Mocka 140120 User manual

Kids Dolls House
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
Hardware Supplied
large screw
x22
B
dowel
x2
C
medium screw
x6
D
small screw
x16
Phillips screwdriver required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
WARNING: Due to the small size of the hardware and the
sharp points of the screws, they are potentially hazardous.
Keep all assembly parts and packaging materials out of
reach of children
Retain packaging information for future reference
Adult assembly required
Recommended age 24 months +

12
Kids Dolls House
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Insert 2 x dowels (B) into panel [10]. Attach panel [5] and [11] together and secure with 2 x screws (A).
Tighten with a screwdriver.
B
B
10
A
A
11
5

3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach panel [10] to panel [11] and secure with 1 x screw (A). Tighten
with a screwdriver.
Attach panel [8] to panel [10] and [5] and secure with 3 x screws (A).
Tighten with a screwdriver.
Kids Dolls House
4
A
10
11
A
A
A
10
8
5

5
4
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Kids Dolls House
6
Slide panels [7] and [9] between panels [8] and [11] as shown. Attach panel [6] to panels [8] and [11] and secure with 4 x screws (A).
Tighten with a screwdriver.
7
9
8
11
A
A
A
A
11
8
6

5
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Kids Dolls House
Attach panel [4] to panels [5] and [6] and secure with 2 x screws (A).
Tighten with a screwdriver.
Attach panel [3] to panels [5] and [6] and secure with 2 x screws (A).
Tighten with a screwdriver.
78
4
A
A
6
5
3
A
A
6
5

6
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Kids Dolls House
Attach panel [1] to panels [3] and [4] and secure with 4 x screws (A).
Tighten with a screwdriver.
Attach panel [2] to panels [3] and [4] and secure with 4 x screws (A).
Tighten with a screwdriver.
910
1
AAAA
4
3
AA
A
A
2
4
3

7
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Kids Dolls House
Attach 4 x panel [5] to panel [1] and secure with 4 x screws (D). Tighten
with a screwdriver.
11 12
D
D
D
D
1
5
55

8
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Kids Dolls House
Attach 4 x panel [6] to panel [2] and secure with 4 x screws (D). Tighten
with a screwdriver.
Attach 4 x panel [6] to panel [4] and secure with 4 x screws (D). Attach
panel [3] to panel [4] and secure with 1 x screw (C). Tighten with a
screwdriver. Repeat this step for the second chair.
13 14
6
6
6
6
6
6
6
6
DD
D
D
2
D
D
D
D
C
Chair x 2
3
4

9
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Kids Dolls House
Attach panel [7] and panel [9] to panel [8] and secure with 4 x screws
(C). Tighten with a screwdriver.
Place the furniture in the desired locations. To move the Dolls House,
lift into place, do not drag.You're done, enjoy!
15 16
CC
CC
7
9
8
