Mitsubishi Electric PUMY-P100VHM Operating manual

TECHNICAL & SERVICE MANUAL
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
CONTENTS
1. SAFETY PRECAUTION····································2
2. OVERVIEW OF UNITS······································5
3. SPECIFICATIONS·············································7
4. DATA ·································································8
5. OUTLINES AND DIMENSIONS······················18
6. WIRING DIAGRAM·········································19
7. NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION ···20
8. TROUBLESHOOTING ····································30
9. ELECTRICAL WIRING····································70
10. REFRIGERANT PIPING TASKS·····················73
11. DISASSEMBLY PROCEDURE························77
12. PARTS LIST ····················································82
13. RoHS PARTS LIST ·········································85
14. OPTIONAL PARTS··························Back Cover
OUTDOOR UNIT
No. OC376
REVISED EDITION-A
[Service Ref.]
PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
Model name
indication
HFC
utilized
R410A
August 2006
NOTE :
· This service manual describes technical data of outdoor unit.
As for indoor units, refer to its service manual.
· RoHS compliant products have <G> mark on the spec name plate.
· For servicing of RoHS compliant products, refer to the RoHS PARTS LIST.
[Model name]
<Outdoor unit>
PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
Revision:
· PUMY-P100VHM and
PUMY-P140VHM are
added in REVISED
EDITION-A.
· RoHS PARTS LIST has
been added.
· Some descriptions have
been modified.
· Please void OC376.
OC376A--1.qxp 06.8.25 11:04 AM Page 1

2
1 SAFETY PRECAUTION
Cautions for units utilizing refrigerant R410A
1-1. CAUTIONS RELATED TO NEW REFRIGERANT
Use new refrigerant pipes.
Make sure that the inside and outside of refrige-
rant piping is clean and it has no contamination
such as sulfur hazardous for use, oxides, dirt,
shredded particles, etc.
In addition, use pipes with specified thickness.
Store the piping to be used during installation
indoors and keep both ends of the piping sealed
until just before brazing. (Leave elbow joints, etc.
in their packaging.)
Use ester oil, ether oil or alkylbenzene oil (small
amount) as the refrigerant oil applied to flares
and flange connections.
Avoid using thin pipes.
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition
change may occur in refrigerant and the efficiency will be
lowered.
Do not use refrigerant other than R410A.
If other refrigerant (R22 etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil etc.
Use a vacuum pump with a reverse flow check
valve.
Vacuum pump oil may flow back into refrigerant cycle and
that can cause deterioration of refrigerant oil etc.
Use the following tools specifically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A refrigerant.
Keep the tools with care.
If dirt, dust or moisture enter into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the efficiency will be lowered.
Flare tool
Electronic refrigerant
charging scale
Vacuum pump adaptor
Size adjustment gauge
Gauge manifold
Torque wrench
Gas leak detector
Charge hose
Tools for R410A
Contamination inside refrigerant piping can cause deterio-
ration of refrigerant oil etc.
If dirt, dust or moisture enter into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
If large amount of mineral oil enter, that can cause deterio-
ration of refrigerant oil etc.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
OC376A--1.qxp 06.8.25 11:04 AM Page 2

3
Gravimeter
Unit
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
No. Specifications
1Gauge manifold ·Only for R410A
·Use the existing fitting specifications. (UNF1/2)
·Use high-tension side pressure of 5.3MPa·G or over.
2Charge hose ·Only for R410A
·Use pressure performance of 5.09MPa·G or over.
3Electronic scale
4Gas leak detector ·Use the detector for R134a, R407C or R410A.
5Adaptor for reverse flow check ·Attach on vacuum pump.
6Refrigerant charge base
7Refrigerant cylinder ·Only for R410A Top of cylinder (Pink)
Cylinder with syphon
8Refrigerant recovery equipment
[1] Cautions for service
(1) Perform service after collecting the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) When performing service, install a filter drier simultaneously.
Be sure to use a filter drier for new refrigerant.
[2] Additional refrigerant charge
When charging directly from cylinder
· Check that cylinder for R410A on the market is syphon type.
· Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)
OC376A--1.qxp 06.8.25 11:04 AM Page 3

4
Cautions for refrigerant piping work
New refrigerant R410A is adopted for replacement inverter series. Although the refrigerant piping work for R410A is same
as for R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the working
pressure of R410A is 1.6 time higher than that of R22, their sizes of flared sections and flare nuts are different.
1Thickness of pipes
Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness
shown below. (Never use pipes of 0.7mm or below.)
2Dimensions of flare cutting and flare nut
The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that,
R410A is a refrigerant, which has higher risk of leakage because of its working pressure is higher than that of other
refrigerants. Therefore, to enhance airtightness and intensity, flare cutting dimension of copper pipe for R410A has been
specified separately from the dimensions for other refrigerants as shown below. The dimension B of flare nut for R410A
also has partly been changed to increase intensity as shown below. Set copper pipe correctly referring to copper pipe
flaring dimensions for R410A below. For 1/2” and 5/8”, the dimension B changes.
Use torque wrench corresponding to each dimension.
3Tools for R410A (The following table shows whether conventional tools can be used or not.)
1/4”
3/8”
1/2”
5/8”
3/4”
6.35
9.52
12.70
15.88
19.05
0.8
0.8
0.8
1.0
—
0.8
0.8
0.8
1.0
1.0
Nominal
dimensions
Diagram below: Piping diameter and thickness
Outside
diameter (mm)
Thickness (mm)
R410A R22
1/4”
3/8”
1/2”
5/8”
3/4”
6.35
9.52
12.70
15.88
19.05
9.1
13.2
16.6
19.7
—
9.0
13.0
16.2
19.4
23.3
Nominal
dimensions
Flare cutting dimensions
Outside
diameter Dimension A ( )
+0
-0.4
(mm)
R410A R22
1/4”
3/8”
1/2”
5/8”
3/4”
6.35
9.52
12.70
15.88
19.05
17.0
22.0
26.0
29.0
—
17.0
22.0
24.0
27.0
36.0
Nominal
dimensions
Flare nut dimensions
Outside
diameter Dimension B (mm)
R410A R22
Gauge manifold
Charge hose
Gas leak detector
Refrigerant recovery equipment
Refrigerant cylinder
Applied oil
Safety charger
Charge valve
Vacuum pump
Flare tool
Bender
Pipe cutter
Welder and nitrogen gas cylinder
Refrigerant charging scale
Vacuum gauge or thermis-
tor vacuum gauge and
vacuum valve
Charging cylinder
Air purge and refrigerant
charge, operation check
Gas leak check
Collection of refrigerant
Refrigerant charge
Apply to flared section
Prevent compressor malfunction
when charging refrigerant by
spraying liquid refrigerant
Prevent gas from blowing out
when detaching charge hose
Vacuum drying and air
purge
Flaring work of piping
Bend the pipes
Cut the pipes
Weld the pipes
Charge refrigerant
Check the degree of vacuum. (Vacuum
valve prevents back flow of oil and refri-
gerant to thermistor vacuum gauge)
Charge refrigerant
Tool exclusive for R410A
Tool exclusive for R410A
Tool for HFC refrigerant
Tool exclusive for R410A
Tool exclusive for R410A
Ester oil and alkylbenzene
oil (minimum amount)
Tool exclusive for R410A
Tool exclusive for R410A
Tools can be used for other
refrigerants if equipped with
adopter for reverse flow check
Tools can be used for other
refrigerants by adjusting
flaring dimension
Tools can be used for other refrigerants
Tools can be used for other refrigerants
Tools can be used for other refrigerants
Tools can be used for other refrigerants
Tools can be used for other
refrigerants
Tool exclusive for R410A

Tools and materials Use R410A tools Can R22 tools be used?
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
Can R407C tools be used?
Ester oil:
Alkylbenzene oil: minimum amount
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
: Prepare a new tool.(Use the new tool as the tool exclusive for R410A.)
:Tools for other refrigerants can be used under certain conditions.
:Tools for other refrigerants can be used.
Dimension A
Dimension B
OC376A--1.qxp 06.8.25 11:04 AM Page 4

Branching pipe
components Branch header
(2 branches) Branch header
(4 branches) Branch header (8 branches)
CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
Outdoor unit
Capacity
50% ~130% of outdoor unit capacity *2
Type 20 ~ Type 140
1~ 8 unit
Indoor
unit that
can be
connected
Number of units
Total system wide capacity
5HP
PUMY-P125VHM
6HP
PUMY-P140VHM
Type 20 ~ Type 125
1~ 6 unit
4HP
PUMY-P100VHM
5
2OVERVIEW OF UNITS
2-1. UNIT CONSTRUCTION
20
25
32
40
50
63
71
80
100
125
140
20VCM-E
25VCM-E
32VCM-E/32VAM-E
40VCM-E/40VAM-E
50VAM-E
63VAM-E
–
80VAM-E
100VAM-E
125VAM-E
–
20VLMD-E
25VLMD-E
32VLMD-E
40VLMD-E
50VLMD-E
63VLMD-E
–
80VLMD-E
100VLMD-E
125VLMD-E
–
20VML-E / VMM-E
25VML-E / VMM-E
32VML-E / VMM-E
40VMH-E / VMM-E
50VMH-E / VMM-E
63VMH-E / VMM-E
71VMH-E / VMM-E
80VMH-E / VMM-E
100VMH-E / VMM-E
125VMH-E / VMM-E
140VMM-E
20VM-E
25VM-E
32VM-E
40VM-E
50VM-E
63VM-E
71VM-E
80VM-E
100VM-E
125VM-E
–
20VAM-E
25VAM-E
32VGM-E
40VGM-E
50VGM-E
–
–
–
–
–
–
20VLEM-E
25VLEM-E
32VLEM-E
40VLEM-E
50VLEM-E
63VLEM-E
–
–
–
–
–
20VLRM-E
25VLRM-E
32VLRM-E
40VLRM-E
50VLRM-E
63VLRM-E
–
–
–
–
–
–
–
–
40VGM-E
–
63VGM-E
–
–
100VGM-E
125VGM-E
–
PLFY-P PLFY-P PEFY-P PDFY-P PKFY-P PCFY-P PFFY-P PFFY-P
Capacity
Model Cassette Ceiling
4-way flow 2-way flow
20VBM-E
25VBM-E
32VBM-E
40VBM-E
–
–
–
–
–
–
–
PMFY-P
1-way flow Ceiling
Concealed Ceiling mounted
built-in Ceiling
Suspended
Wall Mounted Floor standing
Exposed Concealed
Ceiling
Concealed
(Fresh Air) *1
PEFY-P
-
-
-
-
-
-
-
80VMH-E-F
-
-
140VMH-E-F
Decorative panel
Remote
controller
Name
Model number
Functions
M-NET remote controller
PAR-F27MEA-E
• A handy remote controller for use in conjunction
with the Melans centralized management system.
• Addresses must be set.
• Addresses setting is not necessary.
MA remote controller
PAR-21MAA
*1. It is possible only by 1:1 system.
(One indoor unit of Fresh Air type is connected with one outdoor unit.)
Operating temperature range (outdoor temperature) for fresh air type indoor units differ from other indoor units.
Refer to 2-2(3).
*2. When the indoor unit of Fresh Air type is connected with the outdoor unit, the maximum connectable total indoor unit
capacity is 110%(100% in case of heating below -5:(23˚F)).
OC376A--1.qxp 06.8.25 11:04 AM Page 5

6
2-2. UNIT SPECIFICATIONS
(2) Method for identifying MULTI-S model
(1) Outdoor Unit
■ Indoor unit < When using Model 80 > ■ Outdoor unit <When using model 125 >
(3) Operating temperature range
Notes D.B. : Dry Bulb Temperature
W.B. : Wet Bulb Temperature
w1. 10~46°C DB : In case of connecting PKFY-P20/P25 type indoor unit.
P L F Y - P 80 V AM - E PU M Y - P 125 V H M
PAC type
AM
KM
M
KM
LMD
Frequency
conversion
controller
Refrigerant
R407C/R22
R410A
commonness
Refrigerant
R410A
NEW frequency converter
one-to-many air conditioners
(flexible design type)
Indicates equivalent
to Cooling capacity
(k cal / h)
Indicates equivalent
to Cooling capacity
(k cal / h)
Power supply
V: Single phase
220-230-240V 50Hz
220V 60Hz
Power supply
V: 1-phase
220-230-240V : 50Hz
220V : 60Hz
L : Ceiling cassette
K : Wall-mounted type
E : Hidden skylight type
C: Ceiling suspended type
M: Ceiling cassette type
F : Floor standing type
}
M-NET
control
Outdoor unit
model type
Sub-number M-NET control
Frequency
conversion
controller
Outdoor unit
MULTI-S
Service Ref.
Capacity Cooling (kW)
Heating (kW)
PUMY-P140VHM
15.5
18.0
3.3
PUMY-P125VHM
14.0
16.0
2.9
PUMY-P100VHM
11.2
12.5
2.2Motor for compressor (kW)
Cooling
W.B. 15~24°C
D.B. -5~46°C w1
Heating
D.B. 15~27°C
W.B. -15~15°C
Indoor-side intake air temperature
Outdoor-side intake air temperature
Cooling / Heating capacity indicates the maximum value at operation under the following condition.
w. Cooling Indoor : D.B. 27°C / W.B. 19.0°C
Outdoor : D.B. 35°C
Heating Indoor : D.B. 20°C
Outdoor : D.B. 7°C / W.B. 6°C
■In case of connecting fresh air type indoor unit
air type indoor
Capacity of Fresh
Cooling Heating
Indoor-side and Outdoor-side P80 D.B.21~43:w2
W.B.15.5~35:D.B.-10~20:w3
intake air temperature P140 D.B.21~43:w2
W.B.15.5~35:D.B.-5~20:w3
w2.Thermo-off(FAN-mode) automatically starts if the outdoor temp. is lower than 21:D.B..
w3.Thermo-off(FAN-mode) automatically starts if the outdoor temp. is higher than 20:D.B..
OC376A--1.qxp 06.8.25 11:04 AM Page 6

7
3 SPECIFICATIONS
*3
*3
*3
*3
*3
*3
*3
*3
PUMY-P125VHM
Cooling Capacity kW 14.0
Heating Capacity kW 16.0
Input (Cool)kW 4.32
Input Current (Cool)A
20.0/19.1/18.3, 20.0
Input (Heat)kW 4.33
Input Current (Heat)A
20.0/19.1/18.3, 20.0
EER (Cool)3.24
COP (Heat)3.69
Connectable indoor units (Max.)8
Max. Connectable Capacity kW 18.2 (130%)
Power Supply Single phase , 50Hz 220/230/240V, 60Hz 220V
Breaker Size 32A
Sound level (Cool/Heat)dB 50 / 52
External finish Munsell 3Y 7.8/1.1
Refrigerant control Linear Expansion Valve
Compressor Hermetic
ANB33FDCMT
Model
Motor output kW 2.9
Starting method Inverter
Crankcase heater W —
Heat exchanger Plate fin coil (Anti corrosion fin treatment)
Fan Fan (drive) oNo. Propeller fan o2
Fan motor output kW 0.060 + 0.060
Airflow k/min(CFM)100 (3,530)
Dimensions (HxWxD)Wmm
(in.)950(37-3/8)
Dmm
(in.)330+30(13+1-3/16)
Hmm
(in.)1,350(53-1/8)
Weight kg(lbs)127(280)
Refrigerant R410A
Charge kg(lbs)8.5 (18.7)
Protection High pressure protection HP switch
devices Compressor protection Discharge thermo, Over current detection
Fan motor protection Overheating/Voltage protection
Oil (Model)2.3 (MEL56)
Total Piping length (Max.)m
L
120
Farthest m 80
Max Height difference m 30
Chargeless length m 50
Piping diameter Gas [mm 15.88 (5/8")
Liquid [mm 9.52 (3/8")
Guaranteed operation range (cool)-5~ 46:DB
(heat)-15~ 15:WB
*1
*2
Power factor (Cool)
Power factor (Heat)
%
%
98.4
98.5
PUMY-P100VHM
11.2
12.5
3.34
15.4/14.8/14.1, 15.4
3.66
16.9/16.2/15.5,16.9
3.35
3.42
6
14.5 (130%)
49 / 51
2.2
98.4
98.4
PUMY-P140VHM
15.5
18.0
5.35
24.7/23.6/22.7,24.7
5.58
25.8/24.7/23.6,25.8
2.90
3.23
8
20.2 (130%)
51 / 53
3.3
98.4
98.4
Rating conditions (JIS B 8616)
Cooling Indoor : D.B. 27:/ W.B. 19:
Outdoor : D.B. 35:/ W.B. 20:
Heating Indoor : D.B. 20:
Outdoor : D.B. 7:/ W.B. 6:
Note.*1. 20m:In case of installing outdoor unit lower than
indoor unit.
*2. 10~46:DB:In case of connecting PKFY-P20/P25
type indoor unit.
*3. Electrical data is for only outdoor unit.
OC376A--1.qxp 06.8.25 11:04 AM Page 7

8
4DATA
4-1. COOLING AND HEATING CAPACITY AND CHARACTERISTICS
4-1-1. Method for obtaining system cooling and heating capacity:
To obtain the system cooling and heating capacity and the electrical characteristics of the outdoor unit, first add up the ratings
of all the indoor units connected to the outdoor unit (see table below), and then use this total to find the standard capacity with
the help of the tables on 4-2.STANDARD CAPACITY DIAGRAM.
(1) Capacity of indoor unit
4-1-2. Method for obtaining the heating and cooling capacity of an indoor unit:
(1) The capacity of each indoor unit (kW) = the capacity A (or B) o
(2) Sample calculation (using the system described above in 4-1-1. (2) ):
model capacity
total model capacity of all indoor units
During cooling: During heating:
• The total model capacity of the indoor unit is:
2.8 o2 + 5.6 o2=16.8kW
Therefore, the capacity of PKFY-P25VAM-E and
PLFY-P50VLMD-E will be calculated as follows by
using the formula in 4-1-2. (1):
Model 25=14.6 o= 2.43kW
Model 50=14.6 o= 4.87kW
• The total model capacity of indoor unit is:
3.2 o2 + 6.3 o2=19.0
Therefore, the capacity of PKFY-P25VAM-E and PLFY-
P50VLMD-E will be calculated as follows by using the
formula in 4-1-2. (1):
Model 25=16.33 o= 2.75kW
Model 50=16.33 o= 5.41kW
2.8
16.8 3.2
19.0
6.3
19.0
5.6
16.8
(2) Sample calculation
1System assembled from indoor and outdoor unit (in this example the total capacity of the indoor units is greater than that of
the outdoor unit)
• Outdoor unit PUMY-P125VHM
• Indoor unit PKFY-P25VAM-E o2 , PLFY-P50VLMD-E o2
2According to the conditions in 1, the total capacity of the indoor unit will be: 28 o2 + 56 o2 = 168
3The following figures are obtained from the 168 total capacity row of 4-2. STANDARD CAPACITY DIAGRAM :
Model 20
Model Number for indoor unit
Model Capacity 22
Model 25
28
Model 32
36
Model 40
45
Model 50
56
Model 63
71
Model 71
80
Model 80
90
Model 100
112
Model 125
140
Model 140
160
Cooling
A 14.60 Heating
17.6
Cooling
19.4
Heating
3.99
Cooling
4.39
Heating
B 16.33
Capacity (kW) Outdoor unit power consumption (kW) Outdoor unit current (A)/230V
OC376A--1.qxp 06.8.25 11:04 AM Page 8

9
4-2. STANDARD CAPACITY DIAGRAM
4-2-1. PUMY-P100VHM
*Before calculating the sum of total capacity of indoor units,please convert the value into the kW model capacity
following the formula on 4-1-1.
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/220V Current(A)/230V Current(A)/240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
56 5.60 6.30 1.37 1.79 6.3 8.3 6.1 7.9 5.8 7.6
57 5.70 6.41 1.39 1.82 6.4 8.4 6.2 8.1 5.9 7.7
58 5.80 6.53 1.42 1.85 6.6 8.6 6.3 8.2 6.0 7.8
59 5.90 6.64 1.44 1.88 6.7 8.7 6.4 8.3 6.1 8.0
60 6.00 6.75 1.46 1.91 6.8 8.8 6.5 8.4 6.2 8.1
61 6.10 6.87 1.49 1.94 6.9 9.0 6.6 8.6 6.3 8.2
62 6.20 6.98 1.51 1.97 7.0 9.1 6.7 8.7 6.4 8.4
63 6.30 7.09 1.54 2.00 7.1 9.2 6.8 8.8 6.5 8.5
64 6.40 7.20 1.56 2.03 7.2 9.4 6.9 9.0 6.6 8.6
65 6.50 7.32 1.59 2.06 7.4 9.5 7.0 9.1 6.7 8.7
66 6.60 7.43 1.62 2.09 7.5 9.7 7.2 9.2 6.9 8.9
67 6.70 7.54 1.64 2.12 7.6 9.8 7.3 9.4 7.0 9.0
68 6.80 7.66 1.67 2.15 7.7 9.9 7.4 9.5 7.1 9.1
69 6.90 7.77 1.70 2.18 7.9 10.1 7.5 9.6 7.2 9.2
70 7.00 7.88 1.73 2.22 8.0 10.3 7.7 9.8 7.3 9.4
71 7.10 8.00 1.76 2.25 8.1 10.4 7.8 10.0 7.5 9.5
72 7.20 8.11 1.79 2.28 8.3 10.5 7.9 10.1 7.6 9.7
73 7.30 8.22 1.82 2.31 8.4 10.7 8.1 10.2 7.7 9.8
74 7.40 8.33 1.85 2.34 8.6 10.8 8.2 10.3 7.8 9.9
75 7.50 8.44 1.88 2.37 8.7 11.0 8.3 10.5 8.0 10.0
76 7.60 8.56 1.91 2.41 8.8 11.1 8.4 10.7 8.1 10.2
77 7.70 8.67 1.94 2.44 9.0 11.3 8.6 10.8 8.2 10.3
78 7.80 8.78 1.97 2.47 9.1 11.4 8.7 10.9 8.4 10.5
79 7.90 8.89 2.00 2.50 9.2 11.6 8.8 11.1 8.5 10.6
80 8.00 9.00 2.04 2.54 9.4 11.7 9.0 11.2 8.6 10.8
81 8.10 9.10 2.07 2.57 9.6 11.9 9.2 11.4 8.8 10.9
82 8.20 9.20 2.10 2.60 9.7 12.0 9.3 11.5 8.9 11.0
83 8.30 9.30 2.14 2.64 9.9 12.2 9.5 11.7 9.1 11.2
84 8.40 9.40 2.17 2.67 10.0 12.3 9.6 11.8 9.2 11.3
85 8.50 9.50 2.21 2.70 10.2 12.5 9.8 11.9 9.4 11.4
86 8.60 9.60 2.24 2.74 10.4 12.7 9.9 12.1 9.5 11.6
87 8.70 9.70 2.28 2.77 10.5 12.8 10.1 12.2 9.7 11.7
88 8.80 9.80 2.32 2.80 10.7 12.9 10.3 12.4 9.8 11.9
89 8.90 9.90 2.35 2.84 10.9 13.1 10.4 12.6 10.0 12.0
90 9.00 10.00 2.39 2.87 11.1 13.3 10.6 12.7 10.1 12.2
91 9.10 10.10 2.43 2.91 11.2 13.5 10.7 12.9 10.3 12.3
92 9.20 10.22 2.47 2.94 11.4 13.6 10.9 13.0 10.5 12.5
93 9.30 10.33 2.50 2.97 11.6 13.7 11.1 13.1 10.6 12.6
94 9.40 10.45 2.54 3.01 11.7 13.9 11.2 13.3 10.8 12.8
95 9.50 10.56 2.58 3.04 11.9 14.1 11.4 13.4 10.9 12.9
96 9.60 10.67 2.62 3.08 12.1 14.2 11.6 13.6 11.1 13.1
97 9.70 10.79 2.66 3.11 12.3 14.4 11.8 13.8 11.3 13.2
98 9.80 10.90 2.70 3.15 12.5 14.6 11.9 13.9 11.4 13.3
99 9.90 11.02 2.75 3.19 12.7 14.7 12.2 14.1 11.7 13.5
100 10.00 11.13 2.79 3.22 12.9 14.9 12.3 14.2 11.8 13.6
101 10.10 11.24 2.83 3.26 13.1 15.1 12.5 14.4 12.0 13.8
102 10.20 11.36 2.87 3.29 13.3 15.2 12.7 14.5 12.2 13.9
103 10.30 11.47 2.91 3.33 13.5 15.4 12.9 14.7 12.3 14.1
104 10.40 11.59 2.96 3.36 13.7 15.5 13.1 14.9 12.5 14.2
105 10.50 11.70 3.00 3.40 13.9 15.7 13.3 15.0 12.7 14.4
106 10.60 11.81 3.05 3.44 14.1 15.9 13.5 15.2 12.9 14.6
107 10.70 11.93 3.09 3.47 14.3 16.0 13.7 15.3 13.1 14.7
108 10.80 12.04 3.14 3.51 14.5 16.2 13.9 15.5 13.3 14.9
109 10.90 12.16 3.18 3.55 14.7 16.4 14.1 15.7 13.5 15.0
110 11.00 12.27 3.23 3.59 14.9 16.6 14.3 15.9 13.7 15.2
OC376A--1.qxp 06.8.25 11:04 AM Page 9

10
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/220V Current(A)/230V Current(A)/240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
111 11.10 12.38 3.27 3.62 15.1 16.7 14.5 16.0 13.9 15.3
112 11.20 12.50 3.34 3.66 15.4 16.9 14.8 16.2 14.1 15.5
113 11.22 12.51 3.35 3.65 15.5 16.9 14.8 16.1 14.2 15.5
114 11.24 12.53 3.35 3.64 15.5 16.8 14.8 16.1 14.2 15.4
115 11.26 12.54 3.36 3.63 15.5 16.8 14.9 16.0 14.2 15.4
116 11.28 12.55 3.36 3.62 15.5 16.7 14.9 16.0 14.2 15.3
117 11.30 12.56 3.36 3.61 15.5 16.7 14.9 16.0 14.2 15.3
118 11.32 12.57 3.37 3.59 15.6 16.6 14.9 15.9 14.3 15.2
119 11.34 12.58 3.37 3.58 15.6 16.5 14.9 15.8 14.3 15.2
120 11.36 12.60 3.38 3.57 15.6 16.5 14.9 15.8 14.3 15.1
121 11.38 12.61 3.38 3.56 15.6 16.5 14.9 15.7 14.3 15.1
122 11.40 12.62 3.38 3.55 15.6 16.4 14.9 15.7 14.3 15.0
123 11.42 12.63 3.39 3.54 15.7 16.4 15.0 15.7 14.4 15.0
124 11.44 12.64 3.39 3.52 15.7 16.3 15.0 15.6 14.4 14.9
125 11.47 12.66 3.40 3.51 15.7 16.2 15.0 15.5 14.4 14.9
126 11.49 12.67 3.40 3.50 15.7 16.2 15.0 15.5 14.4 14.8
127 11.51 12.68 3.40 3.49 15.7 16.1 15.0 15.4 14.4 14.8
128 11.53 12.69 3.41 3.48 15.8 16.1 15.1 15.4 14.4 14.7
129 11.55 12.70 3.41 3.47 15.8 16.0 15.1 15.3 14.4 14.7
130 11.57 12.71 3.42 3.45 15.8 15.9 15.1 15.3 14.5 14.6
131 11.59 12.73 3.42 3.44 15.8 15.9 15.1 15.2 14.5 14.6
132 11.61 12.74 3.42 3.43 15.8 15.9 15.1 15.2 14.5 14.5
133 11.63 12.75 3.43 3.42 15.9 15.8 15.2 15.1 14.5 14.5
134 11.65 12.76 3.43 3.41 15.9 15.8 15.2 15.1 14.5 14.4
135 11.67 12.77 3.44 3.40 15.9 15.7 15.2 15.0 14.6 14.4
136 11.69 12.78 3.44 3.38 15.9 15.6 15.2 14.9 14.6 14.3
137 11.71 12.80 3.45 3.37 15.9 15.6 15.3 14.9 14.6 14.3
138 11.73 12.81 3.45 3.36 15.9 15.5 15.3 14.9 14.6 14.2
139 11.75 12.82 3.45 3.35 15.9 15.5 15.3 14.8 14.6 14.2
140 11.77 12.83 3.46 3.34 16.0 15.4 15.3 14.8 14.7 14.2
141 11.79 12.84 3.46 3.32 16.0 15.3 15.3 14.7 14.7 14.1
142 11.82 12.86 3.47 3.31 16.0 15.3 15.3 14.6 14.7 14.0
143 11.84 12.87 3.47 3.30 16.0 15.3 15.3 14.6 14.7 14.0
144 11.86 12.88 3.47 3.29 16.0 15.2 15.3 14.5 14.7 13.9
145 11.88 12.89 3.48 3.28 16.1 15.2 15.4 14.5 14.7 13.9
OC376A--1.qxp 06.8.25 11:04 AM Page 10

11
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/ 220V Current(A)/ 230V Current(A)/ 240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
70 7.00 7.88
71 7.10 8.00
72 7.20 8.11
73 7.30 8.22
74 7.40 8.33
75 7.50 8.44
76 7.60 8.56
77 7.70 8.67
78 7.80 8.78
79 7.90 8.89
80 8.00 9.00
81 8.10 9.10
82 8.20 9.20
83 8.30 9.30
84 8.40 9.40
85 8.50 9.50
86 8.60 9.60
87 8.70 9.70
88 8.80 9.80
89 8.90 9.90
90 9.00 10.00
91 9.10 10.10
92 9.20 10.22
93 9.30 10.33
94 9.40 10.45
95 9.50 10.56
96 9.60 10.67
97 9.70 10.79
98 9.80 10.90
99 9.90 11.02
100 10.00 11.13
101 10.10 11.24
102 10.20 11.36
103 10.30 11.47
104 10.40 11.59
105 10.50 11.70
106 10.60 11.81
107 10.70 11.93
108 10.80 12.04
109 10.90 12.16
110 11.00 12.27
111 11.10 12.38
112 11.20 12.50
113 11.30 12.63
114 11.40 12.75
115 11.50 12.88
116 11.60 13.00
117 11.70 13.13
118 11.80 13.25
119 11.90 13.38
120 12.00 13.50
121 12.10 13.63
122 12.20 13.75
123 12.30 13.88
124 12.40 14.00
125 12.50 14.13
126 12.60 14.25
127 12.70 14.38
128 12.80 14.50
129 12.90 14.63
130 13.00 14.75
2.05 8.4
9.5 8.1 9.1 7.7 8.7
2.08 8.6
9.6 8.2 9.2 7.8 8.8
2.11 8.7
9.7 8.3 9.3 8.0 8.9
2.13 8.8
9.8 8.4 9.4 8.1 9.0
2.16 8.9
10.0 8.5 9.5 8.2 9.1
2.19 9.0
10.1 8.6 9.6 8.3 9.2
2.21 9.2
10.2 8.8 9.8 8.4 9.4
2.24 9.3
10.3 8.9 9.9 8.5 9.5
2.27 9.4
10.5 9.0 10.0 8.6 9.6
2.29 9.5
10.6 9.1 10.1 8.7 9.7
2.32 9.7
10.7 9.3 10.3 8.9 9.8
2.35 9.8
10.8 9.4 10.4 9.0 9.9
2.38 9.9
11.0 9.5 10.5 9.1 10.1
2.41 10.1
11.1 9.6 10.6 9.2 10.2
2.44 10.2
11.2 9.8 10.8 9.4 10.3
2.46 10.3
11.4 9.9 10.9 9.5 10.4
2.49 10.5
11.5 10.0 11.0 9.6 10.5
2.52 10.6
11.6 10.2 11.1 9.7 10.7
2.55 10.8
11.8 10.3 11.3 9.9 10.8
2.58 10.9
11.9 10.4 11.4 10.0 10.9
2.61 11.0
12.0 10.6 11.5 10.1 11.0
2.64 11.2
12.2 10.7 11.7 10.3 11.2
2.67 11.3
12.3 10.8 11.8 10.4 11.3
2.70 11.5
12.5 11.0 11.9 10.5 11.4
2.73 11.6
12.6 11.1 12.1 10.7 11.6
2.76 11.8
12.7 11.3 12.2 10.8 11.7
2.79 11.9
12.9 11.4 12.3 10.9 11.8
2.82 12.1
13.0 11.6 12.5 11.1 11.9
2.85 12.2
13.2 11.7 12.6 11.2 12.1
2.89 12.4
13.3 11.9 12.7 11.4 12.2
2.92 12.6
13.5 12.0 12.9 11.5 12.3
2.95 12.7
13.6 12.2 13.0 11.7 12.5
2.98 12.9
13.8 12.3 13.2 11.8 12.6
3.01 13.0
13.9 12.5 13.3 11.9 12.7
3.05 13.2
14.1 12.6 13.4 12.1 12.9
3.08 13.4
14.2 12.8 13.6 12.2 13.0
3.11 13.5
14.4 12.9 13.7 12.4 13.2
3.14 13.7
14.5 13.1 13.9 12.6 13.3
3.18 13.9
14.7 13.3 14.0 12.7 13.4
3.21 14.0
14.8 13.4 14.2 12.9 13.6
3.24 14.2
15.0 13.6 14.3 13.0 13.7
3.28 14.4
15.1 13.7 14.5 13.2 13.9
3.31 14.5
15.3 13.9 14.6 13.3 14.0
3.34 14.7
15.4 14.1 14.8 13.5 14.1
3.38 14.9
15.6 14.2 14.9 13.7 14.3
3.41 15.1
15.7 14.4 15.1 13.8 14.4
3.45 15.3
15.9 14.6 15.2 14.0 14.6
3.48 15.4
16.1 14.8 15.4 14.1 14.7
3.52 15.6
16.2 14.9 15.5 14.3 14.9
3.55 15.8
16.4 15.1 15.7 14.5 15.0
3.59 16.0
16.5 15.3 15.8 14.7 15.2
3.62 16.2
16.7 15.5 16.0 14.8 15.3
3.66 16.4
16.9 15.6 16.1 15.0 15.5
3.69 16.5
17.0 15.8 16.3 15.2 15.6
3.73 16.7
17.2 16.0 16.5 15.3 15.8
3.76 16.9
17.4 16.2 16.6 15.5 15.9
3.80 17.1
17.5 16.4 16.8 15.7 16.1
3.84 17.3
17.7 16.6 16.9 15.9 16.2
3.87 17.5
17.9 16.7 17.1 16.0 16.4
3.91 17.7
18.0 16.9 17.3 16.2 16.5
1.83
1.85
1.88
1.90
1.93
1.96
1.98
2.01
2.04
2.07
2.09
2.12
2.15
2.18
2.21
2.24
2.27
2.30
2.33
2.36
2.39
2.42
2.45
2.49
2.52
2.55
2.58
2.62
2.65
2.68
2.72
2.75
2.79
2.82
2.86
2.89
2.93
2.96
3.00
3.04
3.07
3.11
3.15
3.19
3.22
3.26
3.30
3.34
3.38
3.42
3.46
3.50
3.54
3.58
3.62
3.66
3.71
3.75
3.79
3.83
3.88 3.95 17.9
18.2 17.1 17.4 16.4 16.7
4-2-2. PUMY-P125VHM
*Before calculating the sum of total capacity of indoor units,please convert the value into the kW model capacity
following the formula on 4-1-1.
OC376A--1.qxp 06.8.25 11:04 AM Page 11

12
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/ 220V Current(A)/ 230V Current(A)/ 240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
131 13.10 14.88
132 13.20 15.00
133 13.30 15.13
134 13.40 15.25
135 13.50 15.38
136 13.60 15.50
137 13.70 15.63
138 13.80 15.75
139 13.90 15.88
140 14.00 16.00
141 14.02 16.01
142 14.04 16.02
143 14.06 16.03
144 14.08 16.04
145 14.10 16.06
146 14.12 16.07
147 14.15 16.08
148 14.17 16.09
149 14.19 16.10
150 14.21 16.12
151 14.23 16.13
152 14.25 16.14
153 14.27 16.15
154 14.30 16.16
155 14.32 16.17
156 14.34 16.19
157 14.36 16.20
158 14.38 16.21
159 14.40 16.22
160 14.42 16.23
161 14.45 16.25
162 14.47 16.26
163 14.49 16.27
164 14.51 16.28
165 14.53 16.29
166 14.55 16.31
167 14.57 16.32
168 14.60 16.33
169 14.62 16.34
170 14.64 16.35
171 14.66 16.36
172 14.68 16.38
173 14.70 16.39
174 14.72 16.40
175 14.75 16.41
176 14.77 16.42
177 14.79 16.44
178 14.81 16.45
179 14.83 16.46
180 14.85 16.47
181 14.87 16.48
182 14.89 16.50
3.92 3.98 18.1 18.4 17.3 17.6 16.6 16.9
3.96 4.02 18.3 18.6 17.5 17.8 16.8 17.0
4.01 4.06 18.5 18.7 17.7 17.9 17.0 17.2
4.05 4.10 18.7 18.9 17.9 18.1 17.1 17.3
4.09 4.14 18.9 19.1 18.1 18.3 17.3 17.5
4.14 4.17 19.1 19.3 18.3 18.4 17.5 17.7
4.18 4.21 19.3 19.4 18.5 18.6 17.7 17.8
4.23 4.25 19.5 19.6 18.7 18.8 17.9 18.0
4.27 4.29 19.7 19.8 18.9 18.9 18.1 18.1
4.32 4.33 20.0 20.0 19.1 19.1 18.3 18.3
4.33 4.32 20.0 19.9 19.1 19.1 18.3 18.3
4.33 4.31 20.0 19.9 19.1 19.0 18.3 18.2
4.33 4.30 20.0 19.8 19.1 19.0 18.3 18.2
4.33 4.28 20.0 19.8 19.1 18.9 18.3 18.1
4.33 4.27 20.0 19.7 19.2 18.9 18.4 18.1
4.34 4.26 20.0 19.7 19.2 18.8 18.4 18.0
4.34 4.25 20.0 19.6 19.2 18.7 18.4 18.0
4.34 4.23 20.1 19.5 19.2 18.7 18.4 17.9
4.34 4.22 20.1 19.5 19.2 18.6 18.4 17.9
4.35 4.21 20.1 19.4 19.2 18.6 18.4 17.8
4.35 4.20 20.1 19.4 19.2 18.5 18.4 17.8
4.35 4.19 20.1 19.3 19.2 18.5 18.4 17.7
4.35 4.17 20.1 19.3 19.2 18.4 18.4 17.7
4.35 4.16 20.1 19.2 19.2 18.4 18.4 17.6
4.36 4.15 20.1 19.1 19.3 18.3 18.4 17.5
4.36 4.14 20.1 19.1 19.3 18.3 18.5 17.5
4.36 4.12 20.1 19.0 19.3 18.2 18.5 17.4
4.36 4.11 20.2 19.0 19.3 18.2 18.5 17.4
4.37 4.10 20.2 18.9 19.3 18.1 18.5 17.3
4.37 4.09 20.2 18.9 19.3 18.0 18.5 17.3
4.37 4.08 20.2 18.8 19.3 18.0 18.5 17.2
4.37 4.06 20.2 18.8 19.3 17.9 18.5 17.2
4.37 4.05 20.2 18.7 19.3 17.9 18.5 17.1
4.38 4.04 20.2 18.6 19.3 17.8 18.5 17.1
4.38 4.03 20.2 18.6 19.3 17.8 18.5 17.0
4.38 4.01 20.2 18.5 19.4 17.7 18.6 17.0
4.38 4.00 20.2 18.5 19.4 17.7 18.6 16.9
4.39 3.99 20.3 18.4 19.4 17.6 18.6 16.9
4.39 3.98 20.3 18.4 19.4 17.6 18.6 16.8
4.39 3.97 20.3 18.3 19.4 17.5 18.6 16.8
4.39 3.95 20.3 18.2 19.4 17.5 18.6 16.7
4.39 3.94 20.3 18.2 19.4 17.4 18.6 16.7
4.40 3.93 20.3 18.1 19.4 17.3 18.6 16.6
4.40 3.92 20.3 18.1 19.4 17.3 18.6 16.6
4.40 3.91 20.3 18.0 19.4 17.2 18.6 16.5
4.40 3.89 20.3 18.0 19.5 17.2 18.6 16.5
4.41 3.88 20.4 17.9 19.5 17.1 18.7 16.4
4.41 3.87 20.4 17.9 19.5 17.1 18.7 16.4
4.41 3.86 20.4 17.8 19.5 17.0 18.7 16.3
4.41 3.84 20.4 17.7 19.5 17.0 18.7 16.3
4.42 3.83 20.4 17.7 19.5 16.9 18.7 16.2
4.42 3.82 20.4 17.6 19.5 16.9 18.7 16.2
OC376A--1.qxp 06.8.25 11:04 AM Page 12

13
4-2-3. PUMY-P140VHM
*Before calculating the sum of total capacity of indoor units,please convert the value into the kW model capacity
following the formula on 4-1-1.
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/220V Current(A)/230V Current(A)/240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
80 8.00 9.00 2.35 2.86 10.9 13.2 10.4 12.6 10.0 12.1
81 8.10 9.10 2.38 2.90 11.0 13.4 10.5 12.8 10.1 12.3
82 8.20 9.20 2.41 2.93 11.1 13.5 10.7 13.0 10.2 12.4
83 8.30 9.30 2.44 2.96 11.3 13.7 10.8 13.1 10.3 12.5
84 8.40 9.40 2.48 2.99 11.5 13.8 11.0 13.2 10.5 12.7
85 8.50 9.50 2.51 3.03 11.6 14.0 11.1 13.4 10.6 12.8
86 8.60 9.60 2.54 3.06 11.7 14.1 11.2 13.5 10.8 13.0
87 8.70 9.70 2.57 3.09 11.9 14.3 11.4 13.7 10.9 13.1
88 8.80 9.80 2.61 3.13 12.1 14.5 11.5 13.8 11.1 13.3
89 8.90 9.90 2.64 3.16 12.2 14.6 11.7 14.0 11.2 13.4
90 9.00 10.00 2.67 3.19 12.3 14.7 11.8 14.1 11.3 13.5
91 9.10 10.11 2.71 3.23 12.5 14.9 12.0 14.3 11.5 13.7
92 9.20 10.23 2.74 3.26 12.7 15.1 12.1 14.4 11.6 13.8
93 9.30 10.34 2.77 3.29 12.8 15.2 12.2 14.5 11.7 13.9
94 9.40 10.46 2.81 3.33 13.0 15.4 12.4 14.7 11.9 14.1
95 9.50 10.57 2.84 3.36 13.1 15.5 12.6 14.9 12.0 14.2
96 9.60 10.68 2.88 3.40 13.3 15.7 12.7 15.0 12.2 14.4
97 9.70 10.80 2.91 3.43 13.5 15.9 12.9 15.2 12.3 14.5
98 9.80 10.91 2.95 3.46 13.6 16.0 13.0 15.3 12.5 14.7
99 9.90 11.03 2.98 3.50 13.8 16.2 13.2 15.5 12.6 14.8
100 10.00 11.14 3.02 3.53 14.0 16.3 13.4 15.6 12.8 15.0
101 10.10 11.25 3.05 3.57 14.1 16.5 13.5 15.8 12.9 15.1
102 10.20 11.37 3.09 3.60 14.3 16.6 13.7 15.9 13.1 15.3
103 10.30 11.48 3.13 3.64 14.5 16.8 13.8 16.1 13.3 15.4
104 10.40 11.60 3.16 3.67 14.6 17.0 14.0 16.2 13.4 15.6
105 10.50 11.71 3.20 3.71 14.8 17.1 14.1 16.4 13.6 15.7
106 10.60 11.82 3.24 3.74 15.0 17.3 14.3 16.5 13.7 15.8
107 10.70 11.94 3.27 3.78 15.1 17.5 14.5 16.7 13.9 16.0
108 10.80 12.05 3.31 3.81 15.3 17.6 14.6 16.8 14.0 16.1
109 10.90 12.17 3.35 3.85 15.5 17.8 14.8 17.0 14.2 16.3
110 11.00 12.28 3.39 3.88 15.7 17.9 15.0 17.2 14.4 16.4
111 11.10 12.39 3.43 3.92 15.9 18.1 15.2 17.3 14.5 16.6
112 11.20 12.51 3.46 3.95 16.0 18.3 15.3 17.5 14.7 16.7
113 11.30 12.63 3.50 3.99 16.2 18.4 15.5 17.6 14.8 16.9
114 11.40 12.75 3.54 4.03 16.4 18.6 15.7 17.8 15.0 17.1
115 11.50 12.88 3.58 4.06 16.5 18.8 15.8 17.9 15.2 17.2
116 11.60 13.00 3.62 4.10 16.7 18.9 16.0 18.1 15.3 17.4
117 11.70 13.13 3.66 4.13 16.9 19.1 16.2 18.3 15.5 17.5
118 11.80 13.25 3.70 4.17 17.1 19.3 16.4 18.4 15.7 17.7
119 11.90 13.38 3.74 4.21 17.3 19.5 16.5 18.6 15.8 17.8
120 12.00 13.50 3.78 4.24 17.5 19.6 16.7 18.7 16.0 18.0
121 12.10 13.63 3.82 4.28 17.7 19.8 16.9 18.9 16.2 18.1
122 12.20 13.75 3.86 4.32 17.8 20.0 17.1 19.1 16.4 18.3
123 12.30 13.88 3.90 4.35 18.0 20.1 17.2 19.2 16.5 18.4
124 12.40 14.00 3.95 4.39 18.3 20.3 17.5 19.4 16.7 18.6
125 12.50 14.13 3.99 4.43 18.4 20.5 17.6 19.6 16.9 18.8
126 12.60 14.25 4.03 4.46 18.6 20.6 17.8 19.7 17.1 18.9
127 12.70 14.38 4.07 4.50 18.8 20.8 18.0 19.9 17.2 19.1
128 12.80 14.50 4.12 4.54 19.0 21.0 18.2 20.1 17.5 19.2
129 12.90 14.63 4.16 4.58 19.2 21.2 18.4 20.2 17.6 19.4
130 13.00 14.75 4.20 4.61 19.4 21.3 18.6 20.4 17.8 19.5
131 13.10 14.88 4.24 4.65 19.6 21.5 18.7 20.6 18.0 19.7
132 13.20 15.00 4.29 4.69 19.8 21.7 19.0 20.7 18.2 19.9
133 13.30 15.13 4.33 4.73 20.0 21.9 19.1 20.9 18.3 20.0
134 13.40 15.25 4.38 4.77 20.2 22.0 19.4 21.1 18.6 20.2
135 13.50 15.38 4.42 4.80 20.4 22.2 19.5 21.2 18.7 20.3
136 13.60 15.50 4.46 4.84 20.6 22.4 19.7 21.4 18.9 20.5
137 13.70 15.63 4.51 4.88 20.8 22.6 19.9 21.6 19.1 20.7
138 13.80 15.75 4.55 4.92 21.0 22.7 20.1 21.7 19.3 20.8
139 13.90 15.88 4.60 4.96 21.3 22.9 20.3 21.9 19.5 21.0
140 14.00 16.00 4.64 5.00 21.4 23.1 20.5 22.1 19.7 21.2
141 14.10 16.13 4.69 5.03 21.7 23.2 20.7 22.2 19.9 21.3
142 14.20 16.26 4.74 5.07 21.9 23.4 21.0 22.4 20.1 21.5
143 14.30 16.40 4.78 5.11 22.1 23.6 21.1 22.6 20.3 21.6
144 14.40 16.53 4.83 5.15 22.3 23.8 21.4 22.8 20.5 21.8
145 14.50 16.66 4.87 5.19 22.5 24.0 21.5 22.9 20.6 22.0
OC376A--1.qxp 06.8.25 11:04 AM Page 13

14
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/220V Current(A)/230V Current(A)/240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
146 14.60 16.80 4.92 5.23 22.7 24.2 21.7 23.1 20.8 22.2
147 14.70 16.93 4.97 5.27 23.0 24.4 22.0 23.3 21.1 22.3
148 14.80 17.06 5.02 5.31 23.2 24.5 22.2 23.5 21.3 22.5
149 14.90 17.20 5.06 5.35 23.4 24.7 22.4 23.6 21.4 22.7
150 15.00 17.33 5.11 5.39 23.6 24.9 22.6 23.8 21.6 22.8
151 15.10 17.46 5.16 5.43 23.8 25.1 22.8 24.0 21.9 23.0
152 15.20 17.60 5.21 5.47 24.1 25.3 23.0 24.2 22.1 23.2
153 15.30 17.73 5.26 5.51 24.3 25.5 23.3 24.4 22.3 23.3
154 15.40 17.86 5.31 5.55 24.5 25.6 23.5 24.5 22.5 23.5
155 15.50 18.00 5.35 5.58 24.7 25.8 23.6 24.7 22.7 23.6
156 15.51 18.01 5.35 5.57 24.7 25.7 23.7 24.6 22.7 23.6
157 15.52 18.02 5.35 5.55 24.7 25.7 23.7 24.5 22.7 23.5
158 15.54 18.04 5.36 5.54 24.8 25.6 23.7 24.5 22.7 23.5
159 15.55 18.05 5.36 5.52 24.8 25.5 23.7 24.4 22.7 23.4
160 15.57 18.06 5.36 5.51 24.8 25.5 23.7 24.4 22.7 23.3
161 15.58 18.07 5.37 5.49 24.8 25.4 23.7 24.3 22.7 23.3
162 15.60 18.09 5.37 5.48 24.8 25.3 23.7 24.2 22.7 23.2
163 15.61 18.10 5.37 5.47 24.8 25.3 23.7 24.2 22.8 23.2
164 15.62 18.11 5.37 5.45 24.8 25.2 23.8 24.1 22.8 23.1
165 15.64 18.12 5.38 5.44 24.8 25.1 23.8 24.0 22.8 23.0
166 15.65 18.14 5.38 5.42 24.9 25.1 23.8 24.0 22.8 23.0
167 15.67 18.15 5.38 5.41 24.9 25.0 23.8 23.9 22.8 22.9
168 15.68 18.16 5.38 5.39 24.9 24.9 23.8 23.8 22.8 22.8
169 15.70 18.17 5.39 5.38 24.9 24.9 23.8 23.8 22.8 22.8
170 15.71 18.19 5.39 5.36 24.9 24.8 23.8 23.7 22.8 22.7
171 15.73 18.20 5.39 5.35 24.9 24.7 23.8 23.6 22.8 22.7
172 15.74 18.21 5.40 5.34 24.9 24.7 23.9 23.6 22.9 22.6
173 15.76 18.22 5.40 5.32 24.9 24.6 23.9 23.5 22.9 22.5
174 15.77 18.24 5.40 5.31 25.0 24.5 23.9 23.5 22.9 22.5
175 15.79 18.25 5.40 5.29 25.0 24.5 23.9 23.4 22.9 22.4
176 15.80 18.26 5.41 5.28 25.0 24.4 23.9 23.3 22.9 22.4
177 15.81 18.27 5.41 5.26 25.0 24.3 23.9 23.3 22.9 22.3
178 15.83 18.29 5.41 5.25 25.0 24.3 23.9 23.2 22.9 22.2
179 15.84 18.30 5.41 5.23 25.0 24.2 23.9 23.1 22.9 22.2
180 15.86 18.31 5.42 5.22 25.0 24.1 23.9 23.1 23.0 22.1
181 15.87 18.32 5.42 5.21 25.0 24.1 24.0 23.0 23.0 22.1
182 15.89 18.34 5.42 5.19 25.1 24.0 24.0 22.9 23.0 22.0
183 15.90 18.35 5.43 5.18 25.1 23.9 24.0 22.9 23.0 21.9
184 15.92 18.36 5.43 5.16 25.1 23.9 24.0 22.8 23.0 21.9
185 15.93 18.37 5.43 5.15 25.1 23.8 24.0 22.8 23.0 21.8
186 15.95 18.39 5.43 5.13 25.1 23.7 24.0 22.7 23.0 21.7
187 15.96 18.40 5.44 5.12 25.1 23.7 24.0 22.6 23.0 21.7
188 15.97 18.41 5.44 5.10 25.1 23.6 24.0 22.6 23.0 21.6
189 15.99 18.42 5.44 5.09 25.2 23.5 24.1 22.5 23.1 21.6
190 16.00 18.44 5.45 5.07 25.2 23.5 24.1 22.4 23.1 21.5
191 16.02 18.45 5.45 5.06 25.2 23.4 24.1 22.4 23.1 21.4
192 16.03 18.46 5.45 5.05 25.2 23.3 24.1 22.3 23.1 21.4
193 16.05 18.47 5.45 5.03 25.2 23.3 24.1 22.2 23.1 21.3
194 16.06 18.49 5.46 5.02 25.2 23.2 24.1 22.2 23.1 21.3
195 16.08 18.50 5.46 5.00 25.2 23.1 24.1 22.1 23.1 21.2
196 16.09 18.51 5.46 4.99 25.2 23.1 24.1 22.1 23.1 21.1
197 16.11 18.52 5.46 4.97 25.3 23.0 24.2 22.0 23.1 21.1
198 16.12 18.54 5.47 4.96 25.3 22.9 24.2 21.9 23.2 21.0
199 16.14 18.55 5.47 4.94 25.3 22.9 24.2 21.9 23.2 20.9
200 16.15 18.56 5.47 4.93 25.3 22.8 24.2 21.8 23.2 20.9
201 16.16 18.57 5.48 4.92 25.3 22.7 24.2 21.7 23.2 20.8
202 16.18 18.59 5.48 4.90 25.3 22.7 24.2 21.7 23.2 20.8
203 16.19 18.60 5.48 4.89 25.3 22.6 24.2 21.6 23.2 20.7
204 16.21 18.61 5.48 4.87 25.3 22.5 24.2 21.5 23.2 20.6
205 16.22 18.62 5.49 4.86 25.4 22.5 24.3 21.5 23.2 20.6
206 16.24 18.64 5.49 4.84 25.4 22.4 24.3 21.4 23.3 20.5
207 16.25 18.65 5.49 4.83 25.4 22.3 24.3 21.3 23.3 20.5
208 16.27 18.66 5.49 4.81 25.4 22.3 24.3 21.3 23.3 20.4
OC376A--1.qxp 06.8.25 11:04 AM Page 14

15
4-3. CORRECTING COOLING AND HEATING CAPACITY
4-3-1. Correcting Changes in Air Conditions
(1)The performance curve charts (Figure 1, 2) show the change ratio of capacity and input (power consumption) according to the
indoor and outdoor temperature condition when define the rated capacity (total capacity) and rated input under the standard
condition in standard piping length (5m) as “1.0”.
• Standard conditions:
• Use the rated capacity and rated input given in “4-2.”.
• The input is the single value on the side of the outdoor unit; the input on the sides of each indoor unit must be
added to obtain the total input.
(2)The capacity of each indoor unit may be obtained by multiplying the total capacity obtained in (1) by the ratio between the
individual capacity at the rated time and the total capacity at the rated time.
individual capacity at the rated time
Individual capacity under stated conditions = total capacity under the stated conditions ototal capacity at the rated time
Rated cooling capacity
Rated heating capacity
Indoor D.B. 27°C / W.B. 19°C
Outdoor D.B. 35°C
Indoor D.B. 20°C
Outdoor D.B. 7°C / W.B. 6°C
(3)Capacity correction factor curve
Figure 1. PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
Cooling performance curve
0.4-5 0 10 20 30 40 46
0.6
0.8
1.0
1.2
1.4
0.6
0.8
1.0
1.2
1.4
22
20
18
16
22
20
18
16
0.6
0.4
0.8
1.0
1.2
1.4
0.4
0.6
0.8
1.0
1.2
1.4
-10-15 -5 0 5 10 15
20
25
15
20
25
15
Cooling
Capacity
(ratio)
Cooling
Power
consumption
(ratio)
Heating
Power
consumption
(ratio)
Heating
Capacity
(ratio)
INDOOR
<D.B. :>
INDOOR
<W.B. :>
INDOOR
<W.B. :>
INDOOR
<D.B. :>
Outdoor <D.B. ::>Outdoor <W.B. ::>
Figure 2. PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
Heating performance curve
OC376A--1.qxp 06.8.25 11:04 AM Page 15

16
4-3-2. Correcting Capacity for Changes in the Length of Refrigerant Piping
(1) During cooling, to obtain the ratio (and the equivalent piping length) of the outdoor units rated capacity and the total
in-use indoor capacity, first find the capacity ratio corresponding to the standard piping length from Figure 3,
and then multiply by the cooling capacity from Figure 1 to obtain the actual capacity.
(2) During heating, to find the equivalent piping length, first find the capacity ratio corresponding to standard piping length
from Figure 3, and then multiply by the heating capacity from Figure 2 to obtain the actual capacity.
(2) Method for Obtaining the Equivalent Piping Length
Equivalent length for type P100·125·140 = (length of piping to farthest indoor unit) + (0.3 onumber of bends in the piping) (m)
Length of piping to farthest indoor unit: type P100~P140.....80m
4-3-3. Correction of Heating Capacity for Frost and Defrosting
If heating capacity has been reduced due to frost formation or defrosting, multiply the capacity by the appropriate correction
factor from the following table to obtain the actual heating capacity.
Correction factor diagram
6
1.0 -10 0.95
-8
0.95
-6
0.95
-4
0.9
-2
0.89
0
0.88
2
0.89
4
0.98
Outdoor Intake temperature (W.B.°C)
Correction factor
(1) Capacity CORRECTION CURVE (Figure 3)
Cooling
Heating
100
95
90
85
80
75
70 5 101520253035404550556065707580
Cooling P100 model
Heating P100, 125, 140
models
Cooling P125 model
Cooling P140 model
Capacity ratio [%]
Corrected pipe length
OC376A--1.qxp 06.8.25 11:04 AM Page 16

17
4-4. NOISE CRITERION CURVES
1.5m
1m
MICROPHONE
UNIT
GROUND
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
BAND CENTER FREQUENCIES, Hz
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
PUMY-P100VHM
COOLING
MODE
HEATING
49
SPL(dB)
51
LINE
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
BAND CENTER FREQUENCIES, Hz
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
PUMY-P125VHM
COOLING
MODE
HEATING
50
SPL(dB)
52
LINE
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
BAND CENTER FREQUENCIES, Hz
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
PUMY-P140VHM
COOLING
MODE
HEATING
51
SPL(dB)
53
LINE
OC376A--1.qxp 06.8.25 11:04 AM Page 17

18
5OUTLINES AND DIMENSIONS
45 40
65 92
27 55
23 73 63
Rear piping hole (Knock-Out)
Rear trunking hole (Knock-Out)
Power supply wiring hole (2-[27Knock-Out)
19 55
92
75 40
73 63
23 27 92
Right piping hole (Knock-Out) Right trunking hole
(Knock-Out)
Power supply wiring hole (2-[27Knock-Out)
n92
92 65
4540
27 55
23 73 63
Front piping hole (Knock-Out)
Front trunking hole (Knock-Out)
Power supply wiring hole (2-[27Knock-Out)
n92
14514522030 145
81 219
71
71
Bottom piping hole (Knock-Out)
Drain hole (5-[33)
600175 175
28 370
70
56
42
56
37
19
53
417
330
Installation Feet
2-12o36 Oval holes (Foundation Bolt M10)
2-U Shaped notched holes (Foundation Bolt M10)
30
1088
322
635371
950
23
1350
w1 423
w1 507
Handle for moving
1
2
Ground for the power supply ("GR"marking position)
Ground for the transmission line Ground for concentration control
Terminal block
Left·········For the power supply Center····For the transmission line Right·······For concentration control
( )
Less than
Over
Over Over
Over
Handle for moving
Side Air Intake
Front piping cover
Rear piping cover
Air intake
Rear Air Intake
Handle for moving
Handle for moving
Service panel
Handle for moving
The diagram below shows a basic example. Explantion of particular details are given in the installation manuals etc.
Dimensions of space needed for service access are shown in the below diagram.
<Foundation bolt height>
Please secure the unit firmly with 4 foundation (M10) bolts.(Bolts and washers must be purchased locally.)
Air Discharge
Rear Air Intake
Side Air Intake
1Refrigerant GAS pipe connction(FLARE)[15.88(5/8F)
2Refrigerant LIQUID pipe connection(FLARE)[9.52(3/8F)
w1·····Indication of STOP VALVE connection location.
Example of Notes
Piping Knock-Out Hole Details
1 FREE SPACE (Around the unit) 2 SERVICE SPACE 3 FOUNDATION BOLTS 4 PIPING-WIRING DIRECTIONS
Piping and wiring connections can be made from 4 directions: FRONT,Right,Rear and Below.
30
FOUNDATION
150
500
500
10
Service space
Over 10
Over 10
FREE
Over 150Over 1000
[
92
PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
Unit : mm
OC376A--1.qxp 06.8.25 11:04 AM Page 18

19
6WIRING DIAGRAM
SYMBOL NAME SYMBOL NAME SYMBOL NAMESYMBOL NAME
TB1 Terminal Block <Power Supply>
TB3 Terminal Block <Transmission>
TB7 Terminal Block <Centralized Control>
MC Motor for Compressor
MF1,MF2 Fan Motor
21S4 Solenoid Valve <Four way valve>
SV1 Solenoid Valve <Bypass valve>
TH3
Thermistor <Outdoor Pipe Temperature>
TH4 Thermistor <Discharge Temperature>
TH6
Thermistor <Low Pressure Saturated Temperature>
TH7 Thermistor <Outdoor Temperature>
TH8 Thermistor <Heat sink>
63HS
High Pressure Sensor <Discharge Pressure>
63H High Pressure Switch
63L Low Pressure Switch
CB Main Smoothing Capacitor
ACTM
DCL
Active filter Module
RS Rush Current Protect Resistor
P.B. Power Circuit Board
Connection Terminal <U/V/W-Phase>
U/V/W MULTI.B. Multi Controller Board
Fuse <6.3A>
F1,F2 Fuse <3A>
F500 Switch <Display Selection>
SW1 Switch <Function Selection>
SW2 Switch <Test Run>
SW3 Switch <Model Selection>
SW4 Switch <Function Selection>
SW5 Switch <Function Selection>
SW6 Switch <Function Selection>
SW7 Switch <Function Selection>
SW8
Switch <Unit Address Selection, 1st digit>
SWU1
Switch <Unit Address Selection, 2nd digit>
SWU2 Transformer
TRANS
Digital Indicator <Operation Inspection Display>
LED1,2
LED <Power Supply to Main Microcomputer>
LED3 Connector <Multi System>
CNS1 Connector <Centralized Cotrol>
CNS2
Connector <To Noise Filter Circuit Board>
CNAC Connector <To Noise Filter Circuit>
CNDC Connector <To Power Circuit Board>
CN2 Connector <To Power Circuit Board>
CN4
Connector <Centralized Cotrol Power Supply>
CN40
Connector <For shorting Jumper Connector>
CN41 Connector <Thermistor>
TH3 Connector <Thermistor>
TH4 Connector <Thermistor>
TH7/6 Connector <High Pressure Sensor>
63HS Connector <High Pressure Switch>
63H Connector <Low Pressure Switch>
63L Connector <Fan Motor>
CNF1,CNF2
Connector <Four-way Valve>
21S4 Connector <Bypass Valve>
SV1 Connector <For Option>
SS Connector <For Option>
CN3D Connector <For Option>
CN3S Connector <For Option>
CN3N Connector <For Option>
CN51 Relay
X501~505
M-P.B.
Connector <To Noise Filter Circuit Board>
Transmission Power Board
CN1 Connector <To Multi Controller Board>
CN2
Terminal <L/N-Phase>
TAB-S/T
Terminal <DCVoltage>
TAB-P/P1/P2
Terminal <DCVoltage>
TAB-N/N1/N2
Connector
CN2~5
N.F. Noise Filter Circuit Board
Connection Lead <L-Phase>
LI/LO Connection Lead <N-Phase>
NI/NO
Connection Terminal <Ground>
EI
Connector
CNAC1/2 Connector
CN5
Connector
CNDC Connector
CNAF Inverter
IPM
Light Emitting Diodes <Inverter Control Status>
LED1
Reactor
Bit
Indication
1
Compressor
operated
2
52C
3
21S4
4
SV1
5
(SV2)
6
—
7
—
8
Always lit
• During normal operation
• The LED indicates the drive state of the controller in the outdoor unit.
NOTES:
1.Refer to the wiring diagrams of the indoor units for details on wiring of each indoor unit.
Self-diagnosis function
The indoor and outdoor units can be diagnosed automatically using the self-diagnosis switch (SW1) and LED1, LED2 (LED indication) found
on the multi-controller of the outdoor unit.
LED indication : Set all contacts of SW1 to OFF.
w1 MODEL SELECT
1: ON 0: OFF
MODELS
PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
• When fault requiring inspection has occurred
The LED alternately indicates the inspection code and the location
of the unit in which the fault has occurred.
SW4
123456
0
1
1
1
0
1
0
0
0
0
0
0
1
1
1
0
0
0
Cautions when Servicing
!
• WARNING: When the main supply is turned off, the voltage[340V] in the main capacitor will drop to 20V in approx. 2 minutes (input voltage:240V).
When servicing,make sure that LED1, LED2 on the outdoor circuit board goes out, and then wait for at least 1 minute.
• Components other than the outdoor board may be faulty: Check and take corrective action, referring to the service manual.
Do not replace the outdoor board without checking.
[Example]
When the compressor and
SV1 are turned during cooling
operation.
12345678
1
MF1
4 5 6 7
CN2
(WHT) CN4
(WHT)
CN51
(WHT)
1
MF2
4 5 6 7
52C
(BLK)
3
X505
1
21S4
(GRN)
3 1
SV2
(BLU)
3 1
SV1
(WHT) SS
(WHT)
2 1 212121 3 1
21S4 SV1
7 6 5 4 3 2 1
54321
2 1
LED3
SW6
SW2SW8SW1
SW7SW3SW4
w 1
SW5
SWU2SWU1
TRANS
LED2
88
LED1
88
1 2 1 2 1 23 4
CN3D
(WHT)
1 2 3
1 2 3
CN3S
(RED)
1 2 3
CN3N
(BLU)
1 2 3
3 1
31
CNAC
(RED)
CNS1
(RED) CNS2 (YLW)
123
13
313
12
1
4 5 6
123456
12 12 12 123 4 5 6 7
CNDC
(PIN)
CNAF
(WHT)
CN2
(WHT)
CN3
(WHT)
CN4
(WHT)
CN5
(RED)
CNAC2
(RED)
E I
CN5
(RED)
CNAC1
(WHT)
LO
NO
NILI
TABN1
TABN2
TABP2
TH8
CB
TABN
TABP
TABP1
TABT
DCL
RS
52C
ACTM
TABS
31
TH7TH6 TH3 TH463HS 63H63L
F1
F500
F2
X504 X503 X502 X501
CN102
(WHT)
CN41
(WHT) CN40 (WHT)
4 3 2 1
4 3 2 14 3 2 1
M-P.B.
P. B.
N. F.
3 1
CN2
(WHT)
TP1
CN1
(WHT)
1 2 3 4
M1
M2
S
TB3
TO INDOOR UNIT
CONNECTING WIRES
DC 30V(Non-polar)
FOR CENTRALIZED
CONTROL
DC 30V(Non-polar)
M1
M2
S
TB7
POWER SUPPLY
~/N
AC220/230/240V 50Hz
AC220V 60Hz
TB1
MC
-
+
-
-
+
+
MULTI. B.
CNF1
(WHT) TH7/6
(RED) TH3 (WHT) TH4 (WHT)
63HS
(WHT)
63H
(YLW) 63L
(RED)
CNDC
(PNK)
CNF2
(WHT)
(BRN)
(BRN)
(ORN)
(ORN)
L
N
+
-
+
+
NO FUSE
BREAKER
P
N1
L2 L1
N2
I
U
V
W
~
~
~
~
RED
WHT
BLK
PUMY-P100VHM PUMY-P125VHM PUMY-P140VHM
OC376A--1.qxp 06.8.25 11:04 AM Page 19

20
7NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION
7-1. TRANSMISSION SYSTEM SETUP
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
051
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
056
001
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
010
101
10
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
002
102 104 154
1111
11
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
009
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
008
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
003
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
007
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
006
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
004
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
005
1A transmission wire must be
connected to each refrigerant system (outdoor and indoor).
2Set addresses:
Outdoor unit ..............051-100 Indoor unit .................001-050 Remote controller .....101-200
3PUMY has no 3rd digit switch.
The address automatically become "100" if it is set as "01~50".
Remote controller Remote
controller Remote
controller Remote
controller 105
Remote controller
157
Remote controller
107
Remote controller
For centralized management For remote
controller
Address SW Address SW Address SW Address SW Address SW
Piping
Outdoor unit Outdoor unit
Indoor unit Indoor unit Indoor unit Indoor unit Indoor unit
Indoor unitIndoor unitIndoor unitIndoor unitIndoor unit
Address SW Address SW Address SW Address SW Address SW
Address SWAddress SWAddress SWAddress SWAddress SW
Address SWAddress SW
For centralized management For remote
controller
Transmission wire
2
1
OC376A--1.qxp 06.8.25 11:04 AM Page 20
