Mitsubishi Electric CITY MULTI PUMY-P112VKM6 User manual

SERVICE MANUAL
June 2022
OCH790
1. SERVICE REF. ···································2
2. SAFETY PRECAUTION ·······················3
3. OVERVIEW OF UNITS ························ 7
4. SPECIFICATIONS ···························· 12
5. DATA·············································· 14
6. OUTLINES AND DIMENSIONS ··········· 27
7. WIRING DIAGRAM ··························· 29
8. TROUBLESHOOTING ······················· 31
9. DISASSEMBLY PROCEDURE ···········107
10. SYSTEM CONSTRUCTION ···············119
11. ELECTRICAL WIRING ·····················121
12. REFRIGERANT PIPING TASKS ·········122
13. REMOTE CONTROLLER ··················123
HFC
utilized
R410A
Appendix: Installation manual (Exerpt of English Ver.)
Model
name
indication
PARTS CATALOG (OCB790)
<Outdoor unit>
Model name
PUMY-P112VKM6 PUMY-P112VKM6-ER
PUMY-P125VKM6 PUMY-P125VKM6-ER
PUMY-P140VKM6 PUMY-P140VKM6-ER
PUMY-P112YKM5 PUMY-P112YKM5-ER
PUMY-P125YKM5 PUMY-P125YKM5-ER
PUMY-P140YKM5 PUMY-P140YKM5-ER
Salt proof model
PUMY-P112VKM6-BS PUMY-P112VKM6-ERBS
PUMY-P125VKM6-BS PUMY-P125VKM6-ERBS
PUMY-P140VKM6-BS PUMY-P140VKM6-ERBS
PUMY-P112YKM5-BS PUMY-P112YKM5-ERBS
PUMY-P125YKM5-BS PUMY-P125YKM5-ERBS
PUMY-P140YKM5-BS PUMY-P140YKM5-ERBS

OCH790 _2
1 SERVICE REF.
PUMY-P112VKM6
PUMY-P112VKM6-ER
PUMY-P125VKM6
PUMY-P125VKM6-ER
PUMY-P140VKM6
PUMY-P140VKM6-ER
PUMY-P112YKM5
PUMY-P112YKM5-ER
PUMY-P125YKM5
PUMY-P125YKM5-ER
PUMY-P140YKM5
PUMY-P140YKM5-ER
PUMY-P112VKM6-BS
PUMY-P112VKM6-ERBS
PUMY-P125VKM6-BS
PUMY-P125VKM6-ERBS
PUMY-P140VKM6-BS
PUMY-P140VKM6-ERBS
PUMY-P112YKM5-BS
PUMY-P112YKM5-ERBS
PUMY-P125YKM5-BS
PUMY-P125YKM5-ERBS
PUMY-P140YKM5-BS
PUMY-P140YKM5-ERBS

OCH790 _3
2 SAFETY PRECAUTION
2-1. Cautions related to new refrigerant
■Cautions for units utilizing refrigerant R410A
Preparation before the repair service
• Prepare the proper tools.
• Prepare the proper protectors.
• Provide adequate ventilation.
• After stopping the operation of the air conditioner, turn o󰀨 the power-supply breaker.
• Discharge the condenser before the work involving the electric parts.
Precautions during the repair service
• Do not perform the work involving the electric parts with wet hands.
• Do not pour water into the electric parts.
• Do not touch the refrigerant.
• Do not touch the hot or cold areas in the refrigerating cycle.
• When the repair or the inspection of the circuit needs to be done without turning o󰀨 the power, exercise great caution
not to touch the live parts.
• When opening or closing the valve below freezing temperatures, refrigerant may spurt out from the gap between the
valve stem and the valve body, resulting in injuries.
Use new refrigerant pipes.
• Avoid using thin pipes.
Make sure that the inside and outside of refrigerant piping is clean and it has no contam-
inants such as sulfur, oxides, dirt, shaving particles, etc., which are hazard to refrigerant
cycle. In addition, use pipes with specied thickness.
• Contamination inside refrigerant piping can cause deterioration of refrigerant oil, etc.
Store the piping indoors, and keep both ends of the piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
• If dirt, dust or moisture enters into refrigerant cycle, that can cause deterioration of refrigerant oil or malfunction of
compressor.
The refrigerant oil applied to are and ange connections must be ester oil, ether oil or
alkylbenzene oil in a small amount.
• If large amount of mineral oil enters, that can cause deterioration of refrigerant oil, etc.
Charge refrigerant from liquid phase of refrigerant cylinder.
• If the refrigerant is charged from gas phase, composition change may occur in refrigerant and the e󰀩ciency will be
lowered.
Do not use refrigerant other than R410A.
• If other refrigerant (R22, etc.) is used, chlorine in refrigerant can cause deterioration of refrigerant oil, etc.
Use a vacuum pump with a reverse ow check valve.
• Vacuum pump oil may ow back into refrigerant cycle and that can cause deterioration of refrigerant oil, etc.
Use the following tools specically designed for use with R410A refrigerant.
• The following tools are necessary to use R410A refrigerant.
Tools for R410A
Gauge manifold Flare tool
Charge hose Size adjustment gauge
Gas leak detector Vacuum pump adaptor
Torque wrench Electronic refrigerant charging scale

OCH790 _4
Handle tools with care.
• If dirt, dust or moisture enters into refrigerant cycle, that can cause deterioration of refrigerant oil or malfunction of
compressor.
Do not use a charging cylinder.
• If a charging cylinder is used, the composition of refrigerant will change and the e󰀩ciency will be lowered.
Ventilate the room if refrigerant leaks during operation. If refrigerant comes into contact
with a ame, poisonous gases will be released.
Use the specied refrigerant only.
• Never use any refrigerant other than that specied.
• Doing so may cause a burst, an explosion, or re when the unit is being used, serviced, or disposed of.
• Correct refrigerant is specied in the manuals and on the spec labels provided with our products.
• We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused by
failure to follow the instructions.
Follow the instructions below to prevent abrasive components contained in sandpaper and
cutting tools from entering the refrigerant circuit because those components can cause
failures of the compressor and valves.
• To deburr pipes, use a reamer or other deburring tools, not sandpaper.
• To cut pipes, use a pipe cutter, not a grinder or other tools that use abrasive materials.
• When cutting or deburring pipes, do not allow cutting chips or other foreign matters to enter the pipes.
• If cutting chips or other foreign matters enter pipes, wipe them o󰀨 the inside of the pipes.
Do not pump down the system when a gas leak has been detected.
• The intake of air or other gases causes abnormally high pressure in the refrigeration cycle, which may cause explo-
sion or injury.
2-1-1. Cautions for service
• Perform service after recovering the refrigerant left in unit completely.
• Do not release refrigerant in the air.
• After completing service, charge the cycle with specied amount of refrigerant.
• If moisture or foreign matter might have entered the refrigerant piping during service, ensure to remove them.
2-1-2. Additional refrigerant charge
When charging directly from cylinder
• Check that cylinder for R410A on the market is a syphon type.
• Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)
Unit
Electronic weighing scale
2-1-3. Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
No. Tool name Specications
1Gauge manifold Only for R410A
Use the existing tting specications. (UNF1/2)
Use high-tension side pressure of 5.3MPa·G or over.
2 Charge hose Only for R410A
Use pressure performance of 5.09MPa·G or over.
3Electronic weighing scale –
4 Gas leak detector Use the detector for R134a, R407C or R410A.
5 Adaptor for reverse ow check Attach on vacuum pump.

OCH790 _5
No. Tool name Specications
6Refrigerant charge base –
7Refrigerant cylinder Only for R410A
Top of cylinder (Pink)
Cylinder with syphon
8Refrigerant recovery equipment –
2-2. Precautions for salt-proof type “-BS” model
Although “-BS” model has been designed to be resistant to salt damage, observe the following precautions to maintain
the performance of the unit.
• Avoid installing the unit in a location where it will be exposed directly to seawater or sea breeze.
• If the cover panel may become covered with salt, be sure to install the unit in a location where the salt will be washed
away by rainwater. (If a sunshade is installed, rainwater may not clean the panel.)
• To ensure that water does not collect in the base of the outdoor unit, make sure that the base is level, not at angle.
Water collecting in the base of the outdoor unit could cause rust.
• If the unit is installed in a coastal area, clean the unit with water regularly to remove any salt build-up.
• If the unit is damaged during installation or maintenance, be sure to repair it.
• Be sure to check the condition of the unit regularly.
• Be sure to install the unit in a location with good drainage.
2-2-1. Cautions for refrigerant piping work
New refrigerant R410A is adopted for replacement inverter series. Although the refrigerant piping work for R410A is the
same as for R22, exclusive tools are necessary so as not to mix with di󰀨erent kind of refrigerant. Furthermore as the
working pressure of R410A is 1.6 times higher than that of R22, their sizes of ared sections and are nuts are di󰀨erent.
■Thickness of pipes
Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness
shown below. (Never use pipes of 0.7 mm [7/256 in] or below.)
Piping diameter and thickness
Nominal dimensions (in) Outside diameter (mm) Thickness (mm)
R410A R22
1/4 6.35 0.8 0.8
3/8 9.52 0.8 0.8
1/2 12.70 0.8 0.8
5/8 15.88 1.0 1.0
3/4 19.05 –1.0
■Dimensions of are cutting and are nut
The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that,
R410A is a refrigerant, which has higher risk of leakage because its working pressure is higher than that of other refriger-
ants.
Therefore, to enhance airtightness and strength, are cutting dimension of copper pipe for R410A has been specied
separately from the dimensions for other refrigerants as shown below. The dimension B of are nut for R410A also
has partly been changed to increase strength as shown below. Set copper pipe correctly referring to copper pipe aring
dimensions for R410A below. For 1/2 and 5/8 inch pipes, the dimension B changes. Use torque wrench corresponding to
each dimension.
Dimension A
Dimension B
Flare cutting dimensions
Nominal dimensions (in) Outside diameter (mm) Dimension A (
0
-0.4
) (mm [in])
R410A R22
1/4 6.35 9.1 [11/32-23/64] 9.0
3/8 9.52 13.2 [1/2-33/64] 13.0
1/2 12.70 16.6 [41/64-21/32] 16.2
5/8 15.88 19.7 [49/64-25/32] 19.4
3/4 19.05 – 23.3
Flare nut dimensions
Nominal dimensions (in) Outside diameter (mm) Dimension B (
0
-0.4
) (mm)
R410A R22
1/4 6.35 17.0 17.0
3/8 9.52 22.0 22.0
1/2 12.70 26.0 24.0
5/8 15.88 29.0 27.0
3/4 19.05 – 36.0

OCH790 _6
■Tools for R410A (The following table shows whether conventional tools can be used or not.)
Tools and materials Use R410A tools Can R22 tools be used ? Can R407C tools be used ?
Gauge manifold Air purge, refrigerant charge
and operation check
Tool exclusive for R410A
Charge hose Tool exclusive for R410A
Gas leak detector Gas leak check Tool for HFC refrigerant
Refrigerant recovery
equipment
Refrigerant recovery Tool exclusive for R410A
Refrigerant cylinder Refrigerant charge Tool exclusive for R410A
Applied oil Apply to ared section Ester oil, ether oil and
alkylbenzene oil (minimum
amount)
Ester oil, ether oil:
Alkylbenzene oil: minimum
amount
Safety charger Prevent compressor
malfunction when charging
refrigerant by spraying liquid
refrigerant
Tool exclusive for R410A
Charge valve Prevent gas from blowing out
when detaching charge hose
Tool exclusive for R410A
Vacuum pump Vacuum drying and air purge Tools for other refrigerants
can be used if equipped with
adopter for reverse ow
check
( Usable if equipped with
adopter for reverse ow)
( Usable if equipped with
adopter for reverse ow)
Flare tool* Flaring work of piping Tools for other refrigerants
can be used by adjusting
aring dimension
( Usable by adjusting
aring dimension)
( Usable by adjusting
aring dimension)
Bender Bend the pipes Tools for other refrigerants
can be used
Pipe cutter* Cut the pipes Tools for other refrigerants
can be used
Welder and nitrogen gas
cylinder
Weld the pipes Tools for other refrigerants
can be used
Refrigerant charging scale Refrigerant charge Tools for other refrigerants
can be used
Vacuum gauge or thermistor
vacuum gauge and vacuum
valve
Check the degree of
vacuum. (Vacuum valve
prevents back ow of oil and
refrigerant to thermistor
vacuum gauge)
Tools for other refrigerants
can be used
Charging cylinder Refrigerant charge Tool exclusive for R410A –
: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.)
: Tools for other refrigerants can be used under certain conditions.
: Tools for other refrigerants can be used.
* Follow the instructions below to prevent abrasive components contained in sandpaper and cutting tools from entering
the refrigerant circuit because those components can cause failures of the compressor and valves.
• To deburr pipes, use a reamer or other deburring tools, not sandpaper.
• To cut pipes, use a pipe cutter, not a grinder or other tools that use abrasive materials.
• When cutting or deburring pipes, do not allow cutting chips or other foreign matters to enter the pipes.
• If cutting chips or other foreign matters enter pipes, wipe them o󰀨 the inside of the pipes.

OCH790 _7
3 OVERVIEW OF UNITS
3-1. System construction
Wireless remote
controller
M series indoor unit*5, *6
MSZ-SF·VA/VE series
MSZ-EF·VE/VG(K) series
MSZ-FH·VE series
MFZ-KJ·VE series
MFZ-KT·VG series
MFXZ-KW·VG series
MSZ-LN·VG(2) series
MSZ-AP·VG(K) series
MSZ-AP·VF series
CONNECTION KIT
PAC-LV11M-J
Model name CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
Number of branches 248
Outdoor unit Horsepower 4.5 HP 5 HP 6 HP
Model name P112 P125 P140
Applicable indoor unit Capacity class 10 to 140
Number of units 1 to 9 1 to 10 1 to 12
Total system capacity range 50 to 130% of outdoor unit capacity*1 *2
Connectable indoor unit lineup
Model type Model name 10 15 20 25 32 40 50 63 71 80 100 125 140
Cassette
ceiling
2 by 2 PLFY-P·VFM-E ●●●●●●
2-way ow PLFY-P·VLMD-E ●●●●●● ●●●
4-way ow PLFY-P·VEM-E ●●●●●● ●●●
PLFY-M·VEM6-E ●●●●●●●●●●
PLFY-M·VEM-E ●●●●●● ●●●
1-way ow PMFY-P·VBM-E ●●●●
Ceiling concealed PEFY-P·VMA(L)-E/E2 ●●●●●●●●●●●
PEFY-P·VMA(L)-E3/E4 ●●●●●●●●●●●
PEFY-P·VMHS-E ●●●●●●●●
PEFY-P·VMR-E-L/R ●●●
PEFY-M·VMA-A1 ●●●●●●●●●●●
Wall mounted PKFY-P·VLM-E ●●●●●●●
PKFY-P·VKM-E ● ●
Ceiling suspended PCFY-P·VKM-E ● ● ● ●
Floor
standing
Exposed PFFY-P·VLEM-E ●●●●●●
PFFY-P·VKM-E ●●●●
Concealed
PFFY-P·VLRM(M)-E ●●●●●●
PFFY-P·VCM-E ●●●●●●
Ceiling
concealed
Fresh air*3 PEFY-P·VMHS-E-F ●
Lossnay GUF·RD(H)4*4● ●
Air to Water unit*2 PWFY-P·VM-E1/E2-AU ●
Remote controller Name M-NET remote controller MA remote controller
Model name PAR-F27MEA-E, PAR-U02MEDA PAR-4xMAA, PAR-3xMAA ("x" represents 0 or later)
Functions • A handy remote controller for use in conjunction
with the Melans centralized management system.
• Address setting is required.
• Address setting is not required.
*1. When the indoor unit of Fresh Air type is connected with the outdoor unit, the maximum connectable total indoor unit
capacity is 110%.
*2. When connecting PWFY series (Note that the connection is not allowed inside EU countries and the UK.)
Only 1 PWFY-P100VM-E-AU can be connected. PWFY-P200VM-E-AU and PWFY-P100VM-E-BU cannot be con-
nected.
The PWFY unit cannot be the only unit connected to an outdoor unit. Select an indoor unit so that the total rated
capacity of the indoor units, excluding the PWFY unit, is 50 to 100% of the outdoor unit capacity.
*3. PUMY is connectable to Fresh Air type indoor unit.
It is possible to connect 1 Fresh Air type indoor unit to 1 outdoor unit. (1:1 system)
Operating temperature range (outdoor temperature) for fresh air type indoor units di󰀨er from other indoor units.
Refer to "3-4-3. Operating temperature range".
*4. Do not connect Lossnay remote controller(s). (PZ-61DR-E, PZ-60DR-E, PZ-52SF-E, PZ-43SMF-E)
*5. When connecting the CONNECTION KIT (PAC-LV11M-J) and an M-series indoor unit, refer to the installation manual
for the CONNECTION KIT.
*6. The CONNECTION KIT cannot be connected to the indoor unit whose model name is 60 or larger and LN 18.

OCH790 _8
3-2. System construction (Branch box system)
Outdoor unit Horsepower 4.5 HP 5 HP 6 HP
Model name P112 P125 P140
Applicable indoor unit Capacity class 15 to 100
Number of units 2 to 8
Total system
capacity range*1
50 to 130% of outdoor unit
capacity
50 to 130% of outdoor unit
capacity
50 to 130% of outdoor unit
capacity
6.3 to 16.2 kW 7.1 to 18.2 kW 8.0 to 20.2 kW
Branch box that can be connected Number of units*11 to 2
*1. When connecting ecodan unit(s), the total capacity of connected Air to Air indoor units is up to 130% of the outdoor
unit. (Air to Air 130% + ecodan). However, when operating Air to Air indoor unit(s) in heating mode and ecodan unit(s)
in DHW or heating mode at the same time, the total capacity of connected Air to Air units is below:
PUMY-P112: 1.3 kW, PUMY-P125: 2.8 kW, PUMY-P140: 4.3 kW
However, the following combinations can be connected:
PUMY-P112: MSZ-SF15VA or MSZ-AP15VF × 1
PUMY-P125: MSZ-SF15VA or MSZ-AP15VF × 2
PUMY-P140: MSZ-SF15VA or MSZ-AP15VF × 3
Connectable indoor unit lineup (Heat pump inverter type)
Model type Model name 15 18 20 22 25 35 42 50 60 71 80 100
Wall mounted Deluxe MSZ-RW·VG ● ●
MSZ-FH·VE ● ● ●
MSZ-LN·VG(2) ● ● ●
Standard MSZ-GF·VE ● ●
MSZ-SF·VE ●●●●
MSZ-AP·VG-E1/E6 ●●●●
MSZ-AP·VG(K)-E2/E3/E7
●●●●
MSZ-EF·VE ● ●●●●●
MSZ-EF·VG-E1/E2 ● ●●●●●
MSZ-EF·VGK-E1 ● ●●●●●
Compact MSZ-SF·VA ● ●
MSZ-AP·VF ● ●
MSZ-AP·VG-E3 ● ●
MSZ-AP·VGK-E2 ● ●
Ceiling concealed Low static pressure SEZ-KD·VA(L) ●● ●●●
SEZ-M·DA(L) ●● ●●●
SEZ-M·DA(L)2 ● ● ● ●
Middle static
pressure
PEAD-RP·JA(L)Q(.UK)
● ● ● ●
PEAD-M·JA(L) ● ● ● ●
PEAD-M·JA(L)2 ● ● ● ●
4-way ceiling
cassette
2 by 2 type SLZ-KF·VA2 ● ● ●
SLZ-M·FA ● ● ● ●
SLZ-M·FA2 ● ● ● ●
Standard PLA-RP·EA(.UK) ● ● ● ● ●
PLA-M·EA ● ● ● ● ●
PLA-M·EA2 ● ● ● ● ●
Ceiling suspended PCA-RP·KAQ ● ● ● ● ●
PCA-M·KA ● ● ● ● ●
PCA-M·KA2 ● ● ● ● ●
Floor standing MFZ-KJ·VE2 ● ● ●
MFZ-KT·VG ● ● ●
1-way ceiling cassette MLZ-KA·VA ● ● ●
MLZ-KP·VF ● ● ●
Note:
• The lineup of a connectable indoor unit depends on a district/areas/country.
Connectable ecodan unit
Model type Model name
Cylinder Unit EHST20C series (except EHST20C-MEC)
Hydrobox EHSC series (except EHSC-MEC)
Note:
• Only 1 Cylinder Unit or Hydrobox can be connected.

OCH790 _9
Branch box PAC-MK53/54BC
PAC-MK53BCB
PAC-MK33/34BC
PAC-MK33BCB
Number of branches
(Indoor unit that can be connected) 5 (MAX. 5 units) 3 (MAX. 3 units)
Note:
• A maximum of 2 branch boxes can be connected to 1 outdoor unit.
• PAC-MK31/51BC(B) cannot use for connecting a Cylinder Unit or a Hydrobox.
2-branch pipe (joint), optional parts
Using 1 branch box Not required
Using 2 branch boxes Required
Connection method: are (MSDD-50AR-E)
Connection method: brazing (MSDD-50BR-E)
Note: Select the appropriate model based on the connection method.
Option Optional accessories of indoor units and outdoor units are available.
3-3. System construction (Mixed system)
Branch box PAC-MK5*BC PAC-MK3*BC
Number of branches 5 (MAX. 5 units) 3 (MAX. 3 units)
Outdoor unit Model name P112 P125 P140
Applicable
indoor unit
Capacity
class
CITY MULTI indoor unit*4*515 to 140
Via branch box 15 to 100
Number
of units*1Via branch box CITY MULTI
indoor Via branch box CITY MULTI
indoor Via branch box CITY MULTI
indoor
1 branch box 5 5 5 5 5 5
2 branch boxes 7 or 8*2 3 or 2*2 8383
Total system capacity range*16.3 to 16.2 kW 7.1 to 18.2 kW 8.0 to 20.2 kW
50 to 130% of outdoor unit capacity
CITY MULTI indoor units*3
M series
S series
P series
indoor units*3
Cylinder unit
Hydrobox
MA
remote
controller
MA
remote
controller
CONNECTION KIT
PAC-LV11M-J
M series indoor unit
M-NET
remote
controller
Model name CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
Number of branches 248
*1. When connecting ecodan unit, the total capacity of connected Air to Air indoor units is up to 130% of the outdoor unit
(Air to Air 130% + ecodan). However, when operating Air to Air indoor unit(s) in heating mode and ecodan unit in
DHW or heating mode at the same time, the maximum connectable Air to Air indoor unit is below.
Model name ATA total capacity Can be exceptionally connected
P112 1.3 kW MSZ-SF15VE or MSZ-AP15VF × 1
P125 2.8 kW MSZ-SF15VE or MSZ-AP15VF × 2
P140 4.3 kW MSZ-SF15VE or MSZ-AP15VF × 3
*2. When connecting 7 indoor units via branch box, connectable CITY MULTI indoor units are 3; connecting 8 indoor
units via branch box, connectable CITY MULTI indoor units are 2.
*3. Refer to “3-1. System construction” or “3-2. System construction (Branch box system)”, for more detail.
*4. PKFY-P10/15/20/25/32VLM, PFFY-P*VKM, PFFY-P*VCM, PFFY-P*VL* type indoor units cannot be used with Mixed
system.
*5. PEFY-P*VMHS-E-F can be connected within the total rated capacity and maximum number of connected units.

OCH790 _10
3-4. System Specications
3-4-1. Outdoor Unit
Outdoor unit Model name P112 P125 P140
Capacity Cooling (kW) 12.5 14.0 15.5
Heating (kW) 14.0 16.0 18.0
Cooling/Heating capacity indicates the maximum value at operation under the following condition.
Cooling Indoor: D.B. 27°C/W.B. 19°C
Outdoor: D.B. 35°C
Heating Indoor: D.B. 20°C
Outdoor: D.B. 7°C/W.B. 6°C
3-4-2. Method for identifying MULTI-S model
■Outdoor unit <When using model 125>
PU M Y ─P 125 Y K M ─ BS
Outdoor
unit
Refrigerant R410A
MULTI-S
Frequency conversion
controller
Indicates equivalent to
Cooling capacity(kcal/ h)
Power supply
V: 1-phase
220-230-240 V, 50 Hz
220-230 V, 60 Hz
Y: 3-phase
380-400-415 V, 50 Hz
380 V, 60 Hz
Outdoor unit model type
M-NET control
Sub number
Salt
proof type
5
3-4-3. Operating temperature range
Cooling Heating
Indoor intake air temperature W.B. 15 to 24°C D.B. 15 to 27°C
Outdoor intake air temperature D.B. −5 to 52°C*1W.B. −20 to 15°C
D.B.: Dry Bulb Temperature
W.B.: Wet Bulb Temperature
*1. 10 to 52°C D.B.: When connecting PKFY-P10/15/20/25/32VLM, PFFY-P20/25/32VKM, PFFY-P20/25/32VCM,
PFFY-P20/25/32VLEM, PFFY-P20/25/32VLRM(M), and M series, S series, and P series type indoor
unit.
■When connecting fresh air type indoor unit
PEFY-P·VMHS-E-F
Cooling Heating
Indoor and outdoor intake air temperature D.B. 17 to 43°C*2
W.B. 15.5 to 35°C D.B. -5 to 20°C*3
*2. Thermo-OFF (FAN-mode) automatically starts if the outdoor temp. is lower than 17°C D.B.
*3. Thermo-OFF (FAN-mode) automatically starts if the outdoor temp. is higher than 21°C D.B.
■When connecting PWFY unit
Cooling Heating
Indoor intake water temperature —*4 D.B. 10 to 45°C
Outdoor intake air temperature —*4 W.B. -20 to 15°C
*4. PWFY series can operate in Heating mode but not in Cooling mode. An indoor unit other than that of PWFY series
can operate in Cooling mode.
A PWFY series and other series cannot operate simultaneously.
The operation of PWFY series takes precedence over other series. While a PWFY series is operating, other series
do not operate.
The set temperature on the remote controller represents the target temperature of the outlet water.
■When connecting Cylinder Unit or Hydrobox
Cooling DHW only ATW Heating only DHW + ATA
Heating*5
ATW Heating + ATA
Heating*5
Outlet water temperature —*6 55°C Max. 55°C Max. 55°C Max. 45 to 55°C Max.
Outdoor temperature —*6 −20 to 35°C −20 to 21°C 7 to 35°C −10 to 35°C*7
*5. ATA unit: Air to Air unit (other than PWFY, Cylinder Unit or Hydrobox)
*6. Cylinder Unit and Hydrobox cannot operate Cooling mode in connecting PUMY.
*7. When outdoor temp. is less than 7°C, outlet water temp. is lowered. (Refer to the gure below "Temperature curve of
max. outlet water".)
Furthermore, outlet air temperature is lowered.

OCH790 _11
-10 -5 0 5 10
15
39
41
43
45
47
49
51
53
55
57
Outdoor temp. [°CDB]
Max. outlet water temp. [°C]
3-4-3-1. Temperature curve of max. outlet water

OCH790 _12
4 SPECIFICATIONS
Model PUMY-P112VKM6(-BS)
PUMY-P112VKM6-ER(BS)
PUMY-P125VKM6(-BS)
PUMY-P125VKM6-ER(BS)
PUMY-P140VKM6(-BS)
PUMY-P140VKM6-ER(BS)
Power source 1-phase 220-230-240 V, 50 Hz; 1-phase 220-230 V, 60 Hz
Cooling capacity (Nominal)*1 kW 12.5 14.0 15.5
kcal/h 10,750 12,040 13,330
Btu/h 42,650 47,768 52,886
Power input kW 4.34 5.00 5.17
Current input A 20.03 - 19.16 - 18.36,
20.03 - 19.16
23.08 - 22.08 - 21.16,
23.08 - 22.08
23.86 - 22.83 - 21.87,
23.86 - 22.83
COP kW/kW 2.88 2.80 3.00
Temp. range of
cooling
Indoor W.B. 15 to 24°C
Outdoor D.B. −5 to 52°C *3*4
Heating capacity (Nominal)*2 kW 14.0 16.0 18.0
kcal/h 12,040 13,760 15,480
Btu/h 47,768 54,592 61,416
Power input kW 3.49 4.06 4.63
Current input A 16.11 - 15.41 - 14.77,
16.11 - 15.41
18.74 - 17.93 - 17.18,
18.74 - 17.93
21.37 - 20.44 - 19.59,
21.37 - 20.44
COP kW/kW 4.01 3.94 3.89
Temp. range of
heating
Indoor D.B. 15 to 27°C
Outdoor W.B. −20 to 15°C
Indoor unit
connectable
Total capacity 50 to 130% of outdoor unit capacity
Model/ Quantity CITY MULTI P10 - P140 / 9 P10 - P140 / 10 P10 - P140 / 12
Branch box*6 P15 - P100 / 8 P15 - P100 / 8 P15 - P100 / 8
Mixed
system
Branch box
1 unit*6
CITY MULTI P15 - P140 / 5 P15 - P140 / 5 P15 - P140 / 5
Branch box P15 - P100 / 5 P15 - P100 / 5 P15 - P100 / 5
Branch box
2 units*6
CITY MULTI P15 - P140 / 3 or 2 *5 P15 - P140 / 3 P15 - P140 / 3
Branch box P15 - P100 / 7 or 8 *5 P15 - P100 / 8 P15 - P100 / 8
Sound pressure level (SPL)
(measured in anechoic room)
dB <A> 49/51 50/52 51/53
Sound power level (PWL)
(measured in anechoic room)
dB <A> 69/71 70/72 71/73
Refrigerant piping
diameter
Liquid pipe mm (in) 9.52 (3/8)
Gas pipe mm (in) 15.88 (5/8)
Fan Type × Quantity Propeller Fan x 2
Airow rate m³/min 110
L/s 1,833
cfm 3,884
Control, Driving mechanism DC control
Motor output kW 0.074 + 0.074
External static press. 0
Compressor Type × Quantity Scroll hermetic compressor x 1
Manufacturer Mitsubishi Electric Corporation
Starting method Inverter
Capacity control % Cooling 26 to 100
Heating 20 to 100
Cooling 24 to 100
Heating 18 to 100
Cooling 21 to 100
Heating 17 to 100
Motor output kW 2.9 3.5 3.9
Case heater kW 0
Lubricant FV50S (2.3liter)
External nish Galvanized Steel Sheet Munsell No. 3Y 7.8/1.1
External dimension H × W × D mm 1,338 × 1,050 × 330 (+40)
in 52-11/16 × 41-11/32 × 13 (+1-9/16)
Protection
devices
High pressure protection High pressure switch
Inverter circuit (COMP./FAN) Overcurrent detection, Overheat detection (Heat sink thermistor)
Compressor Compressor thermistor, Overcurrent detection
Fan motor Overheating, Voltage protection, Overcurrent detection
Refrigerant Type × original charge R410A 4.8 kg
Control Linear expansion valve
Net weight kg (lb) 122 (269)
Heat exchanger Cross Fin and Copper tube
HIC circuit (HIC: Heat Inter-Changer) Double pipe heat exchanger
Defrosting method Reversed refrigerant circuit
Standard
attachment
Document Installation Manual
Accessory Grounded lead wire ×1
Optional parts Joint: CMY-Y62-G-E, Header: CMY-Y64/68-G-E, Branch box: PAC-MK34/54BC
Remarks
*1. Nominal cooling conditions:
Indoor: 27°C D.B./19°C W.B. [81°F D.B/66°F W.B.]
Outdoor: 35°C D.B. [95°F D.B.]
Pipe length: 7.5 m [24-9/16 ft]
Level di󰀨erence: 0 m [0 ft]
*2. Nominal heating conditions:
Indoor: 20°C D.B. [68°F D.B.]
Outdoor: 7°C DB/6°C W.B. [45°F D.B./43°F W.B.]
Pipe length: 7.5 m [24-9/16 ft]
Level di󰀨erence: 0 m [0 ft]
*3. 10 to 52°C D.B. [50 to 126°F D.B.], when connecting following models: PKFY-P10/15/20/25/32VLM, PFFY-P20/25/32VLEM, PFFY-P20/25/32VL-
RM(M), PFFY-P20/25/32VKM, PFFY-P20/25/32VCM; and M series, S series, and P series type indoor unit.
*4. −15 to 52°C D.B. [50 to 126°F D.B.], when using an optional air protect guide [PAC-SH95AG-E]. However, this condition does not apply to the indoor
unit listed in *3.
*5. When connecting 7 indoor units via branch box, connectable CITY MULTI indoor units are 3; connecting 8 indoor units via branch box, connectable
CITY MULTI indoor units are 2.
*6. At least two indoor units must be connected when using branch box.
Notes:
• Nominal conditions *1, *2 are subject to ISO 15042.
• Due to continuing improvement, above specications are subject to change without notice.
• See the following for unit conversion: kcal/h = kW × 860, Btu/h = kW × 3,412, cfm = m³/min × 35.31, lb = kg/0.4536
Above specication data is subject to rounding variation.

OCH790 _13
Model
PUMY-P112YKM5(-BS)
PUMY-P112YKM5-ER(BS)
PUMY-P125YKM5(-BS)
PUMY-P125YKM5-ER(-BS)
PUMY-P140YKM5(-BS)
PUMY-P140YKM5-ER(BS)
Power source 3-phase 380-400-415 V, 50 Hz; 3-phase 380 V, 60 Hz
Cooling capacity (Nominal)*1 kW 12.5 14.0 15.5
kcal/h 10,750 12,040 13,330
Btu/h 42,650 47,768 52,886
Power input kW 4.34 5.00 5.17
Current input A 7.76 - 6.97 - 6.36. 7.76 8.94 - 8.02 - 7.33, 8.94 9.25 - 8.30 - 7.58, 9.25
COP kW/kW 2.88 2.80 3.00
Temp. range of
cooling
Indoor W.B. 15 to 24°C
Outdoor D.B. −5 to 52°C *3*4
Heating capacity (Nominal)*2 kW 14.0 16.0 18.0
kcal/h 12,040 13,760 15,480
Btu/h 47,768 54,592 61,416
Power input kW 4.34 5.00 5.17
Current input A 6.24 - 5.60 - 5.12, 6.24 7.26 - 6.52 - 5.95, 7.26 8.28 - 7.43 - 6.79, 8.28
COP kW/kW 4.01 3.94 3.89
Temp. range of
heating
Indoor D.B. 15 to 27°C
Outdoor W.B. −20 to 15°C
Indoor unit
connectable
Total capacity 50 to 130% of outdoor unit capacity
Model/ Quantity CITY MULTI P10 - P140 / 9 P10 - P140 / 10 P10 - P140 / 12
Branch box*6 P15 - P100 / 8 P15 - P100 / 8 P15 - P100 / 8
Mixed
system
Branch box
1 unit*6
CITY MULTI P15 - P140 / 5 P15 - P140 / 5 P15 - P140 / 5
Branch box P15 - P100 / 5 P15 - P100 / 5 P15 - P100 / 5
Branch box
2 units*6
CITY MULTI P15 - P140 / 3 or 2 *5 P15 - P140 / 3 P15 - P140 / 3
Branch box P15 - P100 / 7 or 8 *5 P15 - P100 / 8 P15 - P100 / 8
Sound pressure level (SPL)
(measured in anechoic room)
dB <A> 49/51 50/52 51/53
Sound power level (PWL)
(measured in anechoic room)
dB <A> 69/71 70/72 71/73
Refrigerant piping
diameter
Liquid pipe mm (in) 9.52 (3/8)
Gas pipe mm (in) 15.88 (5/8)
Fan Type × Quantity Propeller Fan × 2
Airow rate m³/min 110
L/s 1,833
cfm 3,884
Control, Driving mechanism DC control
Motor output kW 0.074 + 0.074
External static press. 0
Compressor Type × Quantity Scroll hermetic compressor × 1
Manufacturer Mitsubishi Electric Corporation
Starting method Inverter
Capacity control % Cooling 26 to 100
Heating 20 to 100
Cooling 24 to100
Heating 18 to 100
Cooling 21 to 100
Heating 17 to 100
Motor output kW 2.9 3.5 3.9
Case heater kW 0
Lubricant FV50S (2.3liter)
External nish Galvanized Steel Sheet Munsell No. 3Y 7.8/1.1
External dimension H × W × D mm 1338 × 1050 × 330 (+40)
in 52-11/16 × 41-11/32 × 13 (+1-9/16)
Protection
devices
High pressure protection High pressure switch
Inverter circuit (COMP./FAN) Overcurrent detection, Overheat detection(Heat sink thermistor)
Compressor Compressor thermistor, Over current detection
Fan motor Overheating, Voltage protection, Over current detection
Refrigerant Type × original charge R410A 4.8 kg
Control Linear expansion valve
Net weight kg (lb) 125 (276)
Heat exchanger Cross Fin and Copper tube
HIC circuit (HIC: Heat Inter-Changer) Double pipe heat exchanger
Defrosting method Reversed refrigerant circuit
Standard
attachment
Document Installation Manual
Accessory Grounded lead wire ×1
Optional parts Joint: CMY-Y62-G-E, Header: CMY-Y64/68-G-E, Branch box: PAC-MK34/54BC
Remarks
*1. Nominal cooling conditions:
Indoor: 27°C D.B./19°C W.B. [81°F D.B/66°F W.B.]
Outdoor: 35°C D.B. [95°F D.B.]
Pipe length: 7.5 m [24-9/16 ft]
Level di󰀨erence: 0 m [0 ft]
*2. Nominal heating conditions:
Indoor: 20°C D.B. [68°F D.B.]
Outdoor: 7°C DB/6°C W.B. [45°F D.B./43°F W.B.]
Pipe length: 7.5 m [24-9/16 ft]
Level di󰀨erence: 0 m [0 ft]
*3. 10 to 52°C D.B. [50 to 126°F D.B.], when connecting following models: PKFY-P10/15/20/25/32VLM, PFFY-P20/25/32VLEM, PFFY-P20/25/32VL-
RM(M), PFFY-P20/25/32VKM, PFFY-P20/25/32VCM; and M series, S series, and P series type indoor unit.
*4. −15 to 52°C D.B. [50 to 126°F D.B.], when using an optional air protect guide [PAC-SH95AG-E]. However, this condition does not apply to the indoor
unit listed in *3.
*5. When connecting 7 indoor units via branch box, connectable CITY MULTI indoor units are 3; connecting 8 indoor units via branch box, connectable
CITY MULTI indoor units are 2.
*6. At least two indoor units must be connected when using branch box.
Notes:
• Nominal conditions *1, *2 are subject to ISO 15042.
• Due to continuing improvement, above specications are subject to change without notice.
• See the following for unit conversion: kcal/h = kW × 860, Btu/h = kW × 3,412, cfm = m³/min × 35.31, lb = kg/0.4536
Above specication data is subject to rounding variation.

OCH790 _14
5 DATA
5-1. Selection of indoor and outdoor units
5-1-1. Cooling
Design condition
Outdoor dry bulb temperature 39ºC
Total cooling load 10.6 kW
Room 1 Indoor dry bulb temperature 27ºC
Indoor wet bulb temperature 20ºC
Cooling load 4.6 kW
Room 2 Indoor dry bulb temperature 24ºC
Indoor wet bulb temperature 18ºC
Cooling load 6.0 kW
Other Indoor/Outdoor piping equivalent length 60 m
Capacity of indoor unit
P·FY series Model class of indoor unit 10 15 —20—25 32—40 —50 — 63 71 80 100 125 140
Model capacity (kW) 1.2 1.7 — 2.2 — 2.8 3.6 — 4.5 —5.6 —7.1 8.0 9.0 11.2 14.0 16.0
M series
S series
P series
Model class of indoor unit —15 18 20 22 25 —35 —42 50 60—71 80 100 — —
Model capacity (kW) —1.5 1.8 2.0 2.2 2.5 —3.5 —4.2 5.0 6.0 — 7.1 8.0 10.0 — —
■Cooling calculation
• Tentative selection of indoor units
Room1: PEFY-P50 5.6 kW (Rated)
Room2: PEFY-P71 8.0 kW (Rated)
In this case, the total capacity is 13.6. (5.6 + 8.0 = 13.6)
• Tentative selection of outdoor unit
Proper outdoor unit in this case is P125 as the total capacity of the indoor units is 13.6.
PUMY-P125 14.0 kW (Rated)
• Calculation for the corrected capacity of the total indoor units (CTi)
Correction factor for indoor design wet bulb temperature: Room 1 (20°C) 1.03 (Refer to Figure 1.)
Room 2 (18°C) 0.94 (Refer to Figure 1.)
CTi = Σ (Rated capacity of indoor unit × Correction factor for indoor temperature)
= 5.6 × 1.03 + 8.0 × 0.94
= 13.3 kW
• Calculation for the corrected capacity of the outdoor unit (CTo)
Correction factor for outdoor temperature (39°C) 0.92 (Refer to Figure 2.)
Correction factor for piping length (60 m) 0.88 (Refer to "Correcting Capacity".)
CTo = Rated capacity of outdoor unit × Correction factor for outdoor temperature × Correction factor for piping length
= 14.0 × 0.92 × 0.88
= 11.3 kW
• Determination of maximum system capacity (CTx)
Comparison between CTi and CTo:
CTi = 13.3 > CTo = 11.3, thus, select CTo.
CTx = CTo = 11.3 kW
• Comparison with essential load
Against the essential load 10.6 kW, the maximum system capacity is 11.3 kW: A proper outdoor unit is selected.
• Calculation for the maximum indoor unit capacity of each room
When CTx = CTo, use the calculation formula below.
Room1: CTx × Corrected capacity for Room1/CTi
= 11.3 × (5.6 × 1.03)/13.3
= 4.9 kW
The capacity is enough for the cooling load of Room 1 (4.6 kW): A proper indoor unit is selected.
Room2: CTx × Corrected capacity for Room2/CTi
= 11.3 × (8.0 × 0.94)/13.3
= 6.4 kW
The capacity is enough for the cooling load of Room 2 (6.0 kW): A proper indoor unit is selected.
Note:
• If CTx = CTi, refer to the calculation formula in "Heating" to calculate the maximum indoor unit capacity of each
room.
• Go on to the selection of units for heating after the selection for cooling has successfully completed. If failed, try
again until proper units are selected.

OCH790 _15
5-1-2. Heating
Design condition
Outdoor wet bulb temperature 2°C
Total heating load 13.2 kW
Room 1 Indoor dry bulb temperature 23°C
Heating load 5.4 kW
Room 2 Indoor dry bulb temperature 23°C
Heating load 7.8 kW
Other Indoor/Outdoor piping equivalent length 60 m
Capacity of indoor unit
P·FY series Model class of indoor unit 10 15 —20—25 32—40 —50 — 63 71 80 100 125 140
Model Capacity (kW) 1.4 1.9 —2.5 — 3.2 4.0 —5.0 — 6.3 — 8.0 9.0 10.0 12.5 16.0 18.0
M series
S series
P series
Model class of indoor unit —15 18 20 22 25 —35 —42 50 60—71 80 100 — —
Model Capacity (kW) —1.7 2.1 2.3 2.5 2.9 — 4.0 —4.8 5.7 6.9 — 8.1 9.3 11.2 — —
■Heating calculation
• Tentative selection of indoor units
Room1: PEFY-P50 6.3kW.(Rated)
Room2: PEFY-P71 9.0kW.(Rated)
In this case, the total capacity is 15.3. (6.3 + 9.0 = 15.3)
• Tentative selection of outdoor unit
Proper outdoor unit in this case is P125 as the total capacity of the indoor units is 15.3.
PUMY-P125 16.0 kW
• Calculation for the corrected capacity of the total indoor units (CTi)
Correction factor for indoor temperature: Room 1 (23°C) 0.88 (Refer to Figure 3.)
Room 2 (23°C) 0.88 (Refer to Figure 3.)
CTi = Σ (Rated capacity of indoor unit × Correction factor for indoor temperature)
= 6.3 × 0.88 + 9.0 × 0.88
= 13.5 kW
• Calculation for the corrected capacity of the outdoor unit (CTo)
Correction factor for outdoor temperature (2°C WB) 1.00 (Refer to Figure 4.)
Correction factor for piping length (60 m) 0.96 (Refer to "Correcting Capacity".)
Correction factor for defrosting 0.89 (Refer to Table 1.)
CTo = Rated capacity of outdoor unit × Correction factor for outdoor temperature × Correction factor for piping length ×
Correction factor for defrosting
= 16.0 × 1.00 × 0.96 × 0.89
= 13.7 kW
Table 1 Table of correction factor for frosting and defrosting
Outdoor inlet air temp. (°C) 6 42 0 -2 -4 -6 -8 -10 -15 -20
Correction factor 1.00 0.98 0.89 0.88 0.89 0.90 0.95 0.95 0.95 0.95 0.95
• Determination of maximum system capacity (CTx)
Comparison between CTi and CTo:
CTi = 13.5 < CTo = 13.7, thus, select CTi.
CTx = CTi = 13.5 kW
• Comparison with essential load
Against the essential load 13.2 kW, the maximum system capacity is 13.5 kW: Proper indoor units have been select-
ed.
• Calculation for the maximum indoor unit capacity of each room
When CTx = CTi, use the calculation formula below.
Room1: Rated capacity of Indoor unit × Correction factor for indoor temperature
= 6.3 × 0.88
= 5.5 kW
The capacity is enough for the heating load of Room 1 (5.4 kW): A proper indoor unit is selected.
Room2: Rated capacity of indoor unit × Corrected capacity for the indoor design temperature
= 9.0 × 0.88
= 7.9 kW
The capacity is enough for the heating load of Room 2 (7.8 kW): A proper indoor unit is selected.
Note:
• If CTx = CTo, refer to the calculation formula in "Cooling" to calculate the maximum indoor unit capacity of each
room.
• The selection of units is completed when proper units are selected.

OCH790 _16
5-2. Correction by temperature
The outdoor units have varied capacity at di󰀨erent designing temperature. With the nominal cooling/heating capacity
value and the ratio below, the capacity can be observed at various temperature.
5-2-1. Cooling
15 16 17 18 19 20 21 22 23
24
0.4
0.6
0.8
1.0
1.2
Correction factor of cooling capacity
Indoor temperature [°C WB]
<Figure 1> Indoor unit temperature correction
Correction factor of cooling capacity
Outdoor temperature [°C DB]
Indoor Temperature
-5.0 0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0 52.0
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
19°C WB
Correction factor of power input
Outdoor temperature [°C DB]
Indoor Temperature
-15.0 -10.0 -5.0 0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0 52.0
0.0
0.2
0.4
0.6
0.8
1.0
1.2
16°C WB
18°C WB
19°C WB
20°C WB 22°C WB 24°C WB
<Figure 2> Outdoor unit temperature correction
5-2-2. Heating
15 16 17 18 19 20 21 22 23 24 25 26
27
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Correction factor of heating capacity
Indoor temperature [°C DB]
<Figure 3> Indoor unit temperature correction

OCH790 _17
Correction factor of heating capacity
Outdoor temperature [°C WB]
20°C DB
-20.0 -15.0 -10.0 -5.0 0.0 5.0 10.0 15.0
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Correction factor of power input
Outdoor temperature [°C WB]
Indoor Temperature
-20.0 -15.0 -10.0 -5.0 0.0 5.0 10.0 15.0
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
25°C DB
15°C DB
20°C DB
<Figure 4> Outdoor unit temperature correction
5-3. Standard operation data (Reference data)
Operation
PUMY-P112VKM6(-BS)
PUMY-P112YKM5(-BS)
PUMY-P112VKM6-ER(BS)
PUMY-P112YKM5-ER(BS)
PUMY-P125VKM6(-BS)
PUMY-P125YKM5(-BS)
PUMY-P125VKM6-ER(BS)
PUMY-P125YKM5-ER(BS)
PUMY-P140VKM6(-BS)
PUMY-P140YKM5(-BS)
PUMY-P140VKM6-ER(-BS)
PUMY-P140YKM5-ER(-BS)
Operating conditions Ambient
temperature
Indoor DB/
WB
27°C/19°C 20°C/— 27°C/19°C 20°C/— 27°C/19°C 20°C/—
Outdoor 35°C 7°C/6°C 35°C 7°C/6°C 35°C 7°C/6°C
Indoor unit No. of connected units Unit 2 2 2
No. of units in operation 2 2 2
Model —50 × 1/63 × 1 63 × 2 63 × 1/80 ×1
Piping Main pipe m5 5 5
Branch pipe 2.5 2.5 2.5
Total pipe length 10 10 10
Fan speed — Hi Hi Hi
Amount of refrigerant kg 7.2 7.2 7.2
Outdoor unit Electric current A 16.17/5.26 17.38/5.67 21.67/7.12 21.91/7.22 25.84/8.58 25.54/8.48
Voltage V 230/400 230/400 230/400
Compressor frequency Hz 67 69 84 86 96 96
LEV opening Indoor unit Pulse 357 421 447 525 511 586
Pressure High pressure/Low pressure MPaG 2.70/0.94 2.86/0.70 2.86/0.88 2.87/0.67 2.95/0.85 2.95/0.65
Temp. of each section Outdoor
unit
Discharge °C 67.0 71.9 69.7 72.1 70.7 73.2
Heat exchanger outlet 40.2 2.0 40.8 1.3 43.7 0.9
Accumulator inlet 8.7 1.0 8.0 0.2 5.6 −0.6
Compressor inlet 10.7 1.3 9.1 0.1 7.8 −0.7
Indoor unit LEV inlet 18.9 32.4 17.7 33.0 17.0 33.4
Heat exchanger inlet 12.3 55.5 11.1 55.7 10.4 56.8

OCH790 _18
5-4. Standard capacity diagram
Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity following
the formula on "4-1. Selection of indoor and outdoor units".
PUMY-P112VKM6(-BS)
PUMY-P112YKM5(-BS)
PUMY-P112VKM6-ER(BS)
PUMY-P112YKM5-ER(BS)
■Cooling
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
5.0
10.0
15.0
20.0
25.0
V-Type
Current(A) Capacity(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Current(A) Input(kW)
380V
400V
415V
220V
230V
240V
Y-Type

OCH790 _19
■Heating
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0
18.0
0.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
V-Type
Current(A) Capacity(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Current(A) Input(kW)
380V
400V
415V
220V
230V
240V
Y-Type

OCH790 _20
PUMY-P125VKM6(-BS)
PUMY-P125YKM5(-BS)
PUMY-P125VKM6-ER(BS)
PUMY-P125YKM5-ER(BS)
■Cooling
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0
20.0
0.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0
20.0
0.0
1.0
2.0
3.0
4.0
5.0
6.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0
20.0
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0
20.0
0.0
5.0
10.0
15.0
20.0
25.0
V-Type
Current(A) Capacity(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Current(A) Input(kW)
380V
400V
415V
220V
230V
240V
Y-Type
