MK Diamond Products MK-170 SERIES System manual

MK-170 SERIES
CAUTION:
Read all safety and
operating instructions
before using this
e
q
ui
p
ment
TILE SAW
OWNER’S MANUAL &
OPERATING INSTRUCTIONS
Enter the Serial Number of your new saw in the
space below. The Serial Number is located on the
rear of the Cutting Head.
NOTE:
For your (1) one year warranty to be effective,
complete the warranty card (including the Serial
Number and mail it in as soon as possible.
SERIAL NUMBER:

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 2
INTRODUCTION
We at MK Diamond want to congratulate you on selecting the MK-170 Tile Saw. We are certain that you will
be pleased with your purchase. MK Diamond takes pride in producing the finest products in the industry.
Operated correctly, your MK-170 should provide you with years of quality service. In order to help you, we
have included this manual. This owners manual contains information necessary to operate and maintain your
MK-170 safely and correctly. Please take a few minutes to familiarize yourself with the MK-170 by reading
and reviewing this manual.
If you should have questions concerning your MK-170, please feel free to call our friendly customer service
department at: 800 421-5830
Regards,
MK Diamond

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 3
TABLE OF CONTENTS
Page
SAFETY:
Safety Messages 4
Damage Prevention Message 4
General Safety Precautions and Hazard Symbols 4
California Proposition 65 Message 6
Electrical Requirements and Grounding Instructions 7
Safety Label Locations 9
Tile Saw Specific Warnings 9
Product Specifications 10
UNPACKING, TRANSPORT, UNIVERSAL STAND, and ASSEMBLY
Unpacking 11
Contents 11
Transport 11
Assembly 12
SETUP, ADJUSTMENT AND OPERATION
Setup 14
Adjustment and Operation 16
Cleanup 17
MAINTENANCE AND TROUBLESHOOTING
Maintenance 19
Troubleshooting 21
EXPLODED VIEW AND PARTS LIST
Exploded View 24
Parts List 25
THEORY
Theory of Diamond Saws 27
ACCESSORIES
Accessories 28
ORDERING and RETURN INSTRUCTIONS
Ordering Information 29
Return Material Policy 29
Packaging Instructions 29
Authorized Service Centers 29
Manual Part No. 157243 Revision No. 02/02

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 4
SAFETY
Read and follow all safety, operating and maintenance instructions. Failure to read and follow these
instructions could result in injury or death to you or others. Failure to read and follow these instructions could
also result in damage and/or reduced equipment life.
SAFETY MESSAGES:
Safety messages inform the user about potential hazards that could lead to injury, death and/or equipment
damage. Each safety message will be preceded by one of the following (3) three words that identify the
severity of the message.
Not following instructions WILL lead to DEATH or SERIOUS INJURY
Not following instructions COULD lead to DEATH or SERIOUS INJURY
Not following instructions CAN lead to injury
DAMAGE PREVENTION AND INFORMATION MESSAGES:
A Damage Prevention Message is to inform the user of important information and/or instructions that could
lead to equipment or other property damage if not followed. Information Messages convey information that
pertains to the equipment being used. Each message will be preceded by the word NOTE, as in the example
below.
NOTE:
Equipment and/or property damage may result if these instructions are not followed.
GENERAL SAFETY PRECAUTIONS AND HAZARD SYMBOLS:
In order to prevent injury, the following safety precautions and symbols should be followed at all times!
Safety Precautions:
KEEP GUARDS IN PLACE.
REMOVE ADJUSTING KEYS AND WRENCHES.
Form a habit of checking to see that keys and adjusting wrenches are removed from the power tool before it
is turned on.
KEEP WORK AREA CLEAN.
Cluttered work areas and benches invite accidents.
DO NOT USE IN DANGEROUS ENVIRONMENTS.
Do not use power tools in damp or wet locations nor expose them to rain. Always keep the work area well
lighted.
KEEP CHILDREN AWAY.
All visitors and children should be kept a safe distance from work area.
MAKE THE WORKSHOP KID PROOF.
Make the workshops kid proof by using padlocks, master switches or by removing starter keys.
DO NOT FORCE THE TOOL.
A power tool will do a job better and safer operating at the rate for which it was designed.
USE THE RIGHT TOOL.
Do not force a tool or an attachment, to do a job that it was not designed to do.
In order to prevent injury, keep guards in place and in working order at all times.

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 5
SAFETY
USE THE PROPER EXTENSION CORD.
If using an extension cord make sure it is in good condition first. When using an extension cord, be sure to
use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in
line voltage that will result in a loss of power and overheating. TABLE 1, Page 8 shows the correct AWG
size to use depending on cord length and nameplate ampere rating. If in doubt, use the next heavier gage.
The smaller the gage number, the heavier the cord.
WEAR PROPER APPAREL.
Do not wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry that may be caught in moving
parts. Non-slip footwear is recommended. Wear protective hair covering to contain long hair.
ALWAYS USE SAFETY GLASSES.
Safety glasses should always be worn when working around power tools. In addition, a face,
dust mask or respirator should be worn if a cutting operation is dusty. Everyday eyeglasses only
have impact resistant lenses and may not prevent eye injury-they are NOT safety glasses.
SECURE WORK.
Clamps or a vise should be used to hold work whenever practical. Keeping your hands free to operate a
power tool is safer.
DO NOT OVERREACH.
Keep proper footing and balance at all times by not overreaching.
MAINTAIN TOOLS WITH CARE.
Keep tools clean for the best and safest performance. Always follow maintenance instructions for
lubricating, and when changing accessories.
DISCONNECT TOOLS.
Power tools should always be disconnected before servicing or when changing accessories, such as blades,
bits, cutters, and the like.
REDUCE THE RISK OF UNINTENTIONAL STARTING.
Make sure the ON/OFF Switch is in the OFF position before plugging in a power tool.
USE RECOMMENDED ACCESSORIES.
Consult the owner's manual for recommended accessories. Using improper accessories may increase the
risk of personal or by-stander injury.
NEVER STAND ON THE TOOL.
Serious injury could occur if a power tool is tipped, or if a cutting tool is unintentionally contacted.
CHECK FOR DAMAGED PARTS.
Before using a power tool, check for damaged parts. A guard or any other part that is damaged should be
carefully checked to determine it would operate properly and perform its intended function. Always check
moving parts for proper alignment or binding. Check for broken parts and mountings and all other conditions
that may affect the operation of the power tool. A guard, or any damaged part, should be properly repaired
or replaced.
DIRECTION OF FEED.
Always feed work into a blade or cutter against the direction of rotation. A blade or cutter should always be
installed such that rotation is in the direction of the arrow imprinted on the side of the blade or cutter.
NEVER LEAVE A TOOL RUNNING UNATTENDED – TURN POWER OFF.
Do not leave a tool until it comes to a complete stop. Always turn a power tool OFF when leaving the work
area, or, when a cut is finished.
on

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 6
SAFETY
Hazard Symbols:
ELECTRICAL SHOCK!
Never touch electrical wires or components while the motor is running. Exposed, frayed or worn
electrical motor wiring can be sources of electrical shock that could cause severe injury or burns.
ACCIDENTAL STARTS!
Before plugging the equipment into an electrical outlet, be sure the ON/OFF Switch is in the OFF
position to prevent accidental starting. Unplug the power tool before performing any service operation.
ROTATING OR MOVING PARTS!
Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. Never operate a
power tool with covers, shrouds, or guards removed.
Sawing and drilling generates dust. Excessive airborne particles may cause irritation to eyes, skin and
respiratory tract. To avoid breathing impairment, always employ dust controls and protection suitable to the
material being sawed or drilled; See OSHA (29 CFR Part 1910.1200). Diamond Blades improperly used are
dangerous. Comply with American National Standards Institute Safety Code, B7.1 and, Occupational Safety
and Health Act covering Speed, Safety Guards, Flanges, Mounting Procedures, General Operating Rules,
Handling, Storage and General Machine Conditions.
CALIFORNIA PROPOSITION 65 MESSAGE:
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contain
chemicals known [to the State of California] to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead, from lead-based paints
• Crystalline silica, from bricks and cement and other masonry products and
• Arsenic and chromium, from chemically treated lumber
For further information, consult the following sources:
http://www.osha-slc.gov/sltc/silicarystalline/index.html
http://www.oehha.org/prop65/out_of_date/6022kLstA.html
Your risk from these exposures varies depending on how often you do this type of work. To reduce your
exposure to these chemicals, work in a well-ventilated area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter out microscopic particles.
on

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 7
SAFETY
ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS:
In order to prevent potential electrical shock and injury, the following electrical safety precautions and symbols
should be followed at all times!
In case of a malfunction or breakdown, grounding provides a path of least resistance for electric
current to reduce the risk of electric shock. This tool is equipped with an electric cord having an
equipment-grounding conductor and a grounding plug. The plug must be plugged into a matching
outlet that is properly installed and grounded in accordance with all local codes and ordinances.
• Do not modify the plug provided – if it will not fit the outlet; have the proper outlet installed by a
qualified electrician
• Improper connections of the equipment-grounding conductor can result in a risk of electric shock.
The equipment-grounding conductor is the insulated conductor that has an outer surface that is
green, with or without yellow stripes. If repair or replacement of the electric cord or plug is
necessary, do not connect the equipment-grounding conductor to a live terminal
• Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded
• Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that
accept the tool's plug
• Repair or replace a damaged or worn cord immediately
This tool is intended for use on a circuit that has an outlet that looks like the one shown in Sketch A
of Figure 1. The tool has a grounding plug that looks like the plug illustrated in Sketch A of FIGURE
1. A temporary adapter, which looks like the adapter illustrated in sketches B and C, may be used to
connect this plug to a 2-pole receptacle as shown in Sketch B, if a
properly grounded outlet is not available. The temporary adapter
should be used only until a properly grounded outlet can be
installed by a qualified electrician. The green-colored rigid ear,
lug, and the like, extending from the adapter, must be connected
to a permanent ground such as a properly grounded outlet box.
NOTE: Use of a temporary adapter is not permitted in Canada.
To reduce the risk of electrocution, keep all connections dry and off the ground.
A Ground Fault Circuit Interrupter (GFCI) should be provided on the circuit(s) or outlet(s) to be used
for the Saw. Receptacles are available having built-in GFCI protections and may be used for this
measure of safety.
When using an extension cord, the GFCI should be installed closest to the power source, followed
by the extension cord and lastly, the saw.
M
eta
l
Sc
r
e
w
Cover of Grounded
Outlet Box
(
A
)
(
B
)
(
C
)
(
D
)
A
DAPTER
Grounding
Means
Grounding
Pin
Grounding
Pin
FIGURE 1

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 8
SAFETY
To avoid the possibility of the appliance plug or receptacle getting wet, position the saw to one side
of a wall mounted receptacle. This will prevent water from dripping onto the receptacle or plug. A
"drip loop," shown in FIGURE 2, should be arranged by the user to properly position the power cord
relative to the power source.
The "drip loop" is that part of the cord below the level of the receptacle, or
the connector, if an extension cord is used. This method of positioning the
cord prevents the travel of water along the power cord and coming in
contact with the receptacle.
If the plug or receptacle gets wet, DO NOT unplug the cord. Disconnect
the fuse or circuit breaker that supplies power to the tool. Then unplug and
examine for presence of water in the receptacle.
Use only extensions cords that are intended for outdoor use. These extension cords are identified
by a marking "Acceptable for use with outdoor appliances; store indoors while not in use." Use only
extension cords having an electrical rating not less than the rating of the product. Do not use
damaged extension cords. Examine extension cords before using and replace if damaged. Do not
abuse extension cords and do not yank on any cord to disconnect. Keep cords away from heat and
sharp edges. Always disconnect the extension cord from the receptacle before disconnection the
product form the extension cord.
To reduce the risk of electrocution, keep all connections dry and off the ground. Do not touch the
plug with wet hands.
Use of undersize extension cords result in low voltage to the motor that can result in motor burnout
and premature failure. MK Diamond warns that equipment returned to us showing signs of being run
in a low voltage condition, through the use of undersized extension cords will be repaired or replaced
totally at the customers’ expense. There will be no warranty claim.
To choose the proper extension cord,
• Locate the length of extension cord needed in TABLE 1 below.
• Once the proper length is found, move down the column to obtain the correct AWG size required
for that length of extension cord.
Extension Cord Minimum Gage for Length
Volts Total Length of Cord in Feet
120V 25 ft. 50 ft. 100 ft 150 ft.
AWG AWG AWG AWG
18 16 16 14
TABLE 1
Supporting
Surface
Power
Tool
Drip Loop
Power
Cord
FIGURE 2

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 9
SAFETY
SAFETY LABEL LOCATIONS:
Safety labels are located according to Figures 1 and 6 below. The labels contain important safety
information. Please read the information contained on each safety label. These labels are considered a
permanent part of your saw. If a label comes off or becomes hard to read, contact MK Diamond or your
dealer for a replacement.
Item Location Description Part No.
1A. Motor Top Caution Use With a GFCI 155678
1B. Motor Top Warning General Safety Warnings 155806
2. Motor End Caution Water Pump Receptacle 154822
3. Motor Side Motor Specifications N/A
4. Blade Guard Serial Number 157249-02
5. Pump Side Pump Specifications N/A
6. Pump End Warning Pump Warning N/A
TILE SAW SPECIFIC WARNINGS:
Wear eye protection.
Use splash hood for every operation for which it can be used.
Disconnect saw before servicing, when changing cutting blades, and cleaning.
Use tool only with smooth edge cutting blades free of openings and grooves.
Replace damaged cutting blade before operating.
3
4
21
A
B
6
5

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 10
SAFETY
PRODUCT SPECIFICATIONS:
The MK-170 is a versatile Tile Saw. Operated and used according to this manual, the MK-170 will provide
years of dependable service.
General Description:
The MK-170 Tile Saw is engineered as a tabletop or stand mounted wet tile saw. The saw includes a powerful
115v direct drive AC motor. The saw is capable of cutting tile up to twelve (12) inches in length and one and
three quarter (1-3/4) inches thick in one pass.
Motor Specifications:
Motor specifications for the MK-170 are listed in Table 2 below.
Voltage 115 v
Motor Amperage 5.0 a
Frequency 50/60 Hz
RPM 5500 rpm
Horse Power 1/3 hp
Weight 15 lbs.
Table 2
Blade Capacity:
The MK-170 uses a seven (7) inch (178 mm) diameter, wet cutting continuous rim, MK Diamond blade with a
five-eighths (5/8) inch (15.875 mm) arbor.
Tile Types:
The MK-170 can cut a variety of tile types including Porcelain, Terracotta, Marble, Quarry and Slate, or almost
any other non-ferrous material.
NOTE:
The MK-170 is not designed to cut plastic or ferrous (metals) material.

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 11
UNPACKING, TRANSPORT, UNIVERSAL STAND and ASSEMBLY
UNPACKING:
Your MK-170 has been shipped from the factory thoroughly inspected. Only minimal assembly is required.
Use proper lifting techniques when lifting the MK-170.
If not done, remove the MK-170, accessory box from the carton.
CONTENTS:
In your container, you will find one (1) MK-170 cutting surface, one (1) MK-170 water pan, (1) adjustable
cutting guide, (1) 7-inch wet cutting continuous rim diamond blade, one (1) splash guard, one (1) splash guard
washer, one (1) splash guard wing nut, one (1) electric water pump, one (1) pump discharge fitting, one (1)
blade wrench one (1) shaft wrench, one (1) owners manual, one (1) pump manual and one (1) warranty card.
MK-170 Cutting
Surface MK-170 Water Pan Adjustable Cutting Guide Diamond Blade Splash Guard
Splash Guard
Washer Splash Guard Wing nut Electric Water Pump Pump Discharge Fitting Blade Nut Wrench
Shaft
Wrench Owners Manual Pump Manual Warranty Card
TRANSPORT:
1. The MK-170 weighs approximately fifteen (15) pounds for ease of transport.
2. Never transport the MK-170 with water in the Water Pan.
To lift the saw, grasp the Water Pan on either side and lift.
Lift Point Lift Point

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 12
UNPACKING, TRANSPORT, UNIVERSAL STAND and ASSEMBLY
ASSEMBLY:
Follow the assembly instructions to prepare your MK-170 for operation.
1. Diamond Blade Installation:
NOTE: When installing the Retaining Screw, do not “cross-thread" and DO NOT over tighten the screw.
(A)
Loosen the Blade Guard Pivot
Point Retaining Wingnut
(C)
Open the Blade Guard and place
the Shaft Wrench on the Motor
Shaft and the Blade Wrench on
the Blade Retaining Nut
(D)
Remove the Blade Retaining
Nut and the Outer Flange
(F)
Verify the Directional Arrow of
the Blade faces outward and
matches the Directional Arrow
of the Blade Guard
(G)
Install the Retaining Nut and
Outer Flange, place the Shaft
Wrench and Blade Wrench as
shown in Step C and Tighten
the Retaining Nut
(B)
Loosen the Blade Guard
Retaining Thumbscrew
(E)
Install Diamond Blade onto
Blade Shaft
(I)
Tighten the Blade Guard Pivot
Point Retaining Wingnut
(H)
Close the Blade Guard and
tighten the Blade Guard
Retaining Thumbscrew
Retaining
Wingnut
Turn counter-
clockwise to
loosen
Retaining
Thumbscrew
Turn counter-
clockwise to
loosen Retaining
Nut
Blade
Wrench
Motor
Shaft
Shaft
Wrench
Turn counter-
clockwise to
loosen Hold
steady
Retaining Nut
and Outer
Flange
Diamond
Blade
Blade
Shaft
Correct Direction
of Rotation
Turn clockwise
to tighten
Retaining Nut
and Outer
Flange
Rotate clockwise
to tighten
Retaining
Thumbscrew
Rotate clockwise
to tighten
Retaining
Wingnut

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 13
UNPACKING, TRANSPORT, UNIVERSAL STAND and ASSEMBLY
2. Adjustable Cutting Guide Installation:
NOTE: When installing the Adjustable Cutting Guide, verify the guide is parallel to the Diamond Blade. If
alignment of the Adjustable Cutting Guide is required, see Step 2 in the Adjustment and Operation
Section of this manual.
3. Splash Guard Installation:
(A)
Install the Thumbscrew through
the Washer and Splashguard
then align to the hole found on
back of the Blade Guard and
tighten
Thumbscrew
and Washe
r
Turn clockwise
to tighten
(A)
Loosen the Adjustable Cutting
Guide retaining thumbscrews
(B)
Place the Adjustable Cutting
Guide onto the Cutting Table
with the Front Guide into the
front Guide Slot and the Rear
Guide in the rear Guide Slot
(E)
Tighten the Adjustable Cutting
Guide retaining thumbscrews
(C)
Verify the Front Guide is
properly seated in the front
Guide Slot
(D)
Verify the Rear Guide is
properly seated under the rear
Guide Slot
Turn counter-
clockwise to loosen Adjustable
Cutting Guide
Thumbscrew
Rear Guide
Slot
Adjustable
Cutting Guide
Front Guide
Slot Front
Guide Front Guide
Slot
Rear
Guide Rear Guide
Slot
Turn clockwise
to tighten
Adjustable
Cutting Guide
Thumbscrew
Splash
Guard
Retaining
Hole

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 14
SETUP, ADJUSTMENT and OPERATION
SETUP:
1. Pre-start Inspection:
Prior to beginning work, a pre-start inspection of the saw should be preformed.
2. Water Pump Preparation:
1. To prevent the possibility electrical shock, the MK-170 MUST be de-energized when preparing
the Water Pump for operation.
2. To prevent the possibility of electrical shock, use only MK Diamond qualified replacement parts
(A)
Ensure the ON/OFF Switch is
in the OFF position
(B)
Inspect the Pump Assembly for
damage – ensure the cord is
free of cracks or cuts
(C)
Inspect the Diamond Blade for
damage – verify the blade is
correct for the material being cut
(D)
Inspect the MK-170 for
damage – ensure the cord is
free of cracks or cuts
Inspect for
damage
Off
Position
ON/OFF
Switch
Inspect for
damage
Inspect for
cracks or cuts
Inspect for cracks,
de-bonding, etc.
(A)
Install Water Pump Discharge
Fitting
(B)
Remove the Cutting Table from
the Water Pan (Note the
Cooling Transfer Tube)
(C)
Press the end of the Cooling
Transfer Tube onto the Water
Pump Discharge Fitting
Discharge
Fitting
Pump
Cooling
Transfer Tube
Press on
Discharge
Fitting
Cutting
Table Water
Pan
Cooling
Transfer Tube

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 15
SETUP, ADJUSTMENT and OPERATION
3. MK-170 Setup for Operation:
1. Before connecting the MK-170 to a power supply, be sure the voltage, cycle and phase meet the
requirements of TABLE 3 below.
VOLTAGE – 115V CYCLE – 60 Hz PHASE – 1 Phase
TABLE 3
2. If using an extension cord, make sure the length and wire gauge correspond to the requirements
listed in TABLE 1 on page 8. An extension cord that is too small in wire gauge (diameter), or too
long in length, will cause the motor to overheat and could cause premature failure.
3. Use an approved Ground Fault Circuit Interrupter (GFCI)
4. Do not cover the motor vents as this could lead to motor overheating.
NOTE: In order to avoid breaker tripping, a 20-amp circuit breaker should be used.
(A)
Plug MK-170 into the GFCI (A
GFCI should always be used
when operating the MK-170)
(B)
Plug the GFCI into the Power
source
GFCI
GFCI Plugged
Into Power
Source
(D)
Fill the Water Pan with clean
water (this should be done
periodically during cutting)
(F)
Install the Cutting Table; ensure
the pump power cord is seated
in the slot behind the Post
(E)
Place the Water Pump in the
Water Pan–ensure the pump
suction is covered
(F)
Connect the Water Pump power
cord to the connection found on
the back of the motor
Fill with
clean wate
r
Fill Water
Pan Cover Pump
Suction
Water
Pump Cutting
Table Post
Cord Slot
Pump
Cord
Press
together
Pump
Connection

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 16
SETUP, ADJUSTMENT and OPERATION
ADJUSTMENT and OPERATION:
1. Cutting Tile:
DO NOT FORCE THE TOOL. It will do the job better and safer at the rate for which it was
designed.
2. Adjustable Cutting Guide Alignment:
If during the cutting operation it is found that the Adjustable Cutting Guide is not aligned to the Blade, perform
the following operation.
(A)
Position the Adjustable Cutting
Guide to desired cut length as
measured from the Blade
(B)
Place the tile against the
Adjustable Cutting Guide
(C)
Place the ON/OFF Switch in
the ON position
(D)
Verify cooling flow on both
sides of the blade (adjust
flow if necessary - See
Maintenance Section)
(E)
Push the Tile into the Blade in
a smooth even motion to
perform a cut
(F)
Turn the motor OFF when work
is complete
Tile
Placement
Position
Adjustable
Cutting Guide
Adjustable
Cutting Guide Diamond
Blade
Set Cutting
Length
On
Position
ON/OFF
Switch
Direction
of Cut
Hold Work
in Position
Off
Position
ON/OFF
Switch
Cooling Flow
Points
(A)
Loosen the Adjustable Cutting
Guide Alignment Screws
(B)
Gently align the Adjustable
Cutting Guide to the Blade
(C)
Tighten the Adjustable Cutting
Guide Alignment Screws
Alignment
Screw
Phillips
Screwdrive
r
Alignment
Screw
Phillips
Screwdrive
r
Alignment
Points
Diamond
Blade
Adjustable
Cutting Guide

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 17
SETUP, ADJUSTMENT and OPERATION
3. Cleanup:
NOTE: Dispose of wastewater in accordance with applicable Federal, State and Local laws.
Ensure the saw is disconnected before completing the remainder of the cleanup process.
(A)
Ensure the ON/OFF Switch is
in the OFF position
Off
Position
ON/OFF
Switch
(B)
Remove the Cutting Table from
the Water Pan
(C)
Dispose the contents of the
Water Pan
(D)
Remove the pump Suction
Screen and clean the Water
Pump of all debris
(E)
Fill the Water Pan with clean
water
Fill with
clean wate
r
Fill Water
Pan Cooling Flow
Points
(F)
Run the MK-170 until clear water
is seen at the blade cooling ports
(Approx. 1 minute)
Off
Position
ON/OFF
Switch
(G)
Turn the motor OFF when work
is complete
(H)
Unplug the GFCI from the
Power source
Unplug
(I)
Remove the Cutting Table from
the Water Pan
Empty
Water Pan
Remove
Cutting Table
Removal
Direction
Suction
Screen
Remove
Cutting Table

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 18
SETUP, ADJUSTMENT and OPERATION
NOTE: To extend the life of the MK-170, lubricate the Motor Shaft with light oils such as, 3 in 1, WD-40, etc.
3. Lockout:
The MK-170 is provided with a Lockout device designed to prevent the operation of the saw when the owner is
not around. This Lockout device is a Removable Toggle found on the "Rocker" of the ON/Off Switch. The
Removable Toggle has the words "Remove To Lock" imprinted on the top.
(M)
Clean the Cutting Table, Motor
and Adjustable Cutting Guide
(O)
Clean the Inner and Outer
Flanges and the Blade
Retaining Nut
(L)
Clean the Water Pan
(K)
Clean the MK-170 with soap
and clean water
(N)
Monthly, remove the Blade
then clean and lubricate the
Motor Shaft
(J)
Dispose the contents of the
Water Pan
Empty
Water Pan Clean the Water Pan
Clean with Soap
and Wate
r
Clean Remainder
of MK-170
Motor
Shaft
Retaining
Nut
Flange
(A)
To Lockout the MK-170,
remove the Toggle found on
the "Rocker" of the ON/OFF
Switch
Toggle
Removed
Removable
Toggle

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 19
MAINTENANCE AND TROUBLESHOOTING
MAINTENANCE:
1. Blade Dressing:
Like most cutting instruments, a diamond blade performs best when it is dressed. Over time and use,
diamonds on the outer edge of the blade will become smoothed or “glazed” over. This will reduce grinding
efficiency and may cause the blade to “wander” or bend giving the illusion of an alignment problem. When
this occurs, the blade will need to be dressed. The diamond blade can be dressed using the MK Dressing
Stick (part number 152972) and by following the steps below.
(C)
Position the Dressing Stick
(E)
Push the Dressing Stick into
the Blade in a smooth even
motion to perform a cut, repeat
7 or 8 times to dress the Blade
(B)
Set the Adjustable Cutting
Guide to cut a 1/16-strip
Setup for
O
p
eration
(A)
Setup the MK-170 for
operation (See Setup,
Adjustment and Operation)
Adjustable
Cutting Guide Diamond
Blade
Set Cutting
Length Dressing Stick
Placement
Position
Adjustable
Cutting Guide
(C)
Place the ON/OFF Switch in
the ON position
On
Position
ON/OFF
Switch
(D)
Verify cooling flow on both
sides of the blade (adjust
flow if necessary - See
Maintenance Section)
Cooling Flow
Points Direction
of Cut
Hold Work
in Position
(F)
Turn the motor OFF when work
is complete
Off
Position
ON/OFF
Switch

MK-170 Revision 02/02, Effective Date February 11, 2002 Page 20
MAINTENANCE AND TROUBLESHOOTING
7. Motor Brush Change-out:
Disconnect the tool before servicing and when changing accessories, such as blades, bits,
cutters, and the like.
NOTE: When installing motor brushes, care must be taken to ensure the spring end is straight before
installing the Motor Brush Cap.
(A)
Disconnect the MK-170 (B)
Locate and Remove One
Motor Brush Cap using a Flat
Head Screwdriver
(C)
Remove Motor Brush
Housing Cover
(E)
Clean the Motor Brush Housing
using a Q-tip
(D)
Align and Install New Motor
Brush
(F)
A
lign and install the new Motor
Brush
Housing
Cove
r
Clean Brush Housing
of Carbon All Carbon
Dust and Fragments
Align Motor Brush
with Brush Housing
and install the Brush
Replace Second
Motor Brush
(G)
Install Motor Brush Cap and
tighten using a Flat Head
Screwdriver
(H)
Install the Second Motor Brush
(Repeat Steps B to E)
Install the Motor
Brush Cap
Turn counter-
clockwise to loosen
Flat Head
Screwdrive
r
Remove the
Motor Brush
Disconnect
the MK-170
