0 - 90 3.0 1/20 - 1/4
MMRG30U
MMRG30U-PCM
115 0 - 90 10.0 1/8 - 1
MMRG40U
MMRG40U-PCM
230 0 -180 10.0 1/4 - 2
AC Line Voltage 115 or 230 VAC ± 10%, 50/60 Hz, single phase
Acceleraon & Deceleraon Time Range 0.5 - 6 seconds
Analog Input Range
0 to ± 10 VDC
0 to ± 10 VDC
Input Impedance (S0 to S2) 30K ohms
Form Factor 1.37 at base speed
Load Regulaon 1% base speed or beer
Speed Range 60:1
Vibraon 0.5G maximum (0 - 50 Hz)
0.1G maximum (> 50 Hz)
Ambient Temperature Range 10° - 55° C
* Heat sink kit part number 223-0159 must be used when the connuous
current output is over 5 amps.
MMRG models (signal must be isolated; S0 to S2)
MMRG-PCM models (NEG to POS)

3
MMRG Series
Section 3. Dimensions
Figure 2. MMRG Dimensions
ALL DIMENSIONS IN INCHES [MILLIMETERS]
C503 MMRG
C506
PL1
C507
C508
60HZ
C501
PL2
S1
S2
C509
S0
C510
C505
50HZ
-15V T501+15V
C512
S3
C511
INHIBIT
P505P504P503
SO501
TORQUE
FORWARDIR COMP
TORQUE
REVERSE
P502P501
MAX
SPD
ACC-DEC
SW501
C513
C502
DC VOLTAGEDC VOLTAGE
COMMON
DC VOLTAGE
DC VOLTAGE
3.80 [97]
0.96 [24]
1.50 [38]
2.87 [73]
1.75 [44]
0.99 [25]
3.72 [94]
4.30 [109]
4.42 [112]

4
MMRG Series
Figure 3. MMRG-PCM Dimensions
ALL DIMENSIONS IN INCHES [MILLIMETERS]
ACC-DEC
SPD
MAX
P501 P502
REVERSE
TORQUE
IR COMP
P503 P504
FORWARD
TORQUE
INHIBIT
P505
SO501
S3 S0
COMMON
0.99 [25]
1.75 [44]3.72 [94]
0.96 [24]
3.375 [86]
4.30 [109]
4.42 [112]
3.80 [97]
FWD SIG ADJ
DIR NEGCOM POS
REV SIG ADJ
DIR
COM
POS
NEG
TB501
T502 T501

5
MMRG Series
5.90
[
150
]
6.30
[
160
]
6.90
[
175
]
4.40 [112]
3.00 [76]
3.90 [100]
1.75 [44]
0.7 [18]
1.00 [26]
0.125 [3]
Figure 4. 223-0159 Dimensions
ALL DIMENSIONS IN INCHES [MILLIMETERS]

6
MMRG Series
Section 4. Installation
Do not install, rewire, or remove this control with input power
applied. Failure to heed this warning may result in re, explosion,
or serious injury. Make sure you read and understand the Safety
Precauons on page i before aempng to install this product.

!
WARNING!
Models MMRG30U, MMRG30U-PCM, MMRG40U, and MMRG40U-PCM
require an addional heat sink when the connuous armature current
is above 5 amps. Use Minarik Drives heat sink kit part number 223-
0159. All other chassis drives have sucient heat sinking in their basic
conguraon. Use a thermally conducve heat sink compound (such as
Dow Corning® 340 Heat Sink Compound) between the chassis and the
heat sink surface for opmum heat transfer.
Heat Sinking

7
MMRG Series
• Drive components are sensitive to electrostatic discharge. Avoid
direct contact with the circuit board. Hold the drive by the heat sink
only.
• Protect the drive from dirt, moisture, and accidental contact.
• Provide sufficient room for access to the terminals and calibration
trim pots.
• Mount the drive away from heat sources. Operate the drive within
the specified ambient operating temperature range.
• Prevent loose connections by avoiding excessive vibration of the
drive.
• Mount the drive with its board in either a horizontal or vertical
plane. Eight 0.19” (5 mm) wide slots in the chassis accept #8 pan
head screws. Fasten either the large base or the narrow flange of the
chassis to the subplate.
• The chassis should be earth grounded. Use a star washer beneath
the head of at least one of the mounting screws to penetrate the
anodized surface and to reach bare metal.
Mounng

8
MMRG Series
POT TAB ASSIGNMENTS
WIPER
CW
CCW
SPEED ADJUST
POTENTIOMETER
INSULATING DISK
PANEL
STAR
WASHER
NUT
MOUNT THROUGH A 0.38 IN. (10 MM) HOLE
Figure 5. Speed Adjust Potenometer
If using a remote potenometer with a chassis drive, mount the speed
adjust potenometer through a 0.38 in. (10 mm) hole with the hardware
provided (Figure 5). Install the circular insulang disk between the panel
and the 10K ohm speed adjust potenometer.
Twist the speed adjust potenometer wire to avoid picking up unwanted
electrical noise. If the speed adjust potenometer wires are longer than
18 in. (46 cm), use shielded cable. Keep the speed adjust potenometer
wires separate from power leads (L1, L2, A1, A2).
Speed Adjust Potenometer
Be sure that the potenometer tabs do not make contact with the
potenometer’s body. Grounding the input will cause damage to
the drive.

!
WARNING!

9
MMRG Series
• Use 18 - 24 AWG wire for logic wiring. Use 14 - 16 AWG wire for
AC line and motor wiring.
Wiring
Do not install, rewire, or remove this control with input power
applied. Failure to heed this warning may result in re, explosion,
or serious injury.
Circuit potenals are at 115 or 230 VAC above ground. To prevent
the risk of injury or fatality, avoid direct contact with the printed
circuit board or with circuit elements.
Do not disconnect any of the motor leads from the drive unless
power is removed or the drive is disabled. Opening any one
motor lead while the drive is running may destroy the drive.
This product does not have internal solid state motor overload
protecon. It does not contain speed-sensive overload
protecon, thermal memory retenon or provisions to receive
and act upon signal from remote devices for over temperature
protecon. If motor over protecon is needed in the end-use
product, it needs to be provided by addional equipment in
accordance with NEC standards.

!
WARNING!

10
MMRG Series
Shielding Guidelines
As a general rule, Minarik Drives recommends shielding of all conductors.
If it is not praccal to shield power conductors, it is recommended
to shield all logic-level leads. If shielding of all logic-level leads is not
praccal, the user should twist all logic leads with themselves to
minimize induced noise.
It may be necessary to earth ground the shielded cable. If noise is
produced by devices other than the drive, ground the shield at the drive
end. If noise is generated by a device on the drive, ground the shield at
the end away from the drive. Do not ground both ends of the shield.
If the drive connues to pick up noise aer grounding the shield, it may
be necessary to add AC line ltering devices, or to mount the drive in a
less noisy environment.
Logic wires from other input devices, such as moon controllers and PLL
velocity controllers, must be separated from power lines in the same
manner as the logic I/O on this drive.
Under no circumstances should power and logic level leads be
bundled together. Induced voltage can cause unpredictable
behavior in any electronic device, including motor controls.

!
WARNING!

11
MMRG Series
Chassis drives should be fused for protecon. Use fast acng fuses rated
for 250 VAC or higher and 150% of maximum armature current. Fuse HOT
L1 only when the line voltage is 115 VAC. Fuse both L1 and L2 when the
line fuse is 230 VAC. Table 1 lists the recommended fuse sizes.
Line Fusing
90 VDC
Motor
Horsepower
180 VDC
Motor
Horsepower
Maximum DC
Armature Current
(amps)
AC Line
Fuse Size
(amps)
1/20
1/15
1/8
1/6
1/10
1/8
1/4
1/3
0.5
0.8
1.5
1.7
1
1.5
3
3
1/4 1/2 2.5 5
1/3
1/2
3/4
1
3/4
1

2
3.5
5.0
7.5
10
8
10
15
15
Minarik Drives oers fuse kits. See Secon 9: Accessories and
Replacement Parts for fuse kit part numbers.
Table 1. Recommended Line Fuse Sizes

12
MMRG Series
Connecons
Do not connect this equipment with power applied. Failure to
heed this warning may result in re, explosion, or serious injury.
Minarik Drives strongly recommends the installaon of a
master power switch in the voltage input line, as shown in
Figure 6 (page 13). The switch contacts should be rated at a
minimum of 200% of motor nameplate current and 250 volts.

!
WARNING!
Power Input
Connect the AC line power leads to terminals L1 and L2. Minarik Drives
recommends the use of a single-throw, double-pole master power
switch. The switch should be rated at a minimum of 250 volts and 200%
of motor current. Refer to Figure 6 on page 13.
Motor
Drives supply motor armature voltage from A1 and A2 terminals. It is
assumed throughout this manual that, when A1 is posive with respect
to A2, the motor will rotate clockwise (CW) while looking at the output
sha protruding from the front of the motor. If the motor does not
spin in the desired direcon, remove power and reverse the A1 and A2
connecons.
Connect a DC motor to terminals A1 and A2 as shown in Figure 6 on page
13. Ensure that the motor voltage rang is consistent with the drive’s
output voltage.

13
MMRG Series
FU501
SCR504
SO501
C506
R502
C507
R501
A1
R503
C508
SCR505
A2
SO502
SCR503 SCR502 SCR501
C501
T504
C503
MOV501
C504L1SO503GND
C502
T501
SCR506 SCR507 SCR508
C505
MMRG
SO504L2
T502
T503
AC VOLTAGEAC VOLTAGE
DC VOLTAGE
DC VOLTAGE
EARTH GND
FUSE
*FUSE
EARTH
GROUND
115 VAC
MMRG30U, MMRG30U-PCM
MMRG31U, MMRG31U-PCM
OR
230 VAC
MMRG40U, MMRG40U-PCM
90 VDC MOTOR
MMRG30U, MMRG30U-PCM
MMRG31U, MMRG31U-PCM
OR
180 VDC MOTOR
MMRG40U
*Add fuse to L2 with 230 VAC input only.
MOTOR
Master
Power Switch
Figure 6. Power and Motor Connecons
