Minolta MULTI GLOSS 268 User manual

MULTI GLOSS 268
UNI GLOSS 60
A wide array of display modes
(corresponding to six languages)
You can measure by selecting Basic
mode, Continuous, Statistics from
the Mode screen.
You can select the measurement
angle from the Geometry selection
screen and display two angles or
three angles at the same time.
(MULTI GLOSS 268)
You can select Mode,
Geometry selection,
Difference,
and Calibration
from the Main Menu screen.
Makes its debut with more multifunction to achieve
the effective gloss measurement.
Geometric selection selected two angles.
(MULTI GLOSS 268)
Geometric selection selected three angles.
(MULTI GLOSS 268)
PASS/FAIL Standard value name
Sample name
Large screen size and easily viewable liquid
crystal display.
Easy operation with mode scroll wheel.
By operating the mode scroll wheel in accordance with
easy-to-understand menu items, you can set a wide
array of functions easily.
Wide measurement range that can be
measured from plastic to metal surface
with a high gloss finish : 0.0~ 2,000 GU
(in the case of 20˚)
The gloss difference measurement of the
standard/sample and the PASS/FAIL evaluation.
You can make a pass/fail evaluation by setting the limit value.
You can enter the sample name and the standard value name in
the measurement result.
Autodiagnosis function of calibration
This means a little frequency of calibration and long-term stability.
In addition, if the calibration is required, the message will be
displayed.
Calibrating standard
Protective holder
• It has data compatibility
with the previous MULTI
GLOSS 268 / UNI GLOSS 60,
and improves repeatability
and reproducibility.
• Approx. 10,000 measure-
ments are available with one
AA(R6)size alkaline battery.
(20˚, 60˚, 85˚)
(60˚)
Mac OS 9.2J / Adobe Illustrator9J
MULTI_GLOSS_268_01.ai 2004.11.24

∗ Microsoft Excel®97 or higher.
Windows®, Windows NT®and Excel®is a trademark or registered trademark
of Microsoft Corporation of America or its subsidiaries.
Mac OS 10.3.9J / Adobe Illustrator10J
MULTI_GLOSS_268_02.ai 2007.7.5
AHIDPK
Printed in Japan9242-4890-11
2003 KONICA MINOLTA SENSING, INC. 9
OS Windows®98/2000/Me/XP, Windows NT®4.0
Certificate No : JQA-E-80027
Registration Date : March 12, 1997
Certificate No : YKA 0937154
Registration Date : March 3, 1995
Model MULTI GLOSS 268 UNI GLOSS 60
Measurement geometry  20˚, 60˚, 85˚ 60˚
Size of measurement  20˚ : 10 X 10 mm
spot  60˚ : 9 X 15 mm  60˚ : 9 X 15 mm
 85˚ : 5 X 38 mm
Standard compliance  ISO 2813, ISO 7668, ASTM D 523,
 ASTM D 2457, DIN 67 530, JIS Z 8741,
 BS 3900, BS 6161(Part 12)
Measurement  20˚ : 0.0~2,000 GU
range  60˚ : 0.0~1,000 GU  60˚ : 0.0~1,000 GU
 85˚ : 0.0~160 GU
Resolution  0.0~99.9 GU : 0.1 GU
 100~2,000 GU : 1 GU
Repeatability 0.0~99.9 GU : 0.2 GU
 100~2,000 GU : 0.2% of reading
Inter Instrument  0.0~99.9 GU : 0.5 GU
agreement 100~2,000 GU : 0.5% of reading
Memory  999 measurements with date and time
Difference measurement  Memory for 50 standard
Battery performance  Approx. 10,000 measurements
 (when using 1.5 V AA(R6)size alkaline battery)
Measurement time  0.5 seconds (each measurement)
Power OFF  Auto : 10~99 seconds select
Languages  English,Spanish,German,French,Italian,Japanese
Measurement mode  Normal mode (Sample mode, Statistics, Continuous,
 Basic mode), Difference mode
Interface  RS-232C format
Operating temperature  15 to 40˚C
/humidity range  relative humidity 85% or less (at 35˚C) with no condensation
Storage temperature  -10 to 60˚C
/humidity range  relative humidity 85% or less (at 35˚C) with no condensation
Power supply  1.5 V AA(R6)size alkaline battery
Dimensions  155(W) X 73(H) X 48(D) mm
Weight  400 g
Model MULTI GLOSS 268 UNI GLOSS 60
Standard Calibration holder TRI Calibration holder 60˚
accessories (High gloss tile) (High gloss tile)
 PC-cable
 Carrying case
 Data transfer software (gloss-link)
 1.5 V AA(R6)size alkaline battery
Optional Checking standard TRI  Checking standard 60˚
accessories (3 semi gloss tiles 20, 60, 85˚) (High and semi gloss tile)
 Checking standard mirror
 (3 tiles 20, 60, 85˚)
 USB-adapter
 AC adapter
Note : The specifications described in this document are subject to change without notice.
Specifications Accessories
ASTM DIN ISO
MULTI GLOSS 268 / UNI GLOSS 60 conforms with
international specifications ASTM D 523, DIN 67 530,
ISO 2813.
SAFETY PRECAUTIONS
For correct use and for your safety, be sure to read the
instruction manual before using the instrument.
Always connect the instrument to the specified power supply
voltage. Improper connection may cause a fire or electric shock.
Be sure to use the specified batteries. Using improper batteries
may cause a fire or electric shock.
Dimensions Units : mm
48
73
155
With dedicated Data transfer software
(gloss-link), the data management such as
data transfer to Excel®∗is easy.
