Mitsubishi Electric PLFY Series Operating manual

TECHNICAL & SERVICE MANUAL
Indoor unit
[Model Name] [Service Ref.]
PLFY-P15VCM-E3.TH
PLFY-P20VCM-E3.TH
PLFY-P25VCM-E3.TH
PLFY-P32VCM-E3.TH
PLFY-P40VCM-E3.TH
INDOOR UNIT
CONTENTS
1. SAFETY PRECAUTION..........................2
2. PARTS NAMES AND FUNCTIONS........ 6
3. SPECIFICATIONS.................................14
4. 4-WAY AIR FLOW SYSTEM.................16
5. OUTLINES AND DIMENSIONS............18
6. WIRING DIAGRAM...............................19
7. REFRIGERANT SYSTEM DIAGRAM...... 20
8. TROUBLESHOOTING.......................... 21
9. DISASSEMBLY PROCEDURE............. 29
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
Model name
indication
No.OCH569
PLFY-P15VCM-E3
PLFY-P20VCM-E3
PLFY-P25VCM-E3
PLFY-P32VCM-E3
PLFY-P40VCM-E3
June 2014
Note:
• This manual describes service data
of the indoor units only.
• RoHS compliant products have
<G> mark on spec name plate.
PARTS CATALOG (OCB569)
R407C R22R410A

32 3
Cautions for units utilizing refrigerant R407C
Do not use the existing refrigerant piping.
The old refrigerant and lubricant in the existing piping
contain a large amount of chlorine which may cause the
lubricant deterioration of the new unit.
Use “low residual oil piping”
If there is a large amount of residual oil (hydraulic oil, etc.)
inside the piping and joints, deterioration of the lubricant
will result.
Use ESTR , ETHER or HAB as the lubricant to
coat flares and flange connection parts.
If large amount of mineral oil enters, that can cause
deterioration of refrigerant oil etc.
Use liquid refrigerant to charge the system.
If gas refrigerant is used to seal the system, the composition
of the refrigerant in the cylinder will change and performance
may drop.
Do not use a refrigerant other than R407C.
If another refrigerant (R22, etc.) is used, the chlorine in the
refrigerant may cause the lubricant deterioration.
Use a vacuum pump with a reverse flow check valve.
The vacuum pump oil may flow back into the refrigerant
cycle and cause the lubricant deterioration.
If dust, dirt, or water enters the refrigerant cycle,
deterioration of the oil and compressor trouble may result.
Do not use the existing refrigerant piping.
The old refrigerant and lubricant in the existing piping contains a large amount of chlorine which may cause the lubricant
deterioration of the new unit.
Use “low residual oil piping”
If there is a large amount of residual oil (hydraulic oil, etc.) inside the piping and joints, deterioration of the lubricant will
result.
Use ESTR , ETHER or HAB as the lubricant to coat flares and flange connection parts.
If large amount of mineral oil enter, that can cause deterioration of refrigerant oil etc.
Use liquid refrigerant to seal the system.
If gas refrigerant is used to seal the system, the composition of the refrigerant in the cylinder will change and performance
may drop.
Do not use a refrigerant other than R407C.
If another refrigerant (R22, etc.) is used, the chlorine in the refrigerant may cause the lubricant deterioration.
Use a vacuum pump with a reverse flow check valve.
The vacuum pump oil may flow back into the refrigerant cycle and cause the lubricant deterioration.
Store the piping to be used during installation indoors with keep both ends sealed until just before brazing.
(Store elbows and other joints in a plastic bag.)
If dust, dirt, or water enters the refrigerant cycle, deterioration of the oil and compressor trouble may result.
Store the piping indoors, and both ends of the
piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the
unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused
by failure to follow the instructions.
Use the specified refrigerant only.
1SAFETY PRECAUTION
CAUTIONS RELATED TO NEW REFRIGERANT
OCH569

33
[3] Service tools
Use the below service tools as exclusive tools for R407C refrigerant.
[2] Refrigerant recharging
(1) Refrigerant recharging process
1Direct charging from the cylinder.
· R407C cylinder available on the market has a syphon pipe.
· Leave the syphon pipe cylinder standing and recharge it.
(By liquid refrigerant)
(2) Recharge in refrigerant leakage case
· After recovering the all refrigerant in the unit, proceed to working.
· Do not release the refrigerant in the air.
· After completing the repair service, recharge the cycle with the specified amount of liquid refrigerant.
Gravimeter
Unit
[1] Cautions for service
· After recovering the all refrigerant in the unit, proceed to working.
· Do not release refrigerant in the air.
· After completing the repair service, recharge the cycle with the specified amount of liquid refrigerant.
No. Tool name Specifications
1Gauge manifold · Only for R407C
· Use the existing fitting SPECIFICATIONS. (UNF7/16)
· Use high-tension side pressure of 3.43MPa·G or over.
2Charge hose · Only for R407C
· Use pressure performance of 5.10MPa·G or over.
3Electronic scale —
4Gas leak detector · Use the detector for R134a or R407C.
5Adaptor for reverse flow check · Attach on vacuum pump.
6Refrigerant charge base —
7Refrigerant cylinder · For R407C · Top of cylinder (Brown)
· Cylinder with syphon
8Refrigerant recovery equipment —
OCH569

4 5
Cautions for units utilizing refrigerant R410A
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition
change may occur in refrigerant and the efficiency will be
lowered.
Do not use refrigerant other than R410A.
If other refrigerant (R22 etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil etc.
Use a vacuum pump with a reverse flow check
valve.
Vacuum pump oil may flow back into refrigerant cycle and
that can cause deterioration of refrigerant oil etc.
Use the following tools specifically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A refrigerant.
Handle tools with care.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the efficiency will be lowered.
Flare tool
Electronic refrigerant
charging scale
Vacuum pump adaptor
Size adjustment gauge
Gauge manifold
Torque wrench
Gas leak detector
Charge hose
Tools for R410A
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
If large amount of mineral oil enters, that can cause deterio-
ration of refrigerant oil etc.
Do not use the existing refrigerant piping.
The old refrigerant and lubricant in the existing piping
contains a large amount of chlorine which may cause the
lubricant deterioration of the new unit.
Use “low residual oil piping”
If there is a large amount of residual oil (hydraulic oil, etc.)
inside the piping and joints, deterioration of the lubricant
will result.
Store the piping indoors, and both ends of the
piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
The refrigerant oil applied to flare and flange
connections must be ester oil, ether oil or
alkylbenzene oil in a small amount.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the
unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused
by failure to follow the instructions.
Use the specified refrigerant only.
OCH569

5
[1] Cautions for service
(1) Perform service after recovering the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) When performing service, install a filter drier simultaneously.
Be sure to use a filter drier for new refrigerant.
[2] Additional refrigerant charge
When charging directly from cylinder
· Check that cylinder for R410A on the market is syphon type.
· Charging should be performed with the cylinder of syphon standing vertically. (Refrigerant is charged from liquid phase.)
Gravimeter
Unit
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
No. Tool name Specifications
1Gauge manifold
· Only for R410A
· Use the existing fitting specifications. (UNF1/2)
· Use high-tension side pressure of 5.3MPa·G or over.
2Charge hose · Only for R410A
· Use pressure performance of 5.09MPa·G or over.
3Electronic scale
4Gas leak detector · Use the detector for R134a, R407C or R410A.
5Adaptor for reverse flow check · Attach on vacuum pump.
6Refrigerant charge base
7Refrigerant cylinder · Only for R410A · Top of cylinder (Pink)
· Cylinder with syphon
8Refrigerant recovery equipment
OCH569

76 7
Auto Air Swing Vane
Disperses airflow up and
down and adjusts the angle
of airflow direction.
Grille
Filter
Removes dust and pollutants
from drawn in air.
Horizontal Air Outlet
Sets horizontal airflow automatically
during cooling or dehumidifying.
Air Intake
Draws in air from room.
2PARTS NAMES AND FUNCTIONS
2-1. Indoor Unit
OCH569

77
Function buttons
F1 F2 F3 F4
Press to turn ON/OFF the indoor unit.
ON / OFF button
When the backlight is off, pressing any button turns
the backlight on and does not perform its function.
(except for the (ON / OFF) button)
The functions of the function buttons change depending on
the screen. Refer to the button function guide that appears
at the bottom of the LCD for the functions they serve on a
given screen.
When the system is centrally controlled, the button function
guide that corresponds to the locked button will not appear.
Press to save the setting.
SELECT button
Press to return to the previous screen.
RETURN button
Press to bring up the Main menu.
MENU button
Operation settings will appear.
When the backlight is off, pressing any button turns the
backlight on and it will stay lit for a certain period of time
depending on the screen.
Backlit LCD
This lamp lights up in green while the unit is in operation.
It blinks while the remote controller is starting up or when
there is an error.
ON / OFF lamp
Main display : Press to change the operation mode.
Main menu : Press to move the cursor down.
Function button F1
Main display : Press to decrease temperature.
Main menu : Press to move the cursor up.
Function button F2
Main display : Press to increase temperature.
Main menu : Press to go to the previous page.
Function button F3
Main display : Press to change the fan speed.
Main menu : Press to go to the next page.
Function button F4
Fri
Room
Set temp.
Mode Temp. Fan
Cool Auto
Main
Main display:
Cursor Page
Main menu
Vane·Louver·Vent. (Lossnay)
High power
Timer
Weekly timer
OU silent mode
<Main display> <Main menu>
Function guide
2-2. WIRED REMOTE CONTROLLER <PAR-30MAA/PAR-31MAA>
The functions which can be used are restricted according to each model.
: Supported : Unsupported
Function PAR-30MAA/PAR-31MAA PAR-21MAA
Slim City multi
Body Product size H × W × D (mm) 120 × 120 × 19 120 × 130 × 19
LCD Full Dot LCD Partial Dot LCD
Backlight
Energy-saving Energy-saving operation schedule
Automatic return to the preset temperature
Restriction Setting the temperature range restriction
Function Operation lock function
Weekly timer
On / Off timer
High Power
Manual vane angle
Wired remote controller function
OCH569

89
Fri
Mode Temp. Fan
Room
Cool Auto
Set temp.
Fri
Cool
Mode Temp. Fan
AutoSet temp.
Fri
Mode Temp. Fan
Room
Cool Auto
Set temp.
Fri
Cool
Mode Temp. Fan
AutoSet temp.
The main display can be displayed in two different modes: "Full" and "Basic".
T
he factory setting is "Full". To switch to the "Basic" mode, change the setting on the Main display setting.
<Full mode> <Basic mode>
All icons are displayed for explanation.
Most settings (except ON / OFF, mode, fan speed, temperature) can be made from the Menu screen.
Indoor unit operation mode appears here.
Operation mode
Preset temperature appears here.
Preset temperature
Current time appears here.
Clock (See the Installation Manual.)
Fan speed
Fan speed setting appears here.
Functions of the corresponding buttons appear here.
Button function guide
Appears when the ON/OFF operation is centrally controlled.
Appears when the operation mode is centrally controlled.
Appears when the preset temperature is centrally controlled.
Appears when the lter reset function is centrally controlled.
Indicates when lter needs maintenance.
Current room temperature appears here.
Room temperature
(See the Installation Manual.)
Appears when the buttons are locked.
Appears when the On/Off timer or Night setback function is
enabled.
Appears when the Weekly timer is enabled.
Appears while the units are operated in the energy-save
mode.
Appears when the built-in thermistor on the remote control-
ler is activated to monitor the room temperature.
appears when the thermistor on the indoor unit is acti-
vated to monitor the room temperature.
Indicates the vane setting.
Indicates the louver setting.
Indicates the ventilation setting.
Appears when the preset temperature range is restricted.
OCH569

9
Not all functions are available on all models of indoor units.
Energy saving
Auto return
Schedule
Night setback
Main menu Press the MENU button.
Move the cursor to the desired item with the F1 and F2 buttons, and press the SELECT button.
Vane · Louver · Vent. (Lossnay)
High power
Weekly timer
Restriction
Maintenance
Initial setting
On / Off timer
Auto-Off timer
Temp. range
Operation lock
Manual vane angle
Main / Sub
Timer
Main display
Contrast
Display details
Auto mode
Administrator password
Language selection
Service
Input maintenance info.
Function setting
Lossnay (City Multi only)
Check
Self check
Maintenance password
Remote controller check
Test run
Clock
Auto descending panel
Menu structure
Filter Information
Error Information
OCH569

10 11
Setting and display items Setting details
Vane · Louver · Vent.
(Lossnay)
Use to set the vane angle.
• Select a desired vane setting from ve different settings.
Use to turn ON / OFF the louver.
• Select a desired setting from "ON" and "OFF."
Use to set the amount of ventilation.
• Select a desired setting from "Off," "Low," and "High."
High power Use to reach the comfortable room temperature quickly.
• Units can be operated in the High-power mode for up to 30 minutes.
Timer On/Off timer* Use to set the operation On/Off times.
• Time can be set in 5-minute increments.
Auto-Off
timer
Use to set the Auto-Off time.
• Time can be set to a value from 30 to 240 in 10-minute increments.
Weekly timer* Use to set the weekly operation On / Off times.
• Up to eight operation patterns can be set for each day.
(Not valid when the On/Off timer is enabled.)
Restriction Temp. range Use to restrict the preset temperature range.
• Different temperature ranges can be set for different operation modes.
Operation
lock
Use to lock selected functions.
• The locked functions cannot be operated.
Energy
saving
Auto return Use to get the units to operate at the preset temperature after performing energy-save
operation for a specied time period.
• Time can be set to a value from 30 and 120 in 10-minute increments.
(This function will not be valid when the preset temperature ranges are restricted.)
Schedule* Set the start/stop times to operate the units in the energy-save mode for each day of the
week, and set the energy-saving rate.
• Up to four energy-save operation patterns can be set for each day.
• Time can be set in 5-minute increments.
• Energy-saving rate can be set to a value from 0% or 50 to 90% in 10% increments.
Night setback* Use to make Night setback settings.
• Select "Yes" to enable the setting, and "No" to disable the setting. The temperature range and
the start/stop times can be set.
Filter information Use to check the lter status.
• The lter sign can be reset.
Error information Use to check error information when an error occurs.
• Check code, error source, refrigerant address, unit model, manufacturing number, contact
information (dealer's phone number) can be displayed.
(The unit model, manufacturing number, and contact information need to be registered in
advance to be displayed.)
Maintenance Manual
vane angle
Use to set the vane angle for each vane to a xed position.
Initial setting Clock Use to set the current time.
Main display Use to switch between "Full" and "Basic" modes for the Main display.
• The initial setting is "Full."
Contrast Use to adjust screen contrast.
Language
selection
Use to select the desired language.
Main menu list
* Clock setting is required.
Continue to the next page
OCH569

11
Setting and display items Setting details
Service
Function setting
(City Multi)
Use to make settings for indoor unit's functions.
Input
maintenance
Select "Input maintenance Info." from the Service menu to bring up the Maintenance
information screen.
The following settings can be made from the Maintenance Information screen.
• Model name input • Serial No. input • Dealer information input
Function setting
( City Multi only)
Make the settings for the indoor unit functions via the remote controller as necessary.
LOSSNAY
setting
(City Multi only)
This setting is required only when the operation of City Multi units is interlocked with
LOSSNAY units.
Check Error history: Display the error history and execute delete error history.
Refrigerant leak check: Refrigerant leaks can be judged.
Smooth maintenance: The indoor and outdoor maintenance data can be displayed.
Request cord: Details of the operation data including each thermistor temperature and error
history can be checked.
Self check Error history of each unit can be checked via the remote controller.
Maintenance
password
Take the following steps to change the maintenance password.
Remote
controller
check
When the remote controller does not work properly, use the remote controller checking
function to troublushoot the problem.
OCH569

12 13
°F°C
°F°C
ERROR CODE
AFTER
TIMER
TIME SUN MON TUE WED THU FRI SAT
ON
OFF
Hr
AFTER
FILTER
FUNCTION
ONLY1Hr.
WEEKLY
SIMPLE
AUTO OFF
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
•
•
Display Section
For the purpose of explanation,
all parts of the display are shown.
During actual operation, only
the relevant items will be lit.
Identifies the current operation
Shows the operating mode, etc.
*Multilanguage display is available.
“Centrally Controlled” indicator
Indicates that operation from the
remote controller has been prohib-
ited by a master controller.
“Timer is Off” indicator
Indicates that the timer is off.
Temperature Setting
Shows the target temperature.
Day-of-Week
Shows the current day of the week.
Time/Timer Display
Shows the current time, unless the simple or Auto Off
timer is set.
If the simple or Auto Off timer is set, the time to be
switched off is shown.
“Sensor” indication
Displays when the remote controller
sensor is used.
“Locked” indicator
Indicates that remote controller but-
tons have been locked.
“Clean The Filter” indicator
To be displayed on when it is time to
clean the filter.
Timer indicators
The indicator comes on if the corre-
sponding timer is set.
Up/Down Air Direction indica-
tor
The indicator shows the direc-
tion of the outcoming airflow.
“One Hour Only” indicator
Room Temperature display
Shows the room temperature. The room
temperature display range is 8 – 39:.
The display blinks if the temperature
is less than 8:or 39:or more.
Louver display
Indicates the action of the swing louver.
Does not appear if the louver is not
running.
(Power On indicator)
Indicates that the power is on.
Fan Speed indicator
Shows the selected fan speed.
Ventilation indicator
Appears when the unit is running in
Ventilation mode.
Operation Section
Temperature setting buttons
Down
Up
Timer Menu button
(Monitor/Set button)
Mode button (Return button)
Set Time buttons
Back
Ahead
Timer On/Off button
(Set Day button)
Opening the
cover
ON/OFF button
Fan Speed button
Filter button
(<Enter> button)
Test Run button
Check button (Clear button)
Airflow Up/Down button
Louver button
( Operation button)
To return operation
number
Ventilation button
( Operation button)
To go to next operation
number
Note:
“PLEASE WAIT” message
This message is displayed for approximately 3 minutes when power is supplied to the indoor unit or when the unit is recovering from a power failure.
“NOT AVAILABLE” message
This message is displayed if an invalid button is pressed (to operate a function that the indoor unit does not have).
If a single remote controller is used to operate multiple indoor units simultaneously that are different types, this message will not be displayed as
far as any of the indoor units is equipped with the function.
Built-in temperature sensor
Displays if the airflow is set to
low or downward during COOL
or DRY mode. (Operation varies
according to model.)
The indicator goes off in 1 hour,
when the airflow direction
also changes.
2-3. WIRED REMOTE CONTROLLER <PAR-21MAA>
OCH569

13
2-4. Wireless remote controller
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
NOT AVAILABLE
CHECK TEST RUN
°C
AMPM
AMPM
VANE CONTROL button
Used to change the air flow
CLOCK button
RESET button
SET button
ON/OFF button
The unit is turned ON and OFF alternately
each time the button is pressed.
LOUVER button
Changes left/right airflow direction.
(Not available for this model.)
MODE SELECT button
Used to switch the operation mode between
cooling, drying, fan, heating and auto mode.
CHECK-TEST RUN buttons
Only press this button to perform an
inspection check or test operation.
Do not use it for normal operation.
FAN SPEED SELECT button
Used to change the fan speed.
TIMER display
Displays when in timer operation or when
setting timer.
buttons
SET TEMPERATURE button sets any desired
room temperature.
CLOCK display
Displays the current time.
“ ” “ ” display
Displays the order of timer operation.
“ ” “ ” display
Displays whether timer is on or off.
In case the outdoor unit is cool only type,
the heating and auto mode are not
available.
Buttons used to set the “hour and minute” of
the current time and timer settings.
“h” and “min” buttons
display
display
FAN SPEED display indicates which fan
speed has been selected.
display
The vertical direction of air flow is indicated.
display
Blinks when model is selected.
display
display
CHECK and TEST RUN display indicate that
the unit is being checked or test-run.
display
OPERATION MODE display
Operation mode display indicates which
operation mode is in effect.
TIMER CONTROL buttons
AUTO STOP (OFF timer): when this switch is
set, the air conditioner will be automatically
stopped at the preset time.
AUTO START (ON timer): when this switch is
set, the air conditioner will be automatically
started at the preset time.
MODEL SELECT
CHECK
TEST RUN
SET TEMP. display indicates the set desired
temperature.
Lights up while the signal is transmitted to
the indoor unit when the button is pressed.
Note:
OCH569

1514 15
3-1. SPECIFICATIONS
3SPECIFICATIONS
*1 Nominal cooling conditionNote :
Indoor :
Outdoor :
Pipe length :
Level difference :
27˚CDB/19˚CWB (81˚FDB/66˚FWB)
35˚CDB (95˚FDB)
7.5 m (24-9/16 ft)
0m (0 ft)
*2 Nominal cooling condition
27˚CDB/19.5˚CWB (81˚FDB/67˚FWB)
35˚CDB (95˚FDB)
5m (16-3/8 ft)
0m (0 ft)
*3 Nominal heating condition Unit converter
20˚CDB (68˚FDB)
7˚CDB/6˚CWB (45˚FDB/43˚FWB)
7.5 m (24-9/16 ft)
0 m (0 ft)
*1 and *3 are subject to JIS B8615-1.
kcal = kW × 860
BTU/h
cfm = m3/min x 35.31
lb = kg / 0.4536
Model
Power source
Cooling capacity
(Nominal)
Heating capacity
(Nominal )
External finish
External dimension
H × W × D
Net weight
Decoration
panel
Heat exchanger
FAN
Noise level (Low-Mid-High)
(measured in anechoic room)
Insulation material
Air filter
Protection device
Refrigerant control device
Connectable outdoor unit
Diameter of
refrigerant pipe
Field drain pipe size
Standard
attachment
Remark
Power input
Current input
Power input
Current input
Model
External finish
Dimension
H × W × D
Net Weight
Cord heater
Type × Quantity
External static press.
Motor type
Motor output
Driving mechanism
Airflow rate
(Low-Mid-High)
Liquid
Gas
Document
Accessory
Optional parts
Installation
kW
kcal/ h
BTU/ h
kcal/ h
kW
A
kW
kcal/ h
BTU/ h
kW
A
mm
in
kg (lb)
mm
in
kg (lb)
kW
kW
m3 / min
L / s
cfm
dB <A>
mm (in)
mm (in)
mm (in)
*1
*1
*1
*2
*3
*3
*3
PLFY-P20VCM-E3
Single phase 220-230-240V 50Hz
Unit: Galvanized sheets with grey heat insulation
White Munsell(6.4Y 8.9/0.4)
Cross fin (Aluminum fin and copper tube)
Turbo fan × 1
Single phase induction motor
Direct-driven by motor
Polyethylene foam
PP honeycomb fabric (long life type)
Fuse
LEV
R410A, R407C, R22 CITY MULTI
Installation manual, Instruction book
Drain hose I.D. 32mm (1-1/4"), Wireless junction cable
Decoration panel : SLP-2AAW or SLP-2ALW
*PLFY-P-VCM-E3 should use together with Decoration panel.
2.2
1,900
7,500
2,000
0.04
0.31
2.5
2,200
8,500
0.02
0.20
208 × 570 × 570
8-1/4" × 22-1/2" × 22-1/2"
15 (33)
SLP-2AAW or SLP-2ALW
20 × 650 × 650
13/16" × 25-5/8" × 25-5/8"
3 (7)
0.015
8-9-10
133-150-167
283-318-353
28-31-35
ø6.35 (ø1/4") Flare
ø12.7 (ø1/2") Flare
PLFY-P25VCM-E3
2.8
2,400
9,600
2,500
0.05
0.37
3.2
2,800
10,900
0.03
0.26
208 × 570 × 570
8-1/4" × 22-1/2" × 22-1/2"
15 (33)
20 × 650 × 650
13/16" × 25-5/8" × 25-5/8"
3 (7)
0.015
0.05
8-9-10
133-150-167
283-318-353
29-31-37
ø6.35 (ø1/4") Flare
ø12.7 (ø1/2") Flare
PLFY-P32VCM-E3
3.6
3,100
12,300
3,150
0.05
0.37
4.0
3,400
13,600
0.03
0.26
208 × 570 × 570
8-1/4" × 22-1/2" × 22-1/2"
16.5 (37)
20 × 650 × 650
13/16" × 25-5/8" × 25-5/8"
3 (7)
0.015
8-9-11
133-150-183
283-318-388
29-33-38
ø6.35 (ø1/4") Flare
ø12.7 (ø1/2") Flare
PLFY-P40VCM-E3
4.5
3,900
15,400
4,000
0.05
0.37
5.0
4,300
17,100
0.03
0.26
208 × 570 × 570
8-1/4" × 22-1/2" × 22-1/2"
16.5 (37)
20 × 650 × 650
13/16" × 25-5/8" × 25-5/8"
3 (7)
0.015
0 Pa (0 mmH2O)0 Pa (0 mmH2O)0 Pa (0 mmH2O)0 Pa (0 mmH2O)
PLFY-P15VCM-E3
1.7
1,450
5,800
1,500
0.04
0.31
1.9
1,600
6,500
0.02
0.20
208 × 570 × 570
8-1/4" × 22-1/2" × 22-1/2"
15 (33)
SLP-2AAW or SLP-2ALW
20 × 650 × 650
13/16" × 25-5/8" × 25-5/8"
3 (7)
0.015
8-8.5-9
133-142-150
283-300-353
28-30-31
ø6.35 (ø1/4") Flare
ø12.7 (ø1/2") Flare
0 Pa (0 mmH2O)
8-9-11
133-150-183
283-318-388
30-34-39
ø6.35 (ø1/4") Flare
ø12.7 (ø1/2") Flare
Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other items shall be referred to
the Installation Manual.
O.D. 32mm (1-1/4") (PVC pipe VP-25 connectable)
SLP-2AAW or SLP-2ALW SLP-2AAW or SLP-2ALW SLP-2AAW or SLP-2ALW
• Due to continuing improvement, above specification may be subject to change without notice.
•Nominal conditions
= kW × 3,412
OCH569

1515
3-2. ELECTRICAL PARTS SPECIFICATIONS
Parts name
Service ref.
Symbol
TH21
TH22
TH23
FUSE
Resistance 0:/15k", 10:/9.6k", 20:/6.3k", 25:/5.4k", 30:/4.3k", 40:/3.0k"
Resistance 0:/15k", 10:/9.6k", 20:/6.3k", 25:/5.4k", 30:/4.3k", 40:/3.0k"
Resistance 0:/15k", 10:/9.6k", 20:/6.3k", 25:/5.4k", 30:/4.3k", 40:/3.0k"
250V 6.3A
PLFY-P25VCM-E3.THPLFY-P20VCM-E3.TH
PLFY-P15VCM-E3.TH PLFY-P32VCM-E3.TH PLFY-P40VCM-E3.TH
Thermistor
(Room temperature
detection)
Thermistor
(Pipe temperature
detection/ Liquid)
Thermistor
(Pipe temperature
detection/ Gas)
Fuse
(Indoor controller board)
Fan motor
Electric heater
(Condensation proof)
Power supply
terminal block
Transmission
terminal block
MA remote controller
terminal block
OUTPUT 50 W
MSBPC20M13
DC12V 300"/phase
PLD-12230ME-1
INPUT 12/10.8W 24R/Hr
Thermistor resistance 0:/6k", 10:/3.9k", 20:/2.6k", 25:/2.2k", 30:/1.8k", 40:/1.3k"
DC12V Stepping motor drive, Port dimension [5.2 (0~2000pulse)
EDM-40YGME
Drain pump
Drain sensor
Linear expansion valve
[coil]
* Refer to WIRING DIAGRAM for the supplied voltage.
MF
DP
DS
LEV
H2
TB2
TB5
TB15
240V 15W
(L, N, ;) Rated to 330V 30A*
(M1, M2, S) Rated to 250V 20A*
(1, 2) Rated to 250V 10A*
MVVane motor
OCH569

17
16
17
44-WAY AIR FLOW SYSTEM
4-1. FRESH AIR INTAKE (Location for installation)
At the time of installation, use the duct holes (cut out) located at the positions shown in following diagram, as and when required.
Detail drawing of fresh air intake
Ceiling surface
Refrigerant pipe
Drain pipe
Electrical Box
Cut out hole
[73.4
Burring hole
3-[2.8 hole
[100
118
25
120°
120°
Fresh air intake
Static pressure : P [Pa]
Air flow : Q [m3/min]
50
-50
-100
-150
-200
-250
-300
00.5 1.0 1.5 2.0 2.5 3.0 3.5
PLFY-P15VCM-E3.TH PLFY-P20VCM-E3.TH PLFY-P25VCM-E3.TH
PLFY-P32VCM-E3.TH PLFY-P40VCM-E3.TH
Taking air into the unit
4-2. FRESH AIR INTAKE AMOUNT & STATIC PRESSURE CHARACTERISTICS
Q
0
BA
C
1Curve in the
left graphs
Duct characteristics
at site
Q
A
E C
2
Q
Qa
A D
3
How to read curves
NOTE: Fresh air intake amount should be 20% or less of
whole air amount to prevent dew dripping.
Q…Designed amount of fresh air intake
<m3/min>
A…Static pressure loss of fresh air
intake duct system with air flow
amount Q <Pa>
B…Forced static pressure at air condi-
tioner inlet with air flow amount Q
<Pa>
C…Static pressure of booster fan with
air flow amount Q <Pa>
D…Static pressure loss increase
amount of fresh air intake duct sys-
tem for air flow amount Q <Pa>
E…Static pressure of indoor unit with
air flow amount Q <Pa>
Qa…Estimated amount of fresh air
intake without D <m3/min>
Multiple remote
controller adapter
PAC-SA88HA-E
Indoor controller board
Distance between indoor
controller board and relay
must be within 10m.
Be sure to secure insulation
material by tape, etc.
5Green
Yellow
Orange
Connector (5P)
Indoor unit side
Multiple remote
controller adapter
PAC-SA88HA-E
Be sure to secure insulation
material by tape, etc.
Installation at site
CN51
on
indoor unit
board
Red
Brown
1
~
CN51
MB
+
4-3. OPERATION IN CONJUNCTION
WITH DUCT FAN (Booster fan)
• Whenever the indoor unit operates, the duct fun also
operates.
(1) Connect the optional multiple remote controller
adapter(PAC-SA88HA-E) to the connector CN51 on
the indoor controller board.
(2) Drive the relay after connecting the 12V DC relay
between the Yellow and Orange connector wires.
MB: Electromagnetic switch power relay for duct fan.
X: Auxiliary relay
(For DC 12V, coil rating: 1.0W or below)
OCH569

1717
4-4. FIXING HORIZONTAL VANE
Horizontal vane of each air outlet can be fixed according to the environment where it is installed.
Setting procedures
1) Turn off a main power supply (Turn off a breaker).
2) Disconnect the vane motor connector of the direction of the arrow with pressing the unlocking button as shown in figure
below.
Insulate the disconnected connector with the plastic tape.
Vane motor
Horizontal vane
Connector Unlocking button
Vane motor
3) Set a vertical vane of the air outlet, which is to be fixed by the hand slowly within the range in the table below.
Measured standard
position of the grille
Horizontal vane
Standard of
horizontal position
Dimension A (mm) 21 25 28 30
Level 30°
(Min.) Downward 45° Downward 55° Downward 70° (Max.)
Note: Dimension between 21 mm and 30 mm can be arbitrarily set.
Caution Do not set the dimension out of the range.
Erroneous setting could cause dew drips, smudge on ceiling or malfunction of unit.
<Set range>
.
OCH569

18 19
5OUTLINES AND DIMENSIONS
Brand label
15~37 15~37576~620
530
1
2
Grille
Fresh air intake
Drain pipe
VP-25 connection
Vane motor
Drain hole
V/M
V/M
V/M
V/M
Air intake grille
55 35
35 55
Auto vane
Grille
Air intake hole
Air intake hole
Air outlet hole
Air outlet hole
301
301
Detail drawing of fresh air intake
Ceiling surface
Cut out hole
[73.4
Burring hole
3-[2.8
[100
118
25
120-
120-
377
377
650
650
Suspension bolt M10 or W3/8
230
18248
Terminal block Ceiling surface
235
208
27 +5
0
193
20
93
38~58
66121
17 202
87
31
Ceiling hole
15~37
576~620
420 570 335
199
352
335
Ceiling hole
Grille
Drain pipe
VP-25 connection
(O.D.[32)
Drain hole
55 35
35 55
Auto vane
Grille
Air intake hole
Air outlet hole
301
Detail drawing of fresh air intake
Ceiling surface
Cut out hole
Burring hole
118
25
377
377
650
18248
Terminal block
235
208
27 +5 193
20
93
66121
87
31
15~37
570 335
199
352
335
570
Grille
Drain pipe
Drain hole
55 35
35 55
Auto vane
Grille
Air intake hole
Air outlet hole
301
Detail drawing of fresh air intake
Ceiling surface
Cut out hole
Burring hole
118
25
377
650
Suspension bolt lower edge
18248
Wiring entry
Terminal block
235
208
27 +5 193
20
93
66121
56 57
87
31
Suspension bolt pitch
570 335
199
352
335
Suspension bolt pitch
Models 1 2
PLFY-P15VCM-E3
PLFY-P20VCM-E3
PLFY-P25VCM-E3
PLFY-P32VCM-E3
PLFY-P40VCM-E3
Refrigetant pipe
(6.35mm dia.)
flared connection
1/4 inch
Refrigetant pipe
(12.7mm dia.)
flared connection
1/2 inch
Unit: mm
PLFY-P15VCM-E3.TH PLFY-P20VCM-E3.TH PLFY-P25VCM-E3.TH
PLFY-P32VCM-E3.TH PLFY-P40VCM-E3.TH
OCH569

19
WIRING DIAGRAM6
SYMBOL
CN32
TERMINAL
BLOCK
POWER SUPPLY
TRANSMISSION 14NC
CN51
MA-REMOTE CONTROLLER
CN52
ROOM TEMP DETECTION
CN105 (0
°C /15kΩ,25°C/5.4kΩ)
F1
PIPE TEMP DETECTION/LIQUID
SW1 (0°C/15kΩ,25°C/5.4kΩ)
SW2
PIPE TEMP DETECTION/GAS
SW3 (0°C/15kΩ,25°C/5.4kΩ)
SW4
I.B
SYMBOL
INDOOR CONTROLLER BOARD MV
NAME
TH23
TH22
TH21
REMOTE INDICATION
CENTRALLY CONTROL
JEMA HA TERMINAL-A
REMOTE SWITCH
MODEL SELECTION
MODE SELECTION
FUSE(T6.3AL 250V)
NAME
OPTION PART
TB2
TB5
TB15
THERMISTOR
VANE MOTOR
MODE SELECTION
CAPACITY CODE
IT TERMINAL
SW11
BZSW12
LED1SW14
LED2SWE
RUX1
SW1
SW2
LEV
MF
ADDRESS SETTING 1s DIGIT
DRAIN PUMP/DEW PREVENTION HEATER
DRAIN PUMP(TEST MODE)
BRANCH No.
ADDRESS SETTING 10ths DIGIT
H2
DP DRAIN PUMP
DS
DEW PREVENTION HEATER
DRAIN SENSOR
W.B
FAN MOTOR
LINEAR EXPANSION VALVE
LED(PREPARATION FOR HEATING:ORANGE)
RECEIVING UNIT
EMERGENCY OPERATION(HEAT)
EMERGENCY OPERATION(COOL)
LED(OPERATION INDICATOR:GREEN)
PCB FOR WIRELESS REMOTE CONTROLLER
BUZZER
Notes:
1.At servicing for outdoor unit,always follow the wiring diagram of outdoor unit.
2.In case of using MA-Remote controller, please connect to TB15.
(Remote controller wire is non-polar.)
3.In case of using M-NET, please connect to TB5. (Transmission line is non-polar.)
4.Symbol [S]of TB5 is the shield wire connection.
5.Symbols used in wiring diagram above are, : terminal block, : connecter.
6.The setting of the SW2 dip switches differs in the capacity. For the detail,
refer to the fig:
* 1.
Mark Meaning Function
Power supply for
MA-Remote controller
Main power supply (Indoor unit)
Power on → Iamp is lit
LED on indoor board for service
LED1 Main power supply
Power supply for MA-Remote controller
on → Iamp is lit
LED2
MODELS
P20
SW2
123456
ON
OFF
P15
123456
ON
OFF
P25
123456
ON
OFF
P32
123456
ON
OFF
P40
123456
ON
OFF
LED1
1 2 3 4 5
SW4
ON
OFF
1 2 3 4 5 6 78 9 10
SW1 SW3
1 2 3 4 5 6 78 9
10
1 2 3 4 5 6
SW2
ON
OFF
ON
OFF
See fig *1
TB5
M1
M2
TB15
1
S
2
TO MA-REMOTE
CONTROLLER
DC8.7-13V
TO OUTDOOR UNIT
BC CONTROLLER
M-NET REMOTE
CONTROLLER
DC24-30V
SWE
OFF ON
10
LED2
LED1
1
1
9
2
2
3
3
4
6
6
7
7
8
5
5
5
W.B
GRILLE
M
MV
RED
YLW
YLW
YLW
H2
WHT
VLT
ORN
RED
YLW
ORN
BLU
PINK
GRY
SKY BLU
BLU
BRN
5
M
MV
5
9
5
M
MV
5
M
MV
CNB
SW1
BZ
RU
SW2
L
N
BLU
YLW
YLW
YLW
YLW
TB2
RED
GRN/YLW
PULL
BOX
FUSE
(16A) BREAKER (16A)
TO NEXT
INDOOR
UNIT
POWER
SUPPLY
~/N220-240V
50Hz
M
LEV
RED
YLW
WHT
ORN BLU
RED BLU BLK
BRN
0
1
2
3
4
5
6
7
8
9
SW12
0
1
2
3
4
5
6
7
8
9
SW11SW14
10ths
DIGIT 1s DIGIT
BRANCH
No.
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
1
3
M
1~
DP
+
–
ON
OFF
I.B
MF
MS
3~
19
CN90
(WHT)
16 16
CN60
(WHT)
15
CN51
(WHT)
14
CN41
(WHT)
15
CN52
(GRN)
15
CN105
(RED)
t°
t°
t°
t°
DS
TH22
TH21
TH23
13
CN31
(WHT)
13
CN32
(WHT)
12
CN20
(RED)
12
CN29
(BLK)
12
CN21
(WHT)
CN6V
(GRN)
17 6 5 4
CNMF
(WHT)
15
CND
(BLK)
<fig.*1>
The black square (■) indicates
a switch position. <*1>
X1 13
13
12
CN2M
(BLU)
1
3
CN3A
(BLU)
BLU YLW WHT BLK RED
2
5
9
CNP
(BLU)
F1
CNC
(RED)
J42
J41 Pair No.
LED2 BLU
BLU
ORN
ORN
* Case of wireless grille type
[LEGEND]
PLFY-P15VCM-E3.TH PLFY-P20VCM-E3.TH PLFY-P25VCM-E3.TH
PLFY-P32VCM-E3.TH PLFY-P40VCM-E3.TH
OCH569

20 21
7REFRIGERANT SYSTEM DIAGRAM
Strainer (#50mesh)
Strainer (#100mesh)
Unit: mm (inch)
Strainer1 (#50mesh)
Strainer2 (#100mesh)
Heat exchanger
Thermistor (Room temparature detection) TH21
Thermistor (Pipe temperature detection/ Gas) TH23
Thermistor (Pipe
temperature
detection/ Liquid) TH22
Linear expansion valve
Gas pipe
Liquid pipe
Flare connection
Gas pipe
Liquid pipe
[12.7(1/2)
[6.35(1/4)
PLFY-P15VCM-E3.TH PLFY-P20VCM-E3.TH PLFY-P25VCM-E3.TH
PLFY-P32VCM-E3.TH PLFY-P40VCM-E3.TH
OCH569
