TECHNICAL DATA BOOK
CONTENTS
1. REFERENCE SERVICE MANUAL·············································2
2. SPECIFICATIONS ······································································3
3. OUTLINES AND DIMENSIONS················································23
4. WIRING DIAGRAM···································································42
5. REFRIGERANT SYSTEM DIAGRAM ······································54
6. PERFORMANCE CURVES······················································57
7. CORRECTION FACTORS························································59
8. APPLICABLE EXTENSION PIPE FOR EACH MODEL ··········60
9. AIR FLOW DATA······································································64
10. NOISE CRITERION CURVES ··················································78
11. OPTIONAL PARTS·····································································88
<Indoor unit>
[Model names]
R410A
PLA-RP·AA
PLA-RP·AA2
PEAD-RP·EA
PEAD-RP·EA2
PEAD-RP·GA
PKA-RP·GAL
PKA-RP·FAL
PCA-RP·GA
PCA-RP·HA
PSA-RP·GA
<Outdoor unit>
[Model names]
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
PUHZ-RP35/50/60/71/100/125/140VHA2
PUHZ-RP100/125/140YHA2
May 2006
INVERTER
kW Model
No. OCS05
REVISED EDITION-A
Revision:
• High dimension of PEAD-RP71EA are
modified in REVISED EDITION-A.
• Some descriptions have been
modified.
• Please void OCS05.
OCS05A-1.qxp 06.5.15 0:50 PM Page 1

2
For information on service, please refer to the service manual as follows.
Model name Service Ref. Service
Manual No.
PLA-RP35/50/60/71AA PLA-RP35/50/60/71AA.UK
PLA-RP35/50/60/71AA
OC335
OC327
PLA-RP100/125/140AA2 OC357
PLA-RP100/125/140AA2.UK
PCA-RP50/60/71GA PCA-RP50/60/71GA OC328
PCA-RP100/125/140GA PCA-RP100/125/140GA
PCA-RP71/125HA PCA-RP71/125HA OC329
PKA-RP35/50GAL PKA-RP35/50GAL OC330
PKA-RP60/71/100FAL PKA-RP60/71/100FAL OC331
PSA-RP71/100/125/140GA PSA-RP71/100/125/140GA OC332
PEAD-RP50/60/71/125/140EA PEAD-RP50/60/71/125/140EA.UK HWE05210
PEAD-RP35/100EA2 PEAD-RP35/100EA2.UK
PEAD-RP60/71/100GA PEAD-RP60/71/100GA.UK HWE05060
1-2. OUTDOOR UNIT
Model name Service Ref. Service
Manual No.
PUHZ-RP35/50/60/71VHA2 PUHZ-RP35/50/60/71VHA2 OC374
PUHZ-RP100/125/140VHA2 PUHZ-RP100/125/140VHA2
PUHZ-RP100/125/140YHA2 PUHZ-RP100/125/140YHA2
1-1. INDOOR UNIT
1REFERENCE SERVICE MANUAL
OCS05A-1.qxp 06.5.15 0:50 PM Page 2

3
2SPECIFICATIONS
Model name Indoor unit PLA-RP35AA PLA-RP50AA
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
Cooling Capacity Btu/h 12,300 17,100
kW 3.6(1.6-4.5)5.0(2.3-5.6)
Total input kW 1.07 1.55
EER 3.36 3.23
Energy label class A A
SHF 0.89 0.86
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2)6.0(2.5-7.3)
Total input kW 1.12 1.62
COP 3.66 3.70
Energy label class A A
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 11-12-13-14 14-15-16-18
(Low-Medium2-Medium1-High)
CFM 390-425-460-495 495-530-565-635
External pressure Pa 0 0
Sound level dB(A)27-28-29-31 28-29-31-33
(Low-Medium2-Medium1-High)
External finish (Panel)White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel)D : mm 840 (950)
H : mm 258 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/16)
Weight kg 24 (5)
Unit (Panel)lbs 53 (11)
Unit drain pipe I.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A)44
Sound level at heating dB(A)46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45
lbs 99
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
2-1. CEILING CASSETTE TYPE
OCS05A-1.qxp 06.5.15 0:50 PM Page 3

4
Model name Indoor unit PLA-RP60AA PLA-RP71AA
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7)7.1(3.3-8.1)
Total input kW 1.65 1.97
EER 3.64 3.60
Energy label class A A
SHF 0.78 0.74
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2)8.0(3.5-10.2)
Total input kW 1.85 2.34
COP 3.78 3.42
Energy label class A B
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 14-15-16-18 15-16-18-20
(Low-Medium2-Medium1-High)
CFM 495-530-565-635 530-565-635-705
External pressure Pa 0 0
Sound level dB(A)28-29-31-33 28-30-32-34
(Low-Medium2-Medium1-High)
External finish (Panel)White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel)D : mm 840 (950)
H : mm 258 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/16)
Weight kg 24 (5)
Unit (Panel)lbs 53 (11)
Unit drain pipe I.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 55
CFM 1,940
Sound level at cooling dB(A)47
Sound level at heating dB(A)48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 75
lbs 165
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
OCS05A-1.qxp 06.5.15 0:50 PM Page 4

5
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -20:, W.B. -20:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP100AA2 PLA-RP125AA2 PLA-RP140AA2
Outdoor unit PUHZ-RP100VHA2 PUHZ-RP125VHA2 PUHZ-RP140VHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4)12.5(5.5-14.0)14.0(5.5-15.3)
Total input kW 3.02 3.87 4.65
EER 3.31 3.23 3.01
Energy label class A A B
SHF 0.78 0.74 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.02 3.88 4.69
COP 3.61 3.61 3.41
Energy label class A A B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 19-21-23-27 24-25-27-30
(Low-Medium2-Medium1-High)
CFM 670-740-810-950 850-880-950-1060
External pressure Pa 0 0
Sound level dB(A)33-36-39-41 37-40-43-45
(Low-Medium2-Medium1-High)
External finish (Panel)White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel)D : mm 840 (950)
H : mm 298 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/16)
Weight kg 32 (5)
Unit (Panel)lbs 71 (11)
Unit drain pipe I.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49 50
Sound level at heating dB(A)51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 121 116
lbs 267 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 5

6
Model name Indoor unit PLA-RP100AA2 PLA-RP125AA2 PLA-RP140AA2
Outdoor unit PUHZ-RP100YHA2 PUHZ-RP125YHA2 PUHZ-RP140YHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4)12.5(5.5-14.0)14.0(5.5-15.3)
Total input kW 3.02 3.87 4.65
EER 3.31 3.23 3.01
Energy label class A A B
SHF 0.78 0.74 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.02 3.88 4.69
COP 3.61 3.61 3.41
Energy label class A A B
Booster heater kW - - -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 19-21-23-27 24-25-27-30
(Low-Medium2-Medium1-High)
CFM 670-740-810-950 850-880-950-1060
External pressure Pa 0 0
Sound level dB(A)33-36-39-41 37-40-43-45
(Low-Medium2-Medium1-High)
External finish (Panel)White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel)D : mm 840 (950)
H : mm 298 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/16)
Weight kg 32 (5)
Unit (Panel)lbs 71 (11)
Unit drain pipe I.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49 50
Sound level at heating dB(A)51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135 130
lbs 298 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -20˚C, W.B. -20˚C
4. Above data based on indicated voltage
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional Air protect guide installed. D.B.-15:
OCS05A-1.qxp 06.5.15 0:50 PM Page 6

7
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP35EA2 PEAD-RP50EA
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
Cooling Capacity Btu/h 12,300 16,700
kW 3.6(1.6-4.5)4.9(2.3-5.6)
Total input kW 1.12 1.52
EER 3.21 3.22
Energy label class A A
SHF 0.89 0.82
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2)6.0(2.5-7.3)
Total input kW 1.20 1.65
COP 3.41 3.64
Energy label class B A
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 13.5-17
(Low-High)CFM 476-600
External pressure Pa 30(70)
Sound level dB(A)36-40
(Low-High)(
70Pa : 38-44)
External finish Galvanized sheets
Dimension W : mm 935
D : mm 700
H : mm 295
W : inch 36-13/16
D : inch 27-5/8
H : inch 11-5/8
Weight kg 33 35
lbs 73 77
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A)44
Sound level at heating dB(A)46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45
lbs 99
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-2. CEILING-CONCEALED TYPE
OCS05A-1.qxp 06.5.15 0:50 PM Page 7

8
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP60EA PEAD-RP71EA
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7)7.1(3.3-8.1)
Total input kW 1.86 2.15
EER 3.23 3.30
Energy label class A A
SHF 0.79 0.83
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2)8.0(3.5-10.2)
Total input kW 1.90 2.34
COP 3.68 3.42
Energy label class A B
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 17-21 20-25
(Low-High)CFM 600-741 706-883
External pressure Pa 30(70)70(130)
Sound level dB(A)37-41 37-41
(Low-High)(
70Pa : 39-46)( 130Pa : 40-45)
External finish Galvanized sheets
Dimension W : mm 1175
D : mm 700 740
H : mm 295
W : inch 46-1/8
D : inch 27-5/8
H : inch 11-5/8
325
12-13/16
Weight kg 42 44
lbs 92 97
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 55 55
CFM 1,940 1,940
Sound level at cooling dB(A)47 47
Sound level at heating dB(A)48 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950 950
D : mm 330+30 330+30
H : mm 943 943
W : inch 37-3/8 37-3/8
D : inch 13 + 1-3/16 13 + 1-3/16
H : inch 37-1/8 37-1/8
Weight kg 75 75
lbs 165 165
Refrigerant pipe size Gas side O.D. mm 15.88 15.88
inch 5/8 5/8
Liquid side O.D. mm 9.52 9.52
inch 3/8 3/8
Refrigerant pipe length Height difference m Max.30 Max. 30
Length m Max. 50 Max. 50
OCS05A-1.qxp 06.5.15 0:50 PM Page 8

9
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -20:, W.B. -20:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP100EA2 PEAD-RP125EA PEAD-RP140EA
Outdoor unit PUHZ-RP100VHA2 PUHZ-RP125VHA2 PUHZ-RP140VHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4)12.5(5.5-14.0)14.0(5.5-15.3)
Total input kW 3.06 3.89 4.65
EER 3.27 3.21 3.01
Energy label class A A B
SHF 0.86 0.82 0.83
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.19 3.88 4.69
COP 3.51 3.61 3.41
Energy label class B A B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 33.5-42 36.5-46
(Low-High)CFM 1183-1483 1288-1624
External pressure Pa 70(130)
Sound level dB(A)44-50 46-51
(Low-High)(
130Pa : 46-52)( 130Pa : 47-53)
External finish Galvanized sheets
Dimension W : mm 1415 1715
D : mm 740
H : mm 325
W : inch 55-11/16 67-1/2
D : inch 29-1/8
H : inch 12-13/16
Weight kg 65 70
lbs 143 154
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49 50
Sound level at heating dB(A)51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 121 116
lbs 267 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 9

10
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -20˚C, W.B. -20˚C
4. Above data based on indicated voltage
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional Air protect guide installed. D.B.-15:
Model name Indoor unit PEAD-RP100EA2 PEAD-RP125EA PEAD-RP140EA
Outdoor unit PUHZ-RP100YHA2 PUHZ-RP125YHA2 PUHZ-RP140YHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4)12.5(5.5-14.0)14.0(5.5-15.3)
Total input kW 3.06 3.89 4.65
EER 3.27 3.21 3.01
Energy label class A A B
SHF 0.86 0.82 0.83
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.19 3.88 4.69
COP 3.51 3.61 3.41
Energy label class B A B
Booster heater kW - - -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 33.5-42 36.5-46
(Low-High)CFM 1183-1483 1288-1624
External pressure Pa 70(130)
Sound level dB(A)44-50 46-51
(Low-High)(
130Pa : 46-52)( 130Pa : 47-53)
External finish Galvanized sheets
Dimension W : mm 1415 1715
D : mm 740
H : mm 325
W : inch 55-11/16 67-1/2
D : inch 29-1/8
H : inch 12-13/16
Weight kg 65 70
lbs 143 154
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49 50
Sound level at heating dB(A)51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135 130
lbs 298 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 10

11
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C w2
4. Above data based on indicated voltage
w1. If optional Air protect guide installed. D.B.-15:
w2. For RP100 D.B. -20:
,
W.B. -20:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP60GA PEAD-RP71GA PEAD-RP100GA
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2 PUHZ-RP100VHA2
Cooling Capacity Btu/h 20,500 24,200 34,100
kW 6.0(2.7-6.7)7.1(3.3-8.1)10.0(4.9-11.4)
Total input kW 1.68 2.15 3.08
EER 3.57 3.30 3.25
Energy label class A A A
SHF 0.88 0.83 0.86
Heating Capacity Btu/h 23,900 27,300 38,200
kW 7.0(2.8-8.2)8.0(3.5-10.2)11.0(4.5-14.0)
Total input kW 1.77 2.34 3.23
COP 3.95 3.42 3.41
Energy label class A B B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25 32
Indoor unit Air flow CMM 16.5-21 20-25 26.5-33
(Low-High)CFM 582-741 706-883 935-1165
External pressure Pa 10/50/70 10/50/70
Sound level dB(A)33-37/35-40/36-42 35-38/37-41/37-43 40-43/42-45/42-46
(Low-High)(
10/50/70Pa)( 10/50/70Pa)( 10/50/70Pa)
External finish Galvanized sheets
Dimension W : mm 1171 1411
D : mm 740
H : mm 275
W : inch 46-1/8 55-9/16
D : inch 29-1/8
H : inch 10-13/16
Weight kg 42 50
lbs 93 111
Unit drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 55 100
CFM 1,940 3,530
Sound level at cooling dB(A)47 49
Sound level at heating dB(A)48 51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 121
lbs 165 267
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 11

12
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -20˚C, W.B. -20˚C
4. Above data based on indicated voltage
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional Air protect
g
uide installed. D.B.-15:
Model name Indoor unit PEAD-RP100GA
Outdoor unit PUHZ-RP100YHA2
Cooling Capacity Btu/h 34,100
kW 10.0(4.9-11.4)
Total input kW 3.08
EER 3.25
Energy label class A
SHF 0.86
Heating Capacity Btu/h 38,200
kW 11.0(4.5-14.0)
Total input kW 3.23
COP 3.41
Energy label class B
Booster heater kW -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 26.5-33
(Low-High)CFM 935-1165
External pressure Pa 10/50/70
Sound level dB(A)40-43/42-45/42-46
(Low-High)(
10/50/70Pa)
External finish Galvanized sheets
Dimension W : mm 1411
D : mm 740
H : mm 275
W : inch 55-9/16
D : inch 29-1/8
H : inch 10-13/16
Weight kg 50
lbs 111
Unit drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49
Sound level at heating dB(A)51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 943
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135
lbs 298
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 12

13
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect
g
uide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PKA-RP35GAL PKA-RP50GAL
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
Cooling Capacity Btu/h 12,300 15,700
kW 3.6(1.6-4.5)4.6(2.3-5.4)
Total input kW 1.03 1.63
EER 3.50 2.82
Energy label class A C
SHF 0.84 0.74
Heating Capacity Btu/h 14,000 15,400
kW 4.1(1.6-5.2)4.5(2.5-6.2)
Total input kW 1.27 1.40
COP 3.23 3.21
Energy label class C C
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 9-10-11-12
(Low-Medium2-Medium1-High)
CFM 320-355-390-425
External pressure Pa 0
Sound level dB(A)36-38-41-43
(Low-Medium2-Medium1-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 990
D : mm 235
H : mm 340
W : inch 39
D : inch 9-1/4
H : inch 13-3/8
Weight kg 16
lbs 35
Unit drain pipe O.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A)44
Sound level at heating dB(A)46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45
lbs 99
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-3. WALL MOUNTED TYPE
OCS05A-1.qxp 06.5.15 0:50 PM Page 13

14
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C w2
4. Above data based on indicated voltage
w1. If optional Air protect guide installed. D.B.-15:
w2. For RP100 D.B. -20:, W.B. -20:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PKA-RP60FAL PKA-RP71FAL PKA-RP100FAL
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2 PUHZ-RP100VHA2
Cooling Capacity Btu/h 20,500 24,200 34,100
kW 6.0(2.7-6.7)7.1(3.3-8.1)10.0(4.9-11.4)
Total input kW 1.55 1.98 2.93
EER 3.87 3.59 3.41
Energy label class A A A
SHF 0.83 0.77 0.77
Heating Capacity Btu/h 23,900 27,300 38,200
kW 7.0(2.8-8.2)7.6(3.5-10.2)11.2(4.5-14.0)
Total input kW 2.01 2.23 3.25
COP 3.48 3.41 3.45
Energy label class B B B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25 32
Indoor unit Air flow CMM 15-20 22-28
(Low-High)CFM 530-705 780-990
External pressure Pa 0
Sound level dB(A)39-45 41-46
(Low-High)
External finish Munsell 3.4Y 7.7/0.8
Dimension W : mm 1400 1680
D : mm 235
H : mm 340
W : inch 55-1/8 66-1/8
D : inch 9-1/4
H : inch 13-3/8
Weight kg 24 28
lbs 53 62
Unit drain pipe O.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 55 100
CFM 1,940 3,530
Sound level at cooling dB(A)47 49
Sound level at heating dB(A)48 51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 121
lbs 165 267
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 14

15
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -20˚C, W.B. -20˚C
4. Above data based on indicated voltage
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional Air protect guide installed. D.B.-15:
Model name Indoor unit PKA-RP100FAL
Outdoor unit PUHZ-RP100YHA2
Cooling Capacity Btu/h 34,100
kW 10.0(4.9-11.4)
Total input kW 2.93
EER 3.41
Energy label class A
SHF 0.77
Heating Capacity Btu/h 38,200
kW 11.2(4.5-14.0)
Total input kW 3.25
COP 3.45
Energy label class B
Booster heater kW -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 22-28
(Low-High)CFM 780-990
External pressure Pa 0
Sound level dB(A)41-46
(Low-High)
External finish Munsell 3.4Y 7.7/0.8
Dimension W : mm 1680
D : mm 235
H : mm 340
W : inch 66-1/8
D : inch 9-1/4
H : inch 13-3/8
Weight kg 28
lbs 62
Unit drain pipe O.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49
Sound level at heating dB(A)51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135
lbs 298
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 15

16
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP50GA PCA-RP60GA PCA-RP71GA
Outdoor unit PUHZ-RP50VHA2 PUHZ-RP60VHA2 PUHZ-RP71VHA2
Cooling Capacity Btu/h 16,000 20,500 24,200
kW 4.7(2.3-5.4)6.0(2.7-6.7)7.1(3.3-8.1)
Total input kW 1.67 1.63 2.14
EER 2.81 3.68 3.32
Energy label class C A A
SHF 0.76 0.86 0.74
Heating Capacity Btu/h 18,800 23,900 27,300
kW 5.5(2.5-6.6)7.0(2.8-8.2)7.6(3.5-10.2)
Total input kW 1.71 2.03 2.23
COP 3.22 3.45 3.41
Energy label class C B B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16 25
Indoor unit Air flow CMM 10-11-12-13 14-15-16-18
(Low-Medium2-Medium1-High)
CFM 355-390-425-460 495-530-565-635
External pressure Pa 0 0
Sound level dB(A)37-38-40-42 37-39-41-43
(Low-Medium2-Medium1-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 1000 1310
D : mm 680
H : mm 210
W : inch 39-3/8 51-9/16
D : inch 26-3/4
H : inch 8-1/4
Weight kg 27 34
lbs 60 75
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 35 55
CFM 1,240 1,940
Sound level at cooling dB(A)44 47
Sound level at heating dB(A)46 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800 950
D : mm 300+23 330+30
H : mm 600 943
W : inch 31-1/2 37-3/8
D : inch 11-13/16 + 7/8 13 + 1-3/16
H : inch 23-5/8 37-1/8
Weight kg 45 75
lbs 99 165
Refrigerant pipe size Gas side O.D. mm 12.7 15.88
inch 1/2 5/8
Liquid side O.D. mm 6.35 9.52
inch 1/4 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 50
2-4. CEILING SUSPENDED TYPE
OCS05A-1.qxp 06.5.15 0:50 PM Page 16

17
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -20:, W.B. -20:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP100GA PCA-RP125GA PCA-RP140GA
Outdoor unit PUHZ-RP100VHA2 PUHZ-RP125VHA2 PUHZ-RP140VHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4)12.5(5.5-14.0)14.0(5.5-15.3)
Total input kW 2.92 3.88 4.65
EER 3.42 3.22 3.01
Energy label class A A B
SHF 0.75 0.77 0.75
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.26 4.11 4.60
COP 3.44 3.41 3.48
Energy label class B B B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 20-21-23-25 27-30-32-34
(Low-Medium2-Medium1-High)
CFM 705-840-810-885 955-1060-1130-1200
External pressure Pa 0 0
Sound level dB(A)40-41-43-45 41-43-45-46 42-44-46-48
(Low-Medium2-Medium1-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 1310 1620
D : mm 680
H : mm 270
W : inch 51-9/16 63-3/4
D : inch 26-3/4
H : inch 10-5/8
Weight kg 37 43 45
lbs 82 95 99
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49 50
Sound level at heating dB(A)51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 121 116
lbs 267 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 17

18
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -20˚C, W.B. -20˚C
4. Above data based on indicated voltage
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional Air protect guide installed. D.B.-15:
Model name Indoor unit PCA-RP100GA PCA-RP125GA PCA-RP140GA
Outdoor unit PUHZ-RP100YHA2 PUHZ-RP125YHA2 PUHZ-RP140YHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4)12.5(5.5-14.0)14.0(5.5-15.3)
Total input kW 2.92 3.88 4.65
EER 3.42 3.22 3.01
Energy label class A A B
SHF 0.75 0.77 0.75
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.26 4.11 4.60
COP 3.44 3.41 3.48
Energy label class B B B
Booster heater kW - - -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 20-21-23-25 27-30-32-34
(Low-Medium2-Medium1-High)
CFM 705-840-810-885 955-1060-1130-1200
External pressure Pa 0 0
Sound level dB(A)40-41-43-45 41-43-45-46 42-44-46-48
(Low-Medium2-Medium1-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 1310 1620
D : mm 680
H : mm 270
W : inch 51-9/16 63-3/4
D : inch 26-3/4
H : inch 10-5/8
Weight kg 37 43 45
lbs 82 95 99
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)49 50
Sound level at heating dB(A)51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135 130
lbs 298 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05A-1.qxp 06.5.15 0:50 PM Page 18

19
Model name Indoor unit PCA-RP71HA PCA-RP125HA PCA-RP125HA
Outdoor unit PUHZ-RP71VHA2 PUHZ-RP125VHA2 PUHZ-RP125YHA2
Cooling Capacity Btu/h 24,200 42,700 42,700
kW 7.1(3.3-8.1)12.5(5.5-14.0)12.5(5.5-14.0)
Total input kW 2.21 3.88 3.88
EER 3.21 3.22 3.22
Energy label class A A A
SHF 0.74 0.77 0.77
Heating Capacity Btu/h 27,300 47,800 47,800
kW 7.6(3.5-10.2)13.8(5.0-16.0)13.8(5.0-16.0)
Total input kW 2.23 4.05 4.05
COP 3.41 3.41 3.41
Energy label class B B B
Booster heater kW - - -
Power supply Phase [13
Cycle Hz 50 50
Voltage V 230 400
Breaker size A 25 16
Indoor unit Air flow CMM 17-19 30-38
(Low-High)CFM 600-670 1060-1350
External pressure Pa 0 0
Sound level dB(A)34-38 44-50
(Low-High)
External finish Stainless steel
Dimension W : mm 1136 1520
D : mm 650
H : mm 280
W : inch 44-3/4 59-7/8
D : inch 25-5/8
H : inch 11
Weight kg 41 56
lbs 90 124
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 55 100
CFM 1,940 3,530
Sound level at cooling dB(A)47 50
Sound level at heating dB(A)48 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950 950
D : mm 330+30 330+30
H : mm 943 1350
W : inch 37-3/8 37-3/8
D : inch 13 + 1-3/16 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 116 130
lbs 165 256 287
Refrigerant pipe size Gas side O.D. mm 15.88 15.88
inch 5/8 5/8
Liquid side O.D. mm 9.52 9.52
inch 3/8 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C w2
4. Above data based on indicated voltage
w1. If optional Air protect guide installed. D.B.-15:
w2. For RP125 D.B. -20:, W.B. -20:
Indoor unit Single phase 230V 50Hz
V: Single phase 230V 50Hz
, Y: 3 phase 400V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz (RP125Y : 342~457V, 50Hz)
OCS05A-1.qxp 06.5.15 0:50 PM Page 19

20
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PSA-RP71GA
Outdoor unit PUHZ-RP71VHA2
Cooling Capacity Btu/h 24,200
kW 7.1(3.3-8.1)
Total input kW 2.20
EER 3.23
Energy label class A
SHF 0.73
Heating Capacity Btu/h 27,300
kW 7.6(3.5-10.2)
Total input kW 2.23
COP 3.41
Energy label class B
Booster heater kW -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 15-18
(Low-High)CFM 530-635
External pressure Pa 0
Sound level dB(A)40-45
(Low-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 600
D : mm 270
H : mm 1900
W : inch 23-5/8
D : inch 10-5/8
H : inch 74-13/16
Weight kg 43
lbs 98
Unit drain pipeO.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 55
CFM 1,940
Sound level at cooling dB(A)47
Sound level at heating dB(A)48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 75
lbs 165
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-5. FLOOR STANDING TYPE
OCS05A-1.qxp 06.5.15 0:50 PM Page 20
