Mist MFS092 User manual

UNDERSINK FILTER
INSTALLATION MANUAL
Your filter specs:
THANK YOU FOR CHOOSING
MIST FILTERS
Model: MFS092
Tested and Certified by IAMPO R&T
against NSF/ANSI 42 Standard for
material safety, structural integrity and
aesthetic chlorine reduction.
FILTER LIFE
20,000 gallons
FLOW RATE
1.5 gpm / 60 psi
OPERATING
PRESSURE
30-120 psi
OPERATING
TEMPERATURE
40-100˚F
Do not use with water that is microbiologicallly unsafe or of
unknown quality without adequate disinfection before or after the system.

First, let’s determine the under-kitchen compression water
inlet size. You could find either a 1/2” or 3/8” OD compression
inlet valve under the kitchen cabinet.
1. The quick-connect connectors can be found on both sides of the filter
head. Insert the inlet and outlet water hoses as instructed; push them in
until you feel a “Click” action.
Please check the following images and pick out the
suitable accessories and adapters that work best with your
current under kitchen layout.
FOR 1/2” FIP OUTLET VALVE, please get the compression hose
to 1/2” FIP adapter and adapter 3/8” ready.
For the 3/8” OD Coompression outlet valve, you do NOT need to use any of the compression
hose adapters.
1/2” FIP Outlet 3/8” Compression Outlet
INSTALLATION STEPS
INSTALLATION PREPARATION
2. Find the desired location to mount the
water filtration system.
3. Place the installation template at the
desired location with at least 4 inches of
space between the boom of the filter
cartridge and the floor.
4. Drill through the holes marked on the template; leave
1/3” length of the screws outside for aaching the filter
head. Remove and discard the template after drilling.

If the water inlet valve is a 3/8” compression connection, you can connect
the system directly.
outlet hose
is 3/8”
faucet
hose
INSTALLATION STEPS: 1/2” FIP OUTLETINSTALLATION STEPS: 3/8””
1. Turn off the water inlet valve; leave the
faucet ON. Place a towel under your water
inlet valve to catch any dripping water.
3. Connect the filtration system’s
inlet hose with the water inlet valve.
4. Connect the faucet hose with the filtration
system’s outlet hose to complete the setup.
5. Make sure the faucet is turned on and
then turn the water inlet valve
back on to flush the new system for 5
minutes to condition the new filter.
6. Turn off the faucet to pressurize the new
connected system and check
for any possible leakage.
2. Disconnect the faucet
hose from the water inlet valve.
angle valve
outlet is 3/8”
If it is a 1/2” FIP water inlet valve, please get the 1/2” FIP to 3/8” compression adapter.
2. Disconnect the faucet hose from the water inlet valve, aach the 1/2” FIP to
3/8” compression adapter. Make sure the O ring is in postion; apply Teflon
tape at a clockwise direction 7 times only if needed
1. Turn off the water inlet valve; leave the
faucet ON. Place a towel under your water
inlet valve to catch any dripping water.
3. Connect the filter system’s water inlet
hose onto the adapter.
4. Aach the 3/8” compression to 1/2” FIP
adapter onto the filter system’s outlet hose, then
connect the faucet’s hose. Make sure the O ring
is in position; apply Teflon tape at a clockwise
direction 7 times only if needed.

E
A
S
Y
&
F
A
S
T
R
E
O
R
D
E
R
Use code REORDER for
10% off of your next order
FOR EASY REORDER
Use the camera app
on your smartphone
to scan this QR code
for filter replacements
Tips: It is completely normal for water to spurt out due to the trapped air inside the system.
2. Align, insert, and twist
the new filter to the right
about 1/4 turn to complete
the filter installation.
QUESTIONS? COMMENTS?
Contact us:
Mist Filters
info@mistfilters.com 888-612-2513
3. Flush about 2-3
gallons to condition
the new filter.
1. Turn about 1/4 turn to the left
to release the filter;
then remove the old filter.
FILTER REPLACEMENT
5. Make sure the faucet is turned on and
then turn the water inlet valve
back on to flush the new system for 5
minutes to condition the new filter.
6. Turn off the faucet to pressurize the new
connected system and check
for any possible leakage.
