MO-EL BLACKLIGHT Series User guide
Classe I - IP55
MO-EL S.r.l.
Via Galvani, 18
42027 Montecchio Emilia (RE)
ITALY
tel +39 (0522) 868011
fax +39 (0522) 864223
BLACKLIGHT
RISCALDATORE A RAGGI INFRAROSSI
INFRARED HEATER
USO E MANUTENZIONE
USE AND MAINTENANCE
EMPLOI ET ENTRETIEN
GEBRAUCH UND WARTUNG
USO Y MANTENIMIENTO
USO E MANUTENÇÃO
9
1. IMPORTANT SAFETY INSTRUCTIONS
Instructions should be carefully read before installation and retained by the
user. The booklet must be keeped and delivered to the new user in case
of cession of the machine. The Manufacturer reserves the right to vary the
features of the product without prior notice. The technical data are merely
indicative.
1. This appliance is intended solely for the use it has been designed
for, namely room and people heating. The Manufacturer is not
responsible for any damage that could happen for improper use.
2.
shows no signs of visible damage or tampering.
3.
children.
4. The device can be used by children at least 8 years (as well as by
persons with reduced physical, sensory or mental capabilities, or
under surveillance, or after they have been instructed relating to
the safe use and have understood the potential dangers. Children
should not play with the appliance. Cleaning and maintenance
must be performed by the user and not by unsupervised children.
5. -
ously supervised.
6. Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed in
its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a
7. Children aged from 3 years and less than 8 years shall not plug
in, regulate and clean the appliance or perform user maintenance.
8.
the same as indicated on the device and the line supply is corre-
sponding to the effective rules.
9.
10. Some fundamental rules which apply to all electrical devices must
EN USE AND MAINTENANCE
10
be observed when using the heater:
Do not touch the heather with wet hands.
Do not handle with bare feet.
Do not let children play with the electrical appliance.
11. Avoid the use of an extension cord with this product, because the
12.
13. Keep connections dry.
14. If the power supply cord is damaged, avoid to use the appliance.
For power cord replacing, please contact the manufacturer or the
15. If the appliance is not used for a long period, disconnect it from
the power supply.
16. Always disconnect the appliance before doing any maintenance
operation.
CAUTION - Some parts of this product can become very hot and
cause burns. Particular attention has to be given where children
and vulnerable people are present.
2. ELECTRICAL INSTALLATION
The installation should always be carried out by a qualified electri-
cian or a competent person in accordance with the current electri-
cal standards:
HD 384 CENELEC for Mainland Europe, IEC 60446 and BS 7671
for the United Kingdom, IEC 60445(2010) & ET101:2008 for Ireland
and IEC 60364-7-708 1988 Internationally.
The energy supply to the heater must always be properly earthed.
The appliance must be connected to energy supply line by means
of the provided H05SS-F silicone cable.
An overvoltage category III Combined Circuit breaker and Residual
Current Device (RCD) with rated earth leakage operation not ex-
ceeding 30mA must be fitted upstream on the supply line. The
circuit breaker must have a contact opening distance of at least 3
mm.
The heaters should always be installed only using the mounting
11
Under no circumstances turn the appliance on if it is on any sur-
face.
The appliance must not be recessed in the ceiling. There must be
enough space around the top of the appliance to ensure adequate
the appliance.
A minimum air gap of 30 cm should always be allowed between
the top of the heater and a ceiling or roof. The appliance should be
A safety distance of not less than 100 cm should always be left in
This unit should be mounted at a minimum of 180 cm above ground
180 cm, according with the rules of each Country.
The appliance must not be located neither directly below, nor in
The heater must be installed so as to prevent that the switches can
be touched from those who are in the shower.
-
bustible material or curtains coming into contact with the heater,
or lie near the heater.
The product is in class I and IP55, wich is the protection rate for
of the appliance, the connection of the appliance with the power
supply must be done by means of a minimum IP55 system, as per
the standards HD 384 CENELEC for Europe, or international IEC
60346-7-708 1988.
3. FITTING
Before being used, the heater must be fixed to the wall or to the
ceiling by means of the provided supports, as described below. Be-
fore drilling the holes for the dowels, be sure that the wall is solid
and that you are far from water tubes or electrical wires. Be sure
that the heater is not facing the ceiling or inflammable materials.
12
1. Drill four holes in the wall, following the dimensions in the table
below:
7815 7818 7824 7832
104 (*)
800 (**)
104 (*)
950 (**)
104 (*)
1300 (**)
104 (*)
1600 (**)
Hole spacing (mm)
The value of wheelbase 104 (*)
must be respected, while those
relating to the distance between
recommended.
2.
3. -
ance, inserting and sliding them into the the longitudinal slots.
4. Join together the parts previously set, adjusting at the same
time the inclination of the appliance positioning on both sides the
screws shown in Figure 2 - pos. C.
3:
Twin (cod. 7704)
End to end (cod. 7705)
Extension (cod. 7706)
4. USE
-
tween 1500 W and 3200 W, suitable for heating private homes as
well as public premises (restaurants, pubs).
The appliances can be used indoors and outdoors (patios, verandas,
balconies).
13
failures it is necessary to operate the unit for a few hours every 6
months.
This heating appliance does not feature a device to control ambient
temperature. Do not use it in small rooms used by people who are
unable to leave such rooms on their own unless they are under con-
stant surveillance.
All users should be made aware of all aspects of operation and safety and
these instructions should be retained for reference.
If necessary, change the angle of inclination by acting on the lateral
Do not use the heater directly near a bathtub, a shower, a swimming
pool. In unoccupied premises it is recommended that the heating
system is switched off and isolated from the electrical supply.
14
Models with remote control
In models with remote control, the operation is performed as fol-
lows:
1. Insert two 1.5 V - AAA type batteries (not included) into the re-
mote control, matching the polarities.
2. Connect the appliance to the power supply: the blue LED lights.
3. Operate the remote control as shown in the picture
OFF: switching-off of the appliance.
HIGH: selection of the maximum power:
the red LED lights.
MED: selection of 2/3 of the power:
the violet LED lights.
LOW: selection of 1/3 of the power:
the blue LED lights.
ON: switching-on of the appliance, which
reaches the power set at the time of the
last shutdown.
Wait 15-20 minutes after power to reach the maximum temperature.
5. CARE AND CLEANING
Before cleaning, be sure the appliance is disconnected from the
power supply and allowed to cool. Never immerse the appliance in
water or any other liquid.
all parts are dry before using again.
Avoid the use of harsh detergents, solvents, and abrasive or aerosol
cleaners as they may damage surfaces.
15
6. TECHNICAL SERVICE
If you have any question relevant your appliance, call the local author-
original spare parts.
7. TECHNICAL FEATURES
7815 7818 7824 7832
Power supply
Power 1500 W 1800 W 2400 W 3200 W
Insulation Class I I I I
Protection level IP55 IP55 IP55 IP55
Emission IR-C IR-C IR-C IR-C
8. ENVIRONMENTALLY COMPATIBLE DISPOSAL OF THE APPLI-
ANCE
This product conforms to EU Directive 2002/96/EC.
This appliance bears the symbol of the barred waste
bin. This indicates that, at the end of its useful life,
it must not be disposed of as domestic waste, but
-
trical and electronic equipment, or returned to a re-
tailer on purchase of a replacement.
It is the user’s responsibility to dispose of this appli-
ance through the appropriate channels at the end of
its useful life. Failure to do so may incur the penalties
established by laws governing waste disposal.
49
Fig. 1
50 cm
( min )
180 cm (min)
30 cm (min)
50
Fig. 2
