Mixcder T2 User manual

User Manual
Totally Wireless Sports Earphones
Model: T2

2. Package Contents
-1 x Pair of Wireless Earphones
-1 x Charging Case
-1 x Micro USB Cable
-1 x User Manual
-3 x Pairs of Ear Tips
(Note: One of them is equipped with earphones)
1.Product Overview
Volume +/ Previous Track
Volume -/ Next Track
Power Button (MFB)
Charging Contacts
Smart LED Display
EN-1

3.Specifications
EN-2
AVRCP, A2DP, HFP,
Simultaneous LE and BR, EDR
Earphone: 100mAh;
Charging Case: 950mAh
(it can charge the earphones
for 4-5 times)
Up to 10 hours wireless play;
50 hours with charging case
Earphone: about 1-1.5 hours;
Charging Case: about 2 hours
S.P.L -42±3dB
Speaker Diameter Φ10mm
Impedance 16Ω
S/N ≥90dB
Rated Power 2.5mW
Frequency Response 50Hz-20KHz
Wireless Version V5.0
Wireless Distance 33ft/10m
Transmission Range 2.40GHz-2.48GHz
Reception Sensitivity -85dBm
Support Profile
Pairing Name Mixcder T2
Battery Capability
Charging Port Micro USB
Playtime
Charging Time
Microphone Spec.
Speaker Spec.
Wireless Spec.
Battery Spec.

4.Charging
5.Buttons & Function & Operation
Prior to the first use, please make sure both the earphones and charging
case are fully charged.
Charge the Charging Case
Please use the supplied charging cable to connect the charging case to a
charger or PC to charge. While charging, the LED digital display will show
the current battery capacity.
Charge the Earphones
Put the earphones back into the charging case, and the earphones will
power off and be charged automatically. During charging, LED turns solid
red; after fully charged, LED turns to solid blue for 1min and then turns off.
"+" Button: Short press for volume up/ Long
press for previous track
"-" Button: Short press for volume down/ Long
press for next track
Power Button (MFB)
Answer/End a call: Press the Power Button once
Reject an Incoming Call: Press the Power Button twice
To Activate Siri: Press the Power Button until you hear a prompt.
EN-3

6.Operating Instructions
6-1 Pairing Single Earphone with Your Device
1.Take out the L or R earphone from the charging case, it will auto power on
(LED flashes Red and Blue alternately).
2.Turn on the Bluetooth on your device and choose Mixcder T2 to pair.
1.Take out the L&R earphones from the charging case, and they will
automatically power on (LED flashes Red and Blue alternately) and pair
with each other.
2.Once they successfully paired with each other, LED of one earphone
goes off and the other earphone flashes Red and Blue alternately.
3.Please turn on the Bluetooth on your device and choose Mixcder T2 to
pair.
Note: If you have previously paired the earphones with a device, they will
reconnect with the device automatically when you turn them on.
6-2.Pairing the L&R Earphones with Your Device
EN-4

7.Troubleshooting
How to Restore the Factory Settings?
If the two earphones fail to pair with each other automatically due to
unknown reasons, please do the following steps to restore the factory
settings:
a). Take out the L&R earphones from the charging case simultaneously and
hold down on the power button for 5s to turn them off;
b). Press power buttons of L&R earphones simultaneously for 9s until the
light slowly flashes red and blue twice. Let go your hands and light goes off.
Note: After restoring the factory settings, you need to re-pair the
earphones with your device. Delete the pairing name on your device
Bluetooth list before pairing. Re-search Mixcder T2 and click it to pair again.
How to Switch ON/OFF the Earphones?
To Switch ON: Take out the earphone from the charging case and it will
power on automatically; Or hold down on the power button for about 2s,
LED flashes Blue and you will hear "Power On".
To Switch OFF: Put the earphone back into the charging case and it will
power off automatically; Or hold down on the power button for about 5s until
LED flashes red and you will hear "Power Off".
EN-5

8.Safety Precautions
Mixcder T2 is of excellent quality, and in order to extend lifespan, please
refer to the instructions below:
1. Please keep the earphones out of extreme heat, humidity and corrosion
environment.
2. Please prevent the earphones from being struck, fell, warped, soaked etc.
3. Please don't dismantle the earphones or the charging case.
4. Please don't overcharge the earphones for quite a long time. Otherwise, it
will decrease lifespan.
5. Please use DC5V/1A chargers/adapters certified by a regulated manufac-
turer.
6. Please stop using the earphones if it causes any discomfort or pain.
9.Warranty
The Mixcder T2 is covered by a 1-year manufacturer warranty. For more
information, please visit: https://www.mixcder.com/.
EN-6

2. Contenu de l’emballage
- 1 x paire d’écouteurs sans fil
- 1 x boîtier de charge
- 1 x câble micro-USB
- 1 x manuel d'utilisation
- 3 x paires d'embouts auriculaires
(Remarque: l'une d'elles est équipée d'écouteurs)
1. Aperçu du produit
Volume + / Piste précédente
Volume - / Piste suivante
Bouton d'alimentation (MFB)
Contacts de charge
Écran LED intelligent
FR-1

3. Caractéristiques
FR-2
AVRCP, A2DP,HFP,
LE et BR, EDR simultanés
Écouteur: 100 mAh;
Boîtier de charge: 950 mAh (il
peut recharger les écouteurs
4 à 5 fois)
Jusqu'à 10 heures d'écoute
sans fil; 50 heures avec l'étui
de charge
Écouteur: environ 1 à 1,5 heure;
Boîtier de charge: environ 2 heures
SPL -42±3dB
Diamètre du haut-parleur Φ10mm
Impédance 16Ω
S/N ≥90dB
Puissance nominale 2.5mW
Réponse de fréquence 50Hz-20KHz
Version sans fil V5.0
Distance sans fil 33ft/10m
Plage de transmission 2.40GHz-2.48GHz
Sensibilité de réception -85dBm
Profil de Support
Dénomination du couplage Mixcder T2
Capacité de la batterie
Port de charge Micro USB
Temps de lecture
Temps de charge
Caractéristiques
du microphone
Caractéristiques
du haut-parleur
Caractéristiques
du sans fil
Caractéristiques
de la batterie

4. Charge
Avant la première utilisation, veuillez vous assurer que les écouteurs et le
boîtier de charge sont complètement chargés.
Charger le boîtier de charge
Utilisez le câble de charge fourni pour connecter le boîtier de charge à un
chargeur ou à un PC pour le charger. Pendant le chargement, l’affichage
numérique à LED indiquera la capacité actuelle de la batterie.
Charger les écouteurs
Introduisez les écouteurs dans le boîtier de charge; ils s’éteignent et se
chargent automatiquement. Pendant la charge, le voyant LED passe au
rouge continu; une fois complètement chargés, le voyant vire au bleu
pendant 1 min, puis s’éteint.
Bouton d'alimentation (MFB)
Répondre / Mettre fin à un appel: Appuyez une fois sur le bouton
d'alimentation
FR-3
5. Touches, fonctions et fonctionnement
Touche«+»: Appuyez brièvement pour augmenter le
volume / Appuyez longuement pour passer à la piste
précédente
Touche«-»: Appuyez brièvement pour baisser le volume
/ Appuyez longuement pour passer à la piste suivante
