Minuteman 747 Parts list manual

Parts and Instruction Manual
747 Wide Area Carpet Vacuum
Battery Power
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts
and Instruction Manual
Table of Contents
Main Assembly Bill of Material .......................................................................................................................................... 4
Main Assembly I ................................................................................................................................................................. 5
Main Assembly II ................................................................................................................................................................ 6
Main Assembly III ............................................................................................................................................................... 7
Brush Assembly ................................................................................................................................................................. 8
Fan Assembly ..................................................................................................................................................................... 9
Optional Accessories....................................................................................................................................................... 10
Minuteman International Made Simple Commercial Limited Warranty........................................................................ 11
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 4
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
2 601163 1 SWITCH-20A125V LATCHING PB 68 827876 1 BELT-V 6 RIB POLY
3 710195 4 SCR-MC 5/16-18 X .50 ZINC 69 827877 1 PULLEY MOTOR
4 710207 3 SCR-MC 6-32 X .87 ZINC 70 827878 1 BELT-V 4 RIB POLY
5 710310 1 SCR-MC 6-32 X 1.5 ZINC 71 827880 1 FAN ASSY AV747
6 711599 1 WSR-FLT .187 X 1.00 X .06 72 827890 1 BOX SWITCH
7 710755 3 USE 711202 INSTEAD; SC 1/4-20 X .50 HEX Z 73 830721 1 BRUSH-STATIC FREEASM
8 711016 2 SK 1/4-20 X .50 74 827905 1 COVER, 747 BATT
9 711115 1 SCR-ST-A 8 X .62 ZINC 75 827906 1 HINGE-BASE
10 711124 4 SCR-ST-B 10 X .37 NI 76 827910 1 COVER
11 711221 2 BLT-HH 1/4-20 X 2.25 77 827911 1 HINGE-COVER
12 712565 2 SCR-MC 1/4-20 X .62 SS 78 827912 1 BAFFLE
13 711228 8 BLT-HH 5/16-18 X .75 STL ZINC 79 827919 1 CONNECTOR-W/INSERTTERM
14 711231 4 BLT-HH 5/16-18 X 1.25 80 827925 1 CABLE ASY POSITIVE
16 710776 2 SCR-MC 5/16 X 2.50 ZINC 81 740132 1 INSULATOR (PLASTIC)
17 713045 1 BLT-HH 3/8-16 X 1.75 #5 82 828378 1 DECAL
19 711359 2 NUT-ACORN 5/16-18BR NIPL 83 828596 2 GROMMET
20 711366 2 NUT-WING 5/16-18 ST PL 84 740302 1 14G BLACK 13.50" B= 1
21 711379 16 NUT-FLANGED WIZZ 5/16-18 85 828893 6 RIVET
22 833929 1 SPRING-COMP .063 X .54 X 1.25 86 829182 1 BUMPERASSY
23 711435 4 NUT-FLANGED WIZZ 6-32 87 829184 2 CASTER PIVOT
25 711506 8 WSR-FLT 5/16 (NARROW) STPL 88 829185 1 BATTERYTRAY
27 711539 4 WSR-EXT LOCK 3/8 89 829186 2 CASTER BRKT
28 711544 8 WSR-HELICAL 1/4 90 829187 1 SHAFT
29 711575 5 WSR-FLT .31 X .75 X .06 STL 91 829202 2 AXLE REAR 747
31 712300 2 WSR #8 BR NIPL 92 829205 1 BRKT-HANDLE
32 711553 20 WSR-INT LOCK #10 93 829289 1 LEAD ASSY
33 711515 2 WSR-FLT .406 X .812 X .0625 94 829290 1 LEAD ASSY BLACK
34 712565 2 SCR-MC 1/4-20 X .62 SS 95 831026 1 WIRE LEADASY
35 712667 4 NUT-NYLOC 1/4-20 SS 96 809161 1 WIRE ASY 12GA BLK 18"
36 712810 10 SCR-MC 10-24 X .37 ZINC 97 740241 1 RELAY-24V 50AMP SPNO
37 712811 5 SCR-MC 10-24 X .50 STZ RD HD 98 829296 3 PIN-ROLL 1/4 X 7/8
39 712822 4 SCR-MC 10-24 X .50 SS TR 99 711620 4 PIN-ROLL .25 X 1.25
40 712900 1 NUT-HEX 10-24 STPL 100 829299 2 CASTER-SWIVEL
41 712908 12 NUT-FLANGED WIZZ 10-24 101 829310 2 SPRING-TORSION
42 715384 1 DECAL-MMAN 1.4 X 9.68 DK GRY 102 830301 1 CABLE ASY NEG
43 715029 1 DECAL-NAME PLATE SERIAL 103 831641 1 BAG, CLOTH 724/747 2-ZIPR
44 740097 1 CONNECTOR-SB50 RED HOUSING ONLY 104 830902 1 BATTERY BOX
45 740164-1 1 JUMPER CABLEASSY, RED 4G 12" 105 830903 1 BATTERYSTRAP
46 785208-1 1 DRIVE MTR .75HP 24V W/TERMINLS 106 832204 1 PLUG HOLE
48 808706 1 BLOWER HOSE 107 808759CTD 1 HANDLE 747 PVC COATED
49 833859 1 BRUSH PLATE 747 14GA 109 833472 1 END CAP 747
50 808720 1 BUMPER CLIP 110 833695 1 COVER PLATE 747 18GA
52 808737 3 BUMPER CLIP 111 833928 1 HANDLE,ADJUST NEW STYLE
53 808744 2 CLAMP-HOSE 112 833926 1 HANDLE MOUNT NEW STYLE
54 808756 4 RET RING-E TYPE .62 5133-62 113 833699 1 GASKET HANDLE 747
56 808760 1 HANDLE BRACKET 114 715506 1 DECAL-747 HEIGHTADJ
57 808803 2 BRKT-HOLD DOWN 115 833927 1 ADJUSTING PLATE NEW STYL 3-16
58 808829 1 WHEEL-TRUCK 116 833725 1 CLIP-T
59 809444 2 CLIP-CORD 117 833762 1 8G RED 13.25
61 760428 1 LATCH ONLY-37-11-071-10 118 833763 1 8G BLACK 20.00"
62 760429 1 LATCH-KEEPER 372507117 119 710581 2 SCR-MC 1/4-20 X .75 ZINC
64 711910 2 RIVET-POP 120 711717 1 RET RING-E EXT .37
65 827855PTD 1 747 MAINFRAME PAINTED 121 832448 1 SHOULDER SCREW
66 827871 2 WHEEL 122 715504 1 DECAL-747 DISENGAGE
67 827873 1 MOUNT MOTOR
Main Assembly Bill of Material
Diagrams for part numbers listed can be found on pages 5, 6, and 7
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 5
Main Assembly I
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 6
Main Assembly II
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 7
Main Assembly III
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 8
ITEM PART NO. QTY. DESCRIPTION
1 711161 6 SCR - HI-LO #10-16 X 3/4, PAN HD. #10
2 711162 6 SCR-HI/LO #10 X 1 1/2 ZINC
3 711553 12 WSR-INT LOCK #10
4 712318 2 WSR-FLT .75 X 1.12 X .12 PL
5 828927 1 BRUSH-CORE STATIC FREE
6 827894 2 CUP BEARING
7 827896 1 COVER BEARING
8 827897 1 SHAFT BRUSH
9 827898 1 PULLEY BRUSH
11 828145 2 RET RING
12 828588 2 BEARING-.500 X 1.125 X .312
** 830721 BRUSH ASSEMBLY COMPLETE
Brush Assembly
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 9
ITEM PART NO. QTY. DESCRIPTION
1 827881 1 HOUSING FAN BOTTOM MCH
2 827883 1 HOUSING FAN TOP MCH
3 808727BAL 1 BLOWER FAN BAL 724/747
4 801535 2 BEARING-MOTOR .6693 X 1.5748 X .4724
5 808733 2 RET RING
6 808734 1 FAN PULLEY
7 829183 1 SHAFT BEARING
8 808821 1 KEY-SQ .187 X 1
10 829285PLT 1 SPACER-.25 X .875 X .687 PLATED
13 711206 8 BLT-HH 1/4-20 X .87 STL ZINC
14 711544 8 WSR-HELICAL 1/4
15 711015 2 SK 10-24 X .37
18 827885 1 GASKET HSG
** 827880 FAN ASSEMBLY COMPLETE
Fan Assembly
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606

Parts and Instruction Manual
Page 10
Optional Accessories
www.minutemanvac.com, a division of Enviro Safety Products | 1.800.637.6606
