Mitsubishi electric Pla-rp ba series User manual

Air-Conditioners

PLA-RP·BA Series

PLA-ZRP·BA Series

English

Deutsch

Français

Nederlands

Español

Italiano

Português

Dansk

Svenska

INSTALLATION MANUAL

For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing

the air-conditioner unit.

INSTALLATIONSHANDBUCH

Aus Sicherheitsgründen und zur richtigen Anwendung vor Installation der Klimaanlage die vorliegende Bedie-

nungsanleitung und das Installationshandbuch gründlich durchlesen.

MANUEL D’INSTALLATION

Avant d’installer le climatiseur, lire attentivement ce manuel, ainsi que le manuel d’installation de l’appareil exté-

rieur pour une utilisation sûre et correct.

INSTALLATIONSMANUAL

Läs bruksanvisningen och utomhusenhetens installationshandbok noga innan luftkonditioneringen installeras så

att den används på ett säkert och korrekt sätt.

INSTALLATIEHANDLEIDING

Lees deze handleiding en de installatiehandleiding van het buitenapparaat zorgvuldig door voordat u met het

installeren van de airconditioner begint.

MANUALE DI INSTALLAZIONE

Per un uso sicuro e corretto, prima di installare il condizionatore d’aria leggere attentamente il presente manuale

ed il manuale d’installazione dell’unità esterna.

MANUAL DE INSTALACIÓN

Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de

aire acondicionado.

MANUAL DE INSTALAÇÃO

Para uma utilização segura e correcta, leia atentamente este manual e o manual de instalação da unidade exte-

rior antes de instalar o aparelho de ar condicionado.

INSTALLATIONSMANUAL

Læs af sikkerhedshensyn denne manual samt manualen til installation af udendørsenheden grundigt, før du

installerer klimaanlægget.

FOR INSTALLER

FÜR INSTALLATEURE

TIL INSTALLATØREN

PARA O INSTALADOR

PARA EL INSTALADOR

PER L’INSTALLATORE

VOOR DE INSTALLATEUR

FÖR INSTALLATÖREN

POUR L’INSTALLATEUR

Ελληνικά

ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ ΕΓΚΑΤΑΣΤΑΣΗΣ

Για σωστή και ασφαλή χρήση, διαβάστε προσεκτικά αυτό το εγχειρίδιο, καθώς και το εγχειρίδιο εγκατάστασης

της εξωτερικής μονάδας, πριν από την εγκατάσταση της μονάδας κλιματιστικού.

ΓΙΑ ΑΥΤΟΝ ΠΟΥ ΚΑΝΕΙ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ

Türkçe

MONTAJ ELKİTABI

Emniyetli ve doğru kullanım için, klima cihazını monte etmeden önce bu kılavuzu ve dış ünite montaj kılavuzunu

tamamıyla okuyun.

MONTÖR İÇİN

Русский

РУКОВОДСТВО ПО УСТАНОВКЕ

Для обеспечения безопасной и надлежащей эксплуатации внимательно прочтите данное руководство и

руководство по установке наружного прибора перед установкой кондиционера.

ДЛЯ УСТАНОВИТЕЛЯ

RG79D506K08.indb 1 3/28/2016 12:00:16 PM

► Before installing the unit, make sure you read all the “Safety precau-

tions”.

► Please report to your supply authority or obtain their consent before

connecting this equipment to the power supply system.

Warning:

Describes precautions that must be observed to prevent danger of injury or

death to the user.

Caution:

Describes precautions that must be observed to prevent damage to the unit.

Contents

1. Safety precautions.....................................................................................2

2. Installation location....................................................................................3

3. Installing the indoor unit ............................................................................3

4. Installing the refrigerant piping ..................................................................5

5. Drainage piping work.................................................................................6

6. Electrical work ...........................................................................................7

7. Test run....................................................................................................13

8. System control ........................................................................................16

9. Installing the grille....................................................................................17

10. Easy maintenance function .....................................................................19

1. Safety precautions

After installation work has been completed, explain the “Safety Precautions,” use,

and maintenance of the unit to the customer according to the information in the

Operation Manual and perform the test run to ensure normal operation. Both the

Installation Manual and Operation Manual must be given to the user for keeping.

These manuals must be passed on to subsequent users.

:Indicates a part which must be grounded.

Warning:

Carefully read the labels afxed to the main unit.

Warning:

• Ask a dealer or an authorized technician to install the unit.

•

The user should never attempt to repair the unit or transfer it to another location.

• For installation work, follow the instructions in the Installation Manual and use

tools and pipe components specically made for use with refrigerant specied

in the outdoor unit installation manual.

• The unit must be installed according to the instructions in order to minimize

the risk of damage from earthquakes, typhoons, or strong winds. An incor-

rectly installed unit may fall down and cause damage or injuries.

•

The unit must be securely installed on a structure that can sustain its weight.

• If the air conditioner is installed in a small room, measures must be taken to

prevent the refrigerant concentration in the room from exceeding the safety

limit in the event of refrigerant leakage. Should the refrigerant leak and cause

the concentration limit to be exceeded, hazards due to lack of oxygen in the

room may result.

• Ventilate the room if refrigerant leaks during operation. If refrigerant comes

into contact with a ame, poisonous gases will be released.

• All electric work must be performed by a qualied technician according to lo-

cal regulations and the instructions given in this manual.

• Use only specied cables for wiring. The wiring connections must be made

securely with no tension applied on the terminal connections. Also, never

splice the cables for wiring (unless otherwise indicated in this document).

Failure to observe these instructions may result in overheating or a re.

•

The appliance shall be installed in accordance with national wiring regulations.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concern-

ing use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• The terminal block cover panel of the unit must be rmly attached.

• If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualied persons in order to avoid a hazard.

• Use only accessories authorized by Mitsubishi Electric and ask a dealer or an

authorized technician to install them.

• The user should never attempt to repair the unit or transfer it to another loca-

tion.

• After installation has been completed, check for refrigerant leaks. If refriger-

ant leaks into the room and comes into contact with the ame of a heater or

portable cooking range, poisonous gases will be released.

• When installing or relocating, or servicing the air conditioner, use only the

specied refrigerant (R410A) to charge the refrigerant lines. Do not mix it with

any other refrigerant and do not allow air to remain in the lines.

If air is mixed with the refrigerant, then it can be the cause of abnormal high pres-

sure in the refrigerant line, and may result in an explosion and other hazards.

The use of any refrigerant other than that specied for the system will cause

mechanical failure or system malfunction or unit breakdown. In the worst

case, this could lead to a serious impediment to securing product safety.

1.1. Before installation (Environment)

Caution:

• Do not use the unit in an unusual environment. If the air conditioner is in-

stalled in areas exposed to steam, volatile oil (including machine oil), or sul-

furic gas, areas exposed to high salt content such as the seaside, the perfor-

mance can be signicantly reduced and the internal parts can be damaged.

• Do not install the unit where combustible gases may leak, be produced, ow,

or accumulate. If combustible gas accumulates around the unit, re or explo-

sion may result.

• Do not keep food, plants, caged pets, artwork, or precision instruments in the

direct airow of the indoor unit or too close to the unit, as these items can be

damaged by temperature changes or dripping water.

• When the room humidity exceeds 80% or when the drainpipe is clogged, wa-

ter may drip from the indoor unit. Do not install the indoor unit where such

dripping can cause damage.

• When installing the unit in a hospital or communications ofce, be prepared

for noise and electronic interference. Inverters, home appliances, high-fre-

quency medical equipment, and radio communications equipment can cause

the air conditioner to malfunction or breakdown. The air conditioner may

also affect medical equipment, disturbing medical care, and communications

equipment, harming the screen display quality.

1.2. Before installation or relocation

Caution:

• Be extremely careful when transporting the units. Two or more persons are

needed to handle the unit, as it weighs 20 kg or more. Do not grasp the pack-

aging bands. Wear protective gloves as you can injure your hands on the ns

or other parts.

•

Be sure to safely dispose of the packaging materials. Packaging materials,

such as nails and other metal or wooden parts may cause stabs or other inju-

ries.

• Thermal insulation of the refrigerant pipe is necessary to prevent condensa-

tion. If the refrigerant pipe is not properly insulated, condensation will be

formed.

• Place thermal insulation on the pipes to prevent condensation. If the drain-

pipe is installed incorrectly, water leakage and damage to the ceiling, oor,

furniture, or other possessions may result.

• Do not clean the air conditioner unit with water. Electric shock may result.

• Tighten all are nuts to specication using a torque wrench. If tightened too

much, the are nut can break after an extended period.

• If the unit is run for long hours when the air above the ceiling is at high

temperature/high humidity (due point above 26 ºC), due condensation may be

produced in the indoor unit or the ceiling materials. When operating the units

in this condition, add insulation material (10-20 mm) to the entire surface of

the unit and ceiling materials to avoid due condensation.

1.3. Before electric work

Caution:

• Be sure to install circuit breakers. If not installed, electric shock may result.

• For the power lines, use standard cables of sufcient capacity. Otherwise, a

short circuit, overheating, or re may result.

• When installing the power lines, do not apply tension to the cables.

• Be sure to ground the unit. If the unit is not properly grounded, electric shock

may result.

• Use circuit breakers (ground fault interrupter, isolating switch (+B fuse), and

molded case circuit breaker) with the specied capacity. If the circuit breaker

capacity is larger than the specied capacity, breakdown or re may result.

1.4. Before starting the test run

Caution:

• Turn on the main power switch more than 12 hours before starting operation.

Starting operation just after turning on the power switch can severely damage

the internal parts.

• Before starting operation, check that all panels, guards and other protective

parts are correctly installed. Rotating, hot, or high voltage parts can cause

injuries.

Note:

The phrase “Wired remote controller” in this installation manual refers only to the PAR-31MAA.

If you need any information for the other remote controller, please refer to either the installation manual or initial setting manual which are

included in these boxes.

• Do not operate the air conditioner without the air lter set in place. If the air

lter is not installed, dust may accumulate and breakdown may result.

• Do not touch any switch with wet hands. Electric shock may result.

• Do not touch the refrigerant pipes with bare hands during operation.

•

After stopping operation, be sure to wait at least ve minutes before turning

off the main power switch. Otherwise, water leakage or breakdown may result.

RG79D506K08.indb 2 3/28/2016 12:00:16 PM

170

140

190

60 284 377

2. Installation location

Refer to the outdoor unit installation manual.

3. Installing the indoor unit

3.1. Check the indoor unit accessories (Fig. 3-1)

The indoor unit should be supplied with the following accessories.

Accessory name Q'ty

1Installation template 1

2Washers (with insulation)

Washers (without insulation)

Pipe cover (for refrigerant piping joint)

Small diameter

Large diameter

4Band 8

5Screw with washer (M5 × 25) for mounting grille 4

6Drain socket 1

7Insulation 1

8Flare nut 1/4F(P60) 1

3.2. Ceiling openings and suspension bolt installation

locations (Fig. 3-2)

Caution:

Install the indoor unit at least 2.5m above oor or grade level.

For appliances not accessible to the general public.

• Using the installation template (top of the package) and the gauge (supplied as

an accessory with the grille), make an opening in the ceiling so that the main unit

can be installed as shown in the diagram. (The method for using the template

and the gauge is shown.)

* Before using, check the dimensions of template and gauge, because they

change due to uctuations of temperature and humidity.

* The dimensions of ceiling opening can be regulated within the range shown

in Fig.3-2; so center the main unit against the opening of ceiling, ensuring

that the respective opposite sides on all sides of the clearance between them

becomes identical.

• Use M10 (3/8") suspension bolts.

* Suspension bolts are to be procured at the eld.

• Install securely, ensuring that there is no clearance between the ceiling panel &

grille, and between the main unit & grille.

AOuter side of main unit EGrille

BBolt pitch FCeiling

CCeiling opening GMulti function casement (option)

DOuter side of Grille HEntire periphery

*Note that the space between ceiling panel of the unit and ceiling slab, etc. must be 10 to 15 mm.

*When the optional multi-functional casement is installed, add 135 mm to the

dimensions marked on the gure.

(mm)

Models C D

PLA-RP35/50/60/71BA(2)

PLA-ZRP35/50/60BA 241 258

PLA-RP100/125/140BA(2)

PLA-RP100BA3

PLA-ZRP71/100/125/140BA

281 298

3.3. Refrigerant and drainage piping locations of

indoor unit

The gure marked with * in the drawing represent the dimensions of the main unit

excluding those of the optional multi function casement. (Fig. 3-3)

ADrain pipe

BCeiling

CGrille

DRefrigerant pipe (liquid)

ERefrigerant pipe (gas)

FWater supply inlet

GMain unit

* When the optional multi-functional casement is installed, add 135 mm to the

dimensions marked on the gure.

(mm)

Models A B

(Z)RP35, 50 80 74

(Z)RP60 87 74

(Z)RP71, 100, 125, 140 85 77

Fig. 3-3

Fig. 3-2

1 2

3 4

5 6

7 8

Fig. 3-1

150

160

860-910

20-45

(7.5)(7.5)

20-45 20-45

20-45

810

950

840

187.5

840

135

105

Min. 2500

Min. 500

860-910

950

620

605

RG79D506K08.indb 3 3/28/2016 12:00:16 PM

A=17 +5

105 (240)

605

810

1 2

D E FG

3. Installing the indoor unit

3.4. Branch duct hole and fresh air intake hole (Fig. 3-4)

At the time of installation, use the duct holes (cut out) located at the positions

shown in Fig3-4, as and when required.

• A fresh air intake hole for the optional multi function casement can also be made.

Note:

The gure marked with * in the drawing represent the dimensions of the main

unit excluding those of the optional multi function casement.

When installing the optional multi function casement, add 135 mm to the di-

mensions marked on the gure.

When installing the branch ducts, be sure to insulate adequately. Otherwise

condensation and dripping may occur.

When installing the fresh air intake hole, be sure to remove the insulator P

that is pasted on the indoor unit.

ABranch duct hole Iø175 burring hole pitch

BIndoor unit JFresh air intake hole diagram

CFresh air intake hole K3-ø2.8 burring hole

DDrain pipe Lø125 burring hole pitch

ERefrigerant pipe Mø100 cut out hole

FBranch duct hole diagram NCeiling

(view from either side) O

Detailed gure of removing the insulator

G14-ø2.8 burring hole PInsulator

Hø150 cut out hole

3.5. Suspension structure (Give site of suspension

strong structure) (Fig. 3-5)

• The ceiling work differs according to the construction of the building. Building

constructors and interior decorators should be consulted for details.

(1) Extent of ceiling removal: The ceiling must be kept completely horizontal and

the ceiling foundation (framework: wooden slats and slat holders) must be rein-

forced in order to protect the ceiling from vibration.

(2) Cut and remove the ceiling foundation.

(3) Reinforce the ends of the ceiling foundation where it has been cut and add ceil-

ing foundation for securing the ends of the ceiling board.

(4) When installing the indoor unit on a slanted ceiling, attach a pillar between the

ceiling and the grille and set so that the unit is installed horizontally.

1Wooden structures

• Use tie beams (single storied houses) or second oor beams (2 story houses) as

reinforcing members.

• Wooden beams for suspending air conditioners must be sturdy and their sides

must be at least 6 cm long if the beams are separated by not more than 90 cm

and their sides must be at least 9 cm long if the beams are separated by as much

as 180 cm. The size of the suspension bolts should be ø10 (3/8"). (The bolts do

not come with the unit.)

2Ferro-concrete structures

Secure the suspension bolts using the method shown, or use steel or wooden

hangers, etc. to install the suspension bolts.

3.6. Unit suspension procedures (Fig. 3-6)

Suspend the main unit as shown in the diagram.

Figures given in parentheses represent the dimensions in case of installing optional

multi function casement.

1. In advance, set the parts onto the suspension bolts in the order of the washers

(with insulation), washers (without insulation) and nuts (double).

• Fit the washer with cushion so that the insulation faces downward.

• In case of using upper washers to suspend the main unit, the lower washers (with

insulation) and nuts (double) are to be set later.

2. Lift the unit to the proper height of the suspension bolts to insert the mounting

plate between washers and then fasten it securely.

3. When the main unit cannot be aligned against the mounting hole on the ceiling,

it is adjustable owing to a slot provided on the mounting plate.

• Make sure that A is performed within 17-22 mm. Damage could result by failing

to adhere to this range. (Fig. 3-7)

Caution:

Use the top half of the box as a protective cover to prevent dust or debris

from getting inside the unit prior to installation of the decorative cover or

when applying ceiling materials.

3.7. Conrming the position of main unit and

tightening the suspension bolts (Fig. 3-8)

• Using the gauge attached to the grille, ensure that the bottom of the main unit is

properly aligned with the opening of the ceiling. Be sure to conrm this, otherwise

condensation may form and drip due to air leakage, etc.

• Conrm that the main unit is horizontally levelled, using a level or a vinyl tube

lled with water.

• After checking the position of the main unit, tighten the nuts of the suspension

bolts securely to fasten the main unit.

• The installation template (top of the package) can be used as a protective sheet

to prevent dust from entering the main unit when the grilles are left unattached for

a while or when the ceiling materials are to be lined after installation of the unit is

nished.

* As for the details of tting, refer to the instructions given on the Installation tem-

plate.

Fig. 3-4

Fig. 3-5

Fig. 3-6

Fig. 3-7

Fig. 3-8

350

70°

100 100 90

100

130

*155

*167

*158

120°

DCeiling

ERafter

FBeam

GRoof beam

H Use inserts rated at 100-150 kg each

(procure locally)

ISuspension bolts M10(3/8”) (procure

locally)

JSteel reinforcing rod

A Unit

BGrille

CPillar

ASuspension bolt

BCeiling

CNut

DWasher (with insulation)

EMounting plate

FWasher (without insulation)

GCheck using the Installation gauge

AMain unit

BCeiling

CGauge

DCeiling opening dimensions

AMain unit

BCeiling

CInstallation template

(Top of the package)

DScrew with washer (accessory)

Min. 30

RG79D506K08.indb 4 3/28/2016 12:00:17 PM

4. Installing the refrigerant piping

4.1. Precautions

For devices that use R410A refrigerant

• Use ester oil, ether oil or alkylbenzene oil (small amount) as the refrigera-

tion oil applied to the ared sections.

• Use C1220 copper phosphorus for copper and copper alloy seamless

pipes, to connect the refrigerant pipes. Use refrigerant pipes with the thick-

nesses specied in the table below. Make sure the insides of the pipes are

clean and do not contain any harmful contaminants such as sulfuric com-

pounds, oxidants, debris, or dust.

Warning:

When installing or relocating, or servicing the air conditioner, use only the

specied refrigerant (R410A) to charge the refrigerant lines. Do not mix it

with any other refrigerant and do not allow air to remain in the lines.

If air is mixed with the refrigerant, then it can be the cause of abnormal high

pressure in the refrigerant line, and may result in an explosion and other haz-

ards.

The use of any refrigerant other than that specied for the system will cause

mechanical failure or system malfunction or unit breakdown. In the worst

case, this could lead to a serious impediment to securing product safety.

(Z)RP35, 50 (Z)RP60-140

Liquid pipe [ 6.35 thickness 0.8 mm [ 9.52 thickness 0.8 mm

Gas pipe [ 12.7 thickness 0.8 mm [ 15.88 thickness 1.0 mm

• Do not use pipes thinner than those specied above.

4.2. Connecting pipes (Fig. 4-1)

• When commercially available copper pipes are used, wrap liquid and gas pipes

with commercially available insulation materials (heat-resistant to 100 °C or

more, thickness of 12 mm or more).

• The indoor parts of the drain pipe should be wrapped with polyethylene foam in-

sulation materials (specic gravity of 0.03, thickness of 9 mm or more).

• Apply thin layer of refrigerant oil to pipe and joint seating surface before tighten-

ing are nut.

• Use 2 wrenches to tighten piping connections.

• Use refrigerant piping insulation provided to insulate indoor unit connections. In-

sulate carefully.

BFlare nut tightening torque

Copper pipe O.D.

(mm)

Flare nut O.D.

(mm)

Tightening torque

(N·m)

[6.35 17 14-18

[6.35 22 34-42

[9.52 22 34-42

[12.7 26 49-61

[12.7 29 68-82

[15.88 29 68-82

[15.88 36 100-120

[19.05 36 100-120

C Apply refrigerating machine oil over the entire are seat surface.

D Use correct are nuts meeting the pipe size of the outdoor unit.

Available pipe size

(Z)RP35, 50 (Z)RP60 (Z)RP71-140

Liquid side [6.35 Ο [6.35 —

—[9.52 Ο [9.52 Ο

Gas side [12.7 Ο [15.88 Ο [15.88 Ο

Ο : Factory are nut attachment to the heat exchanger.

Warning:

When installing the unit, securely connect the refrigerant pipes before start-

ing the compressor.

AFlare cutting dimensions

Copper pipe O.D.

(mm)

Flare dimensions

[A dimensions (mm)

[6.35 8.7 - 9.1

[9.52 12.8 - 13.2

[12.7 16.2 - 16.6

[15.88 19.3 - 19.7

[19.05 23.6 - 24.0

Fig. 4-2

Fig. 4-1

A B

Copper pipe O.D.

(mm)

B (mm)

Flare tool for R410A

Clutch type

[6.35 (1/4”) 0 - 0.5

[9.52 (3/8”) 0 - 0.5

[12.7 (1/2”) 0 - 0.5

[15.88 (5/8”) 0 - 0.5

[19.05 (3/4”) 0 - 0.5

R0.4 - R0.8

45°± 2°

90°± 0.5°

EDie

FCopper pipe

RG79D506K08.indb 5 3/28/2016 12:00:17 PM

25 25 25

F F

E E

K F GC

4.3. Indoor unit (Fig. 4-3)

Heat insulation for refrigerant pipes:

1 Wrap the enclosed large-sized pipe cover around the gas pipe, making sure

that the end of the pipe cover touches the side of the unit.

2 Wrap the enclosed small-sized pipe cover around the liquid pipe, making sure

that the end of the pipe cover touches the side of the unit.

3 Secure both ends of each pipe cover with the enclosed bands. (Attach the

bands 20 mm from the ends of the pipe cover.)

• After connecting the refrigerant piping to the indoor unit, be sure to test the pipe

connections for gas leakage with nitrogen gas. (Check that there is no refrigerant

leakage from the refrigerant piping to the indoor unit.)

4.4. For twin/triple combination

Refer to the outdoor unit installation manual.

4. Installing the refrigerant piping

5. Drainage piping work

5.1. Drainage piping work (Fig. 5-1)

• Use VP25 (O.D. ø32 PVC TUBE) for drain piping and provide 1/100 or more

downward slope.

• Be sure to connect the piping joints using a polyvinyl type adhesive.

• Observe the gure for piping work.

• Use the included drain hose to change the extraction direction.

1Correct piping CSupport metal

2Wrong piping KAir bleeder

AInsulation (9 mm or more) LRaised

BDownward slope (1/100 or more) MOdor trap

Grouped piping

D O.D. ø32 PVC TUBE HDownward slope (1/100 or more)

EMake it as large as possible I O.D. ø38 PVC TUBE for grouped piping.

(9 mm or more insulation)

FIndoor unit

GMake the piping size large for grouped

piping.

J Up to 85 cm

1.Connect the drain socket (supplied with the unit) to the drain port. (Fig. 5-2)

(Fix the tube using PVC adhesive then secure it with a band.)

2.Install a locally purchased drain pipe (PVC pipe, O.D. ø32).

(Fix the pipe using PVC adhesive then secure it with a band.)

3.Insulate the tube and pipe. (PVC pipe, O.D. ø32 and socket)

4.Check that drain ows smoothly.

5.Insulate the drain port with insulating material, then secure the material with a

band. (Both insulating material and band are supplied with the unit.)

A Unit G Drain pipe (O.D. ø32 PVC TUBE)

BInsulating material HInsulating material (purchased locally)

CBand I Transparent PVC pipe

DDrain port (transparent) J O.D. ø32 PVC TUBE(Slope 1/100 or more)

EInsertion margin KDrain socket

FMatching

B,C

ARefrigerant pipe and

insulating material

BPipe cover (large)

CPipe cover (small)

DRefrigerant pipe (gas)

ERefrigerant pipe (liquid)

FBand

GCross-sectional view of

connection

HPipe

IInsulating material

JSqueeze

Fig. 4-3

Fig. 5-1

Fig. 5-2

Max. 20 m

Max. 15 cm

1.5 - 2 m

(mm)

RG79D506K08.indb 6 3/28/2016 12:00:17 PM

6. Electrical work

6.1. Indoor unit (Fig. 6-1)

1. Remove the electrical wiring service panel.

2. Remove the electrical box cover.

3. Wire the power cable and control cable separately through the respective wiring

entries given in the diagram.

• Do not allow slackening of the terminal screws.

• Leave excess cable so that the electrical box cover can be suspended below the

unit during servicing. (Approx. 50 to 100 mm)

AEntry for control cable

BEntry for power

CClamp

DElectrical box cover

EService panel for electrical wiring

FTemporary hook for electrical box cover

GIndoor / Outdoor unit connecting terminals

HRemote controller connector

ISecure with the clamp

JEarth terminal

6.1.1. Indoor unit power supplied from outdoor unit

The following connection patterns are available.

The outdoor unit power supply patterns vary on models.1 System

A B C

G G G G

HHH

* Afx label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.

A Outdoor unit power supply

B Earth leakage breaker

C Wiring circuit breaker or isolating switch

D Outdoor unit

E Indoor unit/outdoor unit connecting cables

F Remote controller

G Indoor unit

* Afx label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.

*1. <For 35-140 outdoor unit application>

Max. 45 m

If 2.5 mm2used, Max. 50 m

If 2.5 mm2used and S3 separated, Max. 80 m

Max. 18 m

If 2.5 mm2used, Max. 30 m

If 4 mm2used and S3 separated, Max. 50 m

If 6 mm2used and S3 separated, Max. 80 m

*2. The 10 m wire is attached in the remote controller accessory. Max. 500 m

*3. The gures are NOT always against the ground.

S3 terminal has 24 V DC against S2 terminal. However between S3 and S1, these terminals are not electrically insulated by the transformer or other device.

Notes: 1. Wiring size must comply with the applicable local and national code.

Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed exible cord. (Design 60245 IEC 57)

3. Install an earth longer than other cables.

A Outdoor unit power supply

B Earth leakage breaker

C Wiring circuit breaker or isolating switch

D Outdoor unit

E Indoor unit/outdoor unit connecting cables

F Remote controller

G Indoor unit

H Indoor unit earth

Simultaneous twin/triple/quadruple system

1:1 System

Wiring

Wire No. × size

(e)

Circuit

rating

Indoor unit model PLA

Indoor unit-Outdoor unit *1 3 × 1.5 (polar)

Indoor unit-Outdoor unit earth *1 1 × Min. 1.5

Indoor unit earth 1 × Min. 1.5

Remote controller-Indoor unit *2 2 × 0.3 (Non-polar)

Indoor unit (Heater) L-N *3 —

Indoor unit-Outdoor unit S1-S2 *3 230 V AC

Indoor unit-Outdoor unit S2-S3 *3 24 V DC

Remote controller-Indoor unit *3 12 V DC

Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a re or communication failure.

Warning:

Fig. 6-1

RG79D506K08.indb 7 3/28/2016 12:00:17 PM

BLUE

YELLOW

CN01

BLACK

CN01

BLACK

YELLOW

BLUE

YELLOW

CN01

6. Electrical work

6.1.2. Separate indoor unit/outdoor unit power supplies (For PUHZ application only)

The following connection patterns are available.

The outdoor unit power supply patterns vary on models.1:1 System

* The indoor power supply terminal kit is required.

A B C

J B C

G G G G

HHH

* Afx label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.

A Outdoor unit power supply

B Earth leakage breaker

C Wiring circuit breaker or isolating switch

D Outdoor unit

E Indoor unit/outdoor unit connecting cables

F Remote controller

G Indoor unit

H Option

J Indoor unit power supply

* The indoor power supply terminal kits are required.

If the indoor and outdoor units have separate power supplies, refer to the table

below. If the indoor power supply terminal kit is used, change the indoor unit elec-

trical box wiring refering to the gure in the right and the DIP switch settings of the

outdoor unit control board.

* Afx label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.

A Outdoor unit power supply

B Earth leakage breaker

C Wiring circuit breaker or isolating switch

D Outdoor unit

E Indoor unit/outdoor unit connecting cables

F Remote controller

G Indoor unit

H Option

J Indoor unit power supply

K Indoor unit earth

OFF 1 2 (SW8)

Indoor power supply terminal kit (option)

Indoor unit electrical box connector

connection change

Label afxed near each wiring diagram

for the indoor and outdoor units

Outdoor unit DIP switch settings (when

using separate indoor unit/outdoor unit

power supplies only)

Indoor unit specications

Required

*1. A breaker with at least 3.0 mm contact separation in each pole shall be provided. Use earth leakage breaker (NV).

The breaker shall be provided to ensure disconnection of all active phase conductors of the supply.

*2. Max. 120 m

*3. The 10 m wire is attached in the remote controller accessory. Max. 500 m

*4. The gures are NOT always against the ground.

Notes: 1. Wiring size must comply with the applicable local and national code.

Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed exible cord.

(Design 60245 IEC 57)

3. Install an earth longer than other cables.

Option Connectors (connections of initial setting

are for indoor unit power supplied from

outdoor unit)

Indoor unit power supplied from outdoor unit

(initial setting)

If the indoor and

outdoor units have

separate power

supplies, change the

connections of the

connectors as shown

in the following

gure.

Connectors

Indoor unit

control board

Separate indoor unit/outdoor unit power sup-

plies

Option

Indoor unit

control board

* There are 3 types of labels (labels A, B and C). Afx the appropriate labels to the

units according to the wiring method.

Simultaneous twin/triple/quadruple system

1:1 System

Set the SW8-3 to ON.

Indoor unit model PLA

Indoor unit power supply ~/N (single), 50 Hz, 230 V

Indoor unit input capacity

Main switch (Breaker) *1 16 A

Wiring

Wire No. ×

size (mm2)

Indoor unit power supply & earth 3 × Min. 1.5

Indoor unit-Outdoor unit *2 2 × Min. 0.3

Indoor unit-Outdoor unit earth –

Remote controller-Indoor unit *3 2 × 0.3 (Non-polar)

Circuit

rating

Indoor unit L-N *4 230 V AC

Indoor unit-Outdoor unit S1-S2 *4 –

Indoor unit-Outdoor unit S2-S3 *4 24 V DC

Remote controller-Indoor unit *4 12 V DC

Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a re or communication failure.

Warning:

ACB

RG79D506K08.indb 8 3/28/2016 12:00:17 PM

6. Electrical work

6.2. Remote controller

6.2.1. For wired remote controller

1) 2 remote controllers setting

If 2 remote controllers are connected, set one to “Main” and the other to “Sub”. For

setting procedures, refer to “Function selection of remote controller” in the opera-

tion manual for the indoor unit.

6.2.2. For wireless remote controller

1) Setting (Fig. 6-2)

1Insert batteries.

2Press the SET button with something sharp at the end.

MODEL SELECT

blinks and Model No. is lighted.

3Press the temp buttons to set the Model No.

If you mistook the operation, press the ON/OFF button and operate again

from procedure 2.

4Press the SET button with something sharp at the end.

MODEL SELECT

and Model No. are lighted for 3 seconds, then turned off.

Indoor Outdoor AModel No.

PLA PUH, PUHZ, SUZ 001

PU 033

2) Automatic fan speed setting (Fig. 6-3)

It is necessary to set for wireless remote controller only when automatic fan

speed is not set at initial setting.

It is not necessary to set for wired remote controller with automatic fan speed at

initial setting.

1. Press the SET button with something sharp at the end.

Operate when display of remote controller is off.

MODEL SELECT

blinks and Model No. is lighted A.

2. Press the AUTO STOP button.

blinks and setting No. is lighted B.

(Setting No.01: without automatic fan speed )

3. Press the temp. buttons to set the setting No.02.

(Setting No.02:with automatic fan speed )

If you mistook the operation, press the ON/OFF button and operate again

from procedure 2.

4. Press the SET button with something sharp at the end.

MODEL SELECT

and Model No. are lighted for 3 seconds, then turned off.

3) Assigning a remote controller to each unit (Fig. 6-4)

Each unit can be operated only by the assigned remote controller.

Make sure each pair of an indoor unit PC board and a remote controller is assigned

to the same pair No.

4) Wireless remote controller pair number setting operation

1Press the SET button with something sharp at the end.

Start this operation from the status of remote controller display turned off.

MODEL SELECT

blinks and Model No. is lighted.

2Press the

min

button twice continuously. Pair No. “0” blinks.

3Press the temp buttons to set the pair number you want to set.

If you mistook the operation, press the ON/OFF button and operate again

from procedure 2.

4Press the SET button with something sharp at the end.

Set pair number is lighted for 3 seconds then turned off.

APair No. of wireless remote controller Indoor PC board

0 Initial setting

1 Cut J41

2 Cut J42

3-9 Cut J41, J42

ON/OFF TEMP

RESETSET CLOCK

MODEL SELECT

FAN

VANE

TEST RUN

AUTO STOP

AUTO START

min

LOUVER

MODE

CHECK

ON/OFF TEMP

RESETSET CLOCK

MODEL SELECT

FAN

VANE

TEST RUN

AUTO STOP

AUTO START

min

LOUVER

MODE

CHECK

ON/OFF TEMP

FAN

VANE

TEST RUN

AUTO STOP

AUTO START

min

LOUVER

MODE

CHECK

RESETSET CLOCK

MODEL SELECT

Fig. 6-2

Fig. 6-3

Fig. 6-4

RG79D506K08.indb 9 3/28/2016 12:00:18 PM

6.3. Function settings

6.3.1. Function setting on the unit (Selecting the unit functions)

1) For wired remote controller

1(Fig. 6-5)

• Select “Service” from the Main menu, and press the [SELECT] button.

• Select “Function settings” with the [F1] or [F2] button, and press the [SELECT]

button.

2(Fig. 6-6)

• Set the indoor unit refrigerant addresses and unit numbers with the [F1]

through [F4] buttons, and then press the [SELECT] button to conrm the cur-

rent setting.

When the [SELECT] button is pressed, the target indoor unit will start fan opera-

tion. If the unit is common or when running all units, all indoor units for the se-

lected refrigerant address will start fan operation.

3(Fig. 6-7)

• When data collection from the indoor units is completed, the current settings

appears highlighted. Non-highlighted items indicate that no function settings

are made. Screen appearance varies depending on the “Unit No.” setting.

4 (Fig. 6-8)

• Use the [F1] or [F2] button to move the cursor to select the mode number, and

change the setting number with the [F3] or [F4] button.

5 (Fig. 6-9)

• When the settings are completed, press the [SELECT] button to send the set-

ting data from the remote controller to the indoor units.

• When the transmission is successfully completed, the screen will return to the

Function setting screen.

6. Electrical work

F1 F2 F3 F4

Service menu

Cursor

Main menu:

Test run

Input maintenance info.

Function setting

Check

Self check

F1 F2 F3 F4

Function setting

Cursor Address

Monitor:

Ref. address

Unit No. Grp./1/2/3/4/All

Fig. 6-5 Fig. 6-6

F1 F2 F3 F4

Function setting

Cursor Cursor

Request:

Ref. address

Mode 1

Mode 2

Mode 3

Mode 4

Grp.

F1 F2 F3 F4

Function setting

Cursor Cursor

Request:

Ref. address

Mode 7

Mode 8

Mode 9

Mode10

Unit # 1

Fig. 6-7 Fig. 6-8

F1 F2 F3 F4

Function setting

Ref. address

Sending data

Grp.

Fig. 6-9

RG79D506K08.indb 10 3/28/2016 12:00:18 PM

6. Electrical work

CHECK

ON/OFF TEMP

FAN

VANE

TEST RUN

AUTO STOP

AUTO START

min

LOUVER

MODE

CHECK

RESETSET CLOCK

CHECK

CHECKCHECK

1 2

3 4

2) For wireless remote controller (Fig. 6-10)

Changing the power voltage setting

• Be sure to change the power voltage setting depending on the voltage used.

1Going to the function select mode

Press the

CHECK

button Ftwice continuously.

(Start this operation from the status of remote controller display turned off.)

CHECK

is lighted and “00” blinks.

Press the temp button Conce to set “50”. Direct the wireless remote control-

ler toward the receiver of the indoor unit and press the

button A.

2Setting the unit number

Press the temp buttons Cand Dto set the unit number “00”. Direct the

wireless remote controller toward the receiver of the indoor unit and press the

min

button B.

3Selecting a mode

Enter 04 to change the power voltage setting using the temp buttons C

and D. Direct the wireless remote controller toward the receiver of the indoor

unit and press the

button A.

Current setting number: 1 = 1 beep (1 second)

2 = 2 beeps (1 second each)

3 = 3 beeps (1 second each)

4Selecting the setting number

Use the temp buttons Cand Dto change the power voltage setting to 01

(240 V). Direct the wireless remote controller toward the sensor of the indoor

unit and press the

button A.

5To select multiple functions continuously

Repeat steps 3and 4to change multiple function settings continuously.

6Complete function selection

Direct the wireless remote controller toward the sensor of the indoor unit and

press the button E.

Note: Whenever changes are made to the function settings after installation

or maintenance, be sure to record the changes with a mark in the “Setting”

column of the Function table.

6.3.2. Function setting on the remote controller

Refer to the indoor unit operation manual.

Fig. 6-10

Function table

Select unit number 00

Mode Settings Mode no. Setting no.

Initial setting

setting

Power failure automatic recovery Not available 01 1

Available *1 2Ο *2

Indoor temperature detecting Indoor unit operating average

1Ο

Set by indoor unit’s remote controller 2

Remote controller’s internal sensor 3

LOSSNAY connectivity Not Supported

1Ο

Supported (indoor unit is not equipped with outdoor-air intake)

Supported (indoor unit is equipped with outdoor-air intake) 3

Power voltage 240 V 04 1

220 V, 230 V 2Ο

Select unit numbers 01 to 03 or all units (AL [wired remote controller]/07 [wireless remote controller])

Mode Settings Mode no. Setting no.

Initial setting

setting

Filter sign 100Hr

2500Hr 2Ο

No lter sign indicator 3

Fan speed Silent

Standard 2 Ο

High ceiling 3

No. of air outlets 4 directions

1Ο

3 directions 2

2 directions 3

Installed options (high-performance lter) Not supported 10 1Ο

Supported 2

Up/down vane setting Equipped with vanes (vanes angle setup 3)

Equipped with vanes (vanes angle setup 1) 2

Equipped with vanes (vanes angle setup 2)3Ο

*1 When the power supply returns, the air conditioner will start 3 minutes later.

*2 Power failure automatic recovery initial setting depends on the connecting outdoor unit.

RG79D506K08.indb 11 3/28/2016 12:00:18 PM

6. Electrical work

6.3.3 How to set the xed up/down air direction

(Only for wired remote controller and PUHZ, PU(H) application)

• Only the particular outlet can be fixed to certain direction with the

procedures below. Once xed, only the set outlet is xed every time air

conditioner is turned on. (Other outlets follow UP/DOWN air direction

setting of the remote controller.)

■Explanation of word

• "Refrigerant address No." and "Unit No." are the numbers given to

each air conditioner.

• "Outlet No." is the number given to each outlet of air conditioner.

(Refer to the right.)

• "Up/Down air direction" is the direction (angle) to x.

Reset 1

horizontal

2345

Note: “0” indicates all outlets.

Horizontal airow

Downward

Outlet No.3 Outlet No.4

Outlet No.2 Outlet No.1

MITSUBISHI

ELECTRIC

label

Remote controller setting

The airow direction of this outlet

is controlled by the airow direc-

tion setting of remote controller.

Fixed setting

The airow direction of this outlet is xed

in particular direction.

* When it is cold because of direct

airow, the airow direction can be xed

horizontally to avoid direct airow.

F1 F2 F3 F4

Manual vane angle

Select:

Setting

Outlet Angle

If all outlets are selected, will be displayed the

next time the unit goes into operation.

Navigating through the screens

• To go back to the Main menu..........[MENU] button

• To return to the previous screen .....[RETURN] button

MITSUBISHI

ELECTRIC LABEL

The current vane setting will appear.

Select the desired outlets from 1 through 4 with the [F1] or [F2] button.

• Outlet: "1", "2", "3", "4", and "1, 2, 3, 4, (all outlets)"

Press the [F3] or [F4] button to go through the option in the order of "No setting (re-

set)", "Step 1", "Step 2", "Step 3", "Step 4", and "Step 5".

Select the desired setting.

■ Vane setting

Press the [SELECT] button to save the settings.

A screen will appear that indicates the setting information is being transmitted.

The setting changes will be made to the selected outlet.

The screen will automatically return to the one shown above (step 4) when the

transmission is completed.

Make the settings for other outlets, following the same procedures.

No setting

Step 3

All outlets

Step 1

Step 4

Step 2

Step 5

RG79D506K08.indb 12 3/28/2016 12:00:19 PM

F1 F2 F3 F4

Manual vane angle

Input display:

Cur. Address Check

Ref. address

Unit No.

Identify unit Check button

F1 F2 F3 F4

Manual vane angle

Input display:

Ref. address

Unit No.

The air conditioner with the

vane pointing downward is

the target air conditioner.

F1 F2 F3 F4

Manual vane angle

Input display:

There is no response from

the target device.

Confirm the state of the air

conditioner.

Conrmation procedure

1 First, conrm by setting “Ref. address” to 0 and “Unit No.” to 1.

• Move the cursor to “Ref. address” or “Unit No.” with the [F1] button to select.

• Select the refrigerant address and the unit number for the units to whose

vanes are to be xed, with the [F2] or [F3] button, and press the [SELECT]

button.

• Ref. address: Refrigerant address

• Unit No.: 1, 2, 3, 4

Press the [F4] button to conrm the unit.

2 Change the “Unit No.” in order and check each unit.

• Press the [F1] button to select “Unit No.”.

Press the [F2] or [F3] button to change the “Unit No.” to the unit that you want

to check, and then press the [F4] button.

• After pressing the [F4] button, wait approximately 15 seconds, and then check

the current state of the air conditioner.

→ The vane is pointing downward. → This air conditioner is displayed on the

remote controller.

→ All outlets are closed. → Press the [RETURN] button and continue the op-

eration from the beginning.

→ The messages shown to the left are displayed. → The target device does

not exist at this refrigerant address.

• Press the [RETURN] button to return to the initial screen.

3Change the “Ref. address” to the next number.

• Refer to step 1 to change the “Ref. address” and continue with the conrma-

tion.

6. Electrical work

7. Test run

7.1. Before test run

► After completing installation and the wiring and piping of the indoor and

outdoor units, check for refrigerant leakage, looseness in the power sup-

ply or control wiring, wrong polarity, and no disconnection of one phase

in the supply.

► Use a 500-volt megohmmeter to check that the resistance between the

power supply terminals and ground is at least 1.0 MΩ.

► Do not carry out this test on the control wiring (low voltage circuit) termi-

nals.

Warning:

Do not use the air conditioner if the insulation resistance is less than 1.0 MΩ.

7.2. Test run

7.2.1. Using wired remote controller.

■ Make sure to read operation manual before test run. (Especially items to secure safety)

Step 1 Turn on the power.

● Remote controller: The system will go into startup mode, and the remote controller power lamp (green) and “PLEASE WAIT” will blink. While the lamp and message

are blinking, the remote controller cannot be operated. Wait until “PLEASE WAIT” is not displayed before operating the remote controller. After the power is turned on,

“PLEASE WAIT” will be displayed for approximately 2 minutes.

● Indoor controller board: LED 1 will be lit up, LED 2 will be lit up (if the address is 0) or off (if the address is not 0), and LED 3 will blink.

● Outdoor controller board: LED 1 (green) and LED 2 (red) will be lit up. (After the startup mode of the system nishes, LED 2 will be turned off.) If the outdoor controller

board uses a digital display, [- ] and [ -] will be displayed alternately every second.

If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they

are found.

(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)

Symptoms in test run mode

Cause

Remote Controller Display OUTDOOR BOARD LED Display

< > indicates digital display.

Remote controller displays “PLEASE WAIT”,

and cannot be operated. After “startup” is displayed, only green lights up.

<00> • After power is turned on, “PLEASE WAIT” is displayed for 2

minutes during system startup. (Normal)

After power is turned on, “PLEASE WAIT” is

displayed for 3 minutes, then error code is dis-

played.

After “startup” is displayed, green(once) and

red(once) blink alternately. <F1> • Incorrect connection of outdoor terminal block (R, S, T and S1,

S2, S3.)

After “startup” is displayed, green(once) and

red(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.

No display appears even when remote control-

ler operation switch is turned on. (Operation

lamp does not light up.)

After “startup” is displayed, green(twice) and

red(once) blink alternately. <EA. Eb>

• Incorrect wiring between the indoor and outdoor unit (Polarity

is wrong for S1, S2, S3.)

• Remote controller transmission wire short.

After “startup” is displayed, only green lights up.

<00> • There is no outdoor unit of address 0. (Address is other than 0.)

• Remote controller transmission wire open.

Display appears but soon disappears even

when remote controller is operated. After “startup” is displayed, only green lights up.

<00> • After canceling function selection, operation is not possible for

about 30 seconds. (Normal)

RG79D506K08.indb 13 3/28/2016 12:00:19 PM

7. Test run

Step 2 Switch the remote controller to “Test run”.

1Select “Test run” from the Service menu, and press the [SELECT] button. (Fig. 7-1)

2Select “Test run” from the Test run menu, and press the [SELECT] button. (Fig. 7-2)

3The test run operation starts, and the Test run operation screen is displayed.

F1 F2 F3 F4

Cool

Pipe

Auto

Switch disp.

Mode Fan

RemainTest run

Fig. 7-3

F1 F2 F3 F4

unemecivreS

rosruC

:unemniaM

Test run

Input maintenance info.

Function setting

Check

Self check

Fig. 7-1

F1 F2 F3 F4

Test run menu

Cursor

Service menu:

Test run

Drain pump test run

Fig. 7-2

F1 F2 F3 F4

Remain

Vane

Fig. 7-4

Step 3 Perform the test run and check the airow temperature and auto vane.

1Press the [F1] button to change the operation mode. (Fig. 7-3)

Cooling mode: Check that cool air blows from the unit.

Heating mode: Check that warm air blows from the unit.

2 Press the [SELECT] button to display the Vane operation screen, and then press

the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)

Press the [RETURN] button to return to the Test run operation screen.

Step 4 Conrm the operation of the outdoor unit fan.

The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will keep

rotating at that speed unless the performance is insufcient. Therefore, the outdoor wind may cause the fan to stop rotating or to rotate in the opposite direction, but this is

not a problem.

Step 5 Stop the test run.

1Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)

Note: If an error is displayed on the remote controller, see the table below.

LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction

P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)

E0 ~ E5 Communication error between the

remote controller and the indoor unit

P2 Pipe sensor error (liquid pipe) PA Leakage error (refrigerant system)

P4 Drain oat switch connector disconnected

(CN4F) PL Refrigerant circuit abnormal

P5 Drain overow protection operation FB Indoor controller board error

E6 ~ EF Communication error between the

indoor unit and the outdoor unit

P6 Freezing/overheating protection

operation

U*, F*

(* indicates an

alphanumeric

character

excluding FB.)

Outdoor unit malfunction

Refer to the wiring diagram for the

outdoor unit.

P8 Pipe temperature error

See the table below for the details of the LED display (LED 1, 2, and 3) on the indoor controller board.

LED1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.

LED2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is con-

nected to the outdoor unit that has an address of 0.

LED3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.

7.2.2. Using SW4 in outdoor unit

Refer to the outdoor unit installation manual.

7.3. Self-check

■ Refer to the installation manual that comes with each remote controller for details.

RG79D506K08.indb 14 3/28/2016 12:00:19 PM

7. Test run

OPERATION

INDICATOR

lamp blinking

pattern

Beep Beep Beep Beep Beep Beep Beep

Off

Approx. 2.5 sec.

Approx. 3 sec.

0.5 sec.

Off

Approx. 2.5 sec.

Approx. 3 sec.

0.5 sec.

· · · Repeated

Number of blinks/beeps in pattern indicates the check

code in the following table (i.e., n=5 for “U2”)

Number of blinks/beeps in pattern indicates

the check code in the following table

nth

1st 2nd 3rd 1st 2nd

Self-check

starts

(Start signal

received)

Beeper sounds

[Output pattern B]

OPERATION

INDICATOR

lamp blinking

pattern

Beep Beep Beep Beep Beep Beep Beep

Off

Approx. 2.5 sec.

0.5 sec.

0.5 sec. On

0.5 sec.

Off

Approx. 2.5 sec.

0.5 sec.

· · · Repeated

Number of blinks/beeps in pattern indicates the check

code in the following table (i.e., n=5 for “P5”)

Number of blinks/beeps in pattern indicates

the check code in the following table

nth

1st 2nd 3rd 1st 2nd

Self-check

starts

(Start signal

received)

Beeper sounds

• Refer to the following tables for details on the check codes. (Wireless remote controller)

[Output pattern A]

[Output pattern A] Errors detected by indoor unit

Wireless remote controller Wired remote

controller

Symptom Remark

Beeper sounds/OPERATION

INDICATOR lamp blinks

(Number of times)

Check code

1 P1 Intake sensor error

2P2 Pipe (TH2) sensor error

P9 Pipe (TH5) sensor error

3 E6, E7 Indoor/outdoor unit communication error

4 P4 Drain sensor error / Float switch connector open

5P5 Drain pump error

PA Forced compressor error

6 P6 Freezing/Overheating protection operation

7 EE Communication error between indoor and outdoor units

8 P8 Pipe temperature error

9 E4 Remote controller signal receiving error

10 — —

11 — —

12 Fb Indoor unit control system error (memory error, etc.)

14 PL Refrigerant circuit abnormal

No sound E0, E3 Remote controller transmission error

No sound E1, E2 Remote controller control board error

No sound – – – – No corresponding

[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)

Wireless remote controller Wired remote

controller

Symptom Remark

Beeper sounds/OPERATION

INDICATOR lamp blinks

(Number of times)

Check code

1 E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)

For details, check the LED

display of the outdoor controller

board.

2UP Compressor overcurrent interruption

3U3, U4 Open/short of outdoor unit thermistors

4UF Compressor overcurrent interruption (When compressor locked)

5U2 Abnormal high discharging temperature/49C worked/insufcient refrigerant

6U1, Ud Abnormal high pressure (63H worked)/Overheating protection operation

7U5 Abnormal temperature of heat sink

8U8 Outdoor unit fan protection stop

9U6 Compressor overcurrent interruption/Abnormal of power module

10 U7 Abnormality of super heat due to low discharge temperature

11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal

synchronous signal to main circuit/Current sensor error

12 — —

13 — —

14 Others Other errors (Refer to the technical manual for the outdoor unit.)

*1 If the beeper does not sound again after the initial 2 beeps to conrm the self-check start signal was received and the OPERATION INDICATOR lamp does not come on,

there are no error records.

*2 If the beeper sounds 3 times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” after the initial 2 beeps to conrm the self-check start signal was received, the specied

refrigerant address is incorrect.

• On wireless remote controller

The continuous buzzer sounds from receiving section of indoor unit.

Blink of operation lamp

• On wired remote controller

Check code displayed in the LCD.

RG79D506K08.indb 15 3/28/2016 12:00:19 PM

7. Test run

7.4. Check of drainage (Fig. 7-5)

• Ensure that the water is being properly drained out and that no water is leaking

from joints.

When electric work is completed.

• Pour water during cooling operation and check.

When electric work is not completed.

• Pour water during emergency operation and check.

* Drain pan and fan are activated simultaneously when single phase 220-240 V is

turned on to S1 and S2 on terminal block after the connecter (SWE) on controller

board in the electrical branch box is set to ON.

Be sure to turn it back to the former state after work.

• If the unit cannot be operated properly after test run, refer to the following table to nd the cause.

Symptom Cause

Wired remote controller LED 1, 2 (PCB in outdoor unit)

PLEASE WAIT For about 2 minutes

after power-on

After LED 1, 2 are lighted, LED 2 is turned

off, then only LED 1 is lighted. (Correct

operation)

•For about 2 minutes after power-on, operation of the remote

controller is not possible due to system start-up. (Correct

operation)

PLEASE WAIT → Error code

Subsequent to

about 2 minutes

after power-on

Only LED 1 is lighted. →LED 1, 2 blink.

•Connector for the outdoor unit’s protection device is not

connected.

Reverse or open phase wiring for the outdoor unit’s power

terminal block (L1, L2, L3)

Display messages do not appear

even when operation switch is

turned ON

(operation lamp does not light up).

Only LED 1 is lighted. →LED 1 blinks

twice, LED 2 blinks once.

•Incorrect wiring between indoor and outdoor units (incorrect

polarity of S1, S2, S3)

•Remote controller wire short

On the wireless remote controller with condition above, following phenomena take place.

• No signals from the remote controller are accepted.

• Operation lamp is blinking.

• The buzzer makes a short ping sound.

Note:

Operation is not possible for about 30 seconds after cancellation of function selection. (Correct operation)

For description of each LED (LED1, 2, 3) provided on the indoor controller, refer to the following table.

LED 1 (power for microcomputer) Indicates whether control power is supplied. Make sure that this LED is always lit.

LED 2 (power for remote controller) Indicates whether power is supplied to the remote controller. This LED lights only in the case of

the indoor unit which is connected to the outdoor unit refrigerant address “0”.

LED 3 (communication between indoor and outdoor units) Indicates state of communication between the indoor and outdoor units. Make sure that this LED

is always blinking.

Fig. 7-5

8. System control

Refer to the outdoor unit installation manual.

AWater supply pump

BWater (about 1000 cc)

CDrain plug

DPour water through outlet

•Be careful not to spray water into

the drain pump mechanism.

RG79D506K08.indb 16 3/28/2016 12:00:19 PM

15-20

ON/OFF

1 2

3 4

5 7

A=17

9.1. Checking the contents (Fig. 9-1)

• This kit contains this manual and the following parts.

Accessory name Q’ty Remarks

1Grille 1 950 × 950 (mm)

2Screw with captive washer 4 M5 × 0.8 × 25

3Gauge 1 (Divided into 4 parts)

4Fastener 3

5Screw 4 4 × 8

6Screw 1 4 × 12

7Wireless remote controller 1 for PLP-6BALM, PLP-6BALME

8i-see sensor corner panel 1 for PLP-6BAE, PLP-6BALME

9.2. Preparing to attach the grille (Fig. 9-2)

• With the gauge 3 supplied with this kit, adjust and check the positioning of the

unit relative to the ceiling. If the unit is not properly positioned relative to the ceil-

ing, it may allow air leaks or cause condensation to collect.

• Make sure that the opening in the ceiling is within the following tolerances:

860 × 860 - 910 × 910

• Make sure that A is performed within 17-22 mm. Damage could result by failing

to adhere to this range.

AMain unit

BCeiling

CGauge 3(inserted into the unit)

DCeiling opening dimensions

9.2.1. Removing the intake grille (Fig. 9-3)

• Slide the levers in the direction indicated by the arrows 1to open the intake

grille.

• Unlatch the hook that secures the grille.

* Do not unlatch the hook for the intake grille.

• With the intake grille in the “open” position, remove the hinge of the intake grille

from the grille as indicated by the arrows 2.

9.2.2. Removing the corner panel (Fig. 9-4)

• Remove the screw from the corner of the corner panel. Slide the corner panel as

indicated by the arrow 1to remove the corner panel.

[Fig.9-3] [Fig.9-4]

AIntake grille

BGrille

CIntake grille levers

DGrille hook

E Hole for the grille’s hook

FCorner panel

GScrew

HDetail

9.3. Selection of the air outlets

For this grille the discharge direction is available in 11 patterns. Also, by setting the

remote controller to the appropriate settings, you can adjust the air-ow and speed.

Select the required settings from the Table 1 according to the location in which you

want to install the unit.

1) Decide on the discharge direction pattern.

2) Be sure to set the remote controller to the appropriate settings according to the

number of air outlets and the height of the ceiling on which the unit will be in-

stalled.

Note:

For 3 and 2-directional, please use the air outlet shutter plate (option).

9.4. Installing the grille

9.4.1. Preparations (Fig. 9-5)

• Install the 2 enclosed screws with washer 2in the main unit (at the corner drain

pipe area and at the opposite corner) as shown in the diagram.

9. Installing the grille

ABE

GHGB

Fig. 9-3

Fig. 9-4

Fig. 9-1

Fig. 9-2

Fig. 9-5

4-directional 3-directional

Blowout direction

patterns

1 pattern: initial setting 4 patterns:

one air outlet fully closed

2-directional

Blowout direction

patterns

6 patterns:

2 air outlet fully closed

Table 1

AMain unit

BScrew with captive washer

RG79D506K08.indb 17 3/28/2016 12:00:20 PM

9. Installing the grille

9.4.2. Temporary installation of the grille (Fig. 9-6)

• Temporarily secure the grille using the bell shaped holes by putting the socket of

the grille marked Gon the corner drain pipe area of the main unit.

* Make sure that the lead wiring of the grille does not get pinched between the

grille and the main unit.

9.4.3. Securing the grille (Fig. 9-7)

• Secure the grille to the main unit by tightening the previously installed 2 screws

(with captive washer) as well as the 2 remaining screws (with captive washer).

* Make sure that there are no gaps between the main unit and the grille or the

grille and the ceiling.

Fixing gaps between the grille and the ceiling

With the grille attached, adjust the height of the main unit to close the gap.

Caution:

When tightening the screw with captive washer 2, tighten it at a torque of 4.8

N•m or less. Never use an impact screwdriver.

• It may result in parts damage.

9.4.4. Wire connection (Fig. 9-8)

• Remove the 2 screws fixing the cover of electrical branch box of the unit and

open the cover.

• Be sure to connect the connector(white, 20-pole) for vane motor of the grille to

CNV connector of controller board of the unit.

• As for PLP-6BALM(E), the connector of wireless sensor cable is also connected

to connecor CN90 on indoor controller board.

The lead wire of grille is passed through the catch of bell mouth of the unit

perfectly. The remaining lead wire is tied with clamp of the unit and put the cover of

the unit again with 2 screws.

Note:

Do not put the remaining lead wire in electrical branch box of the unit.

9.5. Installing the intake grille (Fig. 9-9 )

Note:

When reinstalling the corner panels (each with a safety wire attached), con-

nect the other end of each safety wire to the grille using a screw (4 pcs,

4×8) as shown in the illustration.

*If the corner panels are not attached, they may fall off while the unit is operating.

• Perform the procedure that is described in “9.2. Preparing to attach the grille” in

reverse order to install the intake grille and the corner panel.

• Multiple units can be installed with grille so that the position of the logo on each

corner panel is consistent with the other units regardless of the orientation of the

intake grille. Align the logo on the panel according to the wishes of the customer

as shown in the diagram to the left. (The position of the grille can be changed.)

DRefrigerant piping of the main unit

EDrain piping of the main unit

FInitial position of the corner panel(logo attached)

* Installation in any position is possible.

GInitial position of the levers on the intake grille

* Although the clips can be installed in any of 4 positions, the conguration shown

here is recommended.(It is not necessary to remove the intake grille when

maintenance is performed on the electric component box of the main unit.)

HReceiver (Only PLP-6BALM, PLP-6BALME Panel)

Ii-see sensor(PLP-6BAE, PLP-6BAMDE, PLP-6BALME panel)

9.6. Installation of i-see sensor corner panel

(Fig. 9-10)

For PLP-6BAE, PLP-6BAMDE, PLP-6BALME panel

• Take the lead wires CN4Y(white) and CN6Y(red) of the i-see sensor corner panel

8 from the side of the electrical box on the unit and make sure to conect them to

the connector of the controller board.

• Lead wires of the i-see sensor corner panel 8 should be xed at the rib of the

grille with the fastener 4 so that there is no slack.

• Lead wires should be held together with the lead wires of the unit and xed with 2

of the fastener 4 so that there is no slack.

• Put the cover back on the electrical box with 3 screws.

* Make sure wires are not caught in the cover of electric box. If they are caught,

they will be cut.

• Adverse procedure of “9.2. Preparing to attach the grille” will be taken for install-

ing the i-see sensor corner panel.

* The i-see sensor corner panel should be xed onto the grille 1with screw 6.

AMain unit

CCorner drain pipe area

DScrew with washer 2(for temporary use)

EGrille

FScrew with washer 2

GSocket

HBell shaped hole

Fig. 9-6

ACeiling

BMain unit

CGrille

DMake sure that there are no gaps.

E Adjust the nut of the main unit using a

wrench, etc.

AClamp of the main unit

BElectrical box

CIndoor controller board

DCatch for bell mouth

ELead wire of grille

Fig. 9-7

AScrew (4×8) 5

BCorner panel

CSafety wire

(Enlarged)

Fig. 9-8

Fig. 9-9

Fig. 9-10

AController board CN4Y

BController board CN6Y

C2 fasteners 4

DFastener 4

Ei-see sensor corner panel 8

FRib for grille

GScrew 6

RG79D506K08.indb 18 3/28/2016 12:00:21 PM

9. Installing the grille

9.7. Locking the up/down airow direction (Fig. 9-11)

The vanes of the unit can be set and locked in up or down orientations depending

upon the environment of use.

• Set according to the preference of the customer.

The operation of the fixed up/down vanes and all automatic controls cannot

be performed using the remote controller. In addition, the actual position of the

vanes may differ from the position indicated on the remote controller.

1Turn off the main power switch.

Injuries or an electrical shock may occur while the fan of the unit is rotating.

2Disconnect the connector for the vane motor of the vent that you want to lock.

(While pressing the button, remove the connector in the direction indicated by the

arrow as shown in the diagram.) After removing the connector, insulate it with tape.

It also can be set by remote controller. Refer to 6.3.3.

9.8. Check

•

Make sure that there is no gap between the unit and the grille, or between the grille

and the surface of the ceiling. If there is any gap between the unit and the grille, or

between the grille and the surface of the ceiling, it may cause dew to collect.

• Make sure that the wires have been securely connected.

• For PLP-6BAE, PLP-6BAMDE, PLP-6BALME, check the rotating movement of

the i-see sensor. If the i-see sensor does not rotate, review the procedure in “9.6.

Installation of i-see sensor corner panel”.

10. Easy maintenance function

Maintenance data, such as the indoor/outdoor unit’s heat exchanger temperature and compressor operation current can be displayed with “Smooth maintenance”.

* This cannot be executed during test operation.

* Depending on the combination with the outdoor unit, this may not be supported by some models.

F1 F2 F3 F4

Check menu

Cursor

Service menu:

Error history

Refrigerant volume check

Refrigerant leak check

Smooth maintenance

Request code

Smooth maintenance

Begin:

Smooth maintenance

Exit:

Ref.address

Stable mode

Cursor

Ref.address

Stable mode

Stabilization→Collecting

Cool / Heat/ Normal

Address

Smooth maintenance

Return:

Smooth maintenance

Return:

Smooth maintenance

Return:

Page

COMP. current

COMP. run time

COMP. On / Off

COMP. frequency

times

Ref. address

Cool

Ref.address

Cool

Ref.address

Cool

Sub cool

OU TH4 temp.

OU TH6 temp.

OU TH7 temp.

IU air temp.

IU HEX temp.

IU filter time

• Select “Service” from the Main menu, and press the [SELECT] button.

• Select “Check” with the [F1] or [F2] button, and press the [SELECT] button.

• Select “Smooth maintenance” with the [F1] or [F2] button, and press the [SELECT]

button.

Select each item.

• Select the item to be changed with the [F1] or [F2] button.

• Select the required setting with the [F3] or [F4] button.

“Ref. address” setting ………. “0” - “15”

“Stable mode” setting……….. “Cool” / “Heat” / “Normal”

• Press the [SELECT] button, xed operation will start.

* Stable mode will take approx. 20 minutes.

The operation data will appear.

The Compressor-Accumulated operating (COMP. run) time is 10-hour unit, and the

Compressor-Number of operation times (COMP. On/Off) is a 100-time unit (fractions

discarded)

Navigating through the screens

• To go back to the Main menu....................[MENU] button

• To return to the previous screen .......... [RETURN] button

Fig. 9-11

AButton

B Vane motor

C Up/down vanes

DConnector

RG79D506K08.indb 19 3/28/2016 12:00:21 PM

200

1.2. Передустановкойилиперемещением

Осторожно:

• Будьтечрезвычайноосторожныпритранспортировкеприборов.Прибордолжны

переноситьдваилиболеечеловека,посколькуонвеситнеменее20кг.Неподнимайте

приборзаупаковочныеленты.Используйтезащитныеперчатки,посколькуможно

повредитьрукиребристымидеталямиилидругимичастямиприбора.

• Утилизируйтеупаковочныематериалынадлежащимобразом.Упаковочныематериа-

лы,такие,какгвоздиидругиеметаллическиеилидеревянныечасти,могутпоранить

илипричинитьдругиетравмы.

• Дляпредотвращенияконденсациинеобходимообеспечитьтеплоизоляциютрубы

хладагента.Еслитрубахладагентанеизолированадолжнымобразом,приработе

приборабудетобразовыватьсяконденсат.

• Обернитетрубытеплоизоляционнымматериаломдляпредотвращенияконденсации.

Еслидренажнаятрубаустановленанеправильно,этоможетвызватьпротечкуводы

ииспортитьпотолок,пол,мебельилидругоеимущество.

Содержание

Предупреждение:

• Длявыполненияустановкиприбораобратитеськдилеруилисертифицированному

техническомуспециалисту.

• Запрещаетсясамостоятельныйремонтилиперемещениеприбора.

•

При установочных работах следуйте инструкциям в Руководстве по установке и ис-

пользуйте инструменты и детали трубопроводов, специально предназначенные для

использованиясхладагентом,указаннымвруководствепоустановкенаружногоприбора.

• Прибордолженбытьустановленсогласноинструкциям,чтобысвестикминимуму

рискповрежденияотземлетрясений,тайфуновилисильныхпорывовветра.Непра-

вильноустановленныйприборможетупастьипричинитьповреждениеилинанести

травму.

• Прибордолженбытьустановленнаконструкции,способнойвыдержатьеговес.

• Есликондиционерустановленвнебольшомпомещении,необходимопринятьмеры

дляпредотвращенияконцентрациихладагентасвышебезопасныхпределоввслу-

чаеутечкихладагента.Вслучаеутечкихладагентаипревышениидопустимойего

концентрациииз-занехваткикислородавпомещенииможетпроизойтинесчастный

случай.

• Есливовремяработыприборапроизошлаутечкахладагента,проветритепомещение.

Приконтактехладагентаспламенемобразуютсяядовитыегазы.

• Всеэлектроработыдолжнывыполнятьсяквалифицированнымтехническимспеци-

алистомвсоответствиисместнымиправиламииинструкциями,приведеннымив

данномРуководстве.

• Используйте для проводки указанные кабели. Убедитесь, что кабели надежно

соединены,а оконечныесоединенияненатянуты.Никогданесоединяйтекабели

внахлест(еслииноенеуказановприлагаемойдокументации).Несоблюдениеэтих

инструкцийможетпривестикперегревуиливозгоранию.

• Установку необходимовыполнятьв соответствиис действующими правилами

электробезопасности.

•

Данныйприборнепредназначендляиспользованиялюдьми(включаядетей)сограни-

ченнымифизическими,сенсорнымиилипсихическимивозможностями.Принедостатке

опытаизнанийразрешаетсяпользоватьсяданнымприборомтолькоподнаблюдением

лица,ответственногозабезопасность,илипослеинструктажапоиспользованиюприбора.

• Следуетследитьзадетьми,чтобыонинеигралисустройством.

• Крышкаклеммнойкоробкидолжнабытьнадежноприсоединенакприбору.

• Поврежденныйкабельизкомплектапоставкидолженбытьзамененвцеляхбезопас-

ностипроизводителем,сервиснымагентомилилицами,обладающиминеобходимой

квалификацией.

• Используйтетолькоте дополнительные принадлежности,на которые имеется

разрешениеотMitsubishiElectric;дляихустановкиобратитеськдилеруилиупол-

номоченномутехническомуспециалисту.

• Пользователюнеследуетпытатьсяремонтироватьприборилиперемещатьегона

другоеместо.

• Поокончанииустановкиубедитесьвотсутствииутечкихладагента.Еслихладагент

проникнетв помещение и произойдет контакт его с пламенем обогревателя или

переносногопищевогонагревателя,образуютсяядовитыхгазов.

• Примонтажеилиперемещении,атакжеприобслуживаниикондиционераиспользуйте

толькоуказанныйхладагент(R410A)длязаполнениятрубопроводовхладагента.Не

смешивайтеегонискакимдругимхладагентоминедопускайтеналичиявоздухав

трубопроводах.

 Наличиевоздухавтрубопроводахможетвызыватьскачкидавления,врезультате

которыхможетпроизойтивзрывилидругиеповреждения.

 Использованиелюбогохладагента,отличногоотуказанногодляэтойсистемы,вы-

зоветмеханическоеповреждение,сбоивработесистемы,иливыходустройстваиз

строя.Внаихудшемслучае,этоможетпослужитьсерьезнойпреградойкобеспечению

безопаснойработыэтогоизделия.

1.1. Передустановкой(Окружающаясреда)

Осторожно:

• Неиспользуйтеприборвнестандартнойокружающейсреде.Установкакондиционе-

равместах,подверженныхвоздействиюпара,летучихмасел(включаямашинное

масло)илисернистыхиспарений,местахсповышеннойконцентрациейсоли(таких,

какберегморя),можетпривестикзначительномуснижениюэффективностиработы

прибораилиповреждениюеговнутреннихчастей.

• Неустанавливайтеприборвместах,гдевозможнаутечка,возникновение,притокили

накоплениегорючихгазов.Еслигорючийгазбудетнакапливатьсявокругприбора,

этоможетпривестиквозникновениюпожараиливзрыву.

• Недержите пищевые продукты, растения, домашнихживотных в клетках, произ-

веденияискусстваиточныеинструментывпрямомпотокевоздухаотвнутреннего

прибораилислишкомблизкокнему,посколькуэтипредметымогутбытьповреждены

перепадамитемпературыиликапающейводой.

• Приуровневлажностивпомещениивыше80%илизакупоркедренажнойтрубыиз

внутреннегоприбораможеткапатьвода.Неустанавливайтевнутреннийприборв

местах,гдетакиекаплимогутвызватькакое-либоповреждение.

• Примонтажеприборавбольницеилицентресвязипримитевовниманиешумовое

иэлектронноевоздействие.Работатакихустройств,какинверторы,бытовыепри-

боры,высокочастотное медицинское оборудование и оборудование радиосвязи

можетвызватьсбоивработекондиционераилиегополомку.Кондиционертакже

можетповлиятьнаработумедицинскогооборудованияимедицинскоеобслужива-

ние,работукоммуникационногооборудования,вызываяискажениеизображенияна

дисплее.

• Немойтекондиционерводой.Этоможетпривестикпоражениюэлектрическимтоком.

• Затягивайтевсехомутынамуфтахвсоответствиисоспецификациями,используя

ключсрегулируемымусилием.Слишкомсильнозатянутыйхомутмуфтыпопро-

шествиинекотороговремениможетсломаться.

• Если прибор работает длительное время и выше потолка присутствует воздух

высокойтемпературы/высокойвлажности(вышеточкиросы26°С),вовнутреннем

прибореилинапотолочныхматериалахможетвозникатьконденсацияросы.При

эксплуатацииприбороввтакихусловиях,навсюповерхностьприбораипотолочных

материаловследуетдобавлятьизоляционныйматериал(10–20мм),чтобыпредот-

вратитьконденсациюросы.

1.3. Передэлектрическимиработами

Осторожно:

• Обязательноустановитеавтоматическиевыключатели.Впротивномслучаевоз-

можнопоражениеэлектрическимтоком.

• Используйтедляэлектропроводкистандартныекабели,рассчитанныенасоответ-

ствующуюмощность.Впротивномслучаеможетпроизойтикороткоезамыкание,

перегревилипожар.

• Примонтажекабелейпитаниянеприкладывайтерастягивающихусилий.

• Обязательнозаземлитеприбор.Отсутствиенадлежащегозаземленияможетпривести

кпоражениюэлектрическимтоком.

• Используйтеавтоматические выключатели (прерыватель утечки тока на землю,

разъединитель(плавкийпредохранитель+B)ипредохранителькорпуса)суказанным

предельнымтоком.Еслипредельныйтокавтоматическоговыключателябольше,

чемнеобходимо,можетпроизойтиполомкаилипожар.

1. Мерыпредосторожности

1.4. Передтестовымпрогоном

Осторожно:

• Включайтеглавныйвыключательпитаниянепозднее,чемза12часовдоначала

эксплуатации.Запускприборасразупослевключениявыключателяпитанияможет

серьезноповредитьвнутренниечасти.

• Передначаломэксплуатациипроверьте,чтовсепульты,щиткиидругиезащитные

частиправильноустановлены.Вращающиеся,нагретыеилинаходящиесяподна-

пряжениемчастимогутнанеститравмы.

•

Не включайте кондиционер без установленного воздушного фильтра. Если воздушный

фильтрнеустановлен,вприбореможетнакопитьсяпыль,чтоможетпривестикегополомке.

• Неприкасайтесьниккакимвыключателямвлажнымируками.Этоможетпривести

кпоражениюэлектрическимтоком.

• Неприкасайтеськтрубамсхладагентомголымирукамивовремяработыприбора.

• Послеостановкиприбораобязательноподождитепокрайнеймерепятьминутперед

выключениемглавноговыключателяпитания.Впротивномслучаевозможнапро-

течкаводыилиполомкаприбора.

Предупреждение:

Описываетмеры предосторожности,необходимыедляпредотвращенияполучения

травмыилигибелипользователя.

Осторожно:

Описываетмерыпредосторожности,необходимыедляпредотвращенияповреждения

прибора.

После окончания установочных работ проинструктируйте пользователя относительно правил

эксплуатации и обслуживания аппарата, а также ознакомьте с разделом “Меры предосто-

рожности” в соответствии с информацией, приведенной в Руководстве по использованию

аппарата, и выполните тестовый прогон аппарата для того, чтобы убедиться, что он работает

нормально. Обязательно передайте пользователю на хранение экземпляры Руководства

по установке и Руководства по эксплуатации. Эти Руководства должны быть переданы и

последующим пользователям данного прибора.

: Указывает, что данная часть должна быть заземлена.

Предупреждение:

Внимательнопрочтитетекстнаэтикеткахглавногоприбора.

Примечание:

Вэтомруководствепоиспользованиюаппаратафраза“проводнойпультдистанционногоуправления”относитсякпультудистанционногоуправленияPAR-

31MAA.

Сведенияодругихпультахдистанционногоуправленияприводятсявруководствепоустановкеилируководствепоначальнымнастройкам,находящемсяв

этихкоробках.

1. Меры предосторожности.....................................................................200

2. Место установки ..................................................................................201

3. Установка внутреннего прибора .........................................................201

4. Прокладка труб хладагента ................................................................203

5. Дренажные трубы ................................................................................204

6. Электрические работы ........................................................................205

7. Выполнение испытания....................................................................... 211

8. Управление системой .........................................................................214

9. Установка вентиляционной решетки ..................................................215

10. Функция простого техобслуживания ..................................................217

Доустановкиприбораубедитесь,чтоВы прочливсе“Мерыпредосторож-

ности”.

Пожалуйста,передподключениемданногооборудованияксистемеэлектро-

питания,сообщитеобэтомсвоемупоставщикуэлектропитанияилиполучите

егоразрешение.

RG79D506K08_RU.indd 200 3/28/2016 1:06:25 PM

This manual suits for next models

Table of contents

Languages:

Other Mitsubishi Electric Air Conditioner manuals

Mitsubishi Electric

Mitsubishi Electric SLZ-A09AR User manual

Mitsubishi Electric

Mitsubishi Electric MSXY-FN07VE-R1 User manual

Mitsubishi Electric

Mitsubishi Electric Starmex MSY-GE10VA User manual

Mitsubishi Electric

Mitsubishi Electric SRK71ZK-S User manual

Mitsubishi Electric

Mitsubishi Electric Mr.Slim SUZ-KA25VA3 User manual

Mitsubishi Electric

Mitsubishi Electric MSZ-GL24NA User manual

Mitsubishi Electric

Mitsubishi Electric PUHZ-P HA Series User manual

Mitsubishi Electric

Mitsubishi Electric PLFY-P20VCM-E2.TH Operating manual

Mitsubishi Electric

Mitsubishi Electric Mr. Slim PKA-RP HAL User manual

Mitsubishi Electric

Mitsubishi Electric PUHZ-ZRP35VKA2 User manual

Mitsubishi Electric

Mitsubishi Electric MS09NW*2 Operating manual

Mitsubishi Electric

Mitsubishi Electric PURY-P72 How to use

Mitsubishi Electric

Mitsubishi Electric MSC-GE20VB User manual

Mitsubishi Electric

Mitsubishi Electric MSZ-A18YV-E1 User manual

Mitsubishi Electric

Mitsubishi Electric MSZ-AP25VG User manual

Mitsubishi Electric

Mitsubishi Electric PUHZ-HRP-HA2 User manual

Mitsubishi Electric

Mitsubishi Electric TRANE NTXSST A112AA Series User manual

Mitsubishi Electric

Mitsubishi Electric City Multi PKFY-P30NKMU-E2 User manual

Mitsubishi Electric

Mitsubishi Electric PUHZ-P100VHA2 User manual

Mitsubishi Electric

Mitsubishi Electric MCFH-13NV-E4 User manual

Mitsubishi Electric

Mitsubishi Electric Mr. Slim MSZ-GE18NA Installation and user guide

Mitsubishi Electric

Mitsubishi Electric MSZ-FD25VA User manual

Mitsubishi Electric

Mitsubishi Electric MUZ-HJ VA Series User manual

Mitsubishi Electric

Mitsubishi Electric Mr.SLIM PUZ-ZM200YKA User manual

Popular Air Conditioner manuals by other brands

Daikin

Daikin FTKE25BVM Service manual

SPT

SPT WA-1511S user manual

Panasonic

Panasonic CS-S18HKQ Service manual

Daikin

Daikin FTXS50EV1B installation manual

INVENTOR

INVENTOR Neo N2UVO-09 user manual

York

York PCG4 Series installation manual

Shinco

Shinco SPF1-10C owner's manual

Samsung

Samsung AQV12J Series user manual

Trane

Trane Packaged TerminalAir Conditioners & Heat... Installation operation & maintenance

Hitachi

Hitachi RAS-70YHA3 instruction manual

Whirlpool

Whirlpool BHAC1000XS0 Use & care guide

GREE ELECTRIC

GREE ELECTRIC GWH09TA-S3DNA1C Service manual

Fujitsu

Fujitsu AGYG09LVCB Service manual

Gree

Gree GMV-ND07PLS/A-T(U) Service manual

Matsui

Matsui MAT-9KACW manual

Hitachi

Hitachi RAS-18LH2 Service manual

Sharp

Sharp Plasmacluster GS-XP07ER Operation manual

Carrier

Carrier CRTWOPOS007A00 installation instructions

Mitsubishi Electric PLA-RP BA Series User manual

Popular Air Conditioner manuals by other brands
