OPERATING INSTRUCTIONS For user
• To use this unit correctly and safely, be sure to read these operating
instructions before use.
SPLIT-TYPE AIR CONDITIONERS
INDOOR UNIT
MS-GS18VF MS-GS24VF
MS-GS30VF MS-GS36VF
01_VG79Y359H01_EN.indd 101_VG79Y359H01_EN.indd 1 23/6/21 10:1123/6/21 10:11

En-1
●OPERATING INSTRUCTIONS ●
SAFETY PRECAUTIONS
CONTENTS
Meanings of symbols displayed on indoor unit and/or outdoor unit
• Since rotating parts and parts which could cause an electric shock are used in this product, be sure to read these
“Safety Precautions” before use.
• Since the cautionary items shown here are important for safety, be sure to observe them.
• After reading this manual, keep it together with the installation manual in a handy place for easy reference.
Marks and their meanings
WARNING :
Incorrect handling could cause serious hazard, such as death, serious injury, etc. with a high probability.
CAUTION : Incorrect handling could cause serious hazard depending on the conditions.
■SAFETY PRECAUTIONS 1
■NAME OF EACH PART 5
■PREPARATION BEFORE OPERATION 7
■SELECTING OPERATION MODES 8
■FAN SPEED AND AIRFLOW DIRECTION ADJUSTMENT 9
■LONG OPERATION 10
■POWERFUL COOL OPERATION 11
■ECONO COOL OPERATION 11
■TIMER OPERATION (ON/OFF TIMER) 12
■CLEANING 13
■WHEN YOU THINK THAT TROUBLE HAS OCCURRED 15
■WHEN THE AIR CONDITIONER IS NOT GOING TO BE USED FOR A LONG TIME 17
■INSTALLATION PLACE AND ELECTRICAL WORK 17
■SPECIFICATIONS 18
WARNING
(Risk of fire)
This unit uses a flammable refrigerant.
If refrigerant leaks and comes in contact with fire or heating part, it will create harmful
gas and there is risk of fire.
Read the OPERATING INSTRUCTIONS carefully before operation.
Service personnel are required to carefully read the OPERATING INSTRUCTIONS and INSTALLATION
MANUAL before operation.
Further information is available in the OPERATING INSTRUCTIONS, INSTALLATION MANUAL, and the like.
01_VG79Y359H01_EN.indd 101_VG79Y359H01_EN.indd 1 23/6/21 10:1123/6/21 10:11

En-2
Meanings of symbols used in this manual
: Be sure not to do. : Be sure to disconnect the power supply plug
from the power outlet.
: Be sure to follow the instruction. : Be sure to shut off the power.
: Never insert your finger or stick, etc. : Risk of fire.
: Never step onto the indoor/outdoor unit
and do not put anything on them. : Never touch with wet hand.
: Danger of electric shock. Be careful. : Never splash water on the unit.
SAFETY PRECAUTIONS
WARNING
Do not connect the power cord to an intermediate point, use an extension cord, or connect
multiple devices to a single AC outlet.
• This may cause overheating, fire, or electric shock.
Make sure the power plug is free of dirt and insert it securely into the outlet.
• A dirty plug may cause fire or electric shock.
Do not bundle, pull, damage, or modify the power cord, and do not apply heat or place heavy
objects on it.
• This may cause fire or electric shock.
Do not turn the breaker OFF/ON or disconnect/connect the power plug during operation.
• This may create sparks, which can cause fire.
• After the indoor unit is switched OFF with the remote controller, make sure to turn the breaker OFF
or disconnect the power plug.
Do not expose your body directly to cool air for a prolonged length of time.
• This could be detrimental to your health.
The unit should not be installed, relocated, disassembled, altered, or repaired by the user.
• An improperly handled air conditioner may cause fire, electric shock, injury, or water leakage, etc.
Consult your dealer.
• If the power supply cord is damaged, it must be replaced by the manufacturer or its service agent
in order to avoid a hazard.
When installing, relocating, or servicing the unit, make sure that no substance other than the
specified refrigerant (R410A) enters the refrigerant circuit.
• Any presence of foreign substance such as air can cause abnormal pressure rise and may result
in explosion or injury.
• The use of any refrigerant other than that specified for the system will cause mechanical failure,
system malfunction, or unit breakdown. In the worst case, this could lead to a serious impediment
to securing product safety.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not insert your finger, a stick, or other objects into the air inlet or outlet.
• This may cause injury, since the fan inside rotates at high speeds during operation.
In case of an abnormal condition (such as a burning smell), stop the air conditioner and disconnect
the power plug or turn the breaker OFF.
• A continued operation in the abnormal state may cause a malfunction, fire, or electric shock. In this
case, consult your dealer.
01_VG79Y359H01_EN.indd 201_VG79Y359H01_EN.indd 2 23/6/21 10:1123/6/21 10:11

En-3
●OPERATING INSTRUCTIONS ●
SAFETY PRECAUTIONS
When the air conditioner does not cool or heat, there is a possibility of refrigerant leakage.
If any refrigerant leakage is found, stop operations and ventilate the room well and consult
your dealer immediately. If a repair involves recharging the unit with refrigerant, ask the service
technician for details.
• The refrigerant used in the air conditioner is safe. Normally, it does not leak. However, if refrigerant
leaks and comes in contact with a heat source such as a fan heater, kerosene heater, or cooking
stove, it will create a harmful gas and there is risk of fire.
The user should never attempt to wash the inside of the indoor unit. Should the inside of the
unit require cleaning, contact your dealer.
• Unsuitable detergent may cause damage to plastic material inside the unit, which may result in
water leakage. Should detergent come in contact with electrical parts or the motor, it will result in
a malfunction, smoke, or fire.
• The appliance shall be stored in a room without continuously operating ignition sources (for example:
open flames, an operating gas appliance or an operating electric heater).
• Be aware that refrigerants may not contain an odour.
• Do not use means to accelerate the defrosting process or to clean the appliance, other than those
recommended by the manufacturer.
• Do not pierce or burn.
The indoor unit must be installed in rooms which exceed the floor space specified. Please
consult your dealer.
CAUTION
Do not touch the air inlet or the aluminum fins of the indoor/outdoor unit.
• This may cause injury.
Do not use insecticides or flammable sprays on the unit.
• This may cause a fire or deformation of the unit.
Do not expose pets or houseplants to direct airflow.
• This may cause injury to the pets or plants.
Do not place other electric appliances or furniture under the indoor/outdoor unit.
• Water may drip down from the unit, which may cause damage or malfunction.
Do not leave the unit on a damaged installation stand.
• The unit may fall and cause injury.
Do not step on an unstable bench to operate or clean the unit.
• This may cause injury if you fall down.
Do not pull the power cord.
• This may cause a portion of the core wire to break, which may cause overheating or fire.
Do not charge or disassemble the batteries, and do not throw them into a fire.
• This may cause the batteries to leak, or cause a fire or explosion.
Do not operate the unit for more than 4 hours at high humidity (80% RH or more) and/or with
windows or outside door left open.
• This may cause the water condensation in the air conditioner, which may drip down, wetting or
damaging the furniture.
• The water condensation in the air conditioner may contribute to growth of fungi, such as mold.
Do not use the unit for special purposes, such as storing food, raising animals, growing plants,
or preserving precision devices or art objects.
• This may cause deterioration of quality, or harm to animals and plants.
Do not expose combustion appliances to direct airflow.
• This may cause incomplete combustion.
Never put batteries in your mouth for any reason to avoid accidental ingestion.
• Battery ingestion may cause choking and/or poisoning.
Before cleaning the unit, switch it OFF and disconnect the power plug or turn the breaker OFF.
• This may cause injury, since the fan inside rotates at high speeds during operation.
When the unit will be unused for a long time, disconnect the power plug or turn the breaker OFF.
• The unit may accumulate dirt, which may cause overheating or fire.
Replace all batteries of the remote controller with new ones of the same type.
• Using an old battery together with a new one may cause overheating, leakage, or explosion.
01_VG79Y359H01_EN.indd 301_VG79Y359H01_EN.indd 3 23/6/21 10:1123/6/21 10:11

En-4
SAFETY PRECAUTIONS
WARNING
Consult your dealer for installing the air conditioner.
• It should not be installed by the user since installation requires specialized knowledge and skills. An
improperly installed air conditioner may cause water leakage, fire, or electric shock.
Provide a dedicated power supply for the air conditioner.
• A non-dedicated power supply may cause overheating or fire.
Do not install the unit where flammable gas could leak.
• If gas leaks and accumulates around the outdoor unit, it may cause an explosion.
Earth the unit correctly.
• Do not connect the earth wire to a gas pipe, water pipe, lightning rod, or a telephone earth wire.
Improper earthing may cause electric shock.
CAUTION
Install an earth leakage breaker depending on the installation location of the air conditioner
(such as highly humid areas).
• If an earth leakage breaker is not installed, it may cause electric shock.
Ensure that the drain water is properly drained.
• If the drain passage is improper, water may drip down from the indoor/outdoor unit, wetting and
damaging the furniture.
In case of an abnormal condition
Immediately stop operating the air conditioner and consult your dealer.
For installation
IMPORTANT
Dirty filters cause condensation in the air conditioner which will contribute to the growth of fungi such as mold. It is
therefore recommended to clean air filters every 2 weeks.
If the battery fluid comes in contact with your skin or clothes, wash them thoroughly with
clean water.
• If the battery fluid comes in contact with your eyes, wash them thoroughly with clean water and
immediately seek medical attention.
Ensure that the area is well-ventilated when the unit is operated together with a combustion
appliance.
• Inadequate ventilation may cause oxygen starvation.
Turn the breaker OFF when you hear thunder and there is a possibility of a lightning strike.
• The unit may be damaged if lightning strikes.
After the air conditioner is used for several seasons, perform inspection and maintenance in
addition to normal cleaning.
• Dirt or dust in the unit may create an unpleasant odor, contribute to growth of fungi, such as mold,
or clog the drain passage, and cause water to leak from the indoor unit. Consult your dealer for
inspection and maintenance, which require specialized knowledge and skills.
Do not operate switches with wet hands.
• This may cause electric shock.
Do not clean the air conditioner with water or place an object that contains water, such as a
flower vase, on it.
• This may cause fire or electric shock.
Do not step on or place any object on the outdoor unit.
• This may cause injury if you or the object falls down.
01_VG79Y359H01_EN.indd 401_VG79Y359H01_EN.indd 4 23/6/21 10:1123/6/21 10:11

En-5
●OPERATING INSTRUCTIONS ●
Indoor unit
NAME OF EACH PART
Outdoor units may be different in appearance.
Outdoor unit
Operation indicator lamp
Remote control receiving section
Emergency
operation switch Page 9
Horizontal vane
Air outlet
Air filter
(Nano platinum filter)
Air inlet
Heat exchanger
Front panel
Air cleaning filter
(Electrostatic
anti-allergy enzyme
filter, option)
Display section
Air inlet (back and side)
Refrigerant piping
Drainage hose
Air outlet
Drain outlet
MS-GS18VF MS-GS24VF
01_VG79Y359H01_EN.indd 501_VG79Y359H01_EN.indd 5 23/6/21 10:1123/6/21 10:11

En-6
Indoor unit
NAME OF EACH PART
Outdoor units may be different in appearance.
Outdoor unit
Operation indicator
lamp
Remote control
receiving section
Emergency
operation switch Page 9
Horizontal vane
Air outlet
Air filter
(Nano platinum filter)
Air inlet
Front panel
Air cleaning filter
(Electrostatic anti-allergy
enzyme filter, option)
Display section
Air inlet (back and side)
Refrigerant piping
Drainage hose
Air outlet
Drain outlet
MS-GS30VF MS-GS36VF
01_VG79Y359H01_EN.indd 601_VG79Y359H01_EN.indd 6 23/6/21 10:1123/6/21 10:11

En-7
●OPERATING INSTRUCTIONS ●
Remote controller
NAME OF EACH PART P
REPARATION BEFORE OPERATION
• Make sure the polarity of the batteries is correct.
•
Do not use manganese batteries and leaking batter-
ies. The remote controller could malfunction.
• Do not use rechargeable batteries.
• Replace all batteries with new ones of the same
type.
• Batteries can be used for approximately 1 year.
However, batteries with expired shelf lives last
shorter.
• Press RESET gently using a thin instrument.
If the RESET button is not pressed, the remote con-
troller may not operate correctly.
Before operation: Insert the power supply plug into the
power outlet and/or turn the breaker on.
Installing the remote controller batteries
1.
Remove the front lid.
2.
Insert the nega-
tive pole of AAA
alkaline batteries
first.
3. Install the front lid.
4. Press RESET.
• Press CLOCK gently using a thin
instrument.
Setting current time
1. Press CLOCK.
3. Press CLOCK
again.
2. Press the TIME buttons
to set the time.
Each press increases/
decreases the time by
1 minute (10 minutes
when pressed longer).
Remote controller
holder
Signal transmitting
section
Distance of signal :
About 6 m
Beep(s) is (are) heard
from the indoor unit
when the signal is
received.
Operation
display section
OFF/ON
(stop/operate)
button
Temperature
buttons Page 8
Operation select
button Page 8
ECONO COOL
button Page 11
FAN speed control
button Page 9
Off-timer button Page 12
On-timer button Page 12
VANE control
button Page 9
TIME set buttons Pages 7, 12
Increase time
Decrease time
CLOCK button Page 7
RESET button Page 7
Lid Slide
down to
open
• Install the remote
controller holder in
a place where the
signal can be re-
ceived by the indoor
unit.
Only use the remote controller provided with the unit.
Do not use other remote controllers.
If two or more indoor units are installed in proximity to one
another, an indoor unit that is not intended to be operated
may respond to the remote controller.
WIDE VANE button Page 9
LONG button Page 10
POWERFUL
COOL button
Page 11
01_VG79Y359H01_EN.indd 701_VG79Y359H01_EN.indd 7 23/6/21 10:1123/6/21 10:11

En-8
SELECTING OPERATION MODES
1Press to start the operation.
2Press to select operation mode. Each press
changes mode in the following order:
(I FEEL) (COOL) (DRY) (FAN)
3Press or to set the temperature.
Each press raises or lowers the temperature by 1°C.
Press to stop the operation.
• The same setting is selected the next time by simply
pressing .
Operation indicator lamp
The operation indicator lamp shows the operation state of the unit.
Indication Operation state Room temperature
The unit is operating to reach the set temperature About 2°C or more away from set tem-
perature
The room temperature is approaching the set temperature About 1 to 2°C from set temperature
Lit Not lit
I FEEL mode
The unit selects the operation mode according to the room temperature when I FEEL is selected. When the
room temperature is higher than 25°C, COOL is selected (set temperature: 24°C). When the room temperature
is lower than 25°C, DRY is selected. However, when operation is stopped and then started within 2 hours, the
mode which has been selected previously is operated.
Note:
During COOL operation, the set temperature may not be changed when the room temperature is more than 2°C
higher than the set temperature. In this case, please wait until the room temperature drops to within 2°C of the
set temperature.
COOL mode
Enjoy cool air at your desired temperature.
DRY mode
Dehumidify your room. The room may be cooled slightly.
Temperature cannot be set during DRY mode.
FAN mode
Circulate the air in your room.
01_VG79Y359H01_EN.indd 801_VG79Y359H01_EN.indd 8 23/6/21 10:1123/6/21 10:11

En-9
●OPERATING INSTRUCTIONS ●
FAN SPEED AND AIRFLOW
DIRECTION ADJUSTMENT
Operation indicator lamp
Emergency operation
When the remote controller cannot be used...
Emergency operation can be activated by pressing the
emergency operation switch (E.O.SW) on the indoor unit.
Each time the E.O.SW is pressed, the
operation changes in the following order:
Auto restart function
If a power failure occurs or the main power is turned off
during operation, “Auto restart function” automatically starts
operation in the same mode as the one set with the remote
controller just before the shutoff of the main power. When
timer is set, timer setting is cancelled and the unit starts
operation when power is resumed.
If you do not want to use this function, please consult
the service representative because the setting of the
unit needs to be changed.
Set temperature : 24°C
Fan speed : Medium
Horizontal vane : Auto
Note:
The first 30 minutes of operation is
test run. Temperature control does not
work, and fan speed is set to High.
Emergency COOL
Stop
Press to select fan speed. Each press
changes fan speed in the following order:
(AUTO) (Low) (Med.) (High) (Super High)
• Two short beeps are heard from the indoor unit
when set to AUTO.
Press to select vertical airflow direction.
Each press changes airflow direction in the fol-
lowing order:
(AUTO) (1) (2) (3) (4) (5) (SWING)
• Two short beeps are heard from the indoor unit
when set to AUTO.
Press to select horizontal airflow direction.
Each press changes airflow direction in the follow-
ing order:
(SWING)
Operation indicator lamp
Emergency COOL
<GS18/24>
<GS30/36>
Stop
01_VG79Y359H01_EN.indd 901_VG79Y359H01_EN.indd 9 23/6/21 10:1123/6/21 10:11
