FR-E700
INSTRUCTION MANUAL
INVERTER
PRECAUTIONS FOR USE
OF THE INVERTER
PARAMETERS
TROUBLESHOOTING
PRECAUTIONS FOR
MAINTENANCE AND INSPECTION
SPECIFICATIONS
OUTLINE
WIRING
FR-E720-008(SC) to 600(SC) - NA
FR-E740-016(SC) to 300(SC) - NA
FR-E720S-008 to 110 - NA
FR-E710W-008 to 050 - NA
IB(NA)-0600334ENG-D (1010)MEE Printed in Japan Specifications subject to change without notice.
FR-E700-NA INVERTER INSTRUCTION MANUAL
D

A-1
Thank you for choosing this Mitsubishi Inverter.
This Instruction Manual provides instructions for advanced use of the FR-E700 series inverters.
Incorrect handling might cause an unexpected fault. Before using the inverter, always read this Instruction Manual
and the Installation Guideline [IB-0600333ENG] packed with the product carefully to use the equipment to its
optimum performance.
1. Electric Shock Prevention
2. Fire Prevention
3.Injury Prevention
4. Additional Instructions
Also the following points must be noted to prevent an
accidental failure, injury, electric shock, etc.
(1) Transportation and Mounting
This section is specifically about safety matters
Do not attempt to install, operate, maintain or inspect the
inverter until you have read through the Instruction Manual
and appended documents carefully and can use the
equipment correctly. Do not use this product until you have
a full knowledge of the equipment, safety information and
instructions.
In this Instruction Manual, the safety instruction levels are
classified into "WARNING" and "CAUTION".
Incorrect handling may cause
hazardous conditions, resulting in
death or severe injury.
Incorrect handling may cause
hazardous conditions, resulting in
medium or slight injury, or may cause
only material damage.
The level may even lead to a serious
consequence according to conditions. Both instruction
levels must be followed because these are important to
personal safety.
zWhile power is ON or when the inverter is running, do not
open the front cover. Otherwise you may get an electric
shock.
zDo not run the inverter with the front cover or wiring cover
removed. Otherwise you may access the exposed high-
voltage terminals or the charging part of the circuitry and
get an electric shock.
zEven if power is OFF, do not remove the front cover
except for wiring or periodic inspection. You may
accidentally touch the charged inverter circuits and get an
electric shock.
zBefore wiring or inspection, power must be switched OFF.
To confirm that, LED indication of the operation panel
must be checked. (It must be OFF.) Any person who is
involved in wiring or inspection shall wait for at least 10
minutes after the power supply has been switched OFF
and check that there are no residual voltage using a tester
or the like. The capacitor is charged with high voltage for
some time after power OFF, and it is dangerous.
z This inverter must be earthed (grounded). Earthing
(grounding) must conform to the requirements of national
and local safety regulations and electrical code (NEC section
250, IEC 536 class 1 and other applicable standards).
A neutral-point earthed (grounded) power supply for 400V
class inverter in compliance with EN standard must be used.
zAny person who is involved in wiring or inspection of this
equipment shall be fully competent to do the work.
zThe inverter must be installed before wiring. Otherwise
you may get an electric shock or be injured.
zSetting dial and key operations must be performed with
dry hands to prevent an electric shock.
zDo not subject the cables to scratches, excessive stress,
heavy loads or pinching. Otherwise you may get an
electric shock.
zDo not change the cooling fan while power is ON. It is
dangerous to change the cooling fan while power is ON.
zDo not touch the printed circuit board or handle the
cables with wet hands. Otherwise you may get an electric
shock.
zWhen measuring the main circuit capacitor capacity, the
DC voltage is applied to the motor for 1s at powering OFF.
Never touch the motor terminal, etc. right after powering
OFF to prevent an electric shock.
WARNING
CAUTION
CAUTION
WARNING
zInverter must be installed on a nonflammable wall without
holes (so that nobody touches the inverter heatsink on the
rear side, etc.). Mounting it to or near flammable material
can cause a fire.
zIf the inverter has become faulty, the inverter power must
be switched OFF. A continuous flow of large current could
cause a fire.
zWhen using a brake resistor, a sequence that will turn OFF
power when a fault signal is output must be configured.
Otherwise the brake resistor may overheat due to damage
of the brake transistor and possibly cause a fire.
zDo not connect a resistor directly to the DC terminals P/+
and N/-. Doing so could cause a fire.
zThe voltage applied to each terminal must be the ones
specified in the Instruction Manual. Otherwise burst,
damage, etc. may occur.
zThe cables must be connected to the correct terminals.
Otherwise burst, damage, etc. may occur.
zPolarity must be correct. Otherwise burst, damage, etc.
may occur.
zWhile power is ON or for some time after power-OFF, do
not touch the inverter as they will be extremely hot. Doing
so can cause burns.
zThe product must be transported in correct method that
corresponds to the weight. Failure to do so may lead to
injuries.
zDo not stack the boxes containing inverters higher than
the number recommended.
zThe product must be installed to the position where
withstands the weight of the product according to the
information in the Instruction Manual.
zDo not install or operate the inverter if it is damaged or
has parts missing.
zWhen carrying the inverter, do not hold it by the front
cover or setting dial; it may fall off or fail.
zDo not stand or rest heavy objects on the product.
zThe inverter mounting orientation must be correct.
zForeign conductive objects must be prevented from
entering the inverter. That includes screws and metal
fragments or other flammable substance such as oil.
zAs the inverter is a precision instrument, do not drop or
subject it to impact.
zThe inverter must be used under the following
environment. Otherwise the inverter may be damaged.
Environment
Surrounding
air
temperature
-10°C to +50°C (14°F to 122°F) (non-freezing)
Ambient
humidity 90%RH or less (non-condensing)
Storage
temperature -20°C to +65°C
(-4°F to 149°F) *1
Atmosphere Indoors (free from corrosive gas, flammable gas,
oil mist, dust and dirt)
Altitude/
vibration
Maximum 1000m (3280.80feet) above sea level for
standard operation. After that derate by 3% for
every extra 500m (1640.40feet) up to 2500m
(8202feet) (91%).
5.9m/s2or less at 10 to 55Hz (directions of X, Y, Z
axes)
∗1 Temperature applicable for a short time, e.g. in transit.
CAUTION
CAUTION
CAUTION

A-2
(2) Wiring
(3) Trial run
(4) Usage
(5) Emergency stop
(6) Maintenance, inspection and parts replacement
(7) Disposal
zDo not install a power factor correction capacitor or surge
suppressor/capacitor type filter on the inverter output
side. These devices on the inverter output side may be
overheated or burn out.
zThe connection orientation of the output cables U, V, W to
the motor affects the rotation direction of the motor.
zBefore starting operation, each parameter must be
confirmed and adjusted. A failure to do so may cause
some machines to make unexpected motions.
zAny person must stay away from the equipment when the
retry function is set as it will restart suddenly after trip.
zSince pressing key may not stop output depending
on the function setting status, separate circuit and switch
that make an emergency stop (power OFF, mechanical
brake operation for emergency stop, etc.) must be
provided.
zOFF status of the start signal must be confirmed before
resetting the inverter fault. Resetting inverter alarm with
the start signal ON restarts the motor suddenly.
z
The inverter must be used for three-phase induction motors.
Connection of any other electrical equipment to the
inverter output may damage the equipment.
zDo not modify the equipment.
z
Do not perform parts removal which is not instructed in this
manual. Doing so may lead to fault or damage of the product.
zThe electronic thermal relay function does not guarantee
protection of the motor from overheating. It is
recommended to install both an external thermal and PTC
thermistor for overheat protection.
zDo not use a magnetic contactor on the inverter input for
frequent starting/stopping of the inverter. Otherwise the
life of the inverter decreases.
zThe effect of electromagnetic interference must be
reduced by using a noise filter or by other means.
Otherwise nearby electronic equipment may be affected.
zAppropriate measures must be taken to suppress
harmonics. Otherwise power supply harmonics from the
inverter may heat/damage the power factor correction
capacitor and generator.
zWhen driving a 400V class motor by the inverter, the
motor must be an insulation-enhanced motor or measures
must be taken to suppress surge voltage. Surge voltage
attributable to the wiring constants may occur at the
motor terminals, deteriorating the insulation of the motor.
zWhen parameter clear or all parameter clear is performed,
the required parameters must be set again before starting
operations because all parameters return to the initial value.
zThe inverter can be easily set for high-speed operation.
Before changing its setting, the performances of the
motor and machine must be fully examined.
zStop status cannot be hold by the inverter's brake
function. In addition to the inverter’s brake function, a
holding device must be installed to ensure safety.
zBefore running an inverter which had been stored for a long
period, inspection and test operation must be performed.
zFor prevention of damage due to static electricity, nearby
metal must be touched before touching this product to
eliminate static electricity from your body.
CAUTION
CAUTION
WARNING
CAUTION
zA safety backup such as an emergency brake must be
provided to prevent hazardous condition to the machine
and equipment in case of inverter failure.
zWhen the breaker on the inverter input side trips, the
wiring must be checked for fault (short circuit), and
internal parts of the inverter for a damage, etc. The cause
of the trip must be identified and removed before turning
ON the power of the breaker.
zWhen any protective function is activated, appropriate
corrective action must be taken, and the inverter must be
reset before resuming operation.
zDo not carry out a megger (insulation resistance) test on
the control circuit of the inverter. It will cause a failure.
zThe inverter must be treated as industrial waste.
General instruction
Many of the diagrams and drawings in this Instruction
Manual show the inverter without a cover or partially open
for explanation. Never operate the inverter in this manner.
The cover must be always reinstalled and the instruction in
this Instruction Manual must be followed when operating
the inverter.
CAUTION
CAUTION
CAUTION

I
CONTENTS
1 OUTLINE 1
1.1 Product checking and parts identification ........................................ 2
1.2 Inverter and peripheral devices ......................................................... 3
1.2.1 Peripheral devices .......................................................................................................................... 4
1.3 Removal and reinstallation of the cover............................................ 5
1.3.1 Front cover ..................................................................................................................................... 5
1.3.2 Wiring cover.................................................................................................................................... 7
1.4 Installation of the inverter and enclosure design ............................. 8
1.4.1 Inverter installation environment..................................................................................................... 8
1.4.2 Cooling system types for inverter panel ....................................................................................... 10
1.4.3 Inverter placement........................................................................................................................ 11
2 WIRING 13
2.1 Wiring ................................................................................................ 14
2.1.1 Terminal connection diagram ....................................................................................................... 14
2.2 Main circuit terminal specifications ................................................ 16
2.2.1 Specification of main circuit terminal ............................................................................................ 16
2.2.2 Terminal arrangement of the main circuit terminal, power supply and the motor wiring .............. 16
2.2.3 Cables and wiring length .............................................................................................................. 18
2.3 Control circuit specifications .......................................................... 22
2.3.1 Control circuit terminal.................................................................................................................. 22
2.3.2 Changing the control logic ............................................................................................................ 25
2.3.3 Wiring of control circuit ................................................................................................................. 27
2.3.4 Safety stop function (available only for the safety stop function model)....................................... 31
2.3.5 Connection to the PU connector................................................................................................... 33
2.4 Connection of stand-alone option unit............................................. 35
2.4.1 Connection of a dedicated external brake resistor (MRS type, MYS type, FR-ABR) (FR-E720-
030(SC) or more, FR-E740-016(SC) or more, FR-E720S-030 or more, FR-E710W-030 or more)..
35
2.4.2 Connection of the brake unit (FR-BU2) ........................................................................................ 37
2.4.3 Connection of the high power factor converter (FR-HC) .............................................................. 38
2.4.4 Connection of the power regeneration common converter (FR-CV) ............................................ 39
2.4.5 Connection of the DC reactor (FR-HEL)....................................................................................... 39
3 PRECAUTIONS FOR USE OF THE INVERTER 41
3.1 EMC and leakage currents ............................................................... 42
CONTENTS

II
3.1.1 Leakage currents and countermeasures ...................................................................................... 42
3.1.2 EMC measures............................................................................................................................. 44
3.1.3 Power supply harmonics............................................................................................................... 46
3.2 Installation of power factor improving reactor ................................ 47
3.3 Power-OFF and magnetic contactor (MC) ........................................ 48
3.4 Inverter-driven 400V class motor ..................................................... 49
3.5 Precautions for use of the inverter................................................... 50
3.6 Failsafe of the system which uses the inverter ............................... 52
4 PARAMETERS 55
4.1 Operation panel................................................................................. 56
4.1.1 Names and functions of the operation panel ................................................................................ 56
4.1.2 Basic operation (factory setting) ................................................................................................... 57
4.1.3 Easy operation mode setting (easy setting mode)........................................................................ 58
4.1.4 Changing the parameter setting value.......................................................................................... 59
4.1.5 Setting dial push ........................................................................................................................... 59
4.2 Parameter list.................................................................................... 60
4.2.1 Parameter list................................................................................................................................ 60
4.3 Control mode .................................................................................... 81
4.3.1 Changing the control method (Pr. 80, Pr. 81, Pr. 800) ................................................................ 82
4.4 Adjustment of the output torque (current) of the motor................. 83
4.4.1 Manual torque boost (Pr. 0, Pr. 46) ............................................................................................. 83
4.4.2 Advanced magnetic flux vector control (Pr. 71, Pr. 80, Pr. 81, Pr.89, Pr. 800) .......................... 85
4.4.3 General-purpose magnetic flux vector control (Pr. 71, Pr. 80, Pr. 81, Pr. 800) ........................... 88
4.4.4 Slip compensation (Pr. 245 to Pr. 247) ....................................................................................... 90
4.4.5 Stall prevention operation (Pr. 22, Pr. 23, Pr. 48, Pr. 66, Pr. 156, Pr. 157, Pr. 277) ................... 91
4.5 Limiting the output frequency ......................................................... 95
4.5.1 Maximum/minimum frequency (Pr. 1, Pr. 2, Pr. 18)..................................................................... 95
4.5.2 Avoiding mechanical resonance points (frequency jumps) (Pr. 31 to Pr. 36) .............................. 96
4.6 V/F pattern........................................................................................ 97
4.6.1 Base frequency, voltage (Pr. 3, Pr. 19, Pr. 47) ............................................................................ 97
4.6.2 Load pattern selection (Pr. 14) .................................................................................................... 99
4.7 Frequency setting by external terminals ...................................... 101
4.7.1 Operation by multi-speed operation (Pr. 4 to Pr. 6, Pr. 24 to Pr. 27, Pr. 232 to Pr. 239)........... 101
4.7.2 Jog operation (Pr. 15, Pr. 16) .................................................................................................... 103
4.7.3 Remote setting function (Pr. 59)................................................................................................ 105

III
CONTENTS
4.8 Setting of acceleration/deceleration time and acceleration/
deceleration pattern...................................................................... 108
4.8.1 Setting of the acceleration and deceleration time
(Pr. 7, Pr. 8, Pr. 20, Pr. 21, Pr. 44, Pr. 45, Pr. 147) .................................................................. 108
4.8.2 Starting frequency and start-time hold function (Pr. 13, Pr. 571) .............................................. 111
4.8.3 Acceleration/deceleration pattern (Pr. 29) ................................................................................. 112
4.8.4 Shortest acceleration/deceleration (automatic acceleration/deceleration)
(Pr. 61 to Pr. 63, Pr. 292, Pr. 293) ............................................................................................. 113
4.9 Selection and protection of a motor ............................................. 115
4.9.1 Motor overheat protection (Electronic thermal O/L relay) (Pr. 9, Pr. 51) ................................... 115
4.9.2 Applied motor (Pr. 71, Pr. 450).................................................................................................. 117
4.9.3 Exhibiting the best performance for the motor (offline auto tuning)
(Pr. 71, Pr. 80 to Pr. 84, Pr. 90 to Pr. 94, Pr. 96, Pr. 859) ......................................................... 119
4.10 Motor brake and stop operation.................................................... 127
4.10.1 DC injection brake (Pr. 10 to Pr. 12).......................................................................................... 127
4.10.2 Selection of a regenerative brake (Pr. 30, Pr. 70) ..................................................................... 129
4.10.3 Stop selection (Pr. 250) ............................................................................................................. 131
4.10.4 Stop-on contact control function (Pr. 6, Pr. 48, Pr. 270, Pr. 275, Pr. 276) ................................ 132
4.10.5 Brake sequence function (Pr. 278 to Pr. 283, Pr. 292).............................................................. 134
4.11 Function assignment of external terminal and control................ 138
4.11.1 Input terminal function selection (Pr. 178 to Pr. 184) ................................................................ 138
4.11.2 Inverter output shutoff signal (MRS signal, Pr. 17).................................................................... 140
4.11.3 Condition selection of function validity by second function selection signal (RT) ...................... 141
4.11.4 Start signal operation selection (STF, STR, STOP signal, Pr. 250) .......................................... 142
4.11.5 Output terminal function selection (Pr. 190 to Pr. 192).............................................................. 144
4.11.6 Detection of output frequency (SU, FU signal, Pr. 41 to Pr. 43) ................................................ 148
4.11.7 Output current detection function (Y12 signal, Y13 signal, Pr. 150 to Pr. 153) ......................... 149
4.11.8 Remote output selection (REM signal, Pr. 495 to Pr. 497)........................................................ 151
4.12 Monitor display and monitor output signal ................................... 152
4.12.1 Speed display and speed setting (Pr. 37).................................................................................. 152
4.12.2 Monitor display selection of DU/PU and terminal AM
(Pr. 52, Pr.158, Pr. 170, Pr. 171, Pr. 268, Pr. 563, Pr. 564) ...................................................... 153
4.12.3 Reference of the terminal AM (analog voltage output) (Pr. 55, Pr. 56) ..................................... 158
4.12.4 Terminal AM calibration (calibration parameter Pr. 645, C1 (Pr.901)) ...................................... 159
4.13 Operation selection at power failure and instantaneous power
failure............................................................................................. 161
4.13.1 Automatic restart after instantaneous power failure/flying start
(Pr. 30, Pr. 57, Pr. 58, Pr. 96, Pr. 162, Pr. 165, Pr. 298, Pr. 299, Pr. 611)................................ 161
4.13.2 Power-failure deceleration stop function (Pr. 261) .................................................................... 167
4.14 Operation setting at fault occurrence .......................................... 169
4.14.1 Retry function (Pr. 65, Pr. 67 to Pr. 69) ..................................................................................... 169
4.14.2 Input/output phase loss protection selection (Pr. 251, Pr. 872) ................................................. 171

IV
4.14.3 Earth (ground) fault detection at start (Pr. 249) ......................................................................... 171
4.15 Energy saving operation ................................................................ 172
4.15.1 Optimum excitation control (Pr. 60) ........................................................................................... 172
4.16 Motor noise, EMI measures, mechanical resonance .................... 173
4.16.1 PWM carrier frequency and soft-PWM control (Pr. 72, Pr. 240)................................................ 173
4.16.2 Speed smoothing control (Pr. 653) ............................................................................................ 174
4.17 Frequency setting by analog input (terminal 2, 4) ........................ 175
4.17.1 Analog input selection (Pr. 73, Pr. 267) ..................................................................................... 175
4.17.2 Response level of analog input and noise elimination (Pr. 74).................................................. 177
4.17.3 Bias and gain of frequency setting voltage (current)
(Pr. 125, Pr. 126, Pr. 241, C2 (Pr. 902) to C7 (Pr. 905)) ........................................................... 178
4.18 Misoperation prevention and parameter setting restriction ........ 183
4.18.1 Reset selection/disconnected PU detection/PU stop selection (Pr. 75) .................................... 183
4.18.2 Parameter write disable selection (Pr. 77)................................................................................. 186
4.18.3 Reverse rotation prevention selection (Pr. 78) .......................................................................... 187
4.18.4 Extended parameter display and user group function (Pr. 160, Pr. 172 to Pr. 174) .................. 187
4.18.5 Password function (Pr. 296, Pr. 297)......................................................................................... 190
4.19 Selection of operation mode and operation location.................... 193
4.19.1 Operation mode selection (Pr. 79)............................................................................................. 193
4.19.2 Operation mode at power-ON (Pr. 79, Pr. 340) ......................................................................... 203
4.19.3 Start command source and frequency command source during communication
operation (Pr. 338, Pr. 339, Pr. 550, Pr. 551)............................................................................ 204
4.20 Communication operation and setting .......................................... 210
4.20.1 Wiring and configuration of PU connector ................................................................................. 210
4.20.2 Initial settings and specifications of RS-485 communication
(Pr. 117 to Pr. 120, Pr. 123, Pr. 124, Pr. 549) ........................................................................... 213
4.20.3 Operation selection at communication error occurrence (Pr. 121, Pr. 122, Pr. 502) ................. 214
4.20.4 Communication EEPROM write selection (Pr. 342) .................................................................. 217
4.20.5 Mitsubishi inverter protocol (computer link communication) ...................................................... 218
4.20.6 Modbus-RTU communication specifications
(Pr. 117, Pr. 118, Pr. 120, Pr. 122, Pr. 343, Pr. 502, Pr. 549) ................................................... 231
4.20.7 USB communication (Pr. 547, Pr. 548)...................................................................................... 244
4.21 Special operation and frequency control ...................................... 245
4.21.1 PID control (Pr. 127 to Pr. 134) ................................................................................................. 245
4.21.2 Dancer control (Pr. 44, Pr. 45, Pr. 128 to Pr. 134)..................................................................... 252
4.21.3 Droop control (Pr. 286 to Pr. 287) ............................................................................................. 259
4.21.4 Regeneration avoidance function (Pr. 665, Pr. 882, Pr. 883, Pr. 885, Pr. 886)......................... 260
4.22 Useful functions ............................................................................. 262
4.22.1 Cooling fan operation selection (Pr. 244) .................................................................................. 262
4.22.2 Display of the life of the inverter parts (Pr. 255 to Pr. 259)........................................................ 263

V
CONTENTS
4.22.3 Maintenance timer alarm (Pr. 503, Pr. 504) .............................................................................. 267
4.22.4 Current average value monitor signal (Pr. 555 to Pr. 557) ........................................................ 268
4.22.5 Free parameter (Pr. 888, Pr. 889) ............................................................................................. 270
4.23 Setting from the parameter unit and operation panel.................. 271
4.23.1 RUN key rotation direction selection (Pr. 40) ............................................................................ 271
4.23.2 PU display language selection(Pr.145) ..................................................................................... 271
4.23.3 Operation panel frequency setting/key lock operation selection (Pr. 161) ................................ 272
4.23.4 Magnitude of frequency change setting (Pr. 295)...................................................................... 274
4.23.5 Buzzer control (Pr. 990)............................................................................................................. 275
4.23.6 PU contrast adjustment (Pr. 991) .............................................................................................. 275
4.24 Parameter clear/ All parameter clear ........................................... 276
4.25 Initial value change list................................................................. 277
4.26 Check and clear of the faults history ........................................... 278
5 TROUBLESHOOTING 281
5.1 Reset method of protective function ............................................. 282
5.2 List of fault or alarm indications.................................................... 283
5.3 Causes and corrective actions ...................................................... 284
5.4 Correspondences between digital and actual characters ............ 294
5.5 Check first when you have a trouble ............................................. 295
5.5.1 Motor does not start.................................................................................................................... 295
5.5.2 Motor or machine is making abnormal acoustic noise................................................................ 297
5.5.3 Inverter generates abnormal noise............................................................................................. 297
5.5.4 Motor generates heat abnormally ............................................................................................... 297
5.5.5 Motor rotates in the opposite direction ....................................................................................... 298
5.5.6 Speed greatly differs from the setting......................................................................................... 298
5.5.7 Acceleration/deceleration is not smooth..................................................................................... 298
5.5.8 Speed varies during operation.................................................................................................... 299
5.5.9 Operation mode is not changed properly ................................................................................... 299
5.5.10 Operation panel display is not operating .................................................................................... 300
5.5.11 Motor current is too large............................................................................................................ 300
5.5.12 Speed does not accelerate......................................................................................................... 301
5.5.13 Unable to write parameter setting............................................................................................... 301
6 PRECAUTIONS FOR MAINTENANCE AND INSPECTION 303
6.1 Inspection items ............................................................................. 304
6.1.1 Daily inspection .......................................................................................................................... 304
6.1.2 Periodic inspection ..................................................................................................................... 304

VI
6.1.3 Daily and periodic inspection ...................................................................................................... 305
6.1.4 Display of the life of the inverter parts ........................................................................................ 306
6.1.5 Checking the inverter and converter modules ............................................................................ 307
6.1.6 Cleaning...................................................................................................................................... 308
6.1.7 Replacement of parts.................................................................................................................. 308
6.1.8 Inverter replacement................................................................................................................... 311
6.2 Measurement of main circuit voltages, currents and powers ....... 312
6.2.1 Measurement of powers ............................................................................................................. 314
6.2.2 Measurement of voltages and use of PT .................................................................................... 314
6.2.3 Measurement of currents............................................................................................................ 315
6.2.4 Use of CT and transducer........................................................................................................... 315
6.2.5 Measurement of inverter input power factor ............................................................................... 315
6.2.6 Measurement of converter output voltage (across terminals P/+ and N/-) ................................. 315
6.2.7 Insulation resistance test using megger ..................................................................................... 316
6.2.8 Pressure test............................................................................................................................... 316
7 SPECIFICATIONS 317
7.1 Rating .............................................................................................. 318
7.2 Common specifications .................................................................. 320
7.3 Outline dimension drawings ........................................................... 321
APPENDIX 327
Appendix 1 For customers who are replacing the conventional model
with this inverter ....................................................................................... 328
Appendix 1-1 Replacement of the FR-E500 series ............................................................................... 328
Appendix 2 Specification change ................................................................................ 330
Appendix 2-1 SERIAL number check .................................................................................................... 330
Appendix 2-2 Changed Functions ......................................................................................................... 330
Appendix 3 Index........................................................................................................... 331

1
3
4
5
6
7
2
1
1 OUTLINE
This chapter explains the "OUTLINE" for use of this product.
Always read the instructions before using the equipment.
1.1 Product checking and parts identification ................................. 2
1.2 Inverter and peripheral devices................................................... 3
1.3 Removal and reinstallation of the cover..................................... 5
1.4 Installation of the inverter and enclosure design ...................... 8
<Abbreviations>
PU .................................................. Operation panel and parameter unit (FR-PU04/FR-PU07)
Inverter ........................................... Mitsubishi inverter FR-E700 series
FR-E700 ........................................ Mitsubishi inverter FR-E700 series
Pr. ................................................... Parameter number (Function number of inverter)
PU operation .................................. Operation using the PU (operation panel/FR-PU04/FR-PU07)
External operation .......................... Operation using the control circuit signals
Combined operation ....................... Operation using both the PU (operation panel/FR-PU04/FR-
PU07) and external operation
Operation panel for E500, PA02..... FR-E500 series operation panel (FR-PA02-02)
Mitsubishi standard motor .............. SF-JR
Mitsubishi constant-torque motor ... SF-HRCA
<Trademarks>
Microsoft and Visual C++ are registered trademarks of Microsoft Corporation in the United States
and/or other countries.
LONWORKS®is a registered trademark of Echelon Corporation in the U.S.A and other countries.
DeviceNet ® is a registered trademark of ODVA (Open DeviceNet Vender Association, Inc.).
Other company and product names herein are the trademarks and registered trademarks of their
respective owners.
<Mark>
REMARKS :Additional helpful contents and relations with other functions are stated
NOTE :Contents requiring caution or cases when set functions are not
activated are stated.
POINT :Useful contents and points are stated.
Parameters referred to : related parameters are stated.
.....Specifications differ according to the date assembled. Refer to page 330 to check
the SERIAL number.

2
Product checking and parts identification
1.1 Product checking and parts identification
Unpack the inverter and check the capacity plate on the front cover and the rating plate on the inverter side face to ensure that
the product agrees with your order and the inverter is intact.
zInverter model
∗Location of the capacity plate and the rating plate differs according to the inverter capacity.
Refer to the outline dimension drawing.(Refer to page 317)
•Accessory
· Fan cover fixing screws (M3 × 35mm)
These screws are necessary for compliance with the EU Directive (
Refer to the Installation Guideline )
Type Number
FR-E720-080(SC) to 175(SC), FR-E740-040(SC) to 095(SC), FR-E720S-050 to 110 1
FR-E720-240(SC) to 600(SC), FR-E740-120(SC) to 300(SC) 2
Connector for plug-in
option connection
(Refer to the instruction
manual of options.)
Inverter model
Serial number
Capacity plate *
FR-E740-095-NA
Rating plate *
Inverter model
Input rating
Output rating
Serial number
FR-E740-095-NA
Cooling fan
(Refer to page 308)
USB connector
(mini-B connector)
(Refer to page 244)
Control circuit terminal
block
(Refer to page 22)
Changing the control
logic jumper connector
(Refer to page 25)
Combed shaped wiring
cover
(Refer to page 7)
Main circuit
terminal block
(Refer to page 16)
PU connector cover
(Refer to page 33)
Front cover
(Refer to page 5)
USB connector cover
(Refer to page 244)
Voltage/current input switch
(Refer to page 22)
Operation panel
(Refer to page 56)
PU connector
(Refer to page 24)
FR E740 095
-- -
NA
Displays the
rated current
Control circuit terminal specificationSymbol
Standard control circuit terminal
(screw type)
No symbol
Safety stop function modelSC
Symbol Voltage class
E720
E740
Three-phase 200V class
Three-phase 400V class
Single-phase 200V class
E720S
Single-phase 100V class
E710W
Example of FR-E740-095-NA

3
1
OUTLINE
Inverter and peripheral devices
1.2 Inverter and peripheral devices
NOTE
The life of the inverter is influenced by surrounding air temperature. The surrounding air temperature should be as low as
possible within the permissible range. This must be noted especially when the inverter is installed in an enclosure. (Refer
to page 8)
yWrong wiring might lead to damage of the inverter. The control signal lines must be kept fully away from the main circuit
to protect them from noise. (Refer to page 14)
Do not install a power factor correction capacitor, surge suppressor or capacitor type filter on the inverter output side.
This will cause the inverter to trip or the capacitor and surge suppressor to be damaged. If any of the above devices are
connected, immediately remove them.
Electromagnetic wave interference
The input/output (main circuit) of the inverter includes high frequency components, which may interfere with the
communication devices (such as AM radios) used near the inverter. In this case, install options among the capacitor type
EMC filter FR-BIF (for use in the input side only), the ferrite core type EMC filter FR-BSF01/FR-BLF, filterpack, and EMC
filter to minimize the interference. (Refer to page 44).
Refer to the instruction manual of each option and peripheral devices for details of peripheral devices.
EMC filter (ferrite core)
(FR-BSF01, FR-BLF)
Install an EMC filter (ferrite core)
to reduce the electromagnetic
noise generated from the inverter.
Effective in the range from about
1MHz to 10MHz. A wire should be
wound four turns at a maximum.
Motor
Earth (Ground)
Earth (Ground)
Devices connected to the output
Do not install a power factor correction capacitor,
surge suppressor or capacitor type filter on the output
side of the inverter. When installing a moulded case
circuit breaker on the output side of the inverter,
contact each manufacturer for selection of the
moulded case circuit breaker.
The regenerative braking capability
of the inverter can be exhibited fully.
Install this as required.
Power supply harmonics
can be greatly suppressed.
Install this as required.
High power factor
converter (FR-HC)
Power regeneration
common converter
(FR-CV)
Earth (Ground)
R/L1 S/L2 T/L3
P1
UW
PR
V
Great braking capability
is obtained.
Install this as required.
EMC filter (ferrite core) *
(FR-BSF01, FR-BLF)
AC power supply
Use within the permissible power supply
specifications of the inverter. To ensure
safety, use a moulded case circuit breaker,
earth leakage circuit breaker or magnetic
contactor to switch power ON/OFF.
Magnetic contactor (MC)
Install the magnetic contactor to ensure
safety. Do not use this magnetic contactor
to start and stop the inverter. Doing so will
cause the inverter life to be shorten.
Moulded case circuit breaker
(MCCB) or earth leakage circuit
breaker (ELB), fuse
The breaker must be selected carefully
since an in-rush current flows in the
inverter at power on.
Install an EMC filter (ferrite core)
to reduce the electromagnetic
noise generated from the
inverter. Effective in the range
from about 1MHz to 10MHz.
When more wires are passed
through, a more effective result
can be obtained. A wire should
be wound four turns or more.
To prevent an electric shock, always earth (ground)
the motor and inverter. For reduction of induction noise
from the power line of the inverter, it is recommended
to wire the earthing cable by returning it to the earth
(ground) terminal of the inverter.
AC reactor (FR-HAL) DC reactor (FR-HEL) *
EMC filter
(capacitor) *
(FR-BIF)
P/+
P/+
PR
PR
Brake unit
(FR-BU2)
Reduces the
radio noise.
Resistor unit (FR-BR)
Discharging resistor (GZG, GRZG)
Inverter (FR-E700)
* Filterpack (FR-BFP2), which contains DC reactor and EMC filter in one package, is also available.
Parameter unit
(FR-PU07)
By connecting the connection
cable (FR-CB2) to the PU
connector, operation can be
performed from FR-PU07,
FR-PA07.
Enclosure surface
operation panel
(FR-PA07)
USB connector
A personal computer and an inverter
can be connected with a
USB (Ver1. 1) cable.
Approved safety
relay module
Required for compliance with
safety standard. Only the
safety stop function model
can be connected.
S1
S2
PC
Reactor (FR-HAL, FR-HEL option)
Reactors (option) must be used when
power harmonics measures are taken,
the power factor is to be improved or the
inverter is installed near a large power
supply system (500kVA or more). The
inverter may be damaged if you do not
use reactors. Select the reactor according
to the model. Remove the jumpers across
terminals P/+ and P1 to connect the DC reactor.
P/+
P/+
P/+
N/-
(Refer to page 318)
(Refer to page 4)
(Refer to page 48)
(Refer to page 244)
(Refer to page 33)
Brake resistor
(FR-ABR, MRS type, MYS type)
Braking capability can be improved. (FR-
E720-030(SC) or more, FR-E740-016(SC)
or more, FR-E720S-030 or more, FR-
E710W-030 or more)
Always install a thermal relay when using
a brake resistor whose capacity is 11K or
more.
(Refer to page 35)

4
Inverter and peripheral devices
1.2.1 Peripheral devices
Check the inverter model of the inverter you purchased. Appropriate peripheral devices must be selected according to the capacity.
Refer to the following list and prepare appropriate peripheral devices:
∗1 Select an MCCB according to the power supply capacity.
Install one MCCB per inverter.
∗2 For the use in the United States or Canada, select a UL and cUL certified fuse with Class T fuse equivalent cut-off
speed or faster with the appropriate rating for branch circuit protection. Alternatively, select a UL489 molded case circuit breaker (MCCB).
( Refer to the Installation Guideline)
∗3 Magnetic contactor is selected based on the AC-1 class. The electrical durability of magnetic contactor is 500,000 times. When the magnetic contactor is
used for emergency stop during motor driving, the electrical durability is 25 times.
When using the MC for emergency stop during motor driving or using on the motor side during commercial-power supply operation, select the MC with class
AC-3 rated current for the motor rated current.
∗5 The power factor may be slightly lower.
∗6 Single-phase 100V power input model is not compatible with DC reactor.
Applicable Inverter
Model
Motor
Output
(kW (HP))
Moulded Case Circuit Breaker
(MCCB) ∗1
or Earth Leakage Circuit Breaker
(ELB) ∗2
Magnetic Contactor (MC)
∗3 Reactor
Reactor connection Reactor connection FR-HAL FR-HEL
without with without with
Three-Phase 200V
FR-E720-008(SC) 0.1 (1/8) 5A 5A S-N10 S-N10 0.4K ∗5 0.4K ∗5
FR-E720-015(SC) 0.2 (1/4) 5A 5A S-N10 S-N10 0.4K ∗5 0.4K ∗5
FR-E720-030(SC) 0.4 (1/2) 5A 5A S-N10 S-N10 0.4K 0.4K
FR-E720-050(SC) 0.75 (1) 10A 10A S-N10 S-N10 0.75K 0.75K
FR-E720-080(SC) 1.5 (2) 15A 15A S-N10 S-N10 1.5K 1.5K
FR-E720-110(SC) 2.2 (3) 20A 15A S-N10 S-N10 2.2K 2.2K
FR-E720-175(SC) 3.7 (5) 30A 30A S-N20, S-N21 S-N10 3.7K 3.7K
FR-E720-240(SC) 5.5 (7.5) 50A 40A S-N25 S-N20, S-N21 5.5K 5.5K
FR-E720-330(SC) 7.5 (10) 60A 50A S-N25 S-N25 7.5K 7.5K
FR-E720-470(SC) 11 (15) 75A 75A S-N35 S-N35 11K 11K
FR-E720-600(SC) 15 (20) 125A 100A S-N50 S-N50 15K 15K
Three-Phase 400V
FR-E740-016(SC) 0.4 (1/2) 5A 5A S-N10 S-N10 H0.4K H0.4K
FR-E740-026(SC) 0.75 (1) 5A 5A S-N10 S-N10 H0.75K H0.75K
FR-E740-040(SC) 1.5 (2) 10A 10A S-N10 S-N10 H1.5K H1.5K
FR-E740-060(SC) 2.2 (3) 15A 10A S-N10 S-N10 H2.2K H2.2K
FR-E740-095(SC) 3.7 (5) 20A 15A S-N10 S-N10 H3.7K H3.7K
FR-E740-120(SC) 5.5 (7.5) 30A 20A S-N20, S-N21 S-N11, S-N12 H5.5K H5.5K
FR-E740-170(SC) 7.5 (10) 30A 30A S-N20, S-N21 S-N20, S-N21 H7.5K H7.5K
FR-E740-230(SC) 11 (15) 50A 40A S-N20, S-N21 S-N20, S-N21 H11K H11K
FR-E740-300(SC) 15 (20) 60A 50A S-N25 S-N20, S-N21 H15K H15K
Single-Phase 200V
FR-E720S-008 0.1 (1/8) 5A 5A S-N10 S-N10 0.4K ∗5 0.4K ∗5
FR-E720S-015 0.2 (1/4) 5A 5A S-N10 S-N10 0.4K ∗5 0.4K ∗5
FR-E720S-030 0.4 (1/2) 10A 10A S-N10 S-N10 0.75K ∗5 0.75K ∗5
FR-E720S-050 0.75 (1) 15A 10A S-N10 S-N10 1.5K ∗5 1.5K ∗5
FR-E720S-080 1.5 (2) 20A 20A S-N10 S-N10 2.2K ∗5 2.2K ∗5
FR-E720S-110 2.2 (3) 40A 30A S-N20, S-N21 S-N10 3.7K ∗5 3.7K ∗5
Single-Phase 100V
FR-E710W-008 0.1 (1/8) 10A 5A S-N10 S-N10 0.75K ∗4 , ∗5 −−− ∗ 6
FR-E710W-015 0.2 (1/4) 10A 10A S-N10 S-N10 1.5K ∗4, ∗5 −−− ∗ 6
FR-E710W-030 0.4 (1/2) 15A 15A S-N10 S-N10 2.2K ∗4, ∗5 −−− ∗ 6
FR-E710W-050 0.75 (1) 30A 20A S-N10 S-N10 3.7K ∗4, ∗5 −−− ∗ 6
∗4 When connecting a single-phase 100V power input inverter to a power transformer (50kVA or more), install a AC reactor (FR-HAL) so that the performance
is more reliable. (Refer to page 47 for details.)
NOTE
When the inverter capacity is larger than the motor capacity, select an MCCB and a magnetic contactor according to
the inverter model and cable and reactor according to the motor output.
When the breaker on the inverter input side trips, check for the wiring fault (short circuit), damage to internal parts of
the inverter, etc. Identify the cause of the trip, then remove the cause and power on the breaker.
MCCB INV
MCCB INV
IM
IM

5
1
OUTLINE
Removal and reinstallation of the cover
1.3 Removal and reinstallation of the cover
1.3.1 Front cover
FR-E720-175(SC) or less, FR-E740-170(SC) or less, FR-E720S, FR-E710W
zRemoval (Example of FR-E740-095)
Remove the front cover by pulling it toward you in the direction of arrow.
zReinstallation (Example of FR-E740-095)
To reinstall, match the cover to the inverter front and install it straight.

6
Removal and reinstallation of the cover
FR-E720-240(SC) to 600(SC), FR-E740-230(SC), 300(SC)
zRemoval (Example of FR-E740-230)
1) Loosen the installation screws of the front cover 1.
2) Remove the front cover 1 by pulling it toward you in the direction of arrow.
3) Remove the front cover 2 by pulling it toward you in the direction of arrow.
zReinstallation (Example of FR-E740-230)
1) Match the front cover 2 to the inverter front and install it straight.
2) Insert the two fixed hooks on the lower side of the front cover 1 into the sockets of the inverter.
3)Tighten the screw of the front cover 1.
NOTE
Fully make sure that the front cover has been reinstalled securely.
The same serial number is printed on the capacity plate of the front cover and the rating plate of the inverter. Since
these plates have the same serial numbers, always reinstall the removed cover onto the original inverter.
Installation
screws
Front cover 1
Front cover 2
1) 2) 3)
Front cover 2
Front cover 1
Fixed hook
Socket of the inverte
r
Tighten
the installation
screws
1) 2) 3)

7
1
OUTLINE
Removal and reinstallation of the cover
1.3.2 Wiring cover
zRemoval and reinstallation
The cover can be removed easily by pulling it toward you. To reinstall, fit the cover to the inverter along the guides.
FR-E720-008(SC) to 050(SC)
FR-E720S-008 to 030
FR-E710W-008 to 030
FR-E720-080(SC) to 175(SC)
FR-E740-016(SC) to 095(SC)
FR-E720S-050 to 110
FR-E710W-050
Example of FR-E720S-030 Example of FR-E740-095
FR-E740-120(SC), 170(SC) FR-E720-240(SC) to 600(SC)
FR-E740-230(SC), 300(SC)
For removal, push the dent on the wiring cover with your finger and
pull toward you.
Example of FR-E740-120 Example of FR-E740-230
Wiring cove
r
Guide
Wiring cove
r
Guide
Wiring cover
Guid
e
Dent
Guide
Wiring cover

8
Installation of the inverter and enclosure design
1.4 Installation of the inverter and enclosure design
When an inverter enclosure is to be designed and manufactured, heat generated by contained equipment, etc., the
environment of an operating place, and others must be fully considered to determine the enclosure structure, size and
equipment layout. The inverter unit uses many semiconductor devices. To ensure higher reliability and long period of
operation, operate the inverter in the ambient environment that completely satisfies the equipment specifications.
1.4.1 Inverter installation environment
As the inverter installation environment should satisfy the standard specifications indicated in the following table, operation in
any place that does not meet these conditions not only deteriorates the performance and life of the inverter, but also causes a
failure. Refer to the following points and take adequate measures.
(1) Temperature
The permissible surrounding air temperature of the inverter is between -10 and +50 ° C (14 ° F to 122 ° F). Always operate the
inverter within this temperature range. Operation outside this range will considerably shorten the service lives of the
semiconductors, parts, capacitors and others. Take the following measures so that the surrounding air temperature of the
inverter falls within the specified range.
1) Measures against high temperature
Use a forced ventilation system or similar cooling system. (Refer to page 10)
Install the panel in an air-conditioned electrical chamber.
Block direct sunlight.
Provide a shield or similar plate to avoid direct exposure to the radiated heat and wind of a heat source.
Ventilate the area around the panel well.
2) Measures against low temperature
Provide a space heater in the enclosure.
Do not power off the inverter. (Keep the start signal of the inverter off.)
3) Sudden temperature changes
Select an installation place where temperature does not change suddenly.
Avoid installing the inverter near the air outlet of an air conditioner.
If temperature changes are caused by opening/closing of a door, install the inverter away from the door.
(2) Humidity
Normally operate the inverter within the 45 to 90% range of the ambient humidity. Too high humidity will pose problems of
reduced insulation and metal corrosion. On the other hand, too low humidity may produce a spatial electrical breakdown. The
insulation distance specified in JEM1103 "Control Equipment Insulator" is defined as humidity 45 to 85%.
1) Measures against high humidity
Make the panel enclosed, and provide it with a hygroscopic agent.
Take dry air into the enclosure from outside.
Provide a space heater in the enclosure.
2) Measures against low humidity
What is important in fitting or inspection of the unit in this status is to discharge your body (static electricity)
beforehand and keep your body from contact with the parts and patterns, besides blowing air of proper humidity into
the panel from outside.
3) Measures against condensation
Condensation may occur if frequent operation stops change the in-panel temperature suddenly or if the outside-air
temperature changes suddenly.
Condensation causes such faults as reduced insulation and corrosion.
Take the measures against high humidity in 1).
Do not power OFF the inverter. (Keep the start signal of the inverter OFF.)
Environmental standard specifications of inverter
Item Description
Surrounding air
temperature -10 to +50
° C (14 ° F to 122 ° F) (non-freezing)
Ambient humidity 90%RH or less (non-condensing)
Atmosphere Free from corrosive and explosive gases, free from dust and dirt
Maximum altitude 1,000m (3280.80 feet) or less
Vibration 5.9m/s2or less at 10 to 55Hz (directions of X, Y, Z axes)

9
1
OUTLINE
Installation of the inverter and enclosure design
(3) Dust, dirt, oil mist
Dust and dirt will cause such faults as poor contact of contact points, reduced insulation or reduced cooling effect due to
moisture absorption of accumulated dust and dirt, and in-panel temperature rise due to clogged filter. In the atmosphere
where conductive powder floats, dust and dirt will cause such faults as malfunction, deteriorated insulation and short circuit in
a short time.
Since oil mist will cause similar conditions, it is necessary to take adequate measures.
Countermeasures
Place in a totally enclosed enclosure.
Take measures if the in-enclosure temperature rises. (Refer to page 10)
Purge air.
Pump clean air from outside to make the in-panel pressure higher than the outside-air pressure.
(4) Corrosive gas, salt damage
If the inverter is exposed to corrosive gas or to salt near a beach, the printed board patterns and parts will corrode or the
relays and switches will result in poor contact.
In such places, take the measures given in Section 3.
(5) Explosive, flammable gases
As the inverter is non-explosion proof, it must be contained in an explosion proof enclosure. In places where explosion may be
caused by explosive gas, dust or dirt, an enclosure cannot be used unless it structurally complies with the guidelines and has
passed the specified tests. This makes the enclosure itself expensive (including the test charges). The best way is to avoid
installation in such places and install the inverter in a non-hazardous place.
(6) Highland
Use the inverter at the altitude of within 1000m (3280.80 feet). If it is used at a higher place, it is likely that thin air will reduce
the cooling effect and low air pressure will deteriorate dielectric strength.
(7) Vibration, impact
The vibration resistance of the inverter is up to 5.9m/s2at 10 to 55Hz frequency and 1mm amplitude for the directions of X, Y,
Z axes. Vibration or impact, if less than the specified value, applied for a long time may make the mechanism loose or cause
poor contact to the connectors.
Especially when impact is imposed repeatedly, caution must be taken as the part pins are likely to break.
Countermeasures
Provide the panel with rubber vibration isolators.
Strengthen the structure to prevent the panel from resonance.
Install the panel away from sources of vibration.

10
Installation of the inverter and enclosure design
1.4.2 Cooling system types for inverter panel
From the panel that contains the inverter, the heat of the inverter and other equipment (transformers, lamps, resistors, etc.)
and the incoming heat such as direct sunlight must be dissipated to keep the in-panel temperature lower than the permissible
temperatures of the in-panel equipment including the inverter.
The cooling systems are classified as follows in terms of the cooling calculation method.
1) Cooling by natural heat dissipation from the enclosure surface (totally enclosed type)
2) Cooling by heat sink (aluminum fin, etc.)
3) Cooling by ventilation (forced ventilation type, pipe ventilation type)
4) Cooling by heat exchanger or cooler (heat pipe, cooler, etc.)
Cooling System Panel Structure Comment
Natural
cooling
Natural ventilation
(enclosed, open type)
Low in cost and generally used, but the panel size increases
as the inverter capacity increases. For relatively small
capacities.
Natural ventilation
(totally enclosed type)
Being a totally enclosed type, the most appropriate for hostile
environment having dust, dirt, oil mist, etc. The panel size
increases depending on the inverter capacity.
Forced
cooling
Fin cooling Having restrictions on the heatsink mounting position and
area, and designed for relative small capacities.
Forced ventilation For general indoor installation. Appropriate for panel
downsizing and cost reduction, and often used.
Heat pipe Totally enclosed type for panel downsizing.
INV
INV
INV
Heatsink
INV
INV
Heat pipe

11
1
OUTLINE
Installation of the inverter and enclosure design
1.4.3 Inverter placement
(1) Installation of the inverter
Enclosure surface mounting
Remove the front cover and wiring cover to fix the inverter to the surface.
(2) Clearances around inverter
(3) Inverter mounting orientation
Mount the inverter on a wall as specified. Do not mount it horizontally or any other way.
NOTE
When encasing multiple inverters, install them in parallel as a
cooling measure.
Install the inverter vertically.
To ensure ease of heat dissipation and maintenance, leave at least the shown clearances around the inverter. At least the
following clearances are required under the inverter as a wiring space, and above the inverter as a heat dissipation space.
Front cover
Wiring cover
Front cover
Wiring cover
FR-E720-008(SC) to 050(SC)
FR-E720S-008 to 030
FR-E710W-008 to 030
FR-E720-080(SC) or more
FR-E740-016(SC) or more
FR-E720S-050 or more
FR-E710W-050
Refer to the clearances below.
Vertical
Measurement
position
Measurement
position
Inverter
5cm
(1.97inches)
5cm
(1.97inches)
5cm (1.97inches)
Humidity: 90% RH or less
Clearances (side)
1cm
(0.39
inches)
or more
*
Inverter
Clearances (front)
10cm
(3.94inches)
or more
10cm
(3.94inches)
or more
1cm
(0.39inches)
or more*
1cm
(0.39inches)
or more*
* 5cm (1.97inches) or more
for the FR-E720-240(SC)
and FR-E740-120(SC), or
more
Leave enough clearances and take
cooling measures.
Temperature: -10 C to +50 C
(14 F to 122 F)
* When using the inverters at the surrounding air
temperature of 40 C (
104 F) or less, the inverters
can be installed without any clearance between them
(0cm (
0inch) clearance).
When surrounding air temperature exceeds 40 C
(
104 F) , clearances between the inverters should be
1cm
(0.39inches) or more (5cm (1.97inches) or more
for the FR-E720-240(SC) and FR-E740-120(SC), or
more).
Surrounding air temperature and humidity
