Minuteman M17120-00 User manual

Front Runner
Floor Machines
Model:
M17120-00, 01, 02, 03
M17240-01, 02, 03
M20120-01, 02, 03
M20240-01, 02, 03
Revised 11/00
OPERATION SERVICE PARTS CARE

1
FOR COMMERCIAL USE ONLY
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING
WARNING - To reduce the risk of fire, electric shock, or injury:
•Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
WARNING
To reduce the risk of electrical shock - Do not expose to rain. Store indoors.
•Never allow children or untrained adults to operate this equipment.
•Keep the area of operation clear of all persons, particularly small children, and pets. Keep
bystanders at least 25 feet away from the area of operation.
•Use only as described in this manual. Use only manufacturer’s recommended attachments.
•Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return it to a service center.
•Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
•Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
•Do not handle plug or appliance with wet hands.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
•Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
•Do not use without dust bag and/or filters in place.
•Turn off all controls before unplugging.
•Use extra care when cleaning on stairs.
•Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where
they may be present.
•Connect to a properly grounded outlet only. See grounding instructions.
SAVE THESE INSTRUCTIONS

2
INSPECTION
Carefully unpack and inspect your machine for shipping damage. Each unit is tested and thoroughly
inspected before shipment, and any damage is the responsibility of the delivery carrier who should
be notified immediately.
WARNING
Read Instruction Manual before operating this piece of equipment.
•To reduce the risk of fire use only commercially available floor cleaners and waxes intended for
machine application.
•Risk of explosion - floor sanding can result in an explosive mixture of fine dust and air. Use floor
sanding machine in a well-ventilated area free from any flame or match.
•Electrical motors and components can cause an explosion when operated near volatile materials
and vapors. Do not use this machine near flammable materials such a solvents, thinners, fuels,
grain dust, etc.
ELECTRICAL - 115 Volt
Model M17120-00, 01 02 M20120-01, 02, 03
This machine is designed to operate on a standard 15 amp. 120 volt, 60 hz, AC circuit. Voltages
below 105 volt AC or above 125 volts AC could cause serious damage to the motor.
ELECTRICAL - 240 Volt
Model M17240-01, 02, 03 M20240-01, 02, 03
This machine is designed to operate on a standard 16 amp. type L fused 230 volt, 50 hz, AC circuit.
Voltages below 200 volt AC or above 250 volts AC could cause serious damage to the motor.
GROUNDING INSTRUCTIONS
•This floor finishing machine should be grounded while in use to protect the operator from electric
shock. The machine is equipped with a three-conductor cord and a three-prong grounding type
attachment plug to fit the proper grounding type receptacle. The green (or green and yellow)
conductor in the cord is the grounding wire. Never connect this wire to other than the grounding
blade.
•Floor Finishing Machines Rated Less Than 150 Volts - If the machine is provided with an attachment
plug as shown in Sketch A it is intended for use on a 120-volt (nominal) circuit.
•If a properly grounded receptacle as shown in Sketch A is not available, an adapter as shown in
Sketch C is available and should be installed as shown in Sketch B if the outlet box that houses the
receptacle is grounded. Be sure to fasten the grounding tab with the faceplate screw.
•Floor Finishing Machines Rated More Than 150 Volts - If the machine is provided with an attachment
plug as shown in Sketch D, it is intended for use on a nominal 240 volt circuit. No adapter is
available for this plug.

3
POUR USAGE COMMERCIAL SEULEMENT
MODE D’EMPLOI SECURITAIRE
Lorsque l’on utilise un appareil électrique, des précautions de base doivent toujours être suivies
telles que:
BIEN LIRE LE MODES D’EMPLOI AVANT USAGE
AVERTISSEMENT - Pour réduire les risques de feu, choc électrique ou blessure:
Ne pas quitter l’appareil lorsque la prise de courant est branchée. Débrancher de la sortie électrique
lorsque la machine n’est pas en usage ou pour en faire le service.
AVERTISSEMENT - Pour réduire le risque de choc électrique - Ne pas exposer à la
pluie - Entreposer à l’intérieur.
•Ne pas permettre l’usage comme jouet. Etre très prudent lorsque l’appareil est utilisé en
présence d ‘enfants.
•Utiliser tel que prescrit dans le livre d’opération et seulement avec les attachements
recommendés par le manufacturier.
•Ne pas s’en servir avec corde ou prise de courant endommangée. Si l’appareil ne fonctionne
pas ou a été échappé, endommagé, entreposé à l’extérieur ou depose dans l’eau, l’appareil
devrait être envoyé à un département de service pour inspection.
•Ne pas tirer ou porter par le câble ou se servir du câble comme poignée. Ne pas fermer de
portes sur le câble ou tirer le câble près d’objets pointus. Ne pas conduire l’appareil en écrasant
le câble et soyez certain de protéger le cable entre toutes surfaces de chauffage.
•Ne pas débrancher en se servant du câble. Pour débrancher tirer sur la prise et non sur le
câble.
•Ne pas manipuler la prise ou l’appareil avec les mains mouillées.
•Ne placer aucun objet dans la sortie et ne pas s’en servir si la sortie est obstruée. Eliminer
toute poussière, maillon, cheveux ou quoique ce soit qui pourrait réduire le mouvement d’air.
•N’exposer aucun cheveux, vêtement, doigts ou autres aux ouvertures de l’appareil.
•Ne rien ramasser de ce qui brûle ou de fumée tels que cigarettes, allumettes ou cendres en
feu.
•Ne pas employer sans filtre de poussière ou autre en position.
•Fermer tous les contrôles après utilisation.
•Soyez très prudent lors du nettoyage d’escaliers.
•Ne pas ramasser de liquide inflammable ou combustible tel que gazoline et ne pas utiliser
dans les endroits ou ces derniers pourraient être présent.
•Brancher dans une prise avec une prise de terre seulement. Voir références pour prise de
terre.
CONSERVEZ CES RECOMMANDATIONS
DE MODE D’EMPLOI

4
USER MAINTENANCE INSTRUCTIONS
A qualified electrician should perform all service and repair. No user serviceable components are
employed in this equipment. No lubrication of the motor is required.
CORD STORAGE
While not in use, storage can be accomplished by winding cord around handle assy. Cord should be
completely unwound during operation.
•Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return to service center.
•Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
•Do not unplug by pulling cord. To unplug, grasp the plug, not the cord.
•Do not handle plug or appliance with wet hands.
•Always unplug the machine when removing brush. This equipment should be stored indoors and
not exposed to rain.
PREVENTATIVE MAINTENANCE - 2-Speed Models Only
This machine employs a motor carbon brush wear indicator light located on the rear of the motor
cover. This will illuminate when the carbon brushes are worn to the point of needing replacement,
service should be done by a qualified electrician.
OPERATION
The brush is attached in the following manner: Tip machine backward with handle on floor. Brush is
then inserted over the lugs on the bottom of the gear unit and twisted to the left. This secures the
clutch plate of the brush over the lugs on the gear unit in the correct driving position.
LOWER HANDLE ASSEMBLY TO WAIST HIGH POSITION AND LOCK.
Due to the rotation of a single disc machine, it will naturally have a tendency to move to the right or
left, depending on the operator’s slight pressure either up or down on the handle. If the handle is
lifted slightly up, the machine will travel to the right; a downward pressure, and
it will travel to the left. It is this maneuverability that enables an operator to cover large areas in a short
time with the least amount of effort. The machine can be made to operate without travel by balancing
... KEEPING THE BRUSH PRESSURE ON THE FLOOR EQUAL. With a few minutes of practice in
a large area, you will have perfect fingertip control of the machine. This equipment is equipped with
trigger safety interloc. Refer to diagram pictured.

5

6

7
Parts List
Item Part No. Qty. Description
1 190000PTD 1 Base Casting
2 190001PTD 1 Housing 17
2A 190002PTD 1 Housing 20
3 807248 2 Handle Brace
4 190030 2 Wheel
5 711510 4 WSR-Flat .50 x 1.00
6 711524 4 WSR-Wave .52 x .87
7 190021 3 Rivet
8 190011 2 Axle
9 760261 1 Bolt, Yoke
10 711515 6 WSR-Flat .44 x .87
11 190017 1 Bumper 17
11A 190018 1 Bumper 20
12 711237 4 Bolt-HH 5/16-18 x 2.00
13 711545 4 WSR-Helical 5/16
14 830949 2 Snap Bushing
15
16 711375 1 Nut-Nyloc 3/8-16
17 715062 1 Decal, Warning
18 711439 2 Nut-Flanged Wizz 3/8-16
19 711592 2 WSR-Nylon .50 x 1.00
20 180035 1 Motor 3/4 HP w/Gear 115V
20A 200002 1 Motor 1 HP w/Gear 115V
20B 200025 1 Motor 1.5 HP w/Gear 115V
20C 200220 1 Motor 1 HP w/Gear 240V
20D 750571 1 Motor 1.5 HP w/Gear 240V
21 715168 1 Decal, Minuteman 17
21A 715169 1 Decal, Minuteman 20
22 805635 1 Cork Gasket
23 160048PTD 1 Motor Cover
24 710153 3 SCR-MC 10-32 x .37
25 740271 1 Motor/Gear Assembly 115V
25A 740273 1 Motor/Gear Assembly 240V
26 760123 1 Motor Cover Mounting Bracket
27 711124 2 SCR-ST-B 10 x .38
28 190020 1 Motor Cover
29 715075 1 Decal 2-Speed
30 829194 1 Motor Top Cover
31 710196 1 SCR-MC 5/16-18 x .63
32 830696 1 Stain Relief
33 832859-1 1 Indicator Light 115V
33A 832860-1 1 Indicator Light 240V
34 715170 1 Decal, High/Low
35 740188 1 Switch 20 amp. 1.5 HP
36 829489 1 Foam Dampener
37 832829 1 Tinnerman Nut
38 762146 1 Cord, Pigtail
39 762160 4 Carbon Brush 115V
39A 740281 4 Carbon Brush 240V
40 740202 1 Bridge Rectifier
41 740259 1 Traic Control 115V
41A 740280 1 Traic Control 240V
42 715067 1 Decal, Brush Wear Indicator

8

9
PARTS LIST
Item Part No. Qty. Description
1 190003 1 Switch Box Front
2 190004 1 Switch Box Rear
2A 190004MCH 1 Switch Box Rear, 240V
3 190007 2 Switch Trigger
4 190008 1 Switch Cap
5 190009 2 Safety Button
6 190006 2 End Cap
7 190005 1 Electrical Box Rear
8 190012 1 Tube Handle
9 190015 2 Trigger Spring
10 150003 1 Strain Relief, 115V
10A 150004 1 Strain Relief, 240V
11 715175 1 Decal, Minuteman Runner
12 711400 2 Nut-Pipe Lock 1/2
13 711619 2 Roll Pin 1/8 x 1.50
14 190016 2 Foam Grip
15 710186 2 SCR-MC 1/4-20 x 2.25 TH
16 711658 2 Roll Pin 1/4 x 1.0
17 170040PLT 1 Cord Hook
18 16224 1 Handle Clamp
19 190010 1 Strain Relief
20 150002 1 Orange Cord Set, 115V
20A 740600 1 Cord Set, 240V
21 803379 1 Yoke
22 190013 1 COrd, Handle
23 832859 1 Indicator Light, 115V
23A 832860 1 Indicator Light, 240V
24 740005 3 Wire Cap 14-18
25 740029 2 Switch 1.5 HP
26 711553 1 WSR-Lock #8
27 740363 1 Wire Assy Green w/Yellow
28 712088 2 SCR-Hi/Lo 8-18 x .75
29 711502 1 WSR-Flat 8
30 710380 2 SCR-MC 1/4-20 x .75
31 711160 4 SCR-Hi/Lo 10 x .63
32 711162 4 SCR-Hi/Lo 10 x 1.50
33 711202 2 Bolt-HH 1/4-20 x .50
34 711316 2 Nut-Hex 1/4-20
35 711373 2 Nut-Nyloc 1/4-20
36 711544 2 WSR-Helical 1/4
37 740036 1 Terminal Block, 240V
38 710579 2 SCR-MC 1/4-20 x .62
39 807674 1 Kick Lever Kit
40 806561 1 Dowel Kit
41 806558 1 Kick Lever
42 807190 1 Bolt Cam
43 806555 1 Washer Cam
44 711374 1 Nut-Nyloc 5/16-18
45 711506 1 WSR-Flat 5/16
46 190029 2 Sleeve
47 711504 4 WSR-Flat 1/4
48 711128 5 SCR-Hi/Low #8-18 x .625

LIMITED WARRANTY
Minuteman International, Inc. warrants to the original purchaser/user that this product is free from defects in workmanship and
materials under normal use and service for a period of three years from date of purchase. In addition, Minuteman International,
Inc. will, at its option, honor labor warranty claims for the first 12 months from date of sale, provided such claims are submitted
through and approved by factory authorized repair stations. Minuteman International, Inc. will, at its option, repair or replace
without charge, except for transportation costs, parts that fail under normal use and service when operated and maintained in
accordance with the applicable operation and instruction manuals.
This warranty does not apply to normal wear, or to items whose life is dependent on their use and care, such as belts, cords,
switches, hoses, rubber parts, electrical motor components or adjustments. Parts not manufactured by Minuteman International,
Inc. such as engines, batteries, battery chargers, hydraulic pumps, and tires are covered by and subject to the warranties and/
or guarantees of their manufacturers. Please contact Minuteman International, Inc. for procedures in warranty claims against
these manufacturers.
Special warning to purchaser — Use of replacement filters and/or prefilters not manufactured by Minuteman International, Inc.
or its designated licensees, will void all warranties expressed or implied.
A potential health hazard exists without exact original equipment replacement.
All warranteed items become the sole property of Minuteman International, Inc. or its original manufacturer, whichever the case
may be.
Minuteman International, Inc. disclaims any implied warranty, including the warranty of merchantability and the warranty of
fitness for a particular purpose. Minuteman International, Inc. assumes no responsibility for any special, incidental or consequential
damages.
This limited warranty is applicable only in the U.S.A. and Canada, and is extended only to the original user/purchaser of this
product. Customers outside the U.S.A. and Canada should contact their local distributor for export warranty policies. Minuteman
International, Inc. is not responsible for costs or repairs performed by persons other than those specifically authorized by Minuteman
International, Inc. This warranty does not apply to damage from transportation, alterations by unauthorized persons, misuse or
abuse of the equipment, use of non-compatible chemicals, or damage to property, or loss of income due to malfunctions of the
product.
If a difficulty develops with this machine, you should contact the dealer from whom it was purchased.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state. Some states do not
allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long an implied warranty
lasts, so the above exclusions and limitations may not apply to you.
World Headquarters Minuteman Canada, Inc.
Minuteman International, Inc. 2210 Drew Road
111 South Rohlwing Road Mississauga, Ontario
Addison, Illinois 60101 L5S 1B1
[phone] [phone]
FAX [phone] FAX [phone]
988342
Printed in U.S.A.
