Mirabelle Winter Haven MIRWH220 User manual

THANK YOU FOR CHOOSING MIRABELLE
Thank you for selecting Mirabelle. We appreciate your commitment to Mirabelle
quality. To insure that your installation proceeds smoothly, please read these
instructions before you begin. Carefully unpack and examine all of the package
contents.
Thanks again for choosing Mirabelle.
ALL INSTALLATION PROCEDURES MUST COMPLY IN STRICT ACCORDANCE
WITH APPLICABLE LOCAL PLUMBING AND BUILDING CODES.
WALL HUNG WATER CLOSET
INSTALLATION INSTRUCTIONS
WINTER HAvEN
MIRWH220

1
7” (180)
13½” (340)
9½” (240)
14¾” (375)
16½” (420)
F
4
3
2
¼” ( 51 3 )
10)½” (
7” (180)
1
OT 9312-108 31/05/2010
EDENTON WALL-HUNG WC
This bowl needs an in-wall-carrier for installation.
Please use the install instruction that comes with the
in-wall-carrier of your choice.
INSTALLATION INSTRUCTIOS
FOR MIRED220WH
15 ” (228)
3
13½” (340)
9½” (240)
14¾” (375)
16½” (420)
F
This bowl requires an in-wall tank system for
installation. Please use the install instructions
that come with the in-wall tank system of your
choice.
BEFORE YOU BEGIN
• Carefully inspect the new toilet for damage.
BEFORE YOU BEGIN
• Carefully inspect the new toilet for damage.
• If the existing toilet does not have a supply
shut-off valve below the tank, install one
before installing the new toilet.
1. REMOVE THE EXISTING TOILET
• Turn off water supply.
• Flush toilet, then sponge out all remaining
water from tank.
• Disconnect supply shut-off valve (if present),
and remove old tank and bowl.
TOOLS AND MATERIALS
10 “ Adjustable wrench
Supply shut-off valve
Tape measure
Level
Sponge
Wax seal
5/16” Bolts w/nuts and
washers
Putty knife
1/2” Nut driver/socket
Hacksaw
Screwdriver
CAUTION
Risk of personal injury or
product damage.
Handle with care. Vitreous china can break
or chip if the product is handled carelessly.
CAUTION
Risk of hazardous gases.
If the new toilet is not installed immediately,
temporarily stuff a rag in the closet flange.
21
• Remove old wax seal from floor with
a putty knife.
• Replace old bolts with the new 5/16”
diameter bolts.
Putty knife
Old wax seal
Flange
Flange
5/16” Diameter bolts
CAUTION: PRODUCT IS FRAGILE.
TO AvOID BREAKAGE AND POSSIBLE
INJURY HANDLE WITH CARE!

2
Critical dimensions below (and on previous page) are calculated using 16-1/2” chair height for bowl.

WARRANTY
3
IMPORTANT CONSUMER
INFORMATION
5
WARRANTY
WHAT IS COVERED?
Wolseley North America “Wolseley” or the
“Company” warrants its products to be free
from defects in material and workmanship
under normal use and service FOR A PERIOD
OF ONE (1) YEAR FROM THE DATE OF
INSTALLATION.
WHAT IS NOT COVERED?
The warranty set forth in paragraph 1 does
not cover installation or any other labor
charges and does not apply to products which
have been damaged as a result of any
accident, abuse, improper installation or
maintenance, or modification of original
plumbing product. The warranty of such
products is limited to the warranty extended to
Wolseley by the product manufacturer. Finally,
WOLSELEY NORTH AMERICA SHALL NOT BE
RESPONSIBLE OR LIABLE FOR ANY FAILURE
OR DAMAGE TO THIS PRODUCT OR ANY
COMPONENT THEREOF CAUSED BY THE
USE OF ABRASIVE CLEANERS.
HOW TO OBTAIN WARRANTY SERVICE
The purchaser should contact their local
Wolseley location, installing contractor or
builder from whom the product was
purchased or upon written request addressed
to Wolseley North America 12500 Jefferson
Avenue, Newport News, VA 23602, Attention
Consumer Affairs. Any shipping charges,
associated with warranty service, must be
prepared by the consumer. In all cases, proof
of purchase will be required.
LIMITATIONS OF IMPLIED WARRANTY AND
DISCLAIMER OF CONSEQUENTIAL OR
INCIDENTAL DAMAGES WOLSELEY NORTH
AMERICA DISCLAIMS ANY LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL
DAMAGES AND DISCLAIMS ALL EXPRESS OR
IMPLIED WARRANTIES, INCLUDING THOSE
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, AS SET FORTH
ABOVE. IMPLIED WARRANTIES OF THE
PRODUCTS AND PRODUCT COMPONENTS
SET FORTH IN PARAGRAPH 1 ABOVE ARE
LIMITED TO THE DURATIONS OF THE
RESPECTIVE WARRANTY. Some states do not
allow the exclusion or limitation of incidental
or consequential damages or limitations on
how long an implied warranty lasts, so the
above limitations may not apply to you. This
warranty gives you specific legal rights and
you may also have other rights, which vary
from state to state.
Attention Installer:
Recommended water pressure is 20 psi.
Care and Cleaning
Clean the outside surface of your vitreous china
water closet with mild soap and warm water.
Wipe the entire surface completely dry with a
clean soft cloth. You may use soft abrasive
cleaners when necessary to clean your water
closet. Wipe any splashes of cleaning
solutions from plastic or plated surfaces
immediately. Use water closet cleaners on the
inside of the bowl only.
If the vitreous china surface becomes
excessively dirty, use a general purpose
cleaner such as: Fantastic, Basin Tub and Tile
Cleaner, Soft Scrub, Disinfectant Bathroom
Cleaner, Spic and Span Liquid, Scrubbing
Bubbles, or Bon Ami. Over time, hard water
deposits may clog water closet rim bowl rinse
holes and trapways. To clean, use a
commercial cleaner that is recommended for
removing hard water deposits. Follow the
cleaner manufacturer’s instructions for use.
Mirabelle shall not be responsible or liable
for any tank fitting damage caused by the use
of cleaners containing chlorine (calcium
hypochlorite).
IMPORTANT CONSUMER INFORMATION
6
CAUTION
Risk of product damage.
DO NOT use strong abrasive cleaners, as
they will scratch and dull the surface.
WARNING
Risk of product damage.
DO NOT use in-tank cleaners in your
water closet. Products containing chlorine
(calcium hypochlorite) can seriously
damage fittings in the tank. This damage
can cause leakage and property damage.
5
WARRANTY
WHAT IS COVERED?
Wolseley North America “Wolseley” or the
“Company” warrants its products to be free
from defects in material and workmanship
under normal use and service FOR A PERIOD
OF ONE (1) YEAR FROM THE DATE OF
INSTALLATION.
WHAT IS NOT COVERED?
The warranty set forth in paragraph 1 does
not cover installation or any other labor
charges and does not apply to products which
have been damaged as a result of any
accident, abuse, improper installation or
maintenance, or modification of original
plumbing product. The warranty of such
products is limited to the warranty extended to
Wolseley by the product manufacturer. Finally,
WOLSELEY NORTH AMERICA SHALL NOT BE
RESPONSIBLE OR LIABLE FOR ANY FAILURE
OR DAMAGE TO THIS PRODUCT OR ANY
COMPONENT THEREOF CAUSED BY THE
USE OF ABRASIVE CLEANERS.
HOW TO OBTAIN WARRANTY SERVICE
The purchaser should contact their local
Wolseley location, installing contractor or
builder from whom the product was
purchased or upon written request addressed
to Wolseley North America 12500 Jefferson
Avenue, Newport News, VA 23602, Attention
Consumer Affairs. Any shipping charges,
associated with warranty service, must be
prepared by the consumer. In all cases, proof
of purchase will be required.
LIMITATIONS OF IMPLIED WARRANTY AND
DISCLAIMER OF CONSEQUENTIAL OR
INCIDENTAL DAMAGES WOLSELEY NORTH
AMERICA DISCLAIMS ANY LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL
DAMAGES AND DISCLAIMS ALL EXPRESS OR
IMPLIED WARRANTIES, INCLUDING THOSE
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, AS SET FORTH
ABOVE. IMPLIED WARRANTIES OF THE
PRODUCTS AND PRODUCT COMPONENTS
SET FORTH IN PARAGRAPH 1 ABOVE ARE
LIMITED TO THE DURATIONS OF THE
RESPECTIVE WARRANTY. Some states do not
allow the exclusion or limitation of incidental
or consequential damages or limitations on
how long an implied warranty lasts, so the
above limitations may not apply to you. This
warranty gives you specific legal rights and
you may also have other rights, which vary
from state to state.
Attention Installer:
Recommended water pressure is 20 psi.
Care and Cleaning
Clean the outside surface of your vitreous china
water closet with mild soap and warm water.
Wipe the entire surface completely dry with a
clean soft cloth. You may use soft abrasive
cleaners when necessary to clean your water
closet. Wipe any splashes of cleaning
solutions from plastic or plated surfaces
immediately. Use water closet cleaners on the
inside of the bowl only.
If the vitreous china surface becomes
excessively dirty, use a general purpose
cleaner such as: Fantastic, Basin Tub and Tile
Cleaner, Soft Scrub, Disinfectant Bathroom
Cleaner, Spic and Span Liquid, Scrubbing
Bubbles, or Bon Ami. Over time, hard water
deposits may clog water closet rim bowl rinse
holes and trapways. To clean, use a
commercial cleaner that is recommended for
removing hard water deposits. Follow the
cleaner manufacturer’s instructions for use.
Mirabelle shall not be responsible or liable
for any tank fitting damage caused by the use
of cleaners containing chlorine (calcium
hypochlorite).
IMPORTANT CONSUMER INFORMATION
6
CAUTION
Risk of product damage.
DO NOT use strong abrasive cleaners, as
they will scratch and dull the surface.
WARNING
Risk of product damage.
DO NOT use in-tank cleaners in your
water closet. Products containing chlorine
(calcium hypochlorite) can seriously
damage fittings in the tank. This damage
can cause leakage and property damage.
WHAT IS COVERED?
Wolseley North America “Wolseley” or the “Company”
warrants its products to be free from defects in material
and workmanship under normal use and service FOR A
PERIOD OF ONE (1) YEAR FROM THE DATE OF
INSTALLATION.
WHAT IS NOT COVERED?
The warranty set forth in paragraph 1 does not cover
installation or any other labor charges and does not apply
to products which have been damaged as a result of any
accident, abuse, improper installation or maintenance, or
modification of original plumbing product. The warranty
of such products is limited to the warranty extended to
Wolseley by the product manufacturer. Finally, WOLSELEY
NORTH AMERICA SHALL NOT BE RESPONSIBLE OR
LIABLE FOR ANY FAILURE OR DAMAGE TO THIS
PRODUCT OR ANY COMPONENT THEREOF CAUSED BY
THE USE OF ABRASIVE CLEANERS.
HOW TO OBTAIN WARRANTY SERVICE
The purchaser should contact their local Wolseley location,
installing contractor or builder from whom the product was
purchased or upon written request addressed to Wolseley
North America 12500 Jefferson Avenue, Newport News, VA
23602, Attention Consumer Affairs. Any shipping charges,
associated with warranty service, must be prepared by the
consumer. In all cases, proof of purchase will be required.
LIMITATIONS OF IMPLIED WARRANTY AND DISCLAIMER
OF CONSEQUENTIAL OR INCIDENTAL DAMAGES
WOLSELEY NORTH AMERICA DISCLAIMS ANY LIABILITY
FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES AND
DISCLAIMS ALL EXPRESS OR IMPLIED WARRANTIES,
INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, AS SET FORTH
ABOVE. IMPLIED WARRANTIES OF THE PRODUCTS AND
PRODUCT COMPONENTS SET FORTH IN PARAGRAPH
1 ABOVE ARE LIMITED TO THE DURATIONS OF THE
RESPECTIVE WARRANTY. Some states do not allow the
exclusion or limitation of incidental or consequential
damages or limitations on how long an implied warranty
lasts, so the above limitations may not apply to you. This
warranty gives you specific legal rights and you may also
have other rights, which vary from state to state.
Attention Installer:
Recommended water pressure is 20 psi.
CARE AND ClEANINg
Clean the outside surface of your vitreous china water
closet with mild soap and warm water.
Wipe the entire surface completely dry with a clean soft
cloth. You may use soft abrasive cleaners when necessary
to clean your water closet. Wipe any splashes of cleaning
solutions from plastic or plated surfaces immediately. Use
water closet cleaners on the inside of the bowl only.
If the vitreous china surface becomes excessively dirty,
use a general purpose cleaner such as: Fantastic, Basin
Tub and Tile Cleaner, Soft Scrub, Disinfectant Bathroom
Cleaner, Spic and Span Liquid, Scrubbing Bubbles, or
Bon Ami. Over time, hard water deposits may clog water
closet rim bowl rinse holes and trapways. To clean, use
a commercial cleaner that is recommended for removing
hard water deposits. Follow the cleaner manufacturer’s
instructions for use.
Mirabelle shall not be responsible or liable for any tank
fitting damage caused by the use of cleaners containing
chlorine (calcium hypochlorite).
©2010 Ferguson Enterprises, Inc. All Rights Reserved 5847 08/10
