Minleaf ML-WT1 User manual
User manual
ML-WT1
ATTENTION
For the correct installation and use of this equipment, please read carefully the
requirements and strictly follow the instructions.
Basic requirements：
● Do not disassemble the equipment by yourself. Please contact a specialized
serviceman if the equipment is out of order.
● Do not under any circumstance modify the structure, safety features, or blade
design without guidance from a specialized serviceman.
●Obey local laws and regulations when using this product.
Assembly Requirements：
1. Read the user manual before assembling the wind generator or starting
maintenance.
2. Don’t install the wind turbine on a rainy day or when the wind scale is at Level 3 or
above.
3. After opening the package, it is advised to short circuit the three leads of the wind
turbine （the exposed copper parts should be screwed together).
4. Before the installation of the wind turbine, lightning grounding must be prepared.
Follow grounding according to national standards, or according to the local
environment and soil condition.
5.When assembling the Wind turbine, all parts should be fastened only with the
fasteners specified.
6.The battery must be connected before the wind turbine is connected to the
controller.
AT A GLANCE
1.Body frame
2.Hoop seat
3.Axis
4.Hub
5.Blade
6.Anti-slack nut
PRODUCT LIST
Serial
Item
Quantity
1
Wind generator
1
2
Hub
1
3
Blades
5
4
Lock nut on shaft（M16）
1
5
Blade bolts（M6*40）
10
6
Lock nut for blades（M6）
10
7
L spanner
1
8
Hex wrench
1
9
Controller
1
10
Washer
4
11
Bolt for hoop
4
12
Fairing
1
7.Fairing
8.Bolt for hoop
9.Elastic washer
10.Bolt for blades
1. Lock nut for blades
SPECIFICATIONS
Model: ML-WT1
Power: 1000 W
Voltage: 12 V/24 V
Starting wind speed: 2.0 m/s
Rated wind speed: 13.0 m/s
Number of blades: 5
Generator type: Three-phase AC permanent magnet synchronous generator
Blade material: Nylon fiber
Host weight: 10.3 kg
INSTALLATION
1. Use 5 blade bolts to fix blade and hub.
2. Tighten blade bolts and nuts with the L wrench.
3. Connect 3 wires to the transmission cables; make sure they are long enough to be
pulled out from the bottom of the tower.
4. Attach the hoop on top of the tower and tighten the screws with an L wrench (not
included in the package)
5. Insert a nut into the hexagonal hole on the hub to fix the hub onto the generator;
tighten up by holding the wrench with your left hand and rotating the hub clockwise
with your right hand.
6. Tighten the cone onto the hub.
7. Connect the controller to a battery, then attach transmission cables from the
tower to the controller.
MAINTENANCE
1. Wind turbines are always exposed, regularly check if the turbine moves in the wind
and that the cables are connected. Use a telescope for extra visibility if required.
2.Timely inspection should be made after a heavy storm. If there is any damage, put
down the tower for maintenance. If mounted on a streetlight, an electrician should
safely climb the pole to check if the generator is not shortcircuited and is operating
properly.
3.Maintenance-free batteries should be kept clean.
.
:
. ●
. ●
. ●
:
.
-
.
.
.
.
