MK MK-112 System manual

TILE SAW
OWNER’S MANUAL &
OPERATING INSTRUCTIONS
MK-112 TILE SAW
READ SAFETY
AND GENERAL
INSTRUCTIONS
CAREFULLY
BEFORE USING
SAW FOR THE
FIRST TIME
serial number
You should record the serial number
of your saw on this owner’s manual
and on the warranty card, which must
be sent in, to be effective. be sure
to include all pertinent information
required.
Part No. 160467
Revision 02/04
CAUTION
!
O
W
N
E
R
S
M
A
N
U
A
L

22 MK-112
Revision 02/04, Effective Date February 19, 2004
23
MK-112 Revision 02/04, Effective Date February 19, 2004
EXPLODED VIEW AND PARTS LIST MK-112
EXPLODED VIEW
A1
A3
A2
A4
B1
B2
B3
B4
B5
B6
B7
B8
B9 C1
C2
C3
C6
C5
C4
D1
D2
D6
D3
D5
D7
D9
D8
D4
E1
E2
E6
E5
E4
E3
E7
E8
E9 F1
F6
F5
F4
F3
F2
G1
G2
G3
G4
G5
G6
G7
G8
G9
G10
H1
H2
H3
H4
J1
J2
J3
J4
J5
J6
J7
J8
J9
K1
K2
L1
L2
L3
M1
M2
N1
N2
P1
P4
P3
P2
P5
R2 R1
R3
R4
R5
R6

22 MK-112
Revision 02/04, Effective Date February 19, 2004
23
MK-112 Revision 02/04, Effective Date February 19, 2004
MK-112 PARTS LIST
PARTS LIST:
Item Description Qty MK Part #
A Assembly, Accessories
A1 Blade, MK-200, 8x7/8 Arbor 1 137158Y
A2 5mm wrench 1 160529
A3 5mm Allen key 1 159979
A4 19mm wrench 1 160530
A5 Card, MK Warranty Registration (not shown) 1 155037
A6 Manual, MK-112 Owners (not shown) 1 160467
A7 Label, Do Not Return (not shown) 1 157063
B Assembly, Frame/Pan
B1 Frame / Pan Weldment 1 160531
B2 Plug, Rubber Drain 1 160532
B3 Leg, Stand LT 1 160533
B4 Leg, Stand RT 1 160534
B5 Foot, Rubber 4 160535
B6 Label, MK-112 Title 1 160468
B7 Screw, Hex HD 5/16-18X1-1/2 4 152467
B8 Nut, Hex Nylock 4 158289
B9 Washer, 5/16 SAE Flat 8 151754
C Assembly, Table
C1 Table, MK 112 2 160536
C2 Knob, MK 112 Table 4 160537
C3 Mats, MK 112 Table 4 160538
C4 Holder, Accessory 1 160539
C5 Label, Serial #, MK-112 1 160469
C6 Label, MK Service Info. 2 1/8 X 1-13/16 1 155038
D Assembly, Pivot Post
D1 Post, 112 (comp)
Post, 112 (raw)
2
2
160466
160417
D2 Screw, Soc HD Cap M8X1.25X50MM 4 160540
D3 Nut, Hex Flange M8 156624
D4 Washer, 5/16 SAE Flat 2 151754
D5 Washer, Fender 5/16 IDX 1.0 OD 2 151053
D6 Nut, Hex Nylock 5/16-18 2 158289
D7 Knob, 3/16-18 MK Angle Adjustment 2 160541
D8 Handle, MK 112 2 160542
D9 Guard, Large Splash 1 160543
E Assembly, Rail
E1 Rail, MK 112 1 160544
E2 Knob, MK 112 Cut Length Adjustment 2 160545
E3 Spacer, Length Adjustment 2 160546
E4 Guide, Length Adjustment 2 160547
E5 Screw, Hex HD M6 x 20mm 2 158158
E6 Wawher, Lock Split 5/16 6 151747
E7 Label, Warning, Read Owners 1 155806
E8 Label, Caution, GFCI 1 155678
E9 Screw, Hex HD M6 x 20mm 2 158158

24 MK-112
Revision 02/04, Effective Date February 19, 2004
25
MK-112 Revision 02/04, Effective Date February 19, 2004
MK-112 PARTS LIST (Cont...)
F Assembly, MK 112 Cutting Head
F1 Block, Rail Saw Bearing 1 160548
F2 Spring, Cutting Head 1 160549
F3 Shaft, Cutting Head 1 160550
F4 Washer, 5/16 SAE Flat 2 151754
F5 Bearing, Radial Ball TYPE 608 ABEC-1 6 160551
F6 Rail, Vertical Guide 1 160552
G Assembly, 115V Motor
G1 Motor, 115 Volt, 60Hz, 1 hp 1 160553
G2 Power, Water Pump 1 160554
G3 Relief, MK-112 Strain w/Lock Nut 1 160555
G4 Nut, Strain Relief Lock 1 160556
G5 Screw, Soc HD Cap M5 x 25mm 2 160557
G6 Cap, Motor 1 160558
G7 Nut, M5-.8 Hex 4 157405
G8 Fan, Motor 1 160559
G9 Handle, Motor 1 160560
G10 Cord, MK-112 Power 1 160561
H Assembly, MK 112 Switch
H1 Switch, MK 112 1 160562
H2 Screw, Pan HD PHIL 4M x 12mm 2 160563
H3 Sleeve, Wire 1 160564
H4 Plate, MK 112 Switch 1 160565
J Assembly, Inner Blade Guard
J1 Guard, MK 112 Inner Blade (comp) 1 160566
J2 Screw, Socket Cap M5 X 10mm 1 160567
J3 Valve, Water 1 160568
J4 Guard, Splash 1 160310
J5 Spray, Water, Bottom (Fem) 1 160569
J6 Spray, Water, Top (Male) 1 160570
J7 Spacer, Steel 1 160571
J8 Bushing, Blade Guard 1 160572
J9 Connector, Blade Guard 1 160573
K Assembly, Blade Guard
K1 Blade Guard, 112 (comp)
Blade Guard, 112 (raw)
1
1
160438
160437
K2 Nut, Hex Flange M5 2 160574
L Assembly, Water Pump
L1 Pump, Water 1 160575
L2 Adapter, Brass 1 160576
L3 Hose, Vinyl 1 160577
M Assembly, MK 112, Slide Protractor
M1 Protractor, MK 112 Sub-assembly 1 160578
M2 Knob, Protractor 1 160579

24 MK-112
Revision 02/04, Effective Date February 19, 2004
25
MK-112 Revision 02/04, Effective Date February 19, 2004
MK-112 PARTS LIST (Cont...)
N Assembly, Antenna
N1 Holder, Antenna 1 160580
N2 Antenna 1 160581
P Assembly, Back Stop
P1 Stop, Left 1 160582
P2 Stop, Right 1 160583
P3 Screw, Soc HD Cap M5 x 8mm 5 160584
P4 Nut, Hex Flange M5 4 160585
P5 Ruler, Stop 1 160586
R Assembly, Side Table
R1 Table, MK-112 Side 1 160588
R2 Mats, MK-112 Table 3 160538
R3 Stop, Right 2 160583
R3 Screw, Soc HD Cap M5 x 8mm 4 160584
R4 Nut, Hex Flange M5 4 160585
R6 Leg, MK-112 Side Table 1 160589
