Mitsubishi Electric CITY MULTI PKFY-P NLMU Series User manual

Air-Conditioners For Building Application
INDOOR UNIT
PKFY-P·NLMU Series
MANUEL D’UTILISATION
Pour une utilisation correcte sans risques, veuillez lire le manuel d’utilisation en entier avant de vous servir du
climatiseur.
OPERATION MANUAL
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
MANUAL DE INSTRUCCIONES
Lea este manual de instrucciones hasta el nal antes de poner en marcha la unidad de aire acondicionado para
garantizar un uso seguro y correcto.
POUR L’UTILISATEUR
FOR USER
PARA EL USUARIO
English
Español
Français
RH79A033H01_en.indd 1 2019/11/21 13:06:57
001

1
Contents
1. Safety Precautions
Before installing the unit, make sure you read all the
“Safety Precautions”.
The “Safety Precautions” provide very important
points regarding safety. Make sure you follow them.
Please report to or take consent by the supply
authority before connection to the system.
• Do not operate the unit for a long time in high humidity, e.g.
leaving a door or window open. In the cool mode, if the unit is
operated in a room with high humidity (80% RH or more) for a
long time, water condensed in the air conditioner may drop and
wet or damage furniture, etc.
• Do not touch the upper air outlet vane or the lower air outlet
damper during operation. Otherwise, condensation may form and
the unit may stop operating.
Caution:
• Do not use any sharp object to push the buttons, as this may
damage the remote controller.
• Never block or cover the indoor or outdoor unit’s air inlets or
outlets.
• Never wipe the remote controller with benzene, thinner chemical
rags, etc.
• This appliance is intended to be used by expert or trained users
in shops, in light industry and on farms, or for commercial use by
lay persons.
• Children should be supervised to ensure that they do not play
with the air conditioner.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• When installing or relocating, or servicing the air conditioner, use
only the specified refrigerant (R410A) to charge the refrigerant
lines. Do not mix it with any other refrigerant and do not allow air
to remain in the lines.
If air is mixed with the refrigerant, then it can be the cause of
abnormal high pressure in the refrigerant line, and may result in
an explosion and other hazards. The use of any refrigerant other
than that specified for the system will cause mechanical failure
or system malfunction or unit breakdown. In the worst case, this
could lead to a serious impediment to securing product safety.
Warning:
• These appliances are not accessible to the general public.
• The unit must not be installed by the user. Ask the dealer or an
authorized company to install the unit. If the unit is installed
improperly, water leakage, electric shock or fire may result.
• Do not alter the unit. It may cause fire, electric shock, injury or
water leakage.
• Do not stand on, or place any items on the unit.
• Do not splash water over the unit and do not touch the unit with
wet hands. An electric shock may result.
• Do not spray combustible gas close to the unit. Fire may result.
• Do not place a gas heater or any other open-flame appliance
where it will be exposed to the air discharged from the unit.
Incomplete combustion may result.
• Do not remove the front panel or the fan guard from the outdoor
unit when it is running.
• Never repair the unit or transfer it to another site by yourself.
• When you notice exceptionally abnormal noise or vibration, stop
operation, turn off the power switch, and contact your dealer.
• Never insert fingers, sticks etc. into the air inlets or outlets.
• If you detect odd smells, stop using the unit, turn off the power
switch and consult your dealer. Otherwise, a breakdown, electric
shock or fire may result.
• This air conditioner is NOT intended for use by children or infirm
persons without supervision.
• If the refrigeration gas blows out or leaks, stop the operation of
the air conditioner, thoroughly ventilate the room, and contact
your dealer.
Symbols used in the text
Warning:
Describes precautions that should be observed to prevent danger
of injury or death to the user.
Caution:
Describes precautions that should be observed to prevent damage
to the unit.
Symbols used in the illustrations
: Indicates a part which must be grounded.
1. Safety Precautions .................................................................1
2. Parts Names...........................................................................2
3. Operation................................................................................7
4. Timer.....................................................................................10
5. Emergency Operation for Wireless Remote-controller.........10
6. Care and Cleaning................................................................11
7. Troubleshooting....................................................................13
8. Specifications .......................................................................15
Note:
The phrase “Wired remote controller” in this operation manual refers to the PAR-40MAA.
If you need any information for the other remote controller, please refer to the instruction book included in this box.
Disposing of the unit
When you need to dispose of the unit, consult your dealer.
en
RH79A033H01_en.indd 1 2019/11/21 13:06:57
002

2
2. Parts Names
■Indoor Unit
PKFY-P·NLMU
Fan speed 4 speed + Auto
Vane Steps 5 steps
Auto swing
Louver Manual
Filter Normal
Filter cleaning indication 100 hr
Enter the model setting number for
the indoor unit you want to operate.* 065 (001)
* For systems that are capable of simultaneous cooling and heating operation, use the setting indicated in parentheses ( ).
For details on the setting procedure, refer to the Installation Manual.
Filter Air intake
VaneAir outletLouver
en
RH79A033H01_en.indd 2 2019/11/21 13:06:57
003

3
2. Parts Names
MENU ON
OFF
RETURN SELECT
HOLD
■Wired Remote Controller
The functions of the function buttons change depending on the
screen.
Refer to the button function guide that appears at the bottom of the
LCD for the functions they serve on a given screen.
When the system is centrally controlled, the button function guide
that corresponds to the locked button will not appear.
▌1[ON/OFF] button
Press to turn ON/OFF the indoor unit.
▌2[SELECT/HOLD] button
Press to save the setting.
When the Main menu is displayed, pressing this button will enable/
disable the HOLD function.
▌3[RETURN] button
Press to return to the previous screen.
▌4[MENU] button
Press to bring up the Main menu.
▌5Backlit LCD
Operation settings will appear.
When the backlight is off, pressing any button turns the backlight on
and it will stay lit for a certain period of time depending on the screen.
When the backlight is off, pressing any button turns the backlight on
and does not perform its function. (except for the [ON/OFF] button)
▌6ON/OFF lamp
This lamp lights up in green while the unit is in operation. It blinks while
the remote controller is starting up or when there is an error.
▌7Function button [F1]
Main display: Press to change the operation mode.
Menu screen: The button function varies with the screen.
▌8Function button [F2]
Main display: Press to decrease temperature.
Main menu: Press to move the cursor left.
Menu screen: The button function varies with the screen.
▌9Function button [F3]
Main display: Press to increase temperature.
Main menu: Press to move the cursor right.
▌0Function button [F4]
Main display: Press to change the fan speed.
Controller interface
Main display
Menu screen
Function guide
Main menu
83
83
Fri
Room
Set temp.
Mode Temp. Fan
Cool Auto
Main Main menu
Energy saving
Main display:
Cursor
Operation
Vane·Louver·Vent. (Lossnay)
High power
Comfort
RETURN
7890
7890
7890
4 32 1
5
6
7890
Function buttons
en
RH79A033H01_en.indd 3 2019/11/21 13:06:58
004

4
2. Parts Names
Fri
Cool
Mode Temp. Fan
Set temp. Auto
83
Fri
Mode Temp. Fan
Room
Cool Set temp. Auto
83
83
The main display can be displayed in two different modes: “Full” and “Basic”. The factory setting is “Full”. To switch to the “Basic” mode, change the
setting on the Main display setting. (Refer to operation manual included with remote controller.)
▌1Operation mode
▌2Preset temperature
▌3Clock
▌4Fan speed
▌5Button function guide
Functions of the corresponding buttons appear here.
▌6
Appears when the ON/OFF operation is centrally controlled.
▌7
Appears when the operation mode is centrally controlled.
▌8
Appears when the preset temperature is centrally controlled.
▌9
Appears when the filter reset function is centrally controlled.
▌0
Indicates when filter needs maintenance.
▌1Room temperature
▌2
Appears when the buttons are locked.
▌3
Appears when the On/Off timer or Auto-off timer function is enabled.
appears when the timer is disabled by the centralized control
system.
appears when the HOLD function is enabled.
<Full mode>
* All icons are displayed for explanation.
<Basic mode>
4
3
2!
1
5
6
#
7
8
90
1
3
9
4
)
@
$2
1
#
5
▌4
Appears when the Weekly timer is enabled.
▌5
Appears while the units are operated in the energy-save mode. (Will
not appear on some models of indoor units)
▌6
Appears while the outdoor units are operated in the silent mode.
(This indication is not available for CITY MULTI models)
▌7
Appears when the built-in thermistor on the remote controller is
activated to monitor the room temperature (1).
appears when the thermistor on the indoor unit is activated to
monitor the room temperature.
▌8
Indicates the vane setting.
▌9
Indicates the louver setting.
▌)
Indicates the ventilation setting.
▌!
Appears when the preset temperature range is restricted.
▌@
Appears when an energy-saving operation is performed using a “3D i-See
sensor” function.
▌#Centrally controlled
Appears for a certain period of time when a centrally-controlled item is
operated.
▌$Preliminary error display
An error code appears during the preliminary error.
Display
Most settings (except ON/OFF, mode, fan speed, temperature)
can be made from the Main menu. (Refer to Page 9.)
32$45 6 7 8
en
RH79A033H01_en.indd 4 2019/11/21 13:06:58
005

5
2. Parts Names
■Wireless Remote-Controller (Optional parts)
Temperature setting
The units of temperature can be changed. For
details, refer to the Installation manual.
Not available
Appears when a non-supported func-
tion is selected.
Battery replacement indicator
Appears when the remaining battery
power is low.
Vane setting
Step 1 Step 2 Step 3 Step 4 Step 5 Swing Auto
Fan speed setting
Set Temperature buttons
Set Time button (Sets the time)
Airfl ow button (Changes up/down airfl ow direction)
Mode button (Changes operation mode)
Timer ON button
Timer OFF button
OFF/ON button
Fan Speed button (Changes fan speed)
SET/SEND button
CANCEL button
Up/Down buttons
Menu button
i-see button (not available)
Reset button
Remote controller display
Battery replacement indicator
Transmission area
Not available
Weekly timer ON/OFF button
(not available)
Operation mode
Cool Dry
Fan
Auto
(single set
point)
Heat
Auto*
(dual set
point)
* The initial setting is necessary.
Refer to Installation manual.
LOUVER button (not available)
en
RH79A033H01_en.indd 5 2019/11/21 13:07:00
006

6
Notes (Only for wireless remote controller):
When using the wireless remote controller, point it towards the receiver on the indoor unit.
If the remote controller is operated within approximately 2 minutes after power is supplied to
the indoor unit, the indoor unit may beep twice as the unit is performing the initial automatic
check.
The indoor unit beeps to confirm that the signal transmitted from the remote controller has
been received. Signals can be received up to approximately 7 meters, 23 feet in a direct line
from the indoor unit in an area 45° to the left and right of the unit. However, illumination such
as fluorescent lights and strong light can affect the ability of the indoor unit to receive signals.
If the operation lamp near the receiver on the indoor unit is blinking, the unit needs to be in-
spected. Consult your dealer for service.
Handle the remote controller carefully! Do not drop the remote controller or subject it to strong
shocks. In addition, do not get the remote controller wet or leave it in a location with high hu-
midity.
To avoid misplacing the remote controller, install the holder included with the remote controller
on a wall and be sure to always place the remote controller in the holder after use.
If the indoor unit beeps 4 times when you are using the wireless remote controller, switch the
auto mode setting to the AUTO (single set point) mode or AUTO (dual set point) mode.
For details, refer to the included Notice (A5 sheet) or the Installation Manual.
Battery installation/replacement
1. Remove the top cover, insert two LR6 AA
batteries, and then install the top cover.
2. Press the Reset button.
1
2
3
Press the Reset button with an
object that has a narrow end.
Top cover
Two LR6 AA batteries
Insert the negative (–) end of
each battery first. Install the
batteries in the correct directions
(+, –)!
After battery installation/replacement, please
set clock.
Without setting clock, you cannot use a part
of function of remote controller.
2. Parts Names
en
RH79A033H01_en.indd 6 2019/11/21 13:07:00
007

7
■About the operation method, refer to the operation manual that comes with each remote controller.
3.1. Turning ON/OFF
[ON] [OFF]
C001
C002
Press the [ON/OFF] button.
The ON/OFF lamp will light up in
green, and the operation will start.
When “LED lighting” is set to “No”,
the ON/OFF lamp will not light up.
Press the [ON/OFF] button again.
The ON/OFF lamp will come off,
and the operation will stop.
■Operation status memory
Remote controller setting
Operation mode Operation mode before the power was turned off
Preset temperature Preset temperature before the power was turned off
Fan speed Fan speed before the power was turned off
■Settable preset temperature range
Operation mode Preset temperature range
Cool/Dry 19 – 30 ºC/67 – 87 °F
Heat 17 – 28 ºC/63 – 83 °F
Auto (Single set point) 19 – 28 ºC/67 – 83 °F
Auto (Dual set points) [Cool] Preset temperature range for the Cool mode
[Heat] Preset temperature range for the Heat mode
Fan/Ventilation Not settable
Note:
Even if you press the ON/OFF button immediately after shutting down the operation is progress, the air conditioner will not start for about 3 minutes.
This is to prevent the internal components from being damaged.
The settable temperature range varies with the model of outdoor units and remote controller.
3. Operation
What the blinking mode icon means
The mode icon will blink when other indoor units in the same refrigerant
system (connected to the same outdoor unit) are already operated in a
different mode. In this case, the rest of the unit in the same group can
only be operated in the same mode.
Press the [F2] button to decrease the preset temperature, and press the
[F3] button to increase.
• Refer to the table on this page for the settable temperature range for
different operation modes.
• Preset temperature range cannot be set for Fan/Ventilation operation.
• Preset temperature will be displayed either in Centigrade in 0.5- or
1-degree, Fahrenheit in 1-2 degree increments, or in Fahrenheit, de-
pending on the indoor unit model and the display mode setting on the
remote controller.
Automatic operation (single set point)
■According to a set temperature, cooling operation starts if the room
temperature is too hot and heating operation starts if the room
temperature is too cold.
■During automatic operation, if the room temperature changes and
remains 1.5°C, 4°F or more above the set temperature for 3 minutes,
the air conditioner switches to cool mode. In the same way, if the room
temperature remains 1.5°C, 4°F or more below the set temperature for
3 minutes, the air conditioner switches to heat mode.
Cool mode 3 minutes (switches
from heating to cooling)
Set temperature +1.5°C, +4°F
Set temperature
Set temperature -1.5°C, -4°F
3 minutes (switches
from cooling to heating)
■Because the room temperature is automatically adjusted in order to
maintain a fixed effective temperature, cooling operation is performed
a few degrees warmer and heating operation is performed a few
degrees cooler than the set room temperature once the temperature is
reached (automatic energy-saving operation).
3.2. Mode Selection
Each pressing of the [F1] button cycles
through the following operation modes.
Select the desired operation mode.
• Operation modes that are not available
to the connected outdoor unit models will
not appear on the display.
Cool
Auto
Drying
Heat
Fan
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
83
83
MENU
ON
OFF
RETURN SELECT
HOLD
Setback
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
83
83
MENU
ON
OFF
RETURN SELECT
HOLD
Operation mode
Room temperature (Refer to the Installation Manual.)
3.3. Temperature setting
<Cool, Dry, Heat, and Auto (Single set point)>
en
RH79A033H01_en.indd 7 2019/11/21 13:07:03
008

8
2Press the [F1] or [F2] button to move the cursor to the desired
temperature setting (cooling or heating).
Press the [F3] button to decrease the selected temperature, and [F4]
to increase.
• Refer to the table on page 7 for the settable temperature range for
different operation modes.
• The preset temperature settings for cooling and heating in the
Auto (dual set point) mode are also used by the Cool/Dry and Heat
modes.
• The preset temperatures for cooling and heating in the Auto (dual
set point) mode must meet the conditions below:
• Preset cooling temperature is higher than preset heating temperature.
• The minimum temperature difference requirement between cooling and
heating preset temperatures (varies with the models of indoor units
connected) is met.
* If preset temperatures are set in a way that does not meet the minimum
temperature difference requirement, both preset temperatures will
automatically be changed within the allowable setting ranges.
Navigating through the screens
• To return to the Main screen ...... [RETURN] button
<Auto operation (dual set point) mode>
When the operation mode is set to the Auto (dual set point) mode, two
preset temperatures (one each for cooling and heating) can be set.
Depending on the room temperature, indoor unit will automatically
operate in either the Cool or Heat mode and keep the room temperature
within the preset range.
The graph below shows the operation pattern of indoor unit operated in
the Auto (dual set point) mode.
Operation pattern during Auto (dual set point) mode
HEAT COOL HEAT COOL
Preset temp.
(COOL)
Preset temp.
(HEAT)
Room
temperature
The room temperature
changes corresponding
to the change in the
outside temperature.
Press [F2] to move the cursor left.
Press [F3] to move the cursor right.
Auto
<Auto (dual set point) mode>
68
83
79
MENU
ON
OFF
RETURN SELECT
HOLD
Preset temperature
for cooling
Preset temperature
for heating
1 The current preset temperatures will appear. Press the [F2] or [F3]
button to display the setting screen.
MENU
ON
OFF
RETURN SELECT
HOLD
68
83
RETURN
Set temp.
Preset temperature
for cooling
Preset temperature
for heating
83
68
3.4. Fan speed setting
MENU
ON
OFF
RETURN SELECT
HOLD
83
83
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
Each pressing of the [F4] button cycles through the following fan speeds.
• The available fan speeds depend on the models of connected indoor
units.
Note:
The number of available fan speeds depends on the type of unit
connected. Note also that some units do not provide an “Auto” setting.
In the following cases, the actual fan speed generated by the unit will differ
from the speed shown the remote controller display.
1. While the display is showing “STAND BY” or “DEFROST”.
2. When the temperature of the heat exchanger is low in the heat mode.
(e.g. immediately after heat operation starts)
3. In HEAT mode, when room temperature is higher than the temperature
setting.
4. When the unit is in DRY mode.
Press the [MENU] button on the
Main display.
The Main menu will appear.
3.5. Airflow direction setting
3.5.1 Navigating through the Main menu
<Accessing the Main menu>
<Item selection>
Main Main menu
Operation
MENU
ON
OFF
RETURN SELECT
HOLD
MENU
ON
OFF
RETURN SELECT
HOLD
Main Main menu
Initial setting
Cursor
3. Operation
en
RH79A033H01_en.indd 8 2019/11/21 13:07:04
009

9
3. Operation
<Exiting the Main menu screen>
MENU
ON
OFF
RETURN SELECT
HOLD
83
83
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
<Display of unsupported functions>
Title
Not available
Unsupported function
Return: RETURN
MENU
ON
OFF
RETURN SELECT
HOLD
The message at left will appear if
the user selects a function not sup-
ported by the corresponding indoor
unit model.
If no buttons are touched for
10 minutes, the screen will
automatically return to the Main
display. Any settings that have not
been saved will be lost.
Press the [RETURN] button to exit
the Main menu and return to the
Main display.
3.5.2 Vane·Vent. (Lossnay)
<Accessing the menu>
MENU
ON
OFF
RETURN SELECT
HOLD
Main Main menu
Operation
MENU
ON
OFF
RETURN SELECT
HOLD
Main menu: RETURN
Cursor
Operation
Vane·Louver·Vent. (Lossnay)
High power
Comfort
<Vane setting>
MENU
ON
OFF
RETURN SELECT
HOLD
Fri
Off
Vent.Vane
Swing
(Sample screen on CITY MULTI)
Select “Operation” from the Main
menu (refer to page 8), and press
the [SELECT/HOLD] button.
Select “Vane·Louver·Vent. (Loss-
nay)” from the Operation menu, and
press the [SELECT/HOLD] button.
Press the [F1] or [F2] button to go
through the vane setting options:
“Auto”, “Step 1”, “Step 2”, “Step 3”,
“Step 4”, “Step 5” and “Swing”.
Select the desired setting.
Auto
Swing
Select “Swing” to move the vanes
up and down automatically.
When set to “Step 1” through “Step
5”, the vane will be xed at the se-
lected angle.
• under the vane setting icon
This icon will appear when the
vane is set to “Step 5” and the
fan operates at low speed during
cooling or drying operation
(depends on the model).
The icon will go off in an hour, and
the vane setting will automatically
change.
Auto
Step 3
Swing
Step 1
Step 4
Step 2
Step 5
83
83
Fri
Room
Set temp.
Mode Temp. Fan
Cool Auto
<Ventilation setting>
Fri
Low
Vent.
MENU
ON
OFF
RETURN SELECT
HOLD
Press the [F3] button to go through
the ventilation setting options in the
order of “Off”, “Low”, and “High”.
* Settable only when Lossnay unit is
connected.
Off Low High
Off Low High
• The fan on some models of indoor
units may be interlocked with
certain models of ventilation units.
en
RH79A033H01_en.indd 9 2019/11/21 13:07:05
010

10
3. Operation
<Returning to the Operation menu>
Note:
● During swing operation, the directional indication on the screen
does not change in sync with the directional vanes on the unit.
●Available directions depend on the type of unit connected.
●In the following cases, the actual air direction will differ from the
direction indicated on the remote controller display.
1. While the display is in “STAND BY” or “DEFROST” states.
2. Immediately after starting heat mode (while the system is wait-
ing for the mode change to take effect).
3. In heat mode, when room temperature is higher than the tem-
perature setting.
4. Timer
■Timer functions are different by each remote controller.
■For details on how to operate the remote controller, refer to the appropriate operation manual included with each remote controller.
<[Manual] To Change the Airflow's Left/Right Direction>
* The louver button cannot be used.
• Stop the unit operation, hold the lever of the
louver, and adjust to the desired direction.
* Do not set to the inside direction when the
unit is in the cooling or drying mode because
there is a risk of condensation and water
dripping.
Caution:
To prevent falls, maintain a stable footing when operating the unit.
3.6. Ventilation
For LOSSNAY combination
■The following 2 patterns of operation is available.
•Run the ventilator together with indoor unit.
•Run the ventilator independently.
Note: (for wireless remote controller)
● Running the ventilator independently is not available.
● No indication on the remote controller.
When the remote controller cannot be used
When the batteries of the remote controller run out or the remote
controller malfunctions, the emergency operation can be done using the
emergency buttons on the grille.
ASTANDBY lamp
BOPERATING lamp
CEmergency operation cooling switch
DEmergency operation heating switch
EReceiver
Starting operation
•
To operate the cooling mode, press the button Cfor more than 2 seconds.
• To operate the heating mode, press the button Dfor more than 2 seconds.
• Lighting of the OPERATING lamp Bmeans the start of operation.
Note:
Details of emergency mode are as shown below.
Details of EMERGENCY MODE are as shown below.
Operation mode COOL HEAT
Set temperature 24°C, 75°F 24°C, 75°F
Fan speed High High
Airflow direction Horizontal (Step 1) Downward (Step 5)
Stopping operation
• To stop operation, press the button Cor the button Dfor more
than 2 seconds.
DC
E
B
A
5. Emergency Operation for Wireless Remote-controller
Press the [RETURN] button to go
back to the Operation menu.
MENU
ON
OFF
RETURN SELECT
HOLD
Main menu: RETURN
Cursor
Operation
Vane·Louver·Vent. (Lossnay)
High power
Comfort
en
RH79A033H01_en.indd 10 2019/11/21 13:07:05
011

11
6. Care and Cleaning
■Filter information
83
83
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri will appear on the Main display
in the Full mode when it is time to
clean the lters.
Wash,clean,orreplacethelters
when this sign appears.
Refer to the indoor unit Instruc-
tions Manual for details.
Select “Filter information” from the
Maintenance menu, and press the
[SELECT/HOLD] button.
Select “Maintenance” from the Main
menu, and press the [SELECT/
HOLD] button.
Press the [F4] button to reset lter
sign.
Refer to the indoor unit Instructions
Manual for how to clean the lter.
Select “OK” with the [F4] button.
A conrmation screen will appear.
Navigating through the screens
• To go back to the Main menu
....................... [MENU] button
• To return to the previous screen
....................... [RETURN] button
If two or more indoor units are connected, filter cleaning timing for each
unit may be different, depending on the filter type.
The icon will appear when the filter on the main unit is due for cleaning.
When the filter sign is reset, the cumulative operation time of all units
will be reset.
The icon is scheduled to appear after a certain duration of operation,
based on the premise that the indoor units are installed in a space with
ordinary air quality. Depending on the air quality, the filter may require
more frequent cleaning.
The cumulative time at which filter needs cleaning depends on the model.
• This indication is not available for wireless remote controller.
Caution:
• Ask authorized people to clean the filter.
►Cleaningthefilters
• Clean the filters using a vacuum cleaner. If you do not have a vacuum
cleaner, tap the filters against a solid object to knock off dirt and dust.
• If the filters are especially dirty, wash them in lukewarm water. Take
care to rinse off any detergent thoroughly and allow the filters to dry
completely before putting them back into the unit.
Caution:
• Do not dry the filters in direct sunlight or by using a heat source,
such as an electric heater: this may warp them.
• Do not wash the filters in hot water (above 50 °C, 122 °F), as this
may warp them.
• Make sure that the air filters are always installed. Operating the
unit without air filters can cause malfunction.
Caution:
• Before you start cleaning, stop operation and turn OFF the power
supply.
• Indoor units are equipped with filters to remove the dust of sucked-
in air. Clean the filters using the methods shown in the following
sketches.
Caution:
• In removing the filter, precautions must be taken to protect your
eyes from dust. Also, if you have to climb up on a stool to do the
job, be careful not to fall.
• When the filter is removed, do not touch the metallic parts inside
the indoor unit, otherwise injury may result.
When the is displayed on the
Main display in the Full mode, the
system is centrally controlled and
the lter sign cannot be reset.
Main Main menu
Maintenance
MENU
ON
OFF
RETURN SELECT
HOLD
Main menu: RETURN
Cursor
Maintenance menu
Error information
Filter information
Cleaning
MENU
ON
OFF
RETURN SELECT
HOLD
Main menu: MENU
Reset
Filter information
Press Reset button after
filter cleaning.
Please clean the filter.
MENU
ON
OFF
RETURN SELECT
HOLD
83
83
Fri
Room
Set temp.
Mode Temp. Fan
Cool Auto
OKCancel
Filter information
Reset filter sign?
Main menu: MENU
Filter information
Filter sign reset
MENU
ON
OFF
RETURN SELECT
HOLD
en
RH79A033H01_en.indd 11 2019/11/21 13:07:06
012

12
6. Care and Cleaning
1Pull both the bottom corners of the grille to open the grille, then lift
the filter.
AFilter
BGrille
A
B
Cleaning the indoor unit
• Wipe the outside of the unit with a clean, dry, soft cloth.
• Clean off any oil stains or finger marks using a neutral household
detergent (such as dishwashing liquid or laundry detergent).
Caution:
Never use gasoline, benzene, thinner, scouring powder or any type
of non-neutral detergent, as these substances may damage the
unit’s case.
en
RH79A033H01_en.indd 12 2019/11/21 13:07:07
013

13
7. Troubleshooting
Having trouble? Here is the solution. (Unit is operating normally.)
Air conditioner does not heat or cool well. ■Clean the filter. (Airflow is reduced when the filter is dirty or clogged.)
■Check the temperature adjustment and adjust the set temperature.
■Make sure that there is plenty of space around the outdoor unit. Is the
indoor unit air inlet or outlet blocked?
■Has a door or window been left open?
When heating operation starts, warm air does not blow from the indoor
unit soon.
■Warm air does not blow until the indoor unit has sufficiently warmed
up.
During heat mode, the air conditioner stops before the set room
temperature is reached.
■When the outdoor temperature is low and the humidity is high,
frost may form on the outdoor unit. If this occurs, the outdoor unit
performs a defrosting operation. Normal operation should begin after
approximately 10 minutes.
Airflow up/down direction changes during operation or airflow up/down
direction cannot be set.
■During cool mode, the vanes automatically move to the step 1 position
after 1 hour when the vane is set to “Step 2” to “Step 5”. This is to
prevent water from forming and dripping from the vanes.
■During heat mode, the vanes automatically move to the step 1
position when the airflow temperature is low or during defrosting
mode.
When the airflow up/down direction is changed, the vanes always move
up and down past the set position before finally stopping at the position.
■When the airflow up/down direction is changed, the vanes move to the
set position after detecting the base position.
A flowing water sound or occasional hissing sound is heard. ■These sounds can be heard when refrigerant is flowing in the air
conditioner or when the refrigerant flow is changing.
A cracking or creaking sound is heard. ■These sounds can be heard when parts rub against each due to
expansion and contraction from temperature changes.
The room has an unpleasant odor. ■The indoor unit draws in air that contains gases produced from the
walls, carpeting, and furniture as well as odors trapped in clothing,
and then blows this air back into the room.
A white mist or vapor is emitted from the indoor unit. ■If the indoor temperature and the humidity are high, this condition may
occur when operation starts.
■During defrosting mode, cool airflow may blow down and appear like a
mist.
Water or vapor is emitted from the outdoor unit. ■During cool mode, water may form and drip from the cool pipes and
joints.
■During heat mode, water may form and drip from the heat exchanger.
■During defrosting mode, water on the heat exchanger evaporates and
water vapor may be emitted.
The air conditioner does not operate even though the ON/OFF button
is pressed. The operation mode display on the remote controller
disappears.
■Is the power switch of the indoor unit turned off? Turn on the power
switch.
“ ” appears in the remote controller display. ■During central control, “ ” appears in the remote controller display
and air conditioner operation cannot be started or stopped using the
remote controller.
When restarting the air conditioner soon after stopping it, it does not
operate even though the ON/OFF button is pressed.
■Wait approximately 3 minutes.
(Operation has stopped to protect the air conditioner.)
Air conditioner operates without the ON/OFF button being pressed. ■Is the on timer set?
Press the ON/OFF button to stop operation.
■Is the air conditioner connected to a central remote controller?
Consult the concerned people who control the air conditioner.
■Does “ ” appear in the remote controller display?
Consult the concerned people who control the air conditioner.
■Has the auto recovery feature from power failures been set?
Press the ON/OFF button to stop operation.
Air conditioner stops without the ON/OFF button being pressed. ■Is the off timer set?
Press the ON/OFF button to restart operation.
■Is the air conditioner connected to a central remote controller?
Consult the concerned people who control the air conditioner.
■Does “ ” appear in the remote controller display?
Consult the concerned people who control the air conditioner.
Remote controller timer operation cannot be set. ■Are timer settings invalid?
If the timer can be set, or appears in the remote controller
display.
“PLEASE WAIT” appears in the remote controller display. ■The initial settings are being performed. Wait approximately 3
minutes.
An error code appears in the remote controller display. ■The protection devices have operated to protect the air conditioner.
■Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be
sure to provide the dealer with the model name and information that
appeared in the remote controller display.
Draining water or motor rotation sound is heard. ■When cooling operation stops, the drain pump operates and then
stops. Wait approximately 3 minutes.
en
RH79A033H01_en.indd 13 2019/11/21 13:07:07
014

14
7. Troubleshooting
Having trouble? Here is the solution. (Unit is operating normally.)
Noise is louder than specifications. ■The indoor operation sound level is affected by the acoustics of the
particular room as shown in the following table and will be higher than
the noise specification, which was measured in an echo-free room.
High sound-
absorbing
rooms
Normal rooms
Low sound-
absorbing
rooms
Location
examples
Broadcasting
studio, music
room, etc.
Reception
room, hotel
lobby, etc.
Office, hotel
room
Noise levels 3 to 7 dB 6 to 10 dB 9 to 13 dB
Nothing appears in the wireless remote controller display, the display
is faint, or signals are not received by the indoor unit unless the
remote controller is close.
■The batteries are low.
Replace the batteries and press the Reset button.
■If nothing appears even after the batteries are replaced, make sure that
the batteries are installed in the correct directions (+, –).
After battery installation/replacement of remote controller, part of
function cannot be used.
■Please check that the clock setting is completed. If clock setting is not
done, please complete.
The operation lamp near the receiver for the wireless remote
controller on the indoor unit is blinking. ■The self diagnosis function has operated to protect the air conditioner.
■Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be sure
to provide the dealer with the model name.
Warm air blows from the indoor unit intermittently when heating mode
is off or during fan mode. ■When another indoor unit is operating in heating mode, the control valve
opens and closes occasionally to maintain stability in the air conditioning
system. This operation will stop after a while.
* If this will cause an undesirable rise in the room temperature in small
rooms, etc., stop the operation of the indoor unit temporarily.
The wireless remote controller does not operate (the indoor unit
beeps 4 times). ■Switch the auto mode setting to the AUTO (single set point) mode or
AUTO (dual set point) mode. For details, refer to the included Notice (A5
sheet) or the Installation Manual.
Refrigerant noise is heard or warm air comes out from the suspended
indoor unit.
■A small amount of refrigerant flows into the suspended indoor unit while
other indoor units are in operation at HEAT mode.
Warning:
If the air conditioner operates but does not cool or heat (depending on model) the room, consult your dealer since there may be a
refrigerant leak. Be sure to ask the service representative whether there is refrigerant leakage or not when repairs are carried out.
The refrigerant charged in the air conditioner is safe. Refrigerant normally does not leak. However, if refrigerant gas leaks indoors, and
comes into contact with the fire of a fan heater, space heater, stove, etc., harmful substances will be generated.
en
RH79A033H01_en.indd 14 2019/11/21 13:07:07
015

15
8. Specifications
Range of application
The range of working temperatures for both the indoor and outdoor units of the series Y, R2, Multi-S is as below.
Model P04 P06 P08 P12 P15 P18
Power source (Voltage/Frequency) <V/Hz> Single, 208/230 V, 60 Hz
Capacity (Cooling/Heating) <BTU/h> 4,000/4,500 6,000/6,700 8,000/9,000 12,000/13,500 15,000/17,000 18,000/20,000
Dimension (Height) <mm (inch)> 299 (11 - 25/32) 299 (11 - 25/32)
Dimension (Width) <mm (inch)> 773 (30 - 7/16) 898 (35 - 3/8)
Dimension (Depth) <mm (inch)> 237 (9 - 11/32) 237 (9 - 11/32)
Net weight <kg (lbs)> 10.7 (23.6) 11.1 (24.5) 12.9 (28.4)
Fan Airflow rate (Low-Middle2-Middle1-High) <CFM> 117-124-134-
148
141-155-173-
191
141-162-191-
237
152-191-244-
297
222-261-304-
353
240-293-360-
438
Noise level (Low-Middle2-Middle1-High) <dB> 22-24-26-28 22-26-29-31 22-27-31-35 24-31-37-41 29-34-37-40 31-36-41-46
Note
1. Operation temperature of indoor unit.
Cooling mode: 15 °C WB (59 °F WB) - 24 °C WB (75 °F WB)
Heating mode: 15 °C DB (59 °F DB) - 27 °C DB (81 °F DB)
2. Cooling/Heating capacity indicates the maximum value at operation under the following condition.
Cooling: Indoor 27 °C DB (81 °F DB)/19 °C WB (66 °F WB), Outdoor 35 °C DB (95 °F DB)
Heating: Indoor 20 °C DB (68 °F DB), Outdoor 7 °C DB (45 °F DB)/6 °C WB (43 °F WB)
en
RH79A033H01_en.indd 15 2019/11/21 13:07:07
016

fr
1
1. Consignes de sécurité
Avertissement :
•Ces appareils ne sont pas accessibles au public.
•Cet appareil ne doit pas être installé par l’utilisateur. Demander au
revendeur ou à une société agréée de l’installer. Si l’appareil n’est
pas correctement installé il peut y avoir un risque de fuite d’eau,
d’électrocution ou d’incendie.
• Nepasmodierl’appareil.Celapourraitprovoquerunrisqued’in-
cendie, d’électrocution, de blessure ou de fuite d’eau.
•Ne pas marcher sur l’appareil ni y déposer des objets.
•Ne jamais éclabousser l’appareil ni le toucher avec des mains
humides. Il pourrait en résulter un risque d’électrocution.
• Ne pas vaporiser de gaz inammable à proximité de l’appareil
sous risque d’incendie.
•Ne pas placer de chauffage au gaz ou tout autre appareil fonction-
nantavecuneammevivelàoùilseraitexposéàl’échappement
d’air du climatiseur. Cela risquerait de provoquer une mauvaise
combustion.
•Ne pas retirer la face avant ou la protection du ventilateur de l’ap-
pareilextérieurpendantsonfonctionnement.
•Ne réparez jamais l’unité et ne la transportez jamais sur un autre
site par vous-même.
•Si vous remarquez des vibrations ou des bruits particulièrement
anormaux, arrêter l’appareil, éteindre l’interrupteur et prendre
contact avec le revendeur.
•N’insérez jamais les doigts, des bâtons, etc. dans les entrées ou
sorties d’air.
•Si vous sentez des odeurs étranges, arrêter l’appareil, le mettre
hors tension et contacter le revendeur. Si vous ne procédez pas
de cette façon, il pourrait y avoir risque de panne, d’électrocution
ou d’incendie.
•Ne JAMAIS laisser des enfants ou des personnes handicapées uti-
liser le climatiseur sans surveillance.
•Si le gaz de réfrigérant fuit, arrêter le fonctionnement du clima-
tiseur, aérer convenablement la pièce et prendre contact avec le
revendeur.
Précaution :
•Ne pas utiliser d’objet pointu pour enfoncer les boutons car cela
risquerait d’endommager la commande à distance.
•N’obstruez et ne recouvrez jamais les entrées ou sorties d’air de
l’unitéintérieureouextérieure.
•N’essuyez jamais la télécommande avec un chiffon imbibé de di-
luant, de benzène, etc.
Remarque :
Dansleprésentmanueld’utilisation,l’expression“Télécommandelaire”faitréférenceaumodèlePAR-40MAA.
Pour toute information relative à un autre modèle de télécommande, reportez-vous au livret d’instructions fourni dans la boîte de cette
dernière.
• Seuleslespersonnesexpérimentéesouayantuneformationspé-
ciquedevente,detravaildanslesecteurdel’industrielégèreet
de l’agriculture peuvent utiliser cet appareil, ainsi que les non-
initiés en cas d’utilisation commerciale.
•Les enfants doivent être surveillés pour s’assurer qu’ils ne jouent
pas avec le climatiseur.
•Cet appareil n’est pas conçu pour être utilisé par des personnes
(y compris des enfants) présentant des capacités physiques, sen-
soriellesoumentalesréduites,oumanquantd’expérienceetde
connaissances, à moins qu’elles ne soient supervisées ou aient
reçu des instructions relatives à l’utilisation de l’appareil par une
personne responsable de leur sécurité.
•Cet appareil peut être utilisé par des enfants de 8 ans et plus et
des personnes dont les capacités mentales, sensorielles ou phy-
siques sont réduites, ou manquant d’expérience et de connais-
sances, dès lors qu’elles sont supervisées ou ont reçu une for-
mation relative à l’utilisation de l’appareil et comprennent les
dangers associés à celui-ci. Les enfants ne doivent pas jouer avec
l’appareil. Le nettoyage et l’entretien ne peuvent pas être effectués
par un enfant sans surveillance.
•Lors de l’installation, du déplacement ou de l’entretien du climati-
seur,n’utilisezqueleréfrigérantspécié(R410A)pourremplirles
tuyauxderéfrigérant.Nepaslemélangeravecunautreréfrigérant
etfairelevided’airdanslestuyaux.
Si du réfrigérant est mélangé avec de l’air, cela peut provoquer des
pointesdepressiondanslestuyauxderéfrigérantetentraînerune
explosionetd’autresrisques.L’utilisationd’unréfrigérantdifférent
deceluispéciépourleclimatiseurpeutentraînerdesdéfaillances
mécaniques, des dysfonctionnements du système ou une panne de
l’appareil. Dans le pire des cas, cela peut entraîner un obstacle à la
mise en sécurité du produit.
1. Consignes de sécurité........................................................... 1
2. Nomenclature ........................................................................ 2
3. Fonctionnement..................................................................... 7
4. Minuterie.............................................................................. 10
5. Fonctionnement d’urgence de la télécommande sans l .... 10
6. Entretien et nettoyage ......................................................... 11
7. Guide de dépannage........................................................... 13
8. Spécications techniques.................................................... 15
► Avant d’installer le climatiseur, lire attentivement toutes
les“Consignesdesécurité”.
► Les“Consignesdesécurité”reprennentdespointstrès
importants concernant la sécurité. Veillez bien à les
suivre.
► Veuillez consulter ou obtenir la permission votre com-
pagnie d’électricité avant de connecter votre système.
Symbolesutilisésdansletexte
Avertissement :
Précautions à suivre pour éviter tout danger de blessure ou de dé-
cès de l’utilisateur.
Précaution :
Décrit les précautions qui doivent être prises pour éviter d’endom-
mager l’appareil.
Symboles utilisés dans les illustrations
: Indique un élément qui doit être mis à la terre.
Index
•Ne faites pas fonctionner l’unité pendant une période prolongée
avecuntauxd’humiditéimportant,parexemple,lorsqu’uneporte
ou une fenêtre est ouverte. En mode de refroidissement, si l’unité
fonctionne longtemps dans une pièce humide (HR [humidité rela-
tive]de80%minimum),l’eaucondenséeàl’intérieurduclimati-
seur risque de s’écouler et d’endommager le mobilier, etc.
• Ne touchez pas à l’ailette de sortie d’air supérieure ou au clapet de
sortie d’air inférieur lors du fonctionnement. Sinon, de la condensa-
tion risque de se former et l’unité risque de cesser de fonctionner.
Rangement de l’appareil
Lorsque vous devez ranger l’appareil, veuillez consulter votre revendeur.
RH79A033H01_fr.indd 1 2019/11/21 10:48:56
017

fr
2
2. Nomenclature
■Unité interne
PKFY-P·NLMU
Vitesse du ventilateur 4 vitesses + Auto
Ailette Niveaux 5 niveaux
Oscillation automatique
Louvre Manuel
Filtre Normal
Témoin de nettoyage du ltre 100 heures
Saisissez le numéro du réglage du
modèle de l’unité intérieure que vous
souhaitez utiliser.*
065 (001)
*
Pour les systèmes capables de fonctionner simultanément en modes de refroidissement et de chauffage, utilisez le réglage indiqué entre parenthèses ( ) .
Pour plus de détails sur la procédure de réglage, reportez-vous au manuel d’installation.
Ailette
Admission d’air
Grille de refou-
lement d’air
Louvre
Filtre
RH79A033H01_fr.indd 2 2019/11/21 10:48:56
018

fr
3
2. Nomenclature
■Télécommandelaire
Les fonctions réalisées par les touches varient en fonction de
l’écran.
Consultez le guide des touches en bas de l’écran LCD pour voir les
fonctions correspondant à un écran donné.
Lorsque le système est piloté à distance, le guide de fonction des
touches n’apparaît pas pour les touches verrouillées.
Interface de la télécommande
MENU ON
OFF
RETURN SELECT
HOLD
Ecran principal
Écran des menus
Guide des fonctions
Menu général
83
83
Fri
Room
Set temp.
Mode Temp. Fan
Cool Auto
Main Main menu
Energy saving
Main display:
Cursor
Operation
Vane·Louver·Vent. (Lossnay)
High power
Comfort
RETURN
7890
7890
7890
4 32 1
5
6
7890
Touches fonctions
▌1Touche[ON/OFF]
Pressez pour allumer ou éteindre l’appareil intérieur.
▌2Touche[SELECT/HOLD]
Pressez pour enregistrer les paramètres.
Lorsque le menu principal est af ché, une pression sur cette touche
active/désactive la fonction HOLD (EN ATTENTE).
▌3Touche[RETURN]
Pressez pour revenir à l’écran précédent.
▌4Touche[MENU]
Pressez pour ouvrir le Menu général.
▌5Écran LCD rétroéclairé
Les paramètres de fonctionnement s’af chent.
Lorsque le rétroéclairage est éteint, appuyer sur une touche l’allume, et
il reste allumé pendant un certain temps en fonction de l’af chage.
Lorsque le rétroéclairage est éteint, appuyer sur une touche ne fait
que l’allumer, sans exécuter la fonction. (à l’exception du bouton
[ON/OFF])
▌6Voyant Marche/Arrêt
Cette lampe s’allume en vert lorsque le système est en fonctionnement.
Elle clignote lorsque la télécommande est en cours de démarrage ou en cas d’erreur.
▌7Touchefonction[F1]
Ecran principal : Pressez pour régler le mode de fonctionnement.
Écran des menus : La fonction des touches varie selon l’écran.
▌8Touchefonction[F2]
Ecran principal : Pressez pour diminuer la température.
Menu général : Appuyez pour déplacer le curseur vers la gauche.
Écran des menus : La fonction des touches varie selon l’écran.
▌9Touchefonction[F3]
Ecran principal : Pressez pour augmenter la température.
Menu général : Appuyez pour déplacer le curseur vers la droite.
▌0Touchefonction[F4]
Ecran principal : Pressez pour changer la vitesse du ventilateur.
RH79A033H01_fr.indd 3 2019/11/21 10:48:57
019

fr
4
2. Nomenclature
L’écran principal peut être afché dans deux modes différents : “complet” et “basic”. Le réglage usine est “complet”. Pour passer au mode “basic”,
changez-le dans l’écran principal. (Reportez-vous au manuel d’utilisation inclus avec la télécommande.)
<Mode complet>
* Toutes les icônes sont afchées pour la compréhension.
<Mode basic>
Afcheur
Fri
Cool
Mode Temp. Fan
Set temp. Auto
83
Fri
Mode Temp. Fan
Room
Cool Set temp. Auto
83
83
4
3
2!
1
5
6
#
7
8
90
1
3
9
4
)
@
$2
1
#
5
32$45 6 7 8
▌1Mode de fonctionnement
▌2Températureprogrammée
▌3Horloge
▌4Vitesse du ventilateur
▌5Guide des fonctions des touches
Les fonctions correspondant aux touches s’afchent ici.
▌6
S’afche lorsque la marche et l’arrêt sont pilotés de façon centralisée.
▌7
S’afche lorsque le mode de fonctionnement est piloté de façon centra-
lisée.
▌8
S’afche lorsque la température sélectionnée est pilotée de façon cen-
tralisée.
▌9
S’afche si la remise à zéro du ltre est pilotée de façon centralisée.
▌0
Indique si le ltre a besoin d’entretien.
▌1Températuredelapièce
▌2
S’afche lorsque les touches sont verrouillées.
▌3
S’afche lorsque la minuterie Marche/Arrêt ou la fonction Arrêt automa-
tique de la minuterie est activée.
apparaît lorsque le timer est désactivé par le système de contrôle
centralisé.
s’afche lorsque la fonction HOLD (EN ATTENTE) est activée.
▌4
S’afche si le programmateur hebdomadaire est activé.
▌5
S’afche lorsque le système est en mode économie d’énergie. (Ceci
n’apparaîtra pas sur certains modèles d’unités intérieures)
▌6
S’afche lorsque les appareils extérieurs sont en mode silencieux.
(Cette indication n’est pas disponible pour les modèles CITY MULTI.)
▌7
S’afche lorsque la thermistance intégrée à la télécommande est utili-
sée pour mesurer la température de la pièce (1).
s’afche lorsque la thermistance de l’appareil intérieur est utilisée
pour mesurer la température de la pièce.
▌8
Indique le réglage du déecteur.
▌9
Indique le réglage des ailettes.
▌)
Indique les réglages de la ventilation.
▌!
S’afche lorsque la plage de température de réglage est réduite.
▌@
S’afche lorsqu’un fonctionnement en économie d’énergie est activé à
l’aide d’une fonction “3D i-See sensor” (Capteur 3D i-See).
▌#Commande centralisée
S’afche pendant une certaine période de temps lorsqu'un élément à
commande centralisée est activé.
▌$Afchaged’erreurpréliminaire
Un code d’erreur s’afche pendant l’erreur préliminaire.
La plupart des réglages (sauf ON/OFF, le mode, la vitesse du
ventilateur, la température) peuvent se faire à partir du menu
principal. (Voir page 9.)
RH79A033H01_fr.indd 4 2019/11/21 10:48:57
020
