Mitsubishi Electric Mr. SLIM Mr. SLIM S KA Series User manual
Air Conditioners
PKA-M·KA(L) Series
INSTALLATION MANUAL
For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing
the air-conditioner unit.
INSTALLATIONSHANDBUCH
Aus Sicherheitsgründen und zur richtigen Anwendung vor Installation der Klimaanlage die vorliegende
Bedienungsanleitung und das Installationshandbuch gründlich durchlesen.
MANUEL D’INSTALLATION
Avant d’installer le climatiseur, lire attentivement ce manuel, ainsi que le manuel d’installation de l’appareil
extérieur pour une utilisation sûre et correct.
INSTALLATIONSMANUAL
Läs bruksanvisningen och utomhusenhetens installationshandbok noga innan luftkonditioneringen installeras
så att den används på ett säkert och korrekt sätt.
INSTALLATIEHANDLEIDING
Lees deze handleiding en de installatiehandleiding van het buitenapparaat zorgvuldig door voordat u met het
installeren van de airconditioner begint.
MANUALE DI INSTALLAZIONE
Per un uso sicuro e corretto, prima di installare il condizionatore d’aria leggere attentamente il presente
manuale ed il manuale d’installazione dell’unità esterna.
MANUAL DE INSTALACIÓN
Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de
aire acondicionado.
MANUAL DE INSTALAÇÃO
Para uma utilização segura e correcta, leia atentamente este manual e o manual de instalação da unidade
exterior antes de instalar o aparelho de ar condicionado.
INSTALLATIONSMANUAL
Læs af sikkerhedshensyn denne manual samt manualen til installation af udendørsenheden grundigt, før du
installerer klimaanlægget.
EΓXEIPIΔIO OΔHΓIΩN EΓKATAΣTAΣHΣ
MONTAJ EL KİTABI
FOR INSTALLER
FÜR INSTALLATEURE
POUR L’INSTALLATEUR
FÖR INSTALLATÖREN
VOOR DE INSTALLATEUR
PER L’INSTALLATORE
PARA EL INSTALADOR
PARA O INSTALADOR
TIL INSTALLATØREN
ΓΙΑ ΑΥΤΟΝ ΠΟΥ ΚΑΝΕΙ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ
MONTÖR İÇİN
English
Deutsch
Français
Nederlands
Español
Italiano
Ελληνικά
Português
Dansk
Svenska
Türkçe
INSTALLASJONSHÅNDBOK
installeres.
FOR MONTØR
Norsk
INSTRUKCJA MONTAŻU
DLA INSTALATORA
Polski
English is original.
Übersetzung des
Originals.
Traduction du texte
d’origine.
Traducción del
original.
Traduzione
dell’originale.
Tradução do
original.
Oversættelse af
den originale tekst.
Översättning från
originalet.
Originalspråket er
engelsk.
Vertaling van het
origineel.
en Go to the above website to download manuals, select model name, then choose language.
de Besuchen Sie die oben stehende Website, um Anleitungen herunterzuladen, wählen Sie den Modellnamen und dann die Sprache aus.
fr Rendez-vous sur le site Web ci-dessus pour télécharger les manuels, sélectionnez le nom de modèle puis choisissez la langue.
nl Ga naar de bovenstaande website om handleidingen te downloaden, de modelnaam te selecteren en vervolgens de taal te kiezen.
es
it Andare sul sito web indicato sopra per scaricare i manuali, selezionare il nome del modello e scegliere la lingua.
el
pt Aceda ao site Web acima indicado para descarregar manuais, seleccione o nome do modelo e, em seguida, escolha o idioma.
da Gå til ovenstående websted for at downloade manualer og vælge modelnavn, og vælg derefter sprog.
sv
tr
ru
uk
bg
pl
cs
sk
hu
sl
ro
et
lv
lt
hr
sr
no Gå til nettstedet over for å laste ned håndbøker og velg modellnavn, og velg deretter språk.
Manual Download
http://www.mitsubishielectric.com/ldg/ibim/
1
Contents
1. Safety precautions
1. Safety precautions.............................................................................................1
2. Installation location............................................................................................3
3. Installing the indoor unit ....................................................................................4
4. Installing the refrigerant piping ..........................................................................8
5. Drainage piping work.......................................................................................10
6. Electrical work .................................................................................................11
7. Test run............................................................................................................17
8. Easy maintenance function .............................................................................21
Note:
The phrase “Wired remote controller” in this installation manual refers only to the PAR-41MAA.
If you need any information for the other remote controller, please refer to either the installation manual or initial setting manual which are included in
these boxes.
►Beforeinstallingtheunit,makesureyoureadallthe“SafetyPrecautions”.
►The“SafetyPrecautions”provideveryimportantpointsregardingsafety.Makesureyoufollowthem.
►Pleasereporttoyoursupplyauthorityorobtaintheirconsentbeforeconnectingthisequipmenttothepowersupplysystem.
Symbols used in the text
Warning:
Describesprecautionsthatshouldbeobservedtopreventdangerofinjuryor
death to the user.
Caution:
Describesprecautionsthatshouldbeobservedtopreventdamagetotheunit.
Symbols used in the illustrations
: Indicates a part which must be grounded.
: Be sure not to do.
After installation work has been completed, explain the “Safety Precautions,” use, and
maintenance of the unit to the customer according to the information in the Operation
Manual and perform the test run to ensure normal operation. Both the Installation
Manual and Operation Manual must be given to the user for keeping. These manuals
must be passed on to subsequent users.
MEANINGSOFSYMBOLSDISPLAYEDONINDOORUNITAND/OROUTDOORUNIT
WARNING
(Risk of re)
This mark is for R32 refrigerant only. Refrigerant type is written on nameplate of outdoor unit.
In case that refrigerant type is R32, this unit uses a ammable refrigerant.
If refrigerant leaks and comes in contact with re or heating part, it will create harmful gas and there is risk of re.
Read the OPERATION MANUAL carefully before operation.
Service personnel are required to carefully read the OPERATION MANUAL and INSTALLATION MANUAL before operation.
Further information is available in the OPERATION MANUAL, INSTALLATION MANUAL, and the like.
Warning:
• Carefully read the labels affixed to the main unit.
• Askadealeroranauthorizedtechniciantoinstall,relocateandrepairthe
unit.
• Theuser shouldneverattempt torepairthe unitortransferittoanother
location.
• Donotaltertheunit.Itmaycausefire,electricshock,injuryorwaterleakage.
• Forinstallationandrelocationwork,followtheinstructionsintheInstallation
Manual and use tools and pipe components specifically made for use with
refrigerant specified in the outdoor unit installation manual.
• Theunitmustbeinstalledaccordingtotheinstructionsinordertominimize
therisk of damage fromearthquakes, typhoons, or strongwinds.An
incorrectlyinstalledunitmayfalldownandcausedamageorinjuries.
• The unit must be securely installed on a structure that can sustain its weight.
• Theapplianceshallbestoredinawell-ventilatedareawheretheroomsize
corresponds to the room area as specified for operation.
• If the air conditioner is installed in a small room or closed room, measures
mustbe taken toprevent the refrigerant concentrationin the room from
exceedingthe safety limit in the event ofrefrigerantleakage.Shouldthe
refrigerantleakandcausetheconcentrationlimittobeexceeded,hazards
duetolackofoxygenintheroommayresult.
• Keep gas-burning appliances, electric heaters, and other fire sources (ignition
sources) away from the location where installation, repair, and other air
conditionerworkwillbeperformed.
If refrigerant comes into contact with a flame, poisonous gases will be
released.
• Ventilatetheroomifrefrigerantleaksduringoperation.Ifrefrigerantcomes
into contact with a flame, poisonous gases will be released.
• Allelectricworkmustbeperformedbyaqualifiedtechnicianaccordingto
localregulationsandtheinstructionsgiveninthismanual.
• Useonlyspecifiedcablesforwiring.Thewiringconnectionsmustbemade
securelywithnotensionappliedontheterminalconnections.Also,never
splice the cables for wiring (unless otherwise indicated in this document).
Failuretoobservetheseinstructionsmayresultinoverheatingorafire.
• Do not use intermediate connection of the electric wires.
• Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
specified refrigerant written on outdoor unit to charge the refrigerant lines.
Do not mix it with any other refrigerant and do not allow air to remain in the
lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other
hazards.
The use of any refrigerant other than that specified for the system will cause
mechanicalfailureorsystemmalfunctionorunitbreakdown.Intheworst
case, this could lead to a serious impediment to securing product safety.
• The appliance shall be installed in accordance with national wiring
regulations.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
andknowledge, unless they havebeen given supervision orinstruction
concerning use of the appliance by a person responsible for their safety.
• Childrenshouldbesupervisedtoensurethattheydonotplaywiththeair
conditioner.
• Theterminalblockcoverpaneloftheunitmustbefirmlyattached.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
serviceagentorsimilarlyqualifiedpersonsinordertoavoidahazard.
• UseonlyaccessoriesauthorizedbyMitsubishiElectricandaskadealeror
anauthorizedtechniciantoinstallthem.
• Afterinstallationhasbeencompleted,checkforrefrigerantleaks.Ifrefrigerant
leaksintotheroomandcomesintocontactwiththeflameofaheateror
portablecookingrange,poisonousgaseswillbereleased.
• Do not use means to accelerate the defrosting process or to clean, other
than those recommended by the manufacturer.
• The appliance shall be stored in a room without continuously operating
ignition sources (for example: open flames, an operating gas appliance or
an operating electric heater).
• Do not pierce or burn.
en
2
1.1. Beforeinstallation(Environment)
Caution:
• Donotusetheunitinanunusualenvironment.Iftheairconditionerisinstalled
inareasexposedtosteam,volatileoil(includingmachineoil),orsulfuricgas,
areas exposed to high salt content such as the seaside, the performance can
be significantly reduced and the internal parts can be damaged.
• Donot install the unitwherecombustible gases may leak,be produced,
flow, or accumulate. If combustible gas accumulates around the unit, fire or
explosion may result.
• Donotkeepfood,plants,cagedpets,artwork,orprecisioninstrumentsin
the direct airflow of the indoor unit or too close to the unit as these items
can be damaged by temperature changes or dripping water.
• When the room humidity exceeds 80% or when the drainpipe is clogged,
water may drip from the indoor unit. Do not install the indoor unit where
such dripping can cause damage.
• When installing the unit in a hospital or communications office, be prepared for
noiseandelectronicinterference.Inverters,homeappliances,high-frequency
medicalequipment,andradiocommunicationsequipmentcancausetheair
conditionertomalfunctionorbreakdown.Theairconditionermayalsoaffect
medicalequipment,disturbingmedicalcare,andcommunicationsequipment,
harmingthescreendisplayquality.
1.4. Beforestartingthetestrun
Caution:
• Turn on the main power switch more than 12 hours before starting operation.
Startingoperationjustafterturningonthepowerswitchcanseverelydamage
the internal parts.
• Beforestartingoperation,checkthatallpanels,guardsandotherprotective
partsarecorrectlyinstalled.Rotating,hot,orhighvoltagepartscancause
injuries.
• Do not operate the air conditioner without the air filter set in place. If the air
filterisnotinstalled,dustmayaccumulateandbreakdownmayresult.
• Donottouchanyswitchwithwethands.Electricshockmayresult.
• Do not touch the refrigerant pipes with bare hands during operation.
•
Afterstoppingoperation,besuretowaitatleastfiveminutesbeforeturningoff
themainpowerswitch.Otherwise,waterleakageorbreakdownmayresult.
1.3. Beforeelectricwork
Caution:
• Besuretoinstallmoldedcasecircuitbreakers.Ifnotinstalled,electricshock
may result.
• For the power lines, use standard cables of sufficient capacity. Otherwise, a
shortcircuit,overheating,orfiremayresult.
• When installing the power lines, do not apply tension to the cables.
• Besuretogroundtheunit.Iftheunitisnotproperlygrounded,electricshock
may result.
• Usecircuitbreakers(groundfaultinterrupter,isolatingswitch(+Bfuse),and
moldedcasecircuitbreaker)withthespecifiedcapacity.Ifthecircuitbreaker
capacityislargerthanthespecifiedcapacity,breakdownorfiremayresult.
1.2. Beforeinstallationorrelocation
Caution:
• Beextremely careful when transporting theunits.Two or morepersons
areneededtohandletheunitasitweighs20kgormore.Donotgraspthe
packagingbands.Wearprotectiveglovesasyoucaninjureyourhandson
the fins or other parts.
• Besuretosafelydisposeofthepackagingmaterials.Packagingmaterials,
such as nails and other metal or wooden parts may cause stabs or other
injuries.
• Thermal insulationof the refrigerant pipe isnecessary to prevent
condensation. If the refrigerant pipe is not properly insulated, condensation
will be formed.
• Placethermalinsulationonthepipestopreventcondensation.Ifthedrainpipe
is installed incorrectly, water leakage and damage to the ceiling, floor,
furniture, or other possessions may result.
• Donotcleantheairconditionerunitwithwater.Electricshockmayresult.
• Tightenallflarenutstospecificationusingatorquewrench.Iftightenedtoo
much,theflarenutcanbreakafteranextendedperiod.
1. Safety precautions
Warning:
• Beawarethatrefrigerantsmaynotcontainanodour.
• Pipe-workshallbeprotectedfromphysicaldamage.
• Theinstallationofpipe-workshallbekepttoaminimum.
• Compliancewithnationalgasregulationsshallbeobserved.
• Keepanyrequiredventilationopeningsclearofobstruction.
• Donotuselowtemperaturesolderalloyincaseofbrazingtherefrigerant
pipes.
• Whenperformingbrazingwork,besuretoventilatetheroomsufficiently.
Makesurethattherearenohazardousorflammablematerialsnearby.
Whenperformingtheworkinaclosedroom,smallroom,orsimilarlocation,
makesurethattherearenorefrigerantleaksbeforeperformingthework.
Ifrefrigerantleaksandaccumulates,itmayigniteorpoisonousgasesmay
be released.
en
3
2. Installation location
Fig. 2-1
2.1. Outline dimensions (Indoor unit) (Fig. 2-1)
Select a proper position allowing the following clearances for installation and
maintenance.
(mm)
ABCDE
Min. 100.5 Min. 52.3 Min. 48 Min. 250 Min. 220
F
Air outlet: Do not place an obstacle within 1500 mm of the air outlet.
G Floor surface
H Furnishings
I When the projection dimension of a curtain rail or the like from the wall exceeds 60 mm,
extra distance should be taken because the fan air current may create a short cycle.
J 1800 mm or greater from the floor surface (for high location mounting)
K 108 mm or greater with left or rear left piping and optional drain pump installation
L 550 mm or greater with optional drain pump installation
M Minimum 7 mm: 265 mm or greater with optional drain pump installation
Warning:
• Thisunitshouldbeinstalledinroomswhichexceedtheoorspacespecied
in outdoor unit installation manual.
Refer to outdoor unit installation manual.
• Installtheindoorunitatleast1.8maboveoororgradelevel.
For appliances not accessible to the general public.
• Refrigerant pipes connection shall be accessible for maintenance purposes.
G
F
A
B
L
1170
365
H
E
J
*
M
I
D
C
295
K
(mm)
en
4
3. Installing the indoor unit
3.1. Checktheindoorunitaccessories(Fig.3-1)
The indoor unit should be supplied with the following accessories.
PART NUMBER
ACCESSORY QUANTITY LOCATION OF
SETTING
1Mount board 1
Fix at the back of the
unit
2Tapping screw 4 ×25 7
3Felt tape 2
4L-shaped connection pipe 1
5Charge nut 1
6* Wireless remote controller 1
7* Remote controller holder 1
8*Alkali batteries (size AAA) 2
9*Tapping screw 3.5 ×16 2
0Spacer 1 Make use of
packaging material
3.2. Installing the wall mounting fixture (Fig. 3-2)
3.2.1. Setting the wall mounting fixture and piping positions
►Usingthewallmountingfixture,determinetheunit’sinstallationposition
and the locations of the piping holes to be drilled.
Warning:
Beforedrillingaholeinthewall,youmustconsultthebuildingcontractor.
A
Mount board 1
B
Indoor unit
C Bottom left rear pipe hole (ø75-ø80)
D Bottom right rear pipe hole (ø75-ø80)
E Knockout hole for left rear hole (75 × 480)
F Bolt hole (4-ø9 hole)
G Center measurement hole (ø2.5 hole)
H Tapping hole (75-ø5.1 hole)
I Hole centre
J Align the scale with the line.
K Insert scale.
3.2.2. Drilling the piping hole (Fig. 3-3)
►Useacoredrilltomakeaholeof75-80mmdiameterinthewallinthe
piping direction, at the position shown in the diagram to the left.
►The hole should incline so that the outside opening is lower than the
inside opening.
►Insertasleeve(witha75mmdiameterandpurchasedlocally)throughthe
hole.
Note:
Thepurposeofthehole’sinclinationistopromotedrainflow.
3.2.3. Installing the wall mounting fixture (Fig. 3-4)
►Sincetheindoorunitweighsnear21kg,selectionofthemounting
locationrequiresthoroughconsideration.Ifthewalldoesnotseemtobe
strong enough, reinforce it with boards or beams before installation.
►The mounting fixture must be secured at both ends and at the centre, if
possible.Neverfixitatasinglespotorinanynonsymetricalway.
(Ifpossible,securethefixtureatallthepositionsmarkedwithaboldarrow.)
Warning:
If possible, secure the fixture at all positions indicated with a bold arrow.
Caution:
• Theunitbodymustbemountedhorizontally.
• Fastenattheholesmarkedwith▲asshownbythearrows.
Fig. 3-1
Fig. 3-2
A
K
J
I
25
0
12.5
37.5
62.5
87.5
104.5
129.5
167
217
229.5
264
292
308.5
311
54
585
465.5
454
439
408.5
384.5
364
314
110
54
0
3
60
10
0
10
60
110
314
364
384
408.5
439
454
517.4
585
530.5
439
430.5
384
339
189
0
216.5
339
R37.5
349.2
384
439
449.2
15.5
0
25
50
75
100
117
125142
192
242
279.5
292
A
B
C
H
F
G
D
E
(mm)
Fig. 3-3
A
C
D
E
B
A Sleeve
B Hole
C (Indoors)
D Wall
E (Outdoors)
123
456*
7*8*9*
0
–
* PKA-M·KAL only
100 mm
Fig. 3-4
A Min. 120 mm (617.6 mm or greater with optional drain pump installation)
B Min. 220 mm
C Min. 70 mm (130 mm or greater with left, rear left, or lower left piping, and optional drain
pump installation)
D Fixing screws (4 × 25) 2
E
Level
F Fasten a thread to the hole.
G
Place the level against the horizontal reference line of the mount board and mount so that it is
level. Hang a weight from the thread and align it with the ▼mark of the mount board to make it
level.
H Weight
I Mount board 1
AB
C
DI
G
F
H
E
en
5
3. Installing the indoor unit
Fig.3-5
Fig.3-7Fig. 3-6
AA
Fig. 3-8
A
B
D
C
E
Fig. 3-10Fig. 3-9
B
A
C
D
3.3. Whenembeddingpipesintothewall(Fig.3-5)
• The pipes are on the bottom left.
• When the cooling pipe, drain pipes internal/external connection lines etc are to
be embedded into the wall in advance, the extruding pipes etc, may have to be
bent and have their length modified to suit the unit.
• Use marking on the mount board as a reference when adjusting the length of the
embedded cooling pipe.
• During construction, give the length of the extruding pipes etc some leeway.
A
Mount board 1
B
Reference marking for flare connection
C Through hole
D On-site piping
3.4. Preparing the indoor unit
* Check beforehand because the preparatory work will differ depending on the
exiting direction of the piping.
* When bending the piping, bend gradually while maintaining the base of the
piping exiting portion. (Abrupt bending will cause misshaping of the piping.)
AttachmentofL-shapedconnectionpipe4
Right, left and rear piping (Fig. 3-6)
1. Remove the flare nut and cap of the indoor unit. (Gas pipe only)
2. Apply refrigerating machine oil to the flare sheet surface. (Preparation on
location)
3. Facing the direction in which the L-shaped connection pipe 4will be removed,
make a quick connection to the indoor unit flare connection opening.
4. Tighten the flare nut using a double open-end wrench. (Fig. 3-9)
Tightening force: 68 to 82 N•m
5. Attach the charge nut 5to the liquid pipe side joint portion, and check for
leakage of the L-shaped connection pipe 4connection portion.
Remove the charge nut 5after completion of the work.
Tightening force: 34 to 42 N•m
6. Cover the flare connection portion with the pipe cover of the L-shaped
connection pipe 4 so that it is not exposed. (Fig. 3-10)
A
L-shaped connection pipe 4
B
Cut-off position (Straight pipe portion)
C Tightening direction
D Cover with pipe cover
ECover the flare nut connection portion with the pipe cover.
Lowerpiping(Fig.3-7)
1. Cut L-shaped connection pipe 4 at the position indicated in (Fig. 3-8).
2. Insert the flare nut that was removed earlier onto the straight pipe side of the cut
L-shaped connection pipe 4and then flare the end of the pipe.
3. Remove the flare nut and cap of the indoor unit. (Gas pipe only)
4. Apply refrigerating machine oil to the flare sheet surface. (Preparation on
location)
5. Quickly connect the L-shaped connection pipe 4that has been processed as
described in part 2) to the indoor unit flare connection opening.
6. Tighten the flare nut using a double open-end wrench. (Fig. 3-9)
Tightening force: 68 to 82 N•m
7. Attach the charge nut 5to the liquid pipe side joint portion, and check for
leakage of the L-shaped connection pipe 4connection portion.
Remove the charge nut 5after completion of the work.
Tightening force: 34 to 42 N•m
8. Cover the flare connection portion with the pipe cover of the L-shaped
connection pipe 4 so that it is not exposed. (Fig. 3-10)
en
6
3. Installing the indoor unit
Fig. 3-11
B
A
C
E
D
LeakagecheckoftheL-shapedconnectionpipeconnectionportion
1. Attach the charge nut 5to the liquid pipe side joint portion.
Tightening force: 34 to 42 N•m
2. Pressurize by filling with nitrogen gas from the charge nut.
Do not pressurize to the current constant pressure all at once. Pressurize
gradually.
1) Pressurize to 0.5 MPa, wait five minutes, and make sure the pressure does
not decrease.
2) Pressurize to 1.5 MPa, wait five minutes, and make sure the pressure does
not decrease.
3) Pressurize to 4.15 MPa and measure the surrounding temperature and
refrigerant pressure.
3. If the specified pressure holds for about one day and does not decrease, the
pipes have passed the test and there are no leaks.
• If the surrounding temperature changes by 1°C, the pressure will change by
about 0.01 MPa. Make the necessary corrections.
4. If the pressure decreases in steps (2) or (3), there is a gas leak. Look for the
source of the gas leak.
Extraction and processing of the piping and wiring (Fig. 3-11)
1. Connection of indoor/outdoor wiring See page 11.
2. Wrap the felt tape 3in the range of the refrigerant piping and drain hose which
will be housed within the piping space of the indoor unit.
• Wrap the felt tape 3securely from the base for each of the refrigerant piping
and the drain hose.
• Overlap the felt tape 3at one-half of the tape width.
• Fasten the end portion of the wrapping with vinyl tape.
A
Liquid pipe
B Gas pipe
C Indoor/outdoor connection cable
D Drain hose
E Felt tape 3
3. Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
Do not pull the drain hose forcefully because it might come out.
Rear, right and lower piping (Fig. 3-12)
1) Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
Arrange the drain hose at the underside of the piping and wrap it with felt
tape 3.
2) Securely wrap the felt tape 3starting from the base. (Overlap the felt tape at
one-half of the tape width.)
A
Cut off for right piping.
B Cut off for lower piping.
Leftandleftrearpiping(Fig.3-13)
4. Drain hose replacement See 5. Drainage piping work
Be sure to replace the drain hose and the drain cap for the left and rear left
piping. Dripping may occur if you forget to install or fail to replace these parts.
C
Drain cap
1) Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
2) Securely wrap the felt tape 3starting from the base. (Overlap the felt tape at
one-half of the tape width.)
3) Fasten the end portion of the felt tape 3with vinyl tape.
D
Cut off for left piping.
Fig. 3-12
Fig. 3-13
B
A
1)2)
C
D
1)
3
)
2)
en
7
Fig. 3-14
Fig.3-15
Fig. 3-16
C
B
A
E
D
BA
C
D
A
C
B
3.5. Mountingtheindoorunit
1. Affix the mount board 1to the wall.
2. Hang the indoor unit on the hook positioned on the upper part of the mount
board.
Rear, right and lower piping (Fig. 3-14)
3. While inserting the refrigerant piping and drain hose into the wall penetration
hole (penetration sleeve), hang the top of the indoor unit to the mount board 1.
4. Move the indoor unit to the left and right, and verify that the indoor unit is hung
securely.
5. Fasten by pushing the bottom part of the indoor unit onto the mount board 1.
(Fig. 3-15)
* Check that the knobs on the bottom of the indoor unit are securely hooked into
the mount board 1.
6. After installation, be sure to check that the indoor unit is installed level.
A
Mount board 1
B
Indoor unit
C Hook
D Square hole
Leftandleftrearpiping(Fig.3-16)
3. While inserting the drain hose into the wall penetration hole (penetration
sleeve), hang the top of the indoor unit to the mount board 1.
Giving consideration to the piping storage, move the unit all the way to the left
side, then cut part of the packaging carton and wrap into a cylindrical form as
illustrated in the diagram. Hook this to the rear surface rib as a spacer, and raise
the indoor unit.
4. Connect the refrigerant piping with the site-side refrigerant piping.
5. Fasten by pushing the bottom part of the indoor unit onto the mount board 1.
* Check that the knobs on the bottom of the indoor unit are securely hooked into
the mount board 1.
6. After installation, be sure to check that the indoor unit is installed level.
AIndoor unit
BPackaging carton
CCut off
DWrap into a cylindrical form
EFasten with tape
3. Installing the indoor unit
en
8
4. Installing the refrigerant piping
A Flare cutting dimensions
Copper pipe O.D.
(mm)
Flare dimensions øA
dimensions (mm)
ø9.52 12.8 - 13.2
ø15.88 19.3 - 19.7
øA
45±2°
AB
C
D
Fig. 4-1
4.1. Precautions
FordevicesthatuseR32/R410Arefrigerant
• Usetherefrigerantoil(smallamount)appliedtotheflaredsections.
• UseC1220copperphosphorusforcopperandcopperalloyseamless
pipes,toconnecttherefrigerantpipes.Userefrigerantpipeswiththe
thicknessesspecifiedinthetablebelow.Makesuretheinsidesofthepipes
are clean and do not contain any harmful contaminants such as sulfuric
compounds, oxidants, debris, or dust.
Warning:
Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
specified refrigerant written on outdoor unit to charge the refrigerant lines.
Do not mix it with any other refrigerant and do not allow air to remain in the
lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other
hazards.
The use of any refrigerant other than that specified for the system will cause
mechanicalfailureorsystemmalfunctionorunitbreakdown.Intheworst
case, this could lead to a serious impediment to securing product safety.
ø9.52 thickness 0.8 mm
ø15.88 thickness 1.0 mm
• Donotusepipesthinnerthanthosespecifiedabove.
R0.4 - R0.8
90°±0.5°
4.2. Connecting pipes (Fig. 4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C or
more, thickness of 12 mm or more).
• The indoor parts of the drain pipe should be wrapped with polyethylene foam
insulation materials (specific gravity of 0.03, thickness of 9 mm or more).
• Apply thin layer of refrigerant oil to pipe and joint seating surface before
tightening flare nut.
• Use two wrenches to tighten piping connections.
• Use refrigerant piping insulation provided to insulate indoor unit connections.
Insulate carefully.
• After connecting the refrigerant piping to the indoor unit, be sure to test the pipe
connections for gas leakage with nitrogen gas. (Check that there is no refrigerant
leakage from the refrigerant piping to the indoor unit.)
• Use flared nut installed to this indoor unit.
• In case of reconnecting the refrigerant pipes after detaching, make the flared part
of pipe re-fabricated.
B Flare nut tightening torque
Copper pipe O.D.
(mm)
Flare nut O.D.
(mm)
Tightening torque
(N·m)
ø9.52 22 34 - 42
ø15.88 29 68 - 82
C Apply refrigerating machine oil over the entire flare seat surface.
Do not apply refrigerating machine oil to the screw portions.
(This will make the flare nuts more apt to loosen.)
D Be certain to use the flare nuts that are attached to the main unit.
(Use of commercially-available products may result in cracking.)
Fig. 4-2
E
F
B
Copper pipe O.D.
(mm)
B (mm)
Flare tool for R32/R410A
Clutch type
ø9.52 (3/8”) 0 - 0.5
ø15.88 (5/8”) 0 - 0.5
EDie
FCopper pipe
en
9
4. Installing the refrigerant piping
Fig. 4-3
D
65
777.8
67
365
1170
444 (A)* 123
482 (B)154
585 (C)
1155
65
65
77
87
F F 77
87 71.218.2
134
295 5
65
67
77
7.8
G
E
Fig. 4-4
Fig.4-5
B
A
D
C
B
A
4.3. Indoor unit
Availablepipesize
Model PKA-M·KA(L) Series
Refrigerant
piping
Liquid O.D. ø9.52 (3/8")
Gas O.D. ø15.88 (5/8")
Drainage piping O.D. ø16
4.4. Positioning refrigerant and drain piping (Fig. 4-3)
A Gas pipe * Indicates the condition with accessories mounted.
B Liquid pipe
C Drain hose
D Left-side piping knockout hole
E Right-side piping knockout hole
F Lower piping knockout hole
GMount board 1
4.5. Refrigerantpiping(Fig.4-4)
Indoor unit
1. Remove the flare nut and cap of the indoor unit.
2. Make a flare for the liquid pipe and gas pipe and apply refrigerating machine oil
(available from your local supplier) to the flare sheet surface.
3. Quickly connect the on site cooling pipes to the unit.
4. Wrap the pipe cover that is attached to the gas pipe and make sure that the
connection join is not visible.
5. Wrap the pipe cover of the unit’s liquid pipe and make sure that it covers the
insulation material of the on site liquid pipe.
6. The portion where the insulation material is joined is sealed by taping.
A
Site-side refrigerant piping
B Unit side refrigerant piping
4.5.1. Storinginthepipingspaceoftheunit(Fig.4-5)
1. Wrap the supplied felt tape in the range of the refrigerant piping which will be
housed within the piping space of the unit to prevent dripping.
2. Overlap the felt tape at one-half of the tape width.
3. Fasten the end portion of the wrapping with vinyl tape, etc.
A
Gas pipe
BLiquid pipe
CIndoor/outdoor connection cable
DFelt tape 3
en
10
5. Drainagepipingwork
5.1. Drainagepipingwork(Fig.5-1)
• Drain pipes should have an inclination of 1/100 or more.
• For extension of the drain pipe, use a soft hose (inner dia. 15 mm) available on
the market or hard vinyl chloride pipe (VP-16/O.D. ø22 PVC TUBE). Make sure
that there is no water leakage from the connections.
• Do not put the drain piping directly in a drainage ditch where sulphuric gas may
be generated.
• When piping has been completed, check that water flows from the end of the
drain pipe.
Caution:
The drain pipe should be installed according to this Installation Manual to
ensure correct drainage. Thermal insulation of the drain pipes is necessary
topreventcondensation.Ifthedrainpipesarenotproperlyinstalledand
insulated, condensation may drip on the ceiling, floor or other possessions.
A
Inclined downwards
B Must be lower than outlet point
C Water leakage
D Trapped drainage
E Air
F Wavy
G The end of drain pipe is under water.
H Drainage ditch
I5 cm or less between the end of drain pipe and the ground.
J Drain hose
K Soft PVC hose (Inside diameter 15 mm)
or
Hard PVC pipe (VP-16)
* Bond with PVC type adhesive
Preparingleftandleftrearpiping(Fig.5-2)
1 Remove the drain cap.
• Remove the drain cap by holding the bit that sticks out at the end of the pipe and
pulling.
A
Drain cap
2 Remove the drain hose.
• Remove the drain hose by holding on to the base of the hose a(shown by
arrow) and pulling towards yourself b.
3 Insert the drain cap.
• Insert a screwdriver etc into the hole at the end of the pipe and be sure to push
to the base of the drain cap.
4 Insert the drain hose.
• Push the drain hose until it is at the base of the drain box connection outlet.
• Please make sure the drain hose hook is fastened properly over the extruding
drain box connection outlet.
B
Hooks
Storinginthepipingspaceoftheindoorunit(Fig.5-3)
* When the drain hose will be routed indoors, be sure to wrap it with commercially
available insulation.
* Gather the drain hose and the refrigerant piping together and wrap them with the
supplied felt tape 3.
* Overlap the felt tape 3at one-half of the tape width.
* Fasten the end portion of the wrapping with vinyl tape, etc.
A
Gas pipe
B Liquid pipe
C Drain hose
D Indoor/outdoor connection wiring
E Felt tape 3
Checkofdrainage(Fig.5-4)
1. Open the front grille and remove the filter.
2. Facing the fins of the heat exchanger, slowly fill with water.
3. After the drainage check, attach the filter and close the grille.
A
a
b
A
A
B
1
3
2
Fig.5-2
Fig.5-3
Fig.5-4
A
B
D
E
C
4
Fig.5-1
J
K
Correct Incorrect
A
B
C
E
D
C
F
Incorrect
Incorrect Incorrect
C
G
H
I
en
11
6. Electricalwork
6.1. Indoor unit (Fig. 6-1)
Connection can be made without removing the front panel.
1. Open the front grille, remove the screw (1 piece), and remove the electrical
parts cover.
2. Securely connect each wire to the terminal board.
* In consideration of servicing, provide extra length for each of the wires.
* Take care when using strand wires, because beards may cause the wiring to
short out.
3. Install the parts that were removed back to their original condition.
4. Fasten each of the wires with the clamp under the electrical parts box.
AElectrical box cover
BFixing screw
CClamp
DGround wire connection portion
E Wired remote control terminal board (PKA-M∙KAL: optional parts): 1 and 2, do not have
polarity
FIndoor/outdoor connection terminal board: S1, S2, and S3, have polarity
GLead
HTerminal screw
IGround wire: Connect the ground wire in the direction illustrated in the diagram.
JWired remote control cord
KIndoor/outdoor connection cord
Fig. 6-1
H
H12mm
55mm
D
12mm
55mm
E
F
K
J
C
J
K
D
F
E
A
B
S3
I
G
6.1.1. Indoor unit power supplied from outdoor unit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
S1
S2
L
N
S3
D
AB C
1
2
S1
S2
S3
S1
S2
S3
S1
S2
S3
S1
S2
S3
E
F
HHH
G G G G
Simultaneous twin/triple/quadruple system
* Affix a label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A
Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor/outdoor unit connecting cords
F Wired remote controller (option)
G Indoor unit
* Affix a label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A
Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor/outdoor unit connecting cords
F Wired remote controller (option)
G Indoor unit
H Indoor unit earth
1:1 System
S1
S2
L
N
1
2
S1
S2
S3
S3
AB C
D
E
F
G
en
12
6. Electricalwork
6.1.2. Separateindoorunit/outdoorunitpowersupplies(ForPUHZ/PUZ-ZMapplication)
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
* The optional wiring replacement kit is required.
S1
S2
L
N
1
2
L
N
S1
S2
S3
S3
D
E
F
G
H
AB C JB C
AB C
S1
S2
L
N
1
2
L
N
S1
S2
S3
L
N
S1
S2
S3
L
N
S1
S2
S3
L
N
S1
S2
S3
S3
D
E
J
F
H
G G G G
H H H
KKK
B C
* Affix a label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A
Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor/outdoor unit connecting cords
F Wired remote controller (option)
G Indoor unit
H Option
J Indoor unit power supply
* The optional wiring replacement kits are required.
Simultaneous twin/triple/quadruple system
* Affix a label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A
Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor/outdoor unit connecting cords
F Wired remote controller (option)
G Indoor unit
H Option
J Indoor unit power supply
K Indoor unit earth
1:1 System
*1. <For 25-140 outdoor unit application>
Max. 45 m
If 2.5 mm2used, Max. 50 m
If 2.5 mm2used and S3 separated, Max. 80 m
For PUHZ-RP100/125/140 YHA application, use shield wires. The shield part must be grounded with the indoor unit OR the outdoor unit, NOT with both.
<For 200/250 outdoor unit application>
Max. 18 m
If 2.5 mm2used, Max. 30 m
If 4 mm2used and S3 separated, Max. 50 m
If 6 mm2used and S3 separated, Max. 80 m
*2. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote controller cables is 200 m. If 2 remote controllers are connected, set one to “Main” and the other to “Sub”. For setting
procedures, refer to “Initial settings” in the installation manual for the remote controller.)
*3. The figures are NOT always against the ground.
S3 terminal has 24V DC/28V DC against S2 terminal. However between S3 and S1, these terminals are not electrically insulated by the transformer or other device.
*4. It depends on the outdoor unit.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2. PowersupplycordsandIndoorunit/Outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedflexiblecord.(Design60245
IEC57)
3. Install an earth longer than other cords.
4. Indoorandoutdoorconnectingwireshavepolarities.Makesuretomatchtheterminalnumber(S1,S2,S3)forcorrectwirings.
5. Wiringforremotecontrollercableshallbeapart(50mmormore)frompowersourcewiringsothatitisnotinfluencedbyelectricnoisefrompower
source wiring.
Indoor unit model PKA-M·KA(L) Series
Wiring Wire
No. × size
(mm²)
Indoor unit-Outdoor unit *1 3 × 1.5 (Polar)
Indoor unit-Outdoor unit earth *1 1 × Min. 1.5
Indoor unit earth 1 × Min. 1.5
Wired remote controller (option) Indoor unit *2 2 × Min. 0.3
Circuit
rating
Indoor unit L-N *3 –
Indoor unit-Outdoor unit S1-S2 *3 230V AC
Indoor unit-Outdoor unit S2-S3 *3 *4 24V DC/28V DC
Wired remote controller (option) Indoor unit *3 12V DC
en
13
S1
S2
S3
L
N
BLUE
BLUE
YELLOW
YELLOW
CN01
CN01
BLACK
CN01
BLACK
S1
S2
S3
L
N
YELLOW
BLUE
BLUE
YELLOW
CN01
Indoor unit model PKA-M·KA(L) Series
Indoor unit power supply ~/N (single), 50/60 Hz, 230 V
Indoor unit input capacity *1
Main power switch (Breaker) 16 A
Wiring
Wire No. × size
(mm2)
Indoor unit power supply & earth 3 × Min. 1.5
Indoor unit earth 1 × Min. 1.5
Indoor unit-Outdoor unit *2 2 × Min. 0.3
Indoor unit-Outdoor unit earth –
Wired remote controller (option) Indoor unit *3 2 × Min. 0.3 (Non-polar)
Circuit
rating
Indoor unit L-N *4 230V AC
Indoor unit-Outdoor unit S1-S2 *4 –
Indoor unit-Outdoor unit S2-S3 *4 *5 24V DC/28V DC
Wired remote controller (option) Indoor unit *4 12V DC
*1. A breaker with at least 3 mm contact separation in each pole shall be provided. Use non-fuse breaker (NF) or earth leakage breaker (NV).
*2. Max. 120 m
For PUHZ-RP/PUZ-ZM100/125/140 YHA application, use shield wires. The shield part must be grounded with the indoor unit OR the outdoor unit, NOT with both.
*3. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote controller cables is 200 m. If 2 remote controllers are connected, set one to “Main” and the other to “Sub”. For setting
procedures, refer to “Initial settings” in the installation manual for the remote controller.)
*4. The figures are NOT always against the ground.
*5. It depends on the outdoor unit.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2. Powersupplycordsandindoorunit/outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedflexiblecord.(Design60245
IEC57)
3. Install an earth longer than other cables.
4. Wiringforremotecontrollercableshallbeapart(50mmormore)frompowersourcewiringsothatitisnotinfluencedbyelectricnoisefrompower
source wiring.
If the indoor and outdoor units have separate power supplies, refer to the table
at the below. If the optional wiring replacement kit is used, change the indoor unit
electrical box wiring referring to the figure in the right and the DIP switch settings of
the outdoor unit control board.
Indoor unit specifications
Indoor power supply terminal kit (option) Required
Indoor unit electrical box connector
connection change Required
Label affixed near each wiring diagram for
the indoor and outdoor units Required
Outdoor unit DIP switch settings (when
using separate indoor unit/outdoor unit
power supplies only)
ON
OFF 1 2 (SW8)
3
* There are three types of labels (labels A, B, and C). Affix the appropriate labels to
the units according to the wiring method.
Connectors (connections when shipped
from the factory are for indoor unit power
supplied from outdoor unit)
Indoor unit power supplied from outdoor unit
(when shipped from factory)
If the indoor and
outdoor units have
separate power
supplies, change the
connections of the
connectors as shown
in the following
figure.
Connectors
Indoor unit
control board
Separate indoor unit/outdoor unit power
supplies
Indoor unit
control board
6. Electricalwork
Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a re or communication failure.
Warning:
en
14
6.2. Function setting
6.2.1. Function setting on the unit (Selecting the unit functions)
1 (Fig. 6-2)
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Settings” from the Service menu, and press the [SELECT] button.
2 (Fig. 6-3)
• Select “Function settings” with the [SELECT] button.
3 (Fig. 6-4)
• Set the indoor unit refrigerant addresses and unit numbers with the [F1]
through [F4] buttons, and then press the [SELECT] button to confirm the
current setting.
<CheckingtheIndoorunitNo.>
When the [SELECT]button is pressed, the target indoor unit will start fan operation.
If the unit is common or when running all units, all indoor units for the selected
refrigerant address will start fan operation.
4 (Fig. 6-5)
• Toggle through the pages with the [F3] or [F4] button.
• Select the mode number with the [F1] or [F2] button, and then press the
[SELECT] button.
5 (Fig. 6-6)
• Select the setting number with the [F1] or [F2] button.
Setting range for modes 1 through 28: 1 through 3.
Setting range for modes 31 through 66: 1 through 15.
6 (Fig. 6-7)
• When the settings are completed, press the [SELECT] button to send the
setting data from the remote controller to the indoor units.
• When the transmission is successfully completed, the screen will return to the
Function setting screen.
Note:
•MaketheabovesettingsonMr.Slimunitsasnecessary.
• Table1summarizesthesettingoptionsforeachmodenumber.RefertotheindoorunitInstallationManualforthedetailedinformationaboutinitialsettings,
mode numbers, and setting numbers for the indoor units.
• Besuretowritedownthesettingsforallfunctionsifanyoftheinitialsettingshasbeenchangedafterthecompletionofinstallationwork.
6. Electricalwork
Settings menu
Cursor
Service menu:
Function setting
Rotation setting
F1 F2 F3 F4
F1 F2 F3 F4
Service menu
Cursor
Main menu:
Test run
Input maintenance info.
Settings
Check
Others
Function setting
Cursor Address
Monitor:
Ref. address
Unit No.
Grp./1/2/3/4/All
F1 F2 F3 F4
Fig. 6-3Fig. 6-2
Fig. 6-4
F1 F2 F3 F4
Function setting
Cursor Page
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
(1/8)
1
2
1
1
Save:
F1 F2 F3 F4
Function setting
Value
Request:
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
(1/8)
2
1
1
1
Fig.6-5
Fig. 6-6
F1 F2 F3 F4
Function setting
Ref. address
Sending data
Grp.
Fig.6-7
en
15
6. Electricalwork
Function table (Table 1)
Select unit number “Grp.”
Mode Settings Mode no. Setting no.
Initial setting
setting
Power failure automatic recovery Not available 01 1
Available *1 2Ο *2
Indoor temperature detecting Indoor unit operating average
02
1Ο
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported
03
1Ο
Supported (indoor unit is not equipped with outdoor-air
intake)
2
Supported (indoor unit is equipped with outdoor-air intake) 3
Power voltage 240 V 04 1
220 V, 230 V 2 Ο
Auto operation mode Single set point (Available 14°C cooling setting *3) 06 1
Dual set point (Not available 14°C cooling setting *3) 2Ο
Smart Defrost *3 Available 20 1Ο
Not available 2
Select unit numbers 1 to 4 or “All”
Mode Settings Mode no. Setting no.
Initial setting
setting
Filter sign 100 Hr
07
1Ο
2500 Hr 2
No filter sign indicator 3
Fan speed Silent (low ceiling)
08
1
Standard 2 Ο
High ceiling 3
Fan speed during the cooling thermostat is OFF Setting fan speed
27
1
Stop 2
Extra low 3 Ο
*1 When the power supply returns, the air conditioner will start 3 minutes later.
*2 Power failure automatic recovery initial setting depends on the connecting outdoor unit.
*3 It is available when the indoor unit is connected to any of the particular outdoor units.
en
16
6. Electricalwork
6.3. Rotation setting
You can set these functions by wired remote controller. (Maintenance monitor)
Rotation setting
Select :
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
4Set the rotation function.
• Select "Rotation" with the [F1] button.
• Select the switching period or "Backup only" with the [F2] or [F3] button.
■"Rotation" setup options
None, 1 day, 3 days, 5 days, 7 days, 14 days, 28 days, Backup only
5Set the support function.
• Select "TempDifTrigger" with the [F1] button.
• Select the difference between the suction temperature and the set temperature with the [F2] or [F3]
button.
1Select “Service” from the Main menu, and press the [SELECT] button.
2Select “Settings” with the [F1] or [F2] button, and press the [SELECT] button.
3Select “Rotation setting” with the [F1] or [F2] button, and press the [SELECT] button.
Rotation setting
Select :
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
Notes:
• When 1 to 28 days are selected from the setup options, the backup function is also enabled.
• When "Backup only" is selected, the rotation function will be disabled. The systems with refrigerant
addresses of 00 or 01 (00 system/ 01 system) will be operated as a main system while the 02 system
is the standby mode as backup.
6Press the [SELECT] button to update the setting.
■"TempDifTrigger" setup options
None, +4ºC, +6ºC, +8ºC
Notes:
• The support function is available only in the COOL mode. (Not available in the HEAT, DRY and AUTO
mode.)
• The support function is enabled when any option other than "None" is selected from the "Rotation"
setup options.
Reset method
• Press the [F4] button in step 4 or 5 to reset the operation time of the rotation function. Once it is reset, operation will start from the systems with
refrigerant addresses of 00 or 01.
Note: When the system with refrigerant address of 02 is in the backup operation, the 00 or 01 systems will be operated again.
F1 F2 F3 F4
Settings menu
Service menu:
Function setting
Rotation setting
Cursor
en
17
7. Testrun
7.2. Testrun
7.2.1. Usingwiredremotecontroller.
■ Make sure to read operation manual before test run. (Especially items to secure safety)
Step 1 Turn on the power.
● Remote controller: The system will go into startup mode, and the remote controller power lamp (green) and “Please Wait” will blink. While the lamp and message are
blinking, the remote controller cannot be operated. Wait until “Please Wait” is not displayed before operating the remote controller. After the power is turned on, “Please
Wait” will be displayed for approximately 2 minutes.
● Indoor controller board: LED 1 will be lit up, LED 2 will be lit up (if the address is 0) or off (if the address is not 0), and LED 3 will blink.
● Outdoor controller board: LED 1 (green) and LED 2 (red) will be lit up. (After the startup mode of the system finishes, LED 2 will be turned off.) If the outdoor controller
board uses a digital display, [- ] and [ -] will be displayed alternately every second.
If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they
are found.
(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)
Symptoms in test run mode
Cause
Remote Controller Display OUTDOORBOARDLEDDisplay
< > indicates digital display.
Remote controller displays “Please Wait”, and
cannot be operated. After “startup” is displayed, only green lights
up. <00> • After power is turned on, “Please Wait” is displayed for 2
minutes during system startup. (Normal)
After power is turned on, “Please Wait” is dis-
played for 3 minutes, then error code is displayed.
After “startup” is displayed, green (once) and red
(once) blink alternately. <F1> • Incorrect connection of outdoor terminal block (~/N: L, N and
S1, S2, S3) (3N~: L1, L2, L3, N and S1, S2, S3)
After “startup” is displayed, green (once) and red
(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.
No display appears even when remote controller
operation switch is turned on. (Operation lamp
does not light up.)
After “startup” is displayed, green (twice) and red
(once) blink alternately. <EA. Eb>
• Incorrect wiring between the indoor and outdoor unit (Polarity
is wrong for S1, S2, S3.)
• Remote controller transmission wire short.
After “startup” is displayed, only green lights
up. <00>
• There is no outdoor unit of address 0. (Address is other than
0.)
• Remote controller transmission wire open.
Display appears but soon disappears even when
remote controller is operated. After “startup” is displayed, only green lights
up. <00> • After canceling function selection, operation is not possible for
about 30 seconds. (Normal)
Step4 Conrmtheoperationoftheoutdoorunitfan.
The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will keep
rotating at that speed unless the performance is insucient. Therefore, the outdoor wind may cause the fan to stop rotating or to rotate in the opposite direction, but this is
not a problem.
7.1. Beforetestrun
►After completing installation and the wiring and piping of the indoor and
outdoorunits,checkforrefrigerantleakage,loosenessinthepower
supply or control wiring, wrong polarity, and no disconnection of one
phase in the supply.
►Usea500-voltmegohmmetertocheckthattheresistancebetweenthe
powersupplyterminalsandgroundisatleast1.0MΩ.
►Donotcarryoutthistestonthecontrolwiring(lowvoltagecircuit)
terminals.
Warning:
Do not use the air conditioner if the insulation resistance is less than 1.0 MΩ.
Step 2 Switch the remote controller to “Test run”.
1Select “Test run” from the Service menu, and press the [SELECT] button.
(Fig. 7-1)
2Select “Test run” from the Test run menu, and press the [SELECT] button.
(Fig. 7-2)
3The test run operation starts, and the Test run operation screen is displayed.
F1 F2 F3 F4
Test run
Input maintenance info.
Setting
Check
Others
Main menu:
Service menu
Cursor
Fig.7-1
F1 F2 F3 F4
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
Fig.7-2
F1 F2 F3 F4
Cool
Pipe
Auto
Switch disp.
Mode Fan
RemainTest run
Fig.7-3
F1 F2 F3 F4
Fri
Swing
Horiz
Low
Vent.Vert
Fig.7-4
Step3 Performthetestrunandchecktheairowtemperatureandautovane.
1 Press the [F1] button to change the operation mode. (Fig. 7-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2Press the [SELECT] button to display the Vane operation screen, and then
press the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)
Press the [RETURN] button to return to the Test run operation screen.
en
18
7. Testrun
7.2.2. Usingwirelessremotecontroller(Fig.7-5)
■ Testrun(Fig.7-5)
1. Press the button 1to stop the air conditioner.
• If the weekly timer is enabled ( is on), press the button 3to
disable it ( is off).
2. Press the button 2for 5 seconds.
• comes on and the unit enters the service mode.
3. Press the button 2.
• Bcomes on and the unit enters the test run mode.
4. Press the following buttons to start the test run.
: Switch the operation mode between cooling and heating and start the
test run.
: Switch the fan speed and start the test run.
: Switch the airflow direction and start the test run.
: Switch the louver and start the test run.
: Start the test run.
5. Stop the test run.
• Press the button 1to stop the test run.
• After 2 hours, the stop signal is transmitted.
7.2.3. UsingSW4inoutdoorunit
Refer to the outdoor unit installation manual.
7.3. Self-check
7.3.1. Wiredremotecontroller
■ Refer to the installation manual that comes with each remote controller for
details.
7.3.2. Wirelessremotecontroller(Fig.7-6)
■ Self-check(Fig.7-6)
1. Press the button 1to stop the air conditioner.
•If the weekly timer is enabled ( is on), press the button 3to
disable it ( is off).
2. Press the button 2for 5 seconds.
• Acomes on and the unit enters the self-check mode.
3. Press the button 5 to select the refrigerant address (M-NET address) Bof the
indoor unit for which you want to perform the self-check.
4. Press the button 4.
• If an error is detected, the check code is indicated by the number of beeps
from the indoor unit and the number of blinks of the OPERATION INDICA-
TOR lamp.
5. Press the button 1.
• A and the refrigerant address (M-NET address) Bgo off and the self-
check is completed.
Step5 Stopthetestrun.
1 Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)
Note: If an error is displayed on the remote controller, see the table below.
LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction
P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)
E0 ~ E5
Communication error between the
remote controller and the indoor
unit
P2 Pipe sensor error (liquid pipe) PA Leakage error (refrigerant system)
P4 Drain oat switch connector
disconnected (CN4F)
Pb Indoor unit fan motor error
PL Refrigerant circuit abnormal
P5 Drain overow protection operation FB Indoor controller board error
E6 ~ EF Communication error between the
indoor unit and the outdoor unit
P6 Freezing/overheating protection
operation
U*, F*
(* indicates an
alphanumeric
character
excluding FB.)
Outdoor unit malfunction
Refer to the wiring diagram for the
outdoor unit.
P8 Pipe temperature error
See the table below for the details of the LED display (LED 1, 2, and 3) on the indoor controller board.
LED 1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is connected
to the outdoor unit that has an address of 0.
LED 3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.
Fig.7-5
Fig.7-6
1
A
B
2
3
5
B
1
A
4
2
3
en
This manual suits for next models
1
Table of contents
Languages:
Other Mitsubishi Electric Air Conditioner manuals
Mitsubishi Electric
Mitsubishi Electric Mr.Slim MSY-GA24NA User manual
Mitsubishi Electric
Mitsubishi Electric PAC-SH63AF-E User manual
Mitsubishi Electric
Mitsubishi Electric Mr. Slim PSA-RP KA Series User manual
Mitsubishi Electric
Mitsubishi Electric Mr.Slim PEH-2.5EKHA User manual
Mitsubishi Electric
Mitsubishi Electric CITY MULTI PEFY-P36NMHU-E-OA User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-GF60VE - E1 User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-FA25VA User manual
Mitsubishi Electric
Mitsubishi Electric PWFY-P200VM-E-AU Product guide
Mitsubishi Electric
Mitsubishi Electric PLFY-P-VCM-E User manual
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM SEZ-KD71VAQ User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-GS18NA User manual
Mitsubishi Electric
Mitsubishi Electric MUZ-JP09WA-U1 User manual
Mitsubishi Electric
Mitsubishi Electric PEAD-A24 User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-FH25VE2 User manual
Mitsubishi Electric
Mitsubishi Electric PUMY-P60NKMU1 Operating manual
Mitsubishi Electric
Mitsubishi Electric PUZ-WZ50VAA User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-GA22VA User manual
Mitsubishi Electric
Mitsubishi Electric CITY MULTI PKFY-P-VKM-E User manual
Mitsubishi Electric
Mitsubishi Electric Trane NTXWPH06A112A Series User manual
Mitsubishi Electric
Mitsubishi Electric PUHZ-P200YKA3 User manual
Popular Air Conditioner manuals by other brands
Retro Aire
Retro Aire R30C Installation, operation & maintenance manual
Retro Aire
Retro Aire R40C Installation, operation & maintenance manual
Daikin
Daikin R32 Split Series installation manual
Fujitsu
Fujitsu AOU48RLXFZ1 installation manual
Haier
Haier AB052MAERA Operation & installation manual
Haier
Haier HC1891VAR Installation & operation manual
MegaLife
MegaLife NEBULA GREEN R32 Use and Installation Instructions
Thermal
Thermal CS011126 User's & technical manual
Hitachi
Hitachi RAK-18PSPA installation manual
Hitachi
Hitachi RA-13JF1 Operation and installation manual
Heiko
Heiko JZ026-B1 installation manual
Nordyne
Nordyne WARRCOIL01 quick start guide
