Mitsubishi GX36A User manual

MITSUBISHI TRACTOR
GX36A
OPERATOR'S MANUAL

hakusi

SAFETY/DECALS
i
CONTENTS
SAFETY / DECALS ......................................ii
SAFETY PRECAUTIONS ......................................... ii
DECALS................................................................... ix
PRIOR TO USE .............................................1
1. Warranty and Service.......................................... 1
2. Specifications (Equipment) ................................ 2
3. Terms and Glossary ............................................ 3
FUNCTIONS OF EACH PART ....................4
1. Names of each part ............................................. 4
2. Operating Controls.............................................. 5
1. Control Switches and Instruments ............................ 5
2. Levers, Pedals, and Seats ........................................ 8
3. Electric System.................................................. 13
1.Fuse ......................................................................... 13
4. Hydraulic System .............................................. 16
1. Operation of Control Levers .................................... 16
2. Flow Control ............................................................ 16
3. Power Steering........................................................ 17
5. PTO Cap ............................................................. 18
1. PTO Cap ................................................................. 18
OPERATION PROCEDURE ......................19
1. Inspection before Operation............................. 19
1. Inspecting Items ...................................................... 19
2. Operation Procedure......................................... 20
1. Engine Start ............................................................ 20
2. Starting Operation ................................................... 22
3. Driving ..................................................................... 23
4. Stopping .................................................................. 24
5. Driving on Slope...................................................... 25
WORKING PROCEDURE ..........................26
1. Field Work .......................................................... 26
1. Entry/Exit of Farm Field........................................... 26
2. Appropriate Speed for Work.................................... 27
3. Operation of Differential Lock.................................. 28
4.Turning in Farm Field ............................................... 28
2. Operation of Equipment Required for Work ... 29
1. Implements.............................................................. 29
MAINTENANCE ..........................................30
1. Periodical Inspection and Maintenance List... 30
2. Oil Supply, Lubrication and Water supply....... 32
1. Points for Oil Supply, Lubrication and
Water supply ........................................................... 32
2. Oil Supply, Lubrication and Water supply List ......... 33
3. Inspection and Replacement of Engine Oil ............. 34
4. Replacement of Engine Oil Filter ............................ 35
5. Refueling ................................................................. 35
6. Replacement and Cleaning of Fuel Filter................ 36
7. Air Vent Procedure .................................................. 36
8. Cleaning of Fuel Tank ............................................. 37
9. Maintenance of Coolant Water................................ 37
10. Inspection and Replacement of Transmission Oil . 39
11. Replacement of Hydraulic Oil filter ........................ 40
12.
Inspection and Replacement of Front Axle Oil ............. 40
13. Lubrication of Each Part........................................ 41
3. Cleaning of Each Part ....................................... 42
1. Cleaning of Air Cleaner ........................................... 42
2. Cleaning of Radiator and Radiator Screen ............. 42
4. Inspection and Adjustment of Each Part ........ 43
1. Inspection and Adjustment of Fan Belt.................... 43
2. Inspection and Adjustment of Clutch Pedal............. 43
3. Inspection and Adjustment of Toe-In ....................... 44
4. Inspection and Adjustment of Brake Pedals............ 45
5. Inspection of Tires ................................................... 46
6. Inspection of Steering Wheel .................................. 46
7. Inspection of Hoses................................................. 47
8. Inspection and Cleaning of Electric Wirings............ 47
9. Inspection and Recharging of Battery ..................... 48
LONG-TERM STORAGE ...........................53
1. Cleaning, Washing, and Storage of Tractor ............ 53
2. Maintenance during Storage ................................... 54
3. Reuse...................................................................... 54
TROUBLESHOOTING ...............................55
1. Engine................................................................. 55
1. Engine does not start. Trouble at starting. .............. 55
2. Insufficient engine output and engine stop.............. 56
2. Driving and Operating Unit............................... 57
1. Tractor does not start. Brake is not applied............. 57
2. Power Steering........................................................ 57
3. Hydraulic Unit .................................................... 58
1. Hydraulic Systems .................................................. 58
4. Electric and Automatic Control Unit................ 58
1. Electric Systems...................................................... 58
APPENDIX TABLE .....................................59
1.General Data ....................................................... 59
2. Consumables..................................................... 60
1. Engine ..................................................................... 60
2. Air Cleaner and Hydraulic Line................................ 60
3. Electric Components ............................................... 61

SAFETY/DECALS
ii
SAFETY PRECAUTIONS
REMEMBER: "SAFETY" IS ONLY A WORD UNTIL IT IS PUT INTO PRACTICE
Improper handling of the tractor could cause an accident. Prior to the operation of the tractor,
be sure to read this Manual carefully and have a through understanding of all of the contents.
In particular, the instructions given in this section entitled "Safety Precautions" must be strictly
followed.
A. GENERAL OPERATING SAFETY
PRECAUTION
1. Observe all the safety precautions in this
manual when operating the tractor.
2. Operate the tractor while wearing tight
clothing that allows easy movement. Avoid
loose jackets, mufflers, ties, scarves, or
loose shirt sleeves to prevent from being
caught by moving parts.
3. Always work when you are in good
physical condition by taking sufcient rest
to avoid overwork.
4. Do not allow children or adults having
no knowledge of the tractor or tractor
operation, to operate the tractor.
5. Never allows riders on the tractor, linkage
drawbar or attachment while traveling and
operating them.
B. BASIC SAFETY REQUIREMENTS
FOR MAINTENANCE
Always follow these maintenance instructions
before operating the tractor:
1. Immediately repair the head lights and
work lamps required to conform to trafc
regulations where the tractor is operated.
2. Keep tractor steps clean to avoid
accidents due to slippage.

SAFETY/DECALS
iii
3. Cover the PTO shaft with a guard when
not using.
4. Be sure to engage the brake and lower
any attachment or implement before
disassembling any part.
5. Never adjust or service the tractor when
it is in motion or while the engine is
running. Always adjust the brake or clutch
properly in accordance with the adjusting
procedure in the operator's manual.
6. Do not remove the radiator cap while the
engine is running. Shut down the engine
and wait until it cools sufficiently. For
removal, turn the cap to the first stop to
relieve pressure. To replace the coolant,
use the coolant recovery tank.
7. Hydraulic oil or fuel escaping under
pressure can penetrate the skin, causing
serious injury. Before disconnecting oil or
fuel lines, be sure to relieve all pressure.
Before restoring pressure after repair,
be sure all connections are tight and
all hydraulic components are in normal
condition. If injured by leaked uid, see a
doctor immediately for proper treatment.
8. When refueling, be particularly careful rst
to stop the engine completely to prevent
the fuel from igniting. Never refuel in
the presence of an open flame or while
smoking.

SAFETY/DECALS
iv
9. Before starting any work on electrical
equipment or work that may cause you
to touch the electrical parts accidentally,
rst disconnect the battery cables. Never
remove the rubber cap cover at the
positive terminal of the battery cable
end. Before connecting the battery to
the charger, make sure that the charger
switch is in "OFF" position.
Be sure to connect the charger to the
correct terminals on the battery (positive
to positive, negative to negative).
A great amount of hydrogen gas is
generated by the battery when it is being
charged. Take precautions against re: Do
not have any exposed flame in the area
where you are working.
Be sure not to cause any leakage of the
electrolyte, since it will corrode the skin or
clothing. In case of accident as described
below, immediately seek rst aid, and see
a doctor immediately for proper treatment.
a) If the diluted sulphuric acid from the
battery has gotten into the eyes:
Clean the eyes with a lot of clean running
water for more than 15 minutes, while
opening the eyes widely, and see a doctor
immediately for proper treatment.
b) If diluted sulphuric acid from the battery
has been swallowed: Rinse the mouth
with clean water immediately, and drink a
lot of raw eggs or milk. Lie down quietly.
see a doctor immediately for proper
treatment.
c) If diluted sulphuric acid has gotten on the
skin of clothing: Wash away the diluted
sulphuric acid completely with a lot of
clean running water and neutraize with
soap solution. Then rinse with water.
d) If the diluted sulphric acid is spilled: Wash
away with a lot of water or neutralize with
slacked lime or bicarbonate of soda.
10. Stop the engine and make sure the
rear PTO shift lever is in Neutral before
performing any of the following services,
including.
a) Removal of the propeller shaft between
PTO and any attachment.
b) Adjustment of PTO drive train and hitch.
c) Adjustment or cleaning of PTO driven
attachment.
11.The steering wheel always has built-in
play to some extent, which is required for
smooth meshing of sector gear and pinion
gear.
Always inspect the amount of the play. Do
not operate the tractor if there is too much
or too little play in the steering.

SAFETY/DECALS
v
C. OPERATION OF THE TRACTOR
Before driving the tractor, follow these rules:
C-1. Before starting and Driving the Tractor
Operate the tractor only when seated
properly in operator’s seat and keep a rm
grip on the steering wheel at all times.
Never attempt to perform any operation
of the tractor from anywhere else, on or
off the tractor. Always wear a "hard hat"
when operating the tractor.
C-2. Starting and Driving the Tractor
Always operate the tractor at the proper
speeds which enable you to keep the
tractor in complete control.
To start traveling, lower the engine speed
and release the clutch pedal slowly.
Before leaving the tractor, stop the engine,
remove the key, apply the parking brake
and make sure that the engine has come
to a complete stop, and any attachment is
completely touching the ground.

SAFETY/DECALS
vi
Slow down when operating the tractor on
rough ground.
Never attempt to jump on or off from
moving tractor.
When starting the tractor, operating any
attachment or engaging the PTO make
sure that no one is in the way, especially
children.
When starting the engine in an enclosed
area or building, ensure proper ventilation
by opening the doors and/or windows to
prevent carbon monoxide inhalation.
Mount the extension exhaust pipe on the
tractor which has a cabin.
Use of the seat belt is not recommended
for tractor without ROPS.

SAFETY/DECALS
vii
C-3. Traveling on Roads and Streets
For traveling on roads and streets, be
sure to lock both brake pedals together
before driving to prevent either brake from
acting independently.
Never operate the differential lock while
driving at high speed or traveling on the
road. For driving the MFD tractor on the
road, be sure to place the MFD shift lever
in OFF position.
C-4. Steering and Turning the Tractor
Slow down your tractor and disengage the
differential lock before going into a turn,
being careful to prevent any attachments
mounted on the front or rear from hitting
anyone or anything.
C-5. Towing and Operating on Hills
For towing work on downward slope,
place the shift lever in low speed and use
engine brake.
Never try to reduce the speed with brake
only.
Towing a heavy object on a hill is highly
hazardous. Widen the tread of the tractor
and mount the wheel weight or chassis
weight to increase the stability and
operate with extra precaution.

SAFETY/DECALS
viii
When operating the tractor on either a
steep slope or at ground, be sure not to
suddenly steer, brake, clutch or operate
attachments.
Do not operate the tractor at the edge of
cliff or steep slope. Be particularly careful
right after the rain when soil is soft and
may give way easily.
For towing, be sure to use the drawbar
only. Set the hitch point below the center
line of the rear axle. When using a chain,
never try to move forward abruptly.
Avoid operating the tractor on an extreme
slope that appears hazardous, when
forced to operate on such slope, use extra
care. Driving forward out of a ditch or
mired condition or up a steep slope could
cause tractor to tip over rearward.
Back out of such situation if possible.
If the situation does not permit you back
out, use the front wheel weight or the
chassis weight for balancing the tractor
lengthwise. Also in case any extra-heavy
rear mounting. Attachments is used, try to
obtain better balance in this manner.
C-6. Using Attachment
To mount or operate attachment, follow
the instruction manual for the particular
attachment for safe operation.
When using agricultural chemicals with
an attachment on the tractor, always
follow the instructions in the manual for
the attachment as well as the instructions
provided by the chemical manufacturer.

SAFETY/DECALS
ix
DECALS
Decals stating how to handle each driving device safely on the tractor and they are installed near
each driving device. Read and observe the instructions shown in the decals.
If the decals are illegible due to damage, lost painted over or cannot be read, be sure to order new
decals to the dealer and replace to the new parts.
1944_0001
1
2
[ Air cleaner cover ]
[ Upper part battery ]

SAFETY/DECALS
x
Decals list
No. Part No. Part Name
1 1904 2746 000 Label Warning
2 1944 2784 000 Label Battery
3 1944 2783 000 Label Warning
4 1944 2786 000 Label Warning
1944_0002a
4
㹡㹭㹬㹲㹰㹭㹪㹱ࠉ㹟㹰㹣ࠉ㹭㹤㹤㸬
%()25(67$57,1*(1*,1(
㹐㹣㹟㹢ࠉ㹭㹮㹣㹰㹟㹲㹭㹰㹱ࠉ㹫㹟㹬㹳㹟㹪ࠉ㹤㹭㹰
㹱㹟㹤㹣㹲㹷ࠉ㹧㹬㹤㹭㹰㹫㹟㹲㹧㹭㹬ࠉ㹟㹬㹢ࠉ㹭㹮㹣㹰㹟㹲㹧㹬㹥
㹧㹬㹱㹲㹰㹳㹡㹲㹧㹭㹬㹱㸬
㹐㹣㹟㹢ࠉ㹟㹪㹪ࠉ㹲㹰㹟㹡㹲㹭㹰ࠉ㹱㹟㹤㹣㹲㹷ࠉ㹱㹧㹥㹬㹱㸬
㹀㹣ࠉ㹱㹳㹰㹣ࠉ㹭㹲㹦㹣㹰ࠉ㹮㹣㹭㹮㹪㹣ࠉ㹟㹰㹣ࠉ㹡㹪㹣㹟㹰
㹭㹤ࠉ㹲㹰㹟㹡㹲㹭㹰ࠉ㹟㹬㹢ࠉ㹣㹯㹳㹧㹮㹫㹣㹬㹲㸬
㹀㹣ࠉ㹱㹳㹰㹣ࠉ㹟㹪㹪ࠉ㹥㹣㹟㹰㹱ࠉ㹱㹦㹧㹤㹲㹣㹢ࠉ㹟㹰㹣ࠉ㹧㹬
㹬㹣㹳㹲㹰㹟㹪ࠉ㹭㹰ࠉ㹮㹟㹰㹩ࠉ㹟㹬㹢ࠉ㹟㹪㹪ࠉ㹎㹒㹍
㹑㹲㹟㹰㹲ࠉ㹣㹬㹥㹧㹬㹣ࠉ㹭㹬㹪㹷ࠉ㹤㹰㹭㹫ࠉ㹱㹣㹟㹲㸬
㹑㹦㹧㹣㹪㹢㹱ࠉ㹟㹰㹣ࠉ㹤㹭㹰ࠉ㹷㹭㹳㹰ࠉ㹮㹰㹭㹲㹣㹡㹲㹧㹭㹬㸬
㹉㹣㹣㹮ࠉ㹲㹦㹣㹫ࠉ㹧㹬ࠉ㹮㹪㹟㹡㹣㸬
23(5$7,21
㹉㹣㹣㹮ࠉ㹦㹟㹬㹢㹱㸪㹤㹣㹣㹲㸪㹟㹬㹢ࠉ㹡㹪㹭㹲㹦㹧㹬㹥
㹟㹵㹟㹷ࠉ㹤㹰㹭㹫ࠉ㹮㹭㹵㹣㹰ࠉ㹢㹰㹧㹴㹣㹬ࠉ㹮㹟㹰㹲㹱㸬
㹄㹭㹰ࠉ㹰㹭㹟㹢ࠉ㹲㹰㹟㹴㹣㹪㸪㹡㹭㹳㹮㹪㹣ࠉ㹠㹰㹟㹩㹣
㹮㹣㹢㹟㹪㹱㸪㹳㹱㹣ࠉ㹤㹪㹟㹱㹦㹧㹬㹥ࠉ㹵㹟㹰㹬㹧㹬㹥
㹪㹟㹫㹮㹱ࠉ㹳㹬㹪㹣㹱㹱ࠉ㹮㹰㹭㹦㹧㹠㹧㹲㹣㹢ࠉ㹠㹷
㹪㹟㹵㸪㹟㹬㹢ࠉ㹩㹣㹣㹮ࠉ㹑㹋㹔ࠉ㹣㹫㹠㹪㹣㹫㹴㹧㹱㹧㹠㹪㹣㸬
75$&7256&$1%(836(7
㹐㹣㹢㹳㹡㹣ࠉ㹱㹮㹣㹣㹢ࠉ㹭㹬ࠉ㹲㹳㹰㹬㹱ࠉ㹟㹬㹢ࠉ㹰㹭㹳㹥㹦
㹥㹰㹭㹳㹬㹢㸬㸿㹴㹭㹧㹢ࠉ㹱㹲㹣㹣㹮ࠉ㹱㹪㹭㹮㹣㹱㸬
㸿㹴㹭㹧㹢ࠉ㹰㹣㹟㹰ࠉ㹳㹮㹱㹣㹲㸬㹎㹳㹪㹪ࠉ㹭㹬㹪㹷ࠉ㹤㹰㹭㹫
㹢㹰㹟㹵㹠㹟㹰㸪㹬㹣㹴㹣㹰ࠉ㹦㹧㹥㹦㹣㹰㸬
:+(175$&725+$667233('
㹃㹬㹥㹟㹥㹣ࠉ㹮㹟㹰㹩ࠉ㹪㹭㹡㹩ࠉ㹭㹰ࠉ㹠㹰㹟㹩㹣㸬
㹊㹭㹵㹣㹰ࠉ㹧㹫㹮㹪㹣㹫㹣㹬㹲ࠉ㹲㹭ࠉ㹥㹰㹭㹳㹬㹢㸬
㹂㹧㹱㹣㹬㹥㹟㹥㹣ࠉ㹎㹒㹍㸪㹱㹲㹭㹮ࠉ㹣㹬㹥㹧㹬㹣㸪
㹟㹬㹢ࠉ㹵㹟㹧㹲ࠉ㹤㹭㹰ࠉ㹟㹪㹪ࠉ㹫㹭㹴㹣㹫㹣㹬㹲ࠉ㹲㹭
㹱㹲㹭㹮ࠉ㹠㹣㹤㹭㹰㹣ࠉ㹱㹣㹰㹴㹧㹡㹧㹬㹥ࠉ㹭㹰
㹡㹪㹣㹟㹰㹧㹬㹥ࠉ㹣㹯㹳㹧㹮㹫㹣㹬㹲㸬
㹌㹭ࠉ㹰㹧㹢㹣㹰㹱ࠉ㹭㹬ࠉ㹲㹰㹟㹡㹲㹭㹰ࠉ㹭㹰
㹣㹯㹳㹧㹮㹫㹣㹬㹲㸬
㹐㹣㹟㹢ࠉ㹲㹦㹣ࠉ㹫㹟㹬㹳㹟㹪ࠉ㹭㹤ࠉ㹲㹰㹟㹡㹲㹭㹰ࠉ㹟㹬㹢ࠉ㹧㹫㹮㹪㹣㹫㹣㹬㹲ࠉ㹵㹧㹲㹦ࠉ㹡㹟㹳㹲㹧㹭㹬
㹟㹬㹢ࠉ㹡㹭㹬㹬㹣㹡㹲ࠉ㹲㹦㹣ࠉ㹧㹫㹮㹪㹣㹫㹣㹬㹲ࠉ㹡㹭㹰㹰㹣㹡㹲㹪㹷㸬
㹐㹣㹥㹳㹪㹟㹲㹣ࠉ㹦㹣㹧㹥㹦㹲ࠉ㹭㹤ࠉ㹲㹦㹣ࠉ㹧㹫㹮㹪㹣㹫㹣㹬㹲ࠉ㹵㹧㹲㹦ࠉ㹲㹦㹣ࠉ㹳㹮㹮㹣㹰
㹪㹧㹫㹧㹲ࠉ㹱㹲㹭㹮㹮㹣㹰ࠉ㹭㹤ࠉ㹮㹭㹱㹧㹲㹧㹭㹬ࠉ㹪㹣㹴㹣㹰㸬
㹁㹍㹌㹌㹃㹁㹒㹇㹍㹌ࠉ㹍㹄ࠉ㹇㹋㹎㹊㹃㹋㹃㹌㹒
㹒㹍ࠉ㹎㹐㹃㹔㹃㹌㹒ࠉ㸿㹌ࠉ㹇㹌㹈㹓㹐㹗ࠉ㸿㹁㹁㹇㹂㹃㹌㹒ࠉ㸿㹌㹂ࠉ㹂㸿㹋㸿㹅㹃ࠉ㹍㹄ࠉ㹋㸿㹁㹆㹇㹌㹃
ە
ە
4
3

PRIOR TO USE
1
1. Warranty and Service
- Please read Limited Warranty Description carefully prior to use.
- Contact the dealer for service and purchase of any parts for this machine. Please inform the model name,
serial number, and engine number when contacting.
Purpose of Use
- Do not modify the machine.
- If the machine is modified, it is out of warranty. Please refer to the limited warranty description for details.
PRIOR TO USE
- Do not modify the machine. If the machine is modified, it can not only reduce its original
performance but also may cause a fatal injury.
WARNING
1944_0003b
Location of Serial No.
(Left Side)
Location of Model Plate
Location of Engine No.

PRIOR TO USE
2
2. Specifications (Equipment)
The main specification (equipment) is as described below.
Some parts may be changed for purpose of quality and performance improvement and safety reasons. In
case any changes are made, some parts of this manual, pictures, and drawings may not be matched to the
actual product.
Power steering
Position control
Model Type
Specification
Mitsubishi GX36A

PRIOR TO USE
3
3. Terms and Glossary
Expression such as Left, Right, Front, or Rear used in this manual should be understood in accordance
with following rules; Front means the front grille end while Rear means the lifting arm end of the tractor.
Left or Right means the left or right hand side of the tractor looking forward from operator's seat.
Definition of Signs
Items to be followed are indicated with the following signs in this instruction manual.
- : Important items for safety are categorized in three levels and
described. Please be sure to read thoroughly.
- NOTE : Points to bring out the full performance of the machine are described. If not followed, it may
cause machine damage.
1944_0004b
Right Rear
Front Left
Turn Right (Clockwise) Turn Left (Counterclockwise)

FUNCTIONS OF EACH PART
4
1. Names of each part
FUNCTIONS OF EACH PART
1944_0005b
Headlight
Engine Control Lever
(Throttle Lever)
Position Control Lever
Parking Brake Lever
Accelerator Pedal
Flow Control Grip
Brake Pedal (Left) (Right)
Turn Signal Indicator (Right)
1944_0006
MFD Control Lever
Step
Clutch Pedal
Fuel Tank
Muffler Fuel Cap
Shuttle Shift Lever
Steering Wheel
Hood
Radiator
Air Cleaner
Battery
Turn Signal Indicator (Left)
Alternator

FUNCTIONS OF EACH PART
5
三菱取説トラクタ G5000Z No. ０１０８０１−１９４３３７１１０００
2. Operating Controls
1. Control Switches and Instruments
1944_0007
Meter Panel
Engine Control Lever
(Throttle Lever)
Brake Pedal (Left) (Right)
Clutch Pedal
Shuttle Shift Lever
1944_0008
Engine Oil
Pressure Indicator
Turn Signal Lamps
Battery Charge Indicator
Engine Coolant
Temperature Gauge
Fuel Gauge
Hourmeter
Starter Key Switch
Tachometer
Combination Switch
・Headlight Switch
・Horn Switch
・Turn Signal Switch
4
7
9
3
1
5
8
6
2

FUNCTIONS OF EACH PART
6
< > {OFF}
The starter key switch can be removed in this
position. Engine and all lamps except the turn
signal and flasher lamps are turned off.
< > {ON}
First position turn to forward from OFF.
The charge indicator and oil pressure indicator
will illuminate.
The fuel gauge and temperature gauge will
show correct values.
< > {HEAT}
In this position (Engine not running) energizes
the glow plugs.
NOTE
Time to warm the engine is less than 8
seconds.
< > {START}
Turn the key fully forward against the force of
the spring in the switch.
The starter motor will turn the engine. Release
the key immediatery when the engine starts.
NOTE
- The engine does not start if the clutch pedal
is stepped completely.
1944_0009
Starter Key Switch
OFF HEAT START
Manual Manual
Automatic
Return
ON
Manual
Tachometer
The tachometer shows the engine speed in
revolutions per minute (RPM).
Hourmeter
The hour meter displays the adjusting time at
the engine driving time.
Fuel Gauge
The meter shows how much fuel is in the tank.
NOTE
- The pointer can be in lowest position when
the starter key switch is in the OFF
position. To get a fuel level indication, turn
the starter key switch to the ON position.
Engine Coolant Temperature Gauge
The gauge indicates the coolant temperature
when the starter key switch is in ON position.If
the engine overheats, the pointer moves to the
up side into H position area. In this case,
discontinue work and run the engine at
1500rpm without load until pointer moves
down. If the pointer stays high temperature
area, stop the engine. After the engine cools
down, check for the cause.
Starter Key Switch
三菱取説トラクタ G5000Z No. ０１０８０１−１９４３３７１１０００
For injury accident prevention
- Keep the key removed when not using
the tractor.
WARNING

FUNCTIONS OF EACH PART
7
三菱取説トラクタ G5000Z No. ０１０８０１−１９４３３７１１０００
Battery Charge Indicator ( )
The charge indicator shows the battery is being
discharged.If the lamp illuminates during
operation, stop the engine and check for the
cause.
Engine Oil Pressure Indicator ( )
The engine oil pressure indicator shows low
engine oil pressure.If the engine oil pressure
drops below its normal pressure, the engine oil
pressure indicator will turn on. Shut off the
engine immediately. Check for the cause.
Turn Signal Lamps
The LH indicator on the TACHOMETER will
operate when the turn signal switch is turned to
the left. The RH indicator will operate when the
switch is turned to the right.
Combination Switch
(1) Headlight Switch
�������������� ALL lamps are OFF. (Turn signal
and flasher lamps can be turned
on.)
�������� First position clockwise illuminates
head lamps,instrument panel and
rear red lamp.
(2) Horn Switch
Press the button to energize the horn.
(3) Turn Signal Switch
To indicate that you are going to turn the tractor
to the RIGHT, move the turn signal switch to
right. To indicate that you are going to turn the
tractor to the LEFT, move the turn signal switch
to left. Center position is OFF.
�������� Turn right
�������� Turn left
MN00002_A
(2) Horn Switch
(3) Turn Signal Switch
(1) Headlight Switch

FUNCTIONS OF EACH PART
8
三菱取説トラクタ G5000Z No. ０１０８０１−１９４３３７１１０００
2. Levers, Pedals, and Seats
NOTE
- When changing the gear, depress on the clutch pedal.
Clutch Pedal Operation
Main shift lever
Shuttle shift lever
Sub shift lever
Rear PTO shift lever
MFD control lever
Required
Required
Required
Required
Required
1944_0010
Rear PTO Shift Lever
Accelerator Pedal
Brake Pedal
Parking Brake Lever
Hood
Side Cover
Clutch Pedal
Shuttle Shift Lever
MFD Control
Lever
Sub Shift Lever
Main Shift Lever
Engine Speed Control Lever
(Throttle Lever)
Differential
Lock Pedal
1
2
10
4
11
9
6
8
7
5
3
12
13
