Mitsubishi Electric Mr.Slim PKH-P3FALH Operating manual

TECHNICAL & SERVICE MANUAL
CONTENTS
1. TECHNICAL CHANGES···································2
2. COMBINATION OF INDOORAND OUTDOOR UNITS···2
3. SAFETY PRECAUTION····································3
4. PART NAMES AND FUNCTIONS ····················4
5. SPECIFICATIONS·············································7
6. DATA ·······························································19
7. OUTLINES AND DIMENSIONS······················42
8. WIRING DIAGRAM·········································44
9. REFRIGERANT SYSTEM DIAGRAM ···················45
10. TROUBLESHOOTING ····································47
11. DISASSEMBLY PROCEDURE························48
12. PARTS LIST ····················································51
13. OPTIONAL PARTS·····················BACK COVER
1999
Indoor unit
[Model names]
1999, 2001
PKH-P2.5FALH
PKH-P3FALH
PKH-P4FALH
2000, 2001
PKA-P2.5FAL
PKA-P3FAL
PKA-P4FAL
[Service Ref.]
1999
PKH-P2.5FALH
PKH-P3FALH
PKH-P4FALH
2000
PKA-P2.5FAL
PKA-P3FAL
PKA-P4FAL
2001
PKH-P2.5FALH1
PKH-P2.5FALH2
PKH-P3FALH1
PKH-P3FALH2
PKH-P4FALH1
PKH-P4FALH2
2001
PKA-P2.5FAL1
PKA-P2.5FAL2
PKA-P3FAL1
PKA-P3FAL2
PKA-P4FAL1
PKA-P4FAL2
Indoor unit
Wall MountedSeries PKH/PKA
No.OC175
REVISED EDITION-B
R407C
ON/OFF
Remote controller
SPLIT-TYPE,HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS
• PKH-P2.5/3/4FALH1, PKA-P2.5/3/4FAL1, PKH-P2.5/3/4FALH2and
PKA-P2.5/3/4FAL2, are added in Revised Edition-B.
• Please void NO.OC175 Revised Edition-A.
• Refer to the OCT03 Revised Edition-C as regarding control relation.
This manual does not cover outdoor units. When servicing them,
please refer to the service manual No.OC180 Revised Edition-A,
OC261 and this manual in a set.
PKH-P•FALH, PKH-P•FALH1
PKA-P•FAL, PKA-P•FAL1PKH-P•FALH2 PKA-P•FAL2
OC175B--1.qxp 01.10.2 3:11 PM Page 1

2
1 TECHNICAL CHANGES
2COMBINATION OF INDOOR AND OUTDOOR UNITS
Heat pump typeOutdoor unit
PUH-P Cooling only type PU-P
Heat pump with
electric heater
PKH-P2.5FALH
PKH-P2.5FALH1
PKH-P3FALH
PKH-P3FALH
1
PKH-P4FALH
PKH-P4FALH
1
PKA-P2.5FAL
PKA-P2.5FAL
1
PKA-P3FAL
PKA-P3FAL
1
PKA-P4FAL
PKA-P4FAL
1
Heat pump without
electric heater
or
Cooling only
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Indoor unit 2.5VGA
2.5VGA12.5YGA 2.5YGA13VGA 3YGA 4YGA 2.5VGA
2.5VGA13VGA 3YGA 4YGA
Heat pump type Outdoor unit
PUH-P Cooling only type PU-P
Heat pump with
electric heater
PKH-P2.5FALH2
PKH-P3FALH 2
PKH-P4FALH 2
PKA-P2.5FAL 2
PKA-P3FAL 2
PKA-P4FAL 2
Heat pump without
electric heater
or
Cooling only
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Indoor unit
2.5VGAA.
UK 2.5YGAA. UK
3VGAA.
UK 3YGAA. UK 4VGAA. UK 4YGAA. UK
2.5VGAA.
UK 2.5YGAA. UK
3VGAA.
UK 3YGAA. UK 4VGAA. UK 4YGAA. UK
PKH-P2.5FALH ➔PKH-P2.5FALH1PKA-P2.5FAL ➔PKA-P2.5FAL1
PKH-P3FALH ➔PKH-P3FALH1PKA-P3FAL ➔PKA-P3FAL1
PKH-P4FALH ➔PKH-P4FALH1PKA-P4FAL ➔PKA-P4FAL1
●DRAIN PAN has changed by changing its shape.
●CENTER SUPPORT has changed by changing its shape.
●NOSE has changed by changing its shape.
●BOX ASSEMBLY has changed by changing its shape.
PKH-P2.5FALH1➔PKH-P2.5FALH2PKA-P2.5FAL1➔PKA-P2.5FAL2
PKH-P3FALH1➔PKH-P3FALH2PKA-P3FAL1➔PKA-P3FAL2
PKH-P4FALH1➔PKH-P4FALH2PKA-P4FAL1➔PKA-P4FAL2
●Outdoor units which are connected to PKH-P·FALH2and PKA-P·FAL2have been added.
●The parts No. of REMOTE CONTROLLER has changed.
(The following parts numbers are interchangeable.)
ON/OFF
[ T7W E03 714 ] [ T7W E06 714 ]
➔
OC175B--1.qxp 01.10.2 3:11 PM Page 2

3
3 SAFETY PRECAUTION
Cautions for using with the outdoor unit which adopts R407C refrigerant.
· Do not use the existing refrigerant piping.
-The old refrigerant and refrigerant oil in the existing piping contains a large amount of chlorine which may cause the refriger-
ant oil of the new unit to deteriorate.
· Do not use copper pipes which are broken, deformed or discolour .
-In addition, be sure that the inner surfaces of the pipes are clean, free of hazardous sulphur and oxides, or have no dust /
dirt, shaving particles, oils, moisture or any other contamination.
-If there is a large amount of residual oil (hydraulic oil, etc.) inside the piping and joints, deterioration of the refrigerant oil will
result.
· Store the piping to be used during installation indoors and keep both ends of the piping sealed until just before
brazing. (Store elbows and other joints in a plastic bag.)
-If dust, dirt, or water enters the refrigerant cycle, deterioration of the oil and compressor trouble may result.
· Use ester oil, ether oil or alkyl benzene (small amount) as the refrigerant oil to coat flares and flange connections.
-The refrigerant oil will degrade if it is mixed with a large amount of mineral oil.
Use liquid refrigerant to fill the system.
-If gas refrigerant is used to fill the system, the composition of the refrigerant in the cylinder will change and performance
may drop.
· Do not use a refrigerant other than R407C.
-If another refrigerant (R22, etc.) is used, the chlorine in the refrigerant may cause the refrigerant oil to deteriorate.
· Use a vacuum pump with a reverse flow check valve.
-The vacuum pump oil may flow back into the refrigerant cycle and cause the refrigerant oil to deteriorate.
· Do not use the following tools that are used with conventional refrigerant.
(Gauge manifold , charge hose, gas leak detector, reverse flow check valve, refrigerant charge base, vacuum gauge,
refrigerant recovery equipment)
-If the conventional refrigerant and refrigerant oil are mixed in the R407C, the refrigerant may deteriorated.
-If water is mixed in the R407C, the refrigerant oil may deteriorate.
-Since R407C does not contain any chlorine, gas leak detectors for conventional refrigerant will not react to it.
· Do not use a charging cylinder.
-Using a charging cylinder may cause the refrigerant to deteriorate.
· Be especially careful when managing the tools.
-if dust, dirt, or water gets in the refrigerant cycle, the refrigerant may deteriorate.
· Don’t use the drier which is sold in the field.
-The drier for R407C refrigerant is Pre-attached to outdoor unit refrigerant circuit.
-Some drier in the field are not in conformity with R407C refrigerant.
[1] Service tools
Use the below service tools as exclusive tools for R407C refrigerant.
No. Tool name Specifications
1Gauge manifold ·Only for R407C.
·Use the existing fitting SPECIFICATIONS. (UNF7/16)
·Use high-tension side pressure of 3.43MPa·G or over.
2Charge hose ·Only for R407C.
·Use pressure performance of 5.10MPa·G or over.
3Electronic scale
4Gas leak detector ·Use the detector for R407C.
5Adapter for reverse flow check ·Attach on vacuum pump.
6Refrigerant charge base
7Refrigerant cylinder ·For R407C ·Top of cylinder (Brown)
·Cylinder with syphon
8Refrigerant recovery equipment
OC175B--1.qxp 01.10.2 3:11 PM Page 3

4
[3] Refrigerant recharging
(1) Refrigerant recharging process
1Direct charging from the cylinder.
·R407C cylinder are available on the market has a syphon pipe.
·Leave the syphon pipe cylinder standing and recharge it.
(By liquid refrigerant)
(2) Recharge in refrigerant leakage case
·After recovering the all refrigerant in the unit, proceed to working.
·Do not release the refrigerant in the air.
·After completing the repair service, recharge the cycle with the specified amount of
liquid refrigerant.
Gravimeter
Unit
[2] Notice on repair service
·After recovering the all refrigerant in the unit, proceed to working.
·Do not release refrigerant in the air.
·After completing the repair service, recharge the cycle with the specified amount of
liquid refrigerant.
4PART NAMES AND FUNCTIONS
● Indoor Unit
Air intake
room air is suctioned
in here. (Removes dust and dirt from the intake air.)
Disperses airflow up and
down as well as adjusts the
angle of air flow direction.
Filter Air intake grille
Air outletAir outlet
Swing louvers
Indicator lamp section
Air flow can be changed to horizontally
by moving the Guide vane to the left or
right.
Guide vane
OC175B--1.qxp 01.10.2 3:11 PM Page 4

5
ON/OFF
RESET
MODE FAN
VANE
TEMP.
START
STOP
HR.
MIN.
ON/OFF
CHECK
ADDRESS
UNIT No.
FUNCTION No.
SELECTION No.
AM
PM
RESET
AM
PM
TEST RUN
FUNCTION
˚C
MODE FAN
VANE
TEMP.
START
STOP
HR.
MIN.
display
OPERATION MODE display
Operation mode display indicates which oper-
ation mode is in effect.
PKH-P2.5/3/4FALH, PKA-P2.5/3/4FAL
PKH-P2.5/3/4FALH1, PKA-P2.5/3/4FAL1
●Wireless remote controller
●When cover is open.
display
Displays when batteries are dead.
display
Lights up when function are set..
display
The unit is turned ON and OFF alternately
each time the button is pressed.
display
The vertical direction of airflow is indicated.
display
FAN SPEED display indicates which fan
speed has been selected.
MODE SELECT button
Used to switch the operation mode between
cooling , drying , blowing , heating and auto
mode.
FAN SPEED SELECT button
Used to change the fan speed.
VANE CONTROL button
Used to change the airflow direction.
display
SET TEMP. display indicates desired tempera-
ture set.
CLOCK display
DIsplays the current time.
“ ”display
Flashes when the current time is displayed.
TIMER display
Displays when in timer operation or when set-
ting timer.
“ ” “ ” display
Displays the order of timer operation.
“ ” “ ” display
Displays whether timer is on or off.
HR. and MIN.buttons
Buttons used to set the “hour and minute” of
the current time and timer settings.
➡
➡
“ ” “ ” display
Displays when the current time and the timer
time can be changed.
▼
▼
●When cover is open.
TEMP. button
SET TEMPERATURE button sets any desired
room temperature.
TIMER CONTROL buttons
STOP (OFF timer): when this switch is set,
the air conditioner will be automatically
stopped at the preset time.
START (ON timer): when this switch is set, the
air conditioner will be automatically started at
the preset time.
• TEST RUN • CHECK display
CHECK&TEST RUN display indicates that the
unit is being checked or test-run.
• FUNCTION
SELECTION NO. display
Displays the selection number..
UNIT NO. display
Displays the number of unit..
FUNCTION NO. display
Displays the mode.
ADDRESS display
Displays the refrigerant address.
display
Lights up while transmission to the indoor unit
is mode using switches.
RESET button
button
OC175B--1.qxp 01.10.2 3:11 PM Page 5

6
PKH-P2.5/3/4FALH2
PKA-P2.5/3/4FAL2
●Wireless remote controller
●When cover is open.
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
NOT AVAILABLE
CHECK TEST RUN
˚C
AMPM
AMPM
VANE CONTROL button
Used to change the air flow direction.
CLOCK button
RESET button
SET button
ON/OFF button
The unit is turned ON and OFF alternately
each time the button is pressed.
LOUVER button
This switch the horizontal fan motion ON
and OFF.
(Not available for this model.)
MODE SELECT button
Used to switch the operation mode between
cooling, drying, blowing, heating and auto
mode.
CHECK-TEST RUN button
Only press this button to perform an inspec-
tion check or test operation.
Do not use it for normal operation.
FAN SPEED SELECT button
Used to change the fan speed.
TIMER display
Displays when in timer operation or when
setting timer.
button
SET TEMPERATURE button sets any desired
room temperature.
CLOCK display
Displays the current time.
“” “ ” display
Displays the order of timer operation.
“ ” “ ” display
Displays whether timer is on or off.
wIn case the outdoor unit is cool only type,
the heating mode is not available.
Buttons used to set the “hour and minute” of
the current time and timer settings.
h and min buttons
display
SET TEMP. display indicates desired temper-
ature set.
display
FAN SPEED display indicates which fan
speed has been selected.
display
The vertical direction of air flow is indicated.
display
Blinks when model is selected.
display
Lights up while transmission to the indoor
unit is mode using switches.
display
CHECK&TEST RUN display indicates that
the unit is being checked or test-run.
display
OPERATION MODE display
Operation mode display indicates which op-
eration mode is in effect.
TIMER CONTROL buttons
AUTO STOP (OFF timer): when this switch
is set, the air conditioner will be au-
tomatically stopped at the preset time.
AUTO START (ON timer): when this switch
is set, the air conditioner will be automatical-
ly started at the preset time.
MODEL SELECT
CHECK TEST RUN
OC175B--1.qxp 01.10.2 3:11 PM Page 6

7
5SPECIFICATIONS
Cooling
22,200
6,500
2.72
0.09
0.43
0.80
11.78 / 4.11
Heating
25,200(32,400)
7,400(9,500)
2.67(4.77)
0.09<2.10>
0.43<8.75>
0.80<8.75>
11.55 / 4.03
PKH-P2.5FALH / PKH-P2.5FALH1
PKA-P2.5FAL / PKA-P2.5FAL1
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
<2.1>
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
26(57)
24(53)
PUH-P2.5VGA, PUH-P2.5VGA1/ PUH-P2.5YGA, PUH-P2.5YGA1
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
77 / 32
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE41VMJM / NE41YEJM
1.9
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch, Anti-phase protector.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
Reverse cycle
48
50
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.3(7.3)
1.2 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKH-P2.5FALH / PKH-P2.5FALH1
PKA-P2.5FAL / PKA-P2.5FAL1
Service Ref. With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity w1
Total input w1
Service Ref.
Power supply(phase, cycle,voltage)
Input w2
Running current w2
Starting current w2
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater w2
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
w1 : ( ) Shows the total rating.
w2 : < > Shows the only booster heater rating.
1. Heat pump type
OC175B--1.qxp 01.10.2 3:11 PM Page 7

8
Service Ref. With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity w1
Total input w1
Service Ref.
Power supply(phase, cycle,voltage)
Input w2
Running current w2
Starting current w2
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater w2
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Cooling
27,000
7,900
3.43
0.09
0.43
0.80
14.64/5.46
Heating
32,200(39,400)
9,450(11,550)
3.61(5.71)
0.09<2.10>
0.43<8.75>
0.80<8.75>
15.43/5.76
PKH-P3FALH / PKH-P3FALH1
PKA-P3FAL / PKA-P3FAL1
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
<2.1>
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
26(57)
24(53)
PUH-P3VGA / PUH-P3YGA
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
93/41
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE52VNJM / NE52YDJM
2.5
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch, Anti-phase protector.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
Reverse cycle
49
51
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.7(8.2)
1.6 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKH-P3FALH / PKH-P3FALH1
PKA-P3FAL / PKA-P3FAL1
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
w1 : ( ) Shows the total rating.
w2 : < > Shows the only booster heater rating.
OC175B--1.qxp 01.10.2 3:11 PM Page 8

9
Service Ref. With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity w1
Total input w1
Service Ref.
Power supply(phase, cycle,voltage)
Input w2
Running current w2
Starting current w2
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater w2
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Cooling
33,100
9,700
3.47
0.11
0.52
0.90
5.49
Heating
37,200(45,400)
10,900(13,300)
3.65(6.05)
0.11<2.40>
0.52<10.00>
0.90<10.00>
5.79
PKH-P4FALH / PKH-P4FALH1
PKA-P4FAL / PKA-P4FAL1
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(777-988)
0(direct blow)
<2.40>
Wireless remote controller & built-in
41-46
20(13/16)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
30(66)
28(62)
PUH-P4YGA
3 phase, 50Hz, 380-400-415V (4wires)
45
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE56YDJM
2.7
Line start
Anti-phase protector, Thermal relay, Discharge thermo, HP switch
38
Plate fin coil
Propeller (direct) x 2
0.070+0.070
85(3,000)
Reverse cycle
51
53
900(35-7/16)
330+20(13+3/4)
1,260 (49-5/8)
96(212)
R407C
4.0(8.8)
1.6 (Ester)MEL56
9.52 (3/8)
19.05 (3/4)
Flared
Flared
Max. 50m
Max. 50m
PKH-P4FALH / PKH-P4FALH1
PKA-P4FAL / PKA-P4FAL1
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
w1 : ( ) Shows the total rating.
w2 : < > Shows the only booster heater rating.
OC175B--1.qxp 01.10.2 3:11 PM Page 9

10
2. Cooling only type
Cooling
22,200
6,500
2.72
PKA-P2.5FAL / PKA-P2.5FAL1
Single phase, 50Hz, 220-230-240V
0.09
0.43
0.80
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
—
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
24(53)
PU-P2.5VGA / PU-P2.5VGA1
Single phase, 50Hz, 220-230-240V
11.78
77
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE41VMJM
1.9
Line start
Internal thermostat, HP switch, Discharge thermo.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
—
48
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.3(7.3)
1.2 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKA-P2.5FAL / PKA-P2.5FAL1
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle,voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
OC175B--1.qxp 01.10.2 3:11 PM Page 10

11
Cooling
27,000
7,900
3.43
PKA-P3FAL / PKA-P3FAL1
Single phase, 50Hz, 220-230-240V
0.09
0.43
0.80
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
—
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
24(53)
PU-P3VGA / PU-P3YGA
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
14.64/5.46
93/41
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE52VNJM / NE52YDJM
2.5
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch, Anti-phase protector.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
—
49
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.7(8.2)
1.6 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKA-P3FAL / PKA-P3FAL1
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle,voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
OC175B--1.qxp 01.10.2 3:11 PM Page 11

12
PKA-P4FAL / PKA-P4FAL1
Single phase, 50Hz, 220-230-240V
0.11
0.52
0.90
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(777-988)
0(direct blow)
—
Wireless remote controller & built-in
41-46
20(13/16)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
28(62)
PU-P4YGA
3 phase, 50Hz, 380-400-415V (4wires)
5.49
45
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE56YDJM
2.7
Line start
Anti-phase protector, Thermal relay, Discharge thermo, HP switch
38
Plate fin coil
Propeller (direct) x 2
0.070+0.070
85(3,000)
—
51
900(35-7/16)
330+20(13+3/4)
1,260 (49-5/8)
96(212)
R407C
4.0(8.8)
1.6 (Ester)MEL56
9.52 (3/8)
19.05 (3/4)
Flared
Flared
Max. 50m
Max. 50m
PKA-P4FAL / PKA-P4FAL1
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle,voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Cooling
33,100
9,700
3.47
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
OC175B--1.qxp 01.10.2 3:11 PM Page 12

13
Cooling
22,200
6,500
2.67
0.09
0.43
0.80
11.90 / 4.48
Heating
25,200(32,400)
7,400(9,500)
2.67(4.43)
0.09<2.10>
0.43<8.75>
0.80<8.75>
11.51 / 4.34
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
<2.1>
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
26(57)
24(53)
PUH-P2.5VGAA.UK / PUH-P2.5YGAA.UK
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
77 / 35
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE41VMJMT / NE41YEKMT
1.9
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
Reverse cycle
48
50
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.1(6.8)
1.2 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKH-P2.5FALH2
PKA-P2.5FAL2
Service Ref. With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity w1
Total input w1
Service Ref.
Power supply(phase, cycle,voltage)
Input w2
Running current w2
Starting current w2
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater w2
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
w1 : ( ) Shows the total rating.
w2 : < > Shows the only booster heater rating.
PKH-P2.5FALH2
PKA-P2.5FAL2
3. Heat pump type
OC175B--1.qxp 01.10.2 3:11 PM Page 13

14
Service Ref. With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity w1
Total input w1
Service Ref.
Power supply(phase, cycle,voltage)
Input w2
Running current w2
Starting current w2
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater w2
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Cooling
27,000
7,900
3.44
0.09
0.43
0.80
14.81 / 5.29
Heating
32,200(39,400)
9,450(11,550)
3.62(5.72)
0.09<2.10>
0.43<8.75>
0.80<8.75>
15.76 / 5.63
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
<2.1>
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
26(57)
24(53)
PUH-P3VGAA.UK / PUH-P3YGAA.UK
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
93 / 47
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE52VNJMT / NE52YDKMT
2.5
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
Reverse cycle
49
51
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.3(7.3)
1.3 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKH-P3FALH2
PKA-P3FAL2
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
w1 : ( ) Shows the total rating.
w2 : < > Shows the only booster heater rating.
PKH-P3FALH2
PKA-P3FAL2
OC175B--1.qxp 01.10.2 3:11 PM Page 14

15
Service Ref. With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
With Electric heater
Without Electric heater
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity w1
Total input w1
Service Ref.
Power supply(phase, cycle,voltage)
Input w2
Running current w2
Starting current w2
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater w2
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Cooling
32,200
9,450
3.59
0.11
0.52
0.90
15.71 / 5.55
Heating
37,200(45,400)
10,900(13,300)
3.78(6.18)
0.11<2.40>
0.52<10.00>
0.90<10.00>
16.58 / 5.86
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(777-988)
0(direct blow)
<2.40>
Wireless remote controller & built-in
41-46
20(13/16)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
30(66)
28(62)
PUH-P4VGAA.UK / PUH-P4YGAA.UK
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
99 / 49
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE56VNJMT / NE56YDKMT
2.7
Line start
Internal thermostat, HP switch Discharge thermo. / Thermal relay, Discharge thermo, HP switch
38
Plate fin coil
Propeller (direct) x 2
0.070+0.070
85(3,000)
Reverse cycle
51
53
900(35-7/16)
330+20(13+3/4)
1,260 (49-5/8)
96(212)
R407C
4.0(8.8)
1.3 (Ester)MEL56
9.52 (3/8)
19.05 (3/4)
Flared
Flared
Max. 50m
Max. 50m
PKH-P4FALH2
PKA-P4FAL2
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
w1 : ( ) Shows the total rating.
w2 : < > Shows the only booster heater rating.
PKH-P4FALH2
PKA-P4FAL2
OC175B--1.qxp 01.10.2 3:11 PM Page 15

16
4. Cooling only type
Cooling
22,200
6,500
2.67
PKA-P2.5FAL2
Single phase, 50Hz, 220-230-240V
0.09
0.43
0.80
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
—
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
24(53)
PU-P2.5VGAA.UK / PU-P2.5YGAA.UK
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
11.90 / 4.48
77 / 35
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE41VMJMT / NE41YEKMT
1.9
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal reray, HP switch, Discharge thermo.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
—
48
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.1(6.8)
1.2 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKA-P2.5FAL2
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle,voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
OC175B--1.qxp 01.10.2 3:11 PM Page 16

17
Cooling
27,000
7,900
3.44
PKA-P3FAL2
Single phase, 50Hz, 220-230-240V
0.09
0.43
0.80
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20 (530-706)
0(direct blow)
—
Wireless remote controller & built-in
39-45
20(13/16)
1,400(13/16)
235(9-1/4)
340(13-3/8)
24(53)
PU-P3VGAA.UK / PU-3YGAA.UK
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
14.81 / 5.29
93 / 47
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE52VNJMT / NE52YDKMT
2.5
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch.
38
Plate fin coil
Propeller (direct) x 1
0.070
50(1,770)
—
49
900(35-7/16)
330+20(13+3/4)
855 (33-5/8)
82(181)
R407C
3.3(7.3)
1.3 (Ester)MEL56
9.52 (3/8)
15.88 (5/8)
Flared
Flared
Max. 50m
Max. 50m
PKA-P3FAL2
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle,voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz / 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
OC175B--1.qxp 01.10.2 3:11 PM Page 17

18
PKA-P4FAL2
Single phase, 50Hz, 220-230-240V
0.11
0.52
0.90
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(777-988)
0(direct blow)
—
Wireless remote controller & built-in
41-46
20(13/16)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
28(62)
PU-P4VGAA.UK / PU-P4YGAA.UK
Single phase, 50Hz, 220-230-240V / 3 phase, 50Hz, 380-400-415V(4wires)
15.71 / 5.55
99 / 49
Munsell 5Y 7/1
Linear Expansion Valve
Hermetic
NE56VNJMT / NE56YDKMT
2.7
Line start
Internal thermostat, HP switch, Discharge thermo. / Thermal relay, Discharge thermo, HP switch
38
Plate fin coil
Propeller (direct) x 2
0.070+0.070
85(3,000)
—
51
900(35-7/16)
330+20(13+3/4)
1,260 (49-5/8)
96(212)
R407C
4.0(8.8)
1.3 (Ester)MEL56
9.52 (3/8)
19.05 (3/4)
Flared
Flared
Max. 50m
Max. 50m
PKA-P4FAL2
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
kW
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
A
A
kW
W
kW
K
/min(CFM )
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle,voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Booster heater
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply (phase, cycle, voltage)
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
INDOOR UNITOUTDOOR UNIT
REFRIGERANT PIPING
W
D
H
Cooling
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Cooling
32,200
9,450
3.59
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit Single phase 240V 50Hz
Outdoor Unit Single phase 240V 50Hz 3 phase 415V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
OC175B--1.qxp 01.10.2 3:11 PM Page 18

19
6DATA
1. PERFORMANCE DATA
1) COOLING CAPACITY(1)
PKH-P2.5FALH, PKH-P2.5FALH1
PKA-P2.5FAL, PKA-P2.5FAL1
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
Outdoor intake air D.B.(°C)
20 25 30
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
6,435
6,890
7,410
6,435
6,890
7,410
6,435
6,890
7,410
7,898
6,435
6,890
7,410
7,898
6,435
6,890
7,410
7,898
6,435
6,890
7,410
7,898
6,435
6,890
7,410
7,898
6,435
6,890
7,410
7,898
SHC(W)
4,505
3,996
3,409
5,019
4,547
4,001
5,534
5,099
4,594
3,949
6,049
5,650
5,187
4,581
6,435
6,201
5,780
5,212
6,435
6,752
6,373
5,844
6,435
6,890
6,965
6,476
6,,435
6,890
7,410
7,108
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
P.C.
2.18
2.22
2.28
2.18
2.22
2.28
2.18
2.22
2.28
2.34
2.18
2.22
2.28
2.34
2.18
2.22
2.28
2.34
2.18
2.22
2.28
2.34
2.18
2.22
2.28
2.34
2.18
2.22
2.28
2.34
CA
6,240
6,695
7,248
6,240
6,695
7,248
6,240
6,695
7,248
7,735
6,240
6,695
7,248
7,735
6,240
6,695
7,248
7,735
6,240
6,695
7,248
7,735
6,240
6,695
7,248
7,735
6,240
6,695
7,248
7,735
SHC(W)
4,368
3,883
3,334
4,867
4,419
3,914
5,366
4,954
4,493
3,868
5,866
5,490
5,073
4,486
6,240
6,026
5,653
5,105
6,240
6,561
6,233
5,724
6,240
6,695
6,813
6,343
6,240
6,695
7,248
6,962
P.C.
2.30
2.34
2.39
2.30
2.34
2.39
2.30
2.34
2.39
2.48
2.30
2.34
2.39
2.48
2.30
2.34
2.39
2.48
2.30
2.34
2.39
2.48
2.30
2.34
2.39
2.48
2.30
2.34
2.39
2.48
CA
6,045
6,468
7,053
6,045
6,468
7,053
6,045
6,468
7,053
7,540
6,045
6,468
7,053
7,540
6,045
6,468
7,053
7,540
6,045
6,468
7,053
7,540
6,045
6,468
7,053
7,540
6,045
6,468
7,053
7,540
SHC(W)
4,232
3,751
3,244
4,715
4,269
3,808
5,199
4,786
4,373
3,770
5,682
5,303
4,937
4,373
6,045
5,821
5,501
4,976
6,045
6,338
6,065
5,580
6,045
6,468
6,629
6,183
6,045
6,468
7,053
6,786
P.C.
2.43
2.50
2.56
2.43
2.50
2.56
2.43
2.50
2.56
2.64
2.43
2.50
2.56
2.64
2.43
2.50
2.56
2.64
2.43
2.50
2.56
2.64
2.43
2.50
2.56
2.64
2.43
2.50
2.56
2.64
OC175B--1.qxp 01.10.2 3:11 PM Page 19

20
COOLING CAPACITY(2)
PKH-P2.5FALH, PKH-P2.5FALH1
PKA-P2.5FAL, PKA-P2.5FAL1
Outdoor intake air D.B.(°C)
35 40 45
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
5,785
6,240
6,760
5,785
6,240
6,760
5,785
6,240
6,760
7,280
5,785
6,240
6,760
7,280
5,785
6,240
6,760
7,280
5,785
6,240
6,760
7,280
5,785
6,240
6,760
7,280
5,785
6,240
6,760
7,280
SHC(W)
4,050
3,619
3,110
4,512
4,118
3,650
4,975
4,618
4,191
3,640
5,438
5,117
4,732
4,222
5,785
5,616
5,273
4,805
5,785
6,115
5,814
5,387
5,785
6,240
6,354
5,970
5,785
6,240
6,760
6,552
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
P.C.
2.61
2.68
2.75
2.61
2.68
2.75
2.61
2.68
2.75
2.80
2.61
2.68
2.75
2.80
2.61
2.68
2.75
2.80
2.61
2.68
2.75
2.80
2.61
2.68
2.75
2.80
2.61
2.68
2.75
2.80
CA
5,525
6,045
6,500
5,525
6,045
6,500
5,525
6,045
6,500
7,020
5,525
6,045
6,500
7,020
5,525
6,045
6,500
7,020
5,525
6,045
6,500
7,020
5,525
6,045
6,500
7,020
5,525
6,045
6,500
7,020
SHC(W)
3,868
3,506
2,990
4,310
3,990
3,510
4,752
4,473
4,030
3,510
5,194
4,957
4,550
4,072
5,525
5,441
5,070
4,633
5,525
5,924
5,590
5,195
5,525
6,045
6,110
5,756
5,525
6,045
6,500
6,318
P.C.
2.80
2.88
2.94
2.80
2.88
2.94
2.80
2.88
2.94
3.02
2.80
2.88
2.94
3.02
2.80
2.88
2.94
3.02
2.80
2.88
2.94
3.02
2.80
2.88
2.94
3.02
2.80
2.88
2.94
3.02
CA
5,265
5,655
6,110
5,265
5,655
6,110
5,265
5,655
6,110
6,630
5,265
5,655
6,110
6,630
5,265
5,655
6,110
6,630
5,265
5,655
6,110
6,630
5,265
5,655
6,110
6,630
5,265
5,655
6,110
6,630
SHC(W)
3,686
3,280
2,811
4,107
3,732
3,299
4,528
4,185
3,788
3,315
4,949
4,637
4,277
3,845
5,265
5,090
4,766
4,376
5,265
5,542
5,255
4,906
5,265
5,655
5,743
5,437
5,265
5,655
6,110
5,967
P.C.
3.03
3.10
3.16
3.03
3.10
3.16
3.03
3.10
3.16
3.21
3.03
3.10
3.16
3.21
3.03
3.10
3.16
3.21
3.03
3.10
3.16
3.21
3.03
3.10
3.16
3.21
3.03
3.10
3.16
3.21
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
OC175B--1.qxp 01.10.2 3:11 PM Page 20
