Mitsubishi A8GT-TK Series User manual

A8GT-TK type
Numeric Keypad Panel
Mitsubishi Graphic Operation Terminal
User's Manual
Thank you for choosing the Mitsubishi General Purpose PC Graphic Operation
Terminal 800 series. To ensure correct use of this equipment, please read this manual
carefully before operating it.
MODEL A8GT-TK-U-E
MODEL
CODE 13JL51
IB-NA-66832-A (9711)MEE
©1997 MITSUBISHI ELECTRIC CORPORATION

The United States Mitsubishi Electronics America, Inc., (Industrial Automation Division)
800 Biemann Court, Mt. Prospect, IL 60056.
Phone : [phone]
Canada Mitsubishi Electric Sales Canada, Inc., (Industrial Automation Division)
4299 14th Avenue, Markham, Ontario L3R OJ2
Phone : [phone]
United Kingdom Mitsubishi Electric UK Ltd., (Industrial Sales Division)
Travellers Lane, Hatfield, Herts., AL10 8XB
Phone : [phone]
Germany Mitsubishi Electric Europe GmbH, (Industrial Automation Division)
Gothaer Strasse 8, Postfach 1548, D-4030 Ratingen 1
Phone : [phone]
Taiwan Setsuyo Enterprise Co., Ltd.,
(106) 11th FI., Chung-Ling Bldg., 363, Sec. 2, Fu-Hsing S. Rd., Taipei,
Taiwan. R.O.C.
Phone : [phone]
Hongkong (& China) Ryoden International Ltd., (Industrial & Electrical Controls Division)
10/F., Manulife Tower, 169 Electric Rd., North Point, Hong Kong.
Phone : [phone]
Singapore (& Malaysia) MELCO Sales Singapore Pte. Ltd., (Industrial Division)
307 Alexandra Rd. #05-01/02, Mitsubishi Electric Bldg., Singapore 0315.
Phone : [phone]
Thailand F.A. Tech Co., Ltd.,
1138/33-34 Rama 3 Rd., Yannawa, Bangkok 10120.
Phone : [phone]
Australia Mitsubishi Electric Australia Pty. Ltd., (Industrial Controls Division)
348 Victoria Rd., Rydalm ere, N.S.W. 2116.
Phone : [phone]
Republic of South Africa M.S.A. Manufacturing (Pty) Ltd., (Factory Automation Division)
P.O. Box 39733, Bramley, Johannesburg 2018.
Phone : [phone]
When exported from Japan, this manual does not require application to the
Ministry of International Trade and Industry for service transaction permission.
Specifications subject to change without notice.
Printed in Japan on recycled paper
HEAD OFFICE: MITSUBISHI DENKI BLDG MARUNOUCHI TOKYO 100 TELEX: J24532 CABLE MELCO TOKYO
NAGOYA WORKS: 1-14, YADA-MINAMI 5, HIGASHI-KU, NAGOYA, JAPAN

Revisions
* The manual number is noted at the lower left of the back cover.
Print Date *Manual Number Revision
Nov. 1997 IB (NA)-66832-AFirst printing
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any
patent licenses. Mitsubishi electric Corporation cannot be held responsible for any problems involving
industrial property rights which may occur as a result of using the contents noted in this manual.
© 1997 Mitsubishi Electric Corporation

A-1
Precautions Regarding Safety 
(Please read carefully before using your equipment)
Before using this product, please read this manual and the relevant manuals
introduced in this manual carefully and pay full attention to safety to handle the
product correctly.
The instructions given in this manual are concerned with this product. For the safety
instructions of the programmable controller system, please read the CPU module
user's manual.
In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".
DANGER
Procedures which may lead to a dangerous condition and
cause death or serious injury if not carried out properly.
CAUTION
Procedures which may lead to a dangerous condition and
cause superficial to medium injury, or physical damage
only, if not carried out properly.
Depending on circumstances, procedures indicated by CAUTION may also be
linked to serious results.
In any case, it is important to follow the directions for usage.
Store this manual in a safe place so that you can take it out and read it whenever
necessary. Always forward it to the end user.
[Precautions Regarding Assembly]
DANGER
l
When connecting the connection cable to the Numeric Keypad Panel, always
switch off GOT power externally in all phases.
A failure to do so can cause misoperation due to miss-input.

A-2
[Precautions Regarding Assembly]
CAUTION
l
Use the Numeric Keypad Panel in the environment defined in the general
specifications given in the GOT user's manual.
Using it in other environment can cause an electric shock, fire, misoperation,
or product damage or deterioration.
l
When plugging the connection cable, insert it into the Numeric Keypad Panel
connector until it "clicks".
After plugging, check that the cable is inserted far enough.
Otherwise, mis-input can occur due to a contact fault.
l
Plug the connection cable into the connector of the external I/O module and
tighten the connector fixing screws within the specified torque range.
Undertightening can cause mis-input due to a contact fault.
Overtightening can cause mis-input due to damaged screws or external
I/O module or a contact fault.
l
When installing the Numeric Keypad Panel to a control box, mount or the like,
tighten the fixing screws within the specified torque range.
Undertightening can cause a drop.
Overtightening can cause a drop due to damaged screws or Numeric Keypad
Panel.
[Precautions Regarding Wiring]
DANGER
l
Before starting wiring work, always switch power off externally in all phases.
A failure to do so can cause an electric shock, product damage or misoperation.
CAUTION
l
The FG wire of the connection cable and the FG terminal of the GOT's power
supply terminal block must be connected to ground separately using a class
3 or higher grounding method.
Otherwise, misoperation can occur.

A-3
[Precaution Regarding Startup and Maintenance]
CAUTION
l
Do not disassemble or modify the Numeric Keypad Panel.
This can cause a failure, misoperation, injury or fire.
l
The Numeric Keypad Panel case is made of resin.Do not drop it or give it hard
impact. This can cause the product to be damaged or fail.
l
Always secure the connection cable connected to the Numeric Keypad Panel
and the power wires drawn from the connection cable, e.g. run them in conduits
or clamp them.
Otherwise, the Numeric Keypad Panel or cable can be damaged due to dangling,
moved or accidentally pulled cable or misoperation can occur due to improper
cable connection.
l
Do not hold and pull the cable part when unplugging the connection cable
connected to the Numeric Keypad Panel or the power wires drawn from the
connection cable.
When the cable is fitted with a connector, hold the connector of the cable part
connected to the Numeric Keypad Panel.
If you pull the cable connected to the Numeric Keypad Panel, the Numeric
Keypad Panel or cable can be damaged or misoperation can occur due to a
contact fault.
[Precautions Regarding Product Disposal ]
CAUTION
l
When disposing of the product, handle it as industrial waste.

Contents
1. Introduction  1
2. System Configuration  3
2.1 System Configuration for No Outputs  3
2.2 System Configuration for Outputs  4
3. Connection Cables  5
3.1 Cable for Connection between External I/O Module and Numeric
Keypad Panel 5
3.1.1 Wiring method  5
3.1.2 How to fabricate the cable 6
3.2 Cable for Connection between Terminal Block Conversion Module and
Numeric Keypad Panel 8
4. Structure  11
5. Installation  12
6. Outline Drawing 13

1
1. Introduction
This user's manual gives specifications, handling instructions and other
information of the A8GT-TK Numeric Keypad Panel (hereafter referred to as
the "Numeric Keypad Panel").
First, please refer to the user's manual of the A8GT-70KBF/A8GT-50KBF
external I/O module (hereafter referred to as the "external I/O module") being
used.
The Numeric Keypad Panel is designed to be mountable onto a control box or
the like. It is connected to the external I/O module or terminal block conversion
module as a data entry Numeric Keypad Panel dedicated to the GOT800 series
(hereafter referred to as the "GOT").
MELSEC/A870GOT
MITSUBISHI
Connection cable Length
GOT
A8GT-TK
A8GT-70KBF/A8GT-50KBF
50cm
(19.69inch)
A8GT-C05TKA8GT-C05TK
Restrictions on use
·Do not press two or more switches of the Numeric Keypad Panel at the same
time.
Pressing two or more switches simultaneously can cause mis-input.
·When setting any operation to each key of the Numeric Keypad Panel on
theSW3NIW-A8GOTPgraphicsettingssoftwarepackage,re-set the default
key code of each key to “FFFF”.
Otherwise, operation setting will be invalid.

2
Performance Specifications
Applicable model A870GOT/A85 GOT
Connection interface A8GT-70KBF/A8GT-50KBF
Application Data entry from keyboard
Number of keys 31
Key makeup Function keys, cursor keys, ten-key pad, other
function keys
Keyboard
Operational life 200,000 times
Online
connection/disconnection
Disallowed
Outline dimensions(mm/inch) 197/7.76(H)×70/2.76(W)×15/0.59(D)
Weight(kg/lb) 0.13/0.29
For general specifications, refer to the user's manual of the GOT used.

3
2. System Configuration
The system configuration differs when outputs are provided by the external
I/O module and when outputs are not provided.
2.1 System Configuration for No Outputs
GOT
Connection cable
A8GT-C05TK*1
DC power supply 12/24V
Entry (Numeric Keypad Panel)
A8GT-TK
External I/O module
A8GT-70KBF/A8GT-50KBF A870/A85•
*1:The cable for connection between the external I/O module and
Numeric Keypad Panel may be fabricated by the user.

4
2.2 System Configuration for Outputs
External I/O module GOTConnection cable
A8GT-C30TB*1
DC power supply 12/24V
A8GT-70KBF/A8GT-50KBF A870/A85•
Outputs(Lamps,relays,etc.)
A6TBY36-E,A6TBY54-E
Connection cable
Fabricated by user
conversion module
Terminal block
Entry (Numeric Keypad Panel)
A8GT-TK
*1:The cable for connection between the external I/O module and
terminal block conversion module may be fabricated by the user.
For details of the fabricating method, refer to the user's manual of
the external I/O module.

5
3. Connection Cables
This chapter provides how to wire and fabricate the connection cables.
3.1 Cable for Connection between External I/O Module and
Numeric Keypad Panel
Use the following cable for connection between the external I/O module and
Numeric Keypad Panel.
· Type A8GT-C05TK Numeric Keypad Panel connection cable
(cable length:50cm (19.65 inch))
·User-fabricatedconnectioncable(max.cablelength:20m(65.62feet.))
3.1.1 Wiring method
The following diagram shows how to wire the cable for connection between
the external I/O module and Numeric Keypad Panel.
External supply power(12/24VDC)
External
I/O module
Numeric
Keypad
Panel
Red wire
(connect to +)
White wire
(connect to -)
Green wire(ground wire)

6
3.1.2 How to fabricate the cable
When you do not use the A8GT-C05TK Numeric Keypad Panel connection
cable, fabricate the connection cable in accordance with the following wiring
diagram and parts list (max. cable length: 20m (65.62 feet)).
(1) Wiring diagram
Numeric Keypad Panel
Connect shield to FG.
Wires for connection
with external input
power supply
12/24VDC
Shield
External I/O module side
4B
4A
3B
3A
2B
2A
1B
1A
8B
8A
7B
7A
6B
6A
5B
5A
9A
9B
10A
10B
11A
11B
12A
13A
13B
14A
14B
15A
15B
16A
16B
17A
17B
18A
18B
19A
19B
20A
20B
12B
Pin
number Signal name
XD0
XD1
XD2
XD3
XD4
XD5
XD6
XD7
XSCN0
YD15
HOT24/12
FG
XSCN1
XSCN2
XSCN3
XSCN4
XSCN5
XSCN6
XSCN7
YD14
YD13
YD12
YD11
YD10
YD9
YD8
YD5
YD4
YD3
YD2
YD1
YD0
YD7
YD6
HOT24/12
HOT24/12
RTN24/12
RTN24/12
XD0
XD1
XD2
XD3
XD4
XD5
XD6
XD7
XSCN0
XSCN1
XSCN2
XSCN3
XSCN4
XSCN5
XSCN6
XSCN7
Pin
number Signal name
Empty
Empty
1
19
2
20
3
21
4
22
6
24
7
25
8
26
9
27
5
23
10
28
11
29
12
30
13
14
32
15
33
16
34
17
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
Must not be used.
35
18
36
31
1) 2) 3) 4)
5)
7)
6)

7
(2) Parts list
Number Name Type Maker Qty
1) Connector FCN-361J040-AU 1
2) Connector cover
FCN-360C040-B
Tightening torque range:
35 to 48N·cm
(3.6 to 4.9kg·cm){3.1 to 4.2lb·inch}
FUJITSU LTD. 1
3) Connector D05-36PC-F0
Japan Aviation
Electronics
Industry, Ltd.
1
4) Connector cover D05-36H-S
Japan Aviatio
n
Electronics
Industry, Ltd.
1
Number Name Type Qty
5) Twisted pair
shielded cable
Conductor OD:1.0mm (0.04 inch)
(equivalent to UL 2935 AWG28) 1
6) FG wire Conductor OD:1.8mm (0.07 inch)
(equivalent to UL 1015 AWG14) 1
7)
External input
power supply
connecting wire
Conductor OD:0.6mm (0.02 inch)
(equivalent to UL 1007 AWG24) 2

8
3.2 Cable for Connection between Terminal Block Conversion
Module and Numeric Keypad Panel
Fabricate the cable for connection between terminal block conversion
module and Numeric Keypad Panel in accordance with the following wiring
diagram, parts list and assembly diagram (max. cable length: 10m
(32.79feet)).
(1) Wiring diagram
1) For use of the terminal block conversion module (A6TBY36-E)
12/24VDC
0 3 4 5 6 71 2-C -C -C -C
10 11
8
12 13 14 15 16 17 18 19 1A-C -C -C -C -C -C 1B 1C 1D
XSCN
0
XSCN1 XSCN2 XSCN3 XSCN4 XSCN5 XSCN6 XSCN7
Terminal block conversion module
9A-C -C BC D E-C -C F-C
1F1E-C -C -C 24V 0V
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Loads:Lamps,relays,etc.
(A6TBY36-E)
XD0 XD1 XD2 XD3 XD4 XD5 XD6 XD7
F8 F7 F6 F5 F4 F3 F2 F1
F9 F10
SP
SCR DWN
SCR UP
6 5 4 9 8 7
BS
0 - 3 2 1 .
Numeric Keypad Panel

9
2) For use of the terminal block conversion module (A6TBY54-E)
12/24VDC
0 3 4 5 6 71 2-C -C -C -C
10 11
8
12 13 14 15 16 17 18 19 1A-C -C -C -C -C -C 1B 1C 1D
XSCN
0
XSCN1 XSCN2 XSCN3 XSCN4 XSCN5 XSCN6 XSCN7
Terminal block conversion module
9A-C -C BC D E-C -C F-C
1F1E-C -C -C 24V 0V
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Loads:Lamps,relays,etc.
(A6TBY54-E)
XD0 XD1 XD2 XD3 XD4 XD5 XD6 XD7
F8 F7 F6 F5 F4 F3 F2 F1
F9 F10
SP
SCR DWN
SCR UP
6 5 4 9 8 7
BS
0 - 3 2 1 .
Numeric Keypad Panel

10
(2) Parts list
Number Name Specifications Qty
1)
Solderless
termi-nal (with
insulat-ion sleeve)
1.25-3.5 16
2) Twisted pair
shielded cable
Conductor OD: 1mm (0.04 inch)
(equivalent to UL 2935 AWG28) 1
Number Name Type Maker Qty
3) Connector D05-36PC-F0
Japan Aviation
Electronics
Industry, Ltd.
1
4) Connector cover D05-36H-S
Japan Aviation
Electronics
Industry, Ltd.
1
(3) Assembly diagram
2)
3) 4)
1)

11
4. Structure
F1 F2 F3
F4 F5 F6
F7 F8 F9
F10 SCROLL
UP
SP BS ðK
0•E-
1 2 3
4 5 6
7 8 9
SCROLL
DOWN
•ª
•«
•¨•©
MELSEC/A8GT-TK
1)
3)
2)
3)
(Front) (Rear)
Number Name Description
1) Keys Used to enter data.
2) Connector Connector for connection of the cable to the external
I/O module or terminal block conversion module.
3) Installation screw holes
(for M4 screws)
When the Numeric Keypad Panel is installed on a
control box or the like, it is fixed with M4 screws
(user prepared).
Screw hole depth: 5mm(0.20inch)
Tightening torque range:
62 to 83.5N·cm(6.3 to 8.5kg·cm){5.5 to 7.4lb·inch}

12
5. Installation
When installing the Numeric Keypad Panel on a control box door, mount or
the like, the door or mount must be machined.
The following diagram shows mounting panel machining dimensions.
Mounting panel machining dimensions (front view)
25{0.98}
25.5
{1.0}
172{0.77}
45{1.77}
2-φ5
79{3.11} 32.75{1.29}
Square
hole
(13.75)
{0.54}
{0.61}
(15.5) Unit:mm{inch}

13
6. Outline Drawing
F1 F2 F3
F4 F5 F6
F7 F8 F9
F10 SCROLL
UP
SP BS ðK
0•E-
1 2 3
4 5 6
7 8 9
SCROLL
DOWN
•ª
•«
•¨•©
MELSEC/A8GT-TK
197(7.76)
70(2.76) 4.5(0.18) 45(1.77)
172(6.77)
2-M4 screw,depth 5(0.20)
15
(0.59)
Unit: mm (inch)
