Minerva 3393 User manual

Tools required:
Components (Label - Description)
**Open all drawers and
boxes to check for
parts before
beginning assembly.
Qty. SketchPart
K
J
I
H
F
E
D
20
10
4
24
16
4
4
Description
Short Allen bolts
Medium Allen bolts
Long Allen bolts
Single-sided Genesis Styling Station
Model #3393
Assembly Instructions
Handle screws
Handles
Washers
Short bolt anchors
5Appliance rings
L
Flat-top Allen bolts
8
G
1 - Base
2 - Bottom cabinet section
3 - Top cabinet section
4 - Mirror panel
5 - Rear panel
PARTS LIST**
Large Allen wrench (included)
Small Allen wrench (Included)
Phillips-head screwdriver (Not included)

1
3
2
3) Turn wrench to tighten
2) Insert bolt into
anchor
1) Insert and
hold steady
1) Remove all the drawers from the top cabinet section (3) by pressing the black release tabs in the
glides (one up, one down) and pulling. Lay drawers out in proper order for replacement.
2) Set the top cabinet section (3) on top of the bottom cabinet section (2), aligning the 4 small holes
in each.
3) Drop the 4 short bolt anchors (I) into the holes in the bottom of the top cabinet section (3) and
secure by screwing in the 4 short Allen bolts (D) with washers (H) upward through both cabinet
sections into the anchors. Use the small Allen wrench to hold the anchors in place while
tightening the bolts (see magnification).
I
I
D
H
I
D
H
D
D
I
H
H
E
H
H
E
HH
E
E
1) Remove all the drawers from the bottom cabinet
section (2) by pressing the black release tabs in
the glides (one up, one down) and pulling.
Lay drawers out in proper order for replacement.
2) Set the bottom cabinet section (2) on top of the
base (1), aligning the 4 small holes in each.
3) Secure the bottom cabinet section (2) to the
base (1) using the 4 medium Allen bolts (E)
and 4 washers (H) as shown.
Hx4
Dx4
Ix4
2- Mounting the top cabinet section
1
2
x4
H
x4
E
1- Mounting bottom cabinet section

1) For shipping, the drawer handles (J) are attached to the insides of the drawer faces. Using a
Phillips-head screwdriver, remove the 2 screws (K) in each and reattach the handles on the
front of the drawers.
2) Drop the metal appliance rings (L) into the holes in the appliance drawer.
3) Slide the drawers back into their respective glides.
L
L
L
L
L
J
K
K
K
K
J
G
G
F
G
F
G
G
G
F
F
F
F
FG
F
G
G
G
FF
F
G
F
G
G
FG
F
H
H
H
H
H
H
HH
F
G
G
F
2
3
1
L
J
Kx20
x10
x5
5 - Replacing the drawers
5
4
x16
G
x16
F
Hx8
1) Rotate the mirror panel (4) such that the holes in the back of the panel are aligned with the holes
in the front faces of the bottom and top cabinet sections (2, 3).
2) Anchor the mirror panel to the cabinets by using the long Allen bolts (F) and washers (H) in the
bottom 4 sets of holes and the flat-top Allen bolts (G) without washers in the top 2 sets of holes.
3) Repeat steps 1 and 2 for the back panel (5), using the same configuration of bolts and washers.
4 - Mounting the mirror and back panels
