MK -20 Series User manual

05.2013
MK-20 SERIES
OWNER’S MANUAL,
OPERATING INSTRUCTIONS
& PARTS LIST
www.mkdiamond.com
Caution: Read all safety and operating instructions
before using this equipment. This owner’s manual
MUST accompany the equipment at all times.
Revision 304
Manual Part# 156777
Gas Powered
Concrete Saw

32
MK-20 SERIES EXPLODED VIEW
FIGURE 1 - PARTS LIST: MK-2020HSP CONCRETE SAW - P/N 156498

33
MK-20 SERIES PARTS LIST
FIGURE 1 - PARTS LIST: MK-2020HSP CONCRETE SAW - P/N 156498
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1NUT, HEX, 5/16 - 18 101196 2
2BELT, BX34 150764 2
3SCREW, 3/8 - 16 X 1 -1/4 HEX HEAD CAP 150774 2
4WASHER, FLAT, SAE 3/8 150923 17
5WASHER, 1/2 SAE FLAT 150924 8
6WASHER, LOCK, SPLIT, 3/8 150925 11
7CLAMP, HOSE, 5.8 151198 4
8NUT, 1/2 - 13 HEX 151282 4
9SCREW, HEX HD, CAP, 5/16 - 18 X 3/4 151369 2
10 WASHER, 1/4 SAE FLAT 151915 12
11 NUT, 3/8 - 16 NYLOK HEX 152505 4
12 SCREW, HEX HD CAP, 3.8 -16 X 1 152507 10
13 WASHER, 1/2 SPLIT LOCK 153524 4
14 SCREW, HEX, 3/8 - 16 X 3.4 153527 1
15 SCREW, 1/2 - 13 X 1 -1/4 HEX HEAD CAP 153532 4
16 SCREW, 1/4 - 20 X 1/2 TRUSS HEAD 153880 10
17 NUT, HEX, TW, 1/4 - 20 153941 2
18 HOSE, 1/4 FUEL, 12” 154163 1
19 HOSE, 1/4 FUEL, 24” 154163 1
20 ELBOW, 1/4 MNPT STREET 154615 1
21 ELBOW, 1/8 MNPT X 1/4 BARB 90DEG 154652 1
22 BELT, AX-42 156110 1
23 GUARD, SHAFT (COMP) 156307 1
24 LIFTING BAIL 156543 1
25 BLADE, MK-799D 16 X 125 X 1 157769 1
26 NUT, HEX, NYLK, 5/16 - 18 158289 1
27 ASSY, BLD GRD 20” 158818 1
28 BELTGUARD (COMP) 159888 1
29 FITTING, PUSH ON HOSE 1/4 X 1/4 MALE 165183 1
30 ASSY, POINTER, CONC SAW 166465 1
31 CAP, 2” FUEL FILLER 167220 1
32 TANK, FUEL, 2.5 GAL 169353 1
33 ASSY, FRAME, LESS ENGINE 169719 1
34 VALVE, BALL, 1/4”M TO 1/4”F 231248 1

34
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 1 - PARTS LIST: MK-2020HSP CONCRETE SAW - P/N 156498
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1WRENCH, BOX END, 1-1/2 X 9/16 137976 1
2GRIP, HANDLE, 1/0 ID 150842 2
3WASHER, FLAT, SAE, 3/8 150923 3
4WASHER, LOCK, SPLIT, 3.8 150925 1
5SCREW, HEX HD CAP, 3/8 - 16 X 1 152507 8
6PULLEY, 1A30 X 1/2 BORE IDLER 153797 1
7SPRING, 9.16 X 2.5 EXTENSION 153807 1
8BRACKET, IDLER PULLEY 154244 1
9WELDMENT, HANDLEBAR 156516 1
10 SCREW, HEX HEAD 3.8 - 16 X 1 - 1/2 LG. 156656 2
11 COVER, 8 - 4 AWG TERMINAL, RED 169355 1
12 ASSY, ENGINE, HONDA GX630 169713 1
13 ASSY, FRAME, LESS ENGINE 169719 1

35
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 1 - PARTS LIST: MK-2020HSP CONCRETE SAW - P/N 156498
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1NUT, HEX, 1/4 -20 151893 4
2WASHER, 1/4 SAE FLAT 151915 12
3NUT, 3/8 -16 NYLOK HEX 152505 4
4SCREW, HEX HD CAP, 1/4 - 20 X 1 152676 2
5CABLE, 4GA X 48 RED BATTERY 153848 1
6CABLE, 4GA X 24 BLACK BATTERY 153849 1
7TACHOMETER/HOURMETER 153877 1
8SCREW, 1/4 -20 X 1/2 TRUSS HEAD 153880 10
9ASSY, THROTTLE CONTROL 155406 1
10 NUT, 10 -24 CLIP 155407 2
11 PANEL, TOWER LOWER BACK 156505 1
12 PLUG, HOLE PLASTIC 3/4” 156615 2
13 NUT, 3/8 - 24 HEX JAM 156623 1
14 SCREW, PAN HD SELF TAP 8 - 32 X 1/2 156632 2
15 BOX, BATTERY 156634 1

36
FIGURE 1 - PARTS LIST: MK-2020HSP CONCRETE SAW - P/N 156498
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
16 SCREW, BTN HD 3/8 16 X 3/4 SOCK 156635 2
17 SCREW, PAN HD PHIL MS 10 24 X 3/4 156641 2
18 TAG, SERIAL #, BLANK 157500-RW 1
19 DRIVE SCREW, #7 X 5/16 ROUND HEAD 157849 2
20 STRAP, NYLON, 1” 158094 1
21 CABEL, CHOKE, HONDA (COMP) 158816 1
22 BATTERY, 12V, 35AH 162589 1
23 COVER, 1” BATTERY TERMINAL, RED 163940 1
24 TAPE, VHB, 5952 (3.0”) 166487 1
25 BRACKET, SWITCH 169714 1
26 WIRING HARNESS, GX630/690 169715 1
27 ASSY, FRAME, LESS ENGINE 169719 1
28 TAG, EVAP, 20S, PARENT 169736-205 1
MK-20 SERIES EXPLODED VIEW & PARTS LIST

37
MK-20 SERIES EXPLODED VIEW
FIGURE 2 - PARTS LIST: MK-2024HSP CONCRETE SAW - P/N 158777

38
MK-20 SERIES PARTS LIST
FIGURE 2 - PARTS LIST: MK-2024HSP CONCRETE SAW - P/N 158777
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1NUT, HEX, 5/16 - 18 101196 2
2BELT, BX34 150764 2
3SCREW, 3/8 - 16 X 1 -1/4 HEX HEAD CAP 150774 2
4WASHER, FLAT, SAE 3/8 150923 17
5WASHER, 1/2 SAE FLAT 150924 8
6WASHER, LOCK, SPLIT, 3/8 150925 11
7CLAMP, HOSE, 5.8 151198 4
8NUT, 1/2 - 13 HEX 151282 4
9SCREW, HEX HD, CAP, 5/16 - 18 X 3.4 151369 2
10 WASHER, 1/4 SAE FLAT 151915 12
11 NUT, 3/8 - 16 NYLOK HEX 152505 4
12 SCREW, HEX HD CAP, 3.8 -16 X 1 152507 10
13 WASHER, 1/2 SPLIT LOCK 153524 4
14 SCREW, HEX, 3/8 - 16 X 3.4 153527 1
15 SCREW, 1/2 - 13 X 1 -1/4 HEX HEAD CAP 153532 4
16 SCREW, 1/4 - 20 X 1/2 TRUSS HEAD 153880 10
17 NUT, HEX, TW, 1/4 - 20 153941 2
18 HOSE, 1/4 FUEL, 12” 154163 1
19 HOSE, 1/4 FUEL, 24” 154163 1
20 ELBOW, 1/4 MNPT STREET 154615 1
21 ELBOW, 1/8 MNPT X 1/4 BARB 90DEG 154652 1
22 BELT, AX-42 156110 1
23 GUARD, SHAFT (COMP) 156307 1
24 LIFTING BAIL 156543 1
25 BLADE, MK-799D 16 X 125 X 1 157769 1
26 NUT, HEX, NYLK, 5/16 - 18 158289 1
27 ASSY, BLD GRD 20” 158818 1
28 BELTGUARD (COMP) 159888 1
29 FITTING, PUSH ON HOSE 1/4 X 1/4 MALE 165183 1
30 ASSY, POINTER, CONC SAW 166465 1
31 CAP, 2” FUEL FILLER 167220 1
32 TANK, FUEL, 2.5 GAL 169353 1
33 ASSY, FRAME, LESS ENGINE 169719 1
34 ASSY, ENGINE, GX690 170048 1
35 VALVE, BALL, 1/4”M TO 1/4”F 231248 1

39
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 2 - PARTS LIST: MK-2024HSP CONCRETE SAW - P/N 158777
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1WRENCH, BOX END, 1-1/2 X 9/16 137976 1
2GRIP, HANDLE, 1/0 ID 150842 2
3WASHER, FLAT, SAE, 3/8 150923 3
4WASHER, LOCK, SPLIT, 3.8 150925 1
5SCREW, HEX HD CAP, 3.8 - 16 X 1 152507 1
6PULLEY, 1A30 X 1/2 BORE IDLER 153797 1
7SPRING, 9.16 X 2.5 EXTENSION 153807 1
8BRACKET, IDLER PULLEY 154244 1
9WELDENT, HANDLEBAR 156516 1
10 SCREW, HEX HEAD 3.8 - 16 X 1 - 1/2 LG. 156656 2
11 COVER, 8 - 4 AWG TERMINAL, RED 169355 1
12 ASSY, FRAME, LESS ENGINE 169719 1
13 ASSY, ENGINE, GX690 170048 1

40
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 2 - PARTS LIST: MK-2024HSP CONCRETE SAW - P/N 158777
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1NUT, HEX, 1/4 -20 151893 4
2WASHER, 1/4 SAE FLAT 151915 12
3NUT, 3/8 -16 NYLOK HEX 152505 4
4SCREW, HEX HD CAP, 1/4 - 20 X 1 152676 2
5CABLE, 4GA X 48 RED BATTERY 153848 1
6CABLE, 4GA X 24 BLACK BATTERY 153849 1
7TACHOMETER/HOURMETER 153877 1
8SCREW, 1/4 -20 X 1/2 TRUSS HEAD 153880 10
9ASSY, TROTTLE CONTROL 155406 1
10 NUT, 10 -24 CLIP 155407 2
11 PANEL, TOWER LOWER BACK 156505 1
12 PLUG, HOLE PLASTIC 3/4” 156615 2
13 NUT, 3/8 - 24 HEX JAM 156623 1
14 SCREW, PAN HD SELF TAP 8 - 32 X 1/2 156632 2
15 BOX, BATTERY 156634 1

41
FIGURE 2 - PARTS LIST: MK-2024HSP CONCRETE SAW - P/N 158777
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
16 SCREW, BTN HD 3/8 16 X 3/4 SOCK 156635 2
17 SCREW, PAN HD PHIL MS 10 24 X 3/4 156641 2
18 TAG, SERIAL #, BLANK 157500-RW 1
19 DRIVE SCREW, #7 X 5/16 ROUND HEAD 157849 2
20 STRAP, NYLON, 1” 158094 1
21 CABEL, CHOKE, HONDA (COMP) 158816 1
22 BATTERY, 12V, 35AH 162589 1
23 COVER, 1” BATTERY TERMINAL, RED 163940 1
24 TAPE, VHB, 5952 (3.0”) 166487 1
25 BRACKET, SWITCH 169714 1
26 WIRING HARNESS, GX630/690 169715 1
27 ASSY, FRAME, LESS ENGINE 169719 1
28 TAG, EVAP, 20S, PARENT 169736-20S 1
MK-20 SERIES EXPLODED VIEW & PARTS LIST

42
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 3 - PARTS LIST: FRAME, LESS ENGINE - P/N 169719
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1WHEEL, REAR CONCRETE SAW 138529 2
2WASHER, 1/2 SAE FLAT 150924 4
3WASHER, 7/16 SPLIT LOCK 151051 5
4SCREW, 5/16 - 18 X 1/2 SOCKET HEAD SET 152607 2
5WASHER, FLAT, SAE, 3/4 153523 4
6COLLAR, SET, 3/4” 153814 2
7AXLE, REAR, Ø 3/4 153873 2
8SCREW, 7/16 - 14 X 1 - 1/2 HEX HEAD CAP 155155 4
9ASSY, THROTTLE CONTROL 155406 1
10 ASSY, PIN CLEVIS 3/8 X 1 - /14 156611 1
11 BLADE SHAFT 20HP 156654 1
12 FRAME, WELDMENT 157092 1
13 ASSY, TRUCK 169710 1

43
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 3 - PARTS LIST: FRAME, LESS ENGINE - P/N 169719
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1WASHER, FLAT, SAE, 3/8 150923 13
2WASHER, 1/2 SAE FLAT 150924 2
3WASHER, LOCK, SPLIT, 3/8 150925 4
4SCREW, PAN HD SELF TP10-24 X 3/8 151262 2
5NUT, HEX, 1/4 - 20 151893 6
6SCREW, HEX HEAD 1/4 - 20 X 1 - 1/2” 151914 1
7NUT, 3/8 - 16 NYLOK HEX 152505 6
8SCREW, HEX HD, 3/8 - 16 X 2 153485 2
9SCREW, HEX, 3/8 - 16 X 3/4 153527 4
10 SCREW, 1/2 - 13 X 1 - 1/4 HEX HEAD CAP 153532 2
11 SCREW, 1/4 - 20 X 1/2 TRUSS HEAD 153880 10
12 EYEBLT, 1/4 - 20 X 2 153887 1
13 ASSY, WATER VALVE 153888 1
14 SPRING, EXTENSION 153957 1
15 LINKAGE, DPTH FEED 1600/9000 155049 1
16 PANEL, RIGHT, 20 SERIES 156500 1
17 PANEL, LEFT, 20 SERIES 156501 1

44
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
18 PANEL, UPPER BACK TOWER 156504 1
19 ASSY, PIN CLEVIS 3/8 X 1 - 1/4 156611 1
20 PLUG, 1/2 FLUSH HEAD BUTTON 156779 1
21 FRAME, WELDMENT 157092 1
22 ASSY, TRANSMISSION 169711 1
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 3 - PARTS LIST: FRAME, LESS ENGINE - P/N 169719

45
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1WASHER, FLAT, SAE, 3/8 150923 9
2SCREW, HEX HD, 5/16 - 18 X 1 151743 1
3WASHER, FLAT, SAE, 5/16 151754 1
4NUT, HEX, 1/4 - 20 151893 1
5WASHER, 1/4 SAE FLAT 151915 2
6NUT, 3/8 -16 NYLOK HEX 152505 5
7SCREW, HEX HD CAP, 3.8 - 16 X 2 153485 2
8SCREW, RND HD, #8 - 32 X 1/2 152517 1
9WASHER, 1/4 SPLIT LOCK 152951 2
10 SCREW, HEX HD, 3/8 - 16 X 1 152507 2
11 SCREW, 3/8 -16 X 1-1/2 HEX HEAD 153528 1
12 NUT, HEX, 8 -32 153549 1
13 SCREW, SOC HD, CAP, 3.8 - 16 X2 153643 1
14 SCREW, FLAT HD, SOC, 1/4 -20 X 1” 153894 1
15 ARM, DRIVE ADJUSTMENT 154242 2
16 KNOB, 1/2 - 20 SSFEM BALL 154486 1
17 LINKAGE, DEPTH FEED 1600/9000 1550449 1
18 STUD, 3/4 - 10 X 10” 155062 1
19 NUT, 3/4 - 10 HEX 155063 2
20 ASSY, THROTTLE CONTROL 155406 1
21 NUT, 10 -24 CLIP 155407 2
22 SCREW, PAN HD, CAP, 14 - 20 X 1/2 155452 2
23 WASHER, FLAT, SAE, #8 155454 2
24 ASSY, CRANK WHEEL, 3/4 - 10 155457 1
25 SCREW, SOCKET HEAD CAP 3.8 - 16 X 1 156602 1
26 CLAMP, DEPTH INDICATOR 156603 1
27 ARM, DEPTH INDICATOR 156604 1
28 SPRING, DEPTH GAUGE 156605 1
29 SPOOL, 2.75 DIA DEPTH INDICATOR 156606 1
30 SCREW, HEX HD, CAP, 1/4 - 20 X 2 - 1/4 156607 1
31 BRACKET, DEPTH INDICATOR 156608 1
32 SPRING, DETENT 156609 1
33 HANDLE, ENGAGE 156610 1
34 ASSY, PIN CLEVIS 3.8 X 1 - 1/4 156611 1
35 SCREW, PAN HD PHIL MS 10 - 24 X 3/4 156641 2
36 LABEL, CONTROL PANEL 165136 1
37 BEARING, FLANGE, 3/4 ID, FD204 165971 1
38 CASING, CONTROL PANEL - COMP 169712 1
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 3 - PARTS LIST: FRAME, LESS ENGINE - P/N 169719

46
MK-20 SERIES EXPLODED VIEW & PARTS LIST
FIGURE 4 - PARTS LIST: BLADE SHAFT - P/N 156654
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1NUT, 1 - 14 RIGHT HAND 138693 1
2NUT, 1 - 14 LEFT HAND 138701 1
3FLANGE, INNER 150731 2
4KEY, 3/16 X 3/4 WOODRUFF 150794 2
5KEY, SQUARE, 1/4 X 1 - 3/4 150796 1
6PULLEY, 2A34B38 X 1610 TB 150010 1
7BUSHING, TPR-LOCK 1610X1 - 3/16” 155011 1
8ASSY, OUTER FLANGE, 4” 155451 1
9BEARING, 1 - 3/16 ID PILLOW BLOCK 155622 2
10 SHAFT, 1 3/16 BLADE 156599 1

47
MK-20 SERIES EXPLODED VIEW & PARTS LIST
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1KEY, SQUARE, 1/4 X 1 - 3/4 150796 1
2WASHER, FLAT, SAE, 3/8 150923 8
3WASHER, 1/2 SAE FLAT 150924 3
4WASHER, LOCK, SPLIT, 5/16 151747 4
5WASHER, FLAT, SAE, 5/16 151754 4
6NUT, 3/8 - 16 NYLOK HEX 152505 4
7SCREW, HEX HD, 3/8 - 16 X 2 153485 4
8WASHER, 1/2 SPLIT LOCK 153524 2
9SCREW, 1/2 - 13 X 1 - 1/4 HEX HEAD CAP 153532 4
10 BOLT, HEX, TAP, 1/2 - 13 X 4 153854 1
11 MOUNT, ENGINE 154237 1
12 BUSHING, TPR - LOCK 1210 X 1 - 1/8” 154430 1
13 ELBOW, 1/8 MNPT X 1/4 BARB 90DEG 154652 1
14 PULLEY, 3A30B34 X 1210TB REV 155009 1
15 ASSY, OIL DRAIN, 14MM 157577-03 1
16 GUARD, INNER BELT 165608 1
17 SCREW, 5/16 - 24 X 3/4 HEX HEAD MACHINE 165617 4
18 ENGINE, HONDA GX630 169592 1
19 ASSY, 7” AIR CLEANER 165593 1
20 MUFFLER, HONDA 20HP 621600 169594 1
21 WASHER, 1/2 SAE FLAT 169958 1
FIGURE 5 - PARTS LIST: ENGINE, HONDA GX630 - P/N 169713

48
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1KEY, SQUARE, 1/4 X 1 - 3/4 150796 1
2WASHER, FLAT, SAE, 3/8 150923 8
3WASHER, 1/2 SAE FLAT 150924 3
4WASHER, LOCK, SPLIT, 5/16 151747 4
5WASHER, FLAT, SAE, 5/16 151754 4
6NUT, 3/8 - 16 NYLOK HEX 152505 4
7SCREW, HEX HD, 3/8 - 16 X 2 153485 4
8WASHER, 1/2 SPLIT LOCK 153524 2
9SCREW, 1/2 - 13 X 1 - 1/4 HEX HEAD CAP 153532 4
10 BOLT, HEX, TAP, 1/2 - 13 X 4 153854 1
11 MOUNT, ENGINE 154237 1
12 BUSHING, TPR - LOCK 1210 X 1 - 1/8” 154430 1
13 ELBOW, 1/8 MNPT X 1/4 BARB 90DEG 154652 1
14 PULLEY, 3A30B34 X 1210TB REV 155009 1
15 ASSY, OIL DRAIN, 14MM 157577-03 1
16 GUARD, INNER BELT 165608 1
17 SCREW, 5/16 - 24 X 3/4 HEX HEAD MACHINE 165617 4
18 ASSY, 7” AIR CLEANER 169593 1
19 MUFFLER, HONDA 20HP 621600 169594 1
20 ENGINE, HONDA GX690 169716 1
21 WASHER, 1/2 SAE FLAT 169958 1
FIGURE 6 - PARTS LIST: ENGINE, HONDA GX690 - P/N 170048
MK-20 SERIES EXPLODED VIEW & PARTS LIST

49
ITEM
NO. DESCRIPTION PART OR IDENTIFYING NO.
QTY.
REQ.
1SCREW, THUMB 1/4 - 20 X 3/4 150991 1
2WHEEL, POINTER, 3” 155066 1
3BUSHING, 3/8ID X 1 - 5/8L 155153 1
4POINTER ARM, CONC SAW 156544 1
5ASSY, POINTER WHEEL 165238 1
FIGURE 7 - PARTS LIST: ASSY, POINTER - P/N 166465
MK-20 SERIES EXPLODED VIEW & PARTS LIST

50
MK-20 Series ORDERING & RETURN
ORDERING INFORMATION
You may order MK Diamond products through your local MK Diamond distributor or, you may order
direct from MK Diamond.
When ordering direct from MK Diamond, please have the following information ready before calling:
• The Model Number of the saw
• The Serial Number of the saw
• Where the saw was purchased and when
• The Part Number for the part(s) being ordered
• The Part Description for the part(s) being ordered
NOTE: There is a $25.00 minimum order when ordering direct from MK Diamond. A $6.00 charge will
be added to orders having a net billing value under $50.00. All purchases must be made using VISA,
MasterCard or American Express.
All parts may be ordered by calling toll free to – 800 421-5830 or 310 539-5221 and asking for
Customer Service. For technical questions, call – 800 474-5594.
RETURN MATERIALS POLICY
To expedite the service relative to the return of a product purchased through MK Diamond, please
observe the following:
NOTE: When returning all items, they must have been purchased within the previous twelve (12)
months.
• Have the Model Number of the saw
• Have the Serial Number of the saw
• Have the location of where the saw was purchased
• Have the date when the saw was purchased
• Contact Customer Service for approval to return the item(s)
• Obtain a Returned Goods Number (RGA) authorizing the return
• Follow the packaging instructions in the following section
• Ensure your item(s) are prepaid to the destination
For returned items, call toll free to – 800 421-5830 or 310 539-5221 and ask for Customer Service.
For technical questions, call – 800 474-5594 or 310 257-2845.
PACKAGING INSTRUCTIONS
• Remove the Cutting Head and Support Angle Assembly
• Dry the saw before shipping
• When packing, include the following: Saw, Diamond Blade, and Blade Guard
Assembly and Adjustable Cutting Guide (Other Accessories are not required)
• Package the unit in its original container or one of comparable size (do not ship the unit partially
exposed)
• Ensure all parts are secured in the packaging to prevent moving
AUTHORIZED SERVICE CENTERS
For quicker repair time, you may contact MK Diamond Customer Service, toll free, at 800 421-5830
or 310 539-5221 for the Authorized Service Center closest too you or visit our web site at
www.mkdiamond.com. For technical questions, call – 800 474-5594.
