Minib NU1 User manual

CONTROL,ACCESSORIES,
INSTALLATION MANUALS

ABOUT US
ABOUT THE COMPANY
MINIB,a.s. is a Czech business through and through, and it ranks
among the leading manufacturers of convectors in the Czech Repub-
lic. It currently exports to thirty countries in Europe, Asia, Australia,
and America.
Since 1999, MINIB has been systematically innovating its producti-
on technology and its products and has invested considerable sums
in proprietary development and design, with the goal of offering our
customers solutions that are mature both from the technical and es-
thetic points of view.
MINIB's business is economically soand and the company consis-
tently turns a profit. This allows us to invest in R&D, technology, and
above all, human capital, so as to ensure our long-term prosperity.
ABOUT THE MANUFACTURING PROCESS
The manufacturing facility is located in Býkev near Mělník and has
excellent transport connections. It is furnished with state-of-the-art
production technology. Most manufacturing operations are carried
out on CNC machines, which allows us to accommodate even the
most sophisticated wishes of our exacting customers.
In response to individual calls for customization, we are able to crea-
te a wide variety of non-standard, one-of-a-kind products that satisfy
specific needs.
All products are made from high-grade material with a useful life of
many years, which is why we offer a 10-year warranty on heat ex-
changers and our stainless-steel convector vats.
MINIB holds an ISO 9001:2008 certificate in addition to numerous uti-
lity models and patents.
The entire range of products is submitted to testing in the indepen-
dent, accredited test chamber of HEATEST, s.r.o. pursuant to the Eu-
ropean Standard EN 442-2, which is why we are able to guarantee the
advertised heating and cooling output.
ABOUT THE PRODUCTS
MINIB's production portfolio consists of over 70 convector types.
Customers can thus choose the right convector for any interior.
The main advantage of convectors is that they are efficient, modern,
economical, and esthetic heaters suitable for both dry and humid
environments. Significant power savings are achieved thanks to
low water requirements for the immediate heating or cooling of a gi-
ven area. This leads to low consumption of electricity required for
its heating. In addition to water and energy savings, a great heating
and cooling dynamics is also important. The space saving design is
another important feature of these products. Our convectors do not
disturb interior esthetics, have a modern design, and - last but not
least - are safe thanks to their 12V power supply.
The product range comprises various types of convectors:
FLOOR convectors without fans that work on the natural con-
vection principle. Convectors with fans utilize the principle of
forced convection.
FREE STANDING AND WALL MOUNTED convectors with and
without fans are also available. Heating benches with gra-
nite and wooden top panels are available for humid environ-
ments (swimming pools, bathrooms).
DESIGN convectors are a unique patent series that use both
the convection and heat radiation principle for heating.
These convectors have aluminum composite front panels
available in a number of modern designs from smooth glass
with various colors or from glass with sand blasted deco-
rations. The company also offers granite front panels.
MINIB can satisfy any individual, non-standard requirements of
its customers such as angular or arc-shaped convectors with
various connections and tailor them to their demands. MINIB
emphasizes high user comfort. All products place low demands
on installation and maintenance.
Numerous accessories are available for individual convector types.
MINIB products have won a number of national and foreign awards.

34
1. UNIT DESCRIPTION
These are wall mounted unit types NU1, NU2, NW 170, NW340, NP1, NP2 (based on the natural convection principle) and NK1, NK2, which are
equipped with fans. Since the units fully use the laws of physics in the area of thermodynamics, they represent the most efficient means of
interior heating.
BENEFITS OF WALL MOUNTED CONVECTORS:
high output,
silent operation and very low noise of fan units,
light weight compared to other heating units with similar output using the radiation principle,
low hot water consumption,
short response time,
design,
minimal operation and maintenance requirements,
the small installation space is a great advantage of these units. You will appreciate this, particularly in situations when the units are used
during interior reconstruction and for the replacement of old heating units, even in places where sufficient heating output needs to be main-
tained.
2. PACKAGE CONTENT
Individual positions in the table correspond to Figure No. 1, see following page.
PACKAGE CONTENT Position NK1 NK2 NU1 NU2 NW 170 NW 340 NP1 NP2
Convector
Plastic cover 1 2 2 2 2 2 2 2 2
Grille 2 1 1 1 1 1 1 1 1
Convector body 3 1 1 1 1 1 1 1 1
Load bearing piece 4 11111111
Exchanger 5 11111111
Exchanger holder + screw 6, 7, 8 22222222
Adjustment screw 9 1 1 1 1 1 1 1 1
Fan 17 1-2 1-2 - - - - - -
EB control unit 18 1 1 - - - - - -
O-RING 18X2 19 1 1 1 1 1 1 1 1
Accessories
Heimeier AT 15 V_exakt valve 1011111111
Thermostatic head 1111111111
Screw fitting - straight 12----1111
Screw fitting - angular 121111----
Hose G1/2“ – 65mm 131-- -1111
Hose G1/2“ – 41 mm 13-111----
Sealing KLIGERSIL C4400 1444444444
Dowel No. 10 1522222222
Wood screw 6x50 1622222222
installation manuals - wall mounted convectors

35
3. TECHNICAL PARAMETERS
Figure 1: COMPONENTS OF WALL MOUNTED CONVECTOR
usage: dry or wet premises according to specifications,
maximum operating pressure: 1.0 MPa,
maximum operating temperature: 95 °C,
operating medium: water. The use of other media is prohibited.
Water may not be mixed with other substances, such as non-free-
ze liquids!
environment: interiors with temperatures between +5°C and
+40°C.
1. PLASTIC COVER - intended for grille attachment to the convector
body.
2. CONVECTOR GRILLE - design element protecting the convector
outlet. Must not be covered !!!
3. EXTERNAL CONVECTOR BODY - aluminum body of the convector.
4. CONVECTOR BEARING PIECE - attachment piece of the wall moun-
ted convector and load bearing piece of the convector body.
5. EXCHANGER - copper pipes with pressed-on aluminum fins through
which the heating water flows.
6. FIXED EXCHANGER HOLDER - intended to set the exchanger po-
sition.
7. EXCHANGER HOLDER - intended for exchanger attachment.
8. EXCHANGER HOLDER SCREW - intended for exchanger holder fit-
ting.
9. ADJUSTMENT SCREW - intended for adjustment of horizontal posi-
tion of the convector body.
10. THERMOSTATIC VALVE - intended for flow control.
11. THERMOSTATIC HEAD - intended for manual regulation.
12. SCREW FITTING - a valve that controls / adjusts heating water
flow.
13. HOSE – the bellows hose is a stainless hose intended for fitting
connection to the convector exchanger.
14. SEALING - seals joints between valves, hoses, and exchangers
(KLEGERSIL C4400). MINIB, s.r.o. recommends this sealing as an
optimum sealing solution, as other materials (rubber, NBR, silicon)
do not have sufficient tightness upon sufficient tightening and be-
cause they are deformed by tightening forces.
15. DOWEL - for screw fixing in the wall.
16. WOOD SCREW - fixing of the convector bearing piece
17. O-RING - sealing between heat exchanger and thermostatic valve.
18. EB CONTROL UNIT - fan motor control unit.
19. FAN - intended for forced convection.
wall mounted convectors - installation manuals

36
NK1 NK2 NU1 NU2 NW 170 NW 340 NP1 NP2
A7985909090909090
B L-185 L-185 L-357 L-357 L-357 L-357 L-357 L-357
C 137 163 135 135 135 135 135 135
D50 50 50 50 50 50 50 50
E41 46 41 41 41 41 31 31
F-30 5 -55 -55 0 0 -10 -10
G105 92 90 260 87 257 92 177
H40 50 45 45 35 35 42 128
I3535------
J130 130 - - - - - -
4. BEFORE INSTALLATION
Use the catalogue to choose a suitable convector - see paragraph 4.1.
Select correct convector position and placement - see paragraph 4.2.
4.1 Suitable Convector Type
Decide whether the convector will act as the main source of heat, an
additional heating element or a thermal barrier.
As the main source of heat in your apartment / room, the convector
should sufficiently cover the entire thermal loss of the room. There-
fore, choose a heating unit with a capacity that is higher than the
thermal loss of your apartment, room, or other premises.
All wall mounted convectors are intended for a dry environment. This
means an environment where the average annual humidity does not
exceed 85%. In terms of convector selection, a dry environment is
generally any environment where no precipitation of vapor occurs in
the convector unit.
4.2 Convector Position
A MINIB Wall mounted convector is intended for installation on walls
under windows or window sills. Install the convector approximate-
ly 100 mm under the window frame. Observe the rule according to
which the gap between the floor should be greater than 80 mm. Never
cover the top grille - this will result in flow reduction and in a conside-
rable decrease of the convector's output.
Installation dimensions (mm) for the installation of water pipes, cabling,
and wall mounting
5. INSTALLATION
installation manuals - wall mounted convectors
Figure 2: The recommended distance of the convector from the bottom of the
window (window sill) is 100mm. The minimum distance from the floor must
be 80mm.
Figure 3: 0 – is the top edge of the rear wall mounted side without covers and
grille.
Figure 4: Plan the position of the heating unit. Observe the dimensions speci-
fied in the installation table - see Table 2. Mark the water inlet/outlet, fitting ho-
les for the bearing piece of the convector, and electric connection (as appro-
priate). Observe the principles specified in paragraph 4.2 (convector position).
Figure 5: Drill the mounting holes. Install the pipes and power supply cable as
appropriate.
Figure 6: Insert dowels in holes.

37
wall mounted convectors - installation manuals
Figure 8: Align the bearing piece into a horizontal position and tighten the
fixing screws.
Figure 9: Mount the exchanger using exchanger holders and screws.
Figure 10: Pull the cable through the grommet and connect the control unit
of the motors according to the "Controls" manual depending on the selected
control type. Test the connection.
Figure 12: Attach the convector frame, grille, and covers.
Figure 13: Screw head onto thermostatic valve.
Figure 7: Turn the adjustment stoppers to middle position. Screw the bearing
plate to the dowels. Do not tighten the screws completely.
Figure 11: Connect fittings. Inlet – thermostatic valve. Outlet – screw fitting.
The inlet is always at the bottom. Test the connection tightness.

38
6. CONNECTION OF FITTINGS
Connect the fittings with the supplied standard accessories.
Connect individual inlet and outlet valves. The thermostatic valve
(standard supply) is connected to the water inlet to the convector
for flow regulation. The screw fitting is installed on the outlet pipe.
Sealing must be used in all joints. Flow direction is from bottom to top.
Use the supplied flexible stainless hoses for exchanger connection
(bellows hose), which will later enable vertical exchanger tilting for
the purpose of cleaning. Connect fittings according to Figure 14.
Stainless hoses are designed to withstand a maximum pressure of
1.0 MPa. Hoses must not be stretched, compressed, or otherwise
deformed.
Media inlet: the thermostatic valve (standard supply) is connected
to the water inlet.
Outlet (return pipe): the screw fitting is always connected to the re-
turn pipe.
8. OPTIONALES ACCESSORIES
Thermostatic valve - straight, ½”
Thermostatic valve - angular, ½”
Screw fitting - straight, ½”
Screw fitting - angular, ½”
Ball valve - straight, ½”
Ivar thermostatic head
Heimeier thermostatic head
Bellows hose ½” - ½” 65 mm
Bellows hose ½ - ½ 41 mm
7. UNIT DEAERATION
Deaerate the unit by opening the deaerating valve during the first use.
The deaerating valve is located near the water inlet on the heat ex-
changer fitting.
installation manuals - wall mounted convectors
Figure 15: Deaerating valve
Figure 14
Figure 14: Adjust the vertical position of the convector using the adjustment
screws at the bottom of the convector body.

REGISTERED OFFICE OF THE COMPANY
MINIB,a.s.
Střešovická 465/49, 162 00 Prague 6
Czech Republic
Tel.: [phone]
Fax: [phone]
Email: [email protected], www.minib.cz
MANUFACTURING
Manufacturing premises MINIB,a.s.
Býkev u Mělníka 84, 276 01 Býkev
Czech Republic
