Mitsubishi FX3U-232ADP(-MB) User manual

JY997D26401A
Safety Precaution (Read these precautions before use.)
This manual classify the safety precautions into two categories:
and .
Depending on circumstances, procedures indicated by may also be
linked to serious results.
In any case, it is important to follow the directions for usage.
Associated Manuals
How to obtain manuals
For the necessary product manuals or documents, consult with the Mitsubishi
Electric dealer from where you purchase your product.
Indicates that incorrect handling may cause hazardous
conditions, resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous
conditions, resulting in medium or slight personal injury
or physical damage.
Manual name Manual No. Description
FX3U Series
User’s Manual
- Hardware Edition
JY997D16501
MODEL CODE:
09R516
Explains FX3U Series PLC
specification details for I/O,
wiring, installation, and
maintenance.
FX3U/FX3UC Series
Programming Manual
- Basic & Applied
Instruction Edition
JY997D16601
MODEL CODE:
09R517
Describes PLC programming
for basic/applied instructions
and devices.
FX Series User’s
Manual
- Data Communication
Edition
JY997D16901
MODEL CODE:
09R715
Explains N:N link, parallel
link, computer link, no
protocol communication by
RS instructions/FX2N-232IF.
FX3U Series User’s
Manual
- MODBUS Serial
Communication Edition
JY997D26201 Explains the MODBUS serial
communication network.
Certification of UL, cUL standards
The FX3U-232ADP-MB unit supports UL and cUL standards.
UL, cUL file number :E95239
Compliance with EC directive(CE Marking )
This document does not guarantee that a mechanical system including this product will
comply with the following standards.
Compliance to EMC directive of the entire mechanical system should be checked by
the user / manufacturer. For more details please contact the local Mitsubishi Electric
sales site.
Requirement for Compliance with EMC directive
The FX3U-232ADP-MB is compliant through direct testing (of the identified standards
below) and design analysis (through the creation of a technical construction file) to the
European Directive for Electromagnetic Compatibility (89/336/EEC) when used as
directed by the appropriate documentation.
Caution for compliance with EC Directive
Installation in Enclosure
Programmable logic controllers are open-type devices that must be installed and used
within conductive control boxes. Please use the FX3U Series programmable logic
controllers while installed in conductive shielded control boxes. Please secure the
control box lid to the control box (for conduction). Installation within a control box
greatly affects the safety of the system and aids in shielding noise from the
programmable logic controller.
1. Outline
The FX3U-232ADP-MB communication special adapter (hereinafter called 232ADP-
MB) is a special adapter for RS-232C communication with an 9-pin D-Sub connector.
232ADP-MB is an isolated signal exchange unit of the RS-232C serial data
communication between the PLC and RS-232C device.
The FX3U-232ADP-MB features all functionality that is available with the FX3U-
232ADP, except that it also has MODBUS communication available.
1.1 Communication Function
1.2 Incorporated Items
Check if the following product and items are included in the package:
Standard Remark
EN61131-2:2003
Programmable controllers
- Equipment requirements and
tests
Compliance with all relevant aspects of the
standard.
•Radiated Emissions
•Mains Terminal Voltage Emissions
•RF immunity
•Fast Transients
•ESD •Surge
•Voltage drops and interruptions
•Conducted
•Power magnetic fields
Communication type Function
Computer link Data transfer via dedicated protocol between PLC and
computer (specified as the master station).
Non-protocol
communication
Serial communication via non-protocol between PLC and
RS-232C device.
Programming
communication
Optional port available for suitable programming tool when
232ADP-MB is connected to PLC.
Remote maintenance Program transfer or monitoring enabled via modem and
phone line connected to serial port of PLC.
MODBUS
communication Data transfer between a master and a slave.
ManualProduct
This
manual
FX 3U -232ADP
-MB
POWER
RD
SD
1.3 External Dimensions, Part Names, and Pin Configuration
1.3.1 External Dimensions and part name
1.4 Pin Configuration
The pin configuration of the RS-232C port on the 232ADP-MB is as shown below.
2. Channel Allocation
Up to two communication ports can be added to the main unit.
Communication port channels are automatically allocated. The closer
communication special adapter to the main unit is ch1.
•Using one communication special adapter + communication expansion board
•Using two communication special adapters
[1] DIN rail mounting groove (DIN rail: DIN46277)
[2] Name plate
[3] Special adapter slide lock:
Used to connect special adapter on left side of this special adapter.
[4] Special adapter connector cover:
Remove this cover for connecting special adapter on the left side.
[5] Direct mounting hole:2 holes of φ4.5 (0.18") (mounting screw: M4 screw)
[6] POWER LED (green): Lit while 5V DC power is supplied from main unit.
[7] RD LED (red):
Lit while receiving data from connected RS-232C device.
[8] SD LED (red):
Lit while sending data to connected RS-232C device.
[9] Special adapter connector:
Used to connect this special adapter to PLC main unit or special adapter.
[10] RS-232C connector (9-pin D-Sub, male):
Connect RS-232C device to this RS-232C connector
[11] Screws to fix a cable connector: Screw holes #4-40UNC (inch screw thread)
[12] DIN rail mounting hook
[13] Special adapter fixing hook
[14] Special adapter connector:
Used to connect communication special adapter or analog special adapter to
this adapter on left side.
FX 3U -232ADP
-MB
[3]
[6]
[5]
[7]
[8]
[9]
[10]
[11]
[12]
[14]
[13]
[2]
[4]
[1]
74(2.92")
Weight: Approx. 80g (0.18 lbs)
Special adapter
connector cover
is removed
7(0.28")
90(3.55")
98(3.86")
106(4.18")
17.6
(0.7")
7.5
(0.29")
15.1
(0.6")
Pin
No. Signal Name Function
1CD
Receive
carrier
detection
ON when carrier for data reception
is detected.
(RS-232C device to 232ADP
-MB )
2RD
(RXD)
Receive
data
Receive data
(RS-232C device to 232ADP
-MB )
3SD
(TXD) Send data
Send data
(232ADP
-MB to RS-232C device)
4ER
(DTR)
Send
request
ON when RS-232C device is ready
to receive data.
(232ADP
-MB to RS-232C device)
5SG
(GND)
Signal
ground
Signal ground
(232ADP
-MB to RS-232C device)
6DR
(DSR)
Send
enable
ON when send request is made
toward RS-232C device.
(RS-232C device to 232ADP
-MB )
7,8,9 Not used Do not wire.
Screws to fix
RS-232C
connector
1
5
6
9
Screw holes:
#4-40UNC
(inch screw
thread)
Analog
special
function
adapter
Analog
special
function
adapter
Analog
special
function
adapter
FX 3U -
232ADP
-MB
Analog
special
function
adapter
Main unit
Communication
expansion board (ch1)
(ch2)
Analog
special
function
adapter
Analog
special
function
adapter
Analog
special
function
adapter
FX 3U -
232ADP
-MB
Analog
special
function
adapter
FX 3U -
232ADP
-MB Main unit
FX 3U -CNV-BD(ch1)(ch2)
FX3U-232ADP-MB
Installation Manual
This manual describes the part names, dimensions, mounting, and
specifications of the product. Before use, read this manual and manuals of
relevant products fully to acquire proficiency in handling and operating the
product. Make sure to learn all the product information, safety information, and
precautions.
And, store this manual in a safe place so that you can take it out and read it
whenever necessary. Always forward it to the end user.
Registration
MODBUS®is a registered trademark of Schneider Electric S.A.
The company name and the product name to be described in this manual are
the registered trademarks or trademarks of each company.
Effective April 2007
Specifications are subject to change without notice.
©2007 Mitsubishi Electric Corporation
Manual Number JY997D26401
Revision A
Date April 2007

This manual confers no industrial property rights or any rights of any other kind,
nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be
held responsible for any problems involving industrial property rights which may
occur as a result of using the contents noted in this manual.
Warranty
Mitsubishi will not be held liable for damage caused by factors found not to be
the cause of Mitsubishi; opportunity loss or lost profits caused by faults in the
Mitsubishi products; damage, secondary damage, accident compensation
caused by special factors unpredictable by Mitsubishi; damages to products
other than Mitsubishi products; and to other duties.
For safe use
This product has been manufactured as a general-purpose part for general
industries, and has not been designed or manufactured to be incorporated in
a device or system used in purposes related to human life.
Before using the product for special purposes such as nuclear power, electric
power, aerospace, medicine or passenger movement vehicles, consult with
Mitsubishi Electric.
This product has been manufactured under strict quality control. However
when installing the product where major accidents or losses could occur if the
product fails, install appropriate backup or failsafe functions in the system.
•
•
•
HEAD OFFICE
HIMEJI WORKS
: TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310,
JAPAN
: 840, CHIYODA CHO, HIMEJI, JAPAN
3. Installation
The product can be mounted on a DIN rail (DIN46227) or mounted directly using
screws.
For installation/uninstallation and safety precautions, refer to the following
manuals:
→ Refer to the FX3U Series User's Manual - Hardware Edition.
3.1 Connection to the FX3U Series PLC
•Refer to the procedure 2) for configuring a new system.
•Refer to the procedure 1) for adding product to an existing system.
Procedure
1) Turn off the power.
Disconnect all the cables connected to the PLC main unit and special adapter.
Dismount the main unit and special adapter mounted on DIN rail or mounted
directly using screws.
2) Install an expansion board to the main unit.
For installation of expansion board, refer to the following manual:
→ Refer to the FX3U Series User's Manual - Hardware Edition.
3) Remove the special adapter connector cover
on the expansion board (Right fig.A).
In case of connecting this product to another
special adapter, please replace the
'expansion board' in the above description
with a 'special adapter' and perform the
procedure as indicated.
4) Slide the special adapter slide lock (Right
fig.B) of the main unit.
In case of connecting this product to another
special adapter, please replace the 'main
unit' in the above description with a 'special
adapter' and perform the procedure as
indicated. (Please replace the following
procedures similarly.)
5) Connect the
special adapter
(Right fig.C) to
the main unit as
shown on the
right.
6) Slide back the
special adapter
slide lock (Right
fig.B) of the main
unit to fix the
special adapter
(Right fig.C).
Connection precautions
Connect all the high-speed I/O special adapters before connecting other
special adapters when they are used in combination.
Do not connect a high-speed I/O special adapter on the left side of a
communication or analog special adapter.
INSTALLATION
PRECAUTIONS
•Cut off all phases of the power source externally before starting the
installation or wiring work, thus avoiding electric shock or damages to the
product.
INSTALLATION
PRECAUTIONS
•Use the product in the environment within the general specifications
described in PLC main unit manual (Hardware Edition).
Never use the product in areas with dust, oily smoke, conductive dusts,
corrosive gas (salt air, Cl2, H2S, SO2, or NO2), flammable gas, vibrations or
impacts, or expose it to high temperature, condensation, or wind and rain.
If the product is used in such a place described above, electrical shock, fire,
malfunction, damage, or deterioration may be caused.
•When drilling screw holes or wiring, cutting chips or wire chips should not
enter ventilation slits.
Such an accident may cause fire, failure or malfunction.
•Do not touch the conductive parts of the product directly, thus avoiding failure
or malfunction.
•Fix the special adapter securely to the specified connector.
Incorrect connection may cause malfunction.
RUN
STOP
FX
3U
-48MR/ES
FX
3U
-48M
3)
4)
B
B
A
4)
RUN
STOP
FX
3U
-48MR/ES
FX
3U
-48M
-48M
POWER
RD
SD
FX
3U
-232ADP
-MB
FX
3U
-48M
6)
C
B
B
5)
5)
5)
6)
4. Wiring
For details of wiring, refer to FX Series User's Manual - Data Communication Edition,
and FX3U Series User’s Manual - MODBUS Serial Communication Edition.
5. Specification
5.1 Applicable PLC
The version number can be checked by monitoring D8001, as well the last three digits
indicate the version number.
5.2 General Specifications
For general specifications, refer to the PLC main unit manual.
The following items are not equivalent to the PLC main unit.
5.3 Power Supply Specification
WIRING
PRECAUTIONS
•Cut off all phases of power source externally, before installation or wiring work in
order to avoid electric shock or damage of product.
WIRING
PRECAUTIONS
•Never let cutting chips and wire chips enter the ventilation slits of this product or
PLC when performing wiring.
Otherwise, fire, failure or malfunction may occur.
•Make sure to observe the precautions below in order to prevent any damage to a
machine or any accident which might be caused by abnormal data written in the
PLC due to the influence of noise:
1) Do not lay close or bundle with the main circuit, high-voltage power line, or
load line.
Otherwise effects of noise or surge induction are likely to take place.
Keep a safe distance of more than 100 mm (3.94") from the above when
wiring.
2) Ground the shield wire or shield of a shielded cable at one point on the PLC.
However, do not ground at the same point as high voltage lines.
STARTUP AND
MAINTENANCE
PRECAUTIONS
•Do not disassemble or modify the unit.
Doing so may cause failure, malfunction or fire.
* For repair, contact your local Mitsubishi Electric distributor.
•Do not drop the product or do not exert strong impact, doing so may cause
damage.
DISPOSAL
PRECAUTIONS
•Please contact a company certified in the disposal of electronic waste for
environmentally safe recycling and disposal of your device.
TRANSPORT AND
STORAGE PRECAUTIONS
•During transportation avoid any impact as the product is a precision instrument.
Check the operation of the product after transportation.
Model name Applicability
FX3U Series PLC
Ver. 2.40 and later for MODBUS communication
Ver. 2.20 and later for all communication functions except
MODBUS
Item Specification
Dielectric withstand
voltage 500 V AC, 1 min Conforming to JEM-1021
Between terminal block and ground
terminal of PLC main unit
Insulation resistance 5MΩor more, 500 V
DC by Megger
Item Specification
Current
consumption
30mA
5V DC power is supplied internally from the main unit.
5.4 Performance Specification
Item Specification
Transmission
standard Conforming to RS-232C
Type of isolation Photocoupler isolation
Transmission
distance 15m (49’ 2") or less
Connection method 9-pin D-Sub connector (male)
Number of occupied
I/O points
0 point (This number is not related to the maximum number
of input/output points of the PLC.)
Communication
method Full-duplex
Baud rate
Computer link, non-protocol communication, and
MODBUS:
300/600/1200/2400/4800/9600/19200 bps
Programming communication:
9600/19200/38400/57600/115200bps
Communication
format
Computer link (dedicated protocol: format 1/format 4),
Non-protocol, Programming communication,
and MODBUS (RTU, ASCII)
LED display:
LED color Power: green, RD: red, SD: red
