SLZ-KF25, KF35, KF50, KF60VA3
INSTALLATION MANUAL
For safe and correct use, please read this manual and the outdoor unit installation manual thoroughly before install-
ing the air-conditioner unit.
English
FOR INSTALLER
BH79A415H01_cover.indd 1 2017/10/31 14:53:49
2
Contents
1. Safety precautions ......................................................................................... 2
2. Selecting the installation location................................................................... 2
3. Installation diagram........................................................................................ 3
4. Installing the indoor unit ................................................................................. 3
5. Refrigerant piping work .................................................................................. 5
6. Drainage piping work ..................................................................................... 7
7. Electrical work................................................................................................ 8
8. Test run ........................................................................................................ 15
9. System control ............................................................................................. 17
10. Installing the grille ........................................................................................ 17
11. Easy maintenance function.......................................................................... 20
1. Safety precautions
• Besuretoread“Safetyprecautions”beforeinstallingtheairconditioner.
• Besuretoobservethecautionsspeciedhereastheyincludeimportant
itemsrelatedtosafety.
• Theindicationsandmeaningsareasfollows.
Warning:
Couldleadtodeath,seriousinjury,etc.
Caution:
Couldleadtoseriousinjuryinparticularenvironmentswhenoperatedincor-
rectly.
• Afterreadingthismanual,besuretokeepittogetherwiththeinstruction
manualinahandyplaceonthecustomer’ssite.
: Indicates a part which must be grounded.
Warning:
Carefullyreadthelabelsaffixedtothemainunit.
Installtheindoorunitatleast2.5mabovefloororgradelevel.
Forappliancesnotaccessibletothegeneralpublic.
Warning:
• Donotinstallitbyyourself(customer).
Incompleteinstallationcouldcauseinjuryduetore,electricshock,theunit
fallingorleakageofwater.Consultthedealerfromwhomyoupurchasedthe
unitorspecialinstaller.
• Installtheunitsecurelyinaplacewhichcanbeartheweightoftheunit.
When installed in an insufcient strong place, the unit could fall causing
injured.
• Usethespeciedwirestoconnecttheindoorandoutdoorunitssecurelyand
attachthewiresrmlytotheterminalboardconnectingsectionssothestress
ofthewiresisnotappliedtothesections.
Incompleteconnectingandxingcouldcausere.
• Donotuseintermediateconnectionofthepowercordortheextensioncord
anddonotconnectmanydevicestooneACoutlet.
Itcouldcauseareoranelectricshockduetodefectivecontact,defective
insulation,exceedingthepermissiblecurrent,etc.
• Checkthattherefrigerantgasdoesnotleakafterinstallationhascompleted.
• Performtheinstallationsecurelyreferringtotheinstallationmanual.
Incomplete installation could cause a personal injury due to re, electric
shock,theunitfallingorleakageofwater.
• Performelectricalworkaccordingtotheinstallationmanualandbesureto
useanexclusivecircuit.
Ifthecapacityofthepowercircuitisinsufcientorthereisincompleteelectri-
calwork,itcouldresultinareoranelectricshock.
• Theusershouldneverattempttorepairtheunitortransferittoanotherloca-
tion.
• Theapplianceshallbeinstalledinaccordancewithnationalwiringregula-
tions.
• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,its
serviceagentorsimilarlyqualiedpersonsinordertoavoidahazard.
• Attachtheelectricalpartcovertotheindoorunitandtheservicepaneltothe
outdoorunitsecurely.
Iftheelectricalpartcoverintheindoorunitand/ortheservicepanelinthe
outdoorunitarenotattachedsecurely,itcouldresultinareoranelectric
shockduetodust,water,etc.
• Besuretousethepartprovidedorspeciedpartsfortheinstallationwork.
Theuseofdefectivepartscouldcauseaninjuryorleakageofwaterduetoa
re,anelectricshock,theunitfalling,etc.
• Ventilatetheroomifrefrigerantleaksduringoperation.
If the refrigerant comes in contact with a ame, poisonous gases will be
released.
• Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
speciedrefrigerant(R410A)tochargetherefrigerantlines.Donotmixitwith
anyotherrefrigerantanddonotallowairtoremaininthelines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressure in the refrigerant line, and may result in an explosion and other
hazards.
Theuseofanyrefrigerantotherthanthatspeciedforthesystemwillcause
mechanical failure or system malfunction or unit breakdown. In the worst
case,thiscouldleadtoaseriousimpedimenttosecuringproductsafety.
Caution:
• Performgrounding.
Donotconnectthegroundwiretoagaspipe,waterpipearresterortelephone
groundwire.Defectivegroundingcouldcauseanelectricshock.
• Donotinstalltheunitinaplacewhereaninammablegasleaks.
Ifgasleaksandaccumulatesintheareasurroundingtheunit,itcouldcause
anexplosion.
• Installagroundleakagebreakerdependingontheinstallationplace(where
itishumid).
If a ground leakage breaker is not installed, it could cause an electric
shock.
• Perform the drainage/piping work securely according to the installation
manual.
Ifthereisadefectinthedrainage/pipingwork,watercoulddropfromtheunit
andhouseholdgoodscouldbewetanddamaged.
• Fastenaarenutwithatorquewrenchasspeciedinthismanual.
Whenfastenedtootight,aarenutmaybrokenafteralongperiodandcause
aleakageofrefrigerant.
• Iftheunitisrunforlonghourswhentheairabovetheceilingisathightem-
perature/highhumidity(dewpointabove26ºC),dewcondensationmaybe
producedintheindoorunitortheceilingmaterials.Whenoperatingtheunits
inthiscondition,addinsulationmaterial(10-20mm)totheentiresurfaceof
theunitandceilingmaterialstoavoiddewcondensation.
2. Selectingtheinstallationlocation
2.1. Indoorunit
• Whereairowisnotblocked.
• Wherecoolairspreadsovertheentireroom.
• Whereitisnotexposedtodirectsunshine.
• Atadistance1mormoreawayfromyourTVandradio(topreventpicturefrom
being distorted or noise from being generated).
• Inaplaceasfarawayaspossiblefromuorescentandincandescentlights(sothe
infrared remote control can operate the air conditioner normally).
• Wheretheairltercanberemovedandreplacedeasily.
Warning:
Mounttheindoorunitintoaceilingstrongenoughtowithstandtheweightof
theunit.
2.2.
Wirelessremotecontrollermounting(ForSLP-2FAL*)
• Placeofmounting
• Whereitiseasytooperateandeasilyvisible.
• Wherechildrencannottouch.
• Mounting
Selectapositionabout1.2mabovetheoor,checkthatsignalsfromtheremote
controlleraresurelyreceivedbytheindoorunitfromthatposition(‘beep’or‘beep-
beep’receivingtonesounds).Afterthat,attachremotecontrollerholdertoapillar
or wall and set the wireless remote controller.
Inrooms whereinverter typeuorescent lampsare used,the signal fromthe
wirelessremotecontrollermaynotbereceived.
Note:
Thephrase“Wiredremotecontroller”inthisinstallationmanualrefersonlytothePAR-33MAA.Ifyouneedanyinformationfortheotherremotecontroller,
pleaserefertoeithertheinstallationmanualorinitialsettingmanualwhichareincludedintheseboxes.
BH79A415H01_en.indd 2 11/10/2017 4:11:47 PM
3
(576) C
(576) C
J
625 D
408
88 525 B
570 A
150
313
576 - 610 C
408
576 - 610 C
625 D
I
570 A
525 B
481
208
245
127
18952
50 - 92
10
*1
37+5
0
K
FEG
3. Installationdiagram
3.1. Indoorunit(Fig.3-1)
ACeiling
BGrille
CObstacle
D Min.1000mm
E Min.500mm(Entireperiphery)
If setting the maintenance space for E,besuretoleaveisaminimumof700mm.
Warning:
Mounttheindoorunitonaceilingstrongenoughtowithstandtheweightof
theunit.
3.2. Outdoorunit
Refer to the outdoor unit installation manual.
(mm)
Fig.3-1
Fig.4-1
4. Installingtheindoorunit
4.2. Ceilingopeningsandsuspensionboltinstallation
locations(Fig.4-2)
Caution:
Installtheindoorunitatleast2.5maboveoororgradelevel.
Forappliancesnotaccessibletothegeneralpublic.
• Usingtheinstallationtemplateandthegauge(suppliedasanaccessorywiththe
grille),makeanopeningintheceilingsothatthemainunitcanbeinstalledasshown
inthediagram.(Themethodforusingthetemplateandthegaugeareshown.)
* Before using, check the dimensions of template and gauge, because they
changeduetouctuationsoftemperatureandhumidity.
* The dimensions of ceiling opening can be regulated within the range shown in
followingdiagram;socenterthemainunitagainsttheopeningofceiling,en-
suringthattherespectiveoppositesidesonallsidesoftheclearancebetween
them becomes identical.
• UseM10(3/8")suspensionbolts.
* Suspensionboltsaretobeprocuredattheeld.
• Installsecurely,ensuringthatthereisnoclearancebetweentheceilingpanel&
grille,andbetweenthemainunit&grille.
AOuter side of main unit
BBolt pitch
CCeiling opening
DOuter side of Grille
EGrille
FCeiling
G Min.500mm(Entireperiphery)
If setting the maintenance space for G,be
suretoleaveisaminimumof700mm.
H Maintenancespace
IFresh air intake
J Angle
K Electriccomponentbox
* Leavethemaintenancespaceattheelectriccomponentboxend.
*1 When installing in an existing ceiling unit location or applying additional heat insulation,
ensure a minimum space of 25 mm.
Fig.4-2
(mm)
24510
625
625
C
D
E
A
B
12
34
5 6
4.1. Checktheindoorunitaccessories(Fig.4-1)
The indoor unit should be supplied with the following accessories.
Accessoryname Q’ty
1Installation template 1
2Washers(withinsulation)
Washers(withoutinsulation)
4
4
3
Pipecover(forrefrigerantpipingjoint)
smalldiameter(liquid)
largediameter(gas)
1
1
4
Band(large)
Band(middle)
Band(small)
6
2
2
5Drain socket 1
6Insulation 1
7.5-24.57.5-24.5
Min.450H
Floor
7.5-24.57.5-24.5
Min.5
Min.2500
Min.450H
BH79A415H01_en.indd 3 11/10/2017 4:11:49 PM
4
J
HI
4. Installingtheindoorunit
4.3. Installationofduct(incaseoffreshairintake)
(Fig.4-3)
Caution:
Linkageofductfanandairconditioner
lncasethataductfanisused,besuretomakeitlinkedwiththeairconditioner
whenoutsideairistaken.
Donotruntheductfanonly.Itcancausedewdrop.
Makingaductange(preparedlocally)
• Theshapeofductangeshownleftisrecommended.
Installationofductange
• Cutoutthecutouthole.Donotknockitout.
• Installaductangetothecutoutholeoftheindoorunitwiththree4×10 tapping
screws which should be prepared locally.
Installationofduct(shouldbepreparedlocally)
• Prepareaductofwhichinnerdiametertsintotheouterdiameteroftheductange.
• Incasethattheenvironmentabovetheceilingishightemperatureandhighhumidity,
wraptheductinaheatinsulatetoavoidcausingdewdroponthewall.
Removethedrainpaninsulation.
A Ductangerecommendedshape
(Thickness:0.8ormore)
B 3-ø5hole
CDetail drawing of fresh air intake
DIndoor unit
ECeiling surface
F 3-Tappingscrewhole
G ø73.4cutouthole
H Ductange(Preparedlocally)
I4 ×10Tappingscrew(Preparedlocally)
JInsulation
4.4. Suspension structure (Give site of suspension
strongstructure)(Fig.4-4)
• Theceilingworkdiffersaccordingtotheconstructionofthebuilding.Buildingcon-
structors and interior decorators should be consulted for details.
(1)Extentofceilingremoval:Theceilingmustbekeptcompletelyhorizontalandthe
ceilingfoundation(framework:woodenslatsandslatholders)mustbereinforced
inordertoprotecttheceilingfromvibration.
(2)Cutandremovetheceilingfoundation.
(3)Reinforcetheendsoftheceilingfoundationwhereithasbeencutandaddceiling
foundation for securing the ends of the ceiling board.
(4)Wheninstallingtheunitonaslantingceiling,interlockapillowbetweentheceiling
andthegrilleandsetsothattheunitisinstalledhorizontally.
1 Woodenstructures
• Usetiebeams(single-storyhouses)orsecondoorbeams(twostoryhouses)as
reinforcing members.
• Woodenbeamsforsuspendingairconditionersmustbesturdyandtheirsidesmust
be at least 6 cm long if the beams are separated by not more than 90 cm and their
sides must be at least 9 cm long if the beams are separated by as much as 180
cm.Thesizeofthesuspensionboltsshouldbeø10(3/8").(Theboltsdonotcome
with the unit.)
2Ferroconcrete structures
Securethesuspensionboltsusingthemethodshown,orusesteelorwoodenhang-
ers,etc.toinstallthesuspensionbolts.
A Unit
BGrille
C Pillow
DCeiling
ERafter
FBeam
GRoof beam
H Useinsertsratedat100-150kg
each(procurelocally)
I SuspensionboltsM10(3/8")(procure
locally)
JSteel reinforcing rod
12
Fig.4-4
A Suspensionbolt(Procurelocally)
BCeiling
C Nut(Procurelocally)
D Washer(withinsulation)(Accessory)
Fig.4-5
4.5. Unitsuspensionprocedures(Fig.4-5)
Suspend the main unit as shown in the diagram.
1. Inadvance,setthepartsontothesuspensionboltsintheorderofthewashers
(withinsulation),washers(withoutinsulation)andnuts(double).
• Fitthewasherwithcushionsothattheinsulationfacesdownward.
• Incaseofusingupperwasherstosuspendthemainunit,thelowerwashers(with
insulation)andnuts(double)aretobesetlater.
2. Lift the unit to the proper height of the suspension bolts to insert the mounting
plate between washers and then fasten it securely.
3. Whenthemainunitcannotbealignedagainstthemountingholeontheceiling,
itisadjustableowingtoaslotprovidedonthemountingplate.(Fig.4-6)
• MakesurethatstepAisperformedwithin37-42mm.Damagecouldresultby
failing to adhere to this range.
4.6. Conrmingthepositionofmainunitandtightening
thesuspensionbolts(Fig.4-7)
• Usingthegaugeattachedtothegrille,ensurethatthebottomofthemainunitis
properlyalignedwiththeopeningoftheceiling.Besuretoconrmthis,otherwise
condensation may form and drip due to air leakage etc.
• Conrmthatthemainunitishorizontallylevelled,usingaleveloravinyltubelled
with water.
• Aftercheckingthepositionofthemainunit,tightenthenutsofthesuspensionbolts
securely to fasten the main unit.
• Theinstallationtemplatecanbeusedasaprotectivesheettopreventdustfrom
entering the main unit when the grilles are left unattached for a while or when the
ceilingmaterialsaretobelinedafterinstallationoftheunitisnished.
* Asforthedetailsoftting,refertotheinstructionsgivenontheInstallationtemplate.
A Mainunit
BCeiling
C Installationtemplate(Accessory)
Fig.4-7
Fig.4-3
(mm)
Fig.4-6
*B:Suspensionboltpitch(seeFig.4-2Bfor details)
E Mountingplate
F Washer(withoutinsulation)(Accessory)
GCheck using the Installation gauge
A Mainunit
BCeiling
C Gauge(Grilleaccessory)
DCeiling opening dimensions
DEFG
*B
*B
37
127
+5
0
A
B
A
C
D
E
F
C
B
G
C
B
A
A
B
C
A C
H
I
B
G
F
D
E
J
120°
120°
120°
60°
ø 100
ø 100
ø 75
15
20
70
140
186
37+5
0 208
576-610D
A=37 +5
0
Min.30
Ductangeconnection
BH79A415H01_en.indd 4 11/10/2017 4:11:50 PM
5
A
B
5. Refrigerantpipingwork
AIndoor unit
BOutdoor unit
ø6.35
SLZ-KF25,KF35:ø9.52
SLZ-KF50:ø12.7
SLZ-KF60:ø15.88
Fig.5-1
5.3. Flaringwork
• Maincauseofgasleakageisdefectinaringwork.
Carryoutcorrectaringworkinthefollowingprocedure.
5.3.1. Pipecutting(Fig.5-2)
• Usingapipecuttercutthecoppertubecorrectly.
5.3.2. Burrsremoval(Fig.5-3)
• Completelyremoveallburrsfromthecutcrosssectionofpipe/tube.
• Puttheendofthecoppertube/pipetodownwarddirectionasyouremoveburrsin
ordertoavoidburrsdropinthetubing.
5.3.3. Puttingnuton(Fig.5-4)
• Removearenutsattachedtoindoorandoutdoorunit,thenputthemonpipe/tube
havingcompletedburrremoval.
(notpossibletoputthemonafteraringwork)
5.3.4. Flaringwork(Fig.5-5)
• Carryoutaringworkusingaringtoolasshownattheright.
Pipediameter
(mm)
Dimension
A(mm)
B +0
-0.4 (mm)
WhenthetoolforR410Aisused
Clutch type
6.35 0-0.5 9.1
9.52 0-0.5 13.2
12.7 0-0.5 16.6
15.88 0-0.5 19.7
Firmlyholdcoppertubeinadieinthedimensionshowninthetableatabove.
aCopper tubes
bGood
cNo good
dTilted
e Uneven
fBurred
Fig.5-2
Fig.5-3
aBurr
b Coppertube/pipe
cSpare reamer
d Pipecutter
Fig.5-4
Fig.5-5
aFlare nut
bCopper tube
aFlaring tool
bDie
cCopper tube
dFlare nut
eYoke
ad
cb
e f
90
d
c
b
a
b
a
a
b
e
b
c
d
c
A
5.2. Refrigerantpipe(Fig.5-1)
Pipingpreparation
• Refrigerantpipesof3,5,7,10and15mareavailableasoptionalitems.
(1)Tablebelowshowsthespecicationsofpipescommerciallyavailable.
Model Pipe Outside diameter Min.wall
thickness
Insulation
thickness
Insulation
material
mm inch
SLZ-KF25
SLZ-KF35
Forliquid 6.35 1/4 0.8 mm 8 mm
Heat resist-
ing foam
plastic 0.045
specic
gravity
For gas 9.52 3/8 0.8 mm 8 mm
SLZ-KF50
Forliquid 6.35 1/4 0.8 mm 8 mm
For gas 12.7 1/2 0.8 mm 8 mm
SLZ-KF60
Forliquid 6.35 1/4 0.8 mm 8 mm
For gas 15.88 5/8 0.8 mm 8 mm
(2)Ensurethatthe2refrigerantpipesarewellinsulatedtopreventcondensation.
(3)Refrigerantpipebendingradiusmustbe100mmormore.
Caution:
Usingcarefulinsulationofspeciedthickness.Excessivethicknessprevents
storagebehindtheindoorunitandsmallerthicknesscausesdewdrippage.
5.1. Precautions
FordevicesthatuseR410Arefrigerant
• Usealkylbenzene oil(small amount)as therefrigeration oilapplied tothe
aredsections.
• UseC1220copperphosphorusforcopperandcopperalloyseamlesspipes,
toconnecttherefrigerantpipes.Userefrigerantpipeswiththethicknesses
specied in the table below. Make sure the insides of the pipes are clean
anddonotcontainanyharmfulcontaminantssuchassulfuriccompounds,
oxidants,debris,ordust.
Warning:
When installing or relocating, or servicing the air conditioner, use only the
specied refrigerant written on outdoor unit to charge the refrigerant lines.
Donotmixitwithanyotherrefrigerantanddonotallowairtoremaininthe
lines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressureintherefrigerantline,andmayresultinanexplosionandotherhaz-
ards.
Theuseofanyrefrigerantotherthanthatspeciedforthesystemwillcause
mechanical failure or system malfunction or unit breakdown. In the worst
case,thiscouldleadtoaseriousimpedimenttosecuringproductsafety.
BH79A415H01_en.indd 5 11/10/2017 4:11:50 PM
6
5. Refrigerantpipingwork
5.5. Pipeconnection(Fig.5-8)
Indoorunit
1) Whenusingcommerciallyavailablecopperpipes:
• Applythinlayerofrefrigerantoiltopipeandjointseatingsurfacebeforetightening
arenut.
• Usetwowrenchestotightenpipingconnections.
• Air-purgetherefrigerantpipingusingyourownrefrigerantgas(don’tair-purgethe
refrigerant charged in the outdoor unit).
• Use leak detector or soapy water to check for gas leaks after connections are
completed.
• Usearednutinstalledtothisindoorunit.
• Incaseofreconnectingtherefrigerantpipesafterdetaching,makethearedpart
ofpipere-fabricated.
• Userefrigerantpipinginsulationprovidedtoinsulateindoorunitconnections.Insulate
carefully following shown below.
2) Heatinsulationforrefrigerantpipes:
1 Wraptheenclosedlarge-sizedpipecoveraroundthegaspipe,makingsurethat
theendofthepipecovertouchesthesideoftheunit.
2 Wraptheenclosedsmall-sizedpipecoveraroundtheliquidpipe,makingsurethat
theendofthepipecovertouchesthesideoftheunit.
3 Securebothendsofeachpipecoverwiththeenclosedbands.(Attachthebands
20mmfromtheendsofthepipecover.)
Makesurethattheslitinthepipecoverisfacingupwardwhenitisinstalled.
Seethatstopvalveonoutdoorunitisfullyshut(unitisshippedwithvalveshut).After
allpipingconnectionsbetweenindoorandoutdoorunithavebeencompleted,vacuum-
purgeairfromsystemthroughtheserviceportforthestopvalveontheoutdoorunit.
Aftercompletingproceduresabove,openoutdoorunitstopvalvesstemfully.This
completes connection of refrigerant circuit between indoor and outdoor units. Stop
valveinstructionsaremarkedonoutdoorunit.
Flarenuttightening
• Applyathincoatofrefrigerationoilontheseatsurfaceofpipe.
• Forconnectionrstalignthecenter,thentightentherst3to4turnsofarenut.
• Usetighteningtorque tablebelowasa guideline forindoorunitside unionjoint
section,andtightenusingtwowrenches.Excessivetighteningdamagestheare
section.
AApplyrefrigeratingmachineoilovertheentireareseatsurface.
BUsecorrectarenutsmeetingthepipesizeoftheoutdoorunit.
CFlarenuttighteningtorque
Copper pipe O.D.
(mm)
Flare nut O.D.
(mm)
Tighteningtorque
(N·m)
ø6.35 17 14-18
ø9.52 22 34-42
ø12.7 26 49-61
ø15.88 29 68-82
Fig.5-8
ARefrigerant pipe and insulating material
(Procurelocally)
B Pipecover(large)(Accessory)
C Pipecover(small)(Accessory)
D Refrigerantpipe(gas)
E Refrigerantpipe(liquid)
F Band(Accessory)
G Cross-sectionalviewofconnection
HRefrigerant pipe
IInsulating material
J Squeeze
Fig.5-9
AFFBCD
E
J
H
I
B,C
F
G
A
B
c
b
a
d e f g h
i
Fig.5-6
B
Fig.5-7
6 196 196
188
133 69
64
A
C
E
F
DB
B(gas)
A(liquid)
5.3.5. Check(Fig.5-6)
• Comparethearedworkwithagureinrightsidehand.
• Ifareisnotedtobedefective,cutoffthearedsectionanddoaringworkagain.
aSmooth all around
bInside is shining without any scratches
f Scratchonaredplane
gCracked
c Evenlengthallaround
dToo much
h Uneven
i Badexamples
eTilted
5.4. Refrigerantanddrainagepipinglocations(Fig.5-7)
ADrain pipe
BCeiling
CGrille
D Refrigerantpipe(liquid)
E Refrigerantpipe(gas)
F Mainunit
Model Dimension
A(liquid) B(gas)
SLZ-KF25
SLZ-KF35 63 mm 72 mm
SLZ-KF50
SLZ-KF60 63 mm 78 mm
C
BH79A415H01_en.indd 6 11/10/2017 4:11:52 PM
7
6. Drainagepipingwork
1. Connectthedrainsocket(suppliedwiththeunit)tothedrainport.(Fig.6-2)
(AfxthetubeusingPVCadhesivethensecureitwithaband.)
2. Installalocallypurchaseddrainpipe(PVCpipe,O.D.ø32).
(AfxthepipeusingPVCadhesivethensecureitwithaband.)
3. Insulatethetubeandpipe.(PVCpipe,O.D.ø32andsocket)
4. Checkthatdrainowssmoothly.
5. Insulatethedrainportwith insulating material,then securethematerialwitha
band.(Bothinsulatingmaterialandbandaresuppliedwiththeunit.)
A Mainunit
BInsulating material
C Band(large)
D Drainport(transparent)
EInsertion margin
F Matching
G Drainpipe(O.D.ø32PVCTUBE)
H Insulatingmaterial(purchasedlocally)
I TransparentPVCpipe
J O.D.ø32PVCTUBE(Slope1/100ormore)
K Band(middle)
LDrain socket
(mm)
Fig.6-2
Fig.6-1
6.1. Drainagepipingwork(Fig.6-1)
• Use VP25 (O. D. ø32 PVC TUBE) for drain piping and provide 1/100 or more
downward slope.
• Besuretoconnectthepipingjointsusingapolyvinyltypeadhesive.
• Observethegureforpipingwork.
• Usetheincludeddrainhosetochangetheextractiondirection.
1Correct piping
2 Wrongpiping
A Insulation(9mmormore)
B Downwardslope(1/100ormore)
CSupport metal
K Airbleeder
LRaised
MOdor trap
Grouped piping
D O.D.ø32PVCTUBE
E Makeitaslargeaspossible
FIndoor unit
G Makethepipingsizelargeforgroupedpiping.
H Downwardslope(1/100ormore)
I O.D.ø38PVCTUBEforgroupedpiping
(9mmormoreinsulation)
J Upto850mm
1
2
AB
C
B
M
L
K
DED
H
I
G
D
F
FF
J
F
B
C
F
K
30 30 30
D E E
L
G
H
I
AA
J
C,K
Max.20m
1.5–2 m
Max.150mm
BH79A415H01_en.indd 7 11/10/2017 4:11:52 PM
8
Indoor unit model SLZ
WiringWireNo.
×size(mm2)
Indoorunit-Outdoorunit *1 3×1.5(polar)
Indoorunit-Outdoorunitearth *1 1×Min.1.5
Indoor unit earth 1×Min.1.5
Remotecontroller-Indoorunit *2 2×0.3(Non-polar)
Circuit rating
Indoorunit(Heater)L-N *3 —
Indoorunit-OutdoorunitS1-S2 *3 230VAC
Indoorunit-OutdoorunitS2-S3 *3 24VDC
Remotecontroller-Indoorunit *3 12VDC
7.1. Indoorunitpowersuppliedfromoutdoorunit
Thefollowingconnectionpatternsareavailable.
Theoutdoorunitpowersupplypatternsvaryonmodels.
S1
S2
L
N
1
2
S1
S2
S3
S3
AB C
D
E
F
G
A Outdoorunitpowersupply
B Earth leakage breaker
C Wiringcircuitbreakerorisolatingswitch
D Outdoor unit
E Indoorunit/outdoorunitconnectingcables
F Remote controller
G Indoor unit
*1.<For25-60outdoorunitapplication>
Max.45m
If 2.5 mm2used,Max.50m
If 2.5 mm2usedandS3separated,Max.80m
*2.Max.500m
(Whenusing2remotecontrollers,themaximumwiringlengthfortheremotecontrollercablesis200m.)
*3.TheguresareNOTalwaysagainsttheground.
S3terminalhas24VDCagainstS2terminal.HoweverbetweenS3andS1,theseterminalsarenotelectricallyinsulatedbythetransformerorotherdevice.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2.
Powersupplycordsandindoorunit/outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedexiblecord.(Design60245IEC57)
3. Installanearthlongerthanothercables.
4. Indoorandoutdoorconnectingwireshavepolarities.Makesuretomatchtheterminalnumber(S1,S2,S3)forcorrectwirings.
5. Wiringforremotecontrollercableshallbeapart(5cmormore)frompowersourcewiringsothatitisnotinuencedbyelectricnoisefrompower
sourcewiring.
1:1 System
Neversplicethepowercableortheindoor-outdoorconnectioncable,otherwiseitmayresultinasmoke,areorcommunicationfailure.
Warning:
7. Electricalwork
BH79A415H01_en.indd 8 11/10/2017 4:11:53 PM
9
7. Electricalwork
Caution:
• Beforeinstallingthegrille,makesurethatthejunctionwireisconnected.
• Ifthegrille hassignalreceiveror i-See sensor,thepack of grilleincludes
junctionwire.
Signalreceiver: CN90
3Di-Seesensor: CN5Y
3Di-Seesensormotor:CN4Z
CN5Y
CN90 CN4Z
Fig.7-3
15
Be sure to connect the remote
controllercable(0.3mm)tothe
locations shown in the diagram.
Secure with a band 4(small)atthe
location shown in the diagram
Secure with a band 4(small)
at the location shown in the
diagram
(Remotecontroller
cable retainer)
Cable strap
12
S1 S2 S3
Fig.7-2
E
B
E
D
C
J
I
G
F
J
7.2. Indoorunit(Fig.7-1)(Fig.7-2)(Fig.7-3)
Workprocedure
1.Loosenthetwoscrewssecuringtheelectriccomponentcover,andthenslideand
removethecover.
2.Route the wires along the wiring routes and through the wire inlets in the electric
componentbox.
(Procurethepowersupplycordandindoor/outdoorunitconnectingcablelocally.)
3.Securelyconnectthepowersupplycordandtheindoor/outdoorunitconnecting
cable to the terminal block.
4.Securethewireswiththecablestrapsinsidetheelectriccomponentbox.
Secure the wires with cable straps as cushioning components so that no stress is
applied to the connecting sections of the terminal block when tension is generated.
5.Installtheelectriccomponentcover.
Makesurethatthewiresdonotgetpinched.
6.Securethewireswiththecablestrapsoutsidetheelectriccomponentbox.
Warning:
• Inserthooktheelectriccomponentcoverintothebentsupportontheelectric
componentboxandattachthecoversecurely.Ifitisattachedincorrectly,it
couldresultinare,electricshockduetodust,water,etc.
• Usethespeciedindoor/outdoorunitconnectingcabletoconnecttheindoor
andoutdoorunitsandxthecabletotheterminalblocksecurelysothatno
stressisappliedtotheconnectingsectionoftheterminalblock.Incomplete
connectionorxingofthecablecouldresultinare.
• Securealloftheindoor/outdoorunitconnectingcableswiththecablestrap
onthesideoftheelectriccomponentbox.
Fig.7-1
A Electriccomponentcover
B Electriccomponentbox
C EntryforIndoor-Outdoorconnectingcable
DEntry for wired remote controller cable
ECable clamp
D
C
F
H
G
A
B
F Indoor/Outdoorunitconnectingterminal
G Wiredremotecontrollerterminal
HIndoor controller
IEarth cable
JCable strap
BH79A415H01_en.indd 9 11/10/2017 4:11:56 PM
10
7. Electricalwork
Fig.7-7
Fig.7-8
B
1
C
A
2
D
Fig.7-6
Fig.7-5
B
C
D
E
Between ribs
7.3. Remotecontroller
7.3.1. Wiredremotecontroller
1)Installingprocedures
Refer to the installation manual that comes with each remote controller for details.
2)Functionselectionofremotecontroller
Iftworemotecontrollersareconnected,setoneto“Main”andtheotherto“Sub”.
For setting procedures, refer to “Function selection of remote controller” in the
operation manual for the indoor unit.
7.3.2. Forwirelessremotecontroller
1)Installationarea
• Areainwhichtheremotecontrollerisnotexposedtodirectsunshine.
• Areainwhichthereisnonearbyheatingsource.
• Areainwhichtheremotecontrollerisnotexposedtocold(orhot)winds.
• Areainwhichtheremotecontrollercanbeoperatedeasily.
• Areainwhichtheremotecontrollerisbeyondthereachofchildren.
2)Installationmethod(Fig.7-7)
1Attachtheremotecontrollerholdertothedesiredlocationusing2tappingscrews.
2Placethelowerendofthecontrollerintotheholder.
ARemote controller BWallCDisplay panel DReceiver
• Thesignalcantraveluptoapproximately7meters(inastraightline)within45
degreestobothrightandleftofthecenterlineofthereceiver.
3)Setting(Clocksetting)(Fig.7-8)
1Insert batteries or press the button with something sharp.
[CLOCK]Aand[:]Bblinks.
2Pressthe button with something sharp.
3Pressthe button to set the time.
Pressthe button to set the Day.
4Pressthe button with something sharp at the end.
[CLOCK]and[:]lighted.
7.2.1.Installingthei-Seesensorandsignalreceiver
Beforeinstallingthegrille,connectthejunctionwiresincludedwiththegrilleacces-
soriesandplacethemintheconnectorbox.
1Removethetwoscrewssecuringthewirecoverofthemainunit,andthenopen
thecover.
2Routethewiresofthei-Seesensorandsignalreceiverthroughthewireinletsin
theelectriccomponentboxasshowninthediagramandaroundthebushingson
thesideofthemainunit.(Fig.7-4)
Whenroutingthewires,opentheclampsecuringthegrillejunctionwire,andthen
securethegrillejunctionwireandthewiresofthei-Seesensorandsignalreceiver
with the clamp.
3Removetheonescrewsecuringtheconnectorboxcover,andthenopenthecover.
(Fig.7-5)
4Placethejunctionwireconnectorintheconnectorbox.
5Installthewirecoverandconnectorboxcover.
Caution:
Wheninstallingthecovers,makesurethatthewiresdonotgetpinched.
Fitthebandsecuringthejunctionwiresbetweentheribsontheconnectorbox
asshowninthediagram.(Fig.7-6)
A Wirecover
B Connectorboxcover
C Connectorbox
D i-Seesensororsignalreceiverleadwire(Grilleaccessory)
EBand
A
Fig.7-4
D
B
A
BH79A415H01_en.indd 10 11/10/2017 4:11:58 PM
11
7. Electricalwork
4-1.Switchingtotheinitialsettingmode
1.Pressthe button 1to stop the air conditioner.
2.Pressthe button 2.
The Function setting screen will be displayed and the function No. Awill
blink.(Fig.7-9)
Pressthe button 4to change the function No.
3.CheckthatfunctionNo.“1”isdisplayed,andthenpressthe button 3.
Thedisplaysettingscreenwillbedisplayed.(Fig.7-10)
4-2.ChangingthetemperatureunitA
Pressthe button 5.
Each time the button 5ispressed,thesettingswitchesbetween and .
: The temperature is displayed in degrees Celsius.
: The temperature is displayed in degrees Fahrenheit.
4-3.ChangingthetimedisplayB
Pressthe button 6.
Each time the button 6ispressed,thesettingswitchesbetween
and .
:Thetimeisdisplayedinthe12-hourformat.
:Thetimeisdisplayedinthe24-hourformat.
4-4.ChangingtheAUTOmodeC
Pressthe button 7.
Each time the button 7ispressed,thesettingswitchesbetween
and .
:TheAUTOmodeoperatesastheusualautomaticmode.
:TheAUTOmodeoperatesusingdualsetpoints.
4-5.ChangingthepairNo.D
Pressthe button 4.
Each time the button 4ispressed,thepairNo.0–3changes.
PairNo.ofwirelessremotecontroller IndoorPCboard
0 Initial setting
1 Cut J41
2 Cut J42
3CutJ41,J42
4-6.ChangingthebacklightsettingE
Pressthe button 8.
Each time the button 8ispressed,thesettingswitchesbetween and
.
: The backlight comes on when a button is pressed.
: The backlight does not come on when a button is pressed.
Fig.7-9 Fig.7-10
A
A
D
E
C
B
7
1
4
2
3
6
5
8
4)Initialsetting
The following settings can be made in the initial setting mode.
Item Setting Fig.7-10
Temperature unit ºC/ºF A
Time display 12-hourformat/24-hourformat B
AUTOmode Singlesetpoint/Dualsetpoint C
PairNo. 0–3 D
Backlight On/Off E
BH79A415H01_en.indd 11 11/10/2017 4:11:59 PM
12
7.4. Functionsettings
7.4.1. Bywiredremotecontroller
1 (Fig.7-11)
• Select“Service”fromtheMainmenu,andpressthe[SELECT]button.
• Select“Functionsetting”withthe[F1]or[F2]button,andpressthe[SELECT]
button.
2 (Fig.7-12)
• Set the indoor unit refrigerant addresses andunit numbers withthe [F1]
through [F4]buttons,andthenpressthe[SELECT]buttontoconrmthecur-
rent setting.
<CheckingtheIndoorunitNo.>
Whenthe [SELECT]buttonispressed,thetargetindoorunitwillstartfanopera-
tion.Iftheunitiscommonor when runningallunits,allindoorunitsforthese-
lected refrigerant address will start fan operation.
3 (Fig.7-13)
• Whendatacollectionfrom the indoorunitsiscompleted,thecurrent settings
appears highlighted. Non-highlighted items indicate that no function settings
aremade.Screenappearancevariesdependingonthe“UnitNo.”setting.
4 (Fig.7-14)
• Usethe[F1]or [F2]buttontomovethecursortoselectthemodenumber,and
change the setting number with the [F3]or [F4]button.
5 (Fig.7-15)
• Whenthesettingsarecompleted,pressthe[SELECT]buttontosendtheset-
ting data from the remote controller to the indoor units.
• Whenthetransmissionissuccessfullycompleted,thescreenwillreturntothe
Function setting screen.
F1 F2 F3 F4
Service menu
Cursor
Main menu:
Test run
Input maintenance info.
Function setting
Check
Self check
F1 F2 F3 F4
Function setting
Cursor Address
Monitor:
Ref. address
Unit No. Grp./1/2/3/4/All
Fig.7-11
Fig.7-13
Fig.7-12
Fig.7-14
F1 F2 F3 F4
Function setting
Cursor Cursor
Request:
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
F1 F2 F3 F4
Function setting
Cursor Cursor
Request:
Ref. address
Mode 7
Mode 8
Mode 9
Mode10
Unit # 1
Fig.7-16
Fig.7-18
Fig.7-17
Fig.7-19
F1 F2 F3 F4
Function setting
Ref. address
Sending data
Fig.7-15
7.4.2. Bywirelessremotecontroller(Fig.7-16,Fig.7-17,Fig.7-18,Fig.
7-19)
1Going to the function select mode
Pressthe button between of 5 seconds.
(Start this operation from the status of remote controller display turned off.)
[CHECK]islightedand"00"blinks.(Fig.7-16)
Pressthe buttontosetthe"50".
Directthewirelessremote controllertowardthereceiverofthe indoor unitand
press the button.
2Setting the unit number
Pressthe button to set unit number A.(Fig.7-17)
Directthewirelessremote controllertowardthereceiverofthe indoor unitand
press the button.
3Select a mode
Pressthe buttontosetModenumberB.(Fig.7-18)
Directthewirelessremote controllertowardthereceiverofthe indoor unitand
press the button.
Currentsettingnumber: 1=1beep(1second)
2=2beep(1secondeach)
3=3beep(1secondeach)
4Selecting the setting number
Usethe button to change the Setting number C.(Fig.7-19)
Directthewirelessremote controllertowardthereceiverofthe indoor unitand
press the button.
5To select multiple functions continuously
Repeat select 3and 4to change multiple function settings continuously.
6Complete function selection
Direct the wireless remote controller toward the sensor of the indoor unit and press
the button.
Note:
MaketheabovesettingsonMr.Slimunitsasnecessary.
• Table1summarizesthesettingoptionsforeachmodenumber.
• Besuretowritedownthesettingsforallfunctionsifanyoftheinitialsettings
hasbeenchangedafterthecompletionofinstallationwork.
A
B
C
7. Electricalwork
BH79A415H01_en.indd 12 11/10/2017 4:12:00 PM
13
7. Electricalwork
7.4.3.Howtosetthexedup/downairdirection
• Onlytheparticularoutletcanbexedtocertaindirectionwiththepro-
cedures below. Once xed, only the set outlet is xed every time air
conditioner is turned on. (Other outlets follow UP/DOWN air direction
setting of the remote controller.)
■ Explanationofword
• "RefrigerantaddressNo."and"UnitNo."arethenumbersgiventoeach
air conditioner.
• "OutletNo."isthenumbergiventoeachoutletofairconditioner.
(Refertotheright.)
• "Up/Downairdirection"isthedirection(angle)tox.
Reset 1
horizontal
2345
Electriccomponentbox
Outlet No. 1
Outlet No. 3 Outlet No. 2
Outlet No. 4
Horizontalairow
Remote controller setting
Theairowdirectionofthisoutlet
iscontrolledbytheairowdirec-
tion setting of remote controller.
Fixedsetting
Theairowdirectionofthisoutletisxed
in particular direction.
* Whenitiscoldbecauseofdirect
airow,theairowdirectioncanbexed
horizontallytoavoiddirectairow.
Downward
Note:
Theoutlet No.isindicated bythe number ofgrooves onbothends ofeach
airoutlet.Settheairdirectionwhilecheckingtheinformationshownonthe
remotecontrollerdisplay.
Airoutletidenticationmarks
Functiontable
Selectunitnumber00[table1]
Mode Settings Modeno. Setting no.
Initial set-
ting
setting
Powerfailureautomaticrecovery Notavailable 01 1
Available *1 2Ο*2
Indoor temperature detecting Indoorunitoperatingaverage
02
1Ο
Setbyindoorunit’sremotecontroller 2
Remotecontroller’sinternalsensor 3
Selectunitnumbers01to03orallunits(AL[wiredremotecontroller]/07[wirelessremotecontroller])
Mode Settings Modeno. Setting no.
Initial set-
ting
setting
Filter sign 100Hr
07
1
2500Hr 2 Ο
Noltersignindicator 3
Fan speed Silent
08
1
Standard 2 Ο
High ceiling 3
Up/downvanesetting Not setting
11
1
Draft-lesssetting(vanesanglesetup1)2Ο
Downwardsetting(vanesanglesetup2)3
3Di-Seesensorpositioning*3 Position1 ("□"stampposition,page19)
12
1
(Position1)2
Position3 ("○"stampposition,page19) 3Ο
Fan speed during the cooling thermostat is OFF Setting fan speed
27
1
Stop 2
Extralow 3Ο
*1Whenthepowersupplyreturns,theairconditionerwillstart3minuteslater.
*2Powerfailureautomaticrecoveryinitialsettingdependsontheconnectingoutdoorunit.
*3Whenthe3Di-Seesensorcornerpanelpositionchanged,changethismode.Refertopage19.
BH79A415H01_en.indd 13 11/10/2017 4:12:01 PM
14
F1 F2 F3 F4
Manual vane angle
Manual vane angle
Select:
Setting
Outlet Angle
Ifalloutletsareselected, willbedisplayedthe
nexttimetheunitgoesintooperation.
Navigatingthroughthescreens
• TogobacktotheMainmenu..........[MENU]button
• Toreturntothepreviousscreen .....[RETURN]button
Thecurrentvanesettingwillappear.
Selectthedesiredoutletsfrom1through4withthe[F1]or[F2]button.
• Outlet:"1","2","3","4",and"1,2,3,4,(alloutlets)"
Pressthe[F3]or[F4]buttontogothroughtheoptionintheorderof"Nosetting(re-
set)","Step1","Step2","Step3","Step4","Step5",and"Draftreduction*".
Select the desired setting.
■Vanesetting
* Draft reduction
Theairowdirectionforthissettingismorehorizontalthantheairowdirectionfor
the“Step1”settinginordertoreduceadraftyfeeling.Thedraftreductioncanbe
setforonly1vane.
Pressthe[SELECT]buttontosavethesettings.
Ascreenwillappearthatindicatesthesettinginformationisbeingtransmitted.
The setting changes will be made to the selected outlet.
The screen will automatically return to the one shown above (step 4) when the
transmission is completed.
Makethesettingsforotheroutlets,followingthesameprocedures.
No setting
Step 3
Draft
reduction*
Step 1
Step 4
Alloutlets
Step 2
Step 5
F1 F2 F3 F4
Manual vane angle
Input display:
Cur. Address Check
Ref. address
Unit No.
Identify unit Check button
Conrmationprocedure
1First,conrmbysetting“Ref.address”to0and“UnitNo.”to1.
• Movethecursorto"Ref.address"or"UnitNo."withthe[F1]buttontoselect.
• Selecttherefrigerantaddressandtheunitnumberfortheunitstowhosevanes
aretobexed,withthe[F2]or[F3]button,andpressthe[SELECT]button.
• Ref.address:Refrigerantaddress
• UnitNo.:1,2,3,4
Pressthe[F4]buttontoconrmtheunit.
2Changethe“UnitNo.”inorderandcheckeachunit.
• Pressthe[F1]buttontoselect“UnitNo.”.
Pressthe[F2]or[F3]buttontochangethe“UnitNo.”totheunitthatyouwant
tocheck,andthenpressthe[F4]button.
• Afterpressingthe[F4]button,waitapproximately15seconds,andthencheck
the current state of the air conditioner.
→Thevaneispointingdownward.→Thisairconditionerisdisplayedonthe
remote controller.
→Alloutletsareclosed.→Pressthe[RETURN]buttonandcontinuetheopera-
tion from the beginning.
→Themessagesshowntotheleftaredisplayed.→Thetargetdevicedoesnot
existatthisrefrigerantaddress.
• Pressthe[RETURN]buttontoreturntotheinitialscreen.
3Changethe“Ref.address”tothenextnumber.
• Refertostep1tochangethe“Ref.address”andcontinuewiththeconrmation.
F1 F2 F3 F4
Manual vane angle
Return:
No communication
Check Unit state.
F1 F2 F3 F4
Manual vane angle
Return:
Ref. address
Unit No.
Function setting for unit
with vane fully open.
7. Electricalwork
BH79A415H01_en.indd 14 11/10/2017 4:12:01 PM
15
8. Testrun
8.1. Beforetestrun
►Aftercompleting installation andthewiringand piping oftheindoorand
outdoorunits,checkforrefrigerantleakage,loosenessinthepowersup-
plyorcontrolwiring,wrongpolarity,andnodisconnectionofonephase
inthesupply.
► Use a 500-volt megohmmeter to check that the resistance between the
powersupplyterminalsandgroundisatleast1.0MΩ.
►Donotcarryoutthistestonthecontrolwiring(lowvoltagecircuit)termi-
nals.
Warning:
Donotusetheairconditioneriftheinsulationresistanceislessthan1.0MΩ.
8.2. Testrun
8.2.1. Usingwiredremotecontroller
■ Makesuretoreadoperationmanualbeforetestrun.(Especiallyitemstosecuresafety)
Step 1 Turnonthepower.
● Remotecontroller:Thesystemwillgointostartupmode,andtheremotecontrollerpowerlamp(green)and“PLEASEWAIT”willblink.Whilethelampandmessage
areblinking,theremotecontrollercannotbeoperated.Waituntil“PLEASEWAIT”isnotdisplayedbeforeoperatingtheremotecontroller.Afterthepoweristurnedon,
“PLEASEWAIT”willbedisplayedforapproximately2minutes.
● Indoorcontrollerboard:LED1willbelitup,LED2willbelitup(iftheaddressis0)oroff(iftheaddressisnot0),andLED3willblink.
● Outdoorcontrollerboard:LED1(green)andLED2(red)willbelitup.(Afterthestartupmodeofthesystemnishes,LED2willbeturnedoff.)Iftheoutdoorcontroller
boardusesadigitaldisplay,[-]and[-]willbedisplayedalternatelyeverysecond.
Iftheoperationsdonotfunctioncorrectlyaftertheproceduresinstep2andthereafterareperformed,thefollowingcausesshouldbeconsideredandeliminatedifthey
are found.
(Thesymptomsbelowoccurduringthetestrunmode.“Startup”inthetablemeanstheLEDdisplaywrittenabove.)
Symptomsintestrunmode
Cause
RemoteControllerDisplay OUTDOORBOARDLEDDisplay
<>indicatesdigitaldisplay.
Remotecontrollerdisplays“PLEASEWAIT”,and
cannot be operated.
After “startup” is displayed, only green lights
up.<00>
• After power is turned on, “PLEASE WAIT” is displayed for 2
minutesduringsystemstartup.(Normal)
Afterpoweristurnedon,“PLEASEWAIT”isdis-
playedfor3minutes,thenerrorcodeisdisplayed.
After “startup” is displayed, green(once) and
red(once)blinkalternately.<F1>
• Incorrectconnectionofoutdoorterminalblock(R,S,TandS1,
S2,S3.)
After “startup” is displayed, green(once) and
red(twice)blinkalternately.<F3,F5,F9> • Outdoorunit’sprotectiondeviseconnectorisopen.
Nodisplayappearsevenwhenremotecontroller
operation switch is turned on. (Operation lamp
does not light up.)
After “startup” is displayed, green(twice) and
red(once)blinkalternately.<EA.Eb>
• Incorrectwiringbetweentheindoorandoutdoorunit(Polarityis
wrong for S1,S2,S3.)
• Remotecontrollertransmissionwireshort.
After “startup” is displayed, only green lights
up.<00>
• Thereisnooutdoorunitofaddress0.(Addressisotherthan0.)
• Remotecontrollertransmissionwireopen.
Displayappearsbutsoondisappearsevenwhen
remote controller is operated.
After “startup” is displayed, only green lights
up.<00>
• Aftercancelingfunctionselection,operationisnotpossiblefor
about30seconds.(Normal)
Step2 Switchtheremotecontrollerto“Testrun”.
1 Select“Testrun”fromtheServicemenu,andpressthe[SELECT]button.(Fig.8-1)
2 Select“Testrun”fromtheTestrunmenu,andpressthe[SELECT]button.(Fig.8-2)
3 Thetestrunoperationstarts,andtheTestrunoperationscreenisdisplayed.
F1 F2 F3 F4
Cool
Pipe
Auto
Switch disp.
Mode Fan
RemainTest run
Fig.8-3
F1 F2 F3 F4
unemecivreS
rosruC
:unemniaM
Test run
Input maintenance info.
Function setting
Check
Self check
Fig.8-1
F1 F2 F3 F4
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
Fig.8-2
F1 F2 F3 F4
Remain
Vane
Fig.8-4
Step3 Performthetestrunandchecktheairowtemperatureandautovane.
1 Pressthe[F1]buttontochangetheoperationmode.(Fig.8-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2 Pressthe[SELECT]buttontodisplaytheVaneoperationscreen,andthenpress
the[F1]and[F2]buttonstochecktheautovane.(Fig.8-4)
Pressthe[RETURN]buttontoreturntotheTestrunoperationscreen.
Ifthevanesdonotmove,checkthatthejunctionwireconnectorsareconnected
securely and the connector colors match.
Step4 Conrmtheoperationoftheoutdoorunitfan.
Thespeedoftheoutdoorunitfaniscontrolledinordertocontroltheperformanceoftheunit.Dependingontheambientair,thefanwillrotateataslowspeedandwillkeep
rotatingatthatspeedunlesstheperformanceisinsufcient.Therefore,theoutdoorwindmaycausethefantostoprotatingortorotateintheoppositedirection,butthisis
not a problem.
BH79A415H01_en.indd 15 11/10/2017 4:12:01 PM
16
8. Testrun
Step5 Stopthetestrun.
1Pressthe[ON/OFF]buttontostopthetestrun.(TheTestrunmenuwillappear.)
Note: Ifanerrorisdisplayedontheremotecontroller,seethetablebelow.
Iftheunitisoperatedcontinuouslyduringatestrun,theunitstopsafter2hours.
[OutputpatternA] Errorsdetectedbyindoorunit
Wirelessremotecontroller Wiredremote
controller
Symptom Remark
Beepersounds/OPERATION
INDICATORlampblinks(Num-
ber of times)
Check code
1P1 Intake sensor error
2P2 Pipe(TH2)sensorerror
P9 Pipe(TH5)sensorerror
3E6,E7 Indoor/outdoorunitcommunicationerror
4P4 Drainsensorerror/Floatswitchconnectoropen
5P5 Drain pump error
PA Forced compressor error
6P6 Freezing/Overheatingprotectionoperation
7 EE Communication error between indoor and outdoor units
8P8 Pipetemperatureerror
9 E4 Remotecontrollersignalreceivingerror
10 — —
11 PB(Pb) Indoor unit fan motor error
12 FB(Fb) Indoorunitcontrolsystemerror(memoryerror,etc.)
14 PL Refrigerant circuit abnormal
No sound E0,E3 Remote controller transmission error
No sound E1,E2 Remote controller control board error
No sound – – – – No corresponding
[OutputpatternB] Errorsdetectedbyunitotherthanindoorunit(outdoorunit,etc.)
Wirelessremotecontroller Wiredremote
controller
Symptom Remark
Beepersounds/OPERATION
INDICATORlampblinks(Num-
ber of times)
Check code
1 E9 Indoor/outdoorunitcommunicationerror(Transmittingerror)(Outdoorunit)
Fordetails,checktheLED
display of the outdoor controller
board.
2UP Compressorovercurrentinterruption
3U3,U4 Open/shortofoutdoorunitthermistors
14 PLorOthers Abnormalityofrefrigerantcircuitorothererrors
*1Ifthebeeperdoesnotsoundagainaftertheinitial2beepstoconrmtheself-checkstartsignalwasreceivedandtheOPERATIONINDICATORlampdoesnotcomeon,
there are no error records.
*2Ifthebeepersounds3timescontinuously“beep,beep,beep(0.4+0.4+0.4sec.)”aftertheinitial2beepstoconrmtheself-checkstartsignalwasreceived,thespeci-
edrefrigerantaddressisincorrect.
• Onwirelessremotecontroller
Thecontinuousbuzzersoundsfromreceivingsectionofindoorunit.
Blink of operation lamp
• Onwiredremotecontroller
Check code displayed in the LCD.
• Refertothefollowingtablesfordetailsonthecheckcodes.(Wirelessremotecontroller)
OPERATIONIN-
DICATOR lamp
blinking pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx.2.5sec.
On
Approx.3sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx.2.5sec.
On
Approx.3sec.
On
0.5 sec.
On
0.5 sec.
···Repeated
Number of blinks/beeps in pattern indicates the check
codeinthefollowingtable(i.e.,n=5for“U2”)
Numberofblinks/beepsinpatternindicatesthe
check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Startsignal
received)
Beeper sounds
[OutputpatternB]
OPERATIONIN-
DICATOR lamp
blinking pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx.2.5sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx.2.5sec.
On
0.5 sec.
On
0.5 sec.
···Repeated
Number of blinks/beeps in pattern indicates the check
codeinthefollowingtable(i.e.,n=5for“P5”)
Numberofblinks/beepsinpatternindicatesthe
check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Startsignal
received)
Beeper sounds
[OutputpatternA]
SeethetablebelowforthedetailsoftheLEDdisplay(LED1,2,and3)ontheindoorcontrollerboard.
LED1(microcomputerpowersupply) Indicateswhethercontrolpowerissupplied.MakesurethatthisLEDisalwayslit.
LED2(remotecontrollerpowersupply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is connected
to the outdoor unit that has an address of 0.
LED3(indoor/outdoorunitcommunication) Indicateswhethertheindoorandoutdoorunitsarecommunicating.MakesurethatthisLEDisalwaysblinking.
BH79A415H01_en.indd 16 11/10/2017 4:12:02 PM
17
8. Testrun
B
C
D
A8.4. Checkofdrainage(Fig.8-6)
• Ensurethatthewaterisbeingproperlydrainedoutandthatnowaterisleaking
fromjoints.
Whenelectricworkiscompleted.
• Pourwaterduringcoolingoperationandcheck.
Whenelectricworkisnotcompleted.
• Pourwaterduringemergencyoperationandcheck.
* Drain pump and fan are activated simultaneously when single phase 230 V is
turnedontoS1andS2onterminalblockaftertheconnector(SWE)oncontroller
boardintheelectricalcomponentboxissettoON.
Be sure to turn it back to the former state after work.
Fig.8-6
9. Systemcontrol
Refer to the outdoor unit installation manual.
AWatersupplypump
BWater(about1000cc)
CDrain plug
DPourwaterthroughoutlet
•Be careful not to spray water into
the drain pump mechanism.
8.3. Self-check
■ Refertotheinstallationmanualthatcomeswitheachremotecontrollerfordetails.
1
2 3
Whenequippedwiththesignalreceiver
Whenequippedwiththei-Seesensor
4657
Whenequippedwiththewirelessremotecontroller
890 1
10. Installingthegrille
Fig.10-1
10.1. Checkthegrilleaccessories(Fig.10-1)
• Thegrilleshouldbesuppliedwiththefollowingaccessories.
Accessoryname Q’ty Remark
1Grille 1 625×625(mm)
2Screw with washer 4 M5×0.8×25(mm)
3Gauge 1
4Junction wire for signal re-
ceiver 1Included when equipped with the
signalreceiver.
5Junctionwirefori - Seesensor 1Included when equipped with the
i-Seesensor.
6Fastener 2Included when equipped with the
signalreceiver.
7Fastener 2Included when equipped with the
i-Seesensor.
8Wirelessremotecontroller 1Included when equipped with the
wireless remote controller.
9Remote controller holder 1Included when equipped with the
wireless remote controller.
0LR6AAbatteries 2Included when equipped with the
wireless remote controller.
13.5 × 16 tapping screws 2 Included when equipped with the
wireless remote controller.
45
8
6
23
7
8.2.2. Usingthewirelessremotecontroller
1Turn on the power to the unit at least 12 hours before the test run.
2 Pressthe buttonfor5seconds.(Fig.8-5)
(Performthisoperationwhentheremotecontrollerdisplayisturnedoff.)
3 Pressthe button.
A[TEST]andthecurrentoperationmodearedisplayed.(Fig.8-5)
4 Pressthe button toactivatecool mode,thencheck whethercool airis
blown out from the unit.
5 Pressthe buttontoactivateheatmode,thencheckwhetherwarmairis
blown out from the unit.
6 Pressthe button and check whether the fan speed changes.
7 Pressthe buttonandcheckwhethertheautovaneoperatesproperly.
8 Pressthe
button to stop the test run.
(Aftertwohours,asignalwillbesenttostopthetestrun.)
Note:
• Pointtheremotecontrollertowardstheindoorunitreceiverwhilefollowing
steps 3to 8.
• ItisnotpossibletoperformthetestruninFAN,DRY,orAUTOmode.
Fig.8-5
BH79A415H01_en.indd 17 11/10/2017 4:12:03 PM
18
Fig.10-4
10.2.2.Removingthecornerpanel(Fig.10-4)
• Loosenthescrewfromthecornerofthecornerpanel.Slidethecornerpanelas
indicated by the arrow 1toremovethecornerpanel.
AGrille
BCorner panel
CScrew
A
B
1
C
10. Installingthegrille
Fig.10-5
<Hookisintheraisedposition>
Mainunithook
<Grillehook> 10.3. Installingthegrille
• Pleasepayattentionbecausethereisarestrictionintheattachmentpositionofthe
grille.
10.3.1.Temporarilyinstallingthegrille
• Alignthescrewholesinthecornersofthegrillewiththescrewmountingholesin
thecornersofthemainunit,latchthetwohooksonthegrilleontothedrainpan
projectionsonthemainunit,andtemporarilyhangthegrille.(Fig.10-5)
Caution:
Wheninstallingthei-Seesensorandsignalreceiver,placethejunctionwires
intheconnectorboxbeforetemporarilyhangingthegrille.
Referto7.2.1.onpage10toroutethejunctionwires.
B
A
D
CG
C
Fig.10-7Fig.10-6
10.3.2.Securingthegrille
• Securethegrillebytighteningthefourscrews.(Fig.10-6)
*Makesurethattherearenogapsbetweenthemainunitandthepanelorthepanel
andtheceiling.(Fig.10-7)
A Mainunit
B Electriccomponentbox
C Screwwithwasher(Accessory)
DGrille
ECeiling
F Makesurethattherearenogaps.
GTemporarily hanging hooks on the panel
Caution:
• WhentighteningthescrewwithcaptivewasherC,tightenitatatorqueof4.8
N•morless.Neveruseanimpactscrewdriver.
Itmayresultinpartsdamage.
• Aftertighteningthescrew,conrmthatthetwogrillehooks(Fig.10-5)are
latchedontothehooksonthemainunit.
ED
F
A
10.2. Preparingtoattachthegrille(Fig.10-2)
• Withthegaugesuppliedwiththiskit,adjustandcheckthepositioningoftheunit
relativetotheceiling.Iftheunitisnotproperlypositionedintheceiling,theremay
beairleaks,condensationmayform,ortheup/downvanesmaynotoperatecor-
rectly.
• Makesurethattheopeningintheceilingiswithinthefollowingtolerances:
576 ×576-610×610
• MakesurethatstepAisperformedwithin37-42mm.Damagecouldresultbyfailing
to adhere to this range.
A Mainunit
BCeiling
C Gauge(Accessory)
DCeiling opening dimensions
10.2.1.Removingtheintakegrille(Fig.10-3)
• Slidetheleversinthedirectionindicatedbythearrow1to open the intake grille.
• Unlatchthehookthatsecuresthegrille.
* Do not unlatch the hook for the intake grille.
• Withtheintakegrilleinthe“open”position,removethehingeoftheintakegrille
from the grille as indicated by the arrow 2.
AIntake grille
BGrille
C Intakegrillelevers
DGrille hook
E Holeforthegrille’shook
Fig.10-2
576-610 D
E
112
B
D
A
C
Fig.10-3
A=37 +5
0
BH79A415H01_en.indd 18 11/10/2017 4:12:06 PM
19
10.3.3.Connectingthewires
1Removetheonescrewsecuringtheconnectorboxcover,andthenopenthecover.
2Securelyconnectthejunctionwireconnectorofthevanemotorandthepanelvane
motorwireconnectorintheconnectorbox.(Fig.10-8)
Therearetwovanemotorconnectors:oneblueconnectorandoneorangecon-
nector.Makesurethattheconnectorcolorsmatchwhenconnectingthem.
3Closetheconnectorboxcover.
Whenclosingtheconnectorboxcover,slidethecoverinthedirectionindicatedby
thearrowandmakesurethattheprojectionisrmlyinserted.(Fig.10-9)
A Connectorboxcover
B Connectorbox
CSecuring screw
DJunction connector
E Wireconnectorforthevanemotor
FBand
Caution:
• Placethebandsecuringthepanelvanemotorwireintheconnectorboxas
showninthediagram.(Fig.10-10)
• Whenclosingtheconnectorboxcover,makesurethatthewiresdonotget
pinched.
Fig.10-9Fig.10-8
Fig.10-10
A
C
DB
E
F
E
E
D
F
E
C
10. Installingthegrille
10.3.4.Wiringthei-Seesensorcornerpanelandsignalreceiver
• Installthei-Seesensorandsignalreceiveratthecornersofthepanelattheloca-
tionsstampedwith“○”or“□”.(Thepositionsmaybereversed.)
• Routethei-Seesensorandsignalreceiverwiresthroughthesquareholesatthe
corners of the panel and install them.
• Connectthejunctionwireconnectorandthewireconnectorsofthei-Seesensor
andsignalreceiverintheconnectorbox.
• Closetheconnectorboxcover.
• Securethei-Seesensorandsignalreceiverwirestothepanelwiththefastener
asshowninthediagramsothatthereisnoslackinthewires,andthencutoffthe
excessendofthefastener.(Fig.10-12)
• Placethei-Seesensorandsignalreceiverwirestotheinsideoftheangeonthe
panel.
• Ifthepositionofthei-Seesensorwaschangedfromthe“○”position(E)tothe“□”
position(F),changethefunctionsettings.(Refertopage13.)
Caution:
• Routethei-SeesensorandsignalreceiverwiresasshowninFig.10-13.
• Placetheexcessportionsofthe i-Seesensorandsignalreceiverjunction
wiresintheelectriccomponentboxinthewireclipasshowninthediagram,
andsecurethewirestogetherwiththefastener.(Fig.10-14)
Makesurethatthebandsecuringthei-Seesensorandsignalreceiverjunction
wiresispositionedinsidetheconnectorbox.(Fig.10-15)
• Ifthevanemotorconnectorsandsignalreceiverconnectorareconnected
incorrectly,thevaneswillnotmoveorcommunicationwiththeremotecon-
trollerwillnotbepossible.
A i-Seesensor
B Signalreceiver
CFastener
D Wireclip
E “○”stamp:defaulti-Seesensorposition
F “□”stamp:defaultsignalreceiverposition
B
A
i-Seesensor
or signal
receiver
Vane
Fig.10-13
Fig.10-11
Fig.10-12
Fig.10-14 Fig.10-15
C
D
BH79A415H01_en.indd 19 11/10/2017 4:12:11 PM
20
10.5. Installingtheintakegrille(Fig.10-17)
• Performtheprocedurethatisdescribedin“10.2.Preparingtoattachthegrille”in
reverseordertoinstalltheintakegrilleandthecornerpanel.
ARefrigerant piping of the main unit
BDrain piping of the main unit
CCorner panel
D Positionoftheleversontheintakegrillewhensentfromthefactory.
*Althoughtheclipscanbeinstalledinanyoffourpositions.
E Receiver
10.6. Check
•
Makesurethatthereisnogapbetweentheunitandthegrille,orbetweenthegrille
andthesurfaceoftheceiling.Ifthereisanygapbetweentheunitandthegrille,or
betweenthegrilleandthesurfaceoftheceiling,itmaycausedewtocollect.
• Makesurethatthewireshavebeensecurelyconnected.
• Checkthatallfourvanesmove.Iftwoorfourvanesdonotmove,referto10.3and
check the connections.
• For3Di-Seesensorcornerpanel,checktherotatingmovement.Ifthe3Di-See
sensordoesnotrotate,reviewtheprocedurein“10.3.Installingthegrille”.
Fig.10-17
E
ADB
E
C
10. Installingthegrille
11. Easymaintenancefunction
Maintenancedata,suchastheindoor/outdoorunit’sheatexchangertemperatureandcompressoroperationcurrentcanbedisplayedwith“Smoothmaintenance”.
* Thiscannotbeexecutedduringtestoperation.
* Dependingonthecombinationwiththeoutdoorunit,thismaynotbesupportedbysomemodels.
F1 F2 F3 F4
Check menu
Cursor
Service menu:
Error history
Refrigerant volume check
Refrigerant leak check
Smooth maintenance
Request code
Smooth maintenance
Begin:
Smooth maintenance
Exit:
Ref.address
Stable mode
Cursor
Ref.address
Stable mode
Stabilization→Collecting
Cool / Heat/ Normal
Cool / Heat/ Normal
Address
Smooth maintenance
Return:
Smooth maintenance
Return:
Smooth maintenance
Return:
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
A
Hz
Hr
times
Hr
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
IU air temp.
IU HEX temp.
IU filter time
1
2
3
• Select“Service”fromtheMainmenu,and
pressthe[SELECT]button.
• Select “Check” with the [F1] or [F2] but-
ton,andpressthe[SELECT]button.
• Select“Smoothmaintenance”withthe[F1]
or [F2] button, and press the [SELECT]
button.
Select each item.
• Selecttheitemtobechangedwiththe[F1]or
[F2]button.
• Selecttherequiredsettingwiththe[F3]or[F4]
button.
“Ref.address”setting ............ “0”-“15”
“Stablemode”setting............. “Cool”/“Heat”/
“Normal”
• Pressthe[SELECT]button,xedoperationwill
start.
* “Stablemode”willtakeapprox.20minutes.
The operation data will appear.
The Compressor-Accumulated operat-
ing (COMP. run) time is 10-hour unit,
andtheCompressor-Numberofopera-
tiontimes(COMP.On/Off) isa100-
timeunit(fractionsdiscarded)
Navigatingthroughthescreens
• TogobacktotheMainmenu....................[MENU]button
• Toreturntothepreviousscreen .......... [RETURN]button
Signalreceiver
Fig.10-16
AButton
B Vanemotor
C Up/downvanes
DConnector
C
B
A
D
B
AD
10.4. Lockingtheup/downairowdirection(Fig.10-16)
Thevanesoftheunitcanbesetandlockedinonupordownorientationdepending
upontheenvironmentofuse.
• Setaccordingtothepreferenceofthecustomer.
Theoperation ofthe xed up/downvanes andall automaticcontrolscannot be
performedusingtheremotecontroller.Inaddition,theactualpositionofthevanes
may differ from the position indicated on the remote controller.
1Turn off the main power switch.
Injuriesandoranelectricalshockmayoccurwhilethefanoftheunitisrotating.
2 Disconnecttheconnectorforthevanemotoroftheventthatyouwanttolock.
(Whilepressingthebutton,removetheconnectorinthedirectionindicatedbythe
arrowasshowninthediagram.)Afterremovingtheconnector,insulateitwithtape.
BH79A415H01_en.indd 20 11/10/2017 4:12:12 PM
This manual suits for next models
3
Table of contents
Other Mitsubishi Electric Air Conditioner manuals
Mitsubishi Electric
Mitsubishi Electric ecodan EHPT20Q-VM2EA User manual
Mitsubishi Electric
Mitsubishi Electric City Multi Series User manual
Mitsubishi Electric
Mitsubishi Electric PEAD-A24AA4 User manual
Mitsubishi Electric
Mitsubishi Electric PCA-RP GA Product guide
Mitsubishi Electric
Mitsubishi Electric Mr. Slim PSA-RP KA Series User manual
Mitsubishi Electric
Mitsubishi Electric PAR-FA31MA User manual
Mitsubishi Electric
Mitsubishi Electric MS09NW User manual
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM PEAD-A24AA User manual
Mitsubishi Electric
Mitsubishi Electric PKA-RP HAL User manual
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM SLZ-KF Series User manual
Mitsubishi Electric
Mitsubishi Electric MS-30SV-A1 User manual
Mitsubishi Electric
Mitsubishi Electric PEAD-RP71 User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-FS12NA-U1 User manual
Mitsubishi Electric
Mitsubishi Electric PUHZ-SW75VHAR6 User manual
Mitsubishi Electric
Mitsubishi Electric s-MEXT-G00 006-044 User manual
Mitsubishi Electric
Mitsubishi Electric CITY MULTI PUMY-P-VKM Series User manual
Mitsubishi Electric
Mitsubishi Electric SUZ-SM35VA Operating manual
Mitsubishi Electric
Mitsubishi Electric MSY-GA24NA User manual
Mitsubishi Electric
Mitsubishi Electric MUZ-A09NA User manual
Mitsubishi Electric
Mitsubishi Electric Mr. Slim PSA-RP100KA/PUHZ-P100YKA User manual
