Traction Drive
Deluxe
Floor Scrubber
Battery
Model: MC20001QP, CE
MC20002QP, CE
OPERATION SERVICE PARTS CARE

TABLE OF CONTENTS
Page
SafetyInstructions 1
Electrical Requirements 2
ControlPanelIdentification 3
OperatingInstructions 4
SqueegeeAdjustments 5
BrushInstallation/Removal 6
BaseAssembly-TractionDrive 7, 8
BaseAssembly-Deluxe 9, 10
TankAssembly 11, 12
UpperAssembly 13
ConsoleAssembly 14
MotorLiftAssembly - Deluxe 15, 16
MotorLiftAssembly -Traction Drive 17
ScrubheadAssembly 18
Dashboard & Back PanelAssembly 19
SqueegeeLift&MechanismAssembly 20
SqueegeeAssemblyComplete 21
Wiring Diagram 22, 23
Wiring Diagram - CE 24, 25

1
IMPORTANT SAFETYINSTRUCTIONS
CAUTION
Operatorsmustreadandunderstandthis manual before operatingormaintainingthisequipment.
• Keephandsandfeetclearofmovingpartswhilemachineisinoperation.
• Allswitchesmustbeinthe“OFF”positionwhenchargingbatteries.
• Electricalmotorsandcomponentscancauseanexplosionwhenoperatednearexplosivematerials
orvapors.Do notoperatethismachinenearflammablematerialssuchassolvents,thinners, fuels,
graindusts,etc.
• Makesureallswitchesare turned “OFF”andbatteryconnectionsareremoved before performing
anymaintenanceprocedures.
• Store or park this machineonalevelsurfaceonly.
• These machines are designed for level floor operation only. DO NOT OPERATE on ramps or
inclines.
• Batteryacidcancauseburns. When workingonoraroundbatteries,wearprotective clothing and
safetyglasses.Removemetal jewelry.Donotlaytoolsormetalobjectsontopofbatteries.
• Thismachineisnotsuitableforpickingup hazardous dust.
Charging batteries generates explosive gases. DO NOT CHARGE BATTERIES WHEN OPEN
FLAMES OR SPARKS ARE PRESENT. DO NOT SMOKE. Make sure the charger is turned off
beforedisconnectingitfromthebatteries.Chargethebatteriesinawell-ventilatedarea.
Maintenanceandrepairsmustbeperformed by authorizedpersonnel.
SAVE THESE INSTRUCTIONS

2
ELECTRICAL REQUIREMENTS:
This piece of equipment operates on 24 Volt DC.
BATTERY REQUIREMENTS:
2 x 12V 185Amp Hour 20 Hour Rate Deepcycle P/N 956709
2 x 12V 210Amp Hour 20 Hour Rate Deepcycle P/N 956210
BATTERY SERVICE AND INSTALLATION:
Warning:Batteryacidcancauseburns.Whenworkingonoraroundbatteries,wearprotectiveclothing
andsafetyglasses.Removemetaljewelry. Do not laytoolsormetalobjectsontopof batteries.
BATTERY INSTALLATION:
1. Raisetankassembly bygrippingthefrontofthetank andliftthetankbackwardasshowninFig.1.
2. Installbatteriesasshownin Figure 2.
CHARGING OF BATTERIES:
Charging of batteries generates explosive gases. DO NOT CHARGE BATTERIES WHEN OPEN
FLAMES OR SPARKS ARE PRESENT. DO NOT SMOKE. Make sure the charger is turned off
beforedisconnectingit fromthebatteries.Charge thebatteriesina well-ventilatedarea. Fluidlevels
shouldbecheckedbeforeandafterchargingandmaintainedattheproperlevels.

3
COMPARISON RECOMMENDED
TYPE DESCRIPTION DURABILITY* COLOR TO PADS USE
Bassine Natural Fiber Short Dark Brown Red Light duty
general cleaning,
acid etching
Nylon Nylon Medium Black Tan/Red General cleaning
& scrubbing vinyl
floors, ceramic tile
& concrete floors
Dyna-Scrub Nylon impregnated Long Light Red General scrubbing,
with 500 Grit vinyl tile, ceramic
SiliconCarbide tile, epoxy floors,
Fine Bristle, urethane finish,
DenseFill uneven concrete floors
Power-Scrub Nylon impregnated Long Rust Red/Blue Moderate aggressive
with 120 Grit Silicon scrubbing, tile floors,
Carbide Fine Bristle, concrete floors
DenseFill
Poly-Grit Nylon impregnated Long Green Brown/Black Aggressive stripping
with 80 Grit and scrubbing, tile
SiliconCarbide floors, unfinished
Coarse Bristle concrete floors
Strata-Grit Nylon impregnated Long Dark Blue Black Heavy duty
with 46 Grit stripping/scrubbing
SiliconCarbide unfinished concrete
Coarse Bristle
1. Squeegee lift lever
2. Recovery dump hose
3. Reverse handle
4. Dashboard control panel
5. Forward handle
6. Safety bar switch
7. Solution control lever
8. Solution dump hose
9. Quick disconnect - Aux. out (Deluxe only)
10. Foot pedal (TD only)
11. Circuit breaker - Brush
12. Circuit breaker - Vac
13. Circuit breaker - System
14. Circuit breaker - Transaxle
15. Keyswitch
16. Main power
17. Emergency button
18. Brush pressure gauge
19. Brush control
20. Pump switch
21. Speed control
22. Battery condition meter
AUTOSCRUBBERBRUSHDESCRIPTION
••
••
• Durability is dependent on floor surface, chemicals used and proper care.

4
OPERATING INSTRUCTIONS
BEFORE STATING, FAMILIARIZE YOURSELF WITHTHE MACHINE AND ITS CONTROLS
(SEE “MACHINE OVERVIEW” & CONTROL PANEL DIAGRAMS)
1. Filling:Fillthesolutiontank with the desired amountofwaterandaddliquidcleaningsolutionto
theproperdilutionratio.DONOTUSEpowderedcleaningchemicals. Powdersareunlikelyto
dissolvethoroughly,resultingincloggingthe in-line solutionfilter. Thiscanreduceorstopwater
flowtothe brush.
2. Close lid.
3. Turn on machine by lifting the red emergency disconnect button (17) so it is in the up position.
Turnkeyswitch(15)clockwiseto“on”position and turnonmainpowerswitch(16).
4. Adjustmainspeedcontrol(21) to full counter-clockwiseposition.
5. Lowerbrushassembly.
- To lower the brush,firstpushthepedal(10)slightlyoutwardonthemachine(unlockit),and
thenreleaseitslowlyorby pressing “brushdown”switch(19)onDeluxemodels.
- Toliftthebrush,pressthepedal (10)downuntilliftmechanismengagesorbypressing”brush
up”switch(19)onDeluxe models.
- Brushwillcomeon automaticallywhenbrushinon the floorand“forward”(5)or “reverse”(3)
handlesaresqueezedandremainonapproximately5secondsafterrelease.
6. Adjustsolutioncontrolfeed lever.
7. Selectvacuumoperations:
- “Vacuum On”mode(23),Vacuumwillremainonuntilswitchedtothe “off”position
- “VacuumAuto” mode (23), Vacuum will come on automatically when “forward” or “reverse”
handle is squeezed, and scrubhead is on the floor. The brush and vacuum will remain on
approximately5minutes.
8. Lowersqueegeeassemblybylowering handle (1).
9. Squeeze“forward”handle(5)andadjustforwardspeed(21)asdesired.
After Use:
1. Turnoffsolutionfeed.
2. Raisesqueegeeassembly.
3. Turnoffvacuummotor.
Solutionandrecoverytanksshould be emptied aftereveryuse.
MAINTENANCE:
Daily 1. Clean float assembly & squeegee blades. Vac filter
2. Rechargebatteries(checkbatteryacidlevels before and after charging).
Monthly 1. Check wear on squeegee blades.
2. Greasefrontwheels.
3. Greasepivotpointsonbrushmotorassembly.
Every500hourscheckconditionof carbon brushesonvacuummotorandbrushdrive motor.

5
SQUEEGEE ADJUSTMENTS
The squeegee set up is pre adjusted at the factory. Adjustments may be required to get optimum
performance for different floors and conditions.
1 Ensure that the scrubber is on a relatively flat surface. Turn on the main power switch and turn the key
switch clockwise to the on position. Raise the scrubhead off the floor. Turn the vacuum switch to the
“vacuum only” position.
2 Turnthe speedcontrolknob counterclockwiseto thelow speedposition. Lowerthe squeegee(item1)
to the floorand squeeze the forward control handle, moving the machine one or two feet forward to
check the rear squeegee blade (item 8) for uniform deflection to the floor.
3 If uneven deflection or lay is evident, minor adjustments may be necessary to avoid streaking and
uneven wear on the blade.
4 To correct this, loosen the wing jam nut (item 4) in order to adjust the castor height. If the squeegee
blade is deflecting too much, the castors need to be lowered to control the down pressure. Lower the
castor by turning the exposed threaded stem (item 9) on the castor clockwise. Make the adjustment a
few turns at a time. Repeat Step 2.
5 Iftheblades arenotdeflecting enough,raisethe castorbyturning thestemcounter clockwiseto adjust
the castor height to allow more down pressure on the squeegee. Repeat Step 2.
6 Make sure that there is an even deflection on the entire length of the rear blade.Adjust the castors and
retighten the wing jam nuts to lock the castor setting in place.
7 Pitch adjustment is necessary if the outer ends on the squeegee blade does not contact the floor and
there is too much deflection in the middle area or if the outer ends are over deflected and there is no
contact in the middle.
8 To adjust the pitch, lower the squeegee to the floor. Loosen the lock nut (item 3) in the turnbuckle
assembly. Turning the turnbuckle (item 2) clockwise or counter clockwise controls the forward and
backward pitch of the squeegee. Having the rear blades deflected uniformly along the entire length is
the desired set up.
9 Repeat Step 2 until the desired set up is achieved.
10 In certain applications where a non-slotted front wiper blade (item 6) is needed, detach the squeegee
assembly by loosening the wing bolts (item 7). Unlock the clamp on the front squeegee to release the
strapsandflip theblade overtothe non-slottedside. Reattachstrapsand lockthe clampbackin place.
11 You can also easily replace the rear blade by unlatching the latch (item 5) and removing the straps by
sliding them off the assembly.

6
BRUSH INSTALLATION - REMOVAL
INSTALLATION
Traction Drive
1. Raise the scrubhead to the “UP” position by depressing the pedal (A) downward as shown on
Fig. 1.
Deluxe Model
1. Raise the scrubhead to the “UP” position by pressing the switch “BRUSH UP” (B) switch as
shownonFig.2untilthe scrubhead stopsretractingupwards.
2. Centerbrush(D)underthescrubheadshroudwhileliningupthecenterhexdrivehubandpressing
thebrushupuntil thebrushengagesonthe drivehub.
REMOVAL
Traction Drive
1. Raise the scrubhead to the “UP” position by depressing the pedal (A) downward as shown on
Fig. 1.
Deluxe Model
1. Raise the scrubhead to the “UP” position by pressing the switch “BRUSH UP” (B) switch as
shownonFig.2untilthe scrubhead stopsretractingupwards.
2. Removethebrush(D)by stepping on the “BRUSHRELEASEPIN”onthetopofthescrubhead
shroudasshownonFig.1below.
Figure 1 Figure 2

7
BASE ASSEMBLY - TRACTION DRIVE

8
TRACTION DRIVE Parts List

9
BASE ASSEMBLY - DELUXE

10
DELUXE Parts List

11
TANK ASSEMBLY

12
TANK ASSEMBLY Part List

13
UPPER ASSEMBLY
Parts List

14
CONSOLEASSEMBLY
Parts List

15
MOTOR LIFT - DELUXE

16
Parts List
200290 Motor Lift Assembly
Item Part No. Qty. Description
1 200249 1 Base Plate Weldment - Deluxe
2 260036 2 Pin
3 712310 4 WSR-Flat .52 x .88 x .06
4 711527 6 WSR-Flat 5/8 x 1.12 x .12
5 762340 2 Oilite Bushing 1/2
6 260041 4 Oilite Flanged Bushing 1/2
7 200242 1 Lift Arm Weldment - Deluxe
8 711713 2 E-Ring 1/2
9 710312 2 SCR-MC 6-32 X 1.75 ZINC
10 740128 2 Microswitch
11 711430 1 Tinnerman Clip
12 833638 2 Brass Stud
13 711368 2 Wing Nut
14 740132 2 Insulator Glastic
15 743032 1 Terminal Block
16 712822 2 SCR-THMS 10-24 x 1/2
17 711807 1 Cotter Hair Pin
18 711672 1 Clevis Pin 1/2
19 711376 1 Nut-Nyloc 1/2-13
20 828264 2 Cup Washer
21 260137 1 Compression Spring
22 200110 1 Spring Bracket
23 711334 1 Nut-Hex 1/2-13
24 200149 1 Adjustment Rod
25 712126 1 Shoulder Bolt 5/16 x 1.75
26 711515 6 WSR-Flat .406 x .81 x .063
27 711373 1 Nut-Nyloc 1/4-20
200285 Pump/Actuator Assembly
28 200174 1 Pump Mounting Bracket
29 712638 4 Nut-Nyloc 10-24 SS
30 200248 1 Pivot Tube
31 831965 1 Clevis Pin 3/8 x 1.63
32 711808 1 Cotter Pin
33 743503 1 Actuator
34 833299 1 Pump
35 711505 4 WSR-Flat 1/4
36 712532 4 SCR-MC 10-24 x 1 SS
37 833325 2 Elbow 3/8 Barb x 1/4 NPT
38 450076 2 Crimp Clamp 185R
39 200282 1 Hose Pump Inlet
40 200281 1 Hose Pump Outlet
41 710329 2 SCR-MC 8-32 x .5 C.E. Only
42 742391 1 RFI Filter, Corcom C.E. Only
43 200335 1 RFI Bracket C.E. Only
44 711372 2 Nut-Nyloc 8-32 C.E. Only
200139 Valve Assembly - Deluxe
45 342430 2 Fitting 3/8 Barb x 3/8 MPT
46 743505 1 Water Solenoid 24V
47 829463 1 WSR-Flat SS
48 828975 1 WSR-Neoprene .75 x 1.5 x .09
49 830062 1 3/8 Street 90qBrass
50 383332 1 3/8 Closed Nipple
51 809413MCH 1 Solution Valve Machined
52 200259 1 Valve Bracket
53 210408 1 Fitting Brass Tee 3/8 NPT
54 450040 1 Elbow 3/8 Barb x 3/8 MPT
